AVGear AVG-HDWP70TX-IR User manual

AVG-HDWP70TX-IR
The
AVG
-
HDWP70TX
-
IR
is
a
Decora
style
transmitter that installs in a double-gang wall
plate to provide a convenient interface for HDMI
and VGA input sources
Features
Selectable HDMI/VGA with audio input
Supports VGAoutput resolutions up to 1920x1200
High bandwidth: 10.2Gbps
In-built scaler function, supports scaling of
HDMI/VGA signals to match the native
resolution of the display
Transmits HDMI signals up to 4K
Compliant with HDMI 1.4, supports 1080p 3D
HDCP compliant, equipped with HDCP auto-
tracking function
Provides auto-switching capability
Supports multiple control methods
including front panel buttons, IR, and
RS232, supports bi-directional IR &
RS232 pass-through control.
Supports firmware upgrading via USB.
DC 12V power output
Powered by local a power pack or PoC connection
up to 60m
Aluminum design for efficient better cooling

AVG-HDWP70TX-IR
PLEASE READ THIS PRODUCT MANUAL CAREFULLY
BEFORE USING THIS PRODUCT.
This manual is for operational use only, and not to be
used in a maintenance capacity. The functions
described in this version are current as at March 2015.
Any changes of functions and operational parameters
will be updated in future manual versions. Please refer
to your dealer for the latest product details.
Version 1.1 1/12/15

AVG-HDWP70TX-IR
SAFETY OPERATION GUIDE
In order to guarantee the reliable operation of the equipment and safety of the
user, please abide by the following procedures in installation, use and
maintenance:
1. The system must be earthed properly. Please do not use two blade plugs
and ensure the AC power supply ranges from 100v to 240v and from 50Hz
to 60Hz.
2. Do not install the switcher in an environment where it will be exposed to
extreme hot or cold temperatures.
3. This unit will generate heat during operation, please ensure that you allow
adequate ventilation to ensure reliable operation.
4. Please disconnect the unit from mains power if it will be left unused for a
long time.
5. Please DO NOT try to open the casing of the equipment, DO NOT attempt to
repair the unit. Opening the unit will void the warranty. There are high
voltage components in the unit and attempting to repair the unit could result
in serious injury.
6. Do not allow the unit to come into contact with any liquid as that could result
in personal injury and product failure.

AVG-HDWP70TX-IR
TABLE OF CONTENTS
Introduction ..............................................................................................................1
Introduction to the AVG-HDWP70TX-IR.......................................................1.1
Features.......................................................................................................1.2
Package List ................……………………………………………………………………2
Product Appearance................................................................................................3
Front Panel...................................................................................................3.1
Side Panel....................................................................................................3.2
Rear Panel....................................................................................................3.3
System Connection..................................................................................................4
System Application.......................................................................................4.1
Usage Precautions.......................................................................................4.2
System Diagram...........................................................................................4.3
Connection Procedure..................................................................................4.4
12V DC Output.............................................................................................4.5
PoC Solution.................................................................................................4.6
System Operations...................................................................................................5
IR Control.....................................................................................................5.1
RS232 Control..............................................................................................5.2
Connection with RS232 Communication Port.................................5.2.1
Installation of the RS232 Control Software.....................................5.2.2
Basic Settings.................................................................................5.2.3
RS232 Communication Commands ............................................................ 5.3
Firmware Update via USB............................................................................5.4
Specification.............................................................................................................6
Panel Drawing ..........................................................................................................7
Troubleshooting & Maintenance.............................................................................8

AVG-HDWP70TX-IR
1. Introduction
1.1. Introduction to the AVG-HDWP70TX-IR
AVG-HDWP70TX-IR is a Decora style transmitter that installs in a double-gang wall
plate to provide a convenient interface for HDMI and VGA input sources.
It has 1 HDMI IN, 1 VGA IN, 1 Audio IN and 1 HDBT OUT with PoC. It supports
VGA with a full HD scaler, and HDMI 1.4 with 4k & 3D. Input signals support auto-
switching. The HDBaseT output supports 60m UHD video transmission with PoC,
enables bi-directional IR and RS232 communication between HDWP70TX-IR and
a remote device.
With its PoC solution, the AVG-HDWP70TX-IR can be powered by a far-end PoC
receiver.
1.2. Features
 Selectable HDMI/ VGA with audio input
 Supports VGA output resolutions up to 1920x1200
 High bandwidth: 10.2Gbps
 Built-in scaler function, supports scaling HDMI and VGA signals to match
the native resolution of the display
 Transmits HDMI signals up to 4K
 Compliant with HDMI 1.4, supports 1080p 3D
 HDCP compliant, equipped with HDCP auto-tracking function
 Provides auto-switching capability
 Supports multiple control methods including front panel buttons, IR, and
RS232, supports bi-directional IR & RS232 pass-through control.
 Supports firmware upgrading via USB.
 DC 12V power output
 Powered by local power pack or PoC connection up to 60m
 Aluminum design for efficient cooling

