Sega PLANTS VS ZOMBIES User manual

BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
To maintain safety:
To ensure the safe operation of this product, be sure to read the following before usage.
The following instructions are intended for the users, operators and the personnel in charge of the
operation of the product. After carefully reading and sufficiently understanding the warning displays
and cautions, handle the product appropriately. Be sure to keep this manual close to the product or
in a convenient place for future reference.
Herein, explanations which require special attention are enclosed with dual lines. Depending on
potentially hazardous degrees, the terms of DANGER, WARNING, CAUTION, etc. are used. Be sure to
understand the contents of the displays before reading the text.
DANGER Indicates that mishandling the product by disregarding this pictograph will
cause severe injury or death.
WARNING Indicates that mishandling the product by disregarding this warning will
cause a potentially hazardous situation which can result in death or serious
injury.
CAUTION Indicates that mishandling the product by disregarding this caution will
cause a slight hazardous situation which can result in personal injury and/or
material damage.
For the safe usage of the product, the following pictographs are used:
Indicates "HANDLE WITH CARE." In order to protect the human body and equipment,
this display is attached to places where the Owner's Manual, Serviceman Manual
and/or Service Manual should be referred to.
Perform work in accordance with the instructions herein stated. Instructions for work are
explained by paying attention to the aspect of accident prevention. Failing to perform work
as per the instructions can cause accidents. In the case where only those who have
technical expertise should perform the work to avoid hazardous situation, the instructions
herein state that the site maintenance personnel should perform such work.
Be sure to turn off the power before working on the machine. To prevent an electric shock, be
sure to turn off the power before carrying out any work that requires direct contact with the
interior of the product. If the work is to be performed in the power-on status, the Instruction
Manual herein always states to that effect.
Be sure to ground the Earth Terminal. (This is not required in the case where a power cord with
earth is used.)
This product is equipped with the Earth Terminal. When installing the product, connect the
Earth Terminal to the "accurately grounded indoor earth terminal" by using an earth wire.
Unless the product is grounded appropriately, the user can be subject to an electric shock.
After performing repair, etc. for the control equipment, ensure that the Earth Wire is firmly
connected to the control equipment.
Ensure that the Power Supply used is equipped with an Earth Leakage Breaker. This product
does not incorporate the Earth Leakage Breaker. Using a power supply which is not
equipped with the Earth Leakage Breaker can cause a fire when earth leakage occurs.
Be sure to use fuses which meet the rating. (Only for the machines which use fuses.) Using
fuses exceeding the specified rating can cause a fire and an electric shock. (Only for the
machines which use fuses).
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

Specification changes (removal of equipment, conversion and addition) not designated by
SEGA are not allowed. The parts of the product include warning labels for safety, covers for
personal protection, etc. It is very hazardous to operate the product by removing parts
and/or modifying the circuits. Should doors, lids and protective parts be damaged or lost,
refrain from operating the product, and contact where the product was purchased from or
the office herein stated. SEGA shall not be held responsible for any accidents, compensation
for damage to a third party, resulting from the specifications not designated by SEGA.
Ensure that the product meets the requirements of appropriate electrical specifications.
Before installing the product, check for electrical specifications. SEGA products have a
nameplate on which electrical specifications are described. Ensure that the product is
compatible with the power supply voltage and frequency requirements of the location.
Using any electrical specifications different from the designated specifications can cause a
fire and an electric shock.
Install and operate the product in places where appropriate lighting is available, allowing
warning labels to be clearly read. To ensure safety for the customers, labels and printed
instructions describing potentially hazardous situations are applied to places where
accidents can be caused. Ensure that where the product is operated has sufficient lighting
allowing the warnings to be read. If any label peeled off, apply it again immediately. Please
place an order with where the product was purchased from or the office herein stated.
When handling the monitor, be very careful. (Applies only to products with monitors.) Some
of the monitor parts are subject to high tension voltage. Even after turning off the power,
some portions are still subject to high tension voltage sometimes. Monitor repair and
replacement should be performed only by those technical personnel who have knowledge
of electricity and technical expertise.
Be sure to adjust the monitor properly. (Applies only to products with monitors.) Do not
operate the product leaving on-screen flickering or blurring as it is. Using the product with the
monitor not properly adjusted may cause dizziness or a headache to an operator, a player,
or the customers.
When transporting or reselling this product, be sure to attach this manual to the product.
In the case where commercially available monitors and printers are used in this product, only
the contents relating to this product are explained herein. Some commercially available
equipment has functions and reactions not stated In this manual. Read this manual together
with the instruction manual of such equipment.
Descriptions herein contained may be subject to improvement changes without notice.
The contents described herein are fully prepared with due care. However, should any
question arise or errors be found, please contact SEGA.
INSPECTIONS IMMEDIATELY AFTER TRANSPORTING THE PRODUCT TO THE LOCATION
Normally, at the time of shipment, SEGA products are in a status allowing for usage immediately after
transporting to the location. Nevertheless, an irregular situation may occur during transportation.
Before turning on the power, check the following points to ensure that the product has been
transported in a satisfactory status.
Are there any dented portions or defects (cuts, etc.) on the external surfaces of the cabinet?
Are casters and adjusters damaged?
Do the power supply voltage and frequency requirements meet with those of the location?
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

