Sensaphone FGD-0109 User manual

FGD-0109
Temperature and Humidity Sensor
Quick Installation Guide
Informational Reference for Authorized Installers and Fitters
1. Overview
FGD-0109 temperature and humidity sensor is compact and user friendly. It measures and
displays both ambient temperature and relative humidity at the same time.
Page 1
Main Features:
1. 12V DC (12-24V DC) Main Power Input
2. Temperature Sensing Range: 0℃ – 50℃ (-32℉– 122℉) (Accuracy: ± 0.5℃ at 25℃)
3. Humidity Sensing Range: 0 – 100% RH (Accuracy: ± 5% RH at 25℃)
4. Temperature Display Unit: Degree Celsius or Degree Fahrenheit
5. 4-20 mA Analog Output
6. Dimension: 80 x 80 x 28mm
7. Weight: 250g
8. Material: ABS

2. Wiring Connection
Page 2
12 3
12V DC +
Temperature Output
Humidity Output
12V DC FGD-0109
+
-
Temperature
Humidity
+-+-
4-20mA
Input 1
4-20mA
Input 2
1
22
3
1
2
3

Page 3
3.1 Configure Temperature Display Unit ℃ / ℉
3. Press to save, press for 3 times to exit
ENTER MENU
1. Press and hold for 3 secondsand ENTER
2. Press for Degree C / for Degree F Set ℃ Set ℉
/
3.2 Configure Humidity Display RH.
3. Press to save, press twice to exit
ENTER MENU
2. Press for no RH display /for RH display Set
%
Set
RH%
/
1. Press and hold for 3 seconds and then pressand ENTER MENU
ENTER
3.3 Temperature and Humidity Offset Value Setting
4. Press to save, press to go to next page
ENTER MENU
6. Press to save, press to exit
ENTER MENU
1. Press and hold for 3 secondsand ENTER MENU
2. Use and to input password: 11 and then press PS
11
3. Use and to input temperature offset value ERR 0.0℃
SET
5. Use and to input humidity offset value ERR RH%
SET 0.0%
