Sharp Aquos LC32D41U User manual

LC-32D41U
LIQUID CRYSTAL TELEVISION
TÉLÉVISEUR ACL
TELEVISOR CON PANTALLA
DE CRISTAL LÍQUIDO
ENGLISHFRANÇAISESPAÑOL
OPERATION MANUAL
MODE D’EMPLOI
MANUAL DE OPERACIÓN
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430-2135
SHARP CORPORATION
Printed in Mexico
Imprimé au Mexique
Impreso en México
TINS-C538WJZZ
06P06-MX-NG
LC-32D41U OPERATION MANUAL MODE D’EMPLOI MANUAL DE OPERACIÓN

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING:
The lightning flash with arrow-head
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a
triangle is intended to alert the user
to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the product.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
1
LC-32D41U
OPERATION MANUAL
• The illustrations and on-screen displays in this operation
manual are for explanation purposes and may vary slightly
from the actual operations.
• Menu items that are not selectable are grayed out.
IMPORTANT:
To aid reporting in case of loss or theft, please record the
TV's model and serial numbers in the space provided. The
numbers are located at the rear of the TV.
Model No.:
Serial No.:
LIQUID CRYSTAL TELEVISION
ENGLISH
IMPORTANT INFORMATION
ENGLISH
32D41U_en_a.indd 132D41U_en_a.indd 1 2006/05/17 11:48:582006/05/17 11:48:58

IMPORTANT INFORMATION
Trademarks
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO
WIDE SLOT, FULLY INSERT.
CAUTION:
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly
approved by the manufacturer could void the user's authority to operate this equipment.
“Note to CATV system installer: This reminder is provided to call the CATV system installer's attention to Article 820-40 of the
National Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of cable entry as practical.”
This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury. Disposal of these materials may be
regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the
Electronic Industries Alliance: www.eia.org
CAUTION:
This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other
equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use
shielded cables and connectors for connections.
INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
DECLARATION OF CONFORMITY:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
RESPONSIBLE PARTY:
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430-2135
TEL: 1-800-BE-SHARP
For Business Customers: URL http://www. sharpusa. com
CAUTION:
DO NOT PLACE THIS PRODUCT ON AN UNSTABLE CART, STAND, TRIPOD, BRACKET, OR
TABLE. THE PRODUCT MAY FALL CAUSING SERIOUS PERSONAL INJURY AND SERIOUS
DAMAGE TO THE PRODUCT. USE ONLY WITH A CART, STAND, TRIPOD, BRACKET, OR TABLE
RECOMMENDED BY THE MANUFACTURER OR SOLD WITH THE PRODUCT. FOLLOW THE
MANUFACTURER'S INSTRUCTIONS WHEN INSTALLING THE PRODUCT AND USE MOUNTING
ACCESSORIES RECOMMENDED BY THE MANUFACTURER. A PRODUCT AND CART
COMBINATION SHOULD BE MOVED WITH CARE. QUICK STOPS, EXCESSIVE FORCE, AND
UNEVEN SURFACES MAY CAUSE THE PRODUCT AND CART COMBINATION TO OVERTURN.
2
• Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby
Laboratories.
• “HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.”
SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-32D41U
32D41U_en_a.indd 232D41U_en_a.indd 2 2006/05/17 11:48:592006/05/17 11:48:59

Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if
improperly handled. This product has been engineered and manufactured with the highest priority on safety. However,
improper use can result in electric shock and/or fire. In order to prevent potential danger, please observe the following
instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service life of
your Liquid Crystal Television, please read the following precautions carefully before using the product.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or
the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in
any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
Additional Safety Information
15) Power Sources—This product should be operated only from the type of power source indicated on the marking
label. If you are not sure of the type of power supply to your home, consult your product dealer or local power
company. For products intended to operate from battery power, or other sources, refer to the operating
instructions.
16) Overloading—Do not overload wall outlets, extension cords, or integral convenience receptacles as this can
result in a risk of fire or electric shock.
17) Object and Liquid Entry—Never push objects of any kind into this product through openings as they may touch
dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any
kind on the product.
18) Damage Requiring Service—Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a) When the AC cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as an improper adjustment of other
controls may result in damage and will often require extensive work by a qualified technician to restore the
product to its normal operation,
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this indicates a need for service.
19) Replacement Parts—When replacement parts are required, be sure the service technician has used replacement
parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other hazards.
20) Safety Check—Upon completion of any service or repairs to this product, ask the service technician to perform
safety checks to determine that the product is in proper operating condition.
21) Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the product
according to the method recommended by the manufacturer.
3
DEAR SHARP CUSTOMER
Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure safety and many years
of trouble-free operation of your product, please read the Important Safety Instructions carefully before
using this product.
IMPORTANT SAFETY INSTRUCTIONS
32D41U_en_a.indd 332D41U_en_a.indd 3 2006/05/17 11:49:002006/05/17 11:49:00

