Sennheiser 100 - 01-09 User manual

Instrucciones de uso
Manual de instruções
Instruction manual
Notice d’emploi
Instruction manual
Istruzioni per l’uso
Gebruiksaanwijzing
EK 100
C
M
Y
CM
MY
CY
CMY
K

1
Contents
Important safety instructions .......................................................................... 2
The EK 100 G3 diversity receiver ..................................................................... 3
The frequency bank system .......................................................................... 3
Areas of application ........................................................................................ 4
Delivery includes .................................................................................................. 4
Product overview ................................................................................................. 5
Overview of the EK 100 G3 diversity receiver ............................................ 5
Overview of the displays ................................................................................ 6
Putting the diversity receiver into operation ............................................... 7
Inserting the batteries/accupack ................................................................. 7
Charging the accupack .................................................................................... 7
Mounting the diversity receiver to a camera ............................................ 7
Using the diversity receiver .............................................................................. 9
Switching the diversity receiver on/off ..................................................... 9
Deactivating the lock mode temporarily ................................................. 10
Selecting a standard display ..................................................................... 10
Using the operating menu ............................................................................. 11
The buttons .................................................................................................... 11
Overview of the operating menu ............................................................... 11
Working with the operating menu ............................................................ 12
Adjusting settings via the operating menu .............................................. 14
The main menu “Menu” .............................................................................. 14
The extended menu “Advanced Menu” ................................................... 16
Synchronizing a transmitter with the diversity receiver ........................ 19
Cleaning the diversity receiver ..................................................................... 21
Recommendations and tips ........................................................................... 21
If a problem occurs ... ....................................................................................... 22
Accessories ......................................................................................................... 23
Specifications .................................................................................................... 23
Manufacturer Declarations ............................................................................. 24
Index .................................................................................................................... 26
For further information, visit the EK 100 G3 product page on
our website at www.sennheiser.com.

2
Important safety instructions
Important safety instructions
• Read this instruction manual.
• Keep this instruction manual. Always include this instruction manual
when passing the product on to third parties.
• Heed all warnings and follow all instructions in this instruction manual.
• Use only a cloth for cleaning the product.
• Do not place the product near any heat sources such as radiators, stoves,
or other devices (including amplifiers) that produce heat.
• Only use attachments/accessories specified by Sennheiser.
• Refer all servicing to qualified service personnel.
Servicing is required if the product has been damaged in any way, liquid
has been spilled, objects have fallen inside, the product has been
exposed to rain or moisture, does not operate properly or has been
dropped.
• WARNING: To reduce the risk of short circuits, do not use the product
near water and do not expose it to rain or moisture.
Replacement parts
When replacement parts are required, be sure the service technician
uses replacement parts specified by Sennheiser or those having the same
characteristics as the original part. Unauthorized substitutions may result
in fire, electric shock, or other hazards.
Intended use
Intended use of the EK 100 G3 diversity receiver includes:
• having read these instructions especially the chapter “Important safety
instructions”,
• using the product within the operating conditions and limitations
described in this instruction manual.
“Improper use” means using the product other than as described in this
instruction manual, or under operating conditions which differ from those
described herein.

