Sharp AQUOS 4T-C65DL1X Manual

親愛的 SHARP 顧客/Dear SHARP customer
衷心感謝您購買 SHARP 液晶顯示器。為確保安全使用本機及多年使用本機，請務必在使用本產品前仔細閱
讀重要的安全注意事項。
重要事項：
請將顯示器的型號和序號抄在右側空格內，萬一本機遺失或遭竊時將
有助於資料的呈報。型號和製造號碼標示於顯示器的背面。
型號/Model No.：
製造號碼/Serial No.：
本產品僅適用於台灣。/ This product is only for Taiwan.
重要資訊/Important Information
Thank you for your purchase of the SHARP Liquid Crystal Monitor. To ensure safety and many
years of trouble-free operation of your product, please read the Important Safety Precautions
carefully before using this product.
IMPORTANT:
To aid reporting in case of loss or theft, please record the Monitor’s
model and serial numbers in the space provided. The numbers are
located at the rear of the Monitor.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING:
/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrow-head
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a
triangle is intended to alert the user
to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the product.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
/ Overuse may damage eyesight.
/ Use 30 minutes, please rest for 10 minutes.
/ Do not let children under age of 2 to
watch the screen, children over age of 2 should not watch the screen for more than 1 hour per day.
SLOT, FULLY INSERT.
CAUTION:
CT
-1
CT
-2
4T-C65DL1X
4T-C50DL1X
4T-C65DK1X
4T-C50DK1X
馬來西亞印製
TINS-H660WJN2
22P09-MA-NS
TINS-H660WJN2
LCD MONITOR
Initial setup guide

CT
-3
CT
-4
C. 連接台座單位
Attaching the stand
•在組裝顯示器之前請勿取下保護墊。否則，屏幕可能會因直接壓力而損壞。
CAUTION
•Do not remove protective pad until Monitor is assembled. Otherwise, the screen can
be damaged from direct pressure.
B. 裝入電池
遙控器 Remote control unit
123
2“AAA”型鹼性電池
Inserting the batteries
“AAA” size battery
Soft cushion
A. 隨機附件 Supplied accessories
台座
4Stand base 螺絲釘
5Screws
2“AAA”型鹼性電池（g 2 支）
“AAA” size battery
(m2)
1遙控器（g 1 支）
Remote control unit
(m1)
3
初始設定指南
印刷紙
Initial setup guide
Printed paper
●
●
Warranty Certificate
保證書
L R
L R
4T-C65DL1X / 4T-C65DK1X
4T-C50DL1X / 4T-C50DK1X
4T-C65DL1X / 4T-C65DK1X
4T-C50DL1X / 4T-C50DK1X
(M5 x 15mm) X 4
(M4 x 12mm) X 4
•在裝入電池時，要注意電池端子
的極性要與電池艙內的極性標記
（e）和（f）一致。
• Place batteries with their terminals
corresponding to the (k) and
(l) indications in the battery
compartment.
Recycle the battery
1. 組裝時請在一張穩定、平坦、寬大且有軟墊的桌子上進行。
2. 與兩個或更多人一起工作。
抬起時請勿抓住顯示器的角。
3. 安裝完成前請勿取下保護墊。
Do not remove the protective pad until the installation is completed.
Work with two or more people.
Do not grab the corners of the Monitor when lifting.
Assemble on a soft cushion on a stable, flat and wide table.
步驟 將支架配插入顯示器底部的開口中。
步驟 將螺絲釘插入顯示器底部/後部的孔內並擰緊。
■4T-C50DL1X / 4T-C50DK1X
Insert and tighten the screws into the holes on the bottom / rear of the Monitor.Step
Insert the stand assembly into the openings on the bottom of the Monitor.Step
台座
4“R”
Stand base “R” 台座
4“L”
Stand base “L”
■4T-C65DL1X / 4T-C65DK1X
5
螺絲釘
Screws
5
螺絲釘
Screws
台座
4“R”
Stand base “R”
台座
4“L”
Stand base “L”
5
螺絲釘
Screws
5
螺絲釘
Screws
6
Soft cushion
6

