Sharp Aquos LB-T462U User manual

Commercial-Grade HDTV LED Displays
LBT462U 46" class (45-63/64" diagonal) widescreen
LBT422U 42" class (42" diagonal) widescreen
Slim,Sleek and Energy Efficient

Model Number LBT462U LBT422U
Installation Landscape
LCD Panel 46" class (45-63/64" diagonal) widescreen, 42" class (42" diagonal) widescreen,
TFT LCD with anti-glare coating TFT LCD with anti-glare coating
Max. Resolution 1,920 x 1,080 pixels
Max. Display Colours (approx.) 1,064 million colours
Pixel Pitch (H x V) 0.177 x 0.530mm 0.162 x 0.485mm
Max. Brightness *1300 cd/m2
Contrast Ratio 6,000:1
Viewing Angle (H/V) 176°/176° (CR≥20)
Active Screen Area (W x H) 40-5/64" x 22-35/64" 36-5/8" x 20-19/32"
Response Time 6 ms (grey to grey, avg.)
Backlight White LED, Edge Lit
Computer Input
Video Analog RGB, Digital (HDMI)
Synchronization Horizontal/vertical separation (TTL: positive/negative)
Plug & Play VESA DDC2B
Power Management VESA DPMS
Video Colour System NTSC (3.58 MHz, 4.43 MHz), PAL, PAL60, SECAM
Tuner
Receiving Channel VHF 2-13ch, UHF 14-69ch
CATV 1-135ch (non scrambled channel only)
Digital Terrestrial Broadcast (8VSB) 2-69ch
Digital Cable *2(64/256 QAM) 1-135ch (non-scrambled channel only)
Audio multiplex BTSC System
Input Terminals
PC/AV Video Analog RGB mini D-sub 15-pin x 1
PC/AV Audio 3.5mm-diameter mini stereo jack x 1
Component RCA (Y, Cb/Pb, Cr/Pr) x 1
HDMI ®HDMI in with HDCP x 4
Audio RCA pin (L/R) x 1
Antenna/Cable 75 Ω Unbalanced, F Type 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE) x 1
Other USB for integrated Photo/Video/Music Media Player x 1
Output Terminals
Audio 3.5mm-diameter mini stereo jack x 1, RCA digital audio x 1
Input/Output Terminals
LAN Port Ethernet RJ45 x 1
RS-232C D-sub 9-pin x 1
Speaker Output 10W + 10W
Mounting
Plate VESA 400 x 400, 4 points
Screws M6, 20mm M6, 25mm
Power Supply 120VAC, 60Hz
Power Consumption 160W (0.7 W Standby) 155W (0.7 W Standby)
Environmental Conditions
Operating Temperature +32°F to +104°F (0°C to +40°C)
Operating Humidity 20% to 80% RH
Frame Width 1-3/8" (34.9mm) - Left, Right & Top 1-3/8" (34.9mm) - Left, Right & Top
2-9/16" (65.1mm) - Bottom 2-19/32" (65.9mm) - Bottom
Dimensions (approx.) (W x H x D)
Without Stand 42-61/64" x 26-5/8" x 1-47/64" 39-17/32" x 24-47/64" x 1-47/64"
With Stand 42-61/64" x 28-1/8" x 10-1/4" 39-17/32" x 26-3/16" x 9-9/16"
Weight (approx.)
Without Stand 33.1 lbs. 27.6 lbs.
With Stand 36.4 lbs. 30.9 lbs.
Package Dimensions (approx.)/Weight 47-5/8" x 6-7/32" x 31-1/4"/45.2 lbs 44-13/32" x 6-1/8" x 28-25/32"/38.6 lbs
Main Accessories Tabletop Stand, remote controller and batteries (AAA size x2), operation manual (CD x1)
Commercial-Grade HDTV LED Displays Specifications
Dimensions (approx.) inch (mm):
LBT462U
LBT422U
10 6/25 (260)
19 7/10 (500)
42 9/20 (1091)
40 1/5 (1021)
28 (711.90)
26 3/5 (675.77)
22 17/25 (575.90)
9/50 (4.5)
1 2/5 (35.8)
3/5 (24.5)
1 3/4 (44)
2/5 (10)
11/25 (11)
4/25 (4)
3/5 (15)
1 3/4 (44)
2/5 (10)
11/25 (11)
4/25 (4)
3/5 (15)
9 1/25 (229.6)
17 7/10 (449.5)
39 1/2 (1004)
36 4/5 (934.2)
26 1/10 (663)
24 7/10 (627.8)
20 3/4 (527)
9/50 (4.5)
1 2/5 (35.8)
3/5 (24.5)
Input/Output Terminals
Digital Audio Output
terminal
HDMI
Antenna/Cable In
RS-232C IOIOI
terminal
Headphone
terminal
Input 1
terminal (HDMI
)
Input 2
terminal (HDMI
)
USB
terminal
Input 3
terminal
(HDMI)
Input 4
terminal
(HDMI)
Ethernet
terminal
PC In
terminal
Audio PC/HDMI
terminal
(shared for
PC in and
HDMI)
INPUT 5
Input 5
terminals (component/AV)
*1 Brightness will depend on input mode and other picture settings. Brightness level will decrease over time. Due to the nature of the equipment, it is not possible
to precisely maintain a constant level brightness. *2 Emergency alert messages via Cable cannot be received.
Design and specifications subject to change without notice.
Sharp is a registered trademark of Sharp Corporation. HDMI
is a registered trademark of HDMI Licensing LLC. All other
trademarks are the property of their respective owners.
All screen images in this brochure are simulated.
