Hunter X-CORE Operating instructions

Owner’s Manual and
Programming Instructions
XCORE

Residential Irrigation Controller
SEASONAL ADJUSTMENT WATER DAYS
START TIMES
SYSTEM OFF CURRENT TIME/DAY
RUN TIMES
ACTIVE
SENSOR BYPASS
RUN
MANUAL-ONE STATION

SEASONAL ADJUSTMENT
WATER DAYS
START TIMES
SYSTEM OFF
CURRENT TIME/DAY
RUN TIMES
ACTIVE
SENSOR BYPASS
RUN
MANUAL SINGLE STATION

3
XCORE COMPONENTS...................................................................4
MOUNTING THE CONTROLLER TO WALL .......................................8
CONNECTING VALVES AND TRANSFORMER .................................9
ACTIVATING THE BATTERY .......................................................... 10
REPLACING THE BATTERY ........................................................... 10
CONNECTING A MASTER VALVE.................................................... 11
CONNECTING A PUMP START RELAY............................................12
CONNECTING A HUNTER “CLIK” WEATHER SENSOR ...................13
Testing the Weather Sensor ........................................................13
Manually Bypassing the Weather Sensor ....................................13
CONNECTING A HUNTER SOLAR SYNC ET SENSOR ................. 14
Installing Solar Sync Sensor ....................................................... 14
Installing the Wireless Solar Sync............................................. 14
Solar Sync Settings .................................................................... 14
Region

..................................................................................15
Water Adjustment

.................................................................16
Uninstalling a Solar Sync Sensor ................................................ 14
Calibration/Setup .......................................................................17
SOLAR SYNC DELAY FEATURE ...................................................18
CONNECTING A HUNTER REMOTE................................................19
Connecting to a Hunter Remote (not included) ...........................19
To install the SmartPort connector..............................................19
POWER FAILURES......................................................................19
PROGRAMMING THE CONTROLLER ............................................20
Setting the Date and Time .....................................................21
Setting the Program Start Time(s) .........................................21
Eliminating a Program Start Time ...............................................21
Setting Station Run Times ......................................................21
Setting Days To Water ...........................................................21
Selecting Specic Days of the Week to Water .............................21
Selecting Odd or Even Days to Water ......................................... 22
Selecting Interval Watering .................................................22
Setting Event Day(s) O............................................................. 22
Automatic Watering ...............................................................22
System O ...........................................................................22
Programmable Rain O..............................................................23
Seasonal Adjustment ............................................................ 23
Manually Run a Single Station 1.............................................23
One-Touch Manual Start and Advance .......................................24
ADVANCED FEATURES.............................................................. 25
Programmable Sensor Override................................................. 25
Test Program of All Stations....................................................... 25
Hunter Quick Check Diagnostics............................................... 25
Easy Retrieve™ Program Memory..............................................26
Programmable Delay Between Stations.....................................26
Resetting Controller / Clearing Controllers Memory ..................26
Clik Delay Instructions................................................................ 27
TROUBLESHOOTING GUIDE..........................................................30
SPECIFICATIONS........................................................................... 33
Operating Specications ............................................................ 33
Electrical Specications.............................................................. 33
Explanation of Symbols.............................................................. 33
CERTIFICATE OF CONFORMITY TO EUROPEAN DIRECTIVES ..34
TABLE OF CONTENTS

XCORE COMPONENTS
LCD Display
1Run Times Allows user to set each valve station run time from 1 minute to 4 hours
2Start Times Allows 1 to 4 start times to be set in each program
3 Station Number Indicates currently selected station number
4 Program Designator Identies program (A, B, or C) in use
5 Day of the Week Identies day of the week
6 Interval Watering Identies month when programming current date
7 Odd/Even Watering Identies if Odd or Even watering has been selected
8 Flashing Sprinkler Indicates that watering is taking place
9System O Allows user to discontinue all programs and watering. Also allows the user to set the programmable
“rain o,” which stops watering for a period from 1 to 7 days.
10 Umbrella Indicates that the rain sensor is active
11 Seasonal Adjustment
Allows the user to make run time changes according to the seasons without reprogramming the controller.
Bars on the le allow quick visual reference to the seasonal adjustment percentage. When using Solar Sync
ET Sensor, will display seasonal adjust updated daily by sensor.
12 Rain Drop Indicates watering will occur on the selected day
13 Crossed Rain Drop Indicates the watering will NOT occur on the selected day
14 Calendar Indicates interval watering schedule has been programmed. Icon also appears when programming the
current day
4

55
XCORE COMPONENTS
Wiring Compartment
15 Lithium Battery
The replaceable lithium battery (included) allows the controller to be programmed in the absence
of AC power. In addition, the battery will provide power for backup timekeeping in the event of a
power outage.
16 Internal Junction Box Junction box in outdoor models for making AC power connections
17 Terminal Strip Use to attach transformer, sensor, and valve wires from their source to the controller
18 Reset Button Use to reset the controller (located on right side of controller)
19 REM Allows for connection of Hunter SmartPort®and Hunter Remote Controls
20 Sensor Bypass Switch Ignores “Clik” weather sensor input when in Bypass position
Control Buttons
Button Increases the selected item ashing in the display
Button Decreases the selected item ashing in the display
Button Returns selected ashing display to previous item
Button Advances the selected ashing display to the next item
Button Selects program A, B, or C for dierent watering zone requirements