Are all wiring connectors correctly and securely connected? Unless connected in the correct
way, connector connections cannot be made accurately. Do not insert connectors forcibly.
Do power cables have cuts and dents?
Are all accessories available?
Can all doors and lids be opened with the accessory keys? Can doors and lids be firmly
closed?
INTRODUCTION
This manual is intended to provide detailed descriptions together with all necessary information
covering the general operation of electronic assemblies, electro-mechanicals, servicing control,
spare parts, etc. for the product, "PLANTS VS ZOMBIES."
This manual is intended for the owners, personnel managers in charge of operation of this product.
Operate the product after carefully reading and sufficiently understanding the instructions.
In the unlikely event that the product does not function correctly, DO NOT allow anyone other than a
technician to touch the internal system. Turn off the power to the machine, making sure to unplug the
electrical cord from the outlet, and contact the office listed below or the point-of-purchase for this
product.
Use of this product is unlikely to cause physical injuries or damage to property. However, points that
require special attention are indicated by bold text, the word ―IMPORTANT‖ and the symbol below.
CONTACT
SEGA Amusements Europe Limited.
42 Barwell Business Park, Leatherhead Road, Chessington, Surrey, KT9 2NY. United Kingdom.
Telephone: [phone] Facsimile: [phone]
email: [email protected] Web: http://www.segaarcade.com.
Sega Total Solutions
42 Barwell Business Park, Leatherhead Road, Chessington, Surrey, KT9 2NY. United Kingdom.
Telephone: [phone] Facsimile: [phone]
email: [email protected] Web: http://www.segaarcade.com/spares
Play it! Amusements
252 Beinoris Drive, Wood Dale, IL. 60191, USA
USA Sales/Service: +00(1) 224 265 4287
INDICATES IMPORTANT INFORMATION THAT, IF IGNORED, MAY RESULT IN THE MISHANDLING
OF THE PRODUCT AND CAUSE FAULTY OPERATION OR DAMAGE TO THE PRODUCT.
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

Parts replacement, maintenance inspections and troubleshooting should be carried out by site
maintenance personnel or other qualified professionals. This manual includes directions for potentially
dangerous procedures which should only be carried out by professionals with the appropriate
specialized knowledge.
The site maintenance personnel or other qualified professionals mentioned in this manual are defined
as follows;
Site maintenance personnel:
Individuals with experience in maintaining amusement equipment, vending machines, etc., working
under the supervision of the owner/operator of this product to maintain machines within amusement
facilities or similar premises by carrying out everyday procedures such as assembly, maintenance
inspections, and replacement of units/expendable parts.
Activities to be carried out by site maintenance personnel:
Amusement equipment/vending machine assembly, maintenance inspection and replacement of
units/expendable parts.
Other qualified professionals continued on the following page;
CABINET
MACHINE DIMENSIONS: W 75 cm (29.53‖) x D 75 cm (29.53‖)
MACHINE HEIGHT: H 206 cm (81.10‖) [INSTALLED]
MACHINE WEIGHT: 120 Kgs. (265 LBS.)
POWER, MAXIMUM CURRENT: 220V ~ 12 AMP [UK/EUROPE]
110V/AC ~ 24 AMP [USA]
SPECIFICATIONS
PROCEDURES NOT DESCRIBED IN THIS MANUAL OR MARKED AS “TO BE CARRIED
OUT BY SITE MAINTENANCE PERSONNEL OR OTHER QUALIFIED PROFESSIONALS”
SHOULD NOT BE CARRIED OUT BY PERSONNEL WITHOUT THE NECESSARY SKILL
OR TECHNOLOGY. WORK CARRIED OUT BY UNQUALIFIED PERSONS MAY CAUSE
SERIOUS ACCIDENTS, INCLUDING ELECTROCUTION.
DEFINITION OF; “SITE MAINTENANCE PERSONNEL OR OTHER QUALIFIED INDIVIDUALS
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