AVG-HDWP70TX-IR
2. Package List
 1 x AVG-HDWP70TX-IR
 4 x Screws
 3 x Pluggable Terminal Blocks (1 2-pin block, 1 3-pin block, and 1 4-pin block)
 1 x Face Plate (Selectable)
 4 x Screws (for the face plate)
 1 x User Manual
Note: Please confirm if the product and the accessories are all included, if not,
please contact your dealer.

AVG-HDWP70TX-IR
3. Product Appearance
3.1. Front Panel
Note: Pictures shown in this manual are for reference only.
No. Name Description
① Power
indicator Illuminates red when power is on
② IR IN Connect with IR receiver, receive IR signals sent from
the IR Emitter connected to the far-end receiver
③ IR OUT Connect with IR Emitter, IR signals emitted from the IR
emitter are received by the IR receiver connected to
the far-end receiver.
④
RS232
Serial port, 3-pin pluggable terminal block, connects
with the control terminal to control the HDWP70TX-
IR, supports bi-directional RS232 control (send
control signal from local or receive control signal sent
from far-end devices).
⑤
VGA IN
Connect with a VGA source device.
The indicator:
 illuminates yellow when there is VGA signal input
 illuminates green when the signal source is chosen as

AVG-HDWP70TX-IR
input source
 turns off when there is no VGA input signal
⑥ AUDIO IN Connect with the audio output socket of the VGA source
device, delivers synchronous audio with the VGA signal
source when VGA is the source signal.
⑦
HDMI IN
Connect with HDMI source device.
The indicator will illuminate yellow when there is VGA
signal input and illuminates green when the signal
source is chosen as input source.
⑧
LINK
&HDCP
 LINK: Twisted Pair Link status indicator, illuminates
green when successfully connected.
 HDCP: HDCP compliance indicator, illuminates
green when the source signals is with HDCP; blinks
when it is not with HDCP; and turns off when there
is no source signal.
⑨ RESET Press the button to reboot HDWP70TX-IR.
⑩
FIRMWARE USB port, used for firmware updates
Plug a flash disk or other storage device with update file
(MERGE.bin), and send command 50698% to update
firmware.
Note: Pictures shown in this manual are for reference only.

AVG-HDWP70TX-IR
3.2. Side Panel
No. Name
Description
①
HDBT OUT RJ45 port, connect with receiver via a CAT5e/6 cable to
deliver Audio/ Video signals, supports PoC.
Note: Pictures shown in this manual are for reference only.
3.3 Rear Panel
No.
Name Description
①
Power In Power in port, 2-pin pluggable terminal block, connect with a
DC 12V power adapter
②
Power
Out Power out port, for powering 3
rd
party equipment
③
RS232 Serial port, connects with a far-end receiver, supports
bi-directional RS232 control (send control signal from local
TX or receive control signal sent from far-end devices).
Note: Pictures shown in this manual are for reference only.

AVG-HDWP70TX-IR
4. System Connection
4.1. System Applications
Reliable performance for control and transmission makes the AVG-HDWP70TX-IR
ideal in the IT computer space, signal monitoring, big screen displays, conference
systems, television broadcast, education, banking and security institutions etc.
4.2. Usage Precautions
1. System should be installed in a clean environment with temperature and humidity
maintained to within equipment specification.
2. All of the power switches, plugs, sockets and power cords should be insulated
and safe.
3. All devices should be connected before power is turned on.
4.3. Connection Diagram
Note: Pictures shown in this manual are for reference only.

