Sensio Alpha-R User manual

Sensio House, Unit 7, Speedwell Road, Whitwood, Castleford, West Yorkshire, WF10 5PY
www.sensio.co.uk
Technical drawings for illustraon purposes only, Sensio had the right to change any informaon without
prior noce. Make sure you check all hole cut outs before work commences.
Waste Electrical & Electronic Equipment (WEEE)
The symbol on the product, or on the document accompanying the product, the crossed out wheelie
bin symbol, indicates that this product may not be treated as household waste.
Instead it shall be handed over to the applicable collecon point for the recycling of electrical and
electronic waste.
5. Suitable for furniture lighng.
6. When the lamp expires the fing must be replaced
7. Class III safety extra low voltage (SELV).
1. Before commencing installaon or maintenance, isolate the main
electrical supply for the appropriate circuit at the fuse board.
2. This product is only suitable for connecng to a 240V 50Hz supply.
3. The lights should be mounted onto a secure surface.
4. Never exceed the total output of the LED driver.
Safety Instrucons
Please read these instrucons carefully before aempng to install this
product. It is
advisable to keep these instrucons in a safe place for future reference.
We recommend that you consult a qualified electrician. All
electrical installaon must be carried out in accordance with
current IEE wiring regulaons (BS7671).
These pThese products must not be modified, if any modificaon are made, it may
invalidate the warranty and may render the product unsafe. These LED
lights operate low voltage (24V).
Do not wire the individual LED light fings directly to the mains. This
product is for indoor use only. Keep out of moisture and use only in dry
rooms.
• If in doubt, installaon must be carried out by a qualified
electrician.
• Install on smooth flat surface(s) only.
• Do not exeed or stretch the cable length of each LED wire.
• This product is IP20 Rated.
• The waage for each light is 3W. Make sure that the LED
dri driver used with these fings has an adequate max waage,
which is higher than 3W.
Important Safety Informaon
Pencil Screwdriver Ø8 mm
Drill Bit
Power Drill
Alpha-R Under Cabinet Spot Light
1 x Instrucons
Manual
Driver and JB4 Distribuon Block
(Not Included)
Tools Required
Components
IMPORTANT: Please read these instrucons before commencing installaon and retain for future reference.
Product Codes: SE11390W0
SE11390C0
INSTALLATION
INSTRUCTIONS
Sensio V1

Finally, connect the driver to the mains supply or aach
a plug.
65
Connect the Alpha-R to the JB4 driver distribuo block.
Sensio V1
4
Sck the metal casing on to the lamp.
3
Peel the backing tape off of the adhesive pads on the
metal casing.
2
Screw the lamp into posion using a screwdriver and
thread the cable through the hole.
1
Carefully mark the the screw locaons using the
dimensions shown above and drill a Ø8mm hole into the
base panel at the back of the cabinet. Note: Dimensions
can vairy if les or splashbacks are installed.
Installaon
Essenal Parts:
- SE40553 6W LED Driver with 4 Port JB4 Distributor
- SE4055 15W LED Driver with 6 Port JB4 Distributor
- SE40556 30W LED Driver with 12 Port JB4 Distributor
- SE4057 60W LED Driver with 12 Port JB4 Distributor
Operaon
Maintenance & Care
• Ensure that the power is disconnected prior to cleaning.
• To keep the finish of this product, wipe over with so cloth periodically.
• Do not use harsh chemical solvents, this may dis-colour or damage the finish.
Technical drawings for illustraon purposes only, Sensio had the right to change any informaon
without prior noce.
www.sensio.co.uk
Sensio House, Unit 7, Speedwell Road, Whitwood, Castleford, West Yorkshire, WF10 5PY
Alpha-R - Under Cabinet Spot Light