Other qualified professionals;
Persons employed by amusement equipment manufacturers, or involved in design, production,
testing or maintenance of amusement equipment. The individual should have either graduated from
technical school or hold similar qualifications in electrical/ electronics /mechanical engineering.
Activities to be carried out by other qualified professionals;
Amusement equipment/vending machine assembly, repair/adjustment of
electrical/electronic/mechanical parts.
The WEEE (Waste of Electrical and Electronic Equipment) directive places an obligation on all EU
based manufacturers and importers of Electrical and Electronic Equipment to take back products at
the end of their useful life. Sega Amusements Europe Ltd. Accepts it‘s responsibility to finance the cost
of treatment and recovery of redundant WEEE in the United Kingdom in accordance with the specific
WEEE recycling requirements.
The symbol shown below will be on all products manufactured from 13th August 2005, which indicates
this product must NOT be disposed of with other normal waste. Instead, it is the user‘s responsibility to
dispose of their waste equipment by arranging to return it to a designated UK collection point for the
correct recycling of waste electrical and electronic equipment.
For more information about where you can send your waste equipment for recycling contact your
local authority office.
For non-UK users, contact your local authority office for information on the recycling of Waste
Electrical and Electronic Equipment.
The EC Directive on Batteries and Accumulators (2006/66/EC) aims to minimize the impact of batteries
on the environment and encourage the recovery of the materials they contain. To achieve increased
collection and recycling of waste batteries, the Directive places ‗producer responsibility‘ obligations
on manufacturers and importers of portable, industrial and automotive batteries.
The symbol shown below will be on all equipment fitted with batteries from 26th September 2008 and
indicates they must NOT be disposed of with other normal waste. Instead, it is the user‘s responsibility
to dispose of used batteries by arranging to return them to a designated collection point for the
correct recycling.
For more information about where you can send your waste batteries for recycling contact your local
authority office.
REGISTERED IN ENGLAND REGISTERED NO. 1711515
REGISTERED OFFICE: BLOCK C 42 BARWELL BUSINESS PARK, CHESSINGTON, SURREY KT9 2NY
WASTE OF ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE) STATEMENT.
BATTERY RECYCLING STATEMENT
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

TABLE OF CONTENTS
INTRODUCTION
1. HANDLING PRECAUTIONS 1
2. PRECAUTIONS REGARDING INSTALLATION 1
3. PRECAUTIONS REGARDING OPERATION 1
4. LOCATION
4-1 GAME LEVELING 1
5. GAME DESCRIPTION
5-1 OVERALL DIMENSIONS and APPEARANCE 1
6. GAME SET UP AND ADJUSTMENTS / TEST FUNCTIONS
6-1 GAME MENU & OPTIONS SETTINGS 1
6-2 TEST FUNCTIONS 1
7. COIN HANDLING
7-1 INSTRUCTION FOR ELECTRONIC COIN COMPARATOR TYPE 1
8. TICKET MECHANISM
8-1 INSTALLING TICKETS 1
9. ELECTRONIC COMPONENTS
9-1 MAIN BOARD 1
9-2 MAIN BOARD I/O 1
9-3 EXTENSION BOARD I/O 1
9-4 WIRING DIAGRAMS 1
9-5 COIL BED ASSEMBLY 1
9-6 GAME ASSEMBLY 1
10. GAME ERROR CODES 1
11. COIL BED SERVICE AND MAINTENANCE
11-1 ACCESSING THE COIL BED 1
11-2 SERVICING THE HEADER LIGHT BOX 1
12. PARTS DESCRIPTION
10-1 CABINET GRAPHICS & LABELS 1
10-2 PARTS LIST 1
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

