Sepura SEM8040H User manual

S M8040H
Quick Reference Guide
DMR Mobile Radio
E

Quick Reference Guide
1
General
This guide covers the basic operation of the DMR Mobile. Please refer
to the DMR Mobile user guide for more detailed information on using
this product.
Disclaimer notice
Sepura’s policy is to continually improve its products. The features and
facilities described in this document were correct at publication, but
are subject to change without notice.
Contact Us
Sepura plc.
Radio House,
St Andrew’s Road,
Cambridge CB4 1GR
United Kingdom
Tel: [phone]
Fax: [phone]
SPR-DOC-03808/1
Original Instructions: ENGLISH
© Sepura plc. 2014
All rights reserved. This document is intended for the use of Sepura plc’s customers and/or
other parties only for the purposes of the agreement or arrangement under which this document
is submitted, and no part of it may be reproduced or transmitted in any form or means without
the prior written permission of Sepura plc.
Contents
Safety ....................................................................................... 2
Disposing of this product.........................................................4
Connectors, controls, buttons and keys ..................................... 6
Status indicators and icons........................................................ 6
Accessory information .............................................................. 8
Fist microphone.....................................................................8
Basic operation......................................................................... 8
Power On/Off........................................................................8
Adjusting the volume..............................................................8
Selecting a Channel................................................................8
Making a PTT call .................................................................8
Receiving a PTT call ..............................................................9
Emergency alarm...................................................................9

DMR Mobile Radio
2
Safety
Read these safety instructions carefully.
Attention!
Sepura mobiles are designed for use by mobile workforces, often
working alone, and are intended for use in occupational and controlled
conditions. This product is restricted for occupational use and is not
intended or authorised for use by the general population.
It is the responsibility of the person operating the product to ensure that
it is operated safely at all times, and that local laws and regulations
governing the usage of Radio Frequency (RF) products are observed.
Users must be trained to operate this product safely. Their personal
safety could be affected if they do not understand how to operate this
product correctly.
Exposure to RF energy
Sepura designs and manufactures products to meet strict guidelines and
international standards relating to Radio Frequency energy and the
potential health risks associated with using such products.
Sepura terminals are low powered radio transmitters and receivers that
receive and transmit Radio Frequency (RF) signals when switched on.
The antenna radiates RF energy only when transmitting and not in
standby mode.
Users should be informed of the potential health risks associated with
long term exposure to RF energy by their employer.
RF energy interference with electronic equipment
Some personal medical devices, such as hearing aids and pacemakers,
can be affected by RF energy. Always consult your Service Provider or
the manufacturer of the medical device before using RF wireless
devices.
Some electronic devices are sensitive to RF energy. Always obey signs
restricting the use of wireless devices.
Safely operating the product
Users should always ensure that the mobile is operating correctly
before entering any environment that has a potential risk to personal
safety.
Operate the fist microphone in a vertical position and with the
microphone 5 cm (2 in.) away from your mouth when transmitting.
Safety in hazardous environments
Always switch off the mobile in environments where RF wireless
devices could potentially cause an explosion. Potentially hazardous
areas are not always signed. Obey all signs and instructions relating to
the usage of RF wireless devices.
Do not use the mobile in the presence of gas fumes, explosives dust
situations, nuclear facilities, fuel or chemical transfer or storage
facilities.
This mobile is not designed for use in potentially explosive
environments where RF wireless devices could potentially cause an
explosion. SWITCH OFF the mobile if you are unsure if the mobile is
a risk in these environments. Potentially hazardous areas are not
always signed. Obey all signs and instructions relating to the usage of
RF wireless devices.
Safety when driving a vehicle
Always obey local laws and regulations governing the operation of RF
wireless devices when driving and whilst at locations.
Do not operate the product if it creates a distraction from driving safely
and observing road conditions.
Always switch off the mobile at refuelling stations. Always observe
and obey warning signs relating to the use of RF wireless devices in
the vicinity of refuelling stations.
Accessories
Sepura products have been tested to meet strict guidelines for personal
safety and operational conditions. Only accessories approved by
Sepura are recommended for use with this product.