3
The EK 100 G3 diversity receiver
The EK 100 G3 diversity receiver
This diversity receiver is part of the evolution wireless series generation 3
(ew G3). With this series, Sennheiser offers high-quality state-of-the-art
RF transmission systems with a high level of operational reliability and
ease of use. Transmitters and receivers permit wireless transmission with
studio-quality sound.
Features of the evolution wireless 100 G3 series:
• Optimized PLL synthesizer and microprocessor technology
•HDX noise reduction system
• Adaptive diversity technology
• Switching bandwidth of 42 MHz
• Scan function (Easy Setup) for scanning the frequency banks for unused
channels
Adaptive diversity
This diversity receiver uses the ground connection of the line cable as its
second antenna to provide improved reception.
The frequency bank system
The diversity receiver is available in 6 UHF frequency ranges with
1,680 receiving frequencies per frequency range:
Each frequency range (A–E, G) offers 21 frequency banks with up to
12 channels each:
Each of the channels in the frequency banks “1” to “20” has been factory-
preset to a fixed receiving frequency (frequency preset). The factory-
preset frequencies within one frequency bank are intermodulation-free.
These frequencies cannot be changed.
For an overview of the frequency presets, please refer to the supplied
frequency information sheet. Updated versions of the frequency informa-
tion sheet can be downloaded from the EK 100 G3 product page on our
website at www.sennheiser.com.
The frequency bank “U” allows you to freely select and store receiving
frequencies. It might be that these receiving frequencies are not intermod-
ulation-free (see page 19).
516 – 558 566 – 608 626 – 668 734 – 776 780 – 822 823 – 865
Range A: Range G: Range B: Range C: Range D: Range E:
Frequency bank 1 ... 20
Frequency bank U
Channel 12 – frequency preset
Channel 1– frequency preset
Channel 2– frequency preset
Channel 12 – freely selectable frequency
Channel 1– freely selectable frequency
Channel 2– freely selectable frequency

4
Delivery includes
Areas of application
The receiver can be combined with the following transmitters:
These transmitters are available in the same UHF frequency ranges and
are equipped with the same frequency bank system with factory-preset
frequencies. An advantage of the factory-preset frequencies is that
• a transmission system is ready for immediate use after switch-on,
• several transmission systems can be operated simultaneously on the
preset frequencies without causing intermodulation interference.
Delivery includes
The packaging contains the following items:
1 EK 100 G3 diversity receiver
2 AA size batteries, 1.5 V
1 CA 2 camera adapter
1 CL 100 line cable
1 CL 1 line cable
1 instruction manual
1 frequency information sheet
Bodypack
transmitter Radio microphone
Plug-on
transmitter
SK 100 SKM 100 SKP 100

5
Product overview
Product overview
Overview of the EK 100 G3 diversity receiver
쐃3.5 mm jack socket (LINE), lockable
(the ground contact is used by antenna II)
쐇Antenna I
쐋Operation and battery status indicator, red LED
lit = ON
flashing = LOW BATT
쐏RF signal indication, green LED
lit = RF
쐄Charging contacts
쐂SET button
쐆왖/왔rocker button (UP/DOWN)
쐊Battery compartment
쐎Battery compartment cover
쐅Battery compartment catches
쐈Infra-red interface
쐉ON/OFF button with ESC function (cancel)
씈Display panel, backlit in orange
쐇
쐋
쐏
쐂
쐄
쐉
쐈
쐄
씈
쐊
쐎
쐅
쐅
쐃
쐆

6
Product overview
Overview of the displays
After switch-on, the diversity receiver displays the “Frequency/Name”
standard display. For further illustrations and examples of the different
standard displays, refer to page 10.
The display backlighting is automatically reduced after approx. 20 seconds.
Display Meaning
햲RF level “RF”
(Radio Frequency)
Diversity display:
Antenna input I is active
Antenna input II is active
RF signal level:
Field strength of the received signal
Squelch threshold level
햳Audio level “AF”
(Audio Frequency)
Modulation of the transmitter
Peak hold function
When the display shows full
deflection, the audio input level
is excessively high.
For details, see page 16.
햴Frequency Current receiving frequency (see page 16)
햵Name Freely selectable name of the receiver
(see page 16)
햶Lock mode icon Lock mode is activated (see page 10)
햷Battery status Charge status:
approx. 100%
approx. 70%
approx. 30%
charge status is critical, the red
LOW BATT LED 쐋
is flashing :
햸Muting function
“MUTE”
“Mute” is only displayed on the “Frequency/
Name” standard display (see page 10) when
the transmitter’s RF signal is deactivated.
The diversity receiver does then not output
an audio signal.
or line output level
AF OUT
The line output level AF OUT is only
displayed on the “Frequency bank/Channel/
Name” standard display (see page 10).
햹Pilot tone “P”Activated pilot tone evaluation
(see page 18)
MHz
823.925
ew100 G3
P
AFRF
MUTE
햲 햳 햴햵
햶
햷햸햹
RF
AF
쐋