1. HANDLING PRECAUTIONS
When installing or inspecting the machine, be very careful of the following points and pay attention
to ensure that the player can enjoy the game safely.
Noncompliance with the following points or inappropriate handling running counter to the cautionary
matters herein stated can cause personal injury or damage to the machine.
Before performing work, be sure to turn the power off. Performing the work without
turning the power off can cause an electric shock or short circuit. In cases where
work should be performed in the status of power on, this manual always states to that
effect.
To avoid an electric shock or short circuit, do not plug in or unplug quickly.
To avoid an electric shock, do not plug in or unplug with a wet hand.
Do not expose power cords or earth wires on the surface, (floor, passage, etc.) If
exposed, the power cords and earth wires are susceptible to damage. Damaged
cords and wires can cause an electric shock or short circuit.
To avoid causing a fire or an electric shock, do not put things on or damage the
power cords.
When or after installing the product, do not unnecessarily pull the power in case the
power cord is damaged, ask for a replacement through where the product was
purchased from or the office herein stated. Using the cord as is damaged can cause
fire, an electric shock or leakage.
Be sure to perform grounding appropriately. Inappropriate grounding can cause an
electric shock.
Be sure to use fuses meeting the specified rating. Using fuses exceeding the specified
rating can cause fire or an electric shock.
Be sure that connections such as IC BD are made properly. Insufficient insertion can
cause an electric shock.
Specification changes, removal of equipment, conversion and/or addition, not
designated by SEGA are not permitted.
Failure to observe this may cause a fire or an electric shock. Non-compliance with
this instruction can have a bad influence upon physical conditions of the players or
the onlookers, or result in injury during play.
SEGA shall not be held responsible for damage, compensation for damage to a third
party, caused by specification changes not designated by SEGA.
Do not perform any work or change parts not listed in this manual. Doing
so may lead to an accident. If you need to perform any work not listed in this manual,
request work from the office indicated in this manual or the point of purchase, or
inquire for details.
Be sure to perform periodic maintenance inspections herein stated.
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

CONCERNING THE STICKER DISPLAY
This SEGA product has stickers attached describing the product manufacturer No. (Serial No.) and
Electrical Specifications. It also has a Sticker describing where to contact for repair and for
purchasing parts.
When inquiring about or asking for repairs, mention the Serial No. and Name of Machine indicated on
the Sticker. The Serial Number indicates the product register. Identical machines could have different
parts depending on the date of production. Also, improvements and modifications might have been
made after the publication of this manual. In order to ensure you order the correct parts, mention the
Serial No. when contacting the applicable places.
CONCERNING WARNING DISPLAYS
This SEGA product has warning displays on stickers, labels and/or printed instructions
adhered/attached to or incorporated in the places where a potentially hazardous situation could
arise. The warning displays are intended for accident prevention for customers and for avoiding
hazardous situations relating to maintenance and servicing work.
Some portions of the cabinet contain high voltage and may cause accidents if touched. When
performing maintenance, be very careful of the warning displays. It is especially important that any
complex repair and replacement work not mentioned herein should be performed by those
technical personnel who have knowledge of electricity and technical expertise.
In order to prevent accidents, caution any customer ignoring the warnings to cease and desist
immediately.
For the IC board circuit inspections, only the use of a logic tester is
recommended. Using a Multi Tester or General Purpose Tester may result in
damage to IC Circuits.
Static electricity from your body may damage some electronics devices on the
IC board. Before handling the IC board, touch a grounded metallic surface so
that the static electricity can be discharged.
Some parts are not designed and manufactured specifically for this game
Machine. The manufacturers may discontinue, or change the specifications of
such general-purpose parts. If this is the case, SEGA cannot repair or replace a
failed game machine whether or not a warranty period has expired.
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

