Sel SEL-3031 User manual

SEL-3031
Serial Radio
Transceiver
Instruction Manual
*PM3031-01*
20091009

© 2009 by Schweitzer Engineering Laboratories, Inc. All rights reserved.
All brand or product names appearing in this document are the trademark or registered trademark of their
respective holders. No SEL trademarks may be used without written permission. SEL products appearing in this
document may be covered by US and Foreign patents.
Schweitzer Engineering Laboratories, Inc. reserves all rights and benefits afforded under federal and
international copyright and patent laws in its products, including without limitation software, firmware, and
documentation.
The information in this manual is provided for informational use only and is subject to change without notice.
Schweitzer Engineering Laboratories, Inc. has approved only the English language manual.
This product is covered by the standard SEL 10-year warranty. For warranty details, visit www.selinc.com or
contact your customer service representative. PM3031-01
SEL-3031 Instruction Manual Date Code 20091009

Date Code 20091009 SEL-3031 Instruction Manual
Table of Contents
List of Tables........................................................................................................... iii
List of Figures...........................................................................................................v
Preface...................................................................................................................... vii
Section 1: Introduction and Overview
Overview................................................................................................................1.1
Features, Benefits, and Applications......................................................................1.2
Models, Options, and Accessories.........................................................................1.2
Product Diagrams...................................................................................................1.4
Specifications.........................................................................................................1.7
Section 2: Installation
Overview................................................................................................................2.1
Connections............................................................................................................2.7
Front-Panel Indicators..........................................................................................2.11
Communications ..................................................................................................2.12
Section 3: Job Done Examples
Overview................................................................................................................3.1
High-Speed Teleprotection or Control With MIRRORED BITS
Communications..........................................................................................3.1
Using an SEL Information Processor to Collect Relay Status and
Measurements..............................................................................................3.6
Section 4: Settings and Commands
PC Software............................................................................................................4.1
Settings...................................................................................................................4.5
Commands............................................................................................................4.15
Section 5: Performance Monitoring, Testing, and Troubleshooting
Overview................................................................................................................5.1
Monitoring Radio Performance..............................................................................5.1
Self-Test .................................................................................................................5.5
Troubleshooting .....................................................................................................5.6
Appendix A: Firmware and Manual Versions
Firmware ...............................................................................................................A.1
Instruction Manual ................................................................................................A.1

SEL-3031 Instruction Manual Date Code 20091009
Table of Contentsii
Appendix B: SEL-3044 Encryption Card
Overview................................................................................................................B.1
NIST FIPS 140-2 Level 2 Security Requirements ................................................B.1
Theory of Operation—SEL Protocol.....................................................................B.2

Date Code 20091009 SEL-3031 Instruction Manual
List of Tables
Table 1.1 Radio Antenna and Cable Accessories..................................1.3
Table 2.1 Fresnel Zone Diameter ..........................................................2.3
Table 2.2 900-MHz Frequency Skip Zones...........................................2.6
Table 2.3 Length vs. Loss in Coaxial Cables at 900 MHz ....................2.6
Table 2.4 Default Passwords................................................................2.10
Table 2.5 Password Jumper Position...................................................2.10
Table 2.6 Communications Cables for Time and Communications
Connections ....................................................................2.11
Table 2.7 Front-Panel Status Indicator LEDs......................................2.11
Table 2.8 SEL-3031 Port Description..................................................2.12
Table 2.9 SEL-3031 Port Description..................................................2.13
Table 4.1 ACSELERATOR QuickSet SEL-5030 Software......................4.1
Table 4.2 Device Editor Menus.............................................................4.9
Table 4.3 Global Settings ....................................................................4.11
Table 4.4 Radio Settings......................................................................4.12
Table 4.5 SKIP Zone Frequencies.......................................................4.12
Table 4.6 Port X Settings.....................................................................4.14
Table 4.7 Fixed Port Settings...............................................................4.15
Table 4.8 DATE Command..................................................................4.17
Table 4.9 ID Command .......................................................................4.17
Table 4.10 IRIG Command ...................................................................4.18
Table 4.11 L_D Command ....................................................................4.18
Table 4.12 PAS Command.....................................................................4.19
Table 4.13 Factory Default Passwords ..................................................4.19
Table 4.14 Valid Password Characters ..................................................4.20
Table 4.15 QUIT Command..................................................................4.20
Table 4.16 RAD Command...................................................................4.21
Table 4.17 SER Command ....................................................................4.22
Table 4.18 SET Command (Change Settings).......................................4.22
Table 4.19 SET Command Editing Keystrokes.....................................4.23
Table 4.20 SHO Command (Show/View Settings)................................4.23
Table 4.21 STA Command (Device Self-Test Status) ...........................4.24
Table 4.22 STA Command Report.........................................................4.24
Table 4.23 Command Definitions..........................................................4.25
Table 5.1 Device Self-Tests...................................................................5.5
Table 5.2 Troubleshooting Tips.............................................................5.6
Table A.1 Firmware Revision History...................................................A.1
Table A.2 Instruction Manual Revision History....................................A.1

