Serene House Scent Flute 2-Notes Guide

Product name: Scent Flute 2-Notes
Product type: Fragrance Diffuser
Model: 101204002
Instruction Manual & Warranty

Directory
Specications 3
SafetyPrecautions 3-5
PrecautionsforUse 5
Main Body & Components 6
How To Use 7
Maintenance 8
Troubleshooting 9
Warranty 10 - 11
Read all instructions,
especially the safety
precautions, before using
the Fragrance Diffuser.
Keep this manual in a
readily accessible place
after reading it.This
manual is also a warranty.
SAVE THIS MANUAL!
2

Specications
Product name: Scent Flute 2-notes
Model code: 101204002
Heating: Cement resistor
Suggestedroomsize:7–9m²,(75-97s.f.)
Oil container capacity: about 2 x 24ml (2 x 0.8
.oz.)
AC adapter:
Input:ACl00V-240V50/60Hz
Output:DC24V850mA
Rated power: 7W
Productsize:(L)II.Ix(W)6.8x(H)I8cm
((L)4.4x(W)2.7x(H)7.1inches)
Weight::485g,(1.1 lb)(Mainbody, tubesandAC
adapterincluded)
Performance: Continuous mode
Country of origin: China
Accessories:AC adapter & Scented Tube x 2
Patent product
TestedTemperature:24°C,(75°F)
TestedHumidity:65%
TestedSpaceHeight:2m,(6.5feet)
(Test results may vary depending on temperature,
humidityandheightofspace.)
Meanings of images
 Warning/Caution
Prohibited
 Mandatory/Assignedbehavior
Safety precautions
For safety, please be sure to comply with the
following instructions:
•Thesesafetyinstructionsareprovidedtoensure
that customers use the product safely and
correctly and to avoid any physical harm to people
or damage to the device.
•NOTES
“Warning” and “Caution” are important safety
instructions. Be sure to follow these instructions.
Warning
•Mayresultindeathorseriousinjury
Caution
•Maycausepersonalinjuryorlossofproperty
3

Warning
Do not use the product when cord or plug is
damaged or the product has been accidently hit,
dropped, broken or damaged in any way.
Must use AC 100V ~ 240V!
Do not operate the product and AC adapter with
wet hands; electric shock may result.
Stop using the product immediately and unplug the
AC adapter once smoke, smell, unusual sounds or
other anomalies occur.
Must use with the enclosed AC adapter.
Do not connect the main body and AC adapter
during installation.
KEEP OUT OF REACH OF CHILDREN AND
PETS!
Do not modify or dismantle this product.
Children should be supervised to ensure that
they do not play with the product.
The product must be disconnected from the
electrical outlet before user maintenance.
This product is not intended for use by persons
(includingchildren)withreducedphysical,sensory
or mental capabilities, or lack of experience and
knowledge, unless they have
been given supervision or instruction concerning
use of the product by a person responsible for
their safety!
The product is only to be used with the
recommended vaporizing medium. The use of
othersubstancesmaygiverisetoatoxicorre
risk.
Caution
Always unplug the product and pour out the oils
when moving the product or not in operation.
Hold theAC adapter rmly when unplugging it
from electrical outlet.
Do not move the tube or put ngers or other
objectsintothediffuserwheninoperation.
Do not place product on the carpet.
Toavoidre,electricshock,injuryordamage,do
not place the product in the areas listed below:
•Indirectsunlightornexttoaheatingapparatus
•Industyplaces
•Ontilted,unstableorunevensurfaces
•Placesfullofsmokeornexttostoves
4

•Industyplaces
•Ontilted,unstableorunevensurfaces
•Placesfullofsmokeornexttostoves
•Nexttooraboveelectricalproducts(TV,stereo,
refrigerator,etc)
•Next to a high-pressure spray can, such as hair
or spray paint.
Donotbend,heatorplaceheavyobjectsonthe
product.
As you add oil, make sure to wipe away any drops
of oil that may have spilled on the cover of the
main unit.
Notes on environmental protection:
When the product is at the end of its life,
we recommend disposal at a collection point
for the recycling of electrical and electronic
equipment, rather than with household waste.The
symbols on the product, instruction manual and
packaging allow for proper sorting and disposal.
Precautions for Use
•Pleasereadallinstructionsbeforeuse!
•Readthe“HowtoUse”sectiononpages7to8in
this manual for correct operation.
•Makesuretoreadandfollowthe“Maintenance”
section on page 8 in this manual for cleaning and
maintaining.
•Thetubeismadeofglass,pleasehandlewithcare.
•The main unit is made of polished melamine.
Please use with caution.
NOTES ON THE USE OF OILS
MUST USE SERENE HOUSE FRAGRANCE OILS.
•FragranceOilsarehighlyconcentratedoils.
Use with caution.
•Donotspilltheoilsastheymaydamageplastic
objectsandfurniture.
• Be sure to read the instructions before use,
especially during pregnancy.
•Childrenandpetsareverysensitivetofragrance.
Use with caution.
•Stop usingthe productandopen the windows
for ventilation if you start to feel uncomfortable.
•Besuretouseappropriateamountsofoil.
5

