Winners Only T1-DF3648N Series User manual

TBS-17556-SNNWC MADE IN MALAYSIA
Page 1 of 3
PARTS LIST
T1-DF3648N--F / T1-DF3648N--X
SOLID TOP B'FLY EXT. TABLE
PART NO FIGURE DESCRIPTION QTY
Legs
Table Top 1 pce
4 pcs
T1-DF3648N--F-01 /
T1-DF3648N--X-01
T1-DF3648N--F-07 /
T1-DF3648N--X-07
T1-DF3648N--F-07 /
T1-DF3648N--X-07
T1-DF3648N--F-13 /
T1-DF3648N--X-13
T1-DF3648N--F-13 /
T1-DF3648N--X-13
Hardware Bag 1 pce
IMPORTANT NOTE : Please keep all hardware parts out of the reach of children.

Unlock Hook
TBS-17556-SNNWC MADE IN MALAYSIA
Page 2 of 3
Flat
Washer
Lock
Washer Hex Bolt
Wrench
Turn the table top upside down on a soft protective surface such as carpet. Attach the table leg to the
corner of the apron by using the provided hardware as shown on Fig1. Repeat same step to the others
legs.
ASSEMBLY :
STEP 1
Fig.1
T1-DF3648N--F / T1-DF3648N--X
SOLID TOP B'FLY EXT. TABLE
Reminders :
Two people are needed for assembly.
Use only hardware supplied.
Do not over tighten bolts.
This item may require periodic tightening.
HARDWARE PART :
Wrench
Flat Washer
Lock Washer
1 pc
8 pcs
Hex Bolt
8 pcs 8 pcs
STEP 2
Lift both leaves from the compartment.

CARE INSTRUCTION
~ Be sure to use the same type of polish consistenly.
Your furniture will appear cloudy or streaky if oil
based or wax based polishes are interchanged.
~ Spray your furniture surface evenly. Wipe in a
circular motion with a soft clean cloth.
IMPORTANT NOTE :
~ Please keep all hardware out of the reach of
children.
Lock Hook
TBS-17556-SNNWC MADE IN MALAYSIA
Page 3 of 3
STEP 4
STEP 3
T1-DF3648N--F / T1-DF3648N--X
SOLID TOP B'FLY EXT. TABLE
Push table top from both ends to close.Lock the hooks underneath the table.
Flip up the aprons and unfold leaf and place the leaf on the table top surface carefully.
