Tyco DS-1 Series User manual

General
Description
TYCO Series DS-1 Dry-Type Sprin-
klers, 5.6K Stainless Steel Pendent,
Horizontal Sidewall, Standard (5 mm
Bulb) and Quick (3 mm Bulb) Re-
sponse, Extended Coverage, are the
rst stainless steel dry-type sprinklers
to be listed by UL and C-UL. With a
K-Factor of 5.6, these corrosion-resis-
tant automatic sprinklers can be used
in wet-pipe, dry-pipe, or preaction
systems.
These pendent and horizontal sidewall
sprinklers are available in a variety of
congurations to suit coverage type
and thermal sensitivity. Refer to the
Model/Sprinkler Identication Num-
bers (SINs) section for details.
Series DS-1 Stainless Steel Dry-Type
Sprinklers are typically used:
• where corrosive atmospheres exist;
for example, salt-water areas, park-
ing garages, chemical storage
areas, mechanical rooms, industrial
manufacturing sites, and software
chip washing facilities.
• on dry-pipe systems exposed to
freezing temperatures; for example,
sprinkler drops from unheated por-
tions of buildings.
• with pipe connections exposed to
freezing temperatures; for example,
sprinkler drops from wet-pipe sys-
tems into freezers or horizontal pip-
ing extensions to protect unheated
areas.
• in systems that are seasonably
drained to avoid freezing; for exam-
ple, vacation areas.
The stainless-steel construction of
these sprinklers extends the life of a
sprinkler beyond that of traditional
copper alloy sprinklers exposed to
corrosive atmospheres. Although
corrosion-resistant sprinklers have
passed the standard corrosion tests
of the applicable approval agencies,
the testing is not representative of all
possible corrosive atmospheres.
Consequently, it is necessary that the
end user be consulted with respect to
the suitability of this alternate material
of construction for any given corrosive
environment. As a minimum, consider
the following criteria:
• ambient temperature
• concentration of chemicals
• humidity
• gas/chemical velocity
• corrosive nature of the chemical to
which the sprinklers are exposed
Stainless Steel Pendent Dry-Type
Sprinklers. The pendent sprinklers
are provided with stainless steel es-
cutcheons that allow vertical ad-
justment during installation. This
adjustment provides a measure of
exibility in determining the length of
xed piping to cut for sprinkler drops.
Stainless Steel Sidewall Dry-Type
Sprinklers. The horizontal sidewall
sprinklers are designed for installation
along a wall or side of a soft and just
beneath a smooth ceiling. Sidewall
sprinklers are commonly used instead
of pendent sprinklers due to aesthet-
ics or building construction consider-
ations where piping along the ceiling
is not desirable.
NOTICE
The Series DS-1 Stainless Steel Dry-
Type Sprinklers described herein
must be installed and maintained in
compliance with this document, as
well as with the applicable standards
of the National Fire Protection
Association, in addition to the
standards of any Authorities Having
Jurisdiction. Failure to do so may
impair the performance of these
devices.
Owners are responsible for maintain-
ing their fire protection system and
devices in proper operating condition.
The installing contractor or sprinkler
manufacturer should be contacted
with any questions.
The Series DS-1 Stainless Steel Dry-
Type Sprinklers must only be installed
in fittings that meet the requirements
of the Design Criteria section.
Page 1 of 12 SEPTEMBER 2011 TFP560
Series DS-1 Stainless Steel Dry-Type Sprinklers
5.6K Pendent, HSW, and Extended Coverage HSW
Standard and Quick Response
Technical Services
800-381-9312
[phone]
www.tyco-re.com
IMPORTANT
Always refer to Technical Data
Sheet TFP700 for the “INSTALLER
WARNING” that provides cau-
tions with respect to handling
and installation of sprinkler sys-
tems and components. Improp-
er handling and installation can
permanently damage a sprin-
kler system or its components
and cause the sprinkler to fail
to operate in a fire situation or cause
it to operate prematurely.