This page intentionally left blank

Date Code 20091009 SEL-3031 Instruction Manual
List of Figures
Figure 1.1 Product Overview .............................................................................1.1
Figure 1.2 SEL-3031 Dimensions......................................................................1.4
Figure 1.3 SEL-3031 Rack Mount (Front and Rear) .........................................1.5
Figure 1.4 SEL-3031 Wall Mount (Front and Rear) ..........................................1.6
Figure 2.1 Fresnel Zone .....................................................................................2.2
Figure 2.2 Antenna Polarization.........................................................................2.5
Figure 2.3 Wall-Mount and Rack-Mount Rear Connections .............................2.7
Figure 2.4 Two-Wire EIA-485 Connections ....................................................2.12
Figure 2.5 EIA-232 and EIA-485 DB-9 Connector Pin Numbers...................2.13
Figure 2.6 SEL Cable C245A: SEL-3031 to Computer...................................2.14
Figure 2.7 SEL Cable C285: SEL-3031 to DTE Device (SEL Relays)...........2.15
Figure 2.8 SEL Cable C782/C387: SEL-3031 to SEL Communications
Processor....................................................................................2.15
Figure 2.9 USB Interface .................................................................................2.16
Figure 3.1 SEL MIRRORED BITS Connection Example......................................3.1
Figure 3.2 SEL-3031 Port Settings for MIRRORED BITS Connection ................3.2
Figure 3.3 SEL-351 Port Settings for MIRRORED BITS Connection ..................3.3
Figure 3.4 SEL-451 Port Settings for MIRRORED BITS Connection ..................3.4
Figure 3.5 SEL-2505 DIP Switch Settings for MIRRORED BITS Connection ....3.5
Figure 3.6 TAR ROKA Command From an SEL-351.......................................3.6
Figure 3.7 SEL-3031 Linking Information Processors to Relays......................3.6
Figure 3.8 SEL-3031 Port 1 Settings for Fast Messaging..................................3.7
Figure 3.9 SEL-351 Port Settings for Fast Messaging.......................................3.8
Figure 3.10 Example AUTO Command Output...................................................3.9
Figure 4.1 Communications Menu.....................................................................4.2
Figure 4.2 Serial Port Communications Parameters ..........................................4.3
Figure 4.3 Terminal Window Menu...................................................................4.4
Figure 4.4 Device Response to ID Command....................................................4.4
Figure 4.5 Selection of Drivers ..........................................................................4.7
Figure 4.6 Update Part Number .........................................................................4.8
Figure 4.7 New Setting Screen...........................................................................4.8
Figure 4.8 Status Screen...................................................................................4.10
Figure 4.9 Radio Strength and Channel Availability .......................................4.11
Figure 4.10 RAD Command Response..............................................................4.21
Figure 4.11 Device Response to the STATUS Command..................................4.24
Figure 5.1 Example RAD Command.................................................................5.2
Figure 5.2 RBAD Generation.............................................................................5.4
Figure B.1 SEL-3044 Encryption Card .............................................................B.1
Figure B.2 In-Band Data Packet Format............................................................B.4
Figure B.3 Operation of the AES Encryption Function.....................................B.5
Figure B.4 Encryption Card Location................................................................B.7