2. PRECAUTIONS REGARDING INSTALLATION
THIS LINE
This product is an indoor game machine. Do not install it outside. Even indoors, avoid
installing in places mentioned below so as not to cause a fire, electric shock, injury and/or
malfunction.
Places subject to rain or water leakage, or places subject to high humidity in the proximity of
an indoor swimming pool and/or shower, etc.
Places subject to direct sunlight, or places subject to high temperatures in the proximity of
heating units, etc.
Places filled with inflammable gas or vicinity of highly inflammable/volatile chemicals or
hazardous matter.
Dusty places.
Sloped surfaces.
Places subject to any type of violent impact.
Vicinity of anti-disaster facilities such as fire exits and fire extinguishers.
Areas where the temperature exceeds the applicable temperature (ambient temperature)
range of 5 to 30 degrees centigrade.
Be sure to check the Electrical Specifications. Ensure that this product is compatible with the
location's power supply, voltage, and frequency requirements. A plate describing Electrical
Specifications is attached to the product. Non-compliance with the Electrical Specifications
can cause a fire and electric shock.
This product requires a breaker and earth mechanism as part of the location facilities. Using
the product without these can cause a fire and electric shock.
Ensure that the indoor wiring for the power supply is rated at 15 A or higher (AC single phase
100 V ~ 120 V area), and 7 A or higher (AC 220 V ~ 240 V area). Non-compliance with the
Electrical Specifications can a fire and electric shock.
Be sure to use an independent power supply equipped with an earth leakage breaker. Using
a power supply without an earth leakage breaker can cause an outbreak of fire if a power
surge occurs.
Putting many loads on one electrical outlet can cause generation of heat and a fire resulting
from overload.
When using an extension cord, ensure that the cord is rated at 15 A or higher (AC 100 V ~ 120
V area) and 7 A or higher (AC 220 V ~ 240 V area). Using a cord rated lower than the
specified rating can cause a fire and electric shock.
LIMITATIONS OF USAGE
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

3. PRECAUTIONS REGARDING OPERATION
4. LOCATIONS:
Securing a safe area for operation as described in this manual will ensure safe operation for
players and observers.
SEGA shall not be held responsible for damage or compensation for damage to a third party,
resulting from the failure to observe this instruction.
For the operation of this machine, please secure a minimum area of 2.10m (D) and 1.10m (W)
Be sure to provide sufficient space specified in this manual. Do not allow objects to block
ventilation ports. It can cause generation of heat and a fire.
Sufficient space either side of the playing area must be allowed for the player to enter or exit
the game play area safely.
OPERATION AREA (SINGLE CABINET)
THE MACHINE IS DESIGNED FOR INDOOR USE ONLY. NEVER INSTALL THIS
MACHINE OUTDOORS OR IN ANY OF THE FOLLOWING:
● LOCATIONS EXPOSED TO DIRECT SUNLIGHT.
● LOCATIONS SUBJECT TO RAIN OR WATER LEAKAGE.
● UNSTABLE LOCATIONS OR LOCATIONS SUBJECT TO VIBRATION.
● DUSTY, HOT, OR DAMP LOCATIONS.
NOTICE
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

4-1 GAME LEVELING:
INSTALL THIS MACHINE ON A FLAT SURFACE. ADJUST LEVELERS TO LIFT THE
LEGS AND LEVEL GAME.
MAKE SURE THAT THE MACHINE IS LEVEL WITH THE FLOOR. IF THE MACHINE
IS NOT LEVEL, THE GAME MAY NOT FUNCTION CORRECTLY.
APPROX 5mm
DISCONNECT GAME POWER BEFORE MOVING
MAKE SURE ALL WHEELS ARE INTACT. REPLACE ANY WHEELS THAT
ARE DAMAGED OR BROKEN BEFORE MOVING THE GAME.
WHEN MOVING THE GAME, DO NOT SLIDE THE GAME ACROSS THE
FLOOR
ENSURE THE GAME IS LEVEL BEFORE CONNECTING THE POWER
WARNING
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

