PG-D2510X (2500 Lumens, XGA)
Compact, Low-Cost 3D Ready BrilliantColor™ DLP® Projector
for Education and Business Applications
The Sharp PG-D2510X offers exceptionally high performance and connectivity at a very affordable price. Designed for school
and business use, the PG-D2510X utilizes the latest BrilliantColor DLP technology with DLP Link™ (for high quality 3D
projection from a single projector). Additional key features include 2500 Lumens brightness, 7 Watt audio system, built-in
closed caption decoder and sealed DLP chip with filter-free design. Built in an ISO 14001 certified factory, with standby power
consumption as low as 0.32W and estimated lamp life of up to 5,000 hours (in eco mode), this slim and lightweight RoHS
compatible projector is exceptionally environmentally friendly.
3D Ready. Make sure your projector is ready for use with new 3D
content. Incorporating DLP Link technology, when used with
compatible 3D field sequential content and PC, and optional 3D
shutter glasses that support the DLP Link system, the PG-D2510X
captivates audiences with breathtaking 3D imagery. This model
offers 3D support with both 60 Hz and 120 Hz XGA (1024 x 768)
and SVGA (800 x 600) sources. When not being used for 3D
projection, the PG-D2510X offers full compatibility with
traditional “2D” content.
High Brightness and Contrast. 2500 Lumens with 1100:1
Contrast Ratio.
High Output 7 Watt Audio System.
BrilliantColor DLP Technology and Six-Segment Color Wheel
for
superior color accuracy with more realistic image reproduction.
Wide Complement of Input/Output Terminals. Inputs include
RGB/Component Video, another RGB/Component Video port
selectable for use either as a second input or loop-through
output, S-Video, Composite Video, two Stereo Audio Inputs
and Stereo Variable Audio Line Output. Control and
Communications terminals include RS-232C and USB.
DTV/HDTV Compatibility with both 4:3 and 16:9 aspect ratios.
Sealed DLP Chip with Filter-Free Design for lower maintenance
and operating costs.
“Quick Start” On-Screen Setup Guide; Built-in Closed Caption
Decoder.
Wall Color Screen Adjustment Function
for use with
whiteboards and blackboards.
Presentation Assist Functions (by remote control) include 3D
Mode on/off, page up/down, GUI (Graphic User Interface)
pointer, spotlight and mouse control. Pointer offers a choice
of five on-screen icons; Spotlight function highlights a box or
row of information.
Audio Pass-Through (standby audio out). Permits the audio
output terminal to be used when the projector is in standby
mode. [Projector must be set to Standby Audio-Out: On and
Standby Mode: Quick Start.]
Unique Slide Lens Cover helps protect lens from dust and
provides an instant lens shutter. In the event the lens cover is
kept closed for more than 30 minutes, the projector turns off
automatically for safety.
Enhanced Anti-Theft Design includes LAN monitor function,
reinforced metal security bar, Kensington™ lock compatibility
and optional security cable kit (for use with optional ceiling
mount bracket).
Shutter Door on Lamp Housing helps keep glass confined in
the event of lamp breakage.
Screen Size and Projection Distance
Normal Mode (4:3)
Projection (Screen) Size Projection Distance [L] Distance from the lens center
to the bottom of the image [H]
Diag. [X] Width Height Minimum [L1] Maximum [L2]
300" 240" 180" 34' 0" 41' 3" 7 ¼"
200" 160" 120" 22' 8" 27' 6" 4 ⁄"
150" 120" 90" 17' 0" 20' 7" 3 ⁄"
120" 96" 72" 13' 7" 16' 6" 2 ⁄"
100" 80" 60" 11' 4" 13' 9" 2 ⁄"
80" 64" 48" 9' 1" 11' 0" 1 ⁄"
60" 48" 36" 6' 10" 8' 3" 1 ⁄"
40" 32" 24" 4' 6" 5' 6" ⁄"
Note: Allow a margin of error in the values in the diagram above.
