sedia systems Mercury User manual

May 2017
Assembly Instructions Mercury

The Mercury auditorium seating system is intended to be
used in a commercial setting. The system consists of the
following components:
• Right Arm Standard
• Left Arm Standard
• Center Arm Standard
• ADA Arm Standard
• Gravity Uplift Seat
• Standard Seat Back
• High Seat Back
• Optional Tablet
• Power System
Note: Read these assembly instructions carefully prior to
product installation. Electrically interconnected furnishings
must also be mechanically interconnected. Product failure
and personal injury may result if instructions are not
followed.
TOOLS REQUIRED
• Hammer drill and 1/4” masonary bit for concrete
anchor holes
• Drill and bit for pilot holes in wood floor
• #3 Phillips head screw driver
• #2 Phillips head screw driver
• Wrench Set
• Socket Set
• Allen Wrench
• 4’ Level
• 6-8’ Flexible straight edge 1/4 round or
equivalent
• 25 and 100’ Tape Measure
• Tailor’s Chalk
• Mercury Drill Template
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical furnishing, basic precautions
should always be followed, including the following:
Read all instructions before installing the Mercury Chair
WARNING:
1. Risk of Electrical Shock - Connect this furnishing
to a properly grounded outlet only.
See Grounding Instructions.
2. Do not use outdoors.
3. Use this furnishing only for its intended use
described in these instructions. Do not use
attachments not recommended by the
manufacturer.
4. The maximum intended load for this seat is 300
pounds (102 Kilograms).
5. Functional Tablet Load - 20 Pounds (9 kg)
GROUNDING INSTRUCTIONS
This product must be connected to a grounded metal,
permanent wiring system, or an equipment-grounding
conductor must be run with the circuit conductors and
connected to the equipment-grounding terminal or lead
on the product.
Note: The power infeeds are to be connected to the
power source by a qualified electrician who must also
check the electrical integrity of the finished system
installation.
SAVE THESE INSTRUCTIONS
CAUTION
!
Assemble units only as described herein. Failure to
do so may result in instability or assembly failure. All
screws, nuts and bolts must be tightened securely
and must be checked periodically after assembly.
Failure to assemble properly, or to secure parts may
result in personal injury.
INTRODUCTION
WHITE
GREEN/BARE
RED
BLACK
GROUND
HOT-2
HOT-1
NEUTRAL-1
CIRCUIT 1
I
CIRCUIT 2
II
WARNING
RISK OF FIRE OR ELECTRIC
SHOCK. DO NOT
ELECTRICALLY CONNECT
TO MORE THAN ONE SOURCE
OF SUPPPLY. ALL SOURCES
MUST BE DISCONNECTED
PRIOR TO ANY SERVICING
SEDIA SYSTEMS, INC.
CHICAGO, IL
*NOT FOR INTERRUPTING CURRENT*
2
Mercury Auditorium Seating
Assembly Instructions

Wood Floors
• Minimum two layers of 3/4” thick plywood
• APA rated grade plywood
• Allow minimum embedment 1-1/2” with lag screws
• Use toggle bolt if less than 1-1/2” embedment
Concrete Floors
• 3000 psi concrete compressive strength
• 3“ thick free of obstruction for 1-1/2”
• Minimum anchor embedment 1-1/2”
Note: Warranty null and void if Sedia Systems MERCURY
Seating product line is installed on flooring that does not
meet the minimum structural requirements stated above.
FLOOR FASTENER REQUIREMENTS
Wood Floors
• 3/8” x 2-1/2” lag bolts
• 3/8” flat washers
• (2) Bolt assemblies required per arm standard
Concrete Floors
• 1/4” x 2-5/8” concrete anchors
• 3/8” flat washers
• (2) Bolt assemblies required per arm standard
CAUTION
!
Assemble units only as described herein. Failure to
do so may result in instability or assembly failure. All
screws, nuts and bolts must be tightened securely
and must be checked periodically after assembly.
Failure to assemble properly, or to secure parts may
result in personal injury.
MINIMUM CONSTRUCTION REQUIREMENTS
3
Site Preparation
1. Read and review the Assembly Instructions.
2. Review project drawings and layouts.
3. Locate floor center.
4. Locate row size line.
5. Draw size line for straight or radius rows.
6. Mark hole centerline for first chair.
7. Mark incremental hole centerline locations.
8. Use drill template to mark hole locations.
9. Use carpet punch at each hole location.
10. Locate and drill anchor holes into floor.
11. Vacuum holes to remove debris.
Chair Installation
12. Mount arms to the floor with anchor bolts.
13. Attach seat back to arms with attached brackets.
14. Attach seat pivot to arm brackets.
Steps for Installing Power Option
Before assembling seat:
1. Attach raceway bracket to arm tube.
2. Assemble the raceway to the raceway bracket.
3. Place the power whip into the raceway.
4. Connect the duplex outlet to the whip or jumper.
5. Attach the raceway end cap and splicer.
6. Complete power component installation per row
and connect duplex end plug to last duplex power
module.
7. Attach the raceway spacers at locations specified
on the layout drawings.
8. Attach the raceway cover so the outlet module fills
the outlet opening in the cover.
9. Attach seat pivot to arm brackets.
10. Connect electrical whip to the main power source.
11. Mount row and seat numbering (optional).
12. Clean product and site for walk through.
Note: Dimensional spacing referenced is centerline to
center line unless otherwise noted.
Mercury Auditorium Seating
Assembly Instructions
CAUTION
!
All power modules rated at 15A 120V 60HZ.
System capacity to be limited to 15A per
circuit.
No more than 12 outlets should be supplied by
one circuit.

