SERVICE MANUAL
Intheinterestsofuser-safety(Requiredbysafetyregulationsinsomecountries)thesetshouldberestoredtoitsoriginal
condition and only parts identical to those specified be used.
LC-121M2E
LC-150M2E
LC-121M2E
LC-150M2E
SHARP CORPORATION
CONTENTS Page
1. IMPORTANT SERVICE SAFETY PRECAUTION .................................................................................... 2
2. SPECIFICATIONS ................................................................................................................................... 3
3. PART NAMES.......................................................................................................................................... 4
4. DISASSEMBLY OF THE SET.................................................................................................................. 5
5. ADJUSTING PROCEDURE OF EACH SECTION ................................................................................... 7
6. INTEGRATED CIRCUIT TERMINAL ARRANGEMENTS ........................................................................18
7. TROUBLE SHOOTING ............................................................................................................................ 23
8. CHASSIS LAYOUT .................................................................................................................................. 26
9. SCHEMATIC DIAGRAM .......................................................................................................................... 28
10. BLOCK DIAGRAM ................................................................................................................................... 43
11. PRINTED WIRING BOARD ASSEMBLIES .............................................................................................. 45
12. REPLACEMENT PARTS LIST ................................................................................................................. 51
13. PACKING OF THE SET ........................................................................................................................... 63
MODELS
LCD AV MONITOR
The component parts of this model are partially different
depending on their suffix symbols. Before servicing the
units, be sure to check the suffix symbol on the model
label that is applied on the bottom side of the unit.
Suffix symbol ( , K , X )
MODELS LC-121M2E/150M2E
SERVICE MANUAL LCD AV MONITOR

2
LC-121M2E
LC-150M2E LC-121M2E
LC-150M2E
1. IMPORTANT SERVICE SAFETY PRECAUTION
æ Service work should be perfomed only by qualified service technicians who are
thoroughly familiar with all safety checks and servicing guidelines which follow:
WARNING
1. For continued safety, no modification of any
circuit should be attempted.
2. Disconnect AC power before servicing.
CAUTION
FOR CONTINUED PROTECTION
AGAINST A RISK OF FIRE REPLACE
ONLY WITH SAME TYPE FUSE. F701 (1.25A,
250V), F702 (2A, 250V), F703 (1.25A, 250V)
FUSE.
BEFORE RETURNING THE MONITOR
(Fire & Shock Hazard)
Before returning the monitor to the user,
perform the following safety checks:
1. Inspect all lead dress to make certain that leads
are not pinched, and check that hardware is not
lodged between the chassis and other metal
parts in the monitor.
2. Inspect all protective devices such as non-me-
talliccontrolknobs,insulationmaterials,cabinet
backs, adjustment and compartment covers or
shields, isolation resistor-capacitor networks,
mechanical insulators, etc.
3. Tobesurethatnoshockhazardexists,checkfor
current in the following manner.
• PlugtheACAdaptordirectlyintoa 100~240volt
AC outlet, and connect the DC power cable into
the monitor's DC jack. (Do not use an isolation
transformer for this test).
• Using two clip leads, connect a 1.5k ohm, 10
watt resistor paralleled by a 0.15µF capacitor in
series with all exposed metal cabinet parts and
aknownearthground,suchaselectricalconduit
orelectricalgroundconnectedtoanearthground.
• Use an AC voltmeter having with 5000 ohm per
volt, or higher, sensitivity or measure the AC
voltage drop across the resisor.
• Connect the resistor connection to all exposed
metal parts having a return path to the chassis
(antenna, metal cabinet, screw heads, knobs
andcontrolshafts, escutcheon, etc.) and meas-
ure the AC voltage drop across the resistor.
All checks must be repeated with the AC Adap-
tor plug connection reversed.(If necessary, a
nonpolarizedadaptorplugmustbeusedonlyfor
the purpose of completing these checks.)
A V
Any reading of 0.3V RMS(this corresponds
to 0.2 milliamp. AC.) or more is excessive and
indicates a potential shock hazard which must
be corrected before returning the monitor to
the owner.
SAFETY NOTICE
Many electrical and mechanical parts in LCD monitor
have special safety-related characteristics.
These characteristics are often not evident from visual
inspection, nor can protection afforded by them be nec-
essarily increased by using replacement components
rated for higher voltage, wattage, etc.
Replacement parts which have these special safety
characteristics are identified in this manual; electrical
components having such features are identified by
“å”and shadedareas inthe ReplacementParts Lists
and Schematic Diagrams .
For continued protection, replacement parts must be
identical to those used in the original circuit.
The use of a substitute replacement parts which do not
have the same safety characteristics as the factory
recommended replacement parts shown in this service
manual, may create shock. fire. or other hazards.
TO EXPOSED
METAL PARTS CONNECT TO
KNOWN EARTH
GROUND
DVM
AC SCALE
1.5k ohms.
10W
0.15 µF
TEST PROBE

