SereneLife PUCRCX10 User manual

SmartVacuumCleaner
PUCRCX10
Automatic Robot Cleaning Vacuum, Includes Remote Control
for Cleaning Modes and Robot Directions

www.SereneLifeHome.com2
Please read this manual carefully before using the product,
and keep it in a safe place for future reference.
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
ABOUT YOUR SWEEPING ROBOT
USING YOUR SWEEPING ROBOT
1. IMPORTANT TIPS BEFORE USE
2. PREPARATION
3. OPERATION
4. CHARGING
CLEANING AND MAINTENANCE
TROUBLESHOOTING
DISPOSAL
SPECIFICATION
3
4
8
8
9
10
11
12
15
15
17

IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of injury or damage, read these safety instructions carefully
and keep them at hand when setting up, using, and maintaining this device.
• This device can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
this device in a safe way and understand the hazards involved.
• Children should be supervised to ensure they do not play with this device.
• Cleaning and maintenance shall not be performed by children without adult
supervision.
• This device is only to be used with the power supply unit provided.
• For the purposes of recharging the battery, only use the detachable power supply
unit provided with this device.
• The used battery should be placed in a sealed plastic bag and disposed of safely
according to local environmental regulations.
• The external exible cable or cord of the power supply unit cannot be replaced;
if the cord is damaged, the power supply unit shall be disposed of.
• This device is for indoor use only.
• This device is not a toy. Do not sit or stand on this device. Small children and pets
should be supervised when this device is operating.
• Store and operate this device in room temperature environments only.
• Do not use this device to pick up anything that is burning or smoking.
• Do not use this device to pick up spills of bleach, paint, chemicals, or anything wet.
• Before using this device, pick up objects like clothing and loose paper. Lift up cords
for blinds or curtains, and move power cords and fragile objects out of the way.
If this device passes over a power cord and drags it, an object could be pulled off
a table or shelf.
• Be aware that this device moves around on its own. Take care when walking in
the area where this device is operating to avoid stepping on it.
• Do not operate this device in areas with exposed electrical outlets on the oor.
• Do not use this device on an unnished, unsealed, waxed or rough oor. It may
result in damage to the oor and this device. Use only on hard oor surfaces or
lowpile carpet.
• This device has been designed to be used on oors without scratching them.
We still recommend that you test this device on a small area of the room to be
cleaned to ensure no scratches are made before cleaning the whole room.
• Unplug it when not in use. Turn if off before cleaning and maintaining.
• Remove batteries in the remote control before long period storage.
www.SereneLifeHome.com 3

ABOUT YOUR SWEEPING ROBOT
1. What’s in the box
Main Body x1 Power Adapter x1 Remote control x1
Side Brushes x 2 Additional High
Performance Filter x1 Brush x1
Mop Assembly x1 Manual x1
www.SereneLifeHome.com4

ABOUT YOUR SWEEPING ROBOT
2. Top & Side
Swivelling Cover
Dust bin
Power adaptor
socket
Power switch
Signal Receiver
Bumper
Start button
Swivelling Cover
www.SereneLifeHome.com 5

ABOUT YOUR SWEEPING ROBOT
3. Bottom
4. Dustin Collector
Front Wheel
Cliff Detect Sensor
Left brush
Cliff Detect
Sensor
Air intake
Left Wheel
Install Socket
Right brush
Cliff Detect
Sensor
Battery cover
Right wheel
Bottom Casing
H10 Filter
H10 support
Primary Filter
Dust bin
www.SereneLifeHome.com6

ABOUT YOUR SWEEPING ROBOT
5. Remote Control
Find the robot
Start cleaning
Stop cleaning
Start edge cleaning
Start focus cleaning
Start random cleaning
www.SereneLifeHome.com 7

USING YOUR SWEEPING ROBOT
1. Important Tips Before Use
A. Remove power cords and small objects from the oor that may entangle robot
B. Fold tasseled edges of area rugs underneath to prevent tangling robot. Avoid
cleaning very dark colored high-pile rugs or rugs thicker than 26 mm as they may
cause robot to malfunction.
C. Keep robot away from spaces lower than 70 mm to prevent robot from getting
stuck. If necessary, place a physical barrier to block off the problem areas.
D. Keep robot away from wet areas.
E. Robot may climb on top of objects less than 16 mm in height. Remove these
objects if possible.
F. Anti-drop sensors prevent robot from tumbling down stairs and steep drops.
They may work less effectively if dirty or used on reective/very dark colored
oors. It is recommended to place physical barriers to block off areas where
robot may fall.
www.SereneLifeHome.com8

USING YOUR SWEEPING ROBOT
2. Preparation
2.1. Install the side brushes before use.
2.2. Turn on the main power switch on the side of host
www.SereneLifeHome.com 9

USING YOUR SWEEPING ROBOT
3. Operation
3.1.1. Press on robot or on the remote control to start cleaning in Auto
Mode. (When the machine is working, the "Start/Pause" light will be solid blue.)
3.1.2. Press on robot or on the remote control to stop cleaning.
3.2. Select a Cleaning Mode
3.2.1. Edge Cleaning
Robot reduces its speed when it detects a wall and then follows the wall to
ensure the edge is cleaned thoroughly. After cleaning, it will turn to auto
cleaning.
Press on the remote control to start cleaning in Edge mode. It detects a wall
and then follows the wall to ensure the edge is cleaned thoroughly.
www.SereneLifeHome.com10
