Sharp R-793M User manual

FROZEN
READY MEALS
CASSEROLE
JACKET
POTATOES
FRESH VEG. PORRIDGE
CHILLED
READY MEALS
STOP
CLEAR
START
AUTO MINUTE
SET
UP
SENSOR
REHEAT
VIEW
MENUS
R-793
DEFROST
COOK
231
564
897
0
POWER
12 : 30
MODE
TINS-A223URR0
R-793M
QUICK START GUIDE
Read SAFETY WARNINGS in the manual before operating
1. TOUCH SCREEN
2. POWER
3. START/AUTO MINUTE key
4. EXPRESS DEFROST key
5. SENSOR REHEAT key
6. SensNcook keys
7. SET UP key
8. VIEW MENUS key
9. EXPRESS COOK key
10. STOP/CLEAR key
11. MODE
1
2
3
5
4
6
9
8
7
11
10
GRILLING
Example of basic grilling:
To grill for 4 minutes, using the high rack.
Place the food on top of
the high rack, in the centre
of the turntable and close
the door.
Enter the cooking time,
4, 0, 0by touching the
numbers on the screen.
Note the top line of the
display and then touch
MODE.
1.
2.
231
564
897
0
POWERMODE
4 . 00
Choose desired cooking
mode by pressing GRILL.
3.
DUAL 10% DUAL 30%
DUAL 50% DUAL 70%
GRILL
4 . 00
Touch here to go to
NEXT STAGE
4 . 00
Press the START key
GRILL
Press the START/AUTO
MINUTE key once to start
cooking.
4.
4 . 00
-1 MIN +1 MIN
GRILL
The display will count
down through cooking
time.
5.

Remove all packaging and accessories from the
oven, including the feature sticker fixed to the
outside of the door and the wrapping shown in the
diagram.
INSTALLATION MICROWAVING
Turntable Assembly
Place the turntable support in
the centre of the oven floor so
that it can freely rotate around
the coupling.
Then place the turntable onto
the turntable support so that it
locates firmly into the coupling.
Example of basic microwaving:
To heat a cup of water on 10 % power for 2
minutes.
Place the cup of water in
the centre of the turntable
and close the door.
Enter the cooking time,
2, 0, 0by touching the
numbers on the screen.
Note the top line of the
display. And then touch
POWER.
INSTALLATION
Ensure there is at least
19.5cm of free space
above the oven.
1.
2.
3.
4.
5.
1.
2.
REMOVE THIS FILM
19.5cm
Plug in the oven. Select SET CLOCK or DEMO MODE.
To set the clock, touch SET CLOCK
and follow the instructions opposite.
NOTE: If no choice is made for 30
seconds, the Demo Mode will begin
automatically. To cancel the Demo
Mode, press the STOP/CLEAR key
and the screen will return to the Home
Page. To set the clock, press the SET
UP key, touch CLOCK and follow the
directions on the Touch screen.
DEMO MODE SET CLOCK
TOUCH SCREEN
Demo Mode provides a
summary of oven features.
Other Accessories
Low and high rack - use for grilling / dual grilling
food.
SETTING THE CLOCK
Enter the time of day
(minutes) by touching 10
MIN 3 times.
Your oven is fitted with a 12 hour clock.
To set the time of day, follow the guidelines given below:
1.
2.
EXAMPLE: To set the time of day to 12:30 PM:
10 MIN 1 MINHOUR
12 : 00 AM
Enter time of day and then
touch AM or PM.
Press START to confirm
AM/PM
After touching SET
CLOCK, enter the time of
day (hour) by touching
HOUR 11 times.
10 MIN 1 MINHOUR
12 : 30 AM
Enter time of day and then
touch AM or PM.
Press START to confirm
AM/PM
Select AM or PM, then
press the START/AUTO
MINUTE key to set the
clock.
3.
10 MIN 1 MINHOUR
12 : 30 PM
Enter time of day and then
touch AM or PM.
Press START to confirm
AM/PM
The clock will start and the display
will return to the Home Page.
The Home Page is the opening
screen, from this screen a variety of
functions can be carried out.
• Touch POWER after entering
cooking time to select one of five
microwave power levels.
• Touch MODE after entering
cooking time to select cooking
mode using the grill heating
element.
• The time of day is also displayed
at the top of the screen. (If the
clock has been set).
4.
231
564
897
0
POWERMODE
12 : 30 PM
231
564
897
0
POWERMODE
2 . 00
Choose desired power by
pressing 10 %.
3.
100 %
10 % 30 %
50 % 70 %
2 . 00
MICRO 10 %
Touch here to go to
NEXT STAGE
2 . 00
Press the START key
MICRO 10 %
Press the START/AUTO
MINUTE key once to start
cooking
4.
2 . 00
-1 MIN +1 MIN
MICRO 10 %
The display will count
down through cooking
time.
5.