-5-6
CT CT
初始安裝
第一次使用本顯示器時，請按照以下步驟逐一操作。視您的顯示器安裝與連接而定，可能不需要進行某些
步驟。

將交流電源線插入交流電源插座。
•將顯示器放在靠近交流電源插座的位置，以便電源插頭就近使用。

按下顯示器上的 (飛梭鍵)。
執行初始安裝。
•按照顯示器螢幕上的指示設置
設定。
束線帶
將整線器插入束線帶。
將束線帶扣 (1) 往內壓，
將束線帶 (2) 往外拉並
完全鬆開。
CT
中文
˙ 必須安裝台座，以防止顯示器跌落造成傷害。
˙
˙
˙
˙
˙
˙
˙
˙
˙
˙
˙
˙
˙
˙
˙
˙
˙
˙
˙
˙
˙
˙
清理—清理產品前，請從交流電源插座上拔下交流電源線。使用柔軟濕潤的布料來清理產品。
請勿使用液態清潔劑，氣溶膠清潔劑或沾染化學藥品的布料來清理, 因為此類材料可能會損壞產品。
水和潮濕 — 不要在近水之處使用本機，例如在靠近洗澡盆，洗臉盆，廚房洗滌槽，洗衣盆，游泳池等，也不要在潮濕的
地下室中使用。
請勿在本機之上放置花瓶或任何其他盛水的容器。
若有水滴濺到本機上，就可能引起火災或觸電。
不要將本機放置於不穩定的推車，台座，三腳架或桌面上。不穩固的基座可能會使本機掉落，導致嚴重的人身傷害以及
造成產品損壞。請僅使用本製造商所推薦或與本產品配套出售的推車，台座，三腳架，托架或桌子。將本機安裝與牆上
時，請務必遵照本製造商的指示。而且只可以使用本製造商所推薦的安裝器材。
將本機放置於推車上搬運時， 必須小心注意安全。急停，用力過度，地面不平等等，都會導致本機從推車上掉落。
通風 — 本機外殼上的散熱孔與其他開口處都是用於散熱通風。請勿堵塞這些散熱孔或開口處，通風散熱不良會使本機過
熱和/或縮短本機的使用壽命。請勿將本機置於臥室，沙發，地毯或其他類似物品上，因為這些物品會堵塞散熱通風孔。
本機之設計不適用於嵌入式安裝； 所以不要將本機置於像書櫃，機架等封閉之處，除非提供合適的通風或遵照本製造商
的指示安裝。
本機所用之液晶顯示器用玻璃製造的。因此，在受到強力撞擊或遭到尖銳物品刻劃時會破損。萬一液晶顯示器破碎，請
小心不要被破碎玻璃割傷。
熱源 —請勿讓本機接近熱源，如暖氣機，加熱器，爐灶或者其他任何會產生熱能的產品（包括廣大機在內）。
為防止發生火災，請勿將任何種類的蠟燭或火焰置于顯示器上或其附近。
為了防止火災或觸電的危險，請勿將交流電源線置于顯示器或其他重物下。
請勿在本機之上放置重物或攀爬於本機之上。這樣做可能導致本機傾倒而造成傷害。特別要注意附近的兒童和寵物。
液晶熒幕採用極高精度技術製造，有效像素達到 99.99% 以上。
0.01% 或以下的缺失像素，或者那些始終亮著的像素不是故障。
在搬運顯示器時的注意事項
在搬運顯示器時，切勿握持或施加壓力於顯示器上。 任何時候都必須由兩個人或多人用雙手搬運 —顯示器的每一側用
一雙手握住。
請勿長時間顯示靜止畫面，這可能會導致殘留影像。
請將本機安裝於能夠很容易地將交流電源線從交流電源插座和本機機背後的 AC INPUT（交流電源輸入）端子上撥出的地
方。
如果顯示器不是放置在平穩的地方，顯示器可能有掉落的危險。很多尤其對於兒童的傷害，可以通過採取簡單的預防措施
˙ 請勿將顯示器安裝在空調機下方或加濕器附近等會受到水滴影響的位置。
而避免，例如：
使用本顯示器製造商所推薦的櫥櫃或台座。
僅使用可以安全支撐顯示器的家具。
確保顯示器沒有外伸在支撐家具的邊緣。
在沒有錨固家具和顯示器於適合的支座的情況下，勿將顯示器放置在高的家具上（例如櫥櫃或書架 )。
請勿將顯示器放置在布料或其他放置在顯示器和支撐家具之間的物資上。
教導兒童有關攀爬家具以觸及顯示器或控制器的危險。
˙水滴掉落在顯示器上並進入其中可能會造成起火，電擊或故障。
˙建議您將顯示器安裝在距離冷氣出風口至少 1m 的位置。
重要的安全注意事項
•
註
本手冊中使用的插圖是根據4T-C50DL1X 。
注意
為避免電擊危險，切勿接觸連接了交流電的未絕緣零件或任何電線。
端子圖
顯示器 (背面)
※根據NCC低功率射頻器材技術規範3.8.2規定：
-取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性
及功能。
-低功率射頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得
繼續使用。前述合法通信，指依電信管理法規定作業之無線電通信。
-低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
電源及選單共用十字按鍵

