Sencor SSI 0910RS Repair manual

EN STEAM GENERATOR
Translation of the original manual
SSI 0910RS

SSI 0910RS

A
2
3
5
7
6
8
1
9
10
4
11

B
ECO
SET
2
3
4
5
7
6
8
1
C
1
D

- 1 - Revision 03/2022
Copyright © 2022, Fast ČR, a.s.
EN Steam generator
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
General warnings
• This appliance may be used by children 8years of
age and older and by persons with physical or mental
impairments or by inexperienced persons, if they are
properly supervised or have been informed about how
to use the product in asafe manner and understand the
potential dangers.
• Children must not play with the appliance. Cleaning
and maintenance performed by the user must not be
performed by unsupervised children.
• In the event that the power cord is damaged, have it
repaired at aprofessional service centre to prevent causing
adangerous situation. It is forbidden to use the appliance if
it has adamaged power cord.
• The iron must not be left without supervision when
connected to mains power.
• Always disconnect the iron from the power socket when
leaving it without supervision, when filling up or emptying
the water tank and when you have finished using it.
• The water tank lid must not be open when ironing. The
refilling of the water tank is described in the relevant
chapter of this user'smanual.

- 2 - Revision 03/2022
Copyright © 2022, Fast ČR, a.s.
• The iron and the base unit may be used and placed only
on astable, even surface. When putting the iron down on
the base unit, check that the surface on which the base
unit is located is stable.
• The iron must not be used if it has fallen on the floor,
exhibits visible signs of damage or if it is leaking.
• The iron must not be left within the reach of children
younger than 8years of age, when it is connected to
mains electricity or while it is cooling down.
Attention:
The surfaces of the iron may become hot during
use.
Electrical safety
• Before connecting the base unit to apower socket, make sure the voltage stated on its rating label corresponds to the voltage in your power socket.
• Connect the base unit only to aproperly grounded socket. Do not use an extension cord.
• Do not touch the iron with wet or damp hands when it is connected to apower socket.
• To avoid potential injury by electrical shock, do not clean the iron or the base unit under running water, do not spray it with water and do not
submerge it in water or any other liquid.
• Ensure that the power cord does not come into contact with water, moisture or ahot surface.
• Do not place heavy items on the power cord. Make sure the power cord does not hang over the edge of atable and that it is not touching ahot
surface or sharp objects.
• Disconnect the base unit from the power socket by gently pulling the plug of the power cord, and not the power cord itself. Otherwise, this could
damage the power cord or the socket.
• Do not pull or carry the base unit by the power cord. Do not pull the iron by the steam hose.
• To avoid the danger of injury by electrical shock, do not repair the iron or the base unit yourself or make any adjustments to it. Have all repairs
performed at an authorised service centre. By tampering with the product you risk voiding your legal rights arising from unsatisfactory performance
or quality warranty.
• If the power cord is damaged, have it replaced at aspecialised service centre. It is forbidden to use the base unit if it has adamaged power cord or
plug. Proceed in the same way in the event of adamaged steam hose.
Safety during use
• This iron is designed for home use. Do not use it in industrial surroundings or outdoors.
• Do not place the iron on or near an electric or gas stove or other sources of heat.
• Never iron clothing on abody.
• Do not touch the hot ironing surfaces. Otherwise, this could cause burns.
• Never fill the water tank directly underneath awater tap. Always use asuitable container for filling the water tank. Never add vinegar, descaling
agents or other additives to the water tank.
• Prior to cleaning or any other handling of the iron and the base unit, ensure that you have disconnected from the power socket, allow the soleplate
to cool down.
• Prior to using this appliance, please read the user'smanual thoroughly, even in cases, when one has already familiarised themselves with previous
use of similar types of appliances. Only use the appliance in the manner described in this user’smanual. Keep this user'smanual in asafe place
where it can be easily retrieved for future use. In the event that you hand this appliance over to somebody else, make sure to also include this
user'smanual.
• Carefully unpack the appliance and take care not to throw away any part of the packaging before you find all its parts. We recommend saving the
original cardboard box, packaging material, purchase receipt and responsibility statement of the vendor or warranty card for at least the duration of
the legal liability for unsatisfactory performance or quality. In the event of transportation, we recommend that you pack the appliance in the original
box from the manufacturer.