6
XCORE COMPONENTS
Terminal
block for -E
(International
models only)
Note: Plug may
look dierent from
illustration
Indoor Model
Outdoor Model
(Internal Transformer
Included)
6

7
XCORE COMPONENTS
Dial Settings
Run Normal dial position for all controller automatic and manual operation
Current Time/Day Allows current day and clock time to be set
Start Times Allows 1 to 4 start times to be set in each program
Run Times Allows user to set each valve station run time from 1 minute to 4 hours
Water Days Allows the user to select interval days to water
Seasonal Adjustment Allows user to make run time changes according to the seasons without reprogramming the controller.
Bars on the le allow quick visual reference to the seasonal adjustment percentage.
1Manual-One Station Allows user to activate a one-time watering of a single valve
System O Allows user to discontinue all programs and watering. Also allows the user to set the programmable
“rain o,” which stops watering for a period from 1 to 7 days
SOLAR SYNCSettings Allows user to program settings when using Solar Sync ET Sensor
External Transformer (Indoor Model Only)
A plug in transformer is provided to supply AC power to the controller

8
MOUNTING THE CONTROLLER TO WALL
Note: The indoor version of the X-Core is not water-
proof or weather-resistant, and must be installed indoors
or in a protected area.
1. Secure one screw into the wall. Install screw anchors if attaching
to drywall or masonry wall.
2. Slide the keyhole on top of the controller over the screw.
3. Secure the controller in place by installing screws in the holes
below the terminal strip.
NOTE:Do not plug transformer into power source until
controller is mounted and all valve wiring has
been connected.
NOTE: For XC - x01 - A: If the supply cord is damaged, it
must be replaced by the manufacturer or service agent,
or a similarly qualied person in order to
avoid hazard.
C
A
B
NOTE: The door on outdoor units must remain closed
for maximum water resistance.

9
Installation of the X-Core should only be done by trained personnel.
1. Route valve wires between the control valve location and controller.
2. At valves, attach a common wire to either solenoid wire on all
valves. This is most commonly a white colored wire. Attach a
separate control wire to the remaining wire of each valve. All
wire connections should be done using waterproof connectors.
3. Route the valve wires through the conduit. Attach the conduit
through the bottom right side of the controller.
4. Secure the white valve common wire to the C (Common) screw
on the terminal strip. Attach each of the individual valve control
wires to the appropriate station terminals and tighten their
screws.
5. Indoor Models: route the transformer cable through the hole on
the le side of the controller and connect the wires to the two
screws marked 24 VAC.
Outdoor Models: transformer wires are already connected to the
AC terminals so all that is required is to connect primary power
to the junction box (see below).
NOTE: X-Core outdoor models are water and
weather-resistant throughout document. Connecting
the outdoor X-Core to primary AC power should only be
done by a licensed electrician following all local codes.
Improper installation could result in shock or re hazard.
High Voltage Wiring (Outdoor Model only)
1. Route AC power cable and conduit through the ½" (13 mm)
conduit opening on the le side bottom of the cabinet.
2. Connect one wire to each of the two wires inside the junction
box. The ground wire should be connected to the green wire.
Wire nuts are provided to make these connections.
Note: For –E models only: Connect the wires to the AC
terminal block inside the junction box. AC supply wires must
be 14 AWG (1.85 mm) or larger with appropriate circuit breaker
for the wire size. A switch or circuit-breaker shall be included
in the building installation (in close proximity to the controller,
within easy reach of the operator) and marked as the discon-
necting device for the equipment.
3. Replace the junction box cover.
Valve Common Wire
CONNECTING VALVES AND TRANSFORMER
BAT
Connect the two transformer
wires to the two AC Terminals
Valve 4
Valve 3
Valve 2
Valve 1
Valve
Wires

10
ACTIVATING THE BATTERY
REPLACING THE BATTERY
A high-energy lithium battery is included with your X-Core
controller. The battery allows the user to remotely program the
controller without connecting AC power. It is also used to keep
the current time and day during power outage conditions.
To replace the battery:
1. Remove the screw from the battery holder.
2. Slide the battery holder down to access the battery.
3. Remove and replace the new battery into the battery holder
and reinstall the battery holder.
NOTE: This positive(+) side of the battery should face
the inside of the battery holder. Battery type: CR2032 3V
SEN C P 1 2 3 4 5 6 7 8
24VA C
BAT
Battery Compartment
Lithium Battery
Battery
Holder
(--) (+)
Aer installing your X-Core, make sure to remove the battery
contact insulator to allow the X-Core to keep time in the event of
a power outage.
CAUTION:
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES AC-
CORDING TO THE INSTRUCTIONS.