Rear Panel

Specifications
Model Number PG-D2510X
3D Ready Yes. Compatible with DLP Link™ Technology
Display Device 0.55" DLP® Chip x 1 with BrilliantColor™ Technology
Color Wheel 6-Segment
Native Resolution/Aspect Ratio XGA (1024 x 768) / 4:3
Brightness/Contrast Ratio 2500 Lumens / 1100:1
Manual Zoom/Focus Lens 1:1.2x Zoom (f = 19.0~22.7mm), F 2.4~2.6
Screen Size (Min/Max) 40" (102cm) to 300" (762cm) diagonal
Input Signals - Computer RGB UXGA*1, SXGA+*1,SXGA*1, WXGA*1, XGA, SVGA / Mac 21"*1, 19", 16", 13"
Input Signals - DTV/HDTV 1080p, 1080i, 720p, 576i, 540p, 480p, 480i; NTSC, PAL, SECAM
Input Terminals 1 - Computer/Component (mini D-sub 15 pin); 1-Computer/Component (mini D-sub 15-pin)
selectable as input or loop-through output; 1 - S-Video (mini DIN 4 pin); 1 – Composite Video (RCA pin type);
1 - Stereo Audio (3.5mm stereo mini jack); 1 - Stereo Audio (RCA L/R)
Output Terminals 1 - Computer / Component (mini D-sub 15-pin) selectable as input or loop-through
output; 1 - Stereo Variable Audio Line Out (3.5mm stereo mini jack)
Control and Communications Terminals USB (type B); RS-232C (mini DIN 9-pin)
Control System Compatibility Crestron®, AMX®, Extron®, Bitlogix®
Closed Caption Yes (CC1, CC2)
On-Screen Display Languages English, German, Spanish, French, Dutch, Italian, Swedish, Portuguese, Russian,
Polish, Hungarian, Turkish, Arabic, Persian, simplified Chinese, Korean, Japanese
Horizontal/Vertical Frequency 15 - 110 kHz (H) / 45 - 85 Hz (V)
Audio System 7 Watts (Monaural)
Fan Noise (Eco+Quiet Off/On) 34 dB / 30 dB
Lamp Module AN-D350LP or AN-D350LP/1 ; 210 Watt DC, User-Replaceable
Estimated Lamp Life Up to 3,000 Hours (Eco+Quiet: Off); Up to 5,000 Hours (Eco+Quiet: On)
Power Source 100 - 240V, 50/60 Hz, 2.8A current
Power Consumption 274W @ 100V (0.32W standby mode); 265W @ 240V (0.77W standby mode)
Operating/Storage Temperature 41°F to 95°F (+5°C to 35°C) / -4°F to 140°F (-20°C to +60°C)
IR Wireless Remote Control Yes - with presentation assist functions (3D on/off, page up/down,
graphic user interface (GUI) pointer, spotlight and mouse control)
Picture Modes Standard, Presentation, sRGB, Movie, Game
Heat Dissipation 940 BTU / hour with AC 100V (Eco+Quiet: Off), 740 BTU / hour with AC 100V (Eco+Quiet: On);
910 BTU / hour with AC 240V (Eco+Quiet: Off), 720 BTU / hour with AC 240V (Eco+Quiet: On)
Safety Approval UL, FCC Class A
Main Body Dimensions (W x H x D) 11-52/64 x 3-1/8 x 9-19/64 (300 x 79 x 236 mm)
Weight 6.2 lbs. (2.8 kg)
Included Accessories Wireless Remote Control; two AA Batteries, 6' AC Power Cord;
10' RGB Signal Cable; Operation Manual, CD-ROM
Optional Accessories X102 3D Active Shutter Glasses; AN-XRCM30 Ceiling Mount Bracket; AN-EP101B Ceiling Mount Extension Tube;
AN-JT200 Angle-Mount Joint for ceiling mount; AN-CMCSS16 16" Security Cable System (for use with ceiling
mount); AN-CMCSS46 46" Security Cable System (for use with ceiling mount and extension tube);
AN-C3CP2 3-RCA (component video) to 15-pin D-sub cable (10'); AN-A1RS RS-232C Adapter; AN-MR2
Remote IR Receiver (for forward/back presentation control in ceiling mount installations);
AN-C500SB Light Duty Storage Bag; AN-D200WCC Hard-Shell Wheeled Storage Bag.
UPC 074000374010
Limited Warranty*2 3 Years Parts and Labor including 3 Years of "ER" 24-hour turnaround Express Repair.
90 day warranty on user-replaceable projection lamp.
10135
SHARP ELECTRONICS CORPORATION
Professional Display Division
Sharp Plaza, Mahwah, NJ 07495-1163
For more information call: 1-866-4-VISUAL (1-866-484-7825)
www.sharpusa.com/projectors
© 2010 Sharp Electronics Corporation. All rights reserved. Printed in the U.S.A. 08-10 LC-02-369
PG-D2510X (2500 Lumens, XGA)
*1 Compatible in intelligent compression
*2 See warranty statement included with product, or as PDF download at www.sharpusa.com
Design and Specifications are subject to change without notice.
Brightness values indicate overall average values of the product at the time of manufacture and are stated based on ISO 21118-2005. This international standard replaces the ANSI lumens ratings.