set forth for a controlled
Quick Reference Guide
3
Always read the instructions supplied with the accessory for additional
safety instructions.
Unauthorised modifications to the product could cause the product to
become non-operational.
The use of non-approved accessories may invalidate any product
warranty.
If a non-approved accessory is fitted, it may compromise the product
safety ratings.
Servicing
Do not attempt to dismantle this product.
Servicing and repairs to this product must be performed by trained
service technicians at Sepura approved service centres.
FCC NOTICE
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Radiation Exposure Statement: This equipment complies with
FCC radiation exposure limits
environment. The antenna of equipment should be installed and
operated with minimum distance 0.75m between the radiator& your
body.
This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
IC Warning
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
The term “IC:” before the certification/registration number only
signifies that the Industry Canada technical specifications were
met.Under Industry Canada regulations, this radio transmitter may only
operate using an antenna of a type and maximum (or lesser) gain
approved for the transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and its gain should
be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is
not more than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent
émetteur radio peut fonctionner avec une antenne d'un type et d'un gain
maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada.
Dans le but de réduire les risques de brouillage radioélectrique à
l'intention des autres utilisateurs, il faut choisir le type d'antenne et son
gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.)
ne dépasse pas l'intensité nécessaire à l'établissement d'une
communication satisfaisante.
This radio transmitter (identify the device by certification number, or
model number if
Category II) has been approved by Industry Canada to operate with the
antenna types listed below with the maximum permissible gain and
required antenna impedance for each antenna type indicated. Antenna

rayonnements définies pour contrôlé environnement.
rth for an controlled environment.
DMR Mobile Radio
4
types not included in this list, having a gain greater than the maximum
gain indicated for that type, are strictly prohibited for use with this
device.
Le présent émetteur radio (identifier le dispositif par son numéro de
certification ou son numéro de modèle s'il fait partie du matériel de
catégorie I) a été approuvé par Industrie Canada pour fonctionner avec
les types d'antenne énumérés ci-dessous et ayant un gain admissible
maximal et l'impédance requise pour chaque type d'antenne. Les types
d'antenne non inclus dans cette liste, ou dont le gain est supérieur au
gain maximal indiqué, sont strictement interdits pour l'exploitation de
l'émetteur.
IC Radiation Exposure Statement: This equipment complies with IC
RF radiation exposure limits set fo
This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter. The antenna of equipment
should be installed and operated with minimum distance 0.75m
between the radiator & your body.
IC exposition aux radiations:
Cet équipement est conforme avec IC les limites d'exposition aux
Cet émetteur ne doit pas être co-localisés ou fonctionner en
conjonction avec une autre antenne ou émetteur.
L'antenne de l'équipement doit être installé et utilisé avec un minimum
de 0.75 m de distance entre le radiateur et votre corps.
Regulatory Sepura declares that this product is compliant
with the essential requirements and other
relevant provisions of the European R&TTE
directive 1999/5/EC relating to radio and
telecommunications terminal equipment and the
mutual recognition of their conformity. This
product is also compliant with directive 2011/65/EU having been
designed and manufactured to the RoHS requirements.
Disposing of this product
This symbol on the product or its packaging indicates
that this product must not be disposed of as household
or commercial waste. Some countries have set up
collection and recycling systems for waste electrical
and electronic products. By ensuring that this product
and its packaging is disposed of correctly, you will
help prevent potentially negative consequences for the
environment and human health, and help conserve natural resources.
Please dispose of your waste product according to your national and
local regulations. Contact your Service Provider for information about
disposing of this product in your region of the world.

Quick Reference Guide
5

DMR Mobile Radio
6
Connectors, controls, buttons and
keys
Refer to the illustration for the location of the following connectors,
controls, buttons and keys:
(1) Volume control knob
(2) Microphone/programming cable interface connector
(3) Left context key
(4) Up navigation key
(5) Down navigation key
(6) Right context key
(7) Power button
(8) LED
(9) Speaker
(10) Microphone
(11) PTT key (hand microphone)
(12) Emergency button
(13) Home/Cancel key
(14) Dial key(future use)
(15) P1 - P4 (programmable keys)
(16) Display
Status indicators and icons
Status indicators show the operational state of your mobile. Icons
appear on your mobile display when you perform certain activities or
activate certain features.
Signal and security icons
Icon Description
Receiving Signal Strength
Indicates the receiving signal strength. Bars indicate the
strength of the signal. Maximum 4 bars indicate
strongest signal.
Transmission Power
Low transmission power for current channel.
High transmission power for current channel.
Security
Analogue scrambling or digital encryption is active.
Emergency
Indicates that the emergency alarm mode is activated.
GPS tracking
GPS feature is available and the terminal is receiving
valid GPS data.
GPS feature is available but the terminal does not have
valid location information.
USB connected
Indicates that USB device is connected.