3
LC-121M2E
LC-150M2E
LC-121M2E
LC-150M2E
2. SPECIFICATIONS
Type: LCD display unit (LCD color AV monitor)
Size: 12.1" type (184.3 mm ×245.8 mm) (LC-121M2E)
15" type (219.9 mm ×305.3 mm) (LC-150M2E)
Display System: Transmitting type TN liquid crystal panel.
Driving System: TFT (Thin Film Transistor) active matrix system
Number of Picture Elements: 921,600 (480 (V) ×640 (H) ×3 (RBG) )
Speaker Output: 0.7 W ×2 (Front)
2 W ×1 (Rear)
Speaker: 30 mm ×40 mm (Elliptic) ×2 (Front)
65 mm (Round) ×1 (Rear)
Light Source: Internal Light (Built-in fluorescent lamp)
Connected Terminals: Input: DC12V, VHS, S-VHS, Audio and DVD
Output: VHS, S-VHS, Audio and Headphone
Power Source: AC 100~240·50/60Hz (Connected to AC Adapter)
Power Consumption (Approx.): 12.1" type 33 W (Connected to AC Adapter) (LC-121M2E)
15" type 35 W (Connected to AC Adapter) (LC-150M2E)
Operating Temparature: –10°C~40°C
12.1" type Dimensions(LC-121M2E): 297.4 mm (W) ×264.6 mm (H) ×87 mm (D) (Includes Set Stand)
297.4 mm (W) ×264.6 mm (H) ×62.5 mm (D) (Not Include Set Stand)
15" type Dimensions(LC-150M2E): 357.7 mm (W) ×309.2 mm (H) ×87 mm (D) (Includes Set Stand)
357.7 mm (W) ×309.2 mm (H) ×62.5 mm (D) (Not Include Set Stand)
Weight (Approx.): 12.1" type 2.9 kg (LC-121M2E)
15" type 3.6 kg (LC-150M2E)
Accessories: Operation Manual, Guarantee Card, AC Adapter, Remote Control,
Set Stand Mounting Screws, Wall mounting set angle and Batteries (AAA size
x 2)
Specifications are subject to changed without prior notice.

4
LC-121M2E
LC-150M2E LC-121M2E
LC-150M2E
3. PART NAMES

5
LC-121M2E
LC-150M2E
LC-121M2E
LC-150M2E
1
Push Cabinet B
Cabinet A b WH
Cabinet A
12 type CCABA2338CE01 GCABA2338CEKA
15 type CCABA2343CE01 GCABA2343CEKA
Cabinet B
12 type
CCABB2246CE01 GCABB2246CEKA (LC-121M2E/K)
CCABB2246CE03 GCABB2246CEKA (LC-121M2X)
15 type
CCABB2249CE01 GCABB2249CEKA (LC-150M2E/K)
CCABB2249CE03 GCABB2249CEKA (LC-150M2X)
Cable
a
a
a
a
a
a
a
1
4
8
5
r
79
e
0q
w
7
t
u
y
u
i
2
6
3
Cabinet B
c WH
4. DISASSEMBLY OFTHE SET
1. Remove four screws (1).
2. Opening six claws ( a ), release the cabinet B.
Remove the wire holder ( b ) and disconnect each
connectors (2~6).
Remove the cabinet B.
3. Remove two screws (7) which mounting the LCD
display unit.
4. Remove soldering of copper-foil tape (8) .
5. Disconnect each connectors (9~e) from the LCD
display unit.
6. Remove the cabinet A.
7. Remove four screws (r) which mounting the main
PWB unit.
8. Removeone screw(t)and removetheremote control
receptor PWB.
9. Remove five screws (y) and GND cable.
10.Removetenscrews(u)andremovetheterminalcover.
11.Remove two screws (i) and remove the switch PWB.

