SeeEyes SC-IPC07PU User manual

Release Version 1.2
1Channel IP Over UTP Transmission Solution
SC-IPC07PU
User’s Manual
TRANSMITTER
RECEIVER

Release Version 1.2
1
Precaution and Safety Guidelines
The content of this guideline is to protect the safety of users and prevent property damage.
Be sure to read this user’s manual thoroughly and use the device correctly.
Warning (If you do not keep any of the below guidelines, you may get seriously injured or
cause somebody’s death.)
■Be sure to install the product after unplugging power cord. Also, do not use several
power plugs at the same time.
- It may cause abnormal heat, fire and electric shock.
■Do not leave the device at any place that water falls or splashes. Also, do not put anything
full of water such as a flower vase on the device.
- It may cause malfunction or fire if liquid goes into the device.
■Do not bend the power cord by excessive force. Make sure the power cord is not crushed by
heavy things.
- It may cause fire.
■Do not open the lid arbitrarily as this device has high voltage part inside. Never disassemble,
repair or modify it.
- By abnormal working, it may cause fire, electric shock and personal injury.
■Do not install this product in places with high humidity, dust, or soot.
- It may cause electric shock and fire.
■Do not tug at the power cord section or unplug the power plug with wet hands. If the power
cord is loose, do not plug in.
- There may be a risk of fire and electric shock.
■Always keep the location of the appliance clean during or after installation to prevent dust.
Especially when cleaning the device, wipe it with dry towel and do not use water, thinner or
organic solvent.
- It may damage the case of this device, and cause malfunction or electric shock.
■Keep the device in a cool place where doesn’t let direct sunlight. Keep it at a proper
temperature and avoid heating appliances like candle or heater. Also, keep the equipment or
tools away from places where people come and go.
- It may cause fire.
■Pay attention to possible hazards in the workplace, such as wet floor, ungrounded power
extension cables, old power cords and a lack of safety earth. Consult your place of purchase or
professional if problems arise.
- It may cause fire and electric shock.
■Concerning the input voltage for operating this device, a voltage range must be within 10%
of rated voltage, and the power outlet must be grounded. Also, do not use a heat source such
as a hair dryer, iron and refrigerator to the same power unit.
- It may cause abnormal heat, fire and electric shock.

Release Version 1.2
2
Caution (If you do not keep any of the below guidelines, you may get injured or suffer
property loss.)
■Proper ambient temperature and humidity are recommended.
- Avoid extremely high temperatures(over 50°C) or low(below -10°C), and humid conditions.
■Install in well ventilated place, and avoid direct sunlight or heat appliance.
■Be sure to plug the power cord with grounded outlet.
- There is a risk of electrical shock and personal injury.
■Do not use this device in close proximity to a device that produces strong waves such as
radio set(TRANCEIVER, Walkie-talkie, etc.) or repeater. It may affect the video signal, or cause
disorders such as noise or crack on the screen.
■Disconnect the power plug with care during thunder and lightning.
■When connecting cables, install as “U” shape in order to prevent rainwater/dew/fog from
getting into the product.
■Refer to the user’s manual for problems or questions besides the above. Contact our service
center if you need assistance from a professional technician.
■UTP(Unshielded Twisted Pair) Cable is for indoor use only. For outdoor use, it is
recommended to use STP(Shield Twisted Pair) Cable which is covered with shield.
- Use standard CAT.5e or higher UTP cable.
■Since this product has a PoE (Power Over Ethernet.) function, it may cause malfunction to the
connected device which doesn’t support PoE function. Make sure to read the user's manual
carefully before using this product.
■Make sure to separate general communication network (internet / in-house use, etc.) from
CCTV network.
- It may cause malfunction.
■Be careful not to change the network cable configuration.
- Refer to the cable wiring way below.
Network Cable Diagram
TIA / EIA 568B Type
Pin No.
Color
Function
1
White
Orange
TX+
2
Orange
TX-
3
White
Green
RX+
4
Blue
PWR+
5
White
Blue
PWR+
6
Green
RX-
7
White
Brown
PWR-
8
Brown
PWR-

Release Version 1.2
3
1. Introduction
1-1. Overview
SC-IPC07PU, which consists of 1CH Transmitter and 1CH Receiver, transmits Ethernet data and power
over one UTP cable. Its built-in power supply function (IEEE802.3at) operates a transmitter and a PoE
camera from the receiver side without separate power lines and it resolves short-distance typical
network system by transmitting Ethernet data in a long distance. Our solution is very cost-effective
by minimizing construction period and cost as you can replace your old UTP system to network by
keeping your UTP cable(CAT.5e).
1-2. Features
•Transmit Ethernet data Max. 800m over UTP cable (CAT.5e, 10Mbps)
•Supply power to PoE IP camera (PoE Type B / Max. 30W)
•Transmission bandwidth: Max. PHY Rate(Physical Layer Speed): 100 Mbps
•Auto MDI/MDIX function
•Auto diagnosis function for stable power supply
•PoE ON/OFF switch mounted on the transmitter
•Built-in surge protection circuit
2. Components
2-1. Transmitter
Transmitter
Bracket
RJ-45 Cable
Manual
2-2. Receiver
Receiver
DC 48V Adapter
(Option)
Power Cord
Bracket
Manual