IMPORTANT SAFETY INSTRUCTIONS
4
• Water and Moisture — Do not use this product near water - for example, near a bath tub, wash
bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.
• Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the
product on an unstable base can cause the product to fall, resulting in serious personal injuries
as well as damage to the product. Use only a cart, stand, tripod, bracket or table recommended
by the manufacturer or sold with the product. When mounting the product on a wall, be sure to
follow the manufacturer's instructions. Use only the mounting hardware recommended by the
manufacturer.
• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not
cover or block these vents and openings since insufficient ventilation can cause overheating
and/or shorten the life of the product. Do not place the product on a bed, sofa, rug or other
similar surface, since they can block ventilation openings. This product is not designed for built-
in installation; do not place the product in an enclosed place such as a bookcase or rack, unless
proper ventilation is provided or the manufacturer's instructions are followed.
• Heat — The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products (including amplifiers) that produce heat.
• The Liquid Crystal panel is a very high technology product with 3,147,264 thin film transistors, giving you fine picture
details.
Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or red. Please note that this
does not affect the performance of your product.
Precautions when transporting the TV
• When transporting the TV, never carry it by holding onto the speakers. Be sure to always
carry the TV by two people holding it with two hands — one hand on each side of the TV.
• The Liquid Crystal panel used in this product is made of glass. Therefore, it can break when the
product is dropped or applied with impact. Be careful not to be injured by broken glass pieces
in case the panel breaks.
• Lightning — For added protection for this television equipment during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it from the wall outlet
and disconnect the antenna. This will prevent damage to the equipment due to lightning and
power-line surges.
• Power Lines — An outside antenna system should not be located in the vicinity of overhead
power lines or other electric light or power circuits, or where it can fall into such power lines
or circuits. When installing an outside antenna system, extreme care should be taken to keep
from touching such power lines or circuits as contact with them might be fatal.
• Selecting the location — Select a place with no direct sunlight and good ventilation.
32D41U_en_a.indd 432D41U_en_a.indd 4 2006/05/17 11:49:012006/05/17 11:49:01

5
• Outdoor Antenna Grounding — If an outside antenna is connected to the television equipment, be sure the antenna
system is grounded so as to provide some protection against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the
mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
ANTENNA
LEAD IN WIRE
GROUND
CLAMP
NEC — NATIONAL ELECTRICAL CODE
• To prevent fire, never place any type of candle or flames on the top or near the TV set.
• To prevent fire or shock hazard, do not expose this product to dripping or splashing.
No objects filled with liquids, such as vases, should be placed on the product.
• To prevent fire or shock hazard, do not place the AC cord under the TV set or other heavy
items.
• Turn off the main power and unplug the AC cord from the wall outlet before handling.
• Use a soft cloth and gently wipe the surface of the display panel. Using a hard cloth may
scratch the panel surface.
• Use a soft damp cloth to gently wipe the panel when it is really dirty.
(It may scratch the panel surface when wiped strongly.)
• If the panel is dusty, use an anti-static brush, which is commercially available, to clean it.
• To protect the panel, do not use a dirty cloth, liquid cleaners or chemical cloth to clean it,
such materials may damage the panel surface.
• To clean the outer cabinet, use the same method. Do not use liquid or aerosol cleaners.
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING ELECTRODE
SYSTEM
(NEC ART 250, PART H)
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
• Do not display a still picture for a long time, as this could cause an afterimage to remain.
IMPORTANT SAFETY INSTRUCTIONS
32D41U_en_a.indd 532D41U_en_a.indd 5 2006/05/17 11:49:042006/05/17 11:49:04

