Sennheiser A 200 audioport User manual

Instruction manual
A 200
Hearing Amplier

Important safety information
A 200 | 1
Important safety information
왘Please read this instruction manual carefully and completely before
using the product.
왘Make this instruction manual easily accessible to all users at all
times. Always include this instruction manual when passing the
product on to third parties.
왘This instruction manual is also available on the Internet at 
www.sennheiser.com.
Preventing health problems
왘Setthevolumetoalowlevelwhenusingtheproduct.Toprotectyour
hearing, avoid listening at high volume levels for long periods of
time.
The product generates stronger permanent magnetic fields that could
cause interference with cardiac pacemakers and implanted defibrilla-
tors (ICDs).
왘Always maintain a distance of at least 3.94” (10 cm) between the
ends of the earbows with the ear pads and the cardiac pacemaker or
implanted defibrillator.
Preventing damage to the product
왘Always keep the product dry and do not expose it to extreme tem-
peratures (normal operating temperatures: 5°C/41°F to 40°C/
104°F).
왘Use the product with care and store it in a clean, dust-free environ-
ment.
왘Switchthepersonalsoundamplifieroff afterusetoconservebattery
power. Remove the batteries if the personal sound amplifier will not
be used for extended periods of time.
왘Use only the supplied power supply unit.
왘Clean the product only with a soft, dry cloth.
왘Do not use the product if it visibly damaged, if it has been dropped
or if liquids or objects have gotten into the product. In this case,
contact a qualified service center or your Sennheiser service partner
to have the product tested.
왘Use only attachments/accessories/spare parts supplied or recom-
mended by Sennheiser.
Preventing damage to the mains unit
왘To reduce the risk of fire or electric shock, do not expose the mains
unit to rain or moisture.

Important safety information
2 | A 200
왘Unplugthemainsunit fromthe wall socket tocompletelydisconnect
theproductfromthemains,duringlightningstormsorwhenunused
for long periods of time.
왘Only operate the mains unit from the type of power source specified
in the specifications chapter (see page 9).
왘To prevent heat accumulation, always ensure that the mains unit is
in a safe operating condition and easily accessible, properly plugged
intothewallsocket and notcoveredorexposedtodirectsunlightfor
longer periods of time.
Intended use
This product is designed for private domestic use. The personal sound
amplifierissuitableforpeoplewhomay sometimesneedtorelyonarti-
ficial assistence for their hearing.
“Improper use” means using the product
• other than as described in this instruction manual,
• under operating conditions which differ from those described in this
instruction manual.
Safety instructions for the nickel metal hydride batteries
If abused or misused, the A 200’s rechargeable battery may leak. In
extreme cases, it may even present
Please understand that Sennheiser doesnot accept liability fordamage
arising from abuse or misuse.
• a heat hazard,
• a fire hazard,
•anexplosionhazard,
• a smoke or gas hazard.
Keep away from
children. Only charge rechargeable batteries with the charger
recommended by
Sennheiser.
Only charge recharge-
able batteries at
ambient temperatures
between 10°C/50°F 
and 40°C/104°F.
Whennotusingrechargeable
batteries for extended
periods of time, charge 
them regularly (about 
every 3 months).

Delivery includes
A 200 | 3
Delivery includes
1 A 200 personal sound amplifier
1 L 200 charger
1 NT 12-2T plug-in power supply unit 
(country-specific, EU or US) for L 200
1 BA 151 rechargeable battery
2 pairs of spare ear pads
1 set of sealing tape
1 instruction manual
Do not expose to
moisture. Observe correct polarity.
Do not mutilate or
dismantle. Switch rechargeable battery- powered products off after
use.
Do not heat above 
70°C/158°F, e.g. do 
not expose to sunlight 
or throw into a fire.
Pack/store charged bat-
teries so that the terminals
cannot contact each other –
danger of shorting out/fire
hazard.
Immediately remove
rechargeable batteries
from an obviously
defective product.
Do not continue to use
defective rechargeable
batteries.
Only use rechargeable
batteries specified by
Sennheiser.
Dispose of rechargeable
batteries at special collec-
tion points or return it to
your specialist dealer.
A list of accessories can be found on the A 200 product
page at www.sennheiser.com. For information on suppliers,
contact your local Sennheiser partner: www.sennheiser.com >
“Service & Support“.

