Sense SNS 1t Installation guide

Locating system
SNS 1t
Quick manual
• transmitter SNS MSt2;
• adapter for transmitter;
• receiver SNS 1t;
• manual;
• WiFi R-Box;
• SNS 1t bag;
• receiver Li-Ion battery
with power cable.
Equipment:
22/14 Oktyabr`skaya str. Ulyanovsk. Russia.
[phone], [email protected], www.sense-hdd.ru

Location screen
Quality of
transmitter
signal
Transmitter
battery level
Power of
transmitter
signal
Receiver
battery level
Transmitter
temperature
Depth
Transmitter
angle
Horizontal
distance to
the probe
/ Predicted
depth in front
(F) point
3m calibration
Switching locating
points
Power ON/
OFF and
lighting
Switching telemetry
channel
Around REAR locating point
Around FRONT locting point
Around Locating Line

3m calibration
Preparations
1. Turn ONReceiver by pushing and holding Power button until sound
signal and turning ONthe screen.
2. Put AA battery into transmitter, close thecap and wait for appearing
data onthe screen.
3. Put thetransmitter into thedrill head (use adapter if needed) with
orienting on“12 o`clock” position. Put drill head in3 meters from left
(right) side of theReceiver like onthe picture below.
4. Press and hold button to start calibration process. Keep holding
button press button until 3.00 m numbers will appear. Unleash both
buttons.
5. CALIBRATION ISDONE
6. Clock position correction– correction clock face position of thedrill
head onthe screen. To make it– turn ONReceiver and transmitter,
put drill head with thetransmitter inneeded clock position, press and
hold button and then press button to confirm. New correction
can be done after canceling previous one. To cancel correction– turn
OFF thetransmitter and make correction again. Position will back to
12o`clock.

WIFI R-Box
Displaying information onthe screen
of theAndroid device using WiFi R-Box
1
34
76
5
2
1. Device ON/OFF button with light indicator
2. WiFi module ON/OFF button with light indicator
3. Telemetry level scale
4. Device battery scale
5. Plug for the antenna
6. MicroUSB plug for direct connection to Android device and for power charging.
7. USB – MicroUSB cable
Telemetry channel Distance / Depth
Telemetry status
Transmitter angle
Rod number
Location screen
Screen inversion
Tool face
Project/Table