1. All parts are lubricated for life.
2. Any service should be conducted by an authorized
service representative.
3. Perform periodic inspections for loose or broken parts.
LAMINATE:To clean the surface, use a damp cloth or
sponge and a mild soap or detergent. Difficult stains such
as coffee or tea can be removed using a mild household
cleaner and baking soda; mixing to achieve a paste
consistency. Use a stiff nylon bristle brush, scrubbing
(approx. 15-20 strokes) the affected area. Do not scrub so
as to mar (damage, scratch) the surface finish. Stubborn
stains that resist any of the above cleaning methods may
require the use of undiluted household bleach or nail polish
remover. Use a cotton ball saturated with bleach or nail
polish remover (acetone); gently rub the stain for up to two
minutes. Rinse thoroughly with warm water and wipe dry
using a soft cloth. This step may be repeated if the stain
appears to be going away and the color of the laminate
has not been affected.
CAUTION:
Prolonged exposure of the laminate and powder coat
surfaces to bleach will cause discoloration. Always rinse
laminate and powder coat surfaces after cleaning! Failure
to rinse after cleaning can cause damage; even if a small
amount of cleaning solution remains on the surface. A dry
residue may be invisible; however, moisture from cups or
drinks can reactivate it, and result in permanently etched
scars or stains over time.
Recommended Household Cleaners:
• Clorox®* • Formula 409® • Dawn® • Fantastik®
• Dow Bathroom Cleaner with Scrubbing Bubbles™
• Favor® • Windex® • Lestoil® • Glass Plus®
• Pledge® • Grease Relief® • Mr. Clean® • TOP JOB®
• Lysol® Brand Disinfectant Basin/Tub/Tile Cleaner
* Prolonged exposure can mar the surface
CAUTION:
Acidic or abrasive cleaners can damage laminate and
powder coat surfaces; do not use them. Drain cleaners
containing lye will permanently damage the laminate
surface. If you spill a drain cleaner, wipe it up immediately
and rinse several times with water. Hair, textile and food
dyes can cause permanent stains. If dye should happen to
spill, wipe it up immediately with dishwashing detergent or
an all-purpose cleaner. Wipe spills away promptly and rinse
several times with water.
CAUTION
!
Assemble units only as described herein. Failure to
do so may result in instability or assembly failure. All
screws, nuts and bolts must be tightened securely
and must be checked periodically after assembly.
Failure to assemble properly, or to secure parts may
result in personal injury.
ROUTINE CARE AND MAINTENANCE
4
Rust removers contain harsh chemicals, which will quickly
cause permanent damage. If a spill occurs, wipe off all
residues immediately, wash thoroughly with soapy water
and rinse several times. Steel wool and other abrasive pads
will damage the laminate and powder coat face. Do not use
them for cleaning and don’t store steel wool pads on your
countertop; the metal can rust and leave stains. Toilet bowl
cleaners contain harsh chemicals that can cause permanent
damage. If spills occur, wipe up immediately, wash surface
with soapy water and rinse several times.
The cleaners listed below can cause damage to the surface
of laminate:
Chemical Ingredient Synonymous Names
Hydrochloric Acid Muriatic Acid
Hydrogen Chloride
Sulfuric Acid Oleic Acid
Oil of Vitriol
Oleum
Hydrofluoric Acid Rust Remover
Phosphoric Acid Rust Remover
Sodium Hydroxide Caustic Soda
Caustic Soda Lye
Lye
Pumice (abrasive)
Remember, sharp objects can damage the surface of
laminate and powder coat surfaces, marring its beauty and
lowering wear and stain resistance. Although the laminate
and powder coat surfaces are somewhat resistant to
scratch and marring, they can be damaged, even under
normal use.
Laminate and powder coat surfaces may need occasional
dusting depending on where it’s used. To keep the surface
beautiful, use a non-oily furniture spray. (Remember to clean
the spray off several times a year to prevent build-up.)
Furniture polish can also help hide fine scratches in the
surface.
UPHOLSTERED FABRIC: Clean with water-based cleaning
agents, foam or pure water-free solvents. Vacuuming or light
brushing is recommended to prevent dust and soil buildup.
For answers to additional questions regarding care or
cleaning please contact Sedia Systems.
Mercury Auditorium Seating
Assembly Instructions

