Select Engineered Systems SAT3 Instructions for use

SAT3 USER / INSTALLER GUIDE
SELECT ENTRY SYSTEMS
User / Installer Guide
SAT3
SAT3/D
SAT
3
Dec 08

SAT3 USER / INSTALLER GUIDE V1.X
S elf Identifying
Automatic
Telephone
3 & 3/D
Select Engineered Systems, Inc. 12/08
7991 West 26th Avenue
Hialeah, Florida 33016
Phone [phone]• Fax [phone]
www.selectses.com

SAT3 USER / INSTALLER GUIDE V1.X
Table of Contents
CHAPTER 1
INTRODUCTION 1
What a SAT3 Does 1
SAT3 Features 1
SAT3 Features (Continued) 2-3
CHAPTER 2
PROGRAMMING 4
HOW TO:
Program a SAT3 4
Get out of program mode 4
Put in a single phone number 5
Take out or remove a phone
Number 5
Put in Second Button Phone Number 5
Call from a PABX 5
Program Pause Time 6
Change SAT3 Talk Time 6
Set SAT3 4-8 Digit Account number 6
Set SAT3 4 digit Zone Number 6
Set SAT3 Account Cycle Time 6
Set SAT3 Account Confirm 7
Put in multiple phone numbers 7
Take out or remove a phone number in a
specific location 8
Change SAT3 Ring Time 8
Set SAT3 Acknowledge Tone 8
Change SAT3 Password 9
Change SAT3 back to Original Factory
Settings 9
Converting SAT3 to Ring Down 10
Set SAT3 To Call a Central Station 10
CHAPTER 3
SAT3 OPERATION 11
How To Remotely Call a SAT3 12
Central Station Operation 12
SAT3 Modem Operation 13-19
C H A P T E R 4
INSTALLATION 20
Installation of SAT3 20
Adjusting SAT3 Audio 21
SAT3 Mounting Template 22
FCC Requirements 23
Specifications 24
Troubleshooting Flow Chart 25
Quick Programming Guide 26

SAT 3 USER / INSTALLER GUIDE
1
SAT3 Self Identifying
Automatic Telephone
Introduction
What a SAT3 Does.
he SAT3 is a telephone device that connects to a telephone line. The SAT3
dials a pre-programmed number, when the PUSH FOR HELP button is
pressed. It can dial up to 9 additional 16-digit phone numbers.
After dialing, it permits two-way voice communication without having to hold a
handset (Hands Free). The amount of time that you can talk on the SAT3 before it
disconnects is programmable from 1 to 9 minutes, or 20 minutes. The SAT3 can
identify itself by sending a 4-8 digit Account number as a series of Touch-Tones.
Another device, like the SATDBRX, can interpret those tones and determine where
the call originated. SAT3 does all of this without requiring an external power source,
because it is telephone line powered.
SAT3 Features.
eatures of the SAT3 include:
Call Progress for dialing phone numbers and for automatic hang-up.
SAT3 detects these Call Progress tones:
Dial Tone
Busy
Fast Busy
Off Hook Alert
Ring Back
Voice
Phone Line Reversal
Disconnect
Chapter
1
T
F
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature
Note: 2 button model
SAT3/D not shown.

SAT 3 USER / INSTALLER GUIDE
2
SAT3 Features, continued.
Stores up to 10 phone numbers up to 16 digits. Depending on the
programming, SAT3 can dial 2 numbers alternating back and forth 5 times, or ten
different phone numbers one after the other. The combinations (up to 10) will
depend on the programming, and can be easily changed.
Touch-ToneDetect. The SAT3 has Touch-Tone detection for:
Remotely hanging up the SAT3.
Sending the 4-8 digit account number on command.
Remote Touch-Tone Programming.
Acknowledging Call. (Lights the flashing Talk LED).
Talk Time.
This is the time from 1 to 9 minutes, in 1-minute increments, or 20 minutes
(fixed), that a SAT3 remains connected for talking, before it times out and
hangs up.
Acknowledge Tone.
If programmed, will light up the flashing TALK light, after the SAT3 places a
call and the Acknowledge Tone has been received.
Password Control.
The SAT3 has a 4 digit-programming password. This is used for remote
programming from a Touch-Tone phone.
Account Cycle Time.
This is how the SAT3 can automatically send its 4 to 8-digit account number.
It does this in 10-second increments.
Account Confirm.
This function, (when programmed to do so), will automatically dial the next
number in it’s memory, if the SAT3 does not send it’s 4 to 8 digit account
number. SAT3 keeps doing this until it does send the account number, or
until it has dialed all the numbers (up to 10 total) programmed into it.
1200/300 Baud modem.
The SAT3 has a 1200/300 Baud modem for remote programming from a
computer, as opposed to a Touch-Tone phone
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature

SAT 3 USER / INSTALLER GUIDE
3
SAT3 Features, continued.
Central Station signals.
This allows the SAT3 to automatically call a central station using the SIA “fast”
format (300 Baud) for off-site monitoring, using central station digital receivers
with two-way voice capability.
Account Number.
The SAT3 allows from a 4 to 8 digit account number, primarily for Central
Station alarm monitoring usage.
Zone Number.
Allows up to 1000 zones, when using a single account code. An example
would be, grouping several SAT3’s on a site together, again for Central Station
alarm monitoring usage.
Second dial button. (SAT3/D only)
The SAT3/D has a second button, to dial a single 16-digit phone number,
such as for further information, or to a different location other than ones
programmed into the 10 pre-programmed locations. The second button when
pressed, will dial a single 16-digit phone number. This number may be used to
call a non-emergency number for instructions, etc. This number will be dialed
once and if not answered, or if the number is busy, the unit will hang up. The
user must press this button again, to try again.
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature

SAT 3 USER / INSTALLER GUIDE
4
SAT3 Programming
How To Program a SAT3(Getting into Program Mode)
he SAT3 can be programmed with the optional hand programmer
(OptSAT3Prgm), or it can be programmed with an ordinary Touch-Tone
telephone. The SAT3 is designed to answer immediately and prompt (with a
beep) for the 4 digit password. SAT3 comes from the factory with all 4 digits
set to 7 (7777 is the password).
To program a SAT3, from a Touch-Tone Phone, get into programming mode by:
☺Calling the SAT3’s phone number.
☺After 1 ring, SAT3 answers and beeps once.
☺From your phone, key in 7777 À.
If the password is valid you will hear two beeps. If the password is not
valid, SAT3 will immediately hang up.
"If you do not key in the password within 5 seconds, SAT3 hangs up.
Once the password is entered, if more than 1 minute goes by with out a key
being pressed on your phone, SAT3 will hang up.
Any programming key press error will cause SAT3 to send a long tone
(Error Tone) instead of 3 beeps (Command Accepted).
How To Get Out of Program Mode.
☺Use your Touch-Tone™ phone to key in 999 À. Then SAT3 can be used
immediately.
Example: To exit program mode, key in 999 À.
"If you simply hang up, the SAT3 cannot be used for at least one minute.
2
T
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature

SAT 3 USER / INSTALLER GUIDE
5
SAT3 Programming Cont.
How To Put in a Single Phone Number
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 10, followed by the phone number, and À.
Example: To make the SAT3 call 555 -1212, key in 10 5551212 À.
You can key in up to 16 digits, for long distance or toll free numbers.
How To Take Out or Remove a Phone number.
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 10, followed by 0, and À.
Example: To make the SAT3 erase 555 -1212, key in 10 0 À
How To Put in SecondButton Phone Number
(SAT3/D onl;y)
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 21, followed by the phone number, and À.
Example: To make the SAT3 call 555 –1212 when 2nd button is pushed, key in 21
5551212 À. It will dial only the programmed phone number and has no central
station capability.
You can key in up to 16 digits, for long distance or toll free numbers.
How To Call from a PABX.
SAT3 can be used behind most Private Automatic Branch Exchange (PABX) systems.
The PABX must be able to send and receive Touch-Tones. Some systems need to dial
an 8 or a 9, and pause briefly before dialing the phone number. The # key on your
phone will add a pause of between 1 and 9 seconds. (Pause time is programmable.)
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 10, followed by 9 # the phone number, and À.
Example: To make the SAT3 dial 555 -1212, from behind a PABX that uses 9 to
get an outside line, and requires a pause, key in 10 9 # 555 1212 À.
"The 9 and the # both count as one digit each of the maximum allowable 16
digit phone number.
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature

SAT 3 USER / INSTALLER GUIDE
6
SAT3 Programming Cont.
How To Program Pause Time Duration.
SAT3 can be set to pause from 1 to 9 seconds when the # key is pressed during
programming. This is useful for overseas exchanges that might require longer pauses.
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 45 and a digit from 1 to 9 and À.
Example: To set the SAT3 Pause Time from the factory default of 2 seconds, to 4
seconds, key in 45 4 À.
How To Change SAT3 Talk Time.
SAT3 can be set to stay active for conversation from 1 to 9 minutes, or 20 minutes.
The factory default talk time is 1 minute. It beeps 3 times, 10 seconds before
disconnecting.
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 41 and a digit from 1 to 9 and À. To set talk time to 20 minutes, key in 0 and
À.
Example: To set the SAT3 Talk Time from the factory default of 1 minute, to 4
minutes, key in 41 04 À.
How To set SAT3 4 – 8 digit Account number.
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 51, the 4 - 8 digit Account number and À.
Example: To change the SAT3 Account number from the factory default of 0000 to
1950 key in 51 1950 À.
"If less than 4 digits are entered the Account number will not change.
How To set SAT3 4 digit Zone number.
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 52, the 4 digit Zone number and À.
Example: To change the SAT3 Zone number from the factory default of 0000 to 2525
key in 52 2525 À.
If less than 4 digits are entered the Zone number will not change.
How To set SAT3 Account Cycle Time.
When the SAT3 has called, it can automatically send it’s 4 - 8 digit Account number in
increments of 10 seconds from 10 to 90 seconds. This is for security or monitoring
equipment, which know how to interpret the tones that SAT3 is sending.
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature

SAT 3 USER / INSTALLER GUIDE
7
SAT3 Programming Cont.
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 53, the Touch-Tone number between 1 and 9 and À.
Example: To set the SAT3 Account Cycle Time from the factory default of 0 (Account
on Command) to every 20 seconds, key in 53 2 À.
Account on Command is when Account Cycle Time is set to 0. To force
the SAT3 to send an Account on Command, press the À.
How To set SAT3 Account Confirm.
When the SAT3 has called, Account Confirm is the function where it must send it’s
Account number at least once. If SAT3 does not send it’s Account number at least
one time, then when it hangs up, it will dial the next number in it’s memory (if
additional numbers have been programmed into the SAT3). If the next number is
called and the Account number was not sent it would dial the next number, and so on,
until all 10 phone numbers (if they were programmed) have been called.
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 54, the Touch-Tone number 1, and À.
Example: To set the SAT3 Account Confirm from the factory default of 0 (No
Account Confirm) to On, key in 54 1 À.
How To Put in Multiple Phone Numbers.
SAT3 can hold up to 10 phone numbers in memory. These phone numbers are stored
in locations. The locations are numbered 10, 11, 12, etc. all the way to 19.
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 10 followed by the location number, followed by the phone number, and À.
Example: To make the SAT3 call 555 -1212 in the first location and 1 800 342-
5737 in the second location, key in 10 5551212 À11 18003425737 À.
Any number can be put in any location. You could put the same number
in all 10 locations and it would call 10 times if it did not send its Account
number when Account Confirm is on. Or, you could put 2 numbers in five
times; alternating locations so that SAT3 tried one number then the other, 5
times in a row.
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature

SAT 3 USER / INSTALLER GUIDE
8
SAT3 Programming Cont.
"Remember, SAT3 dials locations in order, starting at the 1st location it finds
a number: 10, 11, 12, etc. Pay attention to which numbers you put in which
locations, if you desire a specific calling sequence.
How To TakeOutor Remove aPhonenumber In a
SpecificLocation.
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 11 followed by the location number, followed by 0, and À.
Example: To make the SAT3 erase the fifth phone number in memory, key in 14 0
À. (Remember, the first location is 10).
the SAT3 erase all phone numbers in memory, key in
91 1 À.
How To Change SAT3 Ring Time.
SAT3 can be set to ring from 10 to 90 seconds before it quits trying and hangs up.
Ring Time is in 10-second increments. The factory default Ring Time is 40 seconds.
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 44, a digit from 1 to 9, and À.
Example: To set the SAT3 Ring Detect from the factory default of 40 seconds to
60 seconds, key in 44 6 À.
"Do NOT set SAT3 ring time to 10 seconds, unless you have special
circumstances. In most cases, the local phone company can not connect
the SAT3 fast enough to keep the SAT3 from dialing the next stored phone
number, if Ring Time is set to 1 (10 seconds).
How To Set SAT3 Acknowledge tone.
When the SAT3 calls, if an acknowledge tone is pressed by the called party, the green
light will begin flashing. This lets the person using the SAT3 know that the phone call
was received and acknowledged.
After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key in
42, the Touch-Tone number between 1 and 9 and À.
Example: To set the SAT3 Acknowledge tone from the factory default of 0 (which
is disabled) to 1 key in 42 1 À.
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature

SAT 3 USER / INSTALLER GUIDE
9
SAT3 Programming Cont.
How To Change SAT3 Password.
SAT3 password comes from the factory as 7777. This number can be any 4 digits.
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 55, 4 digits from 0000 to 9999, and À.
Example: To set the SAT3 Password from the factory default of 7777 to 1234 (An
incredibly dumb choice), key in 55 1234 À.
"You must key in all 4 digits or your password will not change.
"Make sure you keep your password recorded and stored safely. If you
forget the password, SAT3 may have to be returned to the factory to be
reset.
How To Change SAT3 Back To Original Factory
Settings.
SAT3 can be set back to original factory settings. This is useful if you think you may
have mis-keyed a function, or if you did not realize the consequences of some of your
choices.
☺After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key
in 91 1, and À.
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature

SAT 3 USER / INSTALLER GUIDE
10
SAT3 Programming Cont.
How To Change SAT3 To Ring Down.
SAT3 can be set to function as a ring down type unit. The factory default is Ring
Down mode = OFF.
After getting into program mode, (see Pg. 4) use your Touch-Tone™ phone to key in
43, and 1, and À.
Example: To set the SAT3 from a phone line unit to a Ring Down unit,
key in 43 1 À.
To set the SAT3 back to a phone line unit, key in 43 0 À.
0 = Normal dialing
1 = Ring down.
When set to ring down, SAT3 will NOT dial. There will be no dial tone.
SAT3 just goes off hook and remains off hook until time out. Pressing Àto
force Account on command is operative, and Account cycle is operative.
How To Set SAT3 To CallaCentral Station
SAT3 can be set to call a Central Station using the built-in 300/1200 Baud modem.
Place two pause signals ahead of the phone number and the SAT3 will call the number
and immediately start up the modem.
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature

SAT 3 USER / INSTALLER GUIDE
11
SAT3 OPERATION
he operation of SAT3 is straight forward from the users’ point of view.
Simply push the button. When the PUSH FOR HELP button is depressed,
the red CALLING light will turn on.
There will be a brief dial tone to let the user know SAT3 is starting the call.
"The SAT3 MUST sense a dial tone within 6 seconds, or it will hang up, and
not automatically re-dial again.
After the button is pushed, pushing on it again, (until call is completed) is
ignored.
The audio will be disabled momentarily to keep the dialed number
confidential. After dial out, SAT3 enables the audio to let the caller hear the progress
of the call. If there is no answer, or the line is busy, or there is a circuits busy (reorder),
SAT3 will hang up. If additional numbers (up to 10 total) have been programmed,
SAT3 will automatically dial the next available phone number.
Once the dialed number has been answered, two-way conversation may begin.
Conversation may go on for whatever length of Talk Time was programmed (1 to 9
minutes or 20 minutes.) 10 seconds before SAT3 times out, it will send three beeps to
alert both caller and called party that SAT3 is about to disconnect.
Pressing a 0 before the SAT3 disconnects, will reset the timer to its
programmed value, to extend the conversation.
The called party may force SAT3 to hang up before Talk Time times out
by pressing # on the called party’s phone.
If SAT3 Account Cycle Time has been set (See Pg. 6), it will transmit a 4 digit
Touch-Toneat the programmed intervals (anywhere from 10 to 90 seconds in 10
second increments). If Account Cycle Time was set to 00 (disabled) it will send only
when receiving a Àfrom the called party. This is called Account on Command.
While SAT3 is transmitting its account, account tones may sometimes
interfere with conversation.
Chapter
3
T
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature

SAT 3 USER / INSTALLER GUIDE
12
SAT3 Operation Cont.
After the SAT3 calls, if an acknowledge tone was programmed (See Pg. 8) and
is pressed by the called party, the green light marked TALK, will begin
flashing once per second. This lets the person using the SAT3 know that the
phone call was received and acknowledged. This is useful for the hearing impaired, to
help comply with ADA requirements in some systems.
If the optional Info Button is installed (SAT3D/R only), pushing that button will
automatically call the number stored in the info location. It will NOT dial any
additional phone numbers if it fails to get a response.
HowTo RemotelyCall a SAT3.
☺Call the SAT3 by dialing its number from another phone on another line. When
the SAT3 answers with its acknowledgement beep; press the first 2 digits of the
Password andÀ. (e.g. 77 and À.) This will open the audio channel to permit 2-
way conversation without the SAT3 having first called out by pressing the PUSH
FOR HELP button.
Example: Dial 555-1212 and wait for the beep. Press 77 À. Begin talking.
SAT3 Central Station Operation
The SAT3 has a built-in data modem that will call a Central Station using the universal
SIA 1 (“Fast”) protocol. Placing 2 pause commands (#, #) in front of the phone
number will cause the modem to dial the number and connect with the Central Station
equipment.
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature

SAT 3 USER / INSTALLER GUIDE
13
SAT3 Modem Operation
The SAT3 has a built-in data modem that will connect at 300 or 1200 Baud. Any
modem terminal program that can call at 300 or 1200 Baud can call the SAT3. The
SAT3 screen formatting emulates a VT-100 terminal. After the SAT3 answers, it will
transmit a “PASSW =” prompt. After connection, key in the 4-digit password and
follow all menu prompts. The main menu choices and the secondary menu choices
follow the same functions as normal programming either through a Touch Tone, or
the optional SAT3 Programmer. For example, changing the password is Main menu
choice 5 and sub-menu 5 and then the password, just like 55 and the password is, from
the SAT3 Programmer or a Touch-Tone phone.
Call the SAT3 with a terminal program and a modem capable of communicating at
1200 or 300 baud, with no error correction or compression selected, in the modem
parameters.
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature
Dialing SAT3
SAT3 connected
SAT3
Password Prompt

SAT 3 USER / INSTALLER GUIDE
14
SAT3 Modem Operation (Cont.)
Key in the SAT3’s password (factory default shown here) and press the Enter key.
Everywhere the terminal screen prompts for a CR (Carriage Return) press the Enter
key. You will see the following screen, showing SAT3 firmware version and menu
choices:
To key in SAT3 phone numbers (up to 10) press the 1 key and the Enter key.
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature
SAT3 password
Keyed in
SAT3 Main Screen

SAT 3 USER / INSTALLER GUIDE
15
SAT3 Modem Operation (Cont.)
This will take you to the SAT3 phone menu.
To key in the first number for the SAT3 to dial, press 0, (1st code location) then the
phone number (up to 16 digits) then the Enter key. Everywhere the terminal screen
prompts for a CR (Carriage Return) press the Enter key. In this example, the code
location 0 and the phone number 3055551212 was keyed in. This gives us the
following result::
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature
SAT3 Phone number to
dial in 1st location. (0)

SAT 3 USER / INSTALLER GUIDE
16
SAT3 Modem Operation (Cont.)
Menu 2 (Info Phone) is used only on the (optional) 2-button SAT3/D for
dialing a single 16-digit number for further information or to dial a different
location other than ones programmed into the 10 pre-programmed locations.
The second button when pressed, will dial a single 16-digit phone number.
This number may be used to call a non-emergency number for instructions,
etc. This number will be dialed once and if not answered, or if the number is
busy, the unit will hang up. The user must press this button again, to try again.
To program the Info Phone number, press 1, then the phone number (up to 16-digits)
and press the Enter key.
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature
SAT3 Info Phone #

SAT 3 USER / INSTALLER GUIDE
17
SAT3 Modem Operation (Cont.)
Menu 3 controls relay choices for a related product, the SAT3R.
Since the SAT3 does not support relay functions of any type, this menu may be
ignored, as any choices selected will not affect operation of the SAT3.
ICON KEY
Valuable Info
"Be Careful!
Installers Note
☺User Note
SAT3 Feature
SAT3 Relay Choices
NOT functional