6
LC-121M2E
LC-150M2E LC-121M2E
LC-150M2E
12.Remove one screw (o) and remove the Sosu shield
angle.
13.Remove four screws (p) which mounting the LCD
display unit.
14.Spread bites of the LCD unit (a) out to be off from
claws.
15.Remove the Lamp unit (s).
o
Holder
LHLDZ2082CEKZ (LC-121M2E)
LHLDZ2085CEKZ (LC-150M2E)
p
p
a
s

7
LC-121M2E
LC-150M2E
LC-121M2E
LC-150M2E
The best adjustment is made before shipping. If any position deviation is found or after part replace is performed, adjust
as follows.
5-1. Preparation for adjustment
(1)Use the exclusive-use AC adapter or stable DC power supply.
AC adapter: UADP-0181CEZZ
DC power supply: 12 ±0.5V
5-2. Special mode setting procedure
(1)After initialization of E2PROM the mode is changed to the adjustment mode.
[Procedure]
Connect TP2007 and TP2008 to GND, and turn on the power.
[Description]
• The initialization of microcomputer is as follows.
• AV position, DAC data, G/A data, and video chroma data adjustment values are taken as defaults.
(2)Change to adjustment mode
[Procedure]
Short-circuit TP2007 to GND, and turn on the power.
Or short-circuit TP2008 to GND, and turn on the power.
Orholdingdownthe[AVINPUT]keyand[MENU]key,turnonthemainpower,andsimultaneouslypressthe(inspection
process) [SELECT "] key and [VOL– ] key to change the mode to the adjustment mode.
[Description]
The manual adjustment or adjustment through communication with the automatic machine is performed.
(3)Inspection mode
[Procedure]
Holding down the [AV INPUT] key and [MENU] key, turn on the power.
[Description]
• In the ordinary menu select “PICTURE” with the [SELECT] key, and decide with the [VOL] key. Then select
“CONTRAST”, “TINT (only NTSC)”, “COLOR”, “BLACK LEVEL”, “SHARPNESS”, “RED” , and “BLUE” with the
[SELECT] key, and decide with the [VOL] key. After that, adjust values with the [VOL] key.
•Intheordinarymenuselect“SOUND”withthe[SELECT]key,anddecidewiththe[VOL]key.Then,select“TREBLE”,
“BASS”,and“BALANCE”withthe[SELECT]key,anddecidewiththe[VOL]key.Afterthatadjustvalueswiththe[VOL]
key.
• VOLUME, CONTRAST, TINT (only NTSC), COLOR, BLACK LEVEL, SHARPNESS, RED, BLUE, TREBLE, BASS,
and BALANCE change as follows.
(4)Shipping setting mode
[Procedure]
Holdingdownthe [AV INPUT] key and [MENU] key, turnonthemain power, and simultaneously press the (inspection
process) [SELECT '] key and [VOL+] key to change the mode to the adjustment mode.
[Description]
User adjustment and other values are taken as defaults.
If AV1 is indicated as SETTING COMPLETE, setting has been completed.
ûMin.ÛûCenterÛûMax.Û
5. ADJUSTING PROCEDURE OF EACH SECTION

8
LC-121M2E
LC-150M2E LC-121M2E
LC-150M2E
5-3. Cancel of special mode
Turn off the main unit power.
5-4. Preparation adjustment
(1)Use the exclusive-use AC adapter or stable DC power supply.
AC adapter: UADP-0181CEN1
DC power supply: 12 ±0.5V
5-5. OSD menu indication and items in case of manual adjustment
Adjusting range
Page Item Minimum Maximum Initial Remarks
1 + B – ADJ 0 255 128
MODEL M2H F2/M2H/M2U/M2E
TUNER OFF 1/2/OFF
AUDIO MULTIPLEX OFF OFF/ON
BOOSTER 0 0/1/2/3
SYSTEM AUTO N358/N443/PAL/PAL-M/SECAM/AUTO
COPY GUARD ON OFF/ON
CH MEMORY OFF OFF/12/16
SECAM ON OFF/ON
MULTI LANG. OFF OFF/ON
TIMER OFF OFF/ON
The Ver. No. will be displayed on the lowest part of lines.
2 TA1276 DATA ~~~~
COM 0 255 128
NTSC/PALM OSC 0 255 128
N358 BRIGHTNESS 0 255 170
R CUTOFF 0 255 80
B CUTOFF 0 255 80
N358UNICOLOR 0 127 80
R DRIVE 0 127 64
B DRIVE 0 127 64
N358SCOLOR 0 31 25
N358TINT 0 127 74
DATA COPY WAIT WAIT/SEND
3 N358 R-Y PHASE 0 3 2
N358 B-Y PHASE 0 3 1
N443 BRIGHTNESS 0 255 170
N443 UNICOLOR 0 127 80
N443 SCOLOR 0 31 25
N443TINT 0 127 74
PAL-M BRIGHTNESS 0 255 170
PAL-M UNICOLOR 0 127 80
PAL-M SCOLOR 0 31 25
PAL-M TINT 0 127 74
R-ADJ 0 255 128
One blank line.