CT
-7
CT
-8
2
觀看電子手冊
觀看內建操作手冊
內建操作指南顯示於螢幕上。您可以閱讀此裝
置的操作說明。
1按下 （首頁），顯示 HOME（首頁）
画面，然後按下 / / / 選擇
「設定」。
按下 / 選擇「應用程式」，按下
/ 選擇「手冊」，然後按下 確定。
將顯示內建操作手冊畫面。
2選擇目錄時，將顯示其頁面。
附錄
疑難排解
下述問題並非一定由於故障而引起。將顯示器送修之前，請再次檢查顯示器。
案方決解的能可題問
•沒有電源。 •檢查是否按下了遙控器上的 "電源"按鍵。
•AC電源線是否中斷連接？
•主電源是否被打開？
•遙控器無法運作。 •電池是否按極性（e、f) 放入？
•沒有影像。 •與其他組件的連接是否正確？
•沒有聲音。 •與其他組件的連接是否正確？
清除密碼
如果您忘記了密碼，請依照下列步驟來清除密碼。
1在 HOME（首頁）畫面中，選擇「設定」>「裝置偏好設定」>「關於」>「恢復原廠設定」，然後按下
確定 。
2顯示器重置後將恢復原廠設定，需重設密碼。
註
•以防萬一，請記下密碼並妥善保管。
設備上的符號
•此標誌表示產品在交流電壓下工作。
•此標誌表示 II 類或雙重絕緣電器，其中產品不需要電氣接地的安全連接。
1
4T-C65DL1X 4T-C65DK1X 4T-C50DK1X4T-C50DL1X
1118 g 720 g 273
1118 g 655 g 80
1462 g 920 g 300
1462 g 854 g 76
22.0 kg (23.0 kg) 11.0 kg (11.5 kg)
寬 g 高 g 深 (mm)
寬 g 高 g 深 (mm)
作為不斷改進政策的一部份，SHARP 保留改進產品而變更設計和規格的權利，恕不另行通知。以上性能規格的數值為產
品設備的標稱值。個別設備的相關數值可能略有差異。
安裝液晶顯示器要專業技術，因此必須由合格的維修人員進行。顧客不應自行嘗試安裝。SHARP 對由於安裝不當或安
裝造成的事故或傷害不承擔任何責任。
開始操作前，請詳細閱讀托架隨附的說明。
請勿在傾斜狀態下安裝/壁掛顯示器。
164 cm 126 cm）離距線角對斜（板面晶液
解析度 8,294,400 像素 (3840 g 2160)
音頻放大器 10 W g 2
端子
(僅供售後服務使用) 3.5 mm 插孔
HDMI 1 (eARC/ARC)
(輸入 1) HDMI (HDMI 輸入)，eARC/ARC
HDMI (HDMI 輸入) (輸入 2)
(輸入 3)
(輸入 4)
HDMI (HDMI 輸入)
HDMI 2
HDMI 3
HDMI (HDMI 輸入) HDMI 4
USB 1
AV IN
USB (DC5V 1.5A 輸出)
USB 2 USB (DC5V 1.5A 輸出)
LAN (乙太網絡)
(10/100 BASE-T) 網路連接器
輸出 耳機 ( 3.5 mm 立體聲)
額定電壓額定頻率 AC 110 V, 60 Hz
額定消耗電功率
145 W
0.6 W
123 W
0.6 W
223 W
0.6 W
208 W
0.6 W
待機
尺寸 不含台座
含台座
不含台座重量（含台座重量)
操作溫度 0°C 到 + 40°C
光學 S/PDIF 數位聲音輸出
(數位聲音輸出)
SERVICE ONLY
DIGITAL AUDIO
OUTPUT
音頻輸入，視訊輸入(影音輸入)
PAL / SECAM / NTSC 3.58 / NTSC 4.43 / PAL 60 視頻彩色系統
WIFI 協議 IEEE 802.11 a/b/g/n/ac 2T/2R 雙頻
WIFI 安全 WFA/WPA/WPA2
Bluetooth V2.1/3.0/4.2/5.0
為防止射頻干擾，配件電源線上有包含一個磁環，不可任意取下。
螢幕顯示語言 英文 / 簡体中文 / 繁體中文 / 阿拉伯語 / 法語 / 葡萄牙語 / 俄語 / 泰語 /
越南語 / 印尼語 / 馬來語
規
3840x2160@60Hz
3840x2160@60Hz
3840x2160@60Hz
3840x2160@60Hz
480p@60Hz

