Security Camera King EL2MPIR250L30X User manual

Auto Tracking Speed Dome Web3.0 Operation Manual
Version 4.0.0

i
Table of Contents
1Network Connection ...................................................................................................................1
1.1 Preparation.....................................................................................................................1
1.2 Log in ..............................................................................................................................1
1.3 Live Interface .................................................................................................................3
1.4 Encode Setup ................................................................................................................3
1.5 Video Window Setup ....................................................................................................4
1.6 System Menu.................................................................................................................5
1.7 Video Window Function Option ..................................................................................5
1.8 PTZ Control....................................................................................................................6
1.9 PTZ Setup/Menu ...........................................................................................................7
2Setup...........................................................................................................................................10
2.1 Camera .........................................................................................................................10
2.1.1 Video......................................................................................................................10
2.1.2 Audio......................................................................................................................15
2.2 IVS.................................................................................................................................16
2.2.1 Global Setup.........................................................................................................16
2.2.2 Scene Setup .........................................................................................................17
2.2.3 Rule Setup ............................................................................................................21
2.2.4 Parameter..............................................................................................................31
2.3 Network.........................................................................................................................32
2.3.1 TCP/IP...................................................................................................................32
2.3.2 Connection............................................................................................................35
2.3.3 PPPoE ...................................................................................................................36

ii
2.3.4 DDNS.....................................................................................................................37
2.3.5 IP filter....................................................................................................................38
2.3.6 SMTP （e-mail）.................................................................................................39
2.3.7 UPnP......................................................................................................................41
2.3.8 SNMP.....................................................................................................................42
2.3.9 Bonjour ..................................................................................................................44
2.3.10 Multicast .........................................................................................................45
2.3.11 IEEE802 .........................................................................................................46
2.3.12 Qos..................................................................................................................47
2.4 Event .............................................................................................................................48
2.4.1 Video detect..........................................................................................................48
2.4.2 Alarm......................................................................................................................53
2.4.3 Abnormity..............................................................................................................55
2.5 Storage .........................................................................................................................58
2.5.1 Record schedule and snapshot schedule........................................................58
2.5.2 Destination............................................................................................................58
2.5.3 Record control......................................................................................................60
2.6 System..........................................................................................................................61
2.6.1 General..................................................................................................................61
2.6.2 Account..................................................................................................................64
2.6.3 PTZ.........................................................................................................................68
2.6.4 Default....................................................................................................................69
2.6.5 Import/Export........................................................................................................70
2.6.6 Auto maintenance................................................................................................71
2.6.7 Firmware update..................................................................................................71
2.7 Information ...................................................................................................................72
2.7.1 Version...................................................................................................................72
2.7.2 Log..........................................................................................................................72
2.7.3 Online User...........................................................................................................73
3Alarm...........................................................................................................................................75
4Log out........................................................................................................................................76

iii
Important
zThe following functions are for reference only. Some series products may not
support all the functions listed below.
zUsually we recommend IE 7 or higher version. For those versions below IE 7, it
may not support the operation of some functions.
zIf it is your first time to login the WEB on the WINDOWS 7 OS or higher, please
login as the administrator.

1
1Network Connection
1.1 Preparation
This series speed dome product supports the Web access and management via PC.
Web includes several modules: monitor channel preview, PTZ control, system configuration, alarm and
etc.
Please follow the steps listed below for network connection.
zMake sure the speed dome has connected to the network properly.
zSpeed dome IP address and PC IP address shall be in the same network segment. If there is router,
please set the corresponding gateway and subnet mask.
zUse order ping ***.***.***.***(* speed dome address) to check connection is OK or not.
1.2 Log in
Open IE and input speed dome address in the address bar.
For example, if your device IP is 192.168.1.108, then please input http:// 192.168.1.108 in IE address
bar. See Figure 1-1.
Figure 1-1
The login interface is shown as below. See Figure 1-2.
Please input your user name and password.
Default factory name is admin and password is admin.
Note: For security reasons, please modify your password after you first login.
Input your IP
address here