9
LC-121M2E
LC-150M2E
LC-121M2E
LC-150M2E
4 PAL/SECAM OSC 0 255 128
PAL BRIGHTNESS 0 255 170
PAL UNICOLOR 0 127 80
PAL SCOLOR 0 31 25
PAL TINT 0 127 74
BELL F0 0 255 120
B-Y BLACK LEVEL 0 15 8
R-Y BLACK LEVEL 0 15 8
SECAM BRIGHTNESS 0 255 170
SECAM UNICOLOR 0 127 80
SECAM COLOR 0 127 75
SECAM TINT 0 127 74
5 DVD NT BRIGHTNESS 0 255 170
DVD NT UNICOLOR 0 127 80
DVD NT COLOR 0 127 75
DVD NT TINT 0 127 74
DVD NT R-YPHASE 0 3 2
DVD NT B-YPHASE 0 3 3
DVD PAL BRIGHTNESS 0 255 170
DVD PAL UNICOLOR 0 127 80
DVD PAL COLOR 0 127 75
DVD PAL TINT 0 127 74
I2C DATA 000000
I2C DATA WAIT WAIT/SEND
6 TEST PATTERN OFF ON/OFF
G/A DATA 0000
G/A DATA WAIT WAIT/SEND
DIGITAL SYNC SEP. 0 FF 87 Fixed
AV NTSC H 0 7F 18 Fixed
DVD NTSC H 0 7F 1C Fixed
AV PAL H 0 7F 11 Fixed
DVD PAL H 0 7F 15 Fixed
AV SECAM H 0 7F 0E Fixed
NT/PALM V 1 1F 0C Fixed
PAL V 1 1F 0B Fixed
SECAM V 1 1F 0B Fixed
7 N443 R-YPHASE 0 3 2 Fixed
N443 B-YPHASE 0 3 1 Fixed
PAL R-YPHASE 0 3 2 Fixed
PAL B-YPHASE 0 3 1 Fixed
PAL-M R-YPHASE 0 3 2 Fixed
PAL-M B-YPHASE 0 3 1 Fixed
SECAM R-YPHASE 0 3 2 Fixed
SECAM B-YPHASE 0 3 1 Fixed
DVD PAL R-YPHASE 0 3 2 Fixed
DVD PAL B-YPHASE 0 3 1 Fixed
COLOR 0 127 60 Fixed
SCONT 0 31 18 Fixed

10
LC-121M2E
LC-150M2E LC-121M2E
LC-150M2E
5-6. Service Adjusting
5-6-1. Basic Adjustment
Adjustment Adjusting conditions Adjusting method
1 +B Adjustment 1. Connect the DC voltmeter to 1. Adjust +B-ADJ to 5.1V ±0.05V.
TP1104 ( DAC 9ch )
2 Model setup 1. Make sure that M2H has been set. When M2H is selected, the item
(Not setting M2E) settings are as follows.
TUNER OFF
AUDIO MULTIPLEX OFF
BOOSTER 0
SYSTEM AUTO
COPY GUARD ON
CH MEMORY OFF
SECAM ON
MULTI LANG. OFF
TIMER OFF
3 Counter-bias adjustment 1. Set the AV1 mode to set signal 1. Adjust COM so as to minimize the
noninput state. waveform peak-peak.
2. Fit the specified adjusting instrument (DAC7ch)
to the screen center.
3. Observe the adjusting instrument
output on the oscilloscope.
4 NTSC / PAL-MOSC 1. Input the monoscope pattern of 1. Adjust NTSC/PALM OSC so as to
adjustment NTSC into AV1. get the normal screen.
(DAC8ch)
8 DAC 2 1ch 0 255 0 Fixed
DAC 2 2ch 0 255 0 Fixed
DAC 2 3ch 0 255 0 Fixed
DAC 2 4ch 0 255 0 Fixed
DAC 2 5ch 0 255 0 Fixed
DAC 2 6ch 0 255 0 Fixed
DAC 2 7ch 0 255 0 Fixed
DAC 2 8ch 0 255 0 Fixed
DAC 2 9ch 0 255 0 Fixed
DAC 2 10ch 0 255 0 Fixed
DAC 2 11ch 0 255 0 Fixed
DAC 2 12ch 0 255 0 Fixed