This page intentionally left blank

Date Code 20091009 SEL-3031 Instruction Manual
Preface
Manual Overview
The SEL-3031 Serial Radio Transceiver manual includes the information needed to
properly install and operate the product.
The scope of this manual includes specifications, installation, mechanical information,
self-monitoring, and alarming.
An overview of each manual section and topics follows.
Preface. Describes the manual organization and conventions used to present
information.
Section 1: Introduction and Overview. Describes the basic features and functions
of the SEL-3031, and lists the specifications.
Section 2: Installation. Describes how to mount and wire the SEL-3031;
illustrates wiring connections for various applications.
Section 3: Job Done Examples. Describes common SEL-3031 applications.
Section 4: Settings and Commands. Describes settings and commands for use
with the SEL-3031.
Section 5: Performance Monitoring, Testing, and Troubleshooting. Lists common
operating and troubleshooting questions.
Appendix A: Firmware and Manual Versions. Details differences between
firmware versions. Provides a record of changes made to the manual.
Appendix B: SEL-3044 Encryption Card. Describes how the encryption card
operates to secure wireless data. Provides installation information.

SEL-3031 Instruction Manual Date Code 20091009
Preface
Conventions
viii
Conventions
Safety Information
This manual uses three kinds of hazard statements, formatted as follows:
Indicates a potentially hazardous situation that, if not avoided, may result in
minor or moderate injury or equipment damage.
!
CAUTION
Indicates a potentially hazardous situation that, if not avoided, could result in
death or serious injury.
!
WARNING
Indicates an imminently hazardous situation that, if not avoided, will result in
death or serious injury.
!
DANGER
SEL-3031 Cautions, Warnings, and Dangers
The following hazard statements appear in the body of this manual in English. See the
following table for the English and French translation of these statements.
English French
Although the power level is low, concentrated
energy from a directional antenna may pose a
health hazard. Do not allow users to come
closer than 23 cm (9 in) to the antenna when
the transmitter is operating in indoor or
outdoor environments in the 900-MHz band.
!
CAUTION
Bien que le niveau de puissance soit bas,
l'énergie concentrée d'une antenne
directionnelle peut être un danger pour la
santé. Ne pas autoriser les usagers à
s'approcher à moins de 23 cm (9 po) de
l'antenne quand l'émetteur est en opération
dans un environnement intérieur ou
extérieur dans la bande des 900-MHz.
!
ATTENTION
The radio contains devices sensitive to
electrostatic discharge (ESD). Undetectable
permanent damage can result if you do not use
proper ESD procedures. Ground yourself, your
work surface, and this equipment before
removing any cover from this equipment. If
your facility is not equipped to work with these
components, contact SEL about returning this
device and related SEL equipment for service.
!
CAUTION
La radio contient des circuits sensibles aux
décharges électrostatiques (DES). Des
dommages permanents non-décelables
peuvent résulter de l’absence de précautions
contre les DES. Raccordez-vous
correctement à la terre, ainsi que la surface
de travail et l’appareil avant d’en retirer un
panneau. Si vous n’êtes pas équipés pour
travailler avec ce type de composants,
contacter SEL afin de retourner l’appareil
pour un service en usine.
!
ATTENTION