7
Putting the diversity receiver into operation
Putting the diversity receiver into
operation
Inserting the batteries/accupack
For powering the diversity receiver, you can either use two 1.5 V AA size
batteries or the rechargeable Sennheiser BA 2015 accupack or the DC 2
power adapter (see “Accessories” on page 23).
왘Open the battery compartment by pushing the two catches 쐅in the
direction of the arrows and open the cover 쐎.
왘Insert the two batteries or the accupack as shown above. Please
observe correct polarity when inserting the batteries/accupack.
왘Close the battery compartment by pressing on the center of the
cover 쐎.
The battery compartment cover 쐎locks into place with an audible
click.
Charging the accupack
To charge the BA 2015 accupack:
왘Insert the diversity receiver into the L 2015 charger (see “Accessories”
on page 23).
Mounting the diversity receiver to a camera
Use the supplied CA 2 camera adapter to mount the receiver to a camera’s
flash mount.
왘Determine where on the perforated plate 씉the flash mount
adapter 씊will need to be fastened so that the receiver can best be
attached to the camera.
왘At this position, place a square nut 씋under the perforated plate 씉.
왘Fasten the flash mount adapter 씊to the perforated plate 씉using the
square nut 씋.
The L 2015 charger can only charge the combination BA 2015
accupack/diversity receiver. Standard batteries (primary cells) or
individual rechargeable battery cells cannot be charged.
쐎
쐎
쐄
쐅
씉
씊
씋

8
Putting the diversity receiver into operation
왘Lift one side of the belt clip 씌as shown.
왘Press down the belt clip 씌at one fixing point and pull it out of the
receiver housing.
왘Repeat for the other side.
왘Place the perforated plate 씉onto the rear of the receiver.
왘Reinsert the belt clip 씌.
왘Use one of the supplied line cables to connect the line input of the
camera to the socket 쐃.
The ground connection of the line cable serves as the antenna for
the second diversity section. For details on the connector assign-
ment, refer to the diagram on page 24.
씌
쐃

9
Using the diversity receiver
Using the diversity receiver
To establish a transmission link, proceed as follows:
1. Switch the diversity receiver on (see next section).
2. Switch a transmitter on (see the instruction manual of the transmitter).
The transmission link is established and the receiver’s RF level display
“RF”햲reacts.
If you cannot establish a transmission link between transmitter and
receiver, read the chapter “Synchronizing a transmitter with the diversity
receiver” on page 19.
Switching the diversity receiver on/off
왘Push the two battery compartment catches 쐅and open the battery
compartment cover 쐎.
To switch the diversity receiver on:
왘Press the ON/OFF button 쐉.
The red ON LED 쐋lights up and the standard display “Frequency/
Name” appears on the display panel.
To switch the diversity receiver off:
왘Keep the ON/OFF button 쐉pressed until “OFF” appears on the display
panel.
The red ON LED 쐋goes off and the diversity receiver switches off.
It is vital to observe the notes on frequency selection on page 19.
When in the operating menu, pressing the ON/OFF button 쐉will
cancel your entry (ESC function) and return you to the current
standard display.
쐉
쐋
쐎
쐅
쐅

10
Using the diversity receiver
Deactivating the lock mode temporarily
You can activate or deactivate the automatic lock mode via the “Auto
Lock” menu item (see page 16). If the lock mode is activated, you have to
temporarily deactivate it in order to be able to operate the receiver:
The lock mode icon 햶flashes prior to the lock mode being activated again.
Selecting a standard display
For more detailed information, refer to the chapter “Overview of the
displays” on page 6.
왘Press the SET button.
“Locked” appears on the display panel.
왘Press the rocker button.
“Unlock?” appears on the display panel.
왘Press the SET button.
– When you are in the operating menu, the lock mode remains
deactivated until you exit the operating menu.
– When one of the standard displays is shown, the lock mode
is automatically activated after 10 seconds.
왘Press the ON/OFF button to select a standard display.
Contents of the display Selectable standard display
“Frequency/Name”
with “MUTE” display 햸
“Frequency bank/Channel/Name”
with display of the line output level
“AF OUT”햸
SET
SET
MHz
823.925
ew100 G3
P
AFRF
MUTE
ON/OFF
MHz
823.925
ew100 G3
P
MUTE
AFRF
B.Ch: 1. 1
ew100 G3
P 0
AFRF