2
Figure 1-2
If it is your first time to login in, system pops up warning information to ask you whether install control
webrec.cab or not. Please click OK button, system can automatically install the control. When system is
upgrading, it can overwrite the previous Web too.
If you can’t download the ActiveX file, please check whether you have installed the plug-in to disable the
control download. Or you can lower the IE security level. See Figure 1-3.
Figure 1-3

3
1.3 Live Interface
After you logged in, you can see the live monitor window. Now you can operate the speed dome via the
WEB. See Figure 1-4.
Figure 1-4
There are six sections:
zSection 1: Encode setup bar
zSection 2: Window adjust bar
zSection 3: System menu bar
zSection 4: Window function option bar
zSection 5: PTZ control
zSection 6:PTZ setup/menu
1.4 Encode Setup
The encode setup interface is shown as in Figure 1-5.
Figure 1-5
Please refer to the following sheet for detailed information.
Parameter Function
Main stream In normal network width environment, main stream can record
audio/video file and realize network monitor.

4
Sub (Extra)
stream If network width is not sufficient, you can use sub stream to
realize network monitor. It is to reduce network bandwidth
usage.
Protocol You can select video monitor protocol from the dropdown list.
There are three options: TCP/UDP/Multicast.
1.5 Video Window Setup
The interface is shown as in Figure 1-6.
Figure 1-6
Please refer to the following sheet for detailed information.
SN Parameter Function
1 Image
control Click it to open picture setup interface. See Figure 1-7. This
interface is on the top right pane.
2 Original
size Click this button to go to original size. It is to display the actual
size of the video. It depends on the resolution of the video.
3 Full screen Click it to go to full-screen mode. Double click the mouse or
click the Esc button to exit the full screen.
4 Width and
height ratio Click it to restore original ratio or suitable window.
5 Open/close
PTZ Left click it to display or hide the PTZ control interface.
The picture setup interface is shown as in Figure 1-7.
1 2 3 4 5

5
Figure 1-7
Please refer to the following sheet for detailed information.
Parameter Function
Brightness setup icon. It is to adjust
monitor video brightness.
Contrast setup icon. It is to adjust
monitor video contrast ness.
Saturation setup icon. It is to adjust
monitor video saturation.
Hue setup icon. It is to adjust
monitor video hue.
Video
setup
Reset Restore brightness, contrastness
saturation and hue to system default
setup.
Note:
zAll the operations here
apply to WEB end
only.
zPlease go to Setup-
>Camera->Conditions
to adjust brightness,
contrast, hue and
saturation setup.
1.6 System Menu
System menu is shown as in Figure 1-8.
Please refer to chapter 1.3 Live, chapter 2 Setup, chapter 3 Alarm, chapter 5 Log out for detailed
information.
Figure 1-8
1.7 Video Window Function Option
The interface is shown as below. See Figure 1-9.

6
Figure 1-9
Please refer to the following sheet for detailed information.
SN Parameter Function
1/2 Alarm
output Click it to generate an alarm output.
There are two alarm output icons since this series product
supports two relay output.
Please note the alarm output interface may vary due to
different series products.
3 Digital
zoom When video is in original status, click this button you can
select any zone to zoom in. After zoom in ,you can drag the
zoom in area in the specified area. Right click mouse system
restores original status. You can use the wheel to zoom out
the video.
4 Snapshot
You can snapshoot important video.
You can go to Setup->Camera->Video->Path to modify the
local record save path.
5 Triple snap Click it, system can snap at 1f/s for three times. All images
are memorized in system storage folder.
6 Record When you click local record button, the system begins
recording.
You can go to Setup->Camera->Video->Path to modify the
local record save path.
7 Manual
Track Click it and then left click the mouse and drag the mouse in
the video window to select any zone, you can enable the
speed dome to auto track the object in the specified area.
Please note, you need to go to the Setup->IVS setup->Global
setup interface to enable IVS auto track function. Otherwise,
this function is null.
8 Audio
output Turn on or off audio when you are monitoring.
You can go to Setup->Camera->Audio to set.
9 Bidirectional
talk Click it to begin audio talk. You can go to Setup->Camera- >Audio to set bidirectional talk mode.
10 Help Click it to open help file.
1.8 PTZ Control

7
Before PTZ operation, please make sure you have properly set PTZ protocol. (Please go to Setup-
>System->PTZ to set.).
Here you can view direction keys, speed, zoom, focus, iris button. See Figure 1-10.
zPTZ direction: PTZ supports eight directions: left/right/up/down/upper left/upper right/bottom
left/bottom right./fast positioning.
zSpeed: The step 8 speed is faster than step 1.
Figure 1-10
1.9 PTZ Setup/Menu
The PTZ setup/Menu interface is shown as in Figure 1-11.
Figure 1-11
Click PTZ set button, the interface is shown as in Figure 1-12.Here you can set scan, preset, tour
pattern, assistant function and etc.