Temperature
Rating
Bulb
Color Code
Standard Coverage Extended Coverage
Horizontal Sidewall
Pendent Horizontal Sidewall
TY3230
(3 mm Bulb)
w/ Standard
Escutcheon
(Figure 10)
w/ Recessed
Escutcheon(a)
(Figure 11)
w/ Deep
Escutcheon
(Figure 12)
w/o Escutcheon
(Figure 13)
TY3250
(5 mm Bulb)
w/ Standard†
Escutcheon
(Figure 10)
w/ Recessed
Escutcheon(a)
(Figure 11)
w/ Deep†
Escutcheon
(Figure 12)
w/o†
Escutcheon
(Figure 13)
TY3337
(3 mm Bulb)(b)
w/ Standard
Escutcheon
(Figure 14)
w/ Deep
Escutcheon
(Figure 15)
w/o Escutcheon
(Figure 16)
TY3357
(5 mm Bulb)(b)
w/ Standard
Escutcheon
(Figure 14)
w/ Deep
Escutcheon
(Figure 15)
w/o Escutcheon
(Figure 16)
TY3339
(3 mm Bulb)(c)
w/ Standard
Escutcheon
(Figure 17)
135°F (57°C) Orange 1, 2 1, 2 1*, 2*1*, 2*1**, 2**
155°F (68°C) Red 1, 2 1, 2, 3†1*, 2*1*, 2*1**, 2**
175°F (79°C) Yellow 1, 2 1, 2 1*, 2*1*, 2* -
200°F (93°C) Green 1, 2 1, 2, 3†1*, 2*1*, 2* -
286°F (141°C) Blue 1, 2 1, 2, 3†1*, 2*1*, 2* -
360°F (182°C) Mauve -1, 2 -1*, 2* -
Notes:
1. Listed by Underwriters Laboratories, Inc. (UL). Stainless steel sprinklers noted to be UL Listed are listed as Corrosion Resistant
Sprinklers. Maximum order lengths are described in Figures 10 - 17.
2. Listed by Underwriters Laboratories for use in Canada (C-UL). Stainless steel sprinklers noted to be C-UL Listed are listed as
Corrosion Resistant Sprinklers. Maximum order lengths are described in Figures 10 - 17.
3. Loss Prevention Certication Board approval and CE conformity apply to these temperature ratings only.
† LPCB approval and CE conformity apply to only these congurations for TY3250 with only these indicated temperatures.
* Light and Ordinary Hazard Occupancies Only
** Light Hazard Occupancies Only
- Not Applicable
(a) This conguration is applicable only up to 200°F (93°C).
(b) To meet the deector-to-ceiling distance of 4 to 12 inches (100 to 300 mm) for the standard coverage horizontal sidewall, the
centerline of the sprinkler waterway must be 4-5/16 to 12-5/16 inches below the ceiling.
(c) To meet the deector-to-ceiling distance of 4 to 12 inches (100 to 300 mm) for the extended coverage horizontal sidewall, the
centerline of the sprinkler waterway must be 4-7/16 to 12-7/16 inches below the ceiling.
TABLE A
SERIES DS-1 STAINLESS STEEL PENDENT AND HORIZONTAL SIDEWALL DRY-TYPE SPRINKLERS
STANDARD AND EXTENDED COVERAGE
— LABORATORY LISTINGS AND APPROVALS —
TFP560
Page 2 of 12

APPLICATION (1)
Coverage (2)
W x L
Ft. x Ft. (m x m)
Minimum
Flow
GPM (LPM)
Minimum
Pressure
psi (bar)
Temperature
Rating
Top of
Deflector-to-
Ceiling Distance (2)
TY3339
(3 mm Bulb)
For Quick Response,
Light Hazard Extended
Coverage
Per NFPA 13
16 x 16 (4,9 x 4,9) 26 (98) 21.6 (1,49)
135°F (57°C)
and
155°F (68°C)
4 inches (100 mm)
to
12 inches (300 mm)
16 x 18 (4,9 x 5,5) 29 (110) 26.8 (1,85)
16 x 20 (4,9 x 6,1) 32 (121) 32.7 (2,25)
18 x 16 (5,5 x 4,9) 29 (110) 26.8 (1,85)
Notes:
1. These sprinklers are Listed by UL and C-UL. Stainless steel sprinklers noted to be UL and C-UL Listed are listed as Corrosion
Resistant Sprinklers.
2. The minimum allowable spacing between sprinklers to prevent cold soldering is 14 feet (4,3 m).
TABLE B
SERIES DS-1 STAINLESS STEEL EXTENDED COVERAGE HORIZONTAL SIDEWALL DRY-TYPE SPRINKLERS
— UL AND C-UL INSTALLATION CRITERIA —
Model/Sprinkler
Identification
Numbers (SINs)
Standard Coverage Pendent
TY3230 – 3 mm Bulb
TY3250 – 5 mm Bulb
Standard Coverage Horizontal
Sidewall
TY3337 – 3 mm Bulb
TY3357 – 5 mm Bulb
Extended Coverage Horizontal
Sidewall
TY3339 – 3 mm Bulb
Technical
Data
Approvals
• UL and C-UL Listed
• LPCB Approved: Ref. No. 094a/12
• CE Certied: EN 12259-1
Refer to Tables A and B for details.
Maximum Working Pressure
175 psi (12,1 bar)
Inlet Thread Connections
• 1-Inch NPT
• ISO 7-R1
Discharge Coefficient
K = 5.6 GPM/psi1/2
(80,6 LPM/bar1/2)
Temperature Ratings
Refer to Tables A and B.