Product overview
4 | A 200
Product overview
Putting the L 200 charger into operation
Setting up the charger
왘Place the charger on a flat, even surface and use a non-slip pad.
1Ear pads
2Microphones
3Balance control 
(at the rear)
4Battery compartment
5On/off/sound amplification
control
6Indicator for sound
amplification
7Charging compartment for A 200
8DC socket for connection of 
mains unit
9Charging compartment for
optional spare rechargeable
battery
0Charging indicator for optional
spare rechargeable battery
AChargingindicatorfortheA200’s
rechargeable battery
CAUTION
Risk of staining furniture surfaces!
Furniture surfaces are often treated with varnish, polish or synthetics
which might cause stains when they come into contact with other syn-
thetics such as the device feet.
왘Do not place the charger on delicate surfaces; if necessary, place a
pad under the charger.
7
4
5
6
1
2
3
9
8
2
A0

Charging and replacing the rechargeable battery
A 200 | 5
Connecting the charger to the mains
왘Connect the connector of the mains unit to the socket 8on the
charger (12 V DC).
왘Connect the mains unit to a wall socket. The charger is ready for
operation.
To disconnect the charger from the mains:
왘Unplug the mains unit from the wall socket.
Chargingandreplacingtherechargeablebattery
The rechargeable battery can be charged whilst installed in the A 200
or separately in the charging compartment at the side of the charger.
왘Before using the rechargeable battery for the first time, charge it for
at least 16 hours. With a fully charged rechargeable battery, the
operating time is up to 12 hours.
Charging the A 200 with the rechargeable battery installed
왘After use, place the A 200 into the charging
compartment without exerting too much
pressure, making sure the Sennheiser logo is at
the front.
왘When the A 200 is placed correctly, the
indicator
Alights up green.
8
EU
US
A

Using the A 200 personal sound amplifier
6 | A 200
Charging the rechargeable battery in the charging compartment at
the side of the charger
1Pullthe rechargeablebattery outof theA 200’s batterycompartment.
2Insert the rechargeable battery into the charging compartment at
the side of the charger. When the rechargeable battery is inserted
correctly, the indicator 0lights up green.
3Slide the rechargeable battery into the A 200’s battery compart-
ment as far as it will go.
With a spare BA 151 rechargeable battery (to be ordered separately),
you can use the A 200 formore than twice the time. You can charge the
spare rechargeable battery while using the supplied one and replace
one with the other when needed.
Using the A 200 personal sound amplifier
WARNING
Danger of hearing damage!
Listening at high volume levels for long periods can lead to per-
manent hearing defects.
왘Before putting the A 200 on, set the volume to a low level.
왘Then adjust a comfortable sound amplification.
WARNING
Interference due to magnetic fields!
The product generates stronger permanent magnetic fields that
couldcause interferencewith cardiacpacemakersand implanted
defibrillators (ICDs).
왘Alwaysmaintainadistanceofatleast 3.94”(10 cm)between
the ends of the earbows with the ear pads and the cardiac
pacemaker or implanted defibrillator.
1 2 3
0

Using the A 200 personal sound amplifier
A 200 | 7
Switching the A 200 on/off
왘Turntheon/off/sound amplification control 5towardsON untilyou
overcome a slight resistance.
Adjusting the sound amplification
You can choose between 6 different settings for the sound
amplification 6. Position “1” corresponds to a low sound amplification
and position “6” corresponds to a very high sound amplification.
왘Use the control 5to adjust the volume to a sufficient and comfort-
able level.
왘If you hear a loud noise (feedback), turn the control 5towards OFF
until the noise disappears.
5
6
5

Cleaning and maintaining the product
8 | A 200
Adjusting the balance
Thebalancecontrol allows forright/leftvolume adjustment. Adjust the
balance so that you hear equally well with both ears. If necessary, have
the balance adjusted by your hearing aid acoustician.
왘Using a 2 mm slotted screwdriver, turn the balance control 3to
the left Lor right Rin order to increase the volume for the corre-
sponding ear.
Adjusting the bass attenuation
왘Use the two supplied sealing tapes to seal the small holes in back of
the headphone systems of the A 200.
Cleaning and maintaining the product
왘Before cleaning, disconnect the charger from the mains.
왘Only use a slightly humid cloth to clean the product.
The more holes you seal with the sealing tape,
the greater is the bass attenuation. This increases
the speech intelligibility without increasing the
volume – which is an advantage for people with a
hearing impairment at high frequencies.
CAUTION
Liquids can damage the electronics of the product!
Liquids entering the housing of the product can cause a short-circuit
and damage the electronics.
왘Keep all liquids far away from the product.
왘Do not use any solvents or cleansing agents.
3
R
L

