Seconique LIGHT OAK EFFECT VENEER LISBON 3 DRAWER... User manual

LIGHT OAK EFFECT VENEER
PLEASE READ BEFORE YOU CONTINUE FURTHER
THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY
YEARS OF SERVICE IF YOU FOLLOW THE GUIDELINES FOR ITS
SAFE ASSEMBLY AND PERIODIC MAINTENANCE AND CLEANING.
ASSEMBLE ON A SOFT CLEAN SURFACE.
DO NOT USE ANY TOOLS OTHER THAN THOSE SHOWN.
ANY SPANNERS OR ALLEN KEYS REQUIRED ARE INCLUDED WITH
THE FITTINGS KIT.
DO NOT FOR ANY REASON USE A POWER TOOL TO ASSEMBLE
THIS PRODUCT. ITS USE WILL INVALIDATE ANY CLAIM YOU MAY
HAVE AND COULD MAKE THIS PRODUCT UNSAFE.
DEPENDING ON THE AMOUNT OF USE THIS PRODUCT RECEIVES
IT MAY BE NECESSARY TO TIGHTEN UP THE FIXINGS FROM TIME
TO TIME. THIS IS COMPLETELY NORMAL FOR ANY FLAT PACK
FURNITURE. DO NOT OVERTIGHTEN FIXING.
FOR CLEANING, YOU MAY USE A DAMP CLOTH (NOT WET) DO NOT
USE POLISH, DETERGENT OR CHEMICAL CLEANERS.
THE SURFACE OF THIS ITEM IS NOT HEAT RESISTANT. ALWAYS
USE A PLACE MAT UNDER HOT OR COLD ITEMS TO PREVENT
MARKING.
FOR DOMESTIC USE ONLY
IMPORTANT
LISBON 3 DRAWER CHEST
ASSEMBLY INSTRUCTIONS
Page 01
SEC/SH/01/21/EU2
DO NOT
USE

1
5
PART LIST
Part Number Part Code Part Description Quantity Carton
1
2
3
4
5
6
S100-102-064-EU1-01
Back Crossbar
Left Side Panel
Base Front Apron
Upper Front Crossbar
Right Side Panel
11/1
1
1
1
1
1
1/1
1/1
1/1
1/1
1/1
S100-102-064-EU1-02
S100-102-064-EU1-03
S100-102-064-EU1-04
S100-102-064-EU1-05
S100-102-064-EU1-06
6
7
8Drawer Back
Back Panel 2
3
1/1
1/1
S100-102-064-EU1-07
S100-102-064-EU1-08
Top Panel
Page 02
SEC/SH/01/21/EU2
9
11
10
Left Side Drawer
Right Side Drawer 1/1
1/1
S100-102-064-EU1-09
1/1
S100-102-064-EU1-10
S100-102-064-EU1-11
12
13 Drawer Bottom Support Rail
Drawer Base
3
1/1
1/1
S100-102-064-EU1-12
S100-102-064-EU1-13
Drawer Front
7
7
12
3
3
3
3
13
3
9
8
11
2
4
10

HARDWARE LIST
A
B
C
D
E
F
G
H
I
DOWEL 6x30MM
BOLT M6x50MM
DRAWER RUNNER A (L&R)
HANDLE
CAM BOLT+CAM NUT 10 SETS
TACK
2 PCS
22 PCS
J
L
M
N
O
P
Q
SCREW M4 X 16MM
2 PCS
4 PCS
PLASTIC FOOT
ANTI - TIP STRAP
ALLEN KEY
HANDLE SCREW 19MM
6 PCS
SCREW M4 X 38MM
PLASTIC H STRIP
28 PCS
4 PCS
43 PCS
12 PCS
(SCREWDRIVER NOT PROVIDED)
USE A FLAT HEAD SCREWDRIVER TO TIGHTEN THE CAM NUTS. A QUARTER TURN CLOCKWISE IS ALL THAT IS NEEDED.
STEP 1 - PUSH CAM BOLT INTO INSERT
STEP 2 - ALIGN THE CAM BOLT WITH THE HOLE AND PUSH TOGETHER UNTIL FLUSH. ( MAKE SURE THE ARROW OF
THE CAM LOCK IS POINTING TOWARD ON THE EDGE OF THE PANEL.)
STEP 3 - THE HEAD OF THE BOLT GOES INTO THE WIDE MOUTH OF THE CAM LOCK. YOU THEN TURN THE LOCK SO
THE NARROW PART CLOSES OVER THE BOLT.
Page 03
SEC/SH/01/21/EU2
3 PCS
1 PC
6 PCS
6 PCS
6 PCS
K DRAWER RUNNER B (L&R)
SCREW M4 X 30MM
32 PCS
2 PCS
1 PC
R
BOLT M7x60MM
SCREW M3.5x16MM
SCREW M3.5x12MM