Date Code 20091009 SEL-3031 Instruction Manual
Preface
Conventions
ix
Operator safety may be impaired if the device is
used in a manner not specified by SEL.
!
WARNING
La sécurité de l’opérateur peut être
compromise si l’appareil est utilisé d’une
façon non indiquée par SEL.
!
AVERTISSEMENT
Atmospheric electrical charge accumulation
can cause potential between the conductor and
shield of the feedline, or cause lightning to
strike an antenna. A lightning protector should
be installed to prevent damage to equipment or
injury to personnel.
!
WARNING
L'accumulation de charges électriques de
type atmosphérique peut être la cause d'une
différence de potentiel entre le conducteur
et le blindage de la ligne d'alimentation ou
peut attirer la foudre sur l'antenne. Un
parafoudre devrait être installé pour
prévenir les dommages à l'équipement ou
les blessures au personnel.
!
AVERTISSEMENT
Do not look into the fiber (laser)
ports/connectors.
!
WARNING
Ne pas regarder vers l’extremité des ports ou
connecteurs de fibres pour laser.
!
AVERTISSEMENT
Do not look into the end of an optical cable
connected to an optical output.
!
WARNING
Ne pas regarder vers l’extrémité d’un câble
optique raccordé à une sortie optique.
!
AVERTISSEMENT
This device is shipped with default passwords.
Default passwords should be changed to private
passwords at installation. Failure to change
each default password to a private password
may allow unauthorized access. SEL shall not
be responsible for any damage resulting from
unauthorized access.
!
WARNING
Cet appareil est expédié avec des mots de
passe par défaut. A l’installation, les mots de
passe par défaut devront être changés pour
des mots de passe confidentiels. Dans le cas
contraire, un accés non-autorisé á
l’équipement peut être possible. SEL décline
toute responsabilité pour tout dommage
résultant de cet accés non-autorisé.
!
AVERTISSEMENT
Disconnect or de-energize all external
connections before opening this device.
Contact with hazardous voltages and currents
inside this device can cause electrical shock
resulting in injury or death.
!
DANGER
Débrancher tous les raccordements externes
avant d’ouvrir cet appareil. Tout contact avec
des tensions ou courants internes à l’appareil
peut causer un choc électrique pouvant
entraîner des blessures ou la mort.
!
DANGER
English French

This page intentionally left blank

Date Code 20091009 SEL-3031 Instruction Manual
Section 1
Introduction and Overview
Overview
The SEL-3031 is a 900-MHz, license-free, spread-spectrum radio. The radio operates
in the ITU Region 2 ISM band of 902–928 MHz using a fast frequency-hopping
algorithm for noise immunity and long-distance operation.
The SEL-3031 prevents the need for multiple sets of radios or expensive dedicated
fiber transmitting over long distances. Figure 1.1 shows the flexibility of the SEL-3031
in providing DNP3 SCADA information, MIRRORED BITS®control for reclosing
coordination, and engineering access to the SEL-651R Recloser Control.
Figure 1.1 Product Overview
Pole-Mount Radio
Substation Radio
DNP
Engineering
Access
M
IRRORED B ITS
SEL-3031
SEL-351S
SEL-651R
SEL-3031
SEL-3351

SEL-3031 Instruction Manual Date Code 20091009
Introduction and Overview
Features, Benefits, and Applications
1.2
Features, Benefits, and Applications
➤Three Ports in One Radio Reduce Costs. Simultaneously
communicates with up to three independent ports and protocols.
➤Low Latency Enables Fast Control. Transfers control commands
with a typical 5.5-millisecond latency with SEL MIRRORED BITS®
communications.
➤Strong Security Thwarts Attackers. Protects critical data and repels
malicious attacks with optional encryption card, using session
authentication and strong 256-bit Advanced Encryption Standard
(AES) technology.
➤Tough Radio Operates in Extreme Conditions. Is designed, built,
and tested for trouble-free operation in extreme temperature,
electromagnetic interference, shock, and vibration conditions.
➤No Licensing Reduces Delays and Expenses. Uses the license-free,
900-MHz ISM band for on-time, on-budget projects.
➤Mounting Options Simply Installation. Order your SEL-3031 in
one of three different packages: rack-mount, wall-mount, and NEMA
3R prewired radio solution.
➤Multiple Protocols Satisfy Interconnection Requirements.
Communicate with industry-standardized byte-oriented protocols,
such as DNP3, Modbus®, SEL MIRRORED BITS communications,
IEEE C37.118 Synchrophasors, SEL Fast Messaging, and SEL
ASCII.
➤Flexible Serial Port Options Match Integration Needs. Order
serial Port 1 as EIA-232, EIA-485, or optical fiber to easily connect
to your existing devices.
➤Simple Settings Streamline Radio Commissioning. Use
ACSELERATOR QuickSet®SEL-5030 Software for all settings.
➤USB Management Port Conveniently Connects to PC. Make
settings changes, verify status information for proper installation, and
verify radio performance without affecting the three serial channels.
Models, Options, and Accessories
Standard Features
➤Three EIA-232 serial ports
➤IRIG-B time code input