Main Body & Components
Scent Flute 2-Notes
(101204002)
Before use, make sure the following items are
complete and intact.
1. Main body
2. Scented tube
3.ACadapter
1. Main body
2. Scented tube
24ml
4.AC adapter
Air Vent
Main body
Heating plate
6

How To Use
1. Place the product on a FIRM, FLAT and LEVEL
surface.
3.InserttheACplugintothesocketofthemain
unit.
4. Plug the AC adapter into electrical outlet and
LED lights will turn on.
5.Ifthefragrancedoesnotdiffuse,pleasestopthe
machine and check if the tube is installed correctly.
Eachtubewillindividuallyoperatefor45minutes
andtakea15-minutesbreakbeforethenexttube
starts. The tubes are programmed to operate in
this sequence.
*It is normal for the AC adapter to become hot
when the product is in use.
1. Insert the scented tubes into the main unit so
thatittstightly.
2. Pour Fragrance Oil into the scent tubes. MUST
USE SERENE HOUSE FRAGRANCE OILS!
7

Caution
•NEVERconnectthepowerwithouttheScented
Tube in the unit.
• NEVER remove the tube while machine is
running.
• Do not use the product continually for more
than 10 hours a day.
•Pleasepourouttheoilsiftheyhaveremainedin
the tube for more than 2 months.
• Be sure to wipe clean with a cloth any oil
dropletsthatlandontheproductbodyoroor.
• Do not move or touch when in use. Always
disconnect the AC adaptor from the electrical
outlet before cleaning or handling.
*Allow container to cool thoroughly before
handling.
Maintenance
ALWAYS DISCONNECT THE AC ADAPTER
FROM THE ELECTRICAL OUTLET BEFORE
CLEANING
The product requires regular cleaning. Clean once
a week at least. If using it every day, be sure to
cleanitevery3-4days.
Refer to and follow the cleaning instructions.
1.Unplug the AC adapter from the electrical outlet.
2.Remove the scent tube from the main unit.
Discard the used Fragrance Oil and clean the tube
with neutral detergent and clean water. Dry the
scent tube before putting it back into the main
unit.
3.Wipethe main unit with a clean cloth using a
few NEUTRAL detergents.Wipe dry to avoid any
detergent residue.
*DO NOT USE ACID DETERGENTS.
* Pay attention while cleaning.
* DO NOT CLEAN UNDER TAP DIRECTLY!
BE SURETO CLEAN REGULARLY IN ORDERTO
AVOID MALFUNCTION!
8

Condition Reason Solution
Machine does not run
AC adapter is not fully and
correctly inserted into the
electrical outlet
Make sure the adapter is fully and
correctly inserted into the electrical
outlet
Plug is not inserted correctly into
the body socket
Make sure plug is inserted into the
body socket correctly
There is not enough
fragrance
The oils contain too many
chemical additives Use SERENE HOUSE Fragrance Oils
There is not enough oil Add more Fragrance Oil into the
scent tube
The scent tube is dirty Follow the Maintenance instructions
on page 8
Troubleshooting
Review the following steps listed below to insure proper operation.
9

Product name & Model
Guarantee Period
Two year from the date of original purchase. (There is no warranty with respect
to the following which may be supplied with this product. They are included
ceramicchip,cleaningbrush,pipette,scrapingspoon,scentedtube.)
The date of purchase
Customer
information
Name
Te l
Address
E-mail
Retailer
Name
Address
Warranty
USA and Canada Serene House customers may send a Warranty Claim via email to:
serene-housewar[email protected]
You will need to provide the information noted below along with a copy of the original purchase receipt.
10

SERENE HOUSE INTERNATIONAL ENTERPRISE LTD. guarantees this product is free from defects in
material and workmanship for a period of two years from the date of original purchase, except as noted
below.
This product warranty does not cover damage caused by misuse or abuse;accidents; the attachment of any
unauthorized accessory; alteration to the product; or any other conditions whatsoever that are beyond
the control of SERENE HOUSE.This warranty is effective only if the product is purchased and all the
informationintheformaboveiscompleted.Aproductthatrequiresmodicationoradaptationtoenable
it to operate in any country other than the country for which it was designed, manufactured, approved
and/orauthorized,orrepairofproductsdamagedbythesemodicationsisnotcoveredunderwarranty.
SERENE HOUSE shall not be responsible for any type of incidental, consequential or special damages. All
impliedwarranties,includingbutnotlimitedtothoseimpliedwarrantiesoftnessandmerchantability,are
limited in total duration of two years from original purchase date.
The above content is limited to countries or regions in which the product purchase took place. If there is
any problem to the product, please contact with the original product store.
11

Contact SERENE HOUSE at:
SERENE HOUSE INTERNATIONAL ENTERPRISE LTD.
Rm.2,2F.,No.15,Sec.2,TidingBlvd.,NeihuDist.,TaipeiCity11493,Taiwan(R.O.C.)
Tel:[phone]
Fax:[phone]
E-mail: [email protected]
www.serene-house.com
