Securefast ADP324-FR User manual

Page 1 of 4
ADP324-FR
Overview
The Securefast ADP324-FR power supply is a switched-mode power supply with an internal fire relay and is ideal for
powering magnetic door retainers, door locking devices that do not require battery back-up, and general 24VDC
applications. It also has with a normally closed, voltage-free output for signalling status and serviceability of the unit.
The ADP324-FR power supply provide a nominal 24VDC when powered from a 230V AC supply and has the following
features:
-Power OK ON LED, indicating normal operation
-4 X LED’s show status of relay and its outputs
-Electronic overload protection with automatic reset
-Highly efficient power conversion
6 The Cedars Business Park
Avon Road, Cannock, Staffordshire, WS11 1QI
24VDC 500mA Switched-mode power supply, ideal
for powering magnetic fire door retainers and
general 24VDC applications
Installation Manual

Page 2 of 4
Securefast ADP324-FR
The Securefast ADP324-FR supply unit is a 24VDC switched-mode 500mA power supply with an integral fire relay fitted and connected.
It is specially designed to power magnetic fire alarm door retainers and general 24 Volt DC applications. It is supplied in a very
compact and attractive, 1.5mm steel housing, powder-coated, spray painted and heat-treated to provide a durable, wipe-clean
surface. It is secured by a single screw lid fixing for ease of servicing. The 24VDC output is designed for the highly inductive loads
that magnetic door retainers present, eliminating the need for additional control relays and reducing the chance of an
‘electrical spike’ causing problems. The ADP324-FR is protected by intelligent electronic fuses with automatic reset to reduce
system downtime, and it features unique, protective technology, including intelligent and capacitive load switching, surge
protection and snubbing. The ADP324-FR can handle up to 4 double doors with 8 magnetic door retainers, based on 50
mA each.
Installation
•Mount the housing onto the wall.
•Connect the Live, Earth and Neutral terminals to an un-switched fused spur.
•Connect the Fire relay to the system. This can be used to provide Volt free relay or a 24VDC switched output.
•Set the jumper VR for power out or VF if a volt free switching relay is required.
•Relay switches when A to B is closed .
•For voltage-free switch, use C (common) and either NO (Normally Open) or NC (Normally Close)
•Switch on the 230VAC supply and confirm that the Power OK LED is lit and that the appropriate relay LED’s are also lit.
External Power Supply (AC Supply)
The power supply has a three-way terminal block for Live, Earth and Neutral connections. When supplied, earth is connected to
the metal enclosure and the lid earthed with a flying push-fit lead.
24V Power Output
Terminal blocks are provided to connect to systems. The output is floating and can be referenced to earth, if required. It is short
circuit and overload electronically protected and is suitable for switching highly inductive loads.
‘OK ‘ LED
The OK LED, when lit, will indicate if the mains voltage and the 24VDC output are both present.
Knock-out sizes and positions on the housing
Maintenance
There are no serviceable parts. No maintenance is required other than routine periodic testing.
Please note that high voltage is present under the cage –handle with care. Do NOT touch. Do NOT remove the cage.

Page 3 of 4
Layout and connections - ADP324-FR fire relay connections
12/24V + in -
OK
out1
VR
SW
+ -NO0V NC COMA SW B
To equipment
Un-switched 24 VDC
output fused 5 Ampere F1
To PSU
output
24 VDC
Connections DFR-1-24 relay
23112021 V1.0
VF
Switched output 24 VDC
NC=Normally closed
NO= Normally open
Fused 5 Ampere F2
Jumper setting
VF=Volt Free
VR=Volt through relay
VR
Switched input
To relay or switch. volt free
contact required to switch
LED’s
LED IN
Green when power is present/on
LED OUT1
Green when power present on OUT1
If off and power ok on Input check fuse.
SW
Green when switched input A to B is closed
Electronically fused
To reset remove power for 10 seconds
Fire relay or switching relay
Can be used to provide Volt free relay or 24 switched output.
Set the jumper VR for power out or VF if a volt free switching
relay is required. Relay switches when A to B is closed
For Voltage free switch use C (common) and either NO
(Normally Open) or NC (Normally Close)
Also Available in 5 and 12 volt versions DFR-1-5 or DFR-1-12

Page 4 of 4
Specification
Output
DC voltage
24VDC
Voltage tolerance
±1%
Rated current
0.5A
Current range
0~0.5A
Rated power
12W
Ripple & noise
120mVp-p
DC voltage ADJ. range
±10%
Input
Voltage range
90~264VAC
Frequency
47~65Hz, 125~373VDC
AC current
0.25A/115VAC o.15A~373VAC
Efficiency
81%
Inrush current
Cold start 15A/115V. 30A/230VAC
Leakage current
<0.25mA/240VAC
Protection
Over-load
Rated power output 115%-135% start overload protection
Protection type: hiccup mode, auto recovery after fault is removed
Over-voltage
125%~150%
Protection type: hiccup mode, auto recovery after fault is removed
Environment
Working temp, humidity
-10℃~+60℃，20%~90%RH
Storage temp, humidity
-20℃~+85℃，10%~95%RH non-condensing
Withstand vibration
10~500HZ，2G 10min/1cycle，period for 60 minutes, each axis
Safety
Withstand voltage
I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC
Isolation resistance
I/P-O/P, I/P-FG, O/P-FG:100Mohms/500VDC
Standards
Safety standard
Compliance to UL1012
EMC standard
Compliance to EN55022, Class A
Others
Dimensions (h x w x d)
Module = 48 x 28 x 21mm; Housing = 178 x 110 x 68mm
Weight/packing
Module 0.08kg; Housing 1.09 kg