11
Using the operating menu
Using the operating menu
A special feature of the Sennheiser ew G3 series is the consistent, intuitive
menu structure of transmitters and receivers. As a result, adjustments to
the settings can be made quickly – even in stressful situations, for example
on stage or during a live show or presentation.
The buttons
Overview of the operating menu
Button Function of the button
Press the ON/OFF button • Switches the diversity receiver on and off
• Selects a standard display (see page 10)
• Cancels the entry and returns to the current
standard display (ESC function)
Press the SET button • Changes from the current standard display
to the operating menu
• Calls up a menu item
• Enters a submenu
• Stores the settings and returns to the
operating menu
Press the rocker button • Changes to the next/previous menu item
• Changes the setting of a menu item
Display Function of the menu item Page
Main menu “Menu”
Sync Synchronizes a transmitter with the diversity
receiver 14
Squelch Adjusts the squelch threshold 14
Easy Setup Scans for unused frequency presets, releases
and selects frequency presets 15
Frequency Preset Sets the frequency bank and the channel 15
Name Enters a freely selectable name 16
AF Out Adjusts the audio output level 16
Auto Lock Activates/deactivates the automatic lock mode 16
Advanced Calls up the extended menu “Advanced Menu” 16
Exit Exits the operating menu and returns to the
current standard display –
ON/OFF
SET
Main menu
“Menu”
Sync
Squelch
Easy Setup
Frequency Preset
Name
AF Out
Auto Lock
Advanced
Exit Tune
Pilot Tone
LCD Contrast
Reset
Software Revision
Exit
Extended menu
“Advanced Menu”
Reset List
Current List
Scan New List
Exit
“Easy Setup”

12
Using the operating menu
Working with the operating menu
By way of example of the “Frequency Preset” menu, this section describes
how to use the operating menu.
Changing from a standard display to the operating menu
Selecting a menu item
Changing and storing settings
Extended menu “Advanced Menu”
Tune Sets the receiving frequencies for the
frequency bank “U”16
Sets the channel and the receiving frequency
for the frequency bank “U” 17
Pilot Tone* Activates/deactivates the pilot tone evaluation 18
LCD Contrast Adjusts the contrast of the display panel 18
Reset Resets the settings made in the operating
menu 18
Software Revision Displays the current software revision 18
Exit Exits the extended menu “Advanced Menu”
and returns to the main menu –
If the lock mode is activated, you have to deactivate it In order to
be able to work with the operating menu (see page 10).
왘Press the SET button.
The current standard display is replaced by the main menu.
The last selected menu item is displayed.
왘Press the rocker button to change to the “Frequency Preset”
menu item.
The current setting of the selected menu item is displayed:
왘Press the SET button to call up the menu item.
왘Press the rocker button to set the frequency bank.
왘Press the SET button to confirm your selection.
왘Press the rocker button to set the channel.
왘Press the SET button to store the setting.
Display Function of the menu item Page
SET
Menu
Frequency Preset
B.Ch: 1. 1
Menu
B.Ch: 1. 1
Frequency Preset
B.Ch:
823.925MHz
Frequency Preset
1. 1 B.Ch:
Frequency Preset
“Stored”
SET SET
SET
2. 2
823.925MHz
Call up “Frequency
Preset”
Select the frequency
bank and confirm
Select the channel;
store the setting
SET
SET
SET

13
Using the operating menu
Canceling an entry
To subsequently return to the last edited menu item:
Exiting a menu item
To return to the next higher menu level:
To directly return to the current standard display:
왘Press the ON/OFF button to cancel the entry.
The current standard display appears on the display panel.
왘Press the SET button repeatedly until the last edited menu
item appears.
왘Change to the “Exit” menu item.
왘Confirm your selection.
You return to the next higher menu level.
왘Press the ON/OFF button.
ON/OFF
SET
Menu
Exit
SET
ON/OFF

