For Sharp Carousel®Built-in Kit
Models RK56S27 or RK56S30
S = STAINLESS
THIS KIT IS UL APPROVED TO ALLOW CERTAIN MICROWAVE
OVENS TO BE INSTALLED ABOVE ANY ELECTRIC WALL OVEN.
PLEASE SEE THE OPERATION MANUAL REGARDING APPROVED
BUILT-IN APPLICATIONS.
IMPORTANT:
This Built-in Kit is designed for and approved only for those
Sharp Microwave Ovens specifying Built-In Kit RK56S27 or
RK56S30. Refer to instruction manual for approved models.
PLEASE READ THESE INSTRUCTIONS
THOROUGHLY
BEFORE BEGINNING INSTALLATION!
• Be sure to DISCONNECT THE PLUG of the microwave
oven from the electrical outlet before installing the Built-in
Kit. Remove the Carousel turntable from the oven cavity.
• Because the kit includes metal parts, due caution should
be used in handling and installation to avoid the possibil-
ity of injury.
ITEM PART NAME QTY
AFRONT FRAME
RK56S27: FDECAB252MRK0
RK56S30: FDECAB253MRK0
1
B BACK FRAME
RK56S27: FDECAB255MRK0
RK56S30: FDECAB255MRK0
1
C EXHAUST DUCT ASSEMBLY
PDUC-B188MRP0
1
D SCREW D: XTSS740P20000 2
E SCREW E: XOPS740P16000 4
1
INSTALLATION INSTRUCTIONS
A B
D
C
E
V-cut
indicates
center of
duct
CL

2
The opening in the wall or cabinet must be within the
following dimensions:
Cut Out RK56S27 & RK56S30
Height (A) 16
1/4"
Width (B) 261/8" to 26
3/8"
Minimum Depth (C) 20"
Outlet should NOT be in the shaded area as indicated on
Sketch 1.
A
B
4"
C
4"
SKETCH 1
NOTES
• Please allow minimum 3" wood gap between the
microwave oven cutout and the appliance cutout below
the microwave oven. See Sketch 2
3" Min.
Microwave cutout
Wall oven cutout
SKETCH 2
• If the dimension of DEPTH (C) is more than 21", the outlet
location may be any area on the rear wall.
• The oor of the opening should be constructed of plywood
strong enough to support the weight of the oven and oor
load (about 100 pounds). The oor should be level and
90˚ with the face of the cabinet for proper installation and
operation of the oven. Be sure to check the local building
code as it may require that the opening be enclosed with
sides, ceiling and rear partition. The proper functioning of
the oven does not require the enclosure.
STEP 1 CABINET OR WALL OPENING

3
1. Place the EXHAUST DUCT ASSEMBLY in the center of the
opening. Position the front edge of the duct 3/8" proud of
the front edge of the cabinet. See Sketch 3.
2. Mark the two holes, center punch and pre-drill with 1/16"
drill bit. Secure the EXHAUST DUCT ASSEMBLY with two
SCREWS D. See Sketch 3.
STEP 2 EXHAUST DUCT ASSEMBLY INSTALLATION
3/8”
Screw D
Screw D
C
L
Exhaust duct assembly,
position 3/8" proud of the
front edge of cabinet
SKETCH 3
1. Place the oven adjacent to the wall or cabinet opening.
Plug the POWER CORD into the electrical outlet.
2. Carefully guide the assembled oven into the prepared
opening. Slide the oven on the EXHAUST DUCT
ASSEMBLY. See Sketch 4. Avoid pinching the cord
between the oven and the wall. Adjust the position of
the oven so that the feet of the oven are tted into the
recesses of the EXHAUST DUCT ASSEMBLY and door
will open properly. See Sketch 5.
SKETCH 4
Exhaust
duct
assembly
Foot
Duct recess
SKETCH 5
STEP 3 FRAME INSTALLATION

4
For any other assistance or information about this kit,
please call Sharp’s Customer Assistance Center at
1-800-BE-SHARP (1-800-237-4277)
SHARP ELECTRONICS CORPORATION
100 Paragon Drive, Montvale, New Jersey 07645 TINSEB567MRR0
STEP 3 FRAME INSTALLATION
3. DISASSEMBLY: The FRONT FRAME and BACK FRAME
come pre-assembled with ball studs engaged in the
receivers. Separate the FRONT FRAME from the BACK
FRAME. Place the assembly face down on a protected
surface. At the location of the ball stud, insert a at head
screwdriver between the FRONT FRAME and the BACK
FRAME and gently pry up to disengage the ball stud from
the receiver. Repeat for each corner. See Sketch 6.
SKETCH 6
4. BACK FRAME INSTALLATION: Position back frame equal
space top to bottom, side to side. Mark for 4 holes, center
punch and pre-drill with 1/16" drill bit. Secure frame with
4 SCREWS (E). See Sketch 7.
Equal gap top, bottom
Equal gap
side to side
Mounting holes
Mounting holes
Mounting holes
Mounting holes
Screw E
Screw E
Screw E
Screw E
SKETCH 7
5. FRONT FRAME INSTALLATION: Place the FRONT
FRAME onto the BACK FRAME and align ball studs
and receivers. Secure the FRONT FRAME to the BACK
FRAME by rmly pushing the front frame onto the back
frame engaging the four (4) snap attachments. See
Sketch 8.
Snap
Attachment
SKETCH 8