AVG-HDWP70TX-IR
4.4. Connection Procedure
Step 1. Connect HDMI source device (e.g. Blu-ray DVD) to the HDMI input port of
the AVG-HDWP70TX-IR with HDMI cable. Connect a VGA source device
(e.g. PC) to the VGA input port of AVG-HDWP70TX-IR with VGA cable
Step 2. Connect an AVG-HD402PR to the HDBT port on the rear panel with
twisted pair.
Step 3. Connect a HDMI display to the HDMI OUT port of AVG-HD402PR
Step 4. Connect a control terminal to the RS232 port on the front panel of AVG-
HD402PR.
Step 5. Both AVG-HDWP70TX-IR and AVG-HD402PR have IR IN and OUT.
When one model is used for IR signal receiver, the IR signal must be
sent out by the other model.
For example: When “IR IN” of AVG-HDWP70TX-IR connects with
an IR receiver, the IR transmitter must connect to IR OUT of the
AVG-HD402PR.
The IR signal can be transmitted bi-directionally between the
AVG-HDWP70TX-IR and AVG-HD402PR.
Step 6. Connect a control device (e.g. PC) to the RS232 port of AVG-HDWP70TX-
IR or AVG-HD402PR (bi-directional RS232 control, either is available)
Step 7. Connect a DC 24V power adaptor to the power port of the AVG-HD402PR.
The AVG-HDWP70TX-IR is able to get power from the AVG-HD402PR
with the PoC solution.
Note: AVG-HDWP70TX-IR supports unidirectional PoC, i.e, AVG-HDWP70TX-IR
can get power from far-end PoC devices with the PoC function. However, it can’t
power a far-end PoC device when the power supply is connected to HDWP100TX-
IR.

AVG-HDWP70TX-IR
4.5. 12V DC Output
AVG-HDWP70TX-IR has a 12V power output port on the rear panel. Connect the
12V power output port of AVG-HDWP70TX-IR to the power port of a 3
rd
Party Device
for convenient localized powering.
Note: Pictures shown in this manual are for reference only.
4.6. PoC Solution
Note: Pictures shown in this manual are for reference only.

AVG-HDWP70TX-IR
5. System Operations
5.1. IR Control
AVG-HDWP70TX-IR provides an IR IN/ IR OUT socket for connection to an IR
receiver/ IR Transmitter to attain bi-directional IR transmission with the far-end
receiver.
1. Control the far-end output device from the local matrix location.
2. Control the local input/output device remotely.
5.2. RS232 Control
As RS232 can be transmitted bi-directionally between the AVG-HDWP70TX-IR
and AVG-HD402PR, enabling it to control a third party RS232 device locally or
control t h e AVG-HDWP70TX-IR remotely. When controlling a third party
RS232 device, the baud rate of this device should be 2400, 4800, 9600, 19200,
38400, 57600 or 115200 .
5.2.1 Connection with the RS232 Communication Port
As well as the front control panel, the AVG-HDWP70TX-IR can be controlled by a 3
rd
Part control system through the RS232 communication port. This RS232
communication port is a female 9-pin D connector. The definition of its pins is listed
in the table below.
No.
Pin
Function
1 N/C Unused
2 Tx Transmit
3 Rx Receive
4 N/C Unused
5 Gnd Ground
6 N/C Unused
7 N/C Unused
8 N/C Unused
9 N/C Unused

AVG-HDWP70TX-IR
5.2.2. Installation/Removal of RS232 Control Software
Installation Copy the control software file to the computer connected with the
Matrix.
Removal Delete all the control software files in corresponding file path.
5.2.3. Basic Settings
Firstly, connect the AVG-HDWP70TX-IR with an input device and an output device.
Then, connect it with a computer which is installed with RS232 control software.
Double-click the software icon to run this software.
Here we take the software CommWatch.exe as example. The icon is pictured as
below:

AVG-HDWP70TX-IR
The interface of the control software is shown below:
Please set the parameters of COM number, baud rate, data bit, stop bit and the
parity bit correctly, only then will you be able to send commands in the Command
Sending Area.
Parameter
Configuration area
Monitoring area,
indicates whether
the command sent
works.
Command Sending
area

AVG-HDWP70TX-IR
5.3. RS232 Communication Commands
Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none
Command Function Feedback Example
System Commands
50701% Switch to HDMI input Switch to HDMI
50704% Switch to VGA input Switch to VGA
50770% Enable auto-switching Auto Switching
50771% Disable auto-switching Manual Switching
Resolution Commands
50619% Change the resolution to 1360X768
HD
Resolution:
1360x768
50626% Change the resolution to 1024X768
XGA
Resolution:
1024x768
50627% Change the resolution to 1280X720
720P
Resolution:
1280x720
50628% Change the resolution to 1280X800
WXGA
Resolution:
1280x800
50629% Change the resolution to 1920X1080
1080P
Resolution:
1920x1080
50620% Change the resolution to1920X1200
WUXGA
Resolution:
1920x1200
50621% Change the resolution to1600X1200
UXGA
Resolution:
1600x1200
Setup Commands
502xx% Set the brightness to xx. XX ranges
from 00 to 99
Brightness: xx
503xx% Set the contrast to xx. XX ranges
from 00 to 99
Contrast: xx
504xx% Set the saturation to xx. XX ranges
from 00 to 99
Saturation: xx
505xx% Set the sharpness to xx. XX ranges
from 00 to 99
Sharpness: xx
50606% Auto-adjust the input parameter VGA Input Auto