5. GAME DESCRIPTION
OVERALL DIMENSIONS and APPEARANCE;
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

6. GAME SET UP AND ADJUSTMENTS / TEST FUNCTIONS
6-1 GAME MENU and OPTIONS SETTINGS
Menu & Game Options Adjustments Panel
The Game Menu and Adjustments are accessed through the center coin door and
located on a small, COINS, TICKETS and CAPSULES meter panel where three
pushbuttons are found; ―MENU‖, ―OPTION‖ and ―TICKET CLEAR‖. These pushbuttons are
used to access a specific function MENU and change a game settings Option or Test
function within a directory of selections, factory default settings, and/or custom settings
according to the game manual. These adjustments are shown in the game 7 segment,
SCORE LED display on the marquee panel once the ―MENU‖ button has been pressed
by the Operator during non-game play periods.
Menu & Game Options Adjustments
The game adjustment settings, by entering the MENU, [pressing the MENU button inside
the coin door], are displayed in the 3 block, 7 segment, LED display [Score/Jackpot
Display].
When an Operator presses the ―MENU‖ pushbutton located inside the coin door- the
display changes to display the MENU# and the OPTION# setting within the directory
outlined below. By continuing to depress the MENU pushbutton, the Operator may
advance through the various MENU #s in order to reach a specific MENU for
adjustment. Once a specific MENU is displayed, the Operator uses the OPTION
pushbutton to change the various OPTION #s available within that Menu.
Continued on the next page;
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

Menu & Game Options Adjustments [Displayed on the LED Display]
The first 2 digits are the; MENU #.
The second digit is the; OPTION #.
Advancing through the MENU selections back to -0-0-0 will save the selections and
return the game to normal after 2 seconds.
The ―TICKET CLEAR‖ button is used to clear any unpaid tickets stored in memory when a
new bundle of tickets has been installed.
Turning the Power OFF and then ON again will save the game parameters within the
software.
MENU and OPTIONs Directory MENU # OPTION#
00 0
Score Display
*Denotes Factory Default settings at the factory
MENU# OPTION# ACTION
00 0 Return to Game Play
01 0 Free Play
01 1 1 Credit Play
01 2 * 2 Credit Play
01 3 3 Credit Play
01 4 4 Credit Play
02 0 Round of Play 8 seconds (x3)
02 1* Round of Play 10 seconds (x3)
02 2 Round of Play 12 seconds (x3)
02 3 Round of Play 14 seconds (x3)
02 4 Round of Play 16 seconds (x3)
02 5 Round of Play 18 seconds (x3)
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

MENU# OPTION# ACTION
03 0 Ticket mechanism disabled- no tickets - OFF
03 1* Ticket mechanism enabled –ON
04 0 * Ticket value - 1 pt.
04 1 Ticket value - 2 pt.
05 0 Attract OFF
05 1 Attract every 15 seconds
05 2 * Attract every 30 seconds
05 3 Attract every 45 seconds
05 4 Attract every 60 seconds
05 5 Attract every 90 seconds
05 6 Attract every 120 seconds
06 0 Attract Audio OFF
06 1 * Attract Audio ON
07 0 Zombies per round –Lowest
[Zombies time out @ 1 sec.]
07 1* Zombies per round –Low
[Zombies tine out @ .75 sec.]
07 2 Zombies per round –Medium
[Zombies time out @ .5 sec.]
07 3 Zombies per round –Maximum
[Zombies time out @ .25 sec.]
08 0 Jackpot –DISABLED [Capsule dispensed at
perfect score if MENU 11-1 enabled]
08 1 Jackpot fixed amount: 20
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

MENU# OPTION# ACTION
08 2* Jackpot fixed amount: 30
08 3 Jackpot fixed amount: 40
08 4 Jackpot fixed amount: 50
08 5 Jackpot fixed amount: 60
08 6 Jackpot fixed amount: 70
08 7 Jackpot fixed amount: 80
08 8 Jackpot fixed amount: 90
08 9 Jackpot fixed amount: 100
09 0 1 ticket per 2 Zombies hit
09 1 1 ticket per 3 Zombies hit
09 2* 1 ticket per 4 Zombies hit
09 3 1 ticket per 5 Zombies hit
09 4 1 ticket per 6 Zombies hit
09 5 1 ticket per 7 Zombies hit
09 6 1 ticket per 8 Zombies hit
09 7 1 ticket per 9 Zombies hit
09 8 1 ticket per 10 Zombies hit
10 0 Mercy ticket- OFF
10 1* Mercy ticket –1
10 2 Mercy ticket –2
10 3 Mercy ticket –3
10 4 Mercy ticket –4
10 5 Mercy ticket –5
10 6 Mercy ticket –6
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

