Sensidyne Gilian AIRCON-2 Installation and operating instructions

16333 Bay Vista Dr. • Clearwater, FL 33760 • [phone] • [phone] • [phone] [FAX] * www.sensidyne.com
Revision D • Document No. F-PRO-3100
Gilian®
AIRCON-2
HIGH VOLUME AIR SAMPLER
OPERATION & SERVICE MANUAL
CYCLE MODE LOW BATTERY FAULT ERROR
RUNHOLD PROGRAMMINGSINGLE MODE
DELAYTIME
RUN TIME
HOLD TIME
#CYCLES
PRESSURE
PROG
TIME
PRESS.
ACCEPT
RUN
HOLD

LETTER FROM THE PRESIDENT
Thank you for purchasing your new Sensidyne air monitoring product. We stand
behind all of the products we sell . . . each Sensidyne product has been designed
and manufactured to provide unparalleled service, day after day. Our professional
staff has tested each unit under the strictest conditions possible to ensure successful,
accurate results every time. With the minimal care and maintenance described in this
Operation & Service Manual, the Sensidyne product you have purchased will give
you many years of reliable service.
Our only goal is that you are pleased with the quality, performance, and
accuracy of your Sensidyne product. Be assured of our complete and prompt
answers to any questions you may have about this product, since we are totally
committed to providing you with fast, responsive customer service and technical
support.
If you ever have difficulty solving a problem with any Sensidyne product, or if you
are not 100% satisfied with the service you receive from any level of our organiza-
tion, please let me know about it. Call me at either of the numbers listed below, and
I will personally research your problem to ensure that it is resolved in a manner that
is satisfactory to you. Your satisfaction with our products and service is of the utmost
importance to me.
Sincerely,
Carl Mazzuca
President, Sensidyne, Inc.
800-451-9444
727-530-3602
Fax: [phone]

3
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
Sensidyne Document No. F-PRO-3100 (Rev D)
PROPRIETARY NOTICE
This manual was prepared by Sensidyne, Inc. exclusively for the owner of the AirCon-2 High Volume Air Sampler. The
material within this manual is the proprietary information of Sensidyne, Inc. and is to be used only to understand, operate,
and service the instrument. By receiving this document, the recipient agrees that neither this document nor the information
disclosed within nor any part shall be reproduced or transferred, physically, electronically or in any form or used or dis-
closed to others for manufacturing or for any other purpose except as specifically authorized in writing by Sensidyne, Inc.
COPYRIGHT NOTICE
©1998,Sensidyne,Inc.ALLRIGHTSRESERVED.Informationcontainedinthisdocumentisprotectedbycopyright. Nopart
of this document may be photocopied, reproduced, or translated to another program or system without prior written
authorization from Sensidyne, Inc.
TRADEMARK NOTICE
Sensidyne, the Sensidyne logo, Gilian, and the Gilian logo are registered trademarks of Sensidyne, Inc. These trademarks
are protected through use and registration in the United States. The trademarks and servicemarks used in this document are
the property of their respective companies and are used only for informational and explanatory purposes.
DISCLAIMER
THE SELLER ASSUMES NO RESPONSIBILITY WHATSOEVER, TO ANY PARTY WHOSOEVER, FOR ANY
PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH RECEIVED BY OR RESULTING FROM, IN
WHOLE, OR IN PART, THE IMPROPER USE, INSTALLATION, OR STORAGE OF THIS PRODUCT BY THE
USER, PERSON, FIRM, ENTITY, CORPORATION OR PARTY NOT ADHERING TO THE INSTRUCTIONS
AND WARNINGS IN THIS MANUAL, OR OTHERWISE PROVIDED BY THE SELLER OR FROM NOT AD-
HERING TO ALL FEDERAL, STATE, AND LOCAL ENVIRONMENTAL AND OCCUPATIONAL HEALTH AND
SAFETY LAWS AND REGULATIONS.
THE SELLER SHALL NOT BE LIABLE FOR DIRECT, INDIRECT, CONSEQUENTIAL, INCIDENTAL OR
OTHER DAMAGES RESULTING FROM THE SALE AND USE OF ANY GOODS AND SELLERS’ LIABILITY
HEREUNDER SHALL BE LIMITED TO REPAIR OR REPLACEMENT OF ANY GOODS FOUND DEFECTIVE.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING BUT
NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE OR FOR
A PARTICULAR PURPOSE WHICH ARE EXPRESSLY DISCLAIMED.