11
LC-121M2E
LC-150M2E
LC-121M2E
LC-150M2E
5-6-2. AV input Adjustment
Adjustment Adjustment conditions Adjustment method
1 Brightness adjustment 1. Input the standard colour bar signal 1. Adjust N358 BRIGHTNESS, and
(N358) (the same pattern as that of JPN-8CH) adjust the black level of G output so
of N358 into AV1. as to get DC 1.5±0.05V.
2. Connect the oscilloscope to TP821
(IC803, pin7, G output).
2 R-cut off adjustment 1. Input the standard colour bar signal 1. Adjust R CUTOFF so as to equalize
(the same pattern as that of JPN-8CH) the black levels of green and red.
of N358 into AV1.
2. Connect the oscilloscope to TP821
(IC803, pin7, G output).
3. Connect the oscilloscope to TP819
(IC803, pin1, R output).
3 B-cut off adjustment 1. Input the standard colour bar signal 1. Adjust B CUTOFF so as to equalize
(the same pattern as that of JPN-8CH) the black levels of green and blue.
of N358 into AV1.
2. Connect the oscilloscope to TP821
(IC803, pin7, G output).
3. Connect the oscilloscope to TP820
(IC803, pin8, B output).
4 Unicolor adjustment 1. Input the standard colour bar signal 1. Adjust N358UNICOLOR, and
(N358) (the same pattern as that of JPN- adjust so as to get 100% white-
8CH) of N358 into AV1. black level video component equal
2. Connect the oscilloscope to TP821 to 2.3±0.05Vp-p.
(IC803, pin7, G output).
5 R DRIVE adjustment 1. Input the standard colour bar signal 1. Adjust so as to get 100% white level
(the same pattern as that of JPN- identical with that of green.
8CH) of N358 into AV1.
2. Connect CH1 of oscilloscope to
TP821 (G output).
3. Connect CH2 of oscilloscope to
TP819 (R output).

12
LC-121M2E
LC-150M2E LC-121M2E
LC-150M2E
6 B DRIVE adjustment 1. Input the standard colour bar signal 1. Adjust so as to get 100% white level
(the same pattern as that of JPN- identical with that of green.
8CH) of N358 into AV1.
2. Connect CH1 of oscilloscope to
TP821 (G output).
3. Connect CH2 of oscilloscope to
TP820 (B output).
7 Colour level adjustment 1. Input the standard colour bar signal Adjust N358 SCOLOR so as to get the
(N358) (the same pattern as that of JPN- colour bar signal blue amplitude
8CH) of N358 into AV1. (black level - peak level) equal to 2.0V
2. Connect the oscilloscope to TP820 ±0.05Vp-p.
(B output).
8 Tint adjustment 1. Input the standard colour bar signal 1. Adjust N358TINT so as to get the
(N358) (the same pattern as that of JPN- colour bar signal magenta amplitude
8CH) of N358 into AV1. (black level-peak level) equal to 1.7V
2. Connect the oscilloscope to TP820 ±0.05Vp-p.
(B output).
9 N443/PAL-M adjustment 1. Position the cursor on DATA COPY 1. The indication changes from WAIT
and press VOL key. to SEND, and after the lapse of one
second WAIT is restored. Thus, N443,
PAL-M adjustment is completed.
10 4V adjustment 1. Connect the DC voltmeter to TP1110 1. Adjust R-ADJ to 4.0V ±0.05V.
(DAC 6ch)
11 PAL/SECAM OSC 1. Input the monoscope pattern of PAL 1. Adjust PAL/SECAM OSC so as to
adjustment into AV1. get the normal screen.
(DAC8ch)