Date Code 20091009 SEL-3031 Instruction Manual
Introduction and Overview
Models, Options, and Accessories
1.3
➤Power supply
➢Wall mount: 9–30 Vdc
➢Rack mount: 24–48 Vdc, 125/250 Vac or Vdc
➤ACSELERATOR QuickSet software
➤Protocol pass-through support
➢DNP3
➢Modbus
➢SEL MIRRORED BITS
➢SEL Fast Messaging
➢SEL ASCII
➢IEEE C37.118 Synchrophasors
Optional Features
➤One port EIA-485
➤One port fiber-optic (SEL-2812-compatible)
➤SEL-3044 Encryption Card
Accessories
Table 1.1 Radio Antenna and Cable Accessories
Description Part Number
Feed Line
RG-8 TNC to N Connector C964
RG-8 TNC to TNC C965
LMR-400 TNC to N Connector C966
LMR-400 TNC to TNC C961
Antenna
Three-element 8.5 dBi Yagi, N Connector 235-0221
Five-element 11.1 dBi Yagi, N Connector 235-0220
Vertical 2.15 dBi Gain Omni-directional, N Connector 235-0231
Surge Protection
Gas Tube Coaxial Surge Protector, TNC Connector 915900139

SEL-3031 Instruction Manual Date Code 20091009
Introduction and Overview
Product Diagrams
1.4
Product Diagrams
Figure 1.2 SEL-3031 Dimensions
i9163b
RACK-MOUNT CHASSIS WALL-MOUNT CHASSIS
9.15
(232.4)
18.31
(465.1)
FRONT
19.00
(482.6)
1.72
(43.7)
TOP TOP
6.40
(162.6)
6.30
(160) 5.73
(145.5)
3.00
(76.2)
LEGEND
in
(mm)
SIDE
0.21
(5.3)
8.66
(219.7)
FRONT SIDE
0.05
(1.27)
1.73
(43.9)

Date Code 20091009 SEL-3031 Instruction Manual
Introduction and Overview
Product Diagrams
1.5
Figure 1.3 SEL-3031 Rack Mount (Front and Rear)
i4210b

SEL-3031 Instruction Manual Date Code 20091009
Introduction and Overview
Product Diagrams
1.6
Figure 1.4 SEL-3031 Wall Mount (Front and Rear)
i4243c
i4211b

Date Code 20091009 SEL-3031 Instruction Manual
Introduction and Specifications
Specifications
1.7
Specifications
General
Temperature Range
–40° to +85°C per IEC 60068-2-1 and
60068-2-2
Operating Environment
Pollution
Degree: 2
Relative
Humidity: 5–95%, noncondensing
Maximum
Altitude: 2000 m
Dimensions
Wall Mount: 43.9 mm x 219.7 mm x
162.6 mm
(1.73 in x 8.66 in x
6.40 in)
Rack Mount: 43.7 mm x 482.6 mm x
160.0 mm
(1.72 in x 19.00 in x
6.3 in)
Time-Code Input
Port 2, Pins 4 and 6
Format: Demodulated IRIG-B
Input
Impedance: 333 
Accuracy: ± 5 milliseconds
Alarm Contact
Form B Contact
(open when energized and passes diagnostics)
Operating
Voltage: 250 Vdc or 190 Vac
Dielectric Test
Voltage: 500 Vrms
Continuous
Carry: 6 A
Communications
Communications Ports
Serial Port 1: EIA-232, EIA-485
(ordering option)
SEL-2812 Fiber-Optic
Port (ST connectors)
Data Speed: 19200 bps;
9600 bpswithencryption
card
Serial Port 2, 3: Standard EIA-232
Data Speed: 19200 bps;
9600 bpswithencryption
card
Protocols Supported
Modbus, DNP3, SEL MIRRORED BITS
Communications (MB8), ACSELERATOR
QuickSet SEL-5030 Software Support,
SEL ASCII and Compressed ASCII, SEL
Fast Messaging, IEEE C37.118
Synchrophasors
Radio Latency
SEL-3031
MIRRORED BITS: 5.5 ms typical
Standard: 4 ms typical
SEL-3031 With SEL-3044 Encryption Card
MIRRORED BITS: 16 ms typical
Standard: 15 ms typical
Radio
Transmitter
Frequency Band: 902–928 MHz ISM band
Modulation: GFSK
Operating Mode: Point-to-Point
RF Connector: TNC
Power Output: 1 W (30 dBm) to
100 mW (20 dBm)
in steps of 1 dBm
Channel
Bandwidth: 250 kHz