Release Version 1.2
4
3. Product Parts and Functions
3-1. Transmitter
①CAMERA PoE: Switch to set power supply to PoE IP camera.
※In case of connecting PoE IP camera, set CAMERA PoE switch as ON.
※The factory setting for the PoE switch is ON.
※In case of connecting non-PoE IP camera, set CAMERA PoE switch as OFF.
②LED Indicator
Name
Color
Status
PWR
Red
On: Power input
Off: No power input
ETH
Green
Blinking: Ethernet connected
Off: Ethernet Not connected
LINK
Green
On: Connected to Receiver
Off: Not connected to Receiver
PoE
Red
On: PoE Input to IP camera
Off: No Poe input to IP camera
Blinking: IP camera overcurrent (short / open circuit)
※When turning the product on, the LED turns on sequentially first and the product is operated.
③RECEIVER SIDE: Port to connect Receiver and output video.
④CAMERA SIDE: Port to connect IP camera.
④
③
①
②

Release Version 1.2
5
3-2. Receiver
①NVR SIDE: Port to connect NVR or PoE Hub.
②TRANSMITTER SIDE: Port to connect Transmitter and input video.
③DC 48~56V IN: Port to input DC adapter (48V or 56V) power.
※PoE output and transmission distance may vary depending on the connected adapter.
④LED Indicator
Name
Color
Status
PWR
Red
On: Power input
Off: No power input
ETH
Green
Blinking: Ethernet connected
Off: Ethernet Not connected
LINK
Green
On: Connected to Transmitter
Off: Not connected to Transmitter
PoE
Red
On: PoE output to Transmitter
Blinking: Transmitter or cable overcurrent (short / open circuit)
⑤Bandwidth Select Switch: Support 100Mbps, 10Mbps setting
※10M: Transmit by 10Mbps (10Mbps over CAT.5e : 800m).
※100M: Transmit by 100Mbps (100Mbps over CAT.5e : 500m).
※When turning the product on, the LED turns on sequentially first and the product is operated.
⑤
①
②
③
④

Release Version 1.2
6
4. Connection Diagram
4-1. In case of connecting PoE IP Camera (TX’s PoE Switch ON)
<Installation Guide>
①Set Transmitter’s CAMERA PoE switch to ON. (PoE LED On)
※In case of connecting non PoE camera, set transmitter’s CAMERA PoE switch to OFF.
②After connecting IP CAMERA to Transmitter, connect UTP cable connected to Receiver.
③Connect UTP cable from Transmitter to Receiver. Connect Receiver to NVR or PoE Hub.
④Check the transmission distance and set the Bandwidth switch of Receiver to the corresponding
transmission bandwidth.
※10M: Transmit by 10Mbps (10Mbps over CAT.5e: 800m).
※100M: Transmit by 100Mbps (100Mbps over CAT.5e: 500m).
⑤Supply power by connecting DC Adapter (48V or 56V) to the DC Jack of the receiver. (Option)
⑥Check the camera’s video from the monitor connected to NVR.
※If connected properly, LINK LED on Tx and Rx is ON and ETH LED is blinking.
CAMERA PoE switch OFF

Release Version 1.2
7
5. Specifications
MODEL
Transmitter
Power Input
PoE (PoE input from Receiver)
Power Output
Midspan PoE (Type B Only, PoE SW On/Off available)
Transmission Bandwidth
100Mbps
Connection Port
RECEIVER SIDE
RJ-45 (TIA/EIA568B Type)
CAMERA SIDE
RJ-45 (TIA/EIA568B Type)
LED Indicator
PWR
RED LED
ETH
GREEN LED
LINK
GREEN LED
PoE
RED LED
CAMERA PoE SW
Slide Switch
Operating Temperature / Humidity
-10℃~ 50℃/ 0 ~ 80%
Case Body / Weight
ABS / 52g
Dimensions
76(W) x 55(H) x 24(D)
MODEL
Receiver
Power Input
DC 48V-56V/1A adapter or PoE HUB (IEEE 802.3at)
Power Output
PoE (DC 48V)
Power Consumption
DC 48V~56V/900mA
Max. Transmission Distance
100Mbps: 500m (CAT.5e)
10Mbps: 800m (CAT.5e)
Transmission Bandwidth
100Mbps
Connection
Port
TRANSMITTER SIDE
RJ-45 (TIA/EIA568B Type)
NVR SIDE
RJ-45 (TIA/EIA568B Type)
DC 48V-56V IN
DC-JACK
LED
Indicator
PWR
RED LED
ETH
GREEN LED
LINK
GREEN LED
PoE
RED LED
Bandwidth Select Switch
10M: 10Mbps, 100M: 100Mbps
Operating Temperature / Humidity
-10℃~ 50℃/ 0 ~ 80%
Case Body / Weight
ABS / 54g
Dimensions
76(W) x 55(H) x 24(D)