STEP 1
PARTS REQUIRED
1 - LEFT SIDE PANEL x1
HARDWARE REQUIRED
A
H04
STEP 2
04
PARTS REQUIRED
2 - UPPER FRONT CROSSBAR x1
J06
N24
TOOLS REQUIRED
HARDWARE REQUIRED
A
H04
06
TOOLS REQUIRED
A
SEC/SH/01/21/EU2
UP SECOND HOLE
FRONT BACK
LAST SECOND HOLE
FIRST HOLE
H
N
J
5 - RIGHT SIDE PANEL x1
1
5
3 - BASE FRONT APRON x1
4 - BACK CROSSBAR x1
6 - TOP PANEL x1
6A
A
H
2
4
3
A
Page 04

Page 05
SEC/SH/01/21/EU2
C
STEP 3
PARTS REQUIRED
1 - LEFT SIDE PANEL x1
HARDWARE REQUIRED
B
C02
STEP 4
01
PARTS REQUIRED
2 - UPPER FRONT CROSSBAR x1
TOOLS REQUIRED
HARDWARE REQUIRED
TOOLS REQUIRED
2 - UPPER FRONT CROSSBAR x1
3 - BASE FRONT APRON x1
4 - BACK CROSSBAR x1
1
B
B
C02
01 5
C
B
3
2
4

STEP 6
Page 06
SEC/SH/01/21/EU2
STEP 5
PARTS REQUIRED
HARDWARE REQUIRED
TOOLS REQUIRED
6 - TOP PANEL x1
PARTS REQUIRED
7 - BACK PANEL x2
HARDWARE REQUIRED
TOOLS REQUIRED
H
6
7
E
I
N
7
E22
I01
N08

STEP 7
STEP 8
Page 07
SEC/SH/01/21/EU2
PARTS REQUIRED
PARTS REQUIRED
HARDWARE REQUIRED
TOOLS REQUIRED
A12
F12
X3
HARDWARE REQUIRED
TOOLS REQUIRED
D04
O04
O
D
8 - DRAWER BACK x3
9 - LEFT SIDE DRAWER x3
10 - RIGHT SIDE DRAWER x3
11 - DRAWER FRONT x3
H06
A
F
H
X3
8
10
9
11

STEP 9
STEP 10
Page 08
SEC/SH/01/21/EU2
PARTS REQUIRED
HARDWARE REQUIRED
TOOLS REQUIRED
PARTS REQUIRED
HARDWARE REQUIRED
TOOLS REQUIRED
A06
13 - DRAWER BOTTOM SUPPORT RAIL x3
G
11 - DRAWER FRONT x3
12 - DRAWER BASE x3
E21
G03
H06
M06
12
E
X3
H
M
X3
X3
X3
D18
K06
L06
L
DA
11
X3
13
K

STEP 11
STEP 12
Page 09
SEC/SH/01/21/EU2
PARTS REQUIRED
HARDWARE REQUIRED
TOOLS REQUIRED
X3
R
02
PART REQUIRED
HARDWARE REQUIRED
Q
02
TOOLS REQUIRED
WARNING
Wall fixings are not supplied with this product as different wall
materials require different types of fixing devices.Please make
sure you use fixings suitable for the walls in your home.
Serious or fatal injuries can occur from furniture tipping
over. To prevent the furniture from tipping over we
recommend that it is permanently fixed to the wall.
Q
R
TOP
TOP
WALL
Q
WALL
TOP
