Sensative Strips Guard User manual

Strips are Z-Wave magnet sensors that can be added to any
certified Z-Wave system and operate with any Z-Wave device.
Z-Wave is an international standard for wireless communication
in smart homes and buildings enabling you to monitor and
control your home remotely.
Please follow the three steps in this guide to get started.
1. Add 2. Plan 3. Place
A B
For good communication
Strips uses low power radio signals to communicate with your
Z-Wave controller. For best results, please consider the following:
Strips are designed to fit invisibly in between most wood,
aluminum, and plastic door and window frames.
Strips should not be mounted directly on magnetic surfaces
or within a metal structure as the range will be reduced.
Strips range is up to 40 meters.
Any non-battery Z-Wave device will act as a repeater to
increase network reliability and range. Usage of repeaters will
reduce Strips’ battery life.
For good functionality in the door or window
To place Strips invisibly, you need a gap with a minimum
height of 3.5 mm.
Strips may be mounted on the frame (recommended)
and the magnet on the door/window, or vice versa.
Check that magnet (A) can be placed so that it is less
than 10 mm from Strips’ flat end when the window is closed.
When the window is open, the magnet should be at least
30 mm away from Strips.
Open the door/window fully to check that the placement of
Strips and the magnet does not interfere with hinges or
locking mechanisms.
To correctly mount Strips, please follow the steps below:
1. Make sure the surface is clean, dry and at least +10°C(+50°F)
Use the included cloth to clean and prepare the surfaces.
2. Remove the short protective film from the small Strips
test adhesive. The small adhesive is used before the final
placement so it is easy to move Strips if needed.
3. Place Strips where you want it mounted. Check the position
by carefully closing the door/window and then opening it
completely again.
4. Measure and identify where the magnet (A) should be
placed. Remove the protective film and place the magnet.
Close and open again to validate that your Z-Wave
controller detected the changes. Re-mount if needed.
5. When you are satisfied, mark the exact position for Strips.
Remove it from its position, ensure that the surface is still
clean, remove the long film protecting the adhesive backing
and place Strips exactly as you marked. The long adhesive is
used to make the final placement of Strips.
6. Check that the door/window can be fully closed and opened
and that your Z-Wave controller detects the changes.
7. Keep the round magnet (B); since it can be used to wake up,
remove or reset Strips in the future.
More guidance including instructional videos:
www.sensative.com/guard
Strips uard EN LISH
ADDPLANPLACE
Wake up
To wake up Strips manually for Z-Wave communication, first place the
round magnet (B) at the rounded edge. When the LED blinks, move the
magnet away. Repeat a total of 3 times within 10 seconds.
Add/remove
Set your controller in add or remove mode (see your controller’s manual).
Follow the instruction above for Wake up. A long LED blink indicates that the
add/remove was successful.
Reset
You may need to reset Strips if your Z-Wave controller is missing or not responding.
Follow the instructions for “Wake up” above, but on the 3rd repetition, leave the
magnet at the rounded edge for 10 seconds. Along LED signal indicates success.
1 short
blink
User feedback during commands
Specific event detected (e.g. door opened)*
2 short If Strips is not added
1 long User command successfully executed
5 short Error. e.g. communication with controller failed
No Description Values Default
1Notification
type (1 byte)
0: Binary Sensor report
1: Notification report
2: Basic report
1
2LED indication
(1 byte)
0: Specific event
indication (*) Off
1: On
1
Strips are delivered in auto-add mode.
Follow the process below to add Strips to your network.
1. Start the add mode on your Z-Wave controller.
See your controller’s manual.
2. Keep Strips close to its intended location during the add
process. Remove both magnets. 1 long blink confirms the
addition.
3. Your Z-Wave controller application should now be able to
monitor your Strips sensor status.
4. Move the squared magnet (A) away from the squared end.
Check that your Z-Wave system indicates the status
correctly.
5. If your Z-Wave system doesn’t respond, you may need to
change Strips’ notification type from the controller.
Association Strips supports association group 1 (lifeline), max 1 node,
normally used to send Strips’ status to the Z-Wave controller.
Tamper Strips will send a tamper alert if it detects that someone tries to wake up or
manipulate Strips.