MENU# OPTION# ACTION
11 0* Capsule Vendor –DISABLED
11 1 Capsule Vendor - ENABLE
6-2 TEST FUNCTIONS
MENU# OPTION# ACTION
TEST FUNCTIONS: [Most Tests confirmed by an audio ―Ding‖ Bell
Tone (sfx) when actuated by hand]
12 0 Test: Audio- play background main1
12 1 Test: All Zombie OPTO detect- ―ding‖ sfx.
12 2 Test: Zombie coil mechanisms; #1 - #6 in
sequence one at a time actuate UP and DOWN
one time. >―ding‖ sfx.
12 3 Test: Score, Jackpot, Time Display –flash all.
12 4 Test: All LED character rings –flash all.
12 5 Test: Capsule vendor-dispense ONE [enabled]
12 6 Test: Capsule dispense opto detect >‖ding‖ sfx.
12 7 Test: Ticket mechanism run
12 8 Test: Coin mechanism switches- ―ding‖ sfx.
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

7. COIN HANDLING
7-1 INSTRUCTION FOR ELECTRONIC COIN COMPARATOR TYPE
A. REMOVE THE PLASTIC COIN FROM COIN SLOT, REPLACE WITH THE DESIRED
TOKEN OR COIN INSIDE THE SPRING TENSIONED COIN HOLDER.
B. LOOSEN BOLTS AT THE BACK OF COIN ENTRANCE. USE THE DESIRED COIN
DIAMETER TO ADJUST SPACE AT THE BACK OF COIN ENTRANCE. AVOID ERROR
CAUSED BY LARGE DIAMETER TOKENS.
C. ADJUST FOR GAME MAIN BOARD PULSE RATE NEEDS. CHOOSE COIN LONG
SHORT AND FAST SLOW THREE PHASE SWITCH (TIMER SWITCH)：30MS IS SHORT
FAST SIGNAL BEST FOR MACHINES THAT HAVE HIGH POWER AND REQUIRES THE
INSERT OF COINS QUICKLY, 50MS IS MIDDLE SIGNAL, BEST FOR ORDINARY
MACHINES (IF NOT SPECIAL CIRCUMSTANCE, THE MACHINE USUALLY CAN USE
THIS PHASE). 100MS IS LONG, SLOW SIGNAL, BEST FOR MACHINES THAT DO NOT
NEED COINS INSERTED QUICKLY.
D. VR COIN CHOICE SENSITIVITY ADJUSTMENT. ANTICLOCKWISE ADJUSTMENT
（—），ACCEPT SMALLER AREA OF COIN TOLERANCE，COIN TYPE FILTRATION
WILL BE MORE RESTRICTED.
Wiring：
Grey
Red -DC+12V
White –COIN signal
Code Table
Black-Grounded
Grey
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

8. TICKET MECHANISM
8-1 INSTALLING TICKETS:
1. AS SHOWN ON PICTURE1, PUSH THE METAL BLOCK UP AND LIFT THE ALUMINUM PLATE;
2. FEED THE TICKET THROUGH THE INSPECTING SENSOR UNTIL THEY REACH THE ROLLER
AND INSTALL THE TICKET.
3. PRESS THE ―RESET‖ BUTTON TO ADVANCE THE TICKETS THROUGH THE ROLLER.
4. INSTALL THE ALUMINUM PLATE BACK IN PLACE;
5. WHEN ALL TICKETS HAVE BEEN DISPENSED, AND AN UNPAID BALANCE IS HELD IN THE
GAME MEMORY, PRESS THE ―JP CLEAR‖ BUTTON ON THE MENU & ADJUSTMENT PANEL
INSIDE THE COIN DOOR AREA TO DISPENSE REMAINING BALANCES. THIS WILL CLEAR ANY
UNPAID TICKETS FROM MEMORY.
PICTURE 1 PICTURE 2
PICTURE 3 PICTURE 4 PICTURE 5
SENSOR
RESET
BUTTON
You can get this game at www.magic-play.eu
You can get this game at www.magic-play.eu

9. ELECTRONIC COMPONENTS