- 3 - Revision 03/2022
Copyright © 2022, Fast ČR, a.s.
• Prior to using this appliance, please read the user'smanual
thoroughly, even in cases, when one has already familiarised
themselves with previous use of similar types of appliances. Only use
the appliance in the manner described in this user’smanual. Keep this
user'smanual in asafe place where it can be easily retrieved for future
use. In the event that you hand this appliance over to somebody else,
make sure to also include this user'smanual.
• Carefully unpack the appliance and take care not to throw away any
part of the packaging before you find all its parts. We recommend
saving the original cardboard box, packaging material, purchase
receipt and responsibility statement of the vendor or warranty card for
at least the duration of the legal liability for unsatisfactory performance
or quality. In the event of transportation, we recommend that you pack
the appliance in the original box from the manufacturer.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE APPLIANCE
A1 Water tank cap
A2 Iron holders
A3 Base unit with water tank and
iron rest pad
A4 Steam release button
A5 Steam hose wind-up
compartment
A6 Steam hose holders
A7 Lock/release iron from the
base unit
A8 Display and the control
buttons
A9 Handle
A10 Steam hose
A11 Iron rest pad
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B1 Automatic iron shut-off
indicator
B2 ECO mode indicator
B3 Steam ironing indicator
Flashing – heating up
Lit – temperature reached
B4 Low water level in tank
indicator
B5 Iron cleaning button
B6 Main switch
B7 Iron descaling/cleaning
indicator
B8
SET button for toggling
between high steam mode
and ECO mode with less
steam
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
C1 Filling hole
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEFORE FIRST USE
• Before first use, remove all packaging or protective materials including
promotion stickers and labels from the iron and the base unit.
• Wipe the iron'ssoleplate with alightly dampened cloth before first use
and then wipe dry. Using adry or lightly dampened cloth, also clean
the outer parts of the iron and then wipe it dry.
• Clean the surface of the base unit using asoft cloth.
Warning:
Never submerge the iron and the power cord of the
base unit in water or any other liquid!
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FILLING THE WATER TANK
• The water tank on the base unit is intended to be filled with tap water.
Limescale deposits may quickly form if you live in an area with hard or
very hard water. To extend the lifetime of the iron, it is recommended
to mix the tap water with distilled water. The ratio of distilled water to
tap water is as follows:
–1:1 for medium hard water
–2:1 for hard water
–3:1 for very hard water
Note:
Your local water utility will provide information about the
water hardness in your area.
Warning:
Never add water softeners, vinegar, starch, descaling
agents, perfumes or other additives to the water.
• Prior to filling the water tank with water, the base unit must be
disconnected from the power socket and located on astable and
horizontal surface.
• Prepare asuitable container and fill it up with water. Tilt open the cap
of the filling opening and slowly pour the water from the container into
the filling opening of the water tank. Make sure that the water level
does not rise above the maximum water level mark on the water tank.
• After filling the water tank, close the filling hole cap. In the event that
you spilled any water while filling, thoroughly dry everything that is
wet.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TURNING ON
• Connect the power cord of the base unit to apower socket and press
the main switch on the iron. The indicator will be lit on the
display and the iron is ready for use.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
REMOVING THE IRON FROM THE BASE UNIT
• To take the iron off the base unit, it is necessary to first release the iron
by turning the lock/release safety towards the open padlock symbol.
The iron can be taken off the base unit before or after it is turned on.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IRONING WITH STEAM
Warning:
In order to iron with steam, the water tank must be
filled with asufficient amount of water.
Note:
The iron is equipped with electronic temperature control,
which enables the ironing of all types of fabrics that are
suitable for ironing and in whatever order and without the
need to set the temperature or garment class.
• The iron is equipped with the following two steam output intensity
levels that are toggled using the SET: button.
ECO
The ECO mode is intended for sufficient steam output for
standard ironing with low power use; it uses less steam and
saves power without affecting the ironing result.
This mode is intended for maximum steam output for
demanding or vertical ironing.
• Press the SET button to select the steam mode
ECO
or and
wait until the indicator of the selected mode remains permanently lit.
• Holding down the steam button on the iron will start releasing steam
while ironing.
EN Steam generator
User'smanual