6
Supplied accessories
NOTE
• Always use the AC cord supplied with the TV.
Make sure the following accessories are provided with the product.
Remote control unit (g1)
Page 8 Page 8 Page 7
Page 7 Page 7
“AAA” size battery (g2) AC cord (g1)
Cable Clamp (g1) Cable tie (g1) Operation manual (g1)Stand unit (g1)
Page 6
1. Confirm the 8 screws supplied with the TV.
NOTE
• To detach the stand, perform the steps in reverse order.
2. Attach the two parts of the stand unit to each other using
the 4 short screws and the hex key (supplied with the
product) as shown.
3.
1Insert the stand into the opening on the bottom of the
TV.
2Insert and tighten the 4 long screws into the 4 holes on
the rear of the TV.
Attaching the stand
• Before attaching (or detaching) stand, unplug the AC cord from the AC INPUT terminal.
• Before performing work spread cushioning over the base area to lay the TV on.
This will prevent it from being damaged.
Short screws (m4)
(used in step 2) Long screws (m4) (used in step 3)
1
2
QUICK REFERENCE
Hex key
Hex key
Short screw Soft cushion
Long screw
CAUTION
• Attach the stand in the correct direction.
• The “REAR” label should be visible from the back of the TV. Refer to
the figure.
• Incorrect installation of the stand may result in the TV falling over.
• Be sure to follow the instructions. REAR
This side faces the rear.
32D41U_en_a.indd 632D41U_en_a.indd 6 2006/05/17 11:49:052006/05/17 11:49:05

7
QUICK REFERENCE
STOP! To safely remove the AQUOS television from the box
• It's best to use 2 people to remove the AQUOS television for stability.
• Lift onto installation location as the diagram illustrates.
Ventilation & Cleaning Tips
Keep your AQUOS television in a well ventilated area and make sure not to place it by a heat
source or use near water. The AQUOS television is designed for AC use only and should be used
with supplied AC cord.
Clean the screen by spraying a soft lint free cloth with water to lightly moisten. Gently wipe and
avoid pressing on the screen. To clean the outer cabinet, use the same method. Do not use
liquid or aerosol cleaners.
The screen is glass and can be scratched or broken when dropped or impacted.
QUICK INSTALLATION TIPS
1. Attach your antenna to the back of the AQUOS television.
(See page 13.)
NOTE
•TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT
TOUCH UN-INSULATED PARTS OF ANY CABLES
WITH THE AC CORD CONNECTED.
3. Place the Ferrite core in the space indicated in the below
figure and bundle the cords properly with a cable clamp
and cable tie.
4. How to turn on the AQUOS television for the first time.
A) Press POWER on AQUOS television.
POWER
POWER indicator
2. Connect the AC plug for the AQUOS television into the
AC outlet.
B) POWER indicator on the front of the AQUOS television
lights GREEN.
NOTE
• You cannot tilt the screen vertically.
• Speaker cannot be detached from the TV.
AC outlet
• Place the TV close to the AC outlet, and keep the power
plug within reach.
32D41U_en_a.indd 732D41U_en_a.indd 7 2006/06/08 11:37:132006/06/08 11:37:13

30°30°
8
QUICK REFERENCE
If the remote control fails to operate TV functions, replace the batteries in the remote control unit.
1 Open the battery cover.
• Place the batteries with their terminals
corresponding to the (e) and (f)
indications in the battery compartment.
NOTE
Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.
• Do not mix batteries of different types. Different types of batteries have different characteristics.
• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical
leakage in old batteries.
• Remove batteries as soon as they are worn out. Chemicals that leak from batteries that come in contact with skin can cause
a rash. If you find any chemical leakage, wipe thoroughly with a cloth.
• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.
• If you will not be using the remote control unit for an extended period of time, remove batteries from it.
Remote control
sensor
2Insert two “AAA” size batteries
(supplied with the product). 3Close the battery cover.
16n4o(5 m)
IMPORTANT:
The POWER indicator on the AQUOS television should light GREEN indicating you have power to the AQUOS
television.
If the POWER indicator on the AQUOS television still does not light up, press TV POWER
on the remote control to turn the power on.
IMPORTANT:
IF THE UNIT DOES NOT POWER ON - UNPLUG THE AQUOS TELEVISION FROM THE OUTLET AND REPEAT
THE INSTALLATION STEPS.
IF YOU STILL ENCOUNTER NO POWER, PLEASE CONTACT US AT 1-800-BE-SHARP.
Please refer to the BASIC ADJUSTMENT SETTINGS SECTION for EZ Setup and basic channel setup functions
and USING EXTERNAL EQUIPMENT SECTION for other device connections (DVD, VCR, AUDIO, etc) in your
AQUOS operation manual.
32D41U_en_a.indd 832D41U_en_a.indd 8 2006/05/17 11:49:152006/05/17 11:49:15