— PRELIMINARY —
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
4
Sensidyne Document No. F-PRO-3100 (Rev D)
TABLE OF
CONTENTS
• PREFACE
• WARNINGS ........................................................................................................................... 7
• Packing List .......................................................................................................................... 8
SECTION ONE: INTRODUCTION
1.1 Description ................................................................................................................. 9
1.2 Power Sources ...........................................................................................................10
1.2.1 AC Power .......................................................................................................10
1.2.2 Voltage ...........................................................................................................10
1.2.3 DC Power .......................................................................................................10
1.2.4 Power Module................................................................................................10
1.3 Controls & Indicators ..............................................................................................12
1.3.1 On/Off Switch ................................................................................................12
1.3.2 Flow Adjustment ............................................................................................12
1.3.3 LCD Display (Program Model) ......................................................................12
1.3.4 Touch-Pad Buttons (Program Model) ...........................................................12
1.4 Standard Parts ........................................................................................................... 12
1.4.1 Telescopic Sampling Mast .............................................................................12
1.4.2 Air House & Hose Support Tip......................................................................12
SECTION TWO: SET-UP
2.1 General Set-Up ..........................................................................................................16
2.1.1 Sampling Mast ................................................................................................16
2.1.2 Air Hose .........................................................................................................16
2.1.3 Filter Cassettes ...............................................................................................16
2.2 Charging.....................................................................................................................17
2.2.1 Using The DC Unit .........................................................................................17
2.2.2 Charging With The Power module................................................................17

5
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
Sensidyne Document No. F-PRO-3100 (Rev D)
TABLE OF
CONTENTS
SECTION THREE: OPERATION
3.1 Overview ....................................................................................................................21
3.1.1 AC Basic Model ..............................................................................................21
3.1.2 AC Program Model ........................................................................................21
3.1.3 DC Program Model ........................................................................................21
3.2 Basic Operation ........................................................................................................21
3.2.1 Single Mode (All Models) .............................................................................. 21
3.2.2 Cycle Mode Operation...................................................................................21
3.3 Faults...........................................................................................................................24
3.3.1 Fault Function (Program Model) ...................................................................24
3.3.2 Correcting Fault Conditions...........................................................................24
3.3.3 Low Battery Indication (DC Model) ..............................................................24
3.4 Programming Examples .........................................................................................25
3.4.1 Cycle Mode Programming Example ..............................................................25
3.4.2 Other Programming Examples ......................................................................25
SECTION FOUR: AFTER SAMPLING
4.1 Unit Shut Down ........................................................................................................32
4.2 Sampling Mast ........................................................................................................... 32
4.3 Battery Pack Maintenance ...................................................................................... 32

— PRELIMINARY —
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
6
Sensidyne Document No. F-PRO-3100 (Rev D)
SECTION FIVE: APPENDICES
• Appendix A: Parts List ..................................................................................................... 33
• Appendix B: Specifications .............................................................................................34
• Appendix C: Returned Material Authorization ...........................................................35
• Returned Material Authorization .............................................................................35
• Service Options .......................................................................................................35
LIST OF FIGURES
1.1 AirCon-2 Air Sampler with Sampling Mast & Air Hose ...........................................11
1.2 Front Panel (Program Model) ..................................................................................13
1.3 Liquid Crystal Display (Program Model) .................................................................14
1.4 AirCon-2 Accessory Configurations .........................................................................15
2.1 DC Sampler Set-Up ..................................................................................................18
2.2 Power Module Set-Up (Single Pack) .......................................................................19
2.3 Power Module Set-Up (Multiple Packs) ..................................................................20
3.1 Cycle Mode Programming Example ........................................................................25
LIST OF TABLES
1.1 Available AirCon-2 Models ........................................................................................9
3.1 Setting Air Flow (Basic & Program Models) ............................................................22
3.2 Single-Mode Operation ............................................................................................23
3.3 Pre-Programmed Data..............................................................................................26
3.4 Entering Program Mode ...........................................................................................27
3.5 Delay Time ...............................................................................................................28
3.6 Run Time .................................................................................................................29
3.7 Hold Time ................................................................................................................30
3.8 Run Cycles ................................................................................................................31
TABLE OF
CONTENTS