8
Figure 1-12
Please refer to the following sheet for PTZ setup information.
Parameter Function
Scan zClick Setup button, you can set scan left and right limit.
zUse direction buttons to move the camera to you desired
location and then click left limit button. Then move the camera
again and then click right limit button to set a right limit.
Preset zInput the preset value and then click Preset button, the camera
turns to the corresponding position of the preset.
zClick the Set preset button, you can set a preset. Use direction
keys to move the camera to your desired location and then input
preset value. Click add button, you have set one preset.
zThe preset value varies due to different protocols.
Tour zClick the Setup button, you can begin set tour.
zInput tour value and then click the Set button. The tour value
ranges from 1 to 255. (It may vary due to different protocols.)
zInput preset value in the column. Click Add preset button, you
have added one preset in the tour.
Note:
Repeat the above procedures you can add more presets in one tour.
Or you can click delete preset button to remove one preset from the
tour.
Pattern You can input pattern value and then click start button to begin PTZ
movement. Please go back to Figure 1-10 to implement camera
operation. Then you can click stop button in Figure 1-12. Now you
have set one pattern.
Assistant Please input the corresponding aux value here.
You can select one option and then click AUX on or AUX off button.

9
Parameter Function
Light and
wiper You can turn on or turn off the light/wiper.
Goto It is the accurate positioning function. Please input corresponding
horizontal angle, tilt angle, and speed dome zoom speed and then
click Go to button to go to a specified position. One unit of the
horizontal angle or tile angle stands for 0.1 degree.
Rotation Begin or stop speed dome rotation movement.
The Menu button can control the OSD for detailed speed dome or PTZ setup. See Figure 1-13.
Figure 1-13

10
2Setup
2.1 Camera
2.1.1 Video
2.1.1.1 Video bit stream
The video bit stream interface is shown as below. See Figure 2-1.
Figure 2-1
Please refer to the following sheet for detailed information.
Parameter Function
Main
stream Bit stream type It includes general stream, motion stream and alarm
stream. You can select different encode frame rates for
different recorded events.
The frame rates of the motion detect and alarm is
customized.

11
Parameter Function
Encode mode There are four options: H.264, H.264B, H.264H, and
MJPEG encode mode.
zH.264 : Main Profile encode mode.
zH.264B :Baseline Profile encode mode.
zH.264H: High Profile encode mode.
zMJPEG: In this encode mode, the video needs
general large bit stream to guarantee the video
definition. You can use the max bit stream value in
the recommend bit to get the better video output
effect.
Resolution There are multiple resolutions. You can select from the
dropdown list.
For each resolution, the recommended bit stream value
is different.
Frame Rate
(FPS) PAL: 1～25f/s，NTSC: 1～30f/s..
The frame rate may vary due to different resolutions.
Bit Rate Type There are two options: VBR and CBR.
Please note, you can set video quality in VBR mode.
In MJPEG mode, the bit stream control mode can only
be CBR.
Recommended
Bit Recommended bit rate value according to the resolution and frame rate you have set.
Bit Rate zIn CBR, the bit rate here is a fixed value.
zIt is the max value in VBR mode.
I Frame Here you can set the P frame amount between two I
frames. The value ranges from 1 to 150. Default value
is 50.
Recommended value is frame rate *2.
Important
I frame interval setup is null if it is the MJPEG
encode mode.
Watermark This function allows you to verify the video is tampered
or not.
The max length is 128-digit. The character can only
include number, character, underline and hyphen.
Enable Please check the box here to enable extra stream
function.
This function is enabled by default.
Sub
stream
Bit stream type General bit stream.