9
IMPORTANT INFORMATION .................................. 1
Trademarks.............................................................. 2
DEAR SHARP CUSTOMER ..................................... 3
IMPORTANT SAFETY INSTRUCTIONS.................. 3
Supplied accessories.............................................. 6
QUICK REFERENCE................................................ 6
Attaching the stand .............................................. 6
Contents................................................................... 9
Part names............................................................. 10
TV (Front) ........................................................... 10
TV (Rear) ............................................................ 11
Remote control unit............................................ 12
Preparation ............................................................ 13
Using the remote control unit.............................. 13
Cautions regarding the remote control unit..... 13
Antennas............................................................ 13
Watching TV........................................................... 14
Turning on the power ......................................... 14
Turning off the power ......................................... 14
Initial setup ......................................................... 15
Simple button operations for
changing channels .......................................... 16
Simple button operations for
changing volume/sound .................................. 17
Setting MTS/SAP stereo mode........................... 18
Setting Digital broadcasting audio mode ............ 18
Basic adjustment settings.................................... 19
Menu operation buttons ..................................... 19
On-Screen Display ............................................. 19
Menu items for TV/INPUT 1/INPUT 2.................. 20
Menu items for HDMI/DVI................................... 20
EZ Setup............................................................ 21
Channel Setup ................................................... 21
Antenna Setup-DIGITAL ..................................... 22
Favorite channel setting...................................... 23
Picture adjustments............................................ 24
OPC setting.................................................... 24
Advanced picture adjustments ....................... 25
Color Temperature ......................................... 25
Black.............................................................. 25
3D-Y/C........................................................... 25
Monochrome.................................................. 25
Film Mode (3:2 pull-down) .............................. 25
Range of OPC................................................ 25
Sound adjustment .............................................. 26
Surround............................................................ 26
Power Control .................................................... 27
Digital Setup....................................................... 28
Audio Setup ................................................... 28
Using external equipment..................................... 29
Displaying an external equipment image............. 29
Connecting a DVD player or a Digital TV STB
(Air or Cable) .................................................... 30
Connecting HDMI equipment ............................. 31
Displaying an image from HDMI equipment ........ 31
Connecting a PC................................................ 32
Connecting a VCR, game console
or camcorder ................................................... 32
Using Digital Audio Output.................................. 32
Useful adjustment settings................................... 33
Input Skip........................................................... 33
Standby Mode.................................................... 33
Language setting................................................ 33
Image position (AV input mode only)................... 33
Auto Sync. adjustment
(for Analog PC input mode only) ....................... 34
Fine Sync. adjustment ........................................ 34
Reset ................................................................. 35
Input Select........................................................ 36
Input Label ......................................................... 37
View Mode for 4:3 Programs.............................. 38
View Mode for HD Programs.............................. 38
View Mode (for PC input mode).......................... 39
AV MODE........................................................... 40
Input Signal (for PC input mode) ......................... 40
Digital Noise Reduction ...................................... 41
Audio Only.......................................................... 41
Output Select ..................................................... 41
Color System ..................................................... 42
Program Title Display.......................................... 42
Sleep Timer........................................................ 42
Closed Captions and Digital Closed Captions..... 43
Caption Setup .................................................... 44
Secret number setting for parental control
(AV input mode only) ........................................ 45
Parental control (setting V-CHIP level)................. 47
How to temporarily release
the V-CHIP BLOCK .......................................... 50
Reactivating the temporarily released
V-CHIP BLOCK................................................ 50
Other viewing options........................................... 51
Freezing images ................................................. 51
Presetting remote control function...................... 51
Appendix ................................................................ 55
Removing the stand ........................................... 55
Setting the TV on the wall................................... 55
Troubleshooting ................................................. 56
Troubleshooting-Digital broadcasting ................. 57
PC compatibility chart ........................................ 57
Specifications..................................................... 58
Optional accessory............................................. 58
Dimensional drawings........................................... 59
Contents
32D41U_en_b.indd 932D41U_en_b.indd 9 2006/05/17 11:50:522006/05/17 11:50:52