13
LC-121M2E
LC-150M2E
LC-121M2E
LC-150M2E
12 Brightness adjustment 1. Input the standard colour bar signal 1. Adjust PAL BRIGHTNESS, and
(PAL) of PAL into AV1. adjust the black level of G output
2. Connect oscilloscope to TP821 so as to get DC 1.5±0.05V.
(IC803, pin7, G output).
13 Unicolor adjustment 1. Input the standard colour bar signal 1. Adjust PAL UNICOLOR, and adjust
(PAL) of PAL into AV1. so as to get 100% white-black level
2. Connect oscilloscope to TP821 video component equal to 2.3±0.05
(IC803, pin7 , G output ). Vp-p.
14 Colour level adjustment 1. Input the standard colour bar signal Adjust PAL SCOLOR so as to get the
(PAL) (the same pattern as that of E-12CH) colour bar signal blue amplitude
of PAL into AV1. (black level - peak level) equal to 2.0V
2. Connect the oscilloscope to TP820 ±0.05Vp-p.
(B output).
15 Tint adjustment 1. Input the standard colour bar signal 1. Adjust PAL TINT so as to get the
(PAL) (the same pattern as that of E-12CH) colour bar signal magenta amplitude
of PAL into AV1. (black level-peak level) equal to 1.7V
2. Connect the oscilloscope to TP820 ±0.05Vp-p.
(B output).

14
LC-121M2E
LC-150M2E LC-121M2E
LC-150M2E
16 BELL f0 adjustment 1. Connect the oscilloscope to 1. Adjust BELL f0 so as to minimize the
TP2851. a-level.
17 Brightness adjustment 1. Input the standard colour bar signal 1. Adjust SECAM BRIGHTNESS, and
(SECAM) (the same pattern as that of E-10CH) adjust the black level of G output to
of SECAM into AV1. DC 1.5±0.05V.
2. Connect oscilloscope to TP821
(IC803, pin7, G output).
18 Unicolor adjustment 1. Input the standard colour bar signal 1. Adjust SECAM UNICOLOR, and
(SECAM) (the same pattern as that of E-10CH) adjust so as to get 100% white-black
of SECAM into AV1. level video component equal to 2.3±
2. Connect oscilloscope to TP821 0.05Vp-p.
(IC803, pin7, G output ).
19 Colour level adjustment 1. Input the standard colour bar signal Adjust SECAM COLOR so as to get
(SECAM) (the same pattern as that of E-10CH) the colour bar signal blue amplitude
of SECAM into AV1. (black level - peak level) equal to 2.0V
2. Connect the oscilloscope to TP820 ±0.05Vp-p.
(B output).
20 Tint adjustment 1. Input the standard colour bar signal 1. Adjust SECAM TINT so as to get the
(SECAM) (the same pattern as that of E-10CH) colour bar signal magenta amplitude
of SECAM into AV1. (black level-peak level) equal to 1.7V
2. Connect the oscilloscope to TP820 ±0.05Vp-p.
(B output).

15
LC-121M2E
LC-150M2E
LC-121M2E
LC-150M2E
5-6-3. Component input Adjustment
Adjustment Adjusting conditions Adjusting method
1 Brightness adjustment 1. From SG, input the 100% white colour Adjust DVD NT BRIGHTNESS, and
(NTSC) bar signal of NTSC into conponent adjust the black level of G output so
terminal. as to get DC 1.5±0.05V.
2. Connect oscilloscope to TP821
(IC803, pin7, G output).
2 Unicolor adjustment 1.From SG, input the 100% white colour Adjust DVD NT UNICOLOR, and
(NTSC) bar signal of NTSC into conponent adjust so as to get 100% white-
terminal. black level video component equal
2. Connect oscilloscope to TP820 to 2.3±0.05Vp-p.
(IC803, pin8).
3 Colour level adjustment 1.From SG, input the 100% white colour Adjust DVD NT COLOR so as to get
(NTSC) bar signal of NTSC into conponent the colour bar signal blue amplitude
terminal. (black level - peak level) equal to
2. Connect the oscilloscope to TP820 2.8V±0.05Vp-p.
(B output).
4 Tint adjustment 1.From SG, input the 100% white colour Adjust DVD NT TINT so as to get the
(NTSC) bar signal of NTSC into conponent colour bar signal magenta amplitude
terminal. (black level - peak level) equal to 2.3V
2. Connect the oscilloscope to TP820 ±0.05Vp-p.
(B output).