Finishes
Sprinkler: Stainless Steel
Escutcheon: Stainless Steel
Physical Characteristics
With the exceptions of the Bulb, the
Insert, the Deector, and the Seal-
ing Assembly, all components of the
Series DS-1 Stainless Steel Dry-Type
Sprinkler are constructed with Type
316 Stainless Steel.
• The Bulb is Glass.
• The Insert is 300 Series Stainless
Steel.
• The Deector is Type 316L Stainless
Steel.
The Sealing Assembly consists of a
Disc Spring that is sealed on both its
inside and outside faces with a TEF-
LON gasket. The Disc Spring is 1/2
Hard Beryllium Nickel.
Refer to Figures 1 through 3 for
component assemblies.
Operation
When the TYCO Series DS-1 Stainless
Steel Dry-Type Sprinkler is in service,
water is prevented from entering the
assembly by the Plug with Sealing
Assembly in the Inlet of the Sprinkler.
Refer to Figures 1 through 3.
The glass Bulb contains a uid that
expands when exposed to heat. When
the rated temperature is reached, the
uid expands sufciently to shatter
the glass Bulb then release the Bulb
Seat.
The compressed Spring is then able
to expand and push the Water Tube as
well as the Guide Tube outward. This
outward action simultaneously pulls
inward on the Yoke, withdrawing the
Plug with Sealing Assembly from the
Inlet and allowing the sprinkler to acti-
vate and ow water effectively.
Design
Criteria
The TYCO Series DS-1 Stainless
Steel Dry-Type Standard Coverage
Sprinklers are intended for use in re
sprinkler systems designed in accor-
dance with the standard installation
rules recognized by the applicable
Listing or Approval agency; for exam-
ple, UL Listing is based on NFPA 13
requirements.
For more information on LPCB Ap-
proval, contact Tyco Fire Protection
Products at the following ofce:
Kopersteden 1
7547 TJ Enschede
The Netherlands
Tel: [phone]
Fax: [phone]
The Series DS-1 Stainless Steel Ex-
tended Coverage Sprinklers are in-
tended for use in re sprinkler systems
designed in accordance with extend-
ed coverage installation guidelines
provided by NFPA 13 and the installa-
tion criteria provided by Table B.
TFP560
Page 3 of 12

WATER
TUBE
GUIDE
TUBE HOLEINLET
INSERT DEFLECTOR
3 or 5 mm
SCREW
COMPRESSION
SEALING
PLUG WITH
BULB
SEAT
YOKE
1" NPT
CASING
SPRING
VENT
FRAME
BULB
ASSEMBLY
BAND
INLET
FIGURE 2
SERIES DS-1 STAINLESS STEEL DRY-TYPE HORIZONTAL SIDEWALL SPRINKLER
STANDARD COVERAGE
TY3337 (3 mm Bulb) and TY3357 (5 mm Bulb)
WATER
TUBE
GUIDE
TUBE HOLEINLET
INSERT DEFLECTOR
3 mm
SCREW
COMPRESSION
SEALING
PLUG WITH
BULB
SEAT
YOKE
1" NPT
CASING
SPRING
VENT
FRAME
BULB
ASSEMBLY
BAND
INLET
FIGURE 3
SERIES DS-1 STAINLESS STEEL DRY-TYPE HORIZONTAL SIDEWALL SPRINKLER
EXTENDED COVERAGE
TY3339 (3 mm Bulb)
3 or 5 mm BULB
WATER
TUBE
VENT HOLE
GUIDE
TUBE
INSERT
YOKE
SCREW
INLET
SEALING
PLUG WITH
CASING
DEFLECTOR
BULB
SPRING
COMPRESSION
SEAT
ASSEMBLY
FRAME
INLET
BAND
FIGURE 1
SERIES DS-1 STAINLESS STEEL DRY-TYPE PENDENT SPRINKLERS
STANDARD COVERAGE
TY3230 (3 mm Bulb) and TY3250 (5 mm Bulb)
TFP560
Page 4 of 12

• cast bronze threaded tee ttings
that meet the dimensional require-
ments of ANSI B16.15 (Class 125).
• stainless steel threaded tee ttings
that meet the dimensional require-
ments of MSS SP-114.
Do not install the Series DS-1 Stain-
less Steel Dry-Type Sprinklers into
elbow ttings. The inlet of the sprinkler
can contact the interior of the elbow,
potentially damaging the Inlet seal.