Wood Floors
• Minimum two layers of 3/4” thick plywood
• APA rated grade plywood
• Allow minimum embedment 1-1/2” with lag screws
• Use toggle bolt if less than 1-1/2” embedment
Concrete Floors
• 3000 psi concrete compressive strength
• 3“ thick free of obstruction for 1-1/2”
• Minimum anchor embedment 1-1/2”
Note: Warranty null and void if Sedia Systems MERCURY
Seating product line is installed on flooring that does not
meet the minimum structural requirements stated above.
FLOOR FASTENER REQUIREMENTS
Wood Floors
• 3/8” x 2-1/2” lag bolts
• 3/8” flat washers
• (2) Bolt assemblies required per arm standard
Concrete Floors
• 1/4” x 2-5/8” concrete anchors
• 3/8” flat washers
• (2) Bolt assemblies required per arm standard
CAUTION
!
Assemble units only as described herein. Failure to
do so may result in instability or assembly failure. All
screws, nuts and bolts must be tightened securely
and must be checked periodically after assembly.
Failure to assemble properly, or to secure parts may
result in personal injury.
MINIMUM CONSTRUCTION REQUIREMENTS
3
Site Preparation
1. Read and review the Assembly Instructions.
2. Review project drawings and layouts.
3. Locate floor center.
4. Locate row size line.
5. Draw size line for straight or radius rows.
6. Mark hole centerline for first chair.
7. Mark incremental hole centerline locations.
8. Use drill template to mark hole locations.
9. Use carpet punch at each hole location.
10. Locate and drill anchor holes into floor.
11. Vacuum holes to remove debris.
Chair Installation
12. Mount arms to the floor with anchor bolts.
13. Attach seat back to arms with attached brackets.
14. Attach seat pivot to arm brackets.
Steps for Installing Power Option
Before assembling seat:
1. Attach raceway bracket to arm tube.
2. Assemble the raceway to the raceway bracket.
3. Place the power whip into the raceway.
4. Connect the duplex outlet to the whip or jumper.
5. Attach the raceway end cap and splicer.
6. Complete power component installation per row
and connect duplex end plug to last duplex power
module.
7. Attach the raceway spacers at locations specified
on the layout drawings.
8. Attach the raceway cover so the outlet module fills
the outlet opening in the cover.
9. Attach seat pivot to arm brackets.
10. Connect electrical whip to the main power source.
11. Mount row and seat numbering (optional).
12. Clean product and site for walk through.
Note: Dimensional spacing referenced is centerline to
center line unless otherwise noted.
Mercury Auditorium Seating
Assembly Instructions
CAUTION
!
All power modules rated at 15A 120V 60HZ.
System capacity to be limited to 15A per
circuit.
No more than 12 outlets should be supplied by
one circuit.