US/INS 11 01 012 R3
A) LED LI HT SI NALS
B) CONFI URATION
C) USER COMMANDS
D) OTHER
PARAMETERS

Limited Warranty ENGLISH
PRODUCT /WARRANTY/WARRANTY PERIOD/DEFECT:
Sensative AB (”Company” warrants to the original end-user purchaser (“Purchaser”
that Strips (“Product” will be free from substantial defects in material and workmanship
from the date when the Product is delivered to the Purchaser and continues for twelve
(12 months thereafter (“Warranty period” . The information contained herein is provided
to the Purchaser as a convenience.
LIMITATION OF PRODUCT WARRANTY:
Company warrants that the Product under normal use is free from substantial defects
in material and workmanship (“Defect” during the Warranty Period, subject to a proper
installation, operation and maintenance of the Product as set forth in the user manual
and other documentation that may become available to the Purchaser from time to
time at www.sensative.com/strips_tips (“User Manual” . Company does however not
warrant that the Product will operate uninterrupted or error-free or that all deficiencies,
errors, defects or non-conformities will be corrected.
The Warranty extends only to Purchaser and is not transferable to anyone else.
CLAIMS PROCEDURE:
Warranty claims are handled at www.sensative.com/Strips_tips.
Note that warranty claims must be filed to the Company by the Purchaser within 30
days of the manifestation of the problem.
EXCLUSIONS:
The warranty shall not apply to problems or damages resulting from or related
to
i mechanical and/or transport problems
ii external causes such as accidents, acts of God, disasters, weather conditions,
air pollution, abuse, misuse, misapplication or any equipment that generates
electrical disturbance of radio communication that violates FCC regulations
iii negligence, improper handling and failure to operate the Product according
to the User Manual
iv operating and storage problems
v electrical power and telecommunications
vi the network and/or other products in the network
vii change of window/door position
viii accessories or attachments not recommended by Company or modifications
to the Product or its parts
ix failure to follow Companys instructions relating to the Product´s use or
installation and/or to fulfil the maintenance and servicing activities defined in
the User Manual.
x cracks, fractures, cuts, abrasions, physical deformations caused by impact, falling or
dropping the device or other object, improper use or not observing the User Manual
xi service performed by anyone who is not an authorized representative of Company
xii a Product or part that has been modified
xiii a Product that is used commercially or for a commercial purpose
xiv failure of goods or services not obtained from Company
Company does not authorize any person or party to assume or create for it any
obligations or liability in connection with the Product except as set forth herein.
This warranty shall not apply to any Product if the Company´s serial number has been
removed or defaced in any way
COMPANY IS NOT RESPONSIBLE FOR ANY PROBLEM OR DAMAGE THAT OCCURS AS A
RESULT OF PURCHASER´S FAILURE TO OBSERVE THE USER MANUAL
GENERAL TERMS:
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY COMPANY MAKES NO OTHER
WARRANTIES EXPRESSED OR IMPLIED INCLUDING ANY IMPLIED WARRANTIES OF
MERCHANTIBILITY AND FITNESS FOR A PARTICULAR PURPOSE AND WARRANTIES
AGAINST HIDDEN OR LATENT DEFECTS. COMPANY EXPRESSLY DISCLAIMS ALL
WARRANTIES NOT STATED IN THIS WARRANTY. ANY IMPLIED WARRANTIES THAT MAY
BE IMPOSED BY STATUTORY LAW ARE LIMITED IN DURATION TO THE WARRANTY
PERIOD HEREUNDER.
IN NO EVENT SHALL COMPANY BE LIABLE FOR ANY LOSS OF DATA OR ANY
INDIRECT, INCIDENTAL, PUNITIVE, SPECIAL OR CONSEQUENTIAL DAMAGES
OR DAMAGES FOR LOSS OF PROFITS, REVENUE OR USE INCURRED BY
PURCHASER OR ANY THIRD PARTY, WHETHER IN ACTION, IN CONTRACT, OR
OTHERWISE EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
COMPANY´S LIABILITY AND PURCHASER´S EXCLUSIVE REMEDY FOR ANY
CAUSE OF ACTION ARISING IN CONNECTION WITH THE SALE OR USE OF
THE PRODUCT WHETHER BASED ON NEGLIGENCE, STRICT LIABILITY,
BREACH OF WARRANTY OR EQUITABLE PRINCIPLES IS EXPRESSLY LIMITED
TO COMPANY´S OPTION OF REPLACEMENT OF OR REPAYMENT OF THE
PRODUCT PRICE FOR THAT PORTION OF THE PRODUCTS WITH RESPECT TO
WHICH DAMAGES ARE CLAIMED.