HEATED
AREA (SEE DESIGN
CRITERIA
SECTION)
FACE OF
SPRINKLER
FITTING
LENGTH
EXPOSURE
DSB-2
BOOT
FIGURE 6
— EXPOSURE LENGTH —
SIDE
OUTLET
PLUGGED
TO WET
SYSTEM
FITTING
(SEE DESIGN
CRITERIA
SECTION)
SPRINKLER
DSB-2
BOOT
HEATED
AREA
FIGURE 4
SPRINKLER FITTING
— HEATED AREA —
AREA
SUBJECT
TO
FREEZING
RUN
OUTLET
PLUGGED
TO DRY
SYSTEM
DSB-2
BOOT
FITTING
(SEE DESIGN
CRITERIA
SECTION)
SPRINKLER
FIGURE 5
SPRINKLER FITTING IN
— UNHEATED AREA —
(ENDS ON OPPOSING
SIDES OF BOOT)
STRAP TIES
ADHESIVE
SHOWN WITH
STANDARD
ESCUTCHEON
DS-1
1-3/4" DIA.
(44,5 mm)
CLEARANCE
HOLE
FREEZER
STRUCTURE
OR EXTERIOR
INSULATED
CEILING
EXPOSED
DSB-2
BOOT
TO FREEZING
FIGURE 7
MODEL DSB-2 SPRINKLER
BOOT WITH PENDENT
Sprinkler Fittings
Install the 1-Inch NPT Series DS-1
Stainless Steel Dry-Type Sprinkler in
the 1-Inch NPT outlet or run of one of
the following ttings:
• malleable or ductile iron thread-
ed tee ttings that meet the dimen-
sional requirements of ANSI B16.3
(Class 150).
• cast iron threaded tee ttings that
meet the dimensional requirements
of ANSI B16.4 (Class 125).
The unused outlet of the threaded tee is
plugged as shown in Figures 4 and 5.
You can also install the Series DS-1
Sprinklers in the 1-Inch NPT outlet of
a GRINNELL Figure 730 Mechanical
Tee. However, the use of the Figure
730 Tee for this arrangement is limited
to wet-pipe systems.
The conguration shown in Figure 4 is
only applicable for wet-pipe systems
where the sprinkler tting and water-
lled pipe above the sprinkler tting
are not subject to freezing and where
the length of the Stainless Steel Dry-
Type Sprinkler has the minimum
exposure length depicted in Figure 6.
Refer to the Exposure Length section.
For wet-pipe system installations of
the 1-Inch NPT Series DS-1 Stainless
Steel Dry-Type Sprinklers connected
to CPVC piping, use only the following
TYCO CPVC ttings:
• 1” x 1” NPT Female Adapter
(P/N 80145)
• 1” x 1” x 1” NPT Sprinkler Head
Adapter Tee (P/N 80249)
For dry-pipe system installations, use
only the side outlet of maximum 2-1/2
inch reducing tee when locating the
Series DS-1 Stainless Steel Dry-Type
Sprinklers directly below the branch
line. Otherwise, use the conguration
shown in Figure 5 to assure complete
water drainage from above the Series
DS-1 Stainless Steel Dry-Type Sprin-
klers and the branch line. Failure to
do so may result in pipe freezing and
water damage.
(ENDS ON
OPPOSING
SIDES OF
STRAP TIES
BOOT)
ADHESIVE
SHOWN WITH
STANDARD
ESCUTCHEON
DS-1
1-3/4" DIA.
(44,5 mm)
CLEARANCE
HOLE
DSB-2
BOOT
FREEZER
STRUCTURE
OR EXTERIOR
INSULATED
WALL EXPOSED
TO FREEZING
FIGURE 8
MODEL DSB-2 SPRINKLER
BOOT WITH HORIZONTAL
SIDEWALL
TFP560
Page 5 of 12

NOTICE
Do not install the Series DS-1
Stainless Steel Dry-Type Sprinklers
into any other type fitting without first
consulting the Technical Services
Department. Failure to use the
appropriate fitting can result in one of
the following:
• Failure of the sprinkler to operate
properly due to formation of ice
over the Inlet Plug or binding of the
Inlet Plug.
• Insufficient engagement of the In-
let pipe threads with consequent
leakage.
Drainage
In accordance with the minimum
requirements of the National Fire
Protection Association for dry-pipe
sprinkler systems, pitch branch, cross,
and feed main piping connected to
Stainless Steel Dry-Type Sprinklers
and subject to freezing temperatures
to allow proper drainage.
Exposure Length
When using Stainless Steel Dry-Type
Sprinklers in wet-pipe sprinkler sys-
tems protecting areas subject to
freezing temperatures, use Table C
to determine a sprinkler’s appropriate
exposed barrel length to prevent water
from freezing in the connecting pipes
due to conduction. The exposed bar-
rel length measurement must be taken
from the face of the sprinkler tting to
the surface of the structure or insu-
lation that is exposed to the heated
area. Refer to Figure 6 for an example.
Clearance Space
Section 8.4.9.2 of 2010 edition of
NFPA 13 requires a sealed clearance
space around the sprinkler barrel of
dry sprinklers that are connected to
wet-pipe sprinkler systems protect-
ing insulated freezer structures. The
use of the Model DSB-2 Dry Sprin-
kler Boot, described in technical
data sheet TFP591 and illustrated in
Figures 7 and 8, meets this NFPA 13
requirement.