Release Version 1.2
8
6. Power Output (Calculated Value)
Cable Transmission
Distance (CAT.5e)
Transmission
Bandwidth
With
DC48V 1A Adapter
With
DC56V 1.16A Adapter
Cable Loop
Resistance
100m
100Mbps
30W
30W
18.2Ω
200m
100Mbps
17.2W
30W
36.2Ω
300m
100Mbps
11.4W
22W
54.7Ω
400m
100Mbps
8.6W
16.6W
72.9Ω
500m
100Mbps
6.86W
13.3W
90.8Ω
600m
10Mbps
5.8W
11.2W
111.1Ω
700m
10Mbps
4.9W
9.6W
128.7Ω
800m
10Mbps
4.2W
8.3W
147.4Ω
※The transmission distance may vary depending on the specification of camera and NVR.
※In case of using PoE function of the Transmitter, the transmission distance may vary depending on
the type of camera.
Especially, use exclusive adapter for cameras with high power consumption such as IP PTZ
cameras and the cameras with many IR LEDs.
※When transmitting cable distance of 500m or more, the camera input voltage may low.
Therefore, use DC56V adapter connected to the receiver.
7. Installation Precautions
※Use exclusive power adapter separately for each product. It is not recommended to use single
adapter for supplying power to several products.
※It is not recommended to place products in close or tie each other.
※It is not recommended to connect adapter to DC jack when supplying power to the Receiver by
PoE.
※When installing the product by supplying power by PoE, it is recommended to check the video
first and connect the ground of camera.
※When using a surge protector, the cable distance between camera and Receiver is recommended
to be within 50M.
※Use of LAN cable extension gender (coupler) may cause signal attenuation. It is not recommended
to use multiple extended gender connections.

Release Version 1.2
9
8. Trouble Shooting
Symptom
Checking Method
No Power
<Transmitter>
•Check if PoE LED on Receiver and PWR LED on Transmitter is ON.
•Check the connection status of UTP cable.
<Receiver>
•Check if the PWR LED is working properly.
•Check the input status of power adapter or PoE Hub.
•Check if the exclusive adapter is used.
No Video
•Please check if LINK LED is ON and ETH LED is flashing.
•Check if the transmission distance is within the recommended
value or not.
•Check if the Network cable’s wire arrangement is correct.
•In case of using PoE function on Transmitter, check if the PoE LED
is On. If LED is Off, set the PoE switch as ON.
No PoE
•Check the PoE switch status on Transmitter.
•Check if PoE LED on Transmitter is ON.
•Check if the Network Cable arrangement is correct.
•Check if the IP CAMERA supports PoE function.
Unstable Network
•Check if the Network Cable arrangement is correct.
•Check if there is Walkie-Talkie or any device which has strong
waves near the product.
•Check if the Network configuration is installed properly.
Unstable Video
•Check the connection status of UTP and Network cable.
•Check if the NVR is compatible with camera.
•Check the performance status of camera.

Release Version 1.2
10
9. Warranty Certificate
Product No.
Model No.
Date of Purchase
Place of Purchase
Purchaser
Name
Address &
Contact No.
Distributor
Name
Address &
Contact No.
Warranty Period
Two(2) years from the date of purchase
Any failure that occurs in the normal use for only two years after purchase will be
repaired free of charge.
Contact the phone number listed on the user’s manual for repair.
When reporting the failure, please inform the model name and condition of the
product accurately. It is convenient to know the name and department of the person
in charge.
Please check this user’s manual again before reporting the failure.
Product shapes and circuits are subject to change without notice to improve
performance.
Faults following will be treated as a charge:
✓Failure by user’s handling without care
✓Not connecting the rated power
✓Disassembled or repaired arbitrarily by user
✓Replacing consumables
✓Failure caused by natural disaster (lightning, fire, flood, tsunami, etc.)

Release Version 1.2
11
SeeEyes Co., Ltd
#5F, Sunil Technopia, 555 Dunchon-daero, Jungwon-gu,
Seongnam City, Gyeonggi Province, Korea (Zip Code: 13215)
TEL: [phone]
FAX: [phone]
EMAIL: [e-mail]
http://www.sscctv.com/eng