16
LC-121M2E
LC-150M2E LC-121M2E
LC-150M2E
5 Brightness adjustment 1. From SG, input the 100% white colour Adjust DVD PAL BRIGHTNESS, and
(PAL) bar signal of PAL into conponent adjust the black level of G output so
terminal. as to get DC 1.5±0.05V.
2. Connect oscilloscope to TP821
(IC803, pin7, G output).
6 Unicolor adjustment 1.From SG, input the 100% white colour Adjust DVD PAL UNICOLOR, and
(PAL) bar signal of PAL into conponent adjust so as to get 100% white-
terminal. black level video component equal
2. Connect oscilloscope to TP820 to 2.3±0.05Vp-p.
(IC803, pin8, B output).
7 Colour level adjustment 1.From SG, input the 100% white colour Adjust DVD PAL COLOR so as to get
(PAL) bar signal of PAL into conponent the colour bar signal blue amplitude
terminal. (black level - peak level) equal to
2. Connect the oscilloscope to TP820 2.8V±0.05Vp-p.
(B output).
8 Tint adjustment 1. From SG, input the 100% white colour Adjust DVD PAL TINT so as to get
(PAL) bar signal of PAL into conponent the colour bar signal magenta amplitude
terminal. (black level - peak level) equal to
2. Connect the oscilloscope to TP820 2.3V±0.05Vp-p.
(B output).

17
LC-121M2E
LC-150M2E
LC-121M2E
LC-150M2E
5-7. Shipping setting
(1)[Procedure]
Holdingdownthe[AVINPUT]keyand [MENU] key, turn on the main power, and simultaneously press the (inspection
process) [SELECT '] key and [VOL+] key to change the mode to the adjustment mode.
(2)[Indication]
AV1 is indicated as SETTING COMPLETE.
(3)[Description]
Mode is memorized as SETTING COMPLETE.
Menu setting descriptions are as follows.
VOLUME 30
CONTRAST 30 (AV1 / AV2 / COMPONENT)
TINT 0 (AV1 / AV2 / COMPONENT) (ONLY NTSC)
COLOUR 0 (AV1 / AV2 / COMPONENT)
SHARPNESS 0 (AV1 / AV2 / COMPONENT)
RED 0 (AV1 / AV2 / COMPONENT)
BLUE 0 (AV1 / AV2 / COMPONENT)
COLOUR SYSTEM AUTO (AV1 / AV2 / COMPONENT)
TREBLE 0
BASS 0
BALANCE 0
BRIGHTNESS BRIGHT
UPSIDE NORMAL
RIGHT / LEFT NORMAL
AV2 IN / OUT IN
AV1
SETTING COMPLETE

18
LC-121M2E
LC-150M2E LC-121M2E
LC-150M2E
6. INTEGRATED CIRCUITTERMINAL ARRANGEMENTS
1. IC2001 (QFP, 80pins)
Terminal No. Terminal name I/O Function
1 N. C –
2 N. C –
3 KEY3 I Key input 3
4 KEY4 I Key input 4
5 H PDET I Headphon input pickup
6 M O Audio selection 1
7 S O Audio selection 2
8 MONO O Forced monophonic
9 FS MUT O Front speaker MUTE output
10 RS MUT O Rear speaker MUTE output
11 N. C –
12 N. C –
13 CSYNC I Composite sync signal input
14 IF AGC I IFAGC input
15 PLCS O TV PLL chip select output
16 MRDY I I2C bus opening/connection selection input
17 PLLD I TV-PLL lock signal input
18 LMUTE O Lineout-Mute output
19 SCLK I/O Serial clock signal
20 SOUT O Serial data output
21 AFT I AFT voltage input
22 AGC I AGC input voltage
23 SCL I/O I2C bus serial clock line
24 SDA I/O I2C bus serial data line
25 N. C –
26 N. C –
27 CNV s s GND connection
28 φO Timing output
29 RESET I Change to “Reset mode” in “L” state
30 Xin I Microcomputer oscillator connection
31 Xout O Microcomputer oscillator connection
32 V s s I GND
33 PSW I Power switch input
34 POW O DC/DC control output
35 COCS O G/A chip selection output
36 DACS O D/A chip selection output
37 BOOST O Booster selection output
38 BOOLV O Booster level selection output
39 N. C –
40 N. C –
41 DA2CS O D/A 2 chip selection output
42 AV1/AV2 O Analog SW selection 1
43 AV/S O Analog SW selection 2
44 Y/COM O Analog SW selection 3
45 IN/OUT O Analog SW selection 4
46 REQ O “H” in [ADJUSTMENT] mode, “L” in other modes.
47 Empty I
48 STB O Micro computer power off output
49 SECAM O “H” in SECAM mode, “L” in other modes.

