SensFit Habit+Band User manual

SensFit HABIT+ BAND Quick Start Guide
SensFitProprietary
© 2020 SensFit. Allrights reserved.
Charging
Power On/Off
1
To charge,gentlyGently separate the
band from the main body. Grasp the
main body with one hand, andhand
and use your other hand to gently
twist each piece of the band from the
main body.
2
CThen, connect the device to an USB
port on PC or charger. The charging
icon should beindicates to proper
connection displayed. The device will
be fully charge in under 2 hours.
3To assemble, rRemove the main
body from the USB port. Gently push
the main body back into the band.
On To power on, pPress and hold (long
press) the home button on the
device until it vibrates, and the
screen turns on.
HABIT+BAND
Quick Start Guide
FCC ID:2AWCIME-1047
Intelligent motion Bracelet
ME-1047

SensFit HABIT+ BAND Quick Start Guide
SensFitProprietary
© 2020 SensFit. Allrights reserved.
SensFit Mobile App
Scan the QR code below to download the App
on App Store or Play Store. You can also
search for “SensFit” in either store to locate the
download for the App.
Once installed, allow Bluetooth access for
connecting to the device.
Connection
Off
To power off, pPress the home
button to go to the “Functions”
menu. Press and hold the home
button to enter it. Then, press the
home button to go to the “Power
Off” menu. Press and hold the
home button to enter it. Finally,
press the home button to select
“Off” and wait up to 3 seconds for
the band to power off.
ⓘThe App is required to monitor your
progress and to configure the device.
1Go to “Settings” by clicking on the
upper left corner.
2Click on “Device” for Bluetooth
device list.
3Select the Habit+ Bandto connect.
Scroll down to refresh.
ⓘIf you have a previously connected
band, please “Unbind” and unpair in
your phone’s settings.
4To Disconnect, swipe left and click on
“Unbind”.
Functions
Power Off

SensFit HABIT+ BAND Quick Start Guide
SensFitProprietary 4
© 2020 SensFit. Allrights reserved. v0.1
HABIT+ BAND Menu Map
Wearing Habit Setting
Wearing Position
Face Touch Alert
The HABIT+ BAND provides an alert(vibration
and visual notification) when your hand is near
or touches your face. A figure notification will
be displayed on the screen as well.
2Click on “Wearing habits” to change
from left to right hand, and vice versa.
ⓘWear the HABIT+ BAND one finger
width below the wrist bone.

SensFit HABIT+ BAND Quick Start Guide
SensFitProprietary 4
© 2020 SensFit. Allrights reserved. v0.1
Hand Washing Detection
The HABIT+ BAND provides an alert (vibration
and visual notification) when your hands are
properly washed. A figure notification will be
displayed on the screen as well.
Detection Sensitivity Setting
Click on the “Detection Sensitivity” to select
between “Low”, “Medium” and “High”.
Pedometer
Swipe left to view the pedometer statistics on
the app entrance page. Daily step count
isdisplayed, as well asin addition to the
distance travelled, calories burned, and steps
goal.
Tap the circle with step count to view the
detailed daily statistics, as well as the weekly
and monthly statistics.
Sleep Monitor
ⓘTo enable or disable “Face Touch
Alert”, follow the steps in “HABIT+
BANDMenuMap” or the instructions
in “Detection Sensitivity Setting”.
ⓘ
To enable or disable “Hand Wash
Detection”, follow the steps in
“HABIT+ BANDMenu Map” or the
instructions in “Detection Sensitivity
Setting”.
ⓘClick on the switch buttons to enable
or disable “Face Touch Alert” and
“Hand Washing Detection”.

SensFit HABIT+ BAND Quick Start Guide
SensFitProprietary 4
© 2020 SensFit. Allrights reserved. v0.1
Swipe to view the sleep cycle on the app
entrance page. Total time asleep (deep/light
sleep) and times disturbed are displayed.
Tap the circle with total time asleep to view the
detailed sleep cycle, as well as the weekly and
monthly statistics.
Heart Rate Monitor
Firmware Upgrade
If a red dot appears in “Settings”→“Firmware
upgrade”, it indicates the current firmware
version is not the latest one and the HABIT+
BAND is ready for upgrade. Click on the
“Firmware upgrade”to proceed.
ⓘSleep monitor requires user wearing
the HABIT+ BAND while sleeping.
ⓘThe HABIT+ BAND should be in firm
contact with the skin on your wrist. Be
sure to tightly fasten the band, but not
too tightly that it cuts off circulation.
Contact [e-mail]://sensfithealth.com/
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