Ambient Temperature
Exposed to Discharge End
of Sprinkler
Temperatures for Heated Area(a)
40°F (4°C) 50°F (10°C) 60°F (16°C)
Minimum Exposed Barrel Length, Inches (mm)(b)
40°F (4°C) 0 0 0
30°F (-1°C) 0 0 0
20°F (-7°C) 4(100) 0 0
10°F (-12°C) 8 (200) 1 (25) 0
0°F (-18°C) 12 (305) 3(75) 0
-10°F (-23°C) 14 (355) 4(100) 1(25)
-20°F (-29°C) 14 (355) 6(150) 3(75)
-30°F (-34°C) 16 (405) 8 (200) 4 (100)
-40°F (-40°C) 18 (455) 8 (200) 4 (100)
-50°F (-46°C) 20 (510) 10 (255) 6(150)
-60°F (-51°C) 20 (510) 10 (255) 6(150)
Notes:
(a) For protected area temperatures that occur between values listed above, use the next cooler temperature.
(b) These lengths are inclusive of wind velocities up to 30 mph (18,6 kph).
TABLE C
MINIMUM RECOMMENDED LENGTHS OF EXPOSED SPRINKLER BARRELS
IN WET-PIPE SYSTEMS
RECESS
WRENCH
FLAT
WRENCH
WITH SPRINKLER
ENGAGEMENT
IN TO ENSURE
WRENCHING AREA
PUSH WRENCH
FIGURE 9
W-TYPE 7
SPRINKLER WRENCH
TFP560
Page 6 of 12

SPRINKLER
FACE OF
FITTING
(127,0 to 1219,2 mm)
INCREMENTS
IN 1/4" (6,4 mm)
ORDER LENGTHS:
5" to 48"
DEFLECTOR
TO CEILING
1-3/4" (44,5 mm)
MINIMUM
SPRINKLER FITTING
(REFER TO DESIGN
CRITERIA SECTION)
FIGURE 13
PENDENT without ESCUTCHEON
TY3230 (3 mm Bulb) and TY3250 (5 mm Bulb)
ORDER LENGTHS:
INCREMENTS
4-1/4" ± 1/8"
(108,0 ± 3,2 mm)
IN 1/4" (6,4 mm)
(12,7 to 1168,4 mm)
1/2" to 46"
FACE OF
CEILING
(88,9 mm)
3-1/2" DIA.
2-1/2" DIA.
(63,5 mm)
FITTING
FACE OF
SPRINKLER
CRITERIA SECTION)
(REFER TO DESIGN
SPRINKLER FITTING
FIGURE 12
PENDENT with DEEP ESCUTCHEON
TY3230 (3 mm Bulb) and TY3250 (5 mm Bulb)
ORDER LENGTHS:
(69,9 to 1219,2 mm)
2-3/4" to 48"
IN 1/4" (6,4 mm)
INCREMENTS
FITTING
FACE OF
SPRINKLER
SPRINKLER FITTING
(REFER TO DESIGN
CRITERIA SECTION)
(76,2 mm)
3" DIA.
1-3/4" DIA.
(44,5 mm)
(55,6 ± 3,2 mm)
2-3/16" ± 1/8"
CEILING
FACE OF
FIGURE 10
PENDENT with STANDARD ESCUTCHEON
TY3230 (3 mm Bulb) and TY3250 (5 mm Bulb)
2-1/4" DIA.
(57,2 mm)
1-3/8" ± 1/8"
(34,9 ± 3,2 mm)
2-7/8" DIA.
(73,0 mm)
IN 1/4" (6,4 mm)
3-3/4" to 48"
INCREMENTS
(95,3 to 1219,2 mm)
ORDER LENGTHS:
SPRINKLER
FACE OF
FITTING
CEILING
FACE OF
CRITERIA SECTION)
(REFER TO DESIGN
SPRINKLER FITTING
FIGURE 11
PENDENT with RECESSED ESCUTCHEON
TY3230 (3 mm Bulb) and TY3250 (5 mm Bulb)
TFP560
Page 7 of 12

3.5°
5/16"
(7,9 mm)
CENTERLINE
OF WATERWAY
(76,2 mm)
3" DIA.
1-3/4" DIA.