-9-10
Important Safety Precautions [ENGLISH
EN
]
•Stand base must be attached to prevent the Monitor set from falling down and cause injuries.
•Cleaning — Unplug the AC cord from the AC outlet before cleaning the product. Use a soft damp cloth to clean the
product. Do not use liquid cleaners, aerosol cleaners or chemical cloth to clean it, as such materials may damage the
product.
•Water and moisture — Do not use the product near water, such as bathtub, washbasin, kitchen sink, laundry tub,
swimming pool and in a wet basement.
•Do not place vases or any other water-filled containers on this product.
The water may spill onto the product causing fire or electric shock.
•Stand — Do not place the product on an unstable cart, stand, tripod or table. Doing so can cause the product to fall,
resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table
recommended by the manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the
manufacturer’s instructions. Use only the mounting hardware recommended by the manufacturer.
•When relocating the product placed on a cart, it must be moved with utmost care. Sudden stops, excessive force and
uneven floor surface can cause the product to fall from the cart.
•Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these
vents and openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not
place the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is
not designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless
proper ventilation is provided or the manufacturer’s instructions are followed.
•The LCD panel used in this product is made of glass. Therefore, it can break when the product is struck forcefully or
with a sharp object. If the LCD panel is broken, be careful not to be injured by broken glass.
•Heat sources — Keep the product away from heat sources such as radiators, heaters, stoves and other heat-generating
products (including amplifiers).
•To prevent fire, never place any type of candle or naked flames on the top or near the Monitor set.
•To prevent fire or shock hazard, do not place the AC power cord under the Monitor set or other heavy items.
•Do not place heavy objects on this product or stand on it. Doing so could cause injury if the product overturns. Take
special care near children and pets.
•The LCD panel is made with extremely high precision technology, and has 99.99% or more effective pixels.
The 0.01% or less missing pixels or those that are always lit is not a malfunction.
•Precautions when transporting the Monitor
When transporting the Monitor, never carry it by holding or otherwise putting pressure onto the display. Be sure to always
carry the Monitor by two people holding it with two hands — one hand on each side of the Monitor.
•Do not display a still picture for a long time, as this could cause an afterimage to remain.
•Install the product on the place where the AC cord can be unplugged easily from the AC outlet or from the AC INPUT
terminal on the rear of the product.
•If a Monitor is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many
injuries, particularly to children, can be avoided by taking simple precautions such as:
•Using cabinets or stands recommended by the manufacturer of the Monitor.
•Only using furniture that can safely support the Monitor.
•Ensuring the Monitor is not overhanging the edge of the supporting furniture.
•Not placing the Monitor on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture
and the Monitor to a suitable support.
•Not standing the Monitor on cloth or other materials placed between the Monitor and supporting furniture.
•Educating children about the dangers of climbing on furniture to reach the Monitor or its controls.
•Do not install the Monitor in a location in which it will be subject to water drops such as underneath an air conditioning unit
or in the vicinity of a humidifier.
•Water drops falling onto the Monitor and water entering inside it may result in fire, electric shock, or malfunctions.
•We recommend that you install the Monitor at least 1m away from the outlet of an air conditioner.
Initial installation
Terminal Diagram
Follow the steps below one by one when using the Monitor for the rst time. Some steps may not be
necessary depending on your Monitor installation and connection.