10
Part names
POWER button
TV (Front)
Channel buttons
(CHs/r)
Volume buttons (VOLl/k)
INPUT button
OPC indicator*
POWER
indicator**
OPC sensor*
Remote control sensor
NOTE
*OPC: Optical Picture Control (See page 24.)
**See page 14 for TV status indicator.
32D41U_en_b.indd 1032D41U_en_b.indd 10 2006/05/17 11:50:552006/05/17 11:50:55

11
Part names
TV (Rear)
DVI terminal
(INPUT 5)
INPUT 2
terminals
AUDIO OUTPUT
terminals
HDMI terminal (INPUT 3)
HDMI terminal (INPUT 4)
Antenna/Cable in
INPUT 1 terminals
DIGITAL AUDIO
OUTPUT
terminal
DVI AUDIO
terminal
(INPUT 5)
AUDIO input
terminals
(INPUT 4)
AC INPUT terminal
32D41U_en_b.indd 1132D41U_en_b.indd 11 2006/05/19 10:56:552006/05/19 10:56:55

3
2
114
5
6
4
8
17
15
16
18
19
7
20
10
9
21
11 23
24
25
12
13 27
22
26
12
Part names
1TV POWER: Switches the TV power on or enters
standby mode. (See page 14.)
2DISPLAY: Displays the channel information.
3SOURCE POWER: Turns the power of the external
equipment on and off.
4External equipment operational buttons: Operates
the external equipment.
50 – 9: Sets the channel. (See page 16.)
6•(DOT): (See pages 16 and 53.)
7INPUT: Selects a TV input source. (TV, INPUT 1, INPUT
2, INPUT 3, INPUT 4, INPUT 5) (See pages 29 and 36.)
8VOL k/l:Sets the volume. (See page 17.)
9SURROUND: Selects Surround settings. (See page 17.)
10 FREEZE: Sets the still image. Press again to return to
normal screen. (See page 51.)
11 EXIT: Turns off the menu screen.
12 SLEEP: Sets the sleep timer. (See page 42.)
13 AUDIO: Selects the MTS/SAP or the audio mode during
multi-channel audio broadcasts. (See page 18.)
14 FUNCTION: Switches the remote control for TV, CBL/
SAT, VCR, DVD and AUDIO operation. Indicator lights up
for the current mode. (See pages 51 to 54 for details.)
* To enter the code registration mode, you need to press
FUNCTION and DISPLAY at the same time.
15 LIGHT D:When pressed all buttons on the remote
control unit will light. The lighting will turn off if no
operations are performed within about 5 seconds. This
button is used for performing operations in low-light
situations.
16 VIEW MODE: Selects the screen size. (See page 38.)
17 ENT: Jumps to a channel after selecting with the 0–9
buttons.
18 FLASHBACK: Returns to the previous channel or
external input mode. (See page 16.)
19 CHr/s:Selects the channel. (See page 16.)
20 MUTE: Mutes the sound. (See page 17.)
21 MENU: Displays the menu screen.
22 a/b/c/d/ENTER: Selects a desired item on the
screen.
23 RETURN: Returns to the previous menu screen.
24 FAVORITE CH
A, B, C, D: Selects four preset favorite channels in four
different categories. (See page 23 for details.)
While watching, you can toggle the selected channels by
pressing A, B, C and D.
25 FAVORITE: Registers favorite channels. (See page 23.)
26 CC: Displays captions from a closed-caption source. (See
page 43.)
27 AV MODE: Selects an audio or video setting. (When the
input source is TV, INPUT 1 or 2: STANDARD, MOVIE,
GAME, USER, DYNAMIC (Fixed), DYNAMIC. When the
input source is INPUT 3, 4 or 5: STANDARD, MOVIE,
GAME, USER, DYNAMIC (Fixed), DYNAMIC, PC) (See
page 40.)
Remote control unit
NOTE
• When using the remote control unit, point it at the TV.
32D41U_en_b.indd 1232D41U_en_b.indd 12 2006/05/17 11:50:582006/05/17 11:50:58