14
Adjusting settings via the operating menu
Adjusting settings via the operating
menu
The main menu “Menu”
Synchronizing a transmitter with the diversity receiver – “Sync”
You can synchronize a suitable transmitter of the ew 100 G3 series with
the diversity receiver. During synchronization, the following parameters
are transferred to the transmitter:
• Current receiving frequency (“Frequency Preset”, see page 15)
• Current name set for the receiver (“Name”, see page 16)
• Current pilot tone setting of the receiver (“Pilot Tone”, see page 18)
To transfer these parameters:
왘Switch the transmitter and the diversity receiver on.
왘On the receiver, call up the “Sync” menu item.
“Sync” appears on the display panel of the receiver.
왘Place the infra-red interface of the transmitter (see the instruction
manual of the transmitter) in front of the infra-red interface of the
receiver 쐈.
The parameters are transferred to the transmitter. When the transfer
is completed, “ ” appears on the display panel of the diversity
receiver. The receiver then switches back to the current standard
display.
To cancel the transfer:
왘Press the ON/OFF button 쐉on the receiver.
“ ” appears on the display panel of the receiver. “ ” also appears if:
– no transmitter was found or the transmitter is not compatible,
– no transmitter was found and the synchronization process was
canceled after 30 seconds,
– you canceled the transfer.
Adjusting the squelch threshold – “Squelch”
Adjustment range: “Low”, “Middle”, “High”, can be switched off
The squelch eliminates annoying noise when the transmitter is switched
off or when there is no longer sufficient transmitter power received by the
receiver.
왘Adjust the squelch threshold – with the transmitter switched off – to
the lowest possible setting that suppresses hissing noise.
쐈
Menu
Low
Squelch
Call up “Squelch” Select the
desired setting
Store the setting
“Stored”
SET
SET
Squelch Squelch
Low High

15
Adjusting settings via the operating menu
The squelch should only be switched off for servicing purposes. With the
squelch threshold set to “Low”, you switch the squelch off by keeping the
DOWN rocker button pressed for 3 seconds.
If you have accidentally switched off the squelch:
왘Press the UP rocker button to switch the squelch on.
Scanning for, releasing and selecting frequency presets –
“Easy Setup”
Selecting the frequency bank and the channel –
“Frequency Preset”
Overview of the frequency banks and channels:
If the squelch threshold is set to “High”, the transmission range
will be reduced under unfavourable reception conditions.
Display Squelch is ...
... switched on.
The dotted line 햻displays the squelch
threshold.
... switched off.
The dotted line 햻goes off and the audio
level display “AF” shows full deflection
(hissing noise).
Menu item Function of the menu item
Reset List Releases all locked frequency presets
Current List Selects an unused frequency preset
Scan New List Automatically scans for unused receiving frequencies
(frequency preset scan). If receiving frequencies are used,
they will be locked; if receiving frequencies are unused,
they will be released. After the frequency preset scan,
you can select an unused frequency preset.
When setting up multi-channel systems, please observe the
following:
Only the factory-preset receiving frequencies within one
frequency bank (“1” to “20”) are intermodulation-free. It is vital
to observe the notes on frequency selection on page 19.
Frequency bank Channels Type
“1” to “20”up to 12 per
frequency bank
System bank:
frequencies are factory-preset
“U” up to 12 User bank:
frequencies are freely selectable
P
MHz
823.925
ew100 G3
AFRF
MUTE
햻
P
MHz
823.925
ew100 G3
AFRF
햻
P
Menu
B.Ch: 1. 1
Frequency Preset
B.Ch:
823.925MHz
Frequency Preset
1. 1 B.Ch:
Frequency Preset
“Stored”
SET SET
SET
2. 2
823.925MHz
Call up “Frequency
Preset”
Select the frequency
bank and confirm
Select the channel;
store the setting