1. All parts are lubricated for life.
2. Any service should be conducted by an authorized
service representative.
3. Perform periodic inspections for loose or broken parts.
LAMINATE:To clean the surface, use a damp cloth or
sponge and a mild soap or detergent. Difficult stains such
as coffee or tea can be removed using a mild household
cleaner and baking soda; mixing to achieve a paste
consistency. Use a stiff nylon bristle brush, scrubbing
(approx. 15-20 strokes) the affected area. Do not scrub so
as to mar (damage, scratch) the surface finish. Stubborn
stains that resist any of the above cleaning methods may
require the use of undiluted household bleach or nail polish
remover. Use a cotton ball saturated with bleach or nail
polish remover (acetone); gently rub the stain for up to two
minutes. Rinse thoroughly with warm water and wipe dry
using a soft cloth. This step may be repeated if the stain
appears to be going away and the color of the laminate
has not been affected.
CAUTION:
Prolonged exposure of the laminate and powder coat
surfaces to bleach will cause discoloration. Always rinse
laminate and powder coat surfaces after cleaning! Failure
to rinse after cleaning can cause damage; even if a small
amount of cleaning solution remains on the surface. A dry
residue may be invisible; however, moisture from cups or
drinks can reactivate it, and result in permanently etched
scars or stains over time.
Recommended Household Cleaners:
• Clorox®* • Formula 409® • Dawn® • Fantastik®
• Dow Bathroom Cleaner with Scrubbing Bubbles™
• Favor® • Windex® • Lestoil® • Glass Plus®
• Pledge® • Grease Relief® • Mr. Clean® • TOP JOB®
• Lysol® Brand Disinfectant Basin/Tub/Tile Cleaner
* Prolonged exposure can mar the surface
CAUTION:
Acidic or abrasive cleaners can damage laminate and
powder coat surfaces; do not use them. Drain cleaners
containing lye will permanently damage the laminate
surface. If you spill a drain cleaner, wipe it up immediately
and rinse several times with water. Hair, textile and food
dyes can cause permanent stains. If dye should happen to
spill, wipe it up immediately with dishwashing detergent or
an all-purpose cleaner. Wipe spills away promptly and rinse
several times with water.
CAUTION
!
Assemble units only as described herein. Failure to
do so may result in instability or assembly failure. All
screws, nuts and bolts must be tightened securely
and must be checked periodically after assembly.
Failure to assemble properly, or to secure parts may
result in personal injury.
ROUTINE CARE AND MAINTENANCE
4
Rust removers contain harsh chemicals, which will quickly
cause permanent damage. If a spill occurs, wipe off all
residues immediately, wash thoroughly with soapy water
and rinse several times. Steel wool and other abrasive pads
will damage the laminate and powder coat face. Do not use
them for cleaning and don’t store steel wool pads on your
countertop; the metal can rust and leave stains. Toilet bowl
cleaners contain harsh chemicals that can cause permanent
damage. If spills occur, wipe up immediately, wash surface
with soapy water and rinse several times.
The cleaners listed below can cause damage to the surface
of laminate:
Chemical Ingredient Synonymous Names
Hydrochloric Acid Muriatic Acid
Hydrogen Chloride
Sulfuric Acid Oleic Acid
Oil of Vitriol
Oleum
Hydrofluoric Acid Rust Remover
Phosphoric Acid Rust Remover
Sodium Hydroxide Caustic Soda
Caustic Soda Lye
Lye
Pumice (abrasive)
Remember, sharp objects can damage the surface of
laminate and powder coat surfaces, marring its beauty and
lowering wear and stain resistance. Although the laminate
and powder coat surfaces are somewhat resistant to
scratch and marring, they can be damaged, even under
normal use.
Laminate and powder coat surfaces may need occasional
dusting depending on where it’s used. To keep the surface
beautiful, use a non-oily furniture spray. (Remember to clean
the spray off several times a year to prevent build-up.)
Furniture polish can also help hide fine scratches in the
surface.
UPHOLSTERED FABRIC: Clean with water-based cleaning
agents, foam or pure water-free solvents. Vacuuming or light
brushing is recommended to prevent dust and soil buildup.
For answers to additional questions regarding care or
cleaning please contact Sedia Systems.
Mercury Auditorium Seating
Assembly Instructions

Arm Standards
Gravity Lift Seat
19 - 23 Inch Widths
Standard Back High Back
Arm Standard 1
• Left Side
• Right Side
• Center
Arm Standard 2
• Left Side
• Right Side
• Center
Tablet
6
System Components CAUTION
!
Assemble units only as described herein. Failure to
do so may result in instability or assembly failure. All
screws, nuts and bolts must be tightened securely
and must be checked periodically after assembly.
Failure to assemble properly, or to secure parts may
result in personal injury.
Mercury Auditorium Seating
Assembly Instructions

Standard Floor Mounted Chair CAUTION
!
Assemble units only as described herein. Failure to
do so may result in instability or assembly failure. All
screws, nuts and bolts must be tightened securely
and must be checked periodically after assembly.
Failure to assemble properly, or to secure parts may
result in personal injury.
5
1. Seat Back
2. Gravity Uplift Seat
3. Left Arm standard
4. Right Arm Standard
5. Raceway Bracket
6. Raceway
7. Raceway Splicer
8. Jumper Cable
9. Raceway Spacer
10. Duplex End Plug
11. Duplex Power Module
12. Raceway Cover
13. Power Whip
14. Raceway End Cap
1
2
6
7
8
5
9
10
13
14
12
11
3
4
Mercury Auditorium Seating
Assembly Instructions