12
Parameter Function
Encode mode There are four options: H.264, H.264B, H.264H, and
MJPEG encode mode.
zH.264 : Main Profile encode mode.
zH.264B :Baseline Profile encode mode. H.264B is
mainly for Blackberry cell phone to realize the
monitor. You need to enable the sub stream
function in your camera and set the resolution as
CIF. Then you can monitor via the Blackberry cell
phone.
zH.264H: High Profile encode mode.
zMJPEG: In this encode mode, the video needs
general large bit stream to guarantee the video
definition. You can use the max bit stream value in
the recommend bit to get the better video output
effect.
Resolution There are multiple resolutions. You can select from the
dropdown list.
For each resolution, the recommended bit stream value
is different.
Frame Rate
(FPS) PAL: 1～25f/s，NTSC: 1～30f/s..
The frame rate may vary due to different resolutions.
Bit Rate Type There are two options: VBR and CBR.
Please note, you can set video quality in VBR mode.
Recommended
Bit Recommended bit rate value according to the resolution and frame rate you have set.
Bit Rate zIn CBR, the bit rate here is a max value. In dynamic
video, system needs to lower frame rate or video
quality to guarantee the value.
zIt is null in VBR mode.
zPlease refer to recommended bit rate for the detailed
information.
I Frame Here you can set the P frame amount between two I
frames. The value ranges from 1 to 150. Default value
is 50.
Recommended value is frame rate *2.
Important
I frame interval setup is null if it is the MJPEG
encode mode.
2.1.1.2 Snapshot

13
The snapshot interface is shown as in Figure 2-2.
Figure 2-2
Please refer to the following sheet for detailed information.
Parameter Function
Snapshot type There are two modes: general (schedule) and Event
(activation).
General (schedule) snapshot is to snap in the specified period.
Event (Activation) snapshot Is to snap when the motion detect,
camera masking, local alarm event occurrence.
If you want to use this function, please make sure:
zThe event occurred during the specified period.
zMotion detect, video masking, local alarm and
corresponding snap function are all enable.
Image size It has relationship with the resolution of the main stream.
Quality It is to set the image quality. There are six levels.
Interval It is to set snapshot frequency. The value ranges from 1s to 7s.
2.1.1.3 Video Overlay
The video overlay interface is shown as in Figure 2-3.

14
Figure 2-3
Please refer to the following sheet for detailed information.
Parameter Function
Privacy mask zHere you can privacy mask the specified video in the monitor
video.
zSystem max supports 4 privacy mask zones.
Time Title zYou can enable this function so that system overlays time
information in video window.
zThere is no time title if you do not enable this function here.
zYou can use the mouse to drag the time tile position.
Channel Title zYou can enable this function so that system overlays channel
information in video window.
zThere is no channel title if you do not enable this function
here.
zYou can use the mouse to drag the channel tile position.
Refresh After you successfully set privacy mask zone, channel title,
time title, you can click Refresh button to video the effect.

15
2.1.1.4 Path
The storage path interface is shown as in Figure 2-4.
Here you can set snap image saved path ( in the preview interface) and the record storage path
(in the preview interface).The snap picture default setup is C:\PictureDownload and record file
default setup is C:\RecordDownload.
Please click the Save button to save current setup.
Figure 2-4
2.1.2 Audio
The audio interface is shown as below. See Figure 2-5.
Important
Please make sure you have enabled the video function, otherwise you can not enable the audio
function.
Figure 2-5

16
Please refer to the following sheet for detailed information.
Parameter Function
Audio enable zMain stream: Recorded file only contains video by default.
You need to check the audio box here to enable audio
function so that the main stream the network transmitted is
audio/video composite stream.
zSub (Extra) stream: Recorded file only contains video by
default. You need to check the audio box here to enable
audio function so that the extra stream the network
transmitted is audio/video composite stream.
Encode mode The encode mode of the main stream and extra stream include
PCM, G.711A and G.711Mu.
The setup here is for audio encode mode and the bidirectional
talk encode both.
2.2 IVS
2.2.1 Global Setup
The global setup interface is shown as in Figure 2-6.
Figure 2-6
Please refer to the following sheet for detailed information.