16
Adjusting settings via the operating menu
Entering a name – “Name”
Via the “Name” menu, you can enter a freely selectable name (e.g. the
name of the performer) for the receiver. The name is displayed on the
standard display (see page 6). The name can consist of up to 8 characters
such as:
• letters (without pronounciation marks),
•numbersfrom0to9,
• special characters and spaces.
To enter a name, proceed as follows:
Adjusting the audio output level – “AF Out”
Adjustment range: –30 dB to +12 dB, adjustable in 6-dB steps
Via the “AF Out” menu item, you can adjust the level of the audio output
Line from the receiver to the input of the connected camera.
Activating/deactivating the automatic lock mode – “Auto Lock”
The lock mode prevents that the diversity receiver is accidentally switched
off or programed during operation. The lock mode icon 햶on the
current standard display indicates that the lock mode is activated. For
information on how to use the lock mode, refer to page 10.
The extended menu “Advanced Menu”
To get into the extended menu “Advanced Menu”:
왘From the main menu, select “Advanced”.
Setting the receiving frequencies for the frequency bank “U” –
“Tune”
왘Press the rocker button to select a character.
왘Press the SET button to change to the next segment/character
or to store the complete entry.
When you have selected one of the system banks and then select
the “Tune” menu, the diversity receiver automatically switches to
channel 1 of the frequency bank “U”. In this case, “U.1” briefly
appears on the display panel.
Upon delivery, the channels of the frequency bank “U” are not
assigned a receiving frequency.
Menu
Lichael
Name
Name Name
Lichael Michael
“Stored”
Call up “Name” Enter a character
and confirm
Enter a character;
store the setting
SET
Call up “ AF Out ”Select the desired
setting
0 dB
AF Out
0 dB 0 dB
AF Out
Menu
Store the setting
“Stored”
SET
SET
AF Out
+ 6 dB
Active
Auto Lock
Active
Auto Lock
Inactive
Auto Lock
Menu
“Stored”
SET
SET
Call up
“Auto Lock”
Select the desired
setting
Store the setting

17
Adjusting settings via the operating menu
Via the “Tune” menu item, you can set a receiving frequency to be stored
in the current channel or you can select a different channel in the
frequency bank “U” and assign this channel a receiving frequency.
Setting a receiving frequency for the current channel
Selecting a channel and assigning this channel a frequency
왘Set the desired frequency (MHz and kHz section) as described in the
previous chapter.
왘Press the rocker button until the “Tune” menu item appears.
왘Press the SET button.
The MHz section of the receiving frequency of the channel is
highlighted.
It is vital to observe the notes on frequency selection on page 19.
왘Press the rocker button to set the MHz section of the
frequency.
왘Press the SET button to confirm the MHz section of the
frequency.
The kHz section of the frequency is highlighted.
왘Press the rocker button to set the kHz section of the frequency.
왘Press the SET button to confirm the frequency.
“Stored” appears on the display panel. The “Tune” menu item
appears again.
왘Press the rocker button until the “Tune” menu item appears.
왘Press the SET button and keep it pressed until the frequency
bank is highlighted.
왘Press the rocker button to set the channel.
왘Press the SET button to confirm the channel.
The frequency (MHz section) is highlighted.
SET
Tune
B.Ch: U1. 1
Tune
Advanced Menu
Tune
“Stored”
823.925 MHz
823.925 MHz
B.Ch: U1. 1
823.925 MHz
SET SET
SET
Select the frequency
bank and confirm
Select the channel;
store the setting
Call up “Tune”
(special function)
SET
SET
SET
Tune
B.Ch: U1. 1 B.Ch: U5. 1
Tune
Advanced Menu
Tune
“Stored”
823.925 MHz
823.925 MHz 823.925 MHz
SET SET
SET
Select the frequency
bank and confirm
Select the channel;
store the setting
Call up “Tune”
(special function)
SET