(44,5 mm)
FITTING
SPRINKLER
FACE OF
SPRINKLER FITTING
CRITERIA SECTION)
(REFER TO DESIGN
4" ± 1/8"
(101,6 ± 3,2 mm)
2-3/4" to 48" (69,9 to 1219,2 mm)
IN 1/4" (6,4 mm) INCREMENTS
ORDER LENGTHS:
SURFACE
MOUNTING
FACE OF
FIGURE 14
STANDARD COVERAGE HORIZONTAL SIDEWALL with STANDARD ESCUTCHEON
TY3337 (3 mm Bulb) and TY3357 (5 mm Bulb)
3.5° 5/16"
(7,9 mm)
CENTERLINE
OF WATERWAY
FITTING
SPRINKLER
FACE OF
2-1/4" (57,2 mm)
DEFLECTOR TO
5-1/2" to 48" (139,7 to 1219,2 mm)
IN 1/4" (6,4 mm) INCREMENTS
ORDER LENGTHS:
MINIMUM
MOUNTING
SURFACE
SPRINKLER FITTING
CRITERIA SECTION)
(REFER TO DESIGN
FIGURE 16
STANDARD COVERAGE HORIZONTAL SIDEWALL without ESCUTCHEON
TY3337 (3 mm Bulb) and TY3357 (5 mm Bulb)
(88,9 mm)
3-1/2" DIA.
2-1/2" DIA.
(63,5 mm)
4-13/16" ± 1/8"
(122,2 ± 3,2 mm)
3.5°
5/16"
(7,9 mm)
CENTERLINE
OF WATERWAY
FACE OF
SPRINKLER
FITTING
1/2" to 45-3/4" (12,7 to 1162,1 mm)
IN 1/4" (6,4 mm) INCREMENTS
ORDER LENGTHS: FACE OF
MOUNTING
SURFACE
SPRINKLER FITTING
CRITERIA SECTION)
(REFER TO DESIGN
FIGURE 15
STANDARD COVERAGE HORIZONTAL SIDEWALL with DEEP ESCUTCHEON
TY3337 (3 mm Bulb) and TY3357 (5 mm Bulb)
TFP560
Page 8 of 12

Installation
The TYCO Series DS-1 Stainless Steel
Dry-Type Sprinklers must be installed
in accordance with the following
instructions.
NOTICE
The Series DS-1 must only be installed
in fittings that meet the requirements
of the Design Criteria section. For
other important requirements regard-
ing piping design and sealing of the
clearance space around the Sprinkler
Casing, refer to the Design Criteria
section.
Do not install any bulb type sprinkler if
the bulb is cracked or there is a loss of
liquid from the bulb. With the sprinkler
held horizontally, a small air bubble
should be present. The diameter of
the air bubble is approximately 1/16
inch (1,6 mm) for the 135°F (57°C) rat-
ing to 1/8 inch (3,2 mm) for the 286°F
(141°C) rating.
Obtain a leak-tight 1-Inch NPT sprin-
kler joint by applying a minimum-to-
maximum torque of 20 to 30 ft.-lbs.
(26,8 to 40,2 Nm). Higher levels of
torque can distort the sprinkler Inlet
with consequent leakage or impair-
ment of the sprinkler.
Do not attempt to compensate for in-
sufcient adjustment in an Escutch-
eon Plate by under- or over-tightening
the Sprinkler. Re-adjust the position of
the sprinkler tting to suit.
Step 1. Install pendent sprinklers
only in the pendent position with the
deector parallel to the ceiling. Install
horizontal sidewall sprinklers in the
horizontal position with their center-
line of waterway perpendicular to the
back wall and parallel to the ceiling.
Ensure the word “TOP” on the Deec-
tor faces the ceiling.
Step 2. With a non-hardening pipe
thread sealant such as TEFLON ap-
plied to the Inlet threads, hand-tighten
the sprinkler into the sprinkler tting.
Step 3. Wrench-tighten the sprinkler
using a pipe wrench on the Inlet Band
or Casing (refer to Figures 1 to 3) or
using the W-Type 7 Sprinkler Wrench
on the Wrench Flat (refer to Figure 9).
Note: If sprinkler removal becomes
necessary, remove the sprinkler using
the same wrenching method noted
above. Sprinkler removal is easier
when a non-hardening sealant was
used and torque guidelines were fol-
lowed. After removal, inspect the
sprinkler for damage.
Step 4. After installing the ceiling or
wall and applying a ceiling nish, slide
on the outer piece of the Escutcheon
until it comes in contact with the ceil-
ing or wall. Do not lift the ceiling panel
out of its normal position.
When using the Deep Escutcheon,
hold the outer piece in contact with
the mounting surface (ceiling or wall).
Then rotate the inner piece approxi-
mately 1/4 turn, with respect to the
outer piece, to hold the Deep Escutch-
eon rmly together.
MOUNTING
FACE OF
4" ± 1/8"
(101,6 ± 3,2 mm)
SURFACE
7/16"
(11,1 mm)
CENTERLINE
OF WATERWAY
(76,2 mm)
3" DIA.
ORDER LENGTHS:
(69,9 to 1219,2 mm)
2-3/4" to 48"
IN 1/4" (6,4 mm)
INCREMENTS
1-3/4" DIA.
