IN-SV04-02
REV 04/30/04
If you have any questions concerning this bulletin, please contact Manitowoc Beverage Equipment’s Technical Service Department at [phone]
Foodservice Group
MD-150, MD-200, and MD-250
Duratran/Medallion Replacement
FIGURE 1
Knurl Screws
Tools Required
z6 in 1 screw driver
1
1. Disconnect power to the dispenser.
2. Remove full lid or manual fill lid from unit.
3. Remove the 2 Knurl screws from top of merchandiser.
(See Figure 1)
4. Remove the merchandiser from the unit. (See Figure 2)
5. Remove the seven screws from around the outer top and
bottom edges of the merchandiser. (See Figures 3&4)
(The screws are threaded into rubber bumpers inside the
merchandiser. This will free the medallion for removal)
(See Figure 5)
6. Remove the existing medallion from the merchandiser.
(See Figure 6)
FIGURE 2 FIGURE 3
3 Bumber Screws on top of merchandiser

IN-SV04-02
REV 04/30/04
If you have any questions concerning this bulletin, please contact Manitowoc Beverage Equipment’s Technical Service Department at [phone]
Foodservice Group
MD-150, MD-200, and MD-250
Duratran/Medallion Replacement
FIGURE 6
7. Place the new medallion into the merchandiser. (Be sure
the medallion is right side up.)
8. Replace the seven outer screws and bumpers into the
merchandiser (Screws go on the outside of the merchan-
diser and bumpers go inside of the merchandiser. The
bumpers are what the screws thread into.)
9. Replace the merchandiser in reverse order.
10. Re-install lid.
11. Reconnect power to the dispenser.
FIGURE 4
4 Bumper Screws on bottom of merchandiser
FIGURE 5
Rubber Bumpers
