Servotronix softMC 3 User manual

softMC 3
Multi-Axis Motion Controller
Installation Guide
Document Rev. 3.3

softMC 3
Installation Guide 3
Revision History
Doc.
Rev.
Date Remarks
3.3 Dec. 2016 Updated RS232 interface pinout; new ordering format
3.2 Nov. 2016 Updated cabling diagrams and instructions, ordering info.
3.1 Apr. 2016 RS232 correction
3.0 Mar. 2016 softMC 3 product release.
2.2 24 Sept. 2015 Weight specification updated.
2.1 10 June 2015 Minor fix. Updated ordering options.
2.0 27 May 2015 Wiring info. Updates.
1.0 1 Sept. 2014 Initial release
Copyright Notice
© 2016 Servotronix Motion Control Ltd.
All rights reserved. No part of this work may be reproduced or transmitted in any
form or by any means without prior written permission of Servotronix.
Disclaimer
This product documentation was accurate and reliable at the time of its release.
Servotronix Motion Control Ltd. reserves the right to change the specifications of
the product described in this manual without notice at any time.
Trademarks
softMC 3 and ControlStudio are trademarks of Servotronix Motion Control Ltd.
CANopen and CiA are registered trademarks of the CAN in Automation User's
Group
EtherCAT is a registered trademark and patented technology, licensed by
Beckhoff Automation GmbH
Windows is a registered trademark of Microsoft Corporation
Contact Information
Servotronix Motion Control Ltd.
21C Yagia Kapayim Street
Petach Tikva 49130, Israel
Tel: [phone]
Fax: [phone]
Website: www.servotronix.com
Technical Support
If you need assistance with the installation and configuration of the softMC 3
controller, contact Servotronix Technical Support: [e-mail]

softMC 3
4 Installation Guide
Ordering Options
MC E 06 702 0000
softMC Motion Controller
Fieldbus
E EtherCAT
C CANopen
B EtherCAT and CANopen (702 only)
Number of Axes
04, 06 4, 6 axes
08, 16, 32 8, 16, 32 axes
Other number of axes available upon request
Hardware Options
301 softMC 3 – ARM, for 4 to 6 axes
702 softMC 7 – Atom, for 8 to 32 axes
705 softMC 7 – CORE i5, for 8 to 32 axes.
Check availability – contact Servotronix
Options (when available)
Software Add-On
Part Number Item
FW -MC03-CODESYS IEC 61131 CODESYS for softMC 3 – upcoming
FW -MC07-CODESYS IEC 61131 CODESYS for softMC 7

softMC 3
Installation Guide 5
Contents
1Product Description __________________________________________ 7
1.1 Product Overview....................................................................................... 7
1.2 Product Package ........................................................................................ 8
1.3 Technical Specifications .............................................................................. 9
1.4 Dimensions..............................................................................................10
2Safety ____________________________________________________ 11
2.1 Anti-Static Precautions ..............................................................................11
2.2 Installation Precautions .............................................................................11
2.3 General Safety Precautions ........................................................................12
3Installation Preparation ______________________________________ 13
3.1 Required Computer System........................................................................13
3.2 IP Address ...............................................................................................13
3.3 Required Tools .........................................................................................13
3.4 Required Cables .......................................................................................14
3.5 Interfaces ................................................................................................14
4Installation Procedure _______________________________________ 17
4.1 DIN Rail Mounting (Optional)......................................................................17
4.2 Cable Connections ....................................................................................17
4.3 Connecting softMC 3 and CDHD – CANopen Models.......................................18
4.4 Connecting softMC 3 and CDHD – EtherCAT Models.......................................19
4.5 Connecting softMC 3 and stepIM – CANopen Models......................................20
4.6 ControlStudio Software Installation .............................................................21
4.7 Serial Communication ...............................................................................21
4.8 IP Address ...............................................................................................24
4.8.1 Get an IP Address from a DHCP Server.............................................24
4.8.2 Manually Assign an IP Address Using ControlStudio............................24
4.8.3 Define a Fixed IP Address ...............................................................26