Quick Reference Guide
7
General icons
Icon Description
New Message
You have an unread message in your mailbox .
Message inbox full
You need to clear your message inbox. If the message
inbox is not cleared, older messages will be deleted
when a new message is received.
Speaker Off
The speaker is muted.
Monitor Channel
Indicates that monitor channel is active.
Talk-around
Indicates that Talk-around is active for repeater mode
or the current channel is in direct mode.
Channel Scanning
Scanning is in process when the icon rotates. Scanning
stops on a priority channel when the centre triangle is
red. Scanning stops on a non-priority channel when the
centre triangle is green.
External Device connected
Indicates that an external microphone or speaker is
connected.
Calls
Icon Description
Initialising a call
Receiving a call
Private call in progress
Group call in progress
All call in progress
LED status indicators
The LEDs on the radio change colour to show the operational status of
your radio.
LED colour Operational State
Solid red In use and transmitting
Solid green In use and receiving voice, short message or
data. Can also indicate channel activity
Solid orange Call hang time period, press PTT to talk back
Flashing orange Emergency state or there is a missed
call/incoming call alert or the radio is
scanning
Flashing red Incoming emergency alarm

DMR Mobile Radio
8
Accessory information
Sepura supply a range of accessories for this product. Contact your
Service Provider or visit our website for a full list of accessories:
http://www.sepura.com/products/terminals/accessories/dmr-
accessories.aspx
Fist microphone
Your mobile is equipped with a standard fist microphone designed for
close-talk mobile communications.
Attach the microphone heavy-duty connector to the Microphone/
programming cable interface connector on the mobile.
When using the microphone, always hold the microphone firmly in
your hand with the microphone facing towards you and in an upright
position. Hold the microphone approximately 5 cm (2 in.) away from
your mouth when speaking.
To talk, press the PTT grip switch during the call hang time period
(when the LED is solid orange) and talk clearly into the microphone.
Release the grip switch when you have finished talking.
Never hold or swing the microphone by the heavy-duty coiled lead.
Note that your mobile can also be used with an optional keypad fist
microphone (part no. 300-01064). This microphone supports the one
touch button feature that lets you make a group or private call to a
predefined alias or ID by pressing one of the predefined numerical
keys (1 to 9). It can also be used to manually dial a contact.
Always secure your microphone using the mounting clip when not in
use.
Basic operation
Power On/Off
To power on, press and hold the Power button.
To power off the radio, press and hold the Power button.
Adjusting the volume
Rotate the Volume control knob clockwise to increase the volume.
Rotate the Volume control knob counter-clockwise to decrease the
volume.
Selecting a Channel
Your Service Provider may program the mobile channels before use.
Each channel can be configured as either an analogue or digital
channel. Note that some functions, such as messages, are not available
on analogue channels.
Press the up/down navigational keys to select a channel.
Making a PTT call
Your mobile may already be programmed with contacts (people and
groups) by your Service Provider. Each group may be allocated to a
different channel. The contact person or group can be programmed as a
private call, group call or All Call.
Call to the default contact group or person
A contact person or group may be added as a default contact.
The default contact is called when you press the PTT button.
You may need to select the channel before making the call.
In the Home display, press the PTT button to initiate a call.

Quick Reference Guide
9
Call a group or person from the contact list
Press the right context key to activate the Contacts menu.
Select the Contacts List option and then press the left context key to
Confirm.
Use the navigation keys to scroll through the list. With the contact
group or person highlighted, press PTT button to initiate a call.
Manually dial a contact group or person
A keypad fist microphone is required to use this feature.
Press the right context key to activate the Contacts menu.
Use the navigation keys to select the Manual Dial option.
Enter the ID number of the group or person.
Press the PTT button to initiate a call.
Receiving a PTT call
When the mobile is in standby mode the green LED will light to
indicate an incoming call. The display changes to show the call type,
either the private call icon or the group call icon, alias or the ID of the
caller. The incoming call icon appears to indicate that the call is being
received. You will hear the person speaking.
Private call incoming
Group call incoming
Press the PTT button to respond to the caller within the hang time
duration (when the LED is solid orange).
You cannot respond to an All Call.
Emergency alarm
Your mobile may not be programmed for an Emergency alarm. If an
alarm is programmed it may not sound an audible alert. Ask your
Service Provider for information on how your radio is programmed for
Emergency alarms.
The Emergency alarm sounds an audible beep and sends an emergency
message to others in your call group and you can talk to others in the
group.
Press and hold the Emergency button until an audible beep sounds.
The Emergency alarm icon appears on the status bar. The alarm group
alias or ID displays on the screen with the Emergency Alarm icon and
outgoing call icon.
Emergency Alarm status icon
Emergency Alarm icon
Outgoing icon
If the emergency call is successful the mobile displays the message
“emergency alarm succeed”. If the alarm call has failed the mobile
displays the message “emergency alarm failed”.
To cancel the emergency alarm call, press and hold the Emergency
button.

Sepura plc
Radio House
St Andrew’s Road
Cambridge
CB4 1GR
UK
Tel: [phone]
Fax: [phone]
Sepura.com
