Selektro CCM 164 User manual

CCM 164 –User Manual –GB / US 0881-1344005 V06
Copyright Selektro A/S 2018
CCM 164
Communication and Control Module
CCM 164 is a control and monitoring module with analog and digital inputs and relay outputs. All inputs and
outputs can be monitored and controlled via SMS (Short Message Service) or via a smartphone app. The
network is defined by the service provider’s SIM card.
oAn analog 4-20 mA input.
oSix digital (24 VDC) or analog (0-10 V) inputs.
oFour relay outputs - two power relays and two switching relays.
The User Manual can be retrieved from www.selektro.dk/ccm under Manuals.
This manual complies from firmware version 2.0.x.
Selektro A/S, Erhvervsvej 29-35, DK-9632 Møldrup, Denmark

CCM 164 –User Manual –GB / UK
2
Contents
Description of the control lamps, buttons and SIM card .......................................................................... 51.
Control lamps .................................................................................................................................... 51.1.
Button................................................................................................................................................ 61.2.
SIM card............................................................................................................................................. 61.3.
Accessories ................................................................................................................................................ 62.
Connection................................................................................................................................................. 73.
Getting started .......................................................................................................................................... 84.
Module name ............................................................................................................................................ 95.
Adding/modifying the module’s name.............................................................................................. 95.1.
Language.................................................................................................................................................... 96.
Modifying language settings ............................................................................................................. 96.1.
Telephone book....................................................................................................................................... 10
7.
Inserting a number into the telephone book .................................................................................. 107.1.
Retrieving contents from the telephone book................................................................................ 107.2.
Deleting numbers in the telephone book ....................................................................................... 117.3.
Current input ........................................................................................................................................... 128.
Setup of current input ..................................................................................................................... 128.1.
Readout value on current input ...................................................................................................... 128.2.
Digital input ............................................................................................................................................. 139.
Setup of digital input ....................................................................................................................... 139.1.
Readout value of digital input ......................................................................................................... 139.2.
Voltage input ....................................................................................................................................... 1410.
Setup of voltage input ................................................................................................................. 1410.1.
Readout value of voltage input ................................................................................................... 1410.2.
Rules .................................................................................................................................................... 1511.
Creating rules............................................................................................................................... 1511.1.
Rules overview............................................................................................................................. 1711.2.
Retrieve rule definition................................................................................................................ 1811.3.
Delete rule ................................................................................................................................... 1811.4.
Counters, times, number of SMS sent and more ................................................................................ 1912.
Reading counter values of inputs ................................................................................................ 1912.1.
Deleting counter values of inputs................................................................................................ 1912.2.
Good to know… ................................................................................................................................... 2013.
Removing a PIN code from a SIM card ........................................................................................ 2013.1.
Retrieving the module’s status information................................................................................ 2013.2.

CCM 164 –User Manual –GB / UK
3
Locking the configuration............................................................................................................ 2013.3.
Manually unlocking the configuration......................................................................................... 2113.4.
Language restrictions, SMS length (GSM 7 bit / Unicode 16 bit) ................................................ 2113.5.
Recommended configurations .................................................................................................... 21
13.6.
Net power fallouts................................................................................................................................... 21
Supply output (+V) overload.................................................................................................................... 21
Configuration of periodical SMS.............................................................................................................. 21
Locking of the module ............................................................................................................................. 22
Problem resolving (troubleshooting) .................................................................................................. 2214.
Overview of commands (short form) .................................................................................................. 2415.
General command definitions:................................................................................................ 2415.1.
Special functions.................................................................................................................................. 3116.
Firmware update ................................................................................................................................. 3217.
Responsibility and guarantee .............................................................................................................. 3418.
Responsibility for CCM 164 and its use ....................................................................................... 3418.1.
Guarantee.................................................................................................................................... 3418.2.
Electrical specifications ....................................................................................................................... 3519.

CCM 164 –User Manual –GB / UK
4
Warning
Always read this User Manual prior to installation.
Installation and use must be in accordance with
applicable rules and good practice.
Warning
Persons with reduced physical capability, sensory or
mental status, must not use this product unless under
appropriate direct supervision or have been instructed
by a person responsible for their safety. Minors must
not use or play with this product.
Warning
The module is not suited for monitoring sensitive
factories or time-critical processes. GSM network
failures of disruptions in net power can affect safety
and monitoring reliability. Do not use OFF outputs to
implement safety-related functions for
systems/machines.
Warning
The module must not be placed in a dangerous
explosive area or in close proximity to medical
equipment.