Product Description softMC 3
Installation Guide 7
1Product Description
1.1 Product Overview
The softMC 3 is a multi-axis motion control software and hardware package
offering extensive programming capabilities for a variety of automation and
robotics applications.
The product has two models that are identical in appearance: EtherCAT and
CANopen. They are distinguished by the product label on the back panel.
Figure 1-1. softMC 3 Product Labels

softMC 3 Product Description
8 Installation Guide
1.2 Product Package
The following table lists all components included in the softMC 3 product
package.
Notes: The DIN rail and bracket are assembled at factory.
Both book and DIN rail mounting are supplied. Either can be used.
Power supply adapter and cables are not included in the softMC 3
package.
If any of the components in this list are missing, do not proceed with the
installation. Contact Servotronix: [e-mail]
Table 1-1. Product Components
Image Servotronix PN Item Qty
MC-xxx-301-0000 softMC 3 multi-axis motion controller,
equipped with SD card loaded with softMC
firmware (factory installed)
1
CONr10000002M47 2-pin terminal block
Plug component
Nominal current: 8 A
Rated voltage (III/2): 160 V
Number of positions: 2
Pitch: 3.81 mm
Screw connection with tension sleeve
16-28 AWG
Phoenix PN:MC 1,5/2-STF-3,81-1827703
1
CONr10000003M08 3-pin terminal
Receptacle housing
Current rating: 5 A
Rated voltage: 600 V
Number of positions: 3
Number of rows: 1
Pitch: 3 mm
Molex PN: 43645-0300 (Micro-Fit 3.0™)
1
CRPr16020069M00 3-crimp terminal
Connector socket
24-30 AWG
Molex PN: 0016020069
1
MECr16000009-02 Book mounting bracket 1

Product Description softMC 3
Installation Guide 9
Image Servotronix PN Item Qty
MECr16000008-02 DIN mounting bracket 1
MECr12015780-00 DIN rail adapter.
L=42.6, H=19, W=10 [mm]
Phoenix PN: USA 10 - 1201578
1
SCRr000000M3-60 DIN screw, for attaching DIN rail to
bracket
3
SCRr000000M3-60 Mounting bracket screw, for attaching
bracket to softMC 3
2
1.3 Technical Specifications
Table 1-2. Technical Specifications
Feature Specification
System CPU ARM Cortex A9 processor
Chipset iMX6
Memory 512 MB 800 MHz DDR3
Ethernet Controller 1x GbE
Storage Micro SD 1 x Micro SD card slot,
industrial grade, single level cell (SLC) card,
factory-installed softMC firmware
I/Os and
Indicators
Ethernet 1 x RJ45 port
EtherCAT or CAN Bus 1 x RJ45 port
RS232 Service port (3-pin terminal)
USB 2x USB for future used
Display Status LEDs: orange/green, red
Power Power Input 18V–28V DC (2-pin terminal block)
Power Consumption 24V@150mA
Environmental
and
Mechanical
Mounting DIN rail or book mount
Operating Temp. 0°C–45°C
Storage Temp. 0°C–70°C
Humidity 10%–90%, non-condensing
Vibration 1.0 g
Protection
class/Pollution degree
Protection class: IP20, pollution degree: 2 as
per IEC 60664-1
Do not use in the following locations: corrosive
or flammable gasses, water oil or chemical,
dust including iron dust and salts
Compliance CE Pending
Weight 0.2 kg
Physical Dimensions 32.5 mm x 99.5 mm x 74.3 mm (WxHxD)

softMC 3 Product Description
10 Installation Guide
1.4 Dimensions
Figure 1-2. softMC 3 Dimensions – Book Mount
Figure 1-3. softMC 3 Dimensions – DIN Rail Mount