- 4 - Revision 03/2022
Copyright © 2022, Fast ČR, a.s.
• If you wish to stop releasing steam, release the steam button.
• We recommend to select
ECO
mode for all standard ironing tasks.
Only when ironing linen fabrics, strong silk or similar fabrics is it
recommended to select the mode.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IRONING WITH VERTICAL STEAM
• The iron can also be used when ironing hanging textiles (e.g. curtains,
garments hanging on coat hangers, etc.).
• Use the SET button to select mode and wait until the indicator
remains permanently lit.
• Position the iron into avertical position. Use one hand to gently
tension the fabric and vertically move the iron from bottom up and
press the steam button to release steam.
Warning:
Never point the current of steam at persons or
animals.
Never attempt to remove creases from garments that
somebody is wearing.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
STEAM SURGE FUNCTION
• When ironing particularly large creases, the steam boost function
can be used. Quickly pressing the steam button twice will activate
the function and the iron will release astrong steam boost for 2
seconds.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DETECTION OF ABSENCE OF WATER
• In the event that the water level in the water tank declines below
the maximum water level during the ironing process, the indicator
will start flashing and the pump inside the base unit will
automatically shut off. This will prevent damaging the base unit
and extend the lifetime of the appliance. In such acase, disconnect
the base unit from the power socket and add water as described in
chapter FILLING THE WATER TANK.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRIP-STOP SYSTEM
• The iron is equipped with the Drip-Stop system, which automatically
stops water supply when the set temperature is insufficient for
generating steam and thereby prevents potential dripping of hot
water out of the steam outlets.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PUTTING THE IRON ASIDE WHILE IRONING
• During the ironing process, you can put the iron aside either on its rest
pad or on the rest pad of the base unit.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TIPS FOR QUALITY IRONING
• Follow the ironing instructions for each individual garment. Only iron
colourfast and heat resistant laundry. We recommend ironing laundry
with aprint turned inside out.
• Never iron over places that have sweat marks or other stains. The high
temperature fixes the stain in place, making it difficult to remove.
• To avoid silk, wool and synthetic fabrics from being shiny after ironing,
iron them from the underside.
• Some materials are easier to iron when they are lightly damp.
• Spray fine fabrics before ironing them or iron them under alightly
dampened wiping cloth. You can also hold the iron approx. 2cm
above the laundry and use the ECO steam release mode.
• Iron very crumpled garments in the high steam mode.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AUTOMATIC SHUT-OFF WHEN IDLE
• If you leave the iron idle for 10 minutes or do not press any button, the
iron will beep and shut itself off automatically. The indicator will
light up on the display.
Warning:
Despite the iron being equipped with an automatic
shut-off function, for safety reasons, never leave it
without supervision when it is connected to amains
power socket.
• In the event that the iron has automatically shut itself off, press the
SET button. The indicator will start flashing and when it is lit, the
iron is again ready for use.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TURNING OFF
• Press and hold down main switch for at least 2seconds. The iron will
shut off.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLEANING AFTER USE
Warning:
Before cleaning, the base unit must be disconnected
from the power socket and the iron must have cooled
down.
When cleaning, do not submerge the iron or the power
cord of the base unit in water or any other liquid.
• Open the cap of the water tank filling hole and empty out any
remaining water over asink. Close the cap.
• Wipe the dirty soleplate, the surface of the iron or the rest surface of
the base unit with alightly dampened cloth and then wipe dry.
• For cleaning, do not use steel wool, solvents or cleaning products with
an abrasive effect, etc. to prevent damaging the surface being cleaned.
REMOVING LIMESCALE DEPOSITS
• For the removal of limescale deposits from the inner part of the
soleplate, the iron is equipped with aself cleaning function. When the
indicator starts flashing on the display, it is necessary to clean
the iron as soon as possible in the following procedure:
–Fill the water tank with clean water up to the maximum water level
mark. Connect the base unit to apower socket and after releasing
the lock/release safety (if it was locked), take the iron off the base
unit.
–Turn the iron on using the main switch and wait until the indicator
is lit on the display.
–Hold the iron in ahorizontal position above the sink. Hold down
the button for at least 3 seconds. Steam and hot water will start
to be released from the soleplate. At the same time also limescale
deposits from the inner parts of the soleplate will be removed. To
achieve better cleaning results, you can tilt the iron from side to
side several times.
–When it beeps, the cleaning process if finished. Turn off the iron
using the main switch and place it on the rest pad, securing it in
place with the safety.
• Then disconnect the base unit from the power socket.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

- 5 - Revision 03/2022
Copyright © 2022, Fast ČR, a.s.
STORAGE
• When you have finished ironing and cleaning the iron according to
the chapter above, wind the power cord into the bottom part of the
base unit.
• Secure the iron on the rest pad of the base unit.
• Place the complete steam generator in asuitable location so that it
cannot be tipped over.
Warning:
Keep the stored steam generator away from extreme
temperatures, direct sunlight and excessive humidity
and do not store it in an overly dusty environment. Do
not place any items on to the stored steam generator.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TECHNICAL SPECIFICATIONS
Rated voltage range......................................................................... 220−240 VAC
Rated frequency...........................................................................................50/60Hz
Rated power input.........................................................................2,800 - 3,200W
Heating up time (approximately)........................................................................ 35 s
Continuous steam output in the ECO mode................................ 120 ± 5 g/min
Continuous steam output in the high steam mode................... 140 ± 5 g/min
Water tank capacity................................................................................................ 1.3l
Base unit dimensions (length × width × height).....................................................
....................................................................................249 mm × 220 mm × 312 mm
Iron dimensions (length × width × height)...... 265 mm × 124 mm × 119 mm
Weight .....................................................................................................................2,7kg
Changes to text and technical parameters are reserved.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF
USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your
municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that
used electric or electronic products must not be added to
ordinary municipal waste. For proper disposal, renewal and
recycling, hand over these appliances to determined
collection points. Alternatively, in some European Union
states or other European countries you may return your
appliances to the local retailer when buying an equivalent
new appliance. Correct disposal of this product helps save
valuable natural resources and prevents potential negative effects on the
environment and human health, which could result from improper waste
disposal. Ask your local authorities or collection facility for more details. In
accordance with national regulations penalties may be imposed for the
incorrect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic equipment, ask your retailer
or supplier for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this
product, request the necessary information about the correct disposal
method from the local council or from your retailer.
This product meets all the basic requirements of EU
directives related to it.

FAST ČR, a.s.
U Sanitasu 1621
CZ-251 01 Říčany
www.sencor.eu