SEL-3031 Instruction Manual Date Code 20091009
Introduction and Specifications
Specifications
1.8
Receiver
Sensitivity: –97 dBm
Bit Error Rate
(BER): <10–6 at –97 dBm
Distance: 20 miles, line of sight
Error Detection: 32-bit CRC (MB8 mode)
Power Supply
Rated Supply Voltage
Wall-Mount
Model: 12/24 Vdc
Low-Voltage
Model: 24/48 Vdc
High-Voltage
Model: 125/250 Vdc 110/240 Vac, 50/60 Hz
Input Voltage Range
Wall-Mount
Model: 9–30 Vdc
Low-Voltage
Model: 18–60 Vdc
High-Voltage
Model: 85–275 Vdc; 85–264 Vac
Power Consumption
Wall Mount: < 5 W
Rack Mount: < 7 W
Type Tests
Communications Equipment Tests
IEEE 1613-2003
Environmental Tests
Enclosure
Protection: IEC 60529:2001
Vibration
Resistance: IEC 60255-21-1:1988 Class 1 Endurance,
Class 2 Response
IEC 60255-21-3:1993
Class 2
Shock
Resistance: IEC 60255-21-2:1988 Class 1 shock withstand,
bump,
Class 2 shock response
Cold: IEC 60068-2-1:2007
–40°C, 16 hours
Damp Heat,
Cyclic: IEC 60068-2-30:2005 25–55°C, 6 cycles, 95%
relative humidity
Dry Heat: IEC 60068-2-2:2007
+85°C, 16 hours
Dielectric Strength and Impulse Tests
Dielectric
(HiPot): IEC 60255-5:2000 IEEE C37.90–2005
Impulse: IEC 60255-5:2000
0.5 J, 5 kV
RFI and Interference Tests
EMC Immunity
Standard: IEEE 1613, Class 2
Electrostatic
Discharge: IEC 61000-4-2:2008 Severity Level 4
8 kV contact discharge
15 kV air discharge
IEEE C37.90.3–2001
Severity Level 4
8 kV contact discharge
15 kV air discharge
Radiated RF
Immunity: IEC 61000-4-3:2008 10 V/m
IEEE C37.90.2–2004
35 V/m
Fast Transient,
Burst
Immunity:
IEC 61000-4-4:2004
4 kV @ 2.5 kHz, and 5.0
kHz for communications
ports, power supply,
alarm contacts
Surge Withstand
Capability
Immunity:
IEC 60255-22-1:2007
2.5 kV common-mode,
1 kV differential-mode
IEEE C37.90.1–2002
2.5 kV oscillatory, 4 kV
fast transient for
communications ports,
power supply, alarm
contacts
Conducted RF
Immunity: IEC 61000-4-6:2008 10 Vrms
Digital Radio
Telephone RF
Immunity:
ENV 50204-1995
Severity Level 10 V/m at
900 MHz and 1.89 GHz