7
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
Sensidyne Document No. F-PRO-3100 (Rev D)
READ AND UNDERSTAND ALL WARNINGS BEFORE USE
Read and understand ALL warnings before using this product. Failure to read, understand, and comply with
ALL warnings could result in property damage, severe personal injury, or death.
Read and understand ALL applicable Federal, State, and Local environmental health and safety laws and
regulations, including OSHA. Ensure complete compliance with ALL applicable laws and regulations before
and during use of this product.
UNDER NO CIRCUMSTANCES should this product be used except by qualified, trained, technically
competent personnel and not until the warnings, Operation and Service Manual, labels, and other literature
accompanying this product have been read and understood.
The Operation and Service Manual must be read and understood by each user before operating this product
or using its accessories, in order to ensure proper and safe use and installation of this product and to ensure
familiarity with the proper treatment and safety procedures in the event of an accident.
Caution: Risk of electrical shock.
Warning: Line cord must be removed to remove all power from equipment.
DO NOT remove, cover, or alter any label or tag on this product, its accessories, or related products.
DO NOT operate this product should it malfunction or require repair. Operation of a malfunctioning product,
or a product requiring repair may result in serious personal injury or death. DO NOT attempt to repair or
modify the instrument, except as specified in the Operation and Service Manual. Contact the Sensidyne
Service Department to arrange for a Returned Material Authorization (RMA).
Use ONLY genuine Sensidyne®replacement parts when performing any maintenance procedures described
in this manual Specifically the DC version of the AirCon-2 is designed for use with AirCon-2 battery packs,
and should not be used in conjunction with any other equipment. Rechargeable battery packs are designed
to be charged with the AirCon-2 Power Module and in strict accordance with the charging instructions
contained in this manual. Failure to follow these warnings may seriously impair instrument performance.
Repair or alteration of the product beyond the scope of these maintenance instructions, or by anyone other
than a certified Sensidyne®serviceman, could cause the product to fail to perform as designed, and persons
who rely on this product for their safety could sustain severe personal injury or death.
DO NOT operate unit in excessive chemical or water vapor atmospheres. Failure to follow instructions may
cause permanent damage to the equipment.
NEVER block the cooling air inlets (located at the top/back of unit) when the unit is operating.
NEVER block any of the venting holes (located on the sides of the case) when the unit is operating.
ALWAYS place the unit on a secure and level surface when operating.
ALWAYS operate unit within the intrinsically safe environmental regime specified (non-hazardous loca-
tions).
WARNINGS !

— PRELIMINARY —
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
8
Sensidyne Document No. F-PRO-3100 (Rev D)
The items listed below are shipped with the Gilian AirCon-2 High Volume Air Sampler:
• AirCon-2 Air Sampler unit
AirCon-2 “AC” models include a Power Cord
AirCon-2 “DC” models require a battery pack (sold separately)
• Air Hose (Tubing)
• Hose Support Tip
• Sampling Mast
•Operation and Service Manual
• Registration Card/Warranty Card
PACKING LIST
ALWAYS check to make certain
you have received all of the items listed above.
If you have any questions or need assistance,
contact your Sales Representative, or call
[phone]
OR
[phone]

9
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
Sensidyne Document No. F-PRO-3100 (Rev D)
SECTION ONE
INTRODUCTION
Table 1.1
Available Aircon-2 Models
1.1 DESCRIPTION
IMPORTANT
You must read this manual in its entirety to ensure proper
operation of your unit.
The AirCon-2 Air Sampling System is a powerful envi-
ronmental air sampler used to collect air samples in-
doors and outdoors. It is equipped with useful perfor-
mance features industrial hygienists need most; easy
set-up, compact size, battery pack operation, program-
mable timing functions and DC portability.
Table 1.1 (below) lists the available AirCon-2 models.
The AirCon-2 high volume air sampling system consists
of a positive displacement pump with a unique pat-
ented regulator system which maintains flow constant
over a flow range of 2-30 LPM. The sampler maintains
air flow constant for sampling of airborne particulate,
hazardous dust and low concentration pollutants using
many popular filter cassettes. The volume of air that
passes through the filter cassette is determined by the
following:
Air flow xElapsed time = Volume
The unit is set up in the required location and
plugged into a properly grounded voltage source.
DC version units are connected to either a 2-hour or
4-hour battery pack and/or to a power module which
is designed to power DC version units from a stan-
dard AC source.
The AirCon-2 system provides a telescopic sampling
mast which is extended and to which the air hose/
support tip is connected. The media, typically a filter
cassette, is inserted into the end of the sampling
hose. The other end of the air hose is connected to
the “Air Inlet” located at the front of the sampler.
After positioning the unit and setting up the sampling
mast stand, the unit can be turned on. Air flow is set
by use of the external flow adjust knob and is indi-
cated on the built-in rotameter.
Programmable models offer a touch keypad and LCD
display which allow the user to program sampling
routines. Programmable timing functions include:
start and stop times, intermittent run, delay, run/hold
and memory storage of up to three custom timing
programs. The full-function display and touch pad
offer key-in programming and visual monitoring of
all timing functions during programming and sampler
operation.
.oNtraP §epyTledoM/egatloV rewoPCA rewoPCD gnimiT
1-010108 CAV511-cisaBCA X
2-010108 CAV032-cisaBCA
1-110108 CAV511-margorPCA XX
2-110108 CAV032-margorPCA X X
210108**margorPCDXX
:setoN
.launamdna,tsamgnilpmas,pittroppusesoh,esohria,tinurelpmasniam:edulcnistikllA§
.drocenilCAnaedulcnioslastikCA
.noitareporofeludoMrewoPro/dnakcapyrettabruoh-4roruoh-2eriuqerstikCD**
.yletarapesdlossmetiCD
.eludoMrewoPlanoitpohtiwdesunehwtnerrucCAnoetareponacstinuCD†