CCM 164 –User Manual –GB / UK
5
Description of the control lamps, buttons and SIM card1.
Control lamps1.1.
STATUS
Constantly on
on
off
Module recently connected to the power
supply and backup battery is charging.
Slow long flashing
on
off
Module is initializing.
Slow flashing
on
off
Module is ready and everything is OK.
Quick flashing
on
off
There is an error. Refer to MODEM STATUS.
50% on
50% flashing
on
off
EEPROM Error.
Turned off
on
off
No supply voltage. If MODEM STATUS is
flashing the module is using the backup.
NET
STATUS
Slow flashing
on
off
MODEM is operational.
Turned off
on
off
MODEM is turned off.
MODEM STATUS
Slow long flashing
on
off
MODEM is initializing.
Slow short flashing
on
off
Module is using backup. MODEM STATUS
LED is turned off.
Slow flashing
on
off
MODEM is ready with NET connection.
Two quick flashes
on
off
SIM card error.
Quick flashing
on
off
GSM network error.
Turned off
on
off
MODEM is turned off.
50% on/off flashing
on
off
Modem transmitting
NET STATUS
Flashes when the
MODEM is powered
ON.
OUTPUTS
Displays levels for the
4 relay outputs.
MODE
Used for confirmations
and unlocking.
SIM card
Refer to “1.3 SIM card”
Remember that the
card must not have a
PIN code.
STATUS
Flashes slowly when all
is OK. Flashes quickly
when the unit starts or
if there is an error. For
further details refer to
the table below.
MODEM STATUS
Flashes slowly when
the MODEM is ready.
For further details refer
to the table below.
INPUTS
Displays the digital value of
the 6 combined digital and
analog inputs.

CCM 164 –User Manual –GB / UK
6
Button1.2.
The MODE button beneath the cover can be used to unlock the module. Refer to “13.4.
Manually unlocking the configuration”.
SIM card1.3.
Newer versions of the CCM 164 hardware (V2) uses SIM card Nano 12.3 x 8.8 mm type and is
compatible with 1.8V and 3V SIM cards.
Older versions of the CCM 164 hardware (V1) uses SIM card Mini 85.6 x 53.98 mm type and is
compatible with 1.8V and 3V SIM cards.
Note : There must not be a PIN code on the SIM card.
Refer to “13.1. Removing a PIN code from a SIM card”.
Accessories2.
Stub antenna Planar antenna
Stub antenna, order number: 0991-70010001
Planar antenna, order number: 0991-70010003

CCM 164 –User Manual –GB / UK
7
Connection3.
+V
Supply output (20-24V) that can deliver up to 100mA. Can be used to power
external sensors and inputs.
0V
Chassis potential for all inputs and supply voltage +V.
AI1
Current input 4-20mA, reference in relation to 0V.
I1 –I6
These inputs are per default configured as digital inputs (12-24V), they can be
configured as analog inputs (0-10V). When the inputs are configured for
digital, the input resistance is approx. 3 kΩ and the analog approx. 20 kΩ.
L & N
Net supply nominal 230 VAC with external fuse
Q1
Relay contact set 1, terminal 11 –14 is closure (NO).
Q2
Relay contact set 2, terminal 21 –24 is closure (NO).
Q3
Relay contact set 3, terminal 31 –34 is closure (NO)
and 31 –32 is break (NC).
Q4
Relay contact set 4, terminal 41 –44 is closure (NO)
and 41 –42 is break (NC).
For further technical details refer to “19. Electrical specifications”.
External
fuse

