Teknik FLEXI SENSOR User manual

[FLEXI]SENSOR
LED SPOTLIGHT
USER MANUAL

Teknik Lighting Solutions Pty Ltd
ABN: 44 608 397 913
Tel: [phone]
www.tekniklighting.com.au
INTRODUCTION
Thank you for selecting the [FLEXI]SENSOR. This is suitable only
for use with the [FLEXI] LED SPOTLIGHT. Please ensure that
the sensor is installed in accordance with the below
instructions. TEKNIK assumes no responsibility for
inappropriate use or installation of the product, including any
associated damage caused.

SPECIFICATIONS
Input Voltage
Ambient Light
Time Delay
Detection Range
Detection Angle
Motion Detection Speed
Recommended Installation Height
<10-2000 Lux (adjustable)
min: 10sec ±3sec, max: 12min±3min
2 - 12m (< 24oC) (adjustable)
180o
0.6 ~ 1.5m/s
1.8m-2.5m
5V DC

INSTALLATION
Attach the sensor
to the bottom of the
[FLEXI] fitting ensuring
all pins are aligned.
2
Turn the [FLEXI] ON and follow the test and
function setting instructions.
3
1Remove
the cap of
the [FLEXI]
fitting.

FUNCTIONS
LUX
Use this setting to adjust the sensor according to ambient light. When
the lux dial Is set to the moon position the [FLEXI] will only operate
when the ambient light level is below 10lux. When the lux dial is set to
the sun position, the [FLEXI] will operate with an ambient light up to
2000lux.
SENSITIVITY
Use this setting to adjust the sensitivity level. Low sensitivity will detect
motion within 2m and high sensitivity will detect motion up to 12m.
TIME
Use this setting to adjust how long the [FLEXI] stays on after motion is
detected. Minimum ON time is 10sec ±3sec and maximum ON time is
12mins ±3min.

TEST
For testing in daylight turn lux dial to the ÔsunÕ position, sensitivity dial
to max (+) and time dial to (-). Adjust the angle and orientation of the
sensor as desired. Make final lux, sensitivity and time adjustments to
your preferred settings.
To override the sensor operation, turn the power on, activate the light
via the sensor so it is actually illuminated, then switch the power
off/on/off/on within 3 seconds. The [FLEXI] will now remain on until the
power is switched off or put back into sensor mode. To resume
sensor operation, turn off the power for 10 seconds then back on.
Manual Override