— PRELIMINARY —
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
10
Sensidyne Document No. F-PRO-3100 (Rev D)
1.2 POWER SOURCES
1.2.1 AC Power
AC power is provided by means of a removable line
cord which plugs into a 3-prong power jack located on
the back of the unit. A 2-prong Euro plug is provided
for 230 VAC operation.
1.2.2 Voltage
The AirCon-2 operating voltage is preset at the factory
for either 115 or 230 volts. This is indicated on the label
located at the rear of the unit. If you need to change
the voltage, do the following:
WARNING
Make certain you unplug the unit before proceeding.
1. Remove the screws holding the cover
2. Facing the left side of the unit as viewed from the
front, locate the voltage select switch which is ap-
proximately 1/3 of the way up from the bottom of
the PC board.
3. To change the voltage, insert a small flat blade
screwdriver into the slot and rotate to the appropri-
ate voltage.
4. Remove the existing fuse and replace with the ap-
propriate fuse for that voltage.
5. Replace the cover and provide the proper line cord
adapter for the voltage receptacle.
IMPORTANT
You should place a label or sticker on the unit to show that the
voltage has been changed.
NOTE
Changing factory-set 115 VAC units to 230 VAC
negates CE certification.
1.3.3 DC Power
DC Power is provided by two-hour and four-hour bat-
tery packs. The battery packs can be stacked and inter-
connected to achieve the ampere hour rating required
to meet the most stringent sampling conditions. Battery
packs are recharged with the optional Power Module.
1.2.4 Power Module
The DC version of the AirCon-2 can be run directly off
the power module. If the battery module is also at-
tached, it will slowly charge the battery while still pro-
viding sufficient power to run the sampler. It will rap-
idly charge the battery if the sampler is turned off un-
der the same circumstances. The power module may
also be used as a stand-alone battery charger and may
charge one or more batteries. The unit will automati-
cally reduce the charging currents as the battery be-
comes fully charged. An LED indicator illuminates
when charging and flashes when charging is complete.
If no battery is attached it will flash indicating sufficient
voltage to run the sampler. The power module can op-
erate on 115–230 VAC, 47–63 Hz.

11
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
Sensidyne Document No. F-PRO-3100 (Rev D)
Figure 1.1
AirCon-2 Air Sampler with Sampling Mast & Air Hose
20
Enclosure
Handle
Mounting Feet (4)
Cooling Air Inlet
Cooling Air Discharge
Discharge Air Boss
AC Power Inlet
DC Supply Latch **
DC Interconnect Plug **
On/Off Switch
LCD Display †
ACCEPT Key †
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
PROGRAM Key †
TIME/PRESS. Key †
RUN/HOLD Key †
Inlet Air Boss Suction
Flow Adjust Knob
Flowmeter
Sampling Mast
Air Hose
Hose Support
Sampling Media (ref only)
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
** DC Units only
† Program Models only
2
18
17
2
5
5
3
12
7
8
6
4
19
21
22
13 14
9
15 10
11
16
1
CYCLE MODE LOW BATTERY FAULT ERROR
RUNHOLD PROGRAMMINGSINGLE MODE
DELAYTIME
RUN TIME
HOLD TIME
#CYCLES
PRESSURE
PROG
TIME
PRESS.
ACCEPT
RUN
HOLD

