Senninger Xi-Wob UP3 610 User manual

Call [phone] • Web: www.senninger.com
®
PULL
PINCH
PINCH
Nozzle Removal
C
L
I
C
K
PLACE
PLACE
Nozzle Installation Nozzle Visibility
Whole sizes Half sizes
Notches
MS-1026
10 XiWUP3-IN 09
Xi-Wob® UP3TM
Recommended installation
1 2
ENGINE MODULES
Xi-Wob UP3 Bracket Assembly
XIW3BRASM-UP3
610 (Blue deflector)
6-Groove 10-Degree
XIWEMASM610
615 (Black deflector)
6-Groove 15-Degree
XIWEMASM615
910 (Gray deflector)
9-Groove 10-Degree
XIWEMASM910
605-TOP (White deflector)
6-Groove 5-Degree
Top of pipe
XIWEMASM605T
UP3 Nozzle
#7 - #24
UP3NZ07 - UP3NZ24
UP3 Dual Nozzle Carrier
UP3NZCD
Always be sure that the engine module is secured tightly onto the bracket.
Component Assembly

Call [phone] • Web: www.senninger.com
®MS-1026
10 XiWUP3-IN 09
Xi-Wob System Assembly
Mounting (Semi-Rigid)
1.TheXi-Wobisdesignedformountingonsemi-rigid
polyethyleneorsteeldrops.DonotusePVC.
2.MounttheXi-Wobnomorethan1ft.[0.3m]belowtrussrod.
3.SeeSenningerGooseneckbrochureforadditional
mountingoptions.
Pressure Regulator Location
1.Pressureregulatorscanbeinstalledatthetopofthedrop,
orneartheapplicator.
2.Alwaysfollowyourcustomizedprintoutforproper
pressureregulatorplacement.
 Important:Tomaintainproductwarrantyandmaximizedropcomponentlife,
refertotheinformationanddiagramshere.
Performance Data
610 (Blue)
6-Groove 10-degrees
Medium Droplets
615 (Black)
6-groove 15-degrees
Large Droplets
910 (Grey)
9-groove 10-degrees
Small Droplets
605 (White)
6-groove 5-degrees
Medium Droplets
Nozzle sizes
Minimum #77/64"[2.78mm] #105/32"[3.97mm] #105/32"[3.97mm] #105/32"[3.97mm]
Maximum* #243/8"[9.53mm] #243/8"[9.53mm] #243/8"[9.53mm] #243/8"[9.53mm]
Flows
Minimum 1.12gpm[254L/hr] 2.25gpm[511L/hr] 2.25gpm[511L/hr] 2.25gpm[511L/hr]
Maximum 14.4gpm[3271L/hr] 14.4gpm[3271L/hr] 14.4gpm[3271L/hr] 12.06gpm[2739L/hr]
Maximum Spacing**
at6ft[1.8m]groundclearance 18ft[5.49m] 20ft[6.10m] 18ft[5.49m] 20ft.[6.10m]
Operating Press. at the noz.
Minimum 10psi[0.69bar] 10psi[0.69bar] 10psi[0.69bar] 10psi[0.69bar]
Maximum 15psi[1.03bar] 15psi[1.03bar] 15psi[1.03bar] 10psi[0.69bar]
*Itisrecommendedthatlargernozzlesizesbeusedonlyonsoilsandslopesthatcanhandlehigherapplicationrates.
**ForoptimumperformanceSenningerrecommendstheuseofmaximumspacingfor1-2spansonly.
Maintenancenote:KeepXi-Wobsabovecropcanopywhenoutletspacingexceeds10ft[3m].Thisisespeciallyimportantonhighprolecrops.
Notwarrantedforrigidinstallationonoffsetsorboomslongerthan10.5ft.[3.2m].Longeroffsetsandboomsrequireaminimum2ft.[0.61m]reinforcedexhose.
Minimumgroundclearance:
3ft.[0.91m]