18
Adjusting settings via the operating menu
Activating/deactivating the pilot tone evaluation – “Pilot Tone”
The transmitter adds an inaudible signal, known as the pilot tone, to the
transmitted signal. The diversity receiver detects and evaluates the pilot
tone. The pilot tone supports the diversity receiver’s squelch function, thus
protecting against interference due to RF signals from other devices.
Observe the following when combining a transmitter or receiver of the
ew 100 G3 series (generation 3) with devices from an earlier evolution
wireless generation:
Adjusting the contrast of the display panel – “LCD Contrast”
You can adjust the contrast of the display panel in 16 steps.
Resetting the settings made in the operating menu – “Reset”
When resetting the settings made in the operating menu, only the
selected settings for the pilot tone and for the frequency bank “U” remain
unchanged. For an overview of the factory-preset default settings, refer to
the supplied frequency information sheet.
Displaying the software revision – “Software Revision”
You can display the current software revision of the diversity receiver.
Display Meaning
No icon The pilot tone evaluation is deactivated.
The pilot tone evaluation is activated but the receiver does
not receive a pilot tone.
The pilot tone evaluation is activated. The receiver receives
a pilot tone.
Devices of the ew 100 G1 series (generation 1) do not support the
pilot tone function.
Transmitter Receiver Make sure to ...
w G3/ w G2 w G3/ w G2 ... activate the pilot tone function
on both transmitter and diversity
receiver.
w G3 w G1 ... deactivate the pilot tone function on
the ew 100 G3 transmitter.
w G1 w G3 ... deactivate the pilot tone function on
the ew 100 G3 diversity receiver.
Name
Advanced Menu
Pilot Tone
Active
Active
Pilot
Inactive
Pilot
“Stored”
Call up
“Pilot Tone”
Select the desired
setting
Store the setting
Call up
“LCD Contrast”
Select the desired
setting
Store the setting
Name
Advanced Menu
LCD Contrast
7
7
LCD Contrast
“Stored”
LCD Contrast
10
Advanced Menu
Reset Yes
Reset
“Stored”
SET
SET
Select the desired
setting; apply the
setting
Call up “Reset”

19
Synchronizing a transmitter with the diversity receiver
Synchronizing a transmitter with the
diversity receiver
Upon delivery, transmitter and diversity receiver are synchronized with
each other. If, however, you cannot establish a transmission link between
transmitter and diversity receiver, you have to synchronize the channels of
the devices:
왘Deactivate the RF signal on all transmitters (see the instruction manual
of the transmitter).
This prevents that, during the frequency scan, the channels used by
switched-on transmitters are displayed as “used”.
왘With a diversity receiver, perform a frequency preset scan to scan the
frequency banks for unused channels (“Scan New List”, see page 15).
왘Select a frequency bank and a channel on this diversity receiver
(“Current List”, see page 15).
If you want to set up a multi-channel system, select a frequency bank
with a sufficient number of unused channels for all planned transmis-
sion links.
왘Synchronize a transmitter with the diversity receiver (see page 14).
The receiver’s frequency, name and pilot tone setting are transferred to
the transmitter.
OR:
왘Manually set the transmitter to the same frequency bank and channel
that you set on the receiver.
왘Activate the RF signal on this transmitter.
The transmission link is established.
If you want to set up a multi-channel system:
왘Repeat the following 4 steps for each additional transmission link:
– Perform a frequency preset scan with the next diversity receiver.
– Select a channel from the same frequency bank as with the first
diversity receiver.
– Synchronize a transmitter with the diversity receiver.
– Activate the RF signal on the transmitter.
Using freely selectable receiving frequencies
You can also freely select the receiving frequencies and store these
frequencies in the frequency bank “U”.
왘Set each diversity receiver to the frequency bank “U”.
When synchronizing a transmitter with a diversity receiver, please
observe the following:
왘Only use a transmitter and a diversity receiver from the same
frequency range (see the type plates on the transmitter and
the diversity receiver).
왘Make sure that the desired frequencies are listed in the
enclosed frequency information sheet.
You can also contact your Sennheiser partner who will be
pleased to calculate intermodulation-free frequencies for you.
왘Make sure that the desired frequencies are approved and
legal in your country and, if necessary, apply for an operating
license.
It might be that the freely selected frequencies are not inter-
modulation-free
If you use frequencies from the frequency bank “U”, it might be
that the frequencies are not intermodulation-free.
왘Contact your Sennheiser partner who will be pleased to
calculate intermodulation-free frequencies for you (see
www.sennheiser.com).