— PRELIMINARY —
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
12
Sensidyne Document No. F-PRO-3100 (Rev D)
1.3 CONTROLS & INDICATORS
1.3.1 On/Off Switch
The power is activated by a rocker switch located to
the right of the key pad. The removable electrical cord
provided is attached at the back of the unit marked “In-
put Power.”
CAUTION
Line cord must be removed to remove all power from equip-
ment.
1.3.2 Flow Adjustment
The patented flow controller system consists of the flow
control regulator located in the base of the pump, and
the flow control system which consists of the flow ad-
just valve and rotameter located on the front of the
sampler.
1.3.3 LCD Display (Program Model)
A large easy-to-read display is included on Program
Models (see Figures 1.2 & 1.3). The display includes di-
rect digital readings, as well as a variety of messages
pertaining to the operation and programming of the
unit.
1.3.4 Touch-Pad Buttons (Program Model)
The Touch-Pad buttons are explained as follows:
ACCEPT
This is used to switch the unit into the prepro-
grammed cycle modes or as confirmation (in pro-
gramming mode) to accept data into memory.
PROG (Program)
This button is used to enter programming mode
and to set or change program data.
TIME/PRESS. (Pressure)
Pressing this button toggles the display between
Time and Pressures readings. These readings can
be viewed any time while the unit is running.
RUN/HOLD
Pressing this button switches the pump operation
between Run and Hold functions.
1.4 STANDARD PARTS
1.4.1 Telescopic Sampling Mast
The telescopic sampling mast is provided as an inde-
pendent stand to isolate the filter cassette from the unit
insuring vibration-free sampling. The mast can be ex-
tended to achieve any height up to approximately 5
feet and collapses for convenient storage.
1.4.2 Air Hose & Hose Support Tip
Approximately 6 feet of hosing is supplied with the
unit. One end is connected to the Inlet Air Boss Suction
port on the sampler and threaded through the Hose
Support Tip which is mounted on the sampling mast. A
filter cassette is then attached to the other end of the air
hose.

13
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
Sensidyne Document No. F-PRO-3100 (Rev D)
Figure 1.2
Front Panel (Program Model)
PROG
RUN
HOLD
TIME
PRESS.
ACCEPT
OFF
ON
Made in USA
Gilian
®
High Volume Air Sampler
CYCLE MODE LOW BATTERY FAULT ERROR
RUNHOLD PROGRAMMINGSINGLE MODE
DELAY TIME
RUN TIME
HOLD TIME
#CYCLES
PRESSURE
I
O
irCon2
A

— PRELIMINARY —
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
14
Sensidyne Document No. F-PRO-3100 (Rev D)
Figure 1.3
Liquid Crystal display (Program Model)
MODE LOW BATTERY FAULT ERROR
RUNHOLD PROGRAMMINGSINGLE MODE
DELAY TIME
RUN TIME
HOLD TIME
#CYCLES
PRESSURE
CYCLE

15
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
Sensidyne Document No. F-PRO-3100 (Rev D)
Figure 1.4
AirCon-2 Accessory Configurations
PROG
TIME
PRESS.
ACCEPT
RUN
HOLD
CYCLE MODE LOW BATTERY FAULT ERROR
RUNHOLD PROGRAMMINGSINGLE MODE
DELAY TIME
RUN TIME
HOLD TIME
#CYCLES
PRESSURE
PROG
TIME
PRESS.
ACCEPT
RUN
HOLD
CYCLE MODE LOW BATTERY FAULT ERROR
RUNHOLD PROGRAMMINGSINGLE MODE
DELAY TIME
RUN TIME
HOLD TIME
#CYCLES
PRESSURE
4-Hour Battery Pack
mounted on the Power
Module for charging.
DC Sampler mounted onto
a 4-Hour Battery Pack. DC Sampler and 4-Hour Battery Pack mounted on
the Power Module for
operation in AC or DC
environments.
Aircon-2
Sampler
Battery
Pack
Battery
Pack
Power
Module
Aircon-2
Sampler
Battery
Pack
Power
Module

