Setma r.LiNK-Interface E09PO28003 User manual

Version 24.10.2018
r.LiNK-Interface
E09PO28003
Rear and front camera input
incl. video-in-motion
compatible with Porsche vehicles with
PCM 3 and PCM 3.1 navigation systems
Product features
• Plug and play interface
• Integrated into the vehicle infotainment
• Rear-view camera input (+ coding)
•Front camera input
• Rear-view and front camera power (+12V max. 1A)
• Video-in-motion
• Automatic switching to rear-view camera input
• Optionally coding of ParkAssistant to retrofit factory PDC

Version 24.10.2018
Page1"
Contents
1. Prior to installation
1.1. Delivery contents
1.2. Check compatibility of vehicle and accessories
1.3. Setting the Dip-switches of the Interface-Box RLC-M40-2
1.4. Pin-assignments
2. Connection schema
3. Installation
3.1. Interconnecting interface-Box, harness and factory head unit
3.2. Connections to after market rear-view camera
3.3. Connections to OEM rear-view camera
3.4. Connections to front camera
4. Coding of the camera function
4.1. Coding of the rear-view camera (only PCM3.1)
4.1.1. Decoding of the rear-view camera (only PCM3.1)
4.2. Optionally coding of ParkAssistant to retrofit factory PDC (only PCM3.1)
4.2.1. Decoding of the ParkAssistant (only PCM3.1)
4.3. Alternatively coding and decoding of rear-view camera and ParkAssistant (e.g.
if steering-wheel buttons not existing, only PCM3.1)
4.4. Coding and decoding of rear-view camera (only Porsche Cayenne with PCM3)
4.5. LED information
5. Manually front camera activation
6. Specifications
7. Technical support
Legal Information
By law, watching moving pictures while driving is prohibited, the driver must not be
distracted. We do not accept any liability for material damage or personal injury resulting,
directly or indirectly, from installation or operation of this product. This product should only
be used while standing or to display fixed menus or rear-view-camera video when the
vehicle is moving, for example the MP3 menu for DVD upgrades.
Changes/updates of the vehicle’s software can cause malfunctions of the interface. We
offer free software-updates for our interfaces for one year after purchase. To receive a free
update, the interface must be sent in at own cost. Labor cost for and other expenses
involved with the software-updates will not be refunded.

Version 24.10.2018
Page2"
1. Prior to installation
Read the manual prior to installation. Technical knowledge is necessary for installation. The
place of installation must be free of moisture and away from heat sources.
1.1. Delivery contents
1.2. Check compatibility of vehicle and accessories
Take down the SW-version and HW-version of the interface boxes, and store this
manual for support purposes.
Requirements
Vehicle Porsche Cayenne, Panamera, 911, Boxster, Cayman, Macan
Navigation PCM 3 (only Cayenne version) , PCM 3.1 (911, Boxster and
Cayman only from software version 4.xx)
Limitations
Video-in-motion Internal DVD video cannot be watched!
Harness
RLC-POR03-2
Interface-box
RLC-M40-2
HW_____ SW_____

Version 24.10.2018
Page3"
1.3. Setting the dip switches of the interface-box RLC-M40-2
Vehicle/ navigation
Dip 1
Dip 2
Dip 3
Dip 4
Dip 5
Dip 6
PCM 3 with video-in-motion activated
ON
ON
OFF
OFF
OFF
OFF
PCM 3 with video-in-motion deactivated
OFF
ON
OFF
OFF
OFF
OFF
PCM 3.1 with video-in-motion activated
ON
ON
OFF
OFF
OFF
ON
PCM 3.1 with video-in-motion deactivated
OFF
ON
OFF
OFF
OFF
ON
Note: Dip switch functions of the interface-box RLC-M40-2
Dip 1 – Activation video in motion
Dip 2 – OEM- or aftermarket- rear view camera existing
Dip 3 – Coding rear-view camera in conjunction with Dip 5
Dip 4 – Coding ParkAssistant in conjunction with Dip 5 (only PCM3.1, PCM3 no function)
Dip 5 – Camera / ParkAssistant coding (DIP switch for 5 sec. in ON position)
Dip 6 – CAN-bus termination
1.4. Pin-assignments
Pin-assignment factory connector
No liability for vehicle wire colors and pin definition!
Possible changes by the vehicle manufacturer. The given
information must be verified by the installer.
Pin-assignment of the interface-box RLC-M40-2 (Molex 12pin)
Cable colour
Pin-No.
Assignment
●Yellow
Pin 6
CAN-HIGH – connection to the head-unit
●Blue
Pin 5
CAN-LOW – connection to the head-unit
●●Yellow/Black
Pin 12
CAN-HIGH – connection to the vehicle
●●Blue/Black
Pin 11
CAN-LOW – connection to the vehicle
●Red
Pin 1
+12V permanent
●Black
Pin 7
Ground
●Green
Pin 2
+12V rear view camera output (max. 1A)
●White
Pin 3
+12V front camera output (max. 1A)
●Blue
Pin 4
No function
●Yellow
Pin 8
Rear view camera video signal input
●Yellow
Pin 10
Front camera video signal input
●Transparent
Pin 9
Camera video signal output
Cable colour
Assignment
Pin No.
●Red
+12V battery
Pin 15
●Black
Ground
Pin 12
●●Orange/brown
CAN-low
Pin 9
●●Orange/purple
CAN-high
Pin 11