300-ohm twin-lead
75-ohm coaxial cable (round)
75-ohm coaxial cable
IN OUT
300-ohm
twin-lead
VHF
A
NTENNA
UHF
ANTENNA
Combiner
(commercially
available)
or
300/75-ohm adapter
(commercially available)
300-ohm twin-lead (flat)
75-ohm coaxial cable (round)
or
Cable TV lead-In
Coaxial cable
(commercially available)
Coaxial cable
(commercially available)
Home Antenna
terminal (75-ohm)
Home Antenna
terminal (75-ohm)
Using the remote control unit
Use the remote control unit by pointing it towards the remote control sensor on the
TV. Objects between the remote control unit and the remote control sensor may
prevent proper operation.
Cautions regarding the remote control unit
• Do not expose the remote control unit to shock. In addition, do not expose the remote
control unit to liquids, and do not place in an area with high humidity.
• Do not install or place the remote control unit under direct sunlight. The heat may cause
deformation of the remote control unit.
• The remote control unit may not work properly if the remote control sensor on the TV is
under direct sunlight or strong lighting. In such cases, change the angle of the lighting or
the TV, or operate the remote control unit closer to the remote control sensor.
Antennas
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections
that are used for a coaxial cable. If your outdoor antenna uses a 75-ohm coaxial cable with an F-type connector,
plug it into the antenna terminal at the rear of the TV set.
1.A 75-ohm system is generally a round cable with F-type
connector that can easily be attached to a terminal
without tools (Commercially available).
F-type connector
Connecting Antenna Cable
300-ohm twin-lead cable (flat)
F-type connector
75-ohm coaxial cable (round)
75-ohm coaxial cable
Preparation
1Cable without a
CATV converter
3Combination VHF/
UHF antenna
4Separate VHF/
UHF antenna
NOTICE
2.A 300-ohm system is a flat “twin-lead” cable that can be
attached to a 75-ohm terminal through a 300/75-ohm
adapter (Commercially available).
F-type connector should be finger-
tightened only.
When connecting the RF cable to the TV set, do not
tighten F-type connector with tools.
If tools are used, it may cause damage to your TV
set. (The breaking of internal circuit, etc.)
To TV
antenna
terminal
2VHF/UHF antenna • Connect the antenna cable
to the TV using one of the
methods in the illustration as
shown (1, 2, 3or 4).
13
32D41U_en_b.indd 1332D41U_en_b.indd 13 2006/05/17 11:50:592006/05/17 11:50:59

14
Simple operations for watching a TV program
POWER indicator
TV POWER (On/Standby)
Turning on the power
Press POWER on the TV, or TV POWER on the
remote control.
• POWER indicator (Green): The TV is on. (After a few
seconds, a window appears with sound.)
NOTE
• The initial setup starts when the TV powers on for the first
time. If the TV has been turned on before, the EZ Setup will
not be invoked. See page 21 for performing EZ Setup from
the Setup menu.
Turning off the power
Press POWER on the TV, or TV POWER on the
remote control.
• The TV enters standby mode and the image on the screen
disappears.
• The POWER indicator on the TV gradually turns off.
NOTE
• If you are not going to use this TV for a long period of time,
be sure to remove the AC cord from the power outlet.
• Weak electric power is still consumed even when POWER
is turned off.
Watching TV
POWER
TV status indicator (POWER)
ON Lighting (Green)
Lights offOFF/Standby
“Off” is selected in OPC setting
“On” or “On: Display” is selected in OPC setting
Lights off
Lighting (Green)
TV status indicator (OPC)
• See page 24 for details.
OPC indicator
32D41U_en_c.indd 1432D41U_en_c.indd 14 2006/05/17 11:51:412006/05/17 11:51:41