— PRELIMINARY —
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
16
Sensidyne Document No. F-PRO-3100 (Rev D)
SECTION TWO
SET-UP
2.1 GENERAL SET-UP
Place the unit in the desired sampling area. Make cer-
tain the unit is standing in a vertical position.
NOTE
When using rotameters, it is important to maintain a vertical
position for optimum accuracy. The rotameter provided in this
sampler has been tested for accuracy and is within ± 5% of full
scale.
2.1.1 Sampling Mast
To set up the Sampling Mast, perform the following
steps:
1) First, unfold the legs at the bottom of the mast
stand by opening the locking knob and pulling the
legs outwards as far as they will extend.
2) Loosen the largest locking collar at the bottom of
the stand and pull out by the second largest lock-
ing collar. Tighten the largest collar.
3) Holding the extended section, loosen the second
largest locking collar and extend the next section
of the mast. Tighten the second largest collar.
4) Repeat this procedure until the mast is extended to
its full or required height.
5) Be sure to tighten each locking collar before pro-
ceeding to loosen the next. Position the extended
mast next to sampler.
2.1.2 Air Hose
To attach the Air Hose, perform the following steps:
1) Connect one end of the flexible tubing to the air in-
let valve located at the front of the sampler.
2) Connect the hose support tip to the top of the ex-
tended sampling mast.
3) Insert tubing through the hose support tip, with 2–
3" of the hosing extending out.
4) Insert filter cassette or other media into air hose
end.
2.1.3 Filter Cassettes
To install the Filter Cassette, do the following:
1) First, remove any cap plugs from the filter cassette.
These may be colored in red and blue. Also re-
move the end of the filter cassette to expose the fil-
ter. This is called “open-face” filter sampling. This
allows air to enter the cassette freely with minimal
back pressure.
2) Plug the filter cassette into the end of the sampling
hose.

17
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
Sensidyne Document No. F-PRO-3100 (Rev D)
3.4
2.2 CHARGING
2.2.1 Using The DC Unit
Connecting the DC Unit
1) Place the battery pack or power module on a flat
surface, orienting the guide pins either to the left or
right.
2) Tilt the sampler approximately 10°, as shown in
Figure 2.1, and engage the female guide-pin recep-
tacle into the guide pins of the battery pack or
power module. Rotate the unit around the guide
pins such that the back lip of the battery pack or
power module slides over the recess on the back
bottom of the sampler.
NOTE
Once the guide pins are aligned and seated, the electrical
connector on the sampler and battery pack (or power module)
will connect automatically.
3) Pull the latch on the rear of the battery pack (or
power module) over the latch keeper on the back
of the sampler, pushing down on the latch to se-
cure it.
4) Repeat this procedure for any additional battery
packs and/or power modules.
Disconnecting the DC Unit
1) Disengage the latch hook.
2) Rotate the sampler about guide pin until the back
of the sampler disengages the battery pack or
power module.
3) Disengage the female receptacle and guide pins of
the sampler from the battery pack or power mod-
ule respectively.
2.2.2 Charging With The Power Module
The power module may be plugged into any line volt-
age from 115 to 230 VAC, 50/60 Hz without any switch
adjustments.
To charge the battery pack independently:
1) Connect the battery pack to the power module (re-
fer to Figure 2.2). Multiple battery packs may be
connected to the power module (refer to Figure
2.3).
2) Attach the line cord to the receptacle located at the
back of the power module.
3) Plug the line cord into the AC receptacle.
4) An LED, located on the back of the power module
will light, indicating whether there is sufficient DC
voltage available to the sampler. If a battery pack is
attached and is not fully charged, the LED will re-
main illuminated until the battery is charged. When
fully charged, the LED will start to pulse. If no bat-
tery is attached, the unit will pulse.

— PRELIMINARY —
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
18
Sensidyne Document No. F-PRO-3100 (Rev D)
Figure 2.1
DC Sampler Set-Up
ELECTRICAL
CONNECTION
LATCH
HOOK
GUIDE PIN
DC PACK

19
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
Sensidyne Document No. F-PRO-3100 (Rev D)
Figure 2.2
Power Module Set-Up (Single Pack)
ELECTRICAL
CONNECTION
GUIDE PIN
LATCH
HOOK
POWER
MODULE
POWER
MODULE
BATTERY
PACK

— PRELIMINARY —
Gilian® AIRCON-2 HIGH VOLUME AIR SAMPLER
20
Sensidyne Document No. F-PRO-3100 (Rev D)
Figure 2.3
Power Module Set-Up (Multiple Packs)
ELECTRICAL
CONNECTION
GUIDE PIN
LATCH
HOOK POWER
MODULE
BATTERY
PACK
BATTERY
PACK