Version 24.10.2018
Page4"
2. Connection schema

Version 24.10.2018
Page5"
3. Installation
Switch off ignition and disconnect the vehicle’s battery! If according to factory rules
disconnecting the battery has to be avoided, it is usually sufficient to put the vehicle in
sleep-mode. In case the sleep-mode does not show success, disconnect the battery with a
resistor lead.
Place of installation is on rear of the head unit.
3.1. Interconnecting interface-Box, harness and factory head unit
Connect female 12pin Molex connector of harness RLC-POR03-2 to male 12pin Molex
connector of CAN-box RLC-M40-2.
Remove the female Quadlock connector of the vehicle harness from the rear of the
head unit and connect it to the male Quadlock connector of harness RLC-POR03-2.
2
1

Version 24.10.2018
Page6"
Connect female Quadlock connector of harness RLC-POR03-2 to the male Quadlock
connector of the head unit.
3.2. Connections to after market rear-view camera
Connect the video RCA of the rear-view camera to the female RCA connector with the
label „Rear-view camera“ of RLC-POR03-2 harness.
Connect the green cable of harness RLC-POR03 to the camera power supply (+12V
max 1A). The green cable is high when reverse gear is engaged (if ignition is off, too).
The power will be deactivated from a speed of 20 km/h.
Note: Only compatible with NTSC-cameras.
3.3. Connections to OEM rear-view camera
Connect the male RCA plug to the female RCA connector with the label „Rear-view
camera“ from RLC-POR03-2 harness.
1
3
2
1

Version 24.10.2018
Page7"
3.4. Connections to front camera
Connect the video RCA of the front camera to the female RCA connector with the
label „Front-view camera“ of RLC-POR03-2 harness.
Connect the white cable of harness RLC-POR03-2 to the camera power supply (+12V
max 1A). The white cable is high when reverse gear is engaged (if ignition is off, too).
The power will be deactivated from a speed of 20 km/h.
Note: Only compatible with NTSC-cameras.
2
1

Version 24.10.2018
Page8"
4. Coding of the camera function
4.1. Coding of the rear-view camera (only PCM3.1)
It is necessary to code the rear-view camera input of the PCM 3.1 to use it for an after-
market rear-view camera.
1. Turn on ignition
2. Wait until the head-unit has booted
3. Press and hold steering-wheel button HASH KEY/MODE
4. Press and hold steering-wheel button ACCEPT (observe the sequence!)
5. Hold both buttons. During configuration the red and
blue LED are blinking short inside the CAN-box (visible
at the male 8pin Molex connector). The PCM makes a
reset after 5-10 sec.
6. Disengage both steering-wheel buttons
7. The red and the blue LED inside the CAN-Box are
glowing and the menu „Rear-view camera“ appears in
the menu OPTION after a successful coding
4.1.1. Decoding of the rear-view camera (only PCM3.1)
It is possible to decode the coding of the rear-view camera input as follows:
1. Turn on ignition
2. Wait until the head-unit has booted
3. Press and hold steering-wheel button HASH KEY/MODE
4. Press and hold steering-wheel button HANG UP (observe the sequence!)
5. Hold both buttons. During configuration the red and blue LED are blinking inside the
CAN-box (visible at the male 8pin Molex connector). The PCM makes a reset after 5-
10 sec.
6. Disengage both steering-wheel buttons
7. The red and the blue LED inside the CAN-Box are glowing and the menu „Rear-view
camera“ disappears in the menu OPTION after a successful decoding
Steering-wheel buttons left
Steering-wheel buttons right
BACK
HANG UP
HASH KEY/MODE
ACCEPT