Plug the AC cord into the AC outlet.
• Place the Monitor close to the AC outlet, and keep the
power
Monitor (Rear)
plug within reach.
Run the initial installation.
• Follow the guide on the Monitor screen to set
the settings.

Press (JOG-KEY) on the Monitor.
Cable tie
Bundle the cables into
cable tie.
Press cable tie clip (1)
and pull out cable tie (2)
completely to release.
NOTE
• This drawings used throughout this manual are based
on the 4T-C50DL1X.
JOG-KEY

EN
-11
EN
-12
Viewing the Built-in Operation Manual
Displays the built-in operation manual on the
screen. You can read information about how to
use this device.
1Press (HOME) to display the HOME
screen, and then press / / / to
select “Settings”.
Press / to select “Apps”, press
/ to select “Manual”, and then press
確定 (ENTER).
This displays the built-in operation manual
screen.
2When you select contents, its page will be
displayed.
Appendix
Troubleshooting
The problems described below are not always caused by malfunctions. Check the Monitor again before having the
Monitor serviced.
noituloSelbissoPmelborP
• No power. • Check if you pressed 電源 (POWER) on the remote control unit.
• Is the AC cord disconnected?
• Has the power been turned on?
• Remote control unit does
not operate. • Are batteries inserted with polarity ( e, f) aligned?
• No picture. • Is connection to other components correct?
• No sound. • Is connection to other components correct?
Clearing the password
If you forget the password, clear the password using the following procedure.
1From the HOME screen, select “Settings” > “Device Preferences” > “About” > “Factory reset”, and then press
確定 (ENTER).
2When you perform a reset, the Monitor will be returned to the factory preset values, and you need to set the
password again.
NOTE
• As a precautionary measure, make a note of your password, and keep it in a safe place.
Viewing E-Manual
1
2
Symbols placed on equipment
• This mark indicates the product operates on AC Voltage.
• This mark indicates a class II or double insulated electrical appliance wherein the product does not
require a safety connection to electrical earth (ground).
Specifications
W x H x D (mm)
W x H x D (mm)
1462 g 854 g 76
1462 g 920 g 300
1118 g 655 g 80
1118 g 720 g 273
22.0 kg (23.0 kg) 11.0 kg (11.5 kg)
Model
Item 4T-C50DL1X 4T-C50DK1X4T-C65DL1X 4T-C65DK1X
164 cm mc621lenapDCL
Resolution 8,294,400 pixels (3840 g2160)
06LAP/34.4CSTN/85.3CSTN/MACES/LAPmetsysruolocoediV
Audio amplifier 10 W g2
Terminals
SERVICE ONLY 3.5 mm jack
HDMI 1 (eARC/ARC) HDMI (HDMI input), eARC/ARC
HDMI 2 HDMI (HDMI input)
HDMI 3 HDMI (HDMI input)
HDMI 4 HDMI (HDMI input)
AV IN AUDIO in, VIDEO in
USB 1 USB (DC5V 1.5A output)
USB 2 USB (DC5V 1.5A output)
LAN (10/100 BASE-T) Network connector
DIGITAL AUDIO
OUTPUT Optical S/PDIF digital audio output
OUTPUT Headphone ( 3.5 mm stereo)
egaugnalDSO
zH06,V011CAtnemeriuqerrewoP
0.6 W0.6 W
223 W
0.6 W
208 W
0.6 W
145 W 123 W
noitpmusnocrewoP
Standby
WIFI Protocole IEEE 802.11 a/b/g/n/ac 2T/2R Dual Band
WIFI Security WFA/WPA/WPA2
Bluetooth V2.1/3.0/4.2/5.0
Dimensions without stand
with stand
Weight without stand (with stand)
Operating temperature 0°C to +40°C
As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes
for product improvement without prior notice. The performance specification figures indicated are nominal values of
production units. There may be some deviations from these values in individual units.
CAUTION
Installing the Liquid Crystal Monitor requires special skill that should only be performed by qualified service
personnel. Customers should not attempt to do the work themselves. SHARP bears no responsibility for improper
mounting or mounting that results in accident or injury.
Carefully read the instructions that come with the bracket before beginning work.
Do not install / mount the Monitor with tilting condition.
English/Simplified Chinese/Traditional Chinese/Arabic/French/Portuguese/
Russian/Thai/Vietnamese/Indonesia/Malay
Ferrite Core is attached together with AC Cord for EMI improvement. Please do not dismantle for safety purpose.