15
Language
Standby Mode
Air/Cable
CH Search
English
Español
Français
Language
Standby Mode
Air/Cable
CH Search
Mode 1
Mode 2
AIR Analog & Digital Yes
CABLE Analog
No
Yes No
CABLE Analog & Digital Yes No
Language
Standby Mode
Air/Cable
CH Search
Search Start
CH Search
[ ]20
Found
[ ]25
Air
2
Air ANALOG
Audio : MONO
Air/Cable
Standby Mode
Language
CH Search
Air Cable
Watching TV
Initial setup
When you turn on the TV for the first time, it will automatically memorize the broadcasting channels where you live.
Perform the following steps before you press TV POWER on the remote control unit.
1. Insert the batteries into the remote control unit. (See page 8.)
2. Connect the antenna cable to the TV. (See page 13.)
3. Plug in the AC cord to the AC outlet. (See page 7.)
Language setting
Select from among 3 languages: English, French and
Spanish.
Press a/bto select the desired language
listed on the screen, and then press ENTER.
Channel search
Channel auto search makes the TV look for all channels
viewable in the set area.
Press c/dto select “Yes” or “No” for AIR
Analog & Digital, then press bto move down.
Press c/dto select “Yes” or “No” for CABLE
Analog, then press bto move down.
Press c/dto select “Yes” or “No” for
CABLE Analog & Digital, then press bto
move down.
Select “Search Start”, and then press
ENTER.
• If you are only receiving an analog signal through
the cable, select “Yes” for CABLE Analog. If you
are receiving both an analog signal and a digital
signal through the cable, select “Yes” for CABLE
Analog & Digital.
Example
Standby Mode setting
Select the standby setting. (See page 33.)
Antenna setting
Make sure what kind of connection is made with your TV
when selecting “Air” or “Cable”.
Press c/d to select “Air” or “Cable”.
Press ENTER to enter the setting.
Mode 1: Starting TV is quick from standby.
Mode 2: Power consumption is small at the standby.
Example
1
2
3
4
NOTE
• If no channel is found, confirm the type of connection made
with your TV and try EZ Setup again. (See page 21.)
32D41U_en_c.indd 1532D41U_en_c.indd 15 2006/05/17 11:51:442006/05/17 11:51:44

16
22.
Air Air DIGITAL
22.1
22.1
Air
22
Air
2
Air
11
Cable
1
Cable
115
Cable ANALOG
5
Air
5
Air ANALOG
Simple button operations for
changing channels
You can change channels in several ways.
NOTE
• When selecting a 1-digit channel number, it is not
necessary to press 0 before the number.
• When you enter 0-9 only, channel selection will be made if
there is no operation within a few seconds.
To select a 3-digit channel number
(e. g., Channel 115):
Press 1s1s5
To select a 4-digit channel number
(e. g., Channel 22.1):
Press 2 s2s• (DOT) s1sENT
NOTE
• When you enter 0–9 only, channel selection will be made if
there is no operation within a few seconds.
• If you push “0” by itself, nothing will happen.
• Complete the above steps within a few seconds.
• When you enter 0–9 and •(DOT), channel selection will be
made if there is no operation within a few seconds.
Method 1
Using CH r/son the remote control unit or on the
TV.
Method 2
1 Press FLASHBACK to switch to the previously tuned
channel.
2 Press FLASHBACK again to switch back to the
currently tuned channel.
NOTE
• FLASHBACK will not work if no channel has been
changed after the TV is turned on.
Method 3
Using remote control buttons 0-9, • (DOT) to select
channels for VHF/UHF/CATV/DIGITAL.
To select a 1 or 2-digit channel number
(e. g., Channel 5):
Press 5sENT
Watching TV
32D41U_en_c.indd 1632D41U_en_c.indd 16 2006/05/17 11:51:462006/05/17 11:51:46

17
20
20
20 Surround : Off Surround : On
Simple button operations for
changing volume/sound
Changing the volume
You can change the volume on the TV or on the remote
control unit.
NOTE
• VOLl/kon the TV operates the same as VOL k/l on
the remote control unit.
Using VOLk/l
• To increase the volume, press VOLk.
• To decrease the volume, press VOLl.
Audio status
Volume adjustment
* When “Output Select” is set to “Variable”, the indicator on
the screen changes as shown below.
NOTE
• See page 41 for details on the Output Select function.
NOTE
• You can have the same settings by choosing “Surround”
on the menu items. (See page 26.)
SURROUND produces Surround effect from the
speakers. Each time you press SURROUND, the
mode changes between On and Off.
Surround sound options
On: Makes it possible to enjoy natural, realistic surround
sound.
Off: Outputs the normal sound.
Using MUTE on the remote control unit
Mutes the current sound output.
NOTE
• Within 30 minutes of pressing MUTE, mute can be
canceled by using one of the methods below.
— Mute will cancel if you press VOLl/kor MUTE.
• Mute will be canceled after 30 minutes have passed.
However, the TV will not suddenly output a loud sound as
the volume level is set to 0 automatically.
Mute
Press MUTE.
• Mwill be displayed on the screen for 30 minutes, and the
sound is silenced.
Watching TV
Using SURROUND on the remote control unit
Output Select
Output device Fixed Variable
Variable sound Mute Speaker
32D41U_en_c.indd 1732D41U_en_c.indd 17 2006/05/17 11:51:482006/05/17 11:51:48