Specifications
A 200 | 9
Cleaning and replacing the ear pads
The product is supplied with two pairs of ear pads in different fits. You
canchange tothese ear padsto optimize thewearing comfort,if neces-
sary. Other spare ear pads are available from your Sennheiser partner.
1Carefully remove the ear pads from the A 200.
2Clean the ear pads with warm soapy water and rinse thoroughly. Let
the ear pads air dry.
Specifications
A 200 personal sound amplifier
Frequency response 200 - 12,000 Hz
Max. SPL (at 1 kHz) 105 dB
Acoustic amplification, stereo max. 35 dB
Pick-up pattern of microphones omni-directional
Supply voltage 2.4 V
Current consumption approx. 5 mA
Operating time up to 12 hours
Weight (incl. rechargeable battery) approx. 51 g
L 200 charger and BA 151 rechargeable battery
Input voltage L 200 12 V
Current consumption L 200 approx. 20 mA
Charging outputs (2x) max. 7 mA/max. 2.8 V
Charging time of 
rechargeable battery  approx. 16 hours
BA 151 rechargeable battery
nickel metal hydride: 2.4 V, 80 mAh
1 2

Specifications
10 | A 200
NT 12-2T plug-in power supply unit in accordance with
The NT 12-2T plug-in power supply unit is certified in accordance with
the safety requirements of legislation in Europe, the US, Canada and
Australia.
NT 12-2T plug-in power supply unit (country-specific, EU or US)
Nominal input voltage 100–240 V~
Input current max. 50 mA 
@ 240 V/50 Hz, full load
Mains frequency 50–60 Hz
Nominal output voltage 12 V DC
Nominal output current max. 250 mA
Stand-by power consumption ≤0.3 W
Energy efficiency DOE Level VI
Temperature range Operation: 0°C to +40°C
Relative humidity Operation: max. 80%, 
non condensing
Europe EMC: EN 55013, EN 55020
Safety:EN 60950-1
USA EMC: 47CFR15_B
Safety:UL 60950-1
Canada EMC: ICES-003
Safety:CAN/CSA-C22.2 NO. 60950-1
Australia EMC: AS/NZS 4268
Safety:AS/NZS 60950-1

Manufacturer declarations
A 200 | 11
Manufacturer declarations
Warranty
Sennheiser electronic GmbH & Co. KGgives a warranty of 24 months on
this product. For the current warranty conditions, please visit our
website at www.sennheiser.com or contact your Sennheiser partner.
FOR AUSTRALIA ONLY
Sennheisergoodscomewith guaranteesthat cannot beexcludedunder
the Australian Consumer Law. You are entitled to a replacement or
refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if thegoods fail to beof acceptable quality and the
failure does not amount to a major failure. This warranty is in addition
to other rights or remedies under law. Nothing in this warranty
excludes,limits,or modifies anyliabilityof Sennheiser whichis imposed
by law, or limits or modifies any remedy available to the consumer
which is granted by law.
To make a claim under this warranty, contact Sennheiser Australia Pty
Ltd, Unit 3, 31 Gibbes Street Chatswood NSW 2067, Australia; Phone:
[phone], email: se[email protected].
All expenses of claiming the warranty will be borne by the person
making the claim.
The Sennheiser International Warranty is provided by Sennheiser Aus-
tralia Pty Ltd (ABN 68 165 388 312), Unit 3, 31 Gibbes Street Chats-
wood NSW 2067 Australia.
In compliance with the following requirements:
• WEEE Directive (2012/19/EU)
Please dispose of this product by taking it to your local collec-
tion point or recycling centre for such equipment.
• Battery Directive (2013/56/EU)
The supplied rechargeable battery can be recycled. Please
dispose of it as special waste or return it to your specialist
dealer. In order to protect the environment, only dispose of
exhausted batteries.

Manufacturer declarations
12 | A 200
CE Declaration of Conformity
• EMC Directive (2004/108/EC)
• RoHS Directive (2011/65/EC)
• Low Voltage Directive (2006/95/EC)
• ErP Directive (2009/125/EG)
The declaration is available at www.sennheiser.com.
In compliance with:
Europe
Australia/
New Zealand
Canada CAN ICES-3 (B)/NMB-3(B)

Sennheiser electronic GmbH & Co. KG
Am Labor 1, 30900 Wedemark, Germany
www.sennheiser.com
Publ. 12/15, 566667/A01