EN
-13
EN
-14
Trademarks
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks
of Dolby Laboratories Licensing Corporation.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks
or registered trademarks of HDMI Licensing Administrator, Inc.
®.
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by SHARP Corporation is under license. Other trademarks and trade names are those of their respective
owners.
ANY USE OF THIS PRODUCT IN ANY MANNER OTHER THAN PERSONAL USE THAT COMPLIES WITH THE
MPEG-2 STANDARD FOR ENCODING VIDEO INFORMATION FOR PACKAGED MEDIA IS EXPRESSLY
PROHIBITED WITHOUT A LICENSE UNDER APPLICABLE PATENTS IN THE MPEG-2 PATENT PORTFOLIO,
WHICH LICENSE IS AVAILABLE FROM MPEG LA, LLC, 6312 S. Fiddlers Green Circle, Suite 400 E,
Greenwood Village, Colorado 80111 U.S.A.
THIS PRODUCT IS LICENSED UNDER THE VC-1 PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND
NON-COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE VC-1
STANDARD (“VC-1 VIDEO”) AND/OR (ii) DECODE VC-1 VIDEO THAT WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE VC-1 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C.
SEE HTTP://WWW.MPEGLA.COM
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL USE OF
A CONSUMER OR OTHER USES IN WHICH IT DOES NOT RECEIVE REMUNERATION TO (i) ENCODE VIDEO
IN COMPLIANCE WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS
ENCODED BY A CONSUMER ENGAGED IN A PERSONAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C.
SEE HTTP://WWW.MPEGLA.COM
THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE
WITH THE MPEG-4 VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG-4 VIDEO THAT WAS
ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS
OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG-4 VIDEO. NO LICENSE IS
GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION INCLUDING THAT
RELATING TO PROMOTIONAL, INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED
FROM MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM
Appendix
Unit : mm
4T-C65DL1X / 4T-C65DK1X
1462
76
36
1432
854
920
807
139 3 129
300
400531 531
200 541
100
79
Unit : mm
80
47
108
273
1118
1096
928
300 409409
720
617
655
200
122
1565
318
4T-C50DL1X / 4T-C50DK1X
壁掛孔距規格 / VESA SPEC
上/下側壁掛螺釘孔深度 /
UPPER/LOWER VESA SCREW DEPTH
上/下側壁掛螺釘規格 /
UPPER/LOWER VESA SCREW TYPE
200 x 300
12
M4
壁掛孔距規格 / VESA SPEC
上/下側壁掛螺釘孔深度 /
UPPER/LOWER VESA SCREW DEPTH
上/下側壁掛螺釘規格 /
UPPER/LOWER VESA SCREW TYPE
200 x 400
15
M6
輪廓圖/Dimensional Drawing
單位: 公釐 /
單位: 公釐 /

-15
設備名稱：液晶顯示器， 型號（型式）：4T-C65DL1X / 4T-C65DK1X / 4T-C50DL1X / 4T-C50DK1X
Equipment name Type designation (Type)
單元 Unit
限用物質及其化學符號
Restricted substances and its chemical symbols
鉛Lead
(Pb)
汞Mercury
(Hg)
鎘Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr+6)
多溴聯苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl ethers
(PBDE)
○○○○○○
○○○○○○
○○○○○○
電路板
後殼
面板 -○○○○○
電源線
其他線材 -○○○○○
配件 (例：遙控器等)
-○○○○○
備考1.〝超出0.1 wt %〞及〝超出0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準值。
Note 1: “Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted
substance exceeds the reference percentage value of presence condition.
備考2. “○” 係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2: “○” indicates that the percentage content of the restricted substance does not exceed the percentage of
reference value of presence.
備考3. “–” 係指該項限用物質為排除項目。
Note 3: The “–” indicates that the restricted substance corresponds to the exemption.
Printed Circuit Board
Rear Cabinet
Panel
Electric current wires
Other Wiring Material
Accessories (Example:
Remote control etc.）
/Restricted substances and its chemical symbols
限用物質及其化學符號
SHARP CORPORATION
SHARP CORPORATION
16 7
/
/
/