CCM 164 –User Manual –GB / UK
8
Getting started4.
1) Mount the module as described in “3. Connection”and in accordance with the specifications in
“19. Electrical specifications”.
2) Insert a SIM card into the holder beneath the cover. Note that the SIM card must not have a PIN
code. Refer to “13.1. Removing a PIN code from a SIM card”.
3) Turn on the power supply and wait 30 seconds until the internal backup battery has charged.
4) The module is ready when the STATUS lamp flashes slowly.
(If necessary, refer to “1.1. Control lamps”)
5) If an error occurred this is indicated with the STATUS LED and/or the MODEM STATUS LED. E.g. in
case of EEPROM error this is indicated with the STATUS LED. Please refer to 1.1 Control lamps for
an overview of error indications.
6) Send an SMS to the telephone number of the SIM card inserted in the module.
Use the text: #sys info
See “13.2. Retrieving the module’s status information”.
7) If the module answered locked in sys info, then the module must be unlocked before you can
continue with the configuration.
Refer to “13.4. Manually unlocking the configuration”.
8) The connection to the module has now been tested.
9) Configuration of the telephone book –Refer to 7. Telephone book and insert the telephone
number that will receive the messages or that will have access to the module.
10) Configuration of messages –Refer to 11. Rules.
You are now underway and there are many exciting features. For example, look at:
oGood to know 13. Good to know…
oCounters 12. Counters, times, number of SMS sent and more
oSpecial functions 16. Special functions
oShort form instructions 15. Overview of commands (short form)

CCM 164 –User Manual –GB / UK
9
Module name5.
There may be multiple controllers each with their own CCM 164 module. A module name can be added so
that it appears at the start of the SMS messages that are sent from the module.
Adding/modifying the module’s name5.1.
<name> = module name
40 characters max
oExample : Set/modify module name :
send reply
oExample : Retrieve module name :
send reply
Language6.
CCM 164 supports the following languages: Danish, English, German, Russian, French and Spanish.
The factory setting is English. The language setting can be modified by using the following command.
Modifying language settings6.1.
<language> = {DA, EN, DE, RU, FR, ES}
oExample : Modify language setting to Danish
send reply
oExample : Confirm language setting
send reply
#N (Randersvej 44)
OK: N defined
#N ?
N = Randersvej 44
#LANG ?
LANG = EN
#LANG <language>
#N (<name>)
#LANG DA
OK: LANG defined

CCM 164 –User Manual –GB / UK
10
Telephone book7.
CCM 164 has a telephone book that includes a list of up to eight telephone numbers [P1...P8]. These
telephone numbers can be configured to receive messages from the module. If the module is locked, then
only the numbers in the telephone book will be capable of communicating with the module. (Refer to
section “13.3. Locking the configuration”)
To obtain an overview of the telephone book’s contents, the content can be retrieved as described in “7.2.
Retrieving contents from the telephone book”.
Inserting a number into the telephone book7.1.
n is the position in the telephone book,
<countrycode>: +45 is the country code for DK,
<phonenumber>: telephone number.
oExample : Position 1 in the telephone book for Danish telephone number 10101010 and
position 2 in the telephone book for Danish telephone number 20202020
send reply
send reply
Retrieving contents from the telephone book7.2.
Retrieve all active telephone numbers.
NB: If the telephone book is empty then an
empty message is returned.
oExample : Retrieve telephone numbers from the module.
send reply
#Pn <countrycode><phonenumber>
#P ?
#P ?
P1=[phone]
P2=[phone]
#P1 [phone]
OK: P1 defined
#P2 [phone]
OK: P2 defined

CCM 164 –User Manual –GB / UK
11
Deleting numbers in the telephone book7.3.
n is the position in the telephone book.
0 = delete
oExample : Position 3 in the telephone book is to be deleted
send reply
#Pn 0
#P3 0
OK: P3 deleted

CCM 164 –User Manual –GB / UK
12
Current input8.
CCM164 has one 4-20mA current input. The following command is used for setting up the current input for
various types of sensors:
n = {1} Current input number.
(txt) User defined input name in parenthesis. Must not be empty.
16 characters max. Characters not allowed: # [ ] ( )
<resolution> Resolution {1, 0.1, 0.01, 0.001}
<unit> Unit name, 5 characters max. Eg. ”bar” for pressure unit.
<low> Low value at 4mA {-99999..99999}
<high> High value at 20mA {-99999..99999}
Setup of current input8.1.
Set up the current input for 0-10m water level:
send reply
Readout value on current input8.2.
Readout value on current input:
send reply
#AIn (txt) R<resolution> U<unit> L<low> H<high>
#AI1 (water) R0.1 Um L0.0 H10.0
OK: AI1 defined
#AI1 ?
Water = 2.0m

