Securitytronix ST-WD600PTZMINI-IR User manual

1
INSTALLATION MANUAL
ST-WD600PTZMINI-IR
Vandalproof Infrared Intelligent Dome PTZ
Color Camera

2
PACKAGE CONTENTS
This package contains:
One ST-WD600PTZMINI-IR vandalproof infrared intelligent dome color camera
One installation manual
Note: The ST-WD600PTZMINI-IR requires a minimum 12VDC 700mA power supply such as the
ST-PS12VDC1A or ST-PS12VDC2A.
PRODUCT DESCRIPTION
The ST-WD600PTZMINI-IR is a professional grade infrared indoor dome color camera with pan,
tilt and zoom (PTZ) capability of 600TVL of resolution. The camera’s full digital design allows the
saving of all settings in non-volatile memory. The camera features include a 4mm –9mm varifocal
lens.
SPECIFICATIONS
ST-WD600PTZMINI-IR
Specifications (Typical)
1. Image Sensor
1/3” SONY Super HAD CCD II
2. Resolution
600TVL
3. Lens
4mm –9mm varifocal lens
4. Effective Picture Elements
811x508
5. Minimum Illumination
0.001 Lux
6. Scanning System
2:1 interface
7. Video Output
1.0VP-P, 75Ω
8. Signal to Noise Ratio
>48dB
9. Synchronous System
Internal, Negative synch
10. Auto Electronic Shutter
1/60s ~ 1/100,000s
11. Gama Correction
0.45
12. Auto Gain Control
Auto
13. Power
DC12V 700mA
14. Operating Relative Humidity
95% maximum
15. Operating Temperature
14°F –113°F
16. Dimensions
5.3”x5.6”
17. Weight
3.2 lbs

3
INSTALLATION AND OPERATION
CAUTION: To reduce the risk of electrical shock do not remove the cover or back of this
unit. No user serviceable parts are inside.
CAUTION: To prevent electric shocks and risk of fire hazards, do not use other than
specified power source.
1. UNPACKING and HANDLING
Each unit is shipped assembled and factory tested.
Ensure that all accessories are removed from the container before discarding packing material
2. MECHANICAL INSPECTION
Inspect the front and rear of the equipment for shipping damage. Make sure the equipment is
clean, and no connectors are broken, damaged, or loose. If equipment appears to be
damaged or defective please contact your distributor or SecurityTronix at 1-610-429-1511 for
assistance.
3. SPECIAL ATTENTION
a. The installer must comply with electrical safety standards. There must be sufficient
space between the camera’s power supply and video line and any high voltage
equipment and/or cables.
b. To help ensure the camera’s life and proper operation do not point the camera
towards the sun or strong light.
c. Do not install the camera in an environment where the temperature is above 113°F.
d. Do not install the camera near a magnetic field or a high-power motor.
e. Do not mount the camera near a radiator or heater.
f. Only use a dry cloth to clean the camera. If there is dirt that is difficult to remove wipe
gently with a mild detergent. Never use strong or abrasive detergents.
g. A minimum 12VDC 700mA power supply must be used. AC power cannot be applied.
Using an AC or other incorrect power supply will damage the camera.
h. Only qualified installers are allowed to install, test and disassemble the camera.
i. The camera is a low voltage product. If installed outdoors proper safety and lightening
grounding are required.
This symbol is intended to alert the user to the presence of important operating and
maintenance (servicing) instructions.
This symbol is intended to alert the user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electrical shock.

4
4. WIRING CONNECTIONS
a. Connect the power supply’s DC plug to the camera’s power outlet.
b. Connect the camera to the monitor with a 75Ωcoaxial video cable.
c. Connect unshielded twisted pair (UTP) control cable between the camera’s RS485
port and the PTZ controller. Be sure wire polarities are the same at each connection.
The camera’s violet wire (A) is + positive and the white wire (B) is –negative.
d. Connect power supply’s AC plug to a suitable AC power outlet.
e. Adjust the lens direction according to the required surveillance area and environment.

5

6
5. TROUBLESHOOTING
a. No picture after applying power –(i) check all plugs and cables are securely
connected to the proper connectors; (ii) ensure your power supply is providing the
correct voltage and current.
b. The picture has ripples –(i) check to see if the power supply is experiencing AC ripple,
if so a filter may be required; (ii) determine if the monitor is faulty; (iii) determine if
other peripheral equipment is causing ripple and if so make the necessary
adjustments.
c. The picture background continuously changes color –a fluorescent lamp’s magnetic
field may cause color roll, therefore, reduce the number of fluorescent lamps or
increase the distance between the camera and the lamps.
d. The picture appears smeared –(i) the power supply voltage level may be unstable,
therefore, try another power supply; (ii) ensure the cables are correctly connected
and/or the cables are of the correct impedance.
e. Other interference may require a SecurityTronix ground loop isolation filter.
f. Power is on, but the controller does not work –(i) check to make sure the DIP
switches for address and communications baud rate are properly set, (ii) check to
ensure the RS485 connections at the camera and the PTZ Controller have the same
polarity, (iii) check the integrity and continuity of the unshielded twisted pair (UTP)
control cable.
g. Additional troubleshooting assistance can be found on-line at www.securitytronix.com
in addition to support from SecurityTronix sales engineers at 1-610-429-1511.