Version 24.10.2018
Page9"
4.2. Optionally coding of ParkAssistant to retrofit factory PDC (only PCM3.1)
It is necessary to code the ParkAssistant of the PCM 3.1 to retrofit factory PDC.
1. Turn on ignition
2. Wait until the head-unit has booted
3. Press and hold steering-wheel button BACK
4. Press and hold steering-wheel button ACCEPT (observe the sequence!)
5. Hold both buttons. During configuration the red and
blue LED are blinking inside the CAN-box (visible at the
male 8pin Molex connector). The PCM makes a reset
after 5-10 sec.
6. Disengage both steering-wheel buttons
7. The red and the blue LED inside the CAN-Box are
glowing and the menu „ParkAssistant“ appears in the
menu OPTION after a successful coding
4.2.1. Decoding of the ParkAssistant (only PCM3.1)
It is possible to decode the ParkAssistant as follows:
1. Turn on ignition
2. Wait until the head-unit has booted
3. Press and hold steering-wheel button BACK
4. Press and hold steering-wheel button HANG UP (observe the sequence!)
5. Hold both buttons. During configuration the red and blue LED are blinking inside the
CAN-box (visible at the male 8pin Molex connector). The PCM makes a reset after 5-
10 sec.
6. Disengage both steering-wheel buttons
7. The red and the blue LED inside the CAN-Box are glowing and the menu
„ParkAssistant“ disappears in the menu OPTION after a successful decoding
Steering-wheel buttons left
Steering-wheel buttons right
BACK
HANG UP
HASH KEY/MODE
ACCEPT

Version 24.10.2018
Page10"
4.3. Alternatively coding and decoding of rear-view camera and ParkAssistant (e.g. if
steering-wheel buttons not existing, only PCM3.1)
Alternatively to coding by steering-wheel buttons the coding and decoding of rear-view
camera and ParkAssistant can be done by Dip 5 in conjunction with dip 3 and 4 of interface-
box RLC-M40-2.
1. Set dip switch “5” to OFF position
2. Turn on ignition
3. Wait until the head-unit has booted
4. Set dip “3” and dip “4” of CAN-box (depending on the desired coding/decoding)
5. Set dip switch “5” for 5 sec. to ON position
6. During configuration the red and blue LED are blinking
short inside the CAN-box (visible at the male 8pin Molex
connector). The PCM makes a reset after 5-10 sec.
7. The red and the blue LED inside the CAN-Box are
glowing and the menu „Rear-view camera“ respectively
“ParkAssistant” appears in the menu OPTION after a
successful coding (or disappears after successful
decoding)
Note: After a coding or decoding another coding isn’t possible within the next 60 seconds!
If there are factory-PDC existing in the car you have to set Dip 4 to ON while coding. If not
the factory PDC will be decoded!
Dip
Function
ON
OFF
Dip 3
Rear-view camera
Coding
Decoding
Dip 4
ParkAssistant
Coding
Decoding
Dip 5
Activation of the coding/decoding process
5 sec. = start
Default setting
BACK

Version 24.10.2018
Page11"
4.4. Coding and decoding of rear-view camera (only Porsche Cayenne with PCM3)
The rear-view camera coding and decoding can be done by Dip 5 in conjunction with dip 3 of
interface-box RLC-M40-2.
1. Set dip switch “5” to OFF position
2. Turn on ignition
3. Wait until the head-unit has booted
4. Set dip “3” of CAN-box (depending on the desired coding/decoding)
5. Set dip switch “5” for 5 sec. to ON position
6. During configuration the red and blue LED are blinking short inside the CAN-box
(visible at the male 8pin Molex connector). The PCM
makes a reset after 5-10 sec.
7. The red and the blue LED inside the CAN-Box are
glowing and the menu „Rear-view camera“ appears in
the menu OPTION after a successful coding (or
disappears after successful decoding)
Note: After a coding or decoding another coding isn’t possible within the next 60 seconds!
4.5. LED information
5. Manually front camera activation
Press the HANG UP button on the steering wheel for 3 sec.
for manually front camera activation / deactivation.
Dip
Function
ON
OFF
Dip 3
Rear-view camera
Coding
Decoding
Dip 5
Activation of the coding/decoding process
5 sec. = start
Default setting
LED
Status
Explication
Blue
Lights
CAN bus communication OK
Flashes
CAN bus search
Red
Lights
Rear-view camera is coded
Off
Rear-view camera is not coded
HANG UP