TO THE EXTENT ALLOWED BY LOCAL LAW, THE REMEDIES IN THIS WARRANTY
STATEMENT ARE PURCHASER´S SOLE AND EXCLUSIVE REMEDIES AGAINST
COMPANY. [THEY DO NOT HOWEVER AFFECT OR RESTRICT THE RIGHTS THAT
PURCHASER MAY HAVE AGAINST THE DISTRIBUTOR, SERVICE PROVIDER
AND/OR RETAILER.
ALL CLAIMS OF ANY KIND ARISING IN CONNECTION WITH THE SALE OF THE
PRODUCT SHALL BE DEEMED WAIVED UNLESS MADE IN WRITING TO THE
COMPANY WITHIN 30 DAYS FROM COMPANY’S DELIVERY OR THE DATE FIXED
FOR DELIVERY IN THE EVENT OF NON DELIVERY.
DISCLAIMER:
The Product uses radio to wirelessly communicate data between itself and other
devices. Radio communication is inherently not always 100% reliable, and as
such, the Product should not be used in situations in which life and/or valuables
are solely dependent on its function.
WARNINGS:
1) DO NOT EXPOSE THE PRODUCT TO EXTENSIVE TEMPERATURE, FIRE, CHEMICALS,
OR EXPLOSIVES
2) DO NOT BRING THE PRODUCT INTO CONTACT WITH FOOD OR FOODSTUFF
3) DO NOT DISASSEMBLE THE PRODUCT; RECHARGE THE BATTERY, DISCHARGE,
SHORT-CIRCUIT OR INCINERATE
4) DO NOT EEP THE PRODUCT IN CONTACT WITH EXPLOSIVE GASES
5) DO NOT PLACE THE PROCUCT IN A MICRO WAVE, OVEN, WASHING MACHINE,
LAUNDRY DRYER, OR ANY OTHER HEAT PRUDICING APPLIANCE
6) THE PRODUCT USES VERY STRONG NEODYMIUM MAGNETS WHICH CAN BE
HA ARDOUS IF SWALLOWED. KEEP THIS PRODUCT AWAY FROM CHILDREN AT ALL
TIMES
7) MAGNETS FOUND WITHIN THE PRODUCT CAN INTERFERE OR DAMAGE CERTAIN
MAGNETIC MEDIA, INCLUDING BUT NOT LIMITED TO OPTICAL HARD DRIVES,
TELEVISIONS, MAGNETIC STORAGE MEDIA, PACE-MAKERS AND OTHER SENSITIVE
ELECTRONICS
7) DO NOT DISPOSE OF ELECTICAL APPLIANCE AS UNSORTED MUNICIPAL WASTE USE
SEPARATED COLLECTION FACILITIES
FCC NOTICE (for USA):
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Federal Communication Commission (FCC) Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. In order to avoid the possibility of exceeding the
FCC radio frequency exposure limits, human proximity to the antenna shall not
be less than 20cm (8 inches) during normal operation.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
No changes shall be made to the equipment without the Company’s permission as
this may void the user’s authority to operate the equipment.
INDUSTRY CANADA STATEMENTS:
Cet appareil est conforme avec Industrie Canada exempt de licence
Rss standard(s . Son fonctionnement est soumis aux deux conditions
suivantes : (1 cet appareil ne peut causer d’interférences, et (2 cet appareil
doit accepter toute interférence, y compris des interférences qui peuvent
provoquer un fonctionnement indésirable du périphérique.
Ce dispositife est conforme à la norme de sécurité en matière d’exposition
RF conformément à la RSS-102 §2.5.2. Ce dispositif doit être installé et
utilisé conformément aux instructions fournies et à 20 cm espacement
minimal doit être prévu entre l’antenne et le corps de toute personne pendant
les modes sans fil de fonctionnement.
INDUSTRY CANADA STATEMENTS:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired operation
of the device.
This equipment complies with the safety requirements for RF exposure in
accordance with RSS-102 §2.5.2. This equipment must be installed and
operated in accordance with the provided instructions and a minimum 20 cm
spacing must be provided between the antenna and any person’s body
during wireless modes of operation.
INDUSTRY CANADA NOTICE:
“This device complies with ISED’s licence-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device”