18
2
Air ANALOG
Audio : MONO
2
Air ANALOG
Audio : STEREO
2
Air ANALOG
Audio : MAIN
2
Air ANALOG
Audio : SAP
2
Air ANALOG
Audio : MONO
2
Air ANALOG
Audio : ST(SAP)
2
Air ANALOG
Audio : SAP(ST)
2
Air ANALOG
Audio : MONO
Setting MTS/SAP stereo mode
The TV has a feature that allows reception of sound
other than the main audio for the program. This feature
is called Multi-channel Television Sound (MTS). The TV
with MTS can receive mono sound, stereo sound and
Secondary Audio Programs (SAP). The SAP feature
allows a TV station to broadcast other information,
which could be audio in another language or something
completely different like weather information.
You can enjoy Hi-Fi stereo sound or SAP
broadcasts where available.
• Stereo broadcasts
View programs like live sporting events, shows and
concerts in dynamic stereo sound.
• SAP broadcasts
Receive TV broadcasts in either MAIN or SAP sound.
MAIN sound: The normal program soundtrack (either in
mono or stereo).
SAP sound: Listen to a second language, supplementary
commentary or other information. (SAP is mono sound.)
If stereo sound is difficult to hear.
• Obtain a clearer sound by manually switching to fixed
mono-sound mode.
NOTE
•MTS only operates while in TV mode.
You can change MTS as
shown below to match
the television broadcast
signal.
Examples: when receiving MTS and SAP
STEREO mode MAINkSAP mode
Examples: when receiving Digital broadcasting
Setting Digital broadcasting audio
mode
The types of audio transmitted in a digital broadcast
include SURROUND as well as MONO and STEREO.
In addition, it is possible for multiple audio tracks to
accompany a single video track.
Press AUDIO to toggle
between audio modes.
Watching TV
STEREOkSAP mode MONO mode
2.2
Air DIGITAL
Audio3 : SURROUND
2.2
Air DIGITAL
Audio1 : STEREO
2.2
Air DIGITAL
Audio2 : STEREO
32D41U_en_c.indd 1832D41U_en_c.indd 18 2006/05/17 11:51:512006/05/17 11:51:51

19
ENTER
: Select : Enter MENU : Exit
RETURN
: Back
On-Screen Display
Basic adjustment settings
Menu operation buttons
Use the following buttons on the remote control to
operate the menu.
MENU: Press to open or close the menu screen.
a/b/c/d:Press to select a desired item on the
screen or adjust a selected item.
ENTER: Press to go to the next step or complete
the setting.
RETURN: Press to return to the previous step.
The bar above is an operational guide for
the remote control. The bar will change in
accordance with each menu setting screen.
1 Item displayed in yellow
• This indicates the item currently selected.
• Press ENTER to go to the adjustment screen for
this item.
2Item in brackets
• This indicates the current setting for the item.
3Item displayed in white
• This indicates an item can be selected.
4Item displayed in grey
• This indicates that the item cannot be selected.
*There are various reasons why items cannot be
selected, but the main reasons are as follows:
1 Nothing is connected to the selected input terminal.
2 The function is not compatible with the current input
signal.
NOTE
• Menu options differ in the selected input modes, but the
operating procedures are the same.
• The screens in the operation manual are for explanation
purposes (some are enlarged, others cropped) and may
vary slightly from the actual screens.
Example
MENU [Option ... Color System]
Option
Audio Only
Digital Noise Reduction
Input Select
Color System
[Off]
[VIDEO]
Output select [Fixed]
[Auto]
[No]
Favorite CH
Program Title Display
Caption Setup
3
4
2
1
32D41U_en_d.indd 1932D41U_en_d.indd 19 2006/05/17 11:53:252006/05/17 11:53:25