AVG-HDWP70TX-IR
Command Function Feedback Example
50607%
Adjust the color temperature Color Temperature:
xx (xx
can be medium,
warm, user, or
cool)
50608% Set the aspect ratio Aspect Ratio: xx (xx
can be
16:9, 4:3, or auto.)
50614% Set the picture mode Picture Mode: xx (xx
can be dynamic,
standard, mild, or
user.)
50699% Check the system version Version Vx.x.x
50779% Switch to RS232 mode 1, enable
scaler to control far-end devices RS232 Mode 1:
RS232
Control Scaler &
Remote
50780% Switch to RS232 mode 2, enable
far-end devices to control scaler RS232 Mode
2:RS232 &
Remote Control
Scaler
50790% Set the HDCP status of HDMI output
socket to Active
HDCP Active
50791% Set the HDCP status of HDMI output
socket to On
HDCP On
50792% Set the HDCP status of HDMI output
socket to Off
HDCP Off
50698% Software update
50617% Reset to factory default
Query
Commands
50632% Check the output resolution Resolution: xx
50633% Check the picture mode Picture Mode: xx
50793%
Check HDCP status HDC
P Off
HDC
P On
HDCP Active

AVG-HDWP70TX-IR
Command Function Feedback Example
50635% Check the image aspect ratio Aspect Ratio: xx
50636% Check the brightness Brightness: xx
50637% Check the contrast Contrast: xx
50638% Check the saturation Saturation: xx
50639% Check sharpness Sharpness: xx
50640% Check the color temperature Color Temperature:
xx
Adjustment Commands
50678% Enable screen output adjusting Enter Output
Position Adjust
50679% Disable screen output adjusting Exit Output Position
Adjust
50670% Move the image to left Output Position
Adjust X xx
50671% Move the image to right Output Position
Adjust X xx
50672% Move the image up Output Position
Adjust Y xx
50673% Move the image down Output Position
Adjust Y xx
50674% Stretch left from left side (increase
image width)
Output Width Adjust
xx
50675% Pull right from left side (decrease
image width)
Output Width Adjust
xx
50676% Stretch upwards from bottom side
(decrease image height)
Output Height Adjust
xx
50677% Stretch downwards from bottom side
(increase image height)
Output Height Adjust
xx
EDID Commands
50772% EDID pass-through EDID: bypass mode
50773% Set EDID data to 1080P PCM
2.0ch
EDID:1080P&PCM
2ch
50774% Set EDID data to 1080P Dolby 5.1 EDID:1080P&5.1ch
50775% Set EDID data to 1080P3D Dolby
5.1
EDID:1080P3d&5.1c
h

AVG-HDWP70TX-IR
Command Function Feedback Example
50776% Set EDID data to 1080i PCM 2.0ch EDID:1080i&PCM
2ch
50777% Set EDID data to 4K*2K PCM
2.0ch
EDID:4K&PCM 2ch
50778%
Check EDID data
EDID:1080P&
CM 2ch
EDID:1080P&
.1ch
EDID:1080P3d
&5.1ch
EDID:4K&PCM 2ch
50799% Program EDID file, send EDID data
within 10s Waiting for edid
within 10
secs!
Notes:
1. Please disconnect all the twisted pairs before sending command
EDIDUpgrade[X].
2. In above commands, “[”and “]” are symbols for easy reading and do not need to
be typed in actual operation.
3. Please remember to end the commands with the ending symbols “.” and “;”.
4. Type the command carefully, it is case-sensitive.

AVG-HDWP70TX-IR
5.4. Firmware Update via USB
To meet the needs of different users or further additional functions, the firmware of
the AVG-HDWP70TX-IR can be upgraded via USB. If the unit needs upgrading
please download the latest firmware file and then you are able to upgrade it through
the update .exe file. Copy the .exe file to the programming PC and double click the
program to upgrade the firmware.
When the program is running normally, it will display the interface (as shown in the
next figure), please press the button and choose the upgrade file, and then
press the button . It is ready to upgrade.
When updates are done, it will appear with a window showing the message Update
success.
Note:The COM number connected with PC is available only between 1 to 9.