CCM 164 –User Manual –GB / UK
13
Digital input9.
CCM164 has 6 inputs, that each can be configured as either analog/voltage or digital inputs. All 6 inputs are
by default configured as digital. The following command is used for setting up an input as digital:
n = {1..6} Input number.
(txt) User defined input name in parenthesis. Must not be empty.
16 characters max. Characters not allowed: # [ ] ( )
D Digital input.
Setup of digital input9.1.
send reply
Readout value of digital input9.2.
send reply
#In (txt) D
#I1 (Lamp 1) D
OK: I1 defined
#I1 ?
Lamp 1 = ON

CCM 164 –User Manual –GB / UK
14
Voltage input10.
CCM164 has 6 inputs, that each can be configured as either analog/voltage or digital inputs. All 6 inputs are
by default configured as digital. The following command is used for setting up an input as analog/voltage:
n = {1..6} Input number.
(txt) User defined input name in parenthesis. Must not be empty.
16 characters max. Characters not allowed: # [ ] ( )
<resolution> Resolution {1, 0.1, 0.01, 0.001}
<unit> Unit name, 5 characters max. Eg. ”bar” for pressure unit.
<low> Low value at 0V {-99999..99999}
<high> High value at 10V {-99999..99999}
Setup of voltage input10.1.
Set up input 1 as voltage input for 0-10bar pressure:
send reply
Readout value of voltage input10.2.
Readout value on input 1 set up as voltage input:
send reply
#In (txt) R<resolution> U<unit> L<low> H<high>
#I1 (pressure) R0.01 Ubar L0.00 H10.00
OK: I1 defined
#I1 ?
pressure = 5.00bar

CCM 164 –User Manual –GB / UK
15
Rules11.
CCM 164 can be programmed with up to 16 rules. These rules can be set up to activate changes in the
output states or activate sending of SMS messages to one or more recipients in the telephone book.
Creating rules11.1.
n = [1..16] Rule position number,
(txt) Rule text in parenthesis. This is the text that will be sent in the SMS, if the rule
is set up for sending an SMS when activated. Must not be empty.
40 characters max. Characters not allowed: # [ ] ( )
<condition> <condition A><operator><condition B>
Condition A and B can be a digital or voltage input { I1..6 }, or a current input {
AI1 }, or another already defined rule with a lower position number { A1..15 },
or a fixed value when comparing with a current or voltage input.
Digital inputs and rules can be treated as ’active low’ by prefixing with the ’!’
character, e.g. ’!I2’
Operator can be: { >, <, &, + }
a. > and < can only be used with current or voltage inputs, and always
in combination with a fixed value or another voltage input as
condition B.
b. ’&’ corresponds to logical AND, and ’+’ corresponds to logical OR .
Can only be used with digital inputs and other rules.
<action> The action that must be performed when the rule is activated. Can be selected
as either changing the state of one or more outputs, or as sending an SMS
message with the rule text to one or more recipients.
Change output state: <output> <output> <output> <output>
<Output> can be: {Qx, !Qx, =Qx, =!Qx, TQx, QxDt, !QxDt}
Qx -> set output high
!Qx -> set output low
=Qx -> output state follows condition state
=!Qx -> output state follows opposite of condition state
TQx -> toggle output once
QxDt -> set output high for ’t’ seconds
!QxDt -> set output low for ’t’ seconds
Multiple outputs can be combined in one action, e.g. Q1 !Q2 TQ3 =Q4
E.g. if output 1 must be activated for 10 seconds: Q1D10
Send SMS message: <phonebook>
#An (txt) <condition> <action>

CCM 164 –User Manual –GB / UK
16
<phonebook>: Defines the positions in the telephone book that a SMS
message must be sent to. E.g. P146 to send to the position 1, 4, and 6 in the
telephone book.
No action: <>
It is allowed to have a rule without an action, and it can for example be used
for logical combinations in the setup of other rules.
oExample 1: When input 4 is activated, the module must send a SMS message with the text
”Door is open”. The message must be sent to position 1 in the telephone book
([phone]), and the rule must be stored in rule position 1 A1.
send reply
oExample 2: When input 4 is deactivated, the module must send a SMS message with the
text ”Door is closed”, the message must be sent to P1 ([phone]) and another recipient
with phone number [phone].
oFirst set up the new phone number.
send reply
oCreate rule 2
send reply
#A1 (Door is open) I4 P1
OK: A1 defined
#P3 [phone]
OK: P3 defined
#A2 (Door is closed) !I4 P13
OK: A2 defined