Site Preparation CAUTION
!
Assemble units only as described herein. Failure to
do so may result in instability or assembly failure. All
screws, nuts and bolts must be tightened securely
and must be checked periodically after assembly.
Failure to assemble properly, or to secure parts may
result in personal injury.
8
Step 2: Refer to layout drawings and verify room
dimensions.
Step 1: Read and review the assembly instructions.
Step 3: Use tape measure to locate room center and
other reference dimensions and mark with chalk
Step 4: Use layout drawing to locate row size line from
back of riser and mark with chalk.
Step 5: Draw the size line. For radius floor, use
1/4 round or equivalent to get the radius size line.
Step 6: Mark hole locations of the first chair symmetric
the center line and according to the drawing.
MERCURY AUDITORIUM SEATING
Assembly Instructions
May 2017
Mercury Auditorium Seating
Assembly Instructions

9
Site Preparation CAUTION
!
Assemble units only as described herein. Failure to
do so may result in instability or assembly failure. All
screws, nuts and bolts must be tightened securely
and must be checked periodically after assembly.
Failure to assemble properly, or to secure parts may
result in personal injury.
Step 9: Punch carpet using hammer and punch.
Remove thread material and ensure drill area is free of
debris.
Step 10: Drill holes using 1/4” x 4” concrete drill bit.
Concrete Floor - 2 holes, Wood Floor - 2 pilot holes
only.
Step 11: Vacuum holes to remove wood/concrete
particles.
Step 7: Mark all hole locations by incrementing
dimensions sequentially as per drawing.
Step 8: Center drill template and mark hole locations.
Mercury Auditorium Seating
Assembly Instructions

Chair Installation
10
CAUTION
!
Assemble units only as described herein. Failure to
do so may result in instability or assembly failure. All
screws, nuts and bolts must be tightened securely
and must be checked periodically after assembly.
Failure to assemble properly, or to secure parts may
result in personal injury.
Step 11: Align base and fasten with wood or
concrete anchors.
Step 12: Assemble back by aligning bracket with holes
in arm standard. Tighten center seat backs with a box
wrench. Tighten end seat backs with a phillips head
screw driver
Step 13: Assemble seat with bolts to arm standard
brackets.
Mercury Auditorium Seating
Assembly Instructions

System Components
Power System
CAUTION
!
Assemble units only as described herein. Failure to
do so may result in instability or assembly failure. All
screws, nuts and bolts must be tightened securely
and must be checked periodically after assembly.
Failure to assemble properly, or to secure parts may
result in personal injury.
7
Jumper Cable
Lengths Based
on Layout Drawing
8 - 300 Inches
Cover
Lengths Based
on Layout Drawing
10 - 48 Inches
Raceway
Lengths Based
on Layout Drawing
17 - 72 Inches
Power Whip
72 - 300 Inches
Duplex Module End CapEnd Plug SplicerSpacer
Mercury Auditorium Seating
Assembly Instructions

11
Power System Installation CAUTION
!
Assemble units only as described herein. Failure to
do so may result in instability or assembly failure. All
screws, nuts and bolts must be tightened securely
and must be checked periodically after assembly.
Failure to assemble properly, or to secure parts may
result in personal injury.
Step 1: Before the seat is assembled, attach the
raceway bracket to the arm tube.
Step 2: Center the raceway and assemble to the
raceway bracket with #10x1/4” screws.
Step 4: Assemble the duplex outlet module and the
jumper cable to the power whip as per the layout
drawings.
Step 3: Assemble the power whip into the channel
through the access hole on the rear side of the
raceway.
Mercury Auditorium Seating
Assembly Instructions

12
Power System Installation CAUTION
!
Assemble units only as described herein. Failure to
do so may result in instability or assembly failure. All
screws, nuts and bolts must be tightened securely
and must be checked periodically after assembly.
Failure to assemble properly, or to secure parts may
result in personal injury.
Step 7: Assemble the raceway spacers per the layout
drawings. Attach with #8x1/2” screws.
Step 5: Attach splicer to continuing end of raceway
and the end cap to the power inlet side.
Step 6: Connect duplex end plug to end of last duplex
power module.
Step 8: Assemble the raceway cover so the duplex
outlet fills the hole and the cover overlaps the spacers.
Attach with #8x1/2” screws.
Mercury Auditorium Seating
Assembly Instructions

13
Power System Installation CAUTION
!
Assemble units only as described herein. Failure to
do so may result in instability or assembly failure. All
screws, nuts and bolts must be tightened securely
and must be checked periodically after assembly.
Failure to assemble properly, or to secure parts may
result in personal injury.
Step 9: Assemble seats with bolts to arm standard
brackets
Step 10: Have a qualified electrican connect the power
system whip to building power source per the
4-wire/2-circuit schematic.
Mercury Auditorium Seating
Assembly Instructions