(44,5 mm)
FACE OF
SPRINKLER
FITTING
SPRINKLER FITTING
CRITERIA SECTION)
(REFER TO DESIGN
FIGURE 17
SERIES DS-1 STAINLESS STEEL DRY-TYPE EXTENDED COVERAGE
HORIZONTAL SIDEWALL SPRINKLER with STANDARD ESCUTCHEON TY3339 (3 mm Bulb)
Care and
Maintenance
The TYCO Series DS-1 Stainless Steel
Dry-Type Stainless Steel Sprinklers
must be maintained and serviced
in accordance with the following
instructions.
NOTICE
Before closing a fire protection system
main control valve for maintenance
work on the fire protection system that
it controls, obtain permission to shut
down the affected fire protection sys-
tems from the proper authorities and
notify all personnel who may be af-
fected by this action.
Absence of the outer piece of an es-
cutcheon, which is used to cover a
clearance hole, can delay sprinkler
operation in a re situation.
A Vent Hole is provided in the Bulb
Seat to indicate if the Dry Sprinkler
is remaining dry. (Refer to Figures 1
through 3.) Evidence of leakage from
the Vent Hole indicates potential leak-
age past the Inlet seal and the need
to remove the sprinkler to determine
the cause of leakage; for example, an
improper installation or an ice plug.
Close the re protection system con-
trol valve and drain the system before
removing the sprinkler.
TFP560
Page 9 of 12

Exercise care to avoid damage to
sprinklers before, during, and after in-
stallation. Never paint, plate, coat, or
otherwise alter automatic sprinklers
after they leave the factory.
Replace sprinklers that:
• were modied or over-heated.
• were damaged by dropping, strik-
ing, wrench twisting, wrench slip-
page, or the like.
• are leaking or exhibiting visible
signs of corrosion.
• were exposed to corrosive products
of combustion but have not oper-
ated, if you cannot easily remove
combustion by-products with a
cloth.
• have a cracked bulb or have lost
liquid from the bulb. Refer to the In-
stallation section in this data sheet.
Initial and frequent visual inspections
of random samples are recommended
for corrosion-resistant sprinklers to
verify the integrity of the corrosion-
resistant material of construction.
Thereafter, annual inspections per
NFPA 25 should sufce.
Inspections of corrosion-resistant
sprinklers are recommended at close
range, instead of from the oor level
per NFPA. Inspection at close range
can better determine the exact sprin-
kler condition and the long-term in-
tegrity of the corrosion-resistant
material, which can be affected by the
corrosive conditions present.
Responsibility lies with the owner for
the inspection, testing, and mainte-
nance of their re protection system
and devices in compliance with this
document, as well as with the appli-
cable standards of the National Fire
Protection Association (for example,
NFPA 25), in addition to the stan-
dards of any other Authorities Hav-
ing Jurisdiction. Contact the installing
contractor or sprinkler manufacturer
regarding any questions.
Automatic sprinkler systems are rec-
ommended to be inspected, tested,
and maintained by a qualied Inspec-
tion Service in accordance with local
requirements and/or national codes.
Limited
Warranty
Products manufactured by Tyco Fire
Protection Products (TFPP) are war-
ranted solely to the original Buyer for
ten (10) years against defects in ma-
terial and workmanship when paid for
and properly installed and maintained
under normal use and service. This
warranty will expire ten (10) years from
date of shipment by TFPP. No war-
ranty is given for products or com-
ponents manufactured by companies
not afliated by ownership with TFPP
or for products and components
which have been subject to misuse,
improper installation, corrosion, or
which have not been installed, main-
tained, modied or repaired in accor-
dance with applicable Standards of
the National Fire Protection Associa-
tion, and/or the standards of any other
Authorities Having Jurisdiction. Ma-
terials found by TFPP to be defective
shall be either repaired or replaced, at
TFPP’s sole option. TFPP neither as-
sumes, nor authorizes any person to
assume for it, any other obligation in
connection with the sale of products
or parts of products. TFPP shall not
be responsible for sprinkler system
design errors or inaccurate or incom-
plete information supplied by Buyer or
Buyer’s representatives.
In no event shall TFPP be liable, in
contract, tort, strict liability or under
any other legal theory, for inciden-
tal, indirect, special or consequential
damages, including but not limited to
labor charges, regardless of whether
TFPP was informed about the pos-
sibility of such damages, and in no
event shall TFPP’s liability exceed an
amount equal to the sales price.
The foregoing warranty is made in
lieu of any and all other warranties,
express or implied, including warran-
ties of merchantability and tness for
a particular purpose.
This limited warranty sets forth the
exclusive remedy for claims based on
failure of or defect in products, materi-
als or components, whether the claim
is made in contract, tort, strict liability
or any other legal theory.
This warranty will apply to the full ex-
tent permitted by law. The invalidity,
in whole or part, of any portion of this
warranty will not affect the remainder.