19
LC-121M2E
LC-150M2E
LC-121M2E
LC-150M2E
Terminal No. Terminal name I/O Function
50 PAL O “H” in PAL mode, “L” in other modes.
51 N. C –
52 N. C –
53 N. C –
54 SAFE I Parking input
55 Empty I
56 Empty I
57 Empty I
58 Empty I
59 Empty I
60 Empty I
61 N. C I
62 BLK OSD blanking output
63 N. C I
64 N. C –
65 N. C –
66 BOUT O B signal output
67 GOUT O G signal output
68 ROUT O R signal output
69 Vsync I OSD virtical sync signal input
70 Hsync I OSD horizontal sync signal input
71 N. C –
72 V c c I Positive voltage power terminal
73 N. C –
74 OSC1 OSD clock
75 OSC2 OSD clock
76 N. C –
77 KEY 1 I Key input1
78 KEY 2 I Key input2
79 IREM I Ir Remotecontrol input
80 ST/MT I Broadcast mode input

20
LC-121M2E
LC-150M2E LC-121M2E
LC-150M2E
2. IC1201 (QFP, 128pins)
Terminal No. Voltage I/O Signal name Function
1 5.0V I OSD_BK OSD Blanking input
2 5.0V I OSD_R OSD R input
3 5.0V I OSD_G OSD G input
4 5.0V I OSD_B OSD B input
5 5.0V O OSDVD OSD V output
6 5.0V O OSDHD OSD H output
7 5.0V O OSDCK OSD clock output
8 5.0V O VCIHD Horizontal sync output(VCI)
9 5.0V GND
10 5.0V VCC
11 5.0V O OFL PWM output (Inverter)
12 5.0V I MP_DA 3-wire serial data input
13 5.0V I MP_CK 3-wire serial clock input
14 5.0V I MP_CS 3-wire serial chip selection input
15 5.0V I TVAV Copy guard ON/OFF input
16 5.0V I FREE Inside/outside sync selection input
17 5.0V I CSYNC Composit signal input
18 5.0V O PDP PLL control signal output
19 5.0V GND
20 5.0V I OSCI PLL ocsillation input
21 5.0V O OSCO PLL ocsillation output
22 5.0V VCC
23 5.0V GND
24 5.0V O OHSYN Sync separation output
25 5.0V O DVDO Digital sync separation output
26 5.0V I VSYN Virtical sync signal input
27 5.0V I GST Reset input
28 5.0V GND
29 5.0V O REV Graduation power control signal output 1
30 5.0V O REVV0 Graduation power control signal output 2
31 5.0V O GSP1 Gate driver controll signal output 1
32 5.0V O GCK Gate driver controll signal output 2
33 3.3V GND
34 3.3V O OOR7 R output 7 (MSB)
35 3.3V O OOR6 R output 6
36 3.3V O OOR5 R output 5
37 3.3V O OOR4 R output 4
38 3.3V O OOR3 R output 3
39 3.3V O OOR2 R output 2
40 3.3V O OOR1 R output 1
41 3.3V O OOR0 R output 0 (LSB)
42 3.3V GND
43 3.3V O OOG7 G output 7 (MSB)
44 3.3V O OOG6 G output 6
45 3.3V O OOG5 G output 5
46 3.3V O OOG4 G output 4
47 3.3V O OOG3 G output 3
48 3.3V O OOG2 G output 2
49 3.3V GND
50 3.3V VCC