CCM 164 –User Manual –GB / UK
17
oExample 3: Set up current input for 0-10m water level. Send SMS message ”water high” til
P1, if the water level is above 1m.
send reply
send reply
Example 4: Send message ”water high and door open” to P1, if the door is open (I4 active)
and AI1>1.0m, using the previously defined rules.
send reply
Rules overview11.2.
To get an overview of which rule positions are already in use, the module can return a message with a list
of the active rules.
Note: An empty message will be returned if there are no active rules.
oExample:
send reply
#A3 (water high) AI1>1.0 P1
OK: A3 defined
#A ?
Defined rules:
A1 A2
#A ?
#A4 (water high and door open)
A1&A3 P1
OK: A4 defined
#AI1 (water) R0.1 Um L0.0 H10
OK: AI1 defined

CCM 164 –User Manual –GB / UK
18
Retrieve rule definition11.3.
oExample: Retrieve definition for rule number 1
send
reply
Delete rule11.4.
Rules can be deleted one at a time with the following command:
m = [1..16] rule position number
oExample: You wish to delete rule number 2 (Door is closed).
send reply
#A1 ??
#A1 (Door is open) I4 P1
#An ??
#Am 0
#A2 0
OK: A2 deleted

CCM 164 –User Manual –GB / UK
19
Counters, times, number of SMS sent and more12.
The module has possibilities for reading various counters. This includes the number (quantity) of activations
of inputs and outputs, as well as how long they have been active. Various events are also logged, for
example the number of SMS messages sent and counts of the various error conditions.
The following counters are defined:
r = [1..6] Analog/Digital input 1..6
r = [81..84] Relay output 1..4
r = 200 Number of Net power fallouts.
r = 201 Number of (+V) 20-24 V supply output short circuits.
r = 202 Number of alarms that have been generated.
r = 203 Number of SMS transmission attempts (including failures).
r = 204 Numbers of SMS that were not sent due to errors.
r = 205 Number of communication errors with the MODEM.
Further details can be found in 15. Overview of commands (short form) under #C
Reading counter values of inputs12.1.
r = [1..6] is the number of the
analog/digital inputs
oExample : It is requested to read the time that input 4 has been active.
send reply
Deleting counter values of inputs12.2.
r = [1..6] is the number of the digital inputs
oExample : It is requested to delete the counter values for input 4.
send reply
Note:
When reading time the drepresents days.
The numbers are stored in the module’s permanent memory every tenth minute, and as a result the
precision is not better than every tenth minute.
#Cr ?
#C4 ?
C4: 9 activation time:
1d 02:15:24
#Cr 0
#C4 0
OK: C4 reset

CCM 164 –User Manual –GB / UK
20
Good to know…13.
Removing a PIN code from a SIM card13.1.
Mount the SIM card in a mobile phone. If the telephone shows that the card requires a SIM or PUK code
under startup, then use the telephone’s configuration menu to disable this code. Confirm that the code has
been disabled by powering the telephone off and on again. If the telephone does not request the code then
the SIM card is ready for use in the module.
Retrieving the module’s status information13.2.
CCM 164 has a status message that informs of the model name, version number, active functions, the time
the module has been connected to the power network, as well as whether the module’s configuration is
locked or open for change. Sys info can be retrieved from all telephone numbers, even if the module is
locked.
Retrieve
sys info:
reply
Module name = Module’s name. Refer to 5. Module name.
days + time = the time the module has been powered on.
CCM164 = module name.
M02 = module type.
FW = program version in the module.
DA = Danish. The language that has been selected.
F = xxxx, being the selected functions. Refer to 16. Special functions.
locked / unlocked = lock status of the configuration. Refer to 13.4. Manually unlocking the
configuration.
Locking the configuration13.3.
The module can be locked such that it is only the numbers in the telephone book that can read and modify
the module’s configuration and outputs.
Lock the module so that only users in the
telephone book have access.
Unlock the module so that all users have access.
#lock
#unlock
#sys info
”Module name” ”days + time”. CCM164 - M02 FW v01.01 DA. F=0000 –
unlocked