Ordering
Procedure
To place an order, contact your local
distributor. When placing an order, in-
dicate the full product description and
Part Number (P/N).
Stainless Steel Dry-Type Sprinklers
1. Specify Sprinkler:
• Model/SIN from the Model/
Sprinkler Identication Numbers
(SINs) section
• Sprinkler description from the
Model/Sprinkler Identication
Numbers (SINs) section
• Deector Style: Pendent or Hori-
zontal Sidewall
• 5.6 K-Factor
• Order Length
Dry-Type Sprinklers are fur-
nished based upon Order
Length as measured per Figures
10 through 17, as applicable.
Measure the required length and
then round the measurement to
the nearest 1/4 inch increment.
• Inlet Connections: 1-Inch NPT or
ISO 7-R1
• Temperature Rating
Temperature ratings 286°F
(141°C) and 360°F (182°C) apply
to non-recessed sprinkler
assemblies.
• Escutcheon Style, as applicable
• Part Number from Table D
Refer to the price list for a com-
plete listing of part numbers.
Part numbers are for 1-Inch
NPT standard order sprinklers.
Orders for all other sprinkler as-
semblies must be accompanied
by a complete description.
2. Specify Sprinkler Wrench: W-Type 7.
Refer to Figure 9.
Dry-Type Sprinkler Boot
Specify Model DSB-2 Dry Sprinkler
Boot, P/N 63-000-0-002.
The boot part number includes one Boot,
two Strap Ties, and 1/3 oz. of Adhesive.
The quantity of adhesive is sufficient for
installing one Boot.
TFP560
Page 10 of 12

P/ N*60 – XXX – X– XXX
TABLE D
SERIES DS-1 STAINLESS STEEL DRY-TYPE SPRINKLERS
— PART NUMBER SELECTION —
ORDER
LENGTH
EXAMPLES (1)
055 5.50”
082 8.25”
180 18.00”
187 18.75”
372 3 7. 25”
480 48.00”
FINISH
6Stainless Steel for
Sprinkler and Escutcheon
TEMPERATURE
RATING (2)
0135°F (57°C)
1155°F (68°C)
2175°F ( 79°C)
3200°F (93°C)
4286°F (141°C)
5360°F (182°C)
Notes
* Use Prex “I” for ISO 7-R1 Connection; for example,
I-60-110-6-055.
1. Dry-Type Sprinklers are furnished based upon “Order
Length” as measured per Figures 10 through 17 and for
each individual sprinkler where it is to be installed. After
taking the measurement, round it to the nearest 1/4 inch
increment.
2. Temperature ratings 286°F (141°C) and 360°F (182°C)
apply to non-recessed sprinkler assemblies.
MODEL/
SIN
11 SS Pendent Quick Response
w/ Standard Escutcheon (1” NPT)
TY3230
(Figure 10)
12 SS Pendent Quick Response
w/ Recessed Escutcheon (1” NPT)
TY3230
(Figure 11)
13 SS Pendent Quick Response
w/ Deep Escutcheon (1” NPT)
TY3230
(Figure 12)
14 SS Pendent Quick Response
w/o Escutcheon (1” NPT)
TY3230
(Figure 13)
21 SS Pendent Standard Response
w/ Standard Escutcheon (1” NPT)
TY3250
(Figure 10)
22 SS Pendent Standard Response
w/ Recessed Escutcheon (1” NPT)
TY3250
(Figure 11)
23 SS Pendent Standard Response
w/ Deep Escutcheon (1” NPT)
TY3250
(Figure 12)
24 SS Pendent Standard Response
w/o Escutcheon (1” NPT)
TY3250
(Figure 13)
15
SS HSW Quick Response
Standard Coverage
w/ Standard Escutcheon (1” NPT)
TY3337
(Figure 14)
16
SS HSW Quick Response
Standard Coverage
w/ Deep Escutcheon (1” NPT)
TY3337
(Figure 15)
17
SS HSW Quick Response
Standard Coverage
w/o Escutcheon (1” NPT)
TY3337
(Figure 16)
25
SS HSW Standard Response
Standard Coverage
w/ Standard Escutcheon (1” NPT)
TY3357
(Figure 14)
26
SS HSW Standard Response
Standard Coverage
w/ Deep Escutcheon (1” NPT)
TY3357
(Figure 15)
27
SS HSW Standard Response
Standard Coverage
w/o Escutcheon (1” NPT)
TY3357
(Figure 16)
18
SS HSW Quick Response
Extended Coverage
w/ Standard Escutcheon (1” NPT)
TY3339
(Figure 17)
TFP560
Page 11 of 12

TFP560
Page 12 of 12
Copyright © 2009, 2011 Tyco Fire Protection Products. All rights reserved.
TEFLON is trademark of The DuPont Corporation.
