Sharp CD-DK890N User manual

CD-DK890N_US
Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please read this
manual carefully. It will guide you in operating your SHARP product.
2008/June/23
MINI COMPONENT SYSTEM
CD-DK890N Mini Component System consisting of CD-DK890N (main
unit), CP-DK890N (speaker system).
Accessories
Please confirm that only the following accessories are included.
MODEL
OPERATION MANUAL
iPod is a registered trademark of Apple Inc.
CD-DK890N
(RRMCGA173AWSA)
AM loop antenna 1
(QANTL0010AWZZ)
(92LFANT1535A)
iPod
®
adaptor 8
(UACRTA008AW01)
Remote control 1
FM antenna 1

2008/June/17 CD-DK890N_US
2
CD-DK890N
Important Instruction
SPECIAL NOTES
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTSINSIDE. REFER SERVIC-
ING TO QUALIFIED SERVICE PERSONNEL.
Explanation of Graphical Symbols:
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product s en-
closure that may be of sufficient magnitude
to constitute a risk of electric shock to per-
sons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and main-
tenance (servicing) instructions in the lit-
erature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
This product is classified as a CLASS 1 LASER PRODUCT
Caution - Use of any controls, adjustments or procedures
other than those specified herein may result in hazardous
radiation exposure.
“Made for iPod” means that anelectronic accessory has been
designed to connect specifically to iPod and has beencertified
by the developer to meet Apple performance standards.
Apple is not responsible for the operationof this device or its
compliance with safety and regulatory standards.
Note to CATV system installer:
Thisreminder isprovided to call the CATV system installer'sattention to
Article 820-40 of the National Electrical Code that providesguidelinesfor
proper groundingand, in particular, specifiesthat the cable ground shall
be connected to the groundingsystem of the building, asclose to the
point of cable entry aspractical.
NOTE
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful in-
terference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to ra-
dio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
WARNING
FCC Regulations state that any unauthorized changes or modifications
to this equipment not expressly approved by the manufacturer could void
the user's authority to operate this equipment.
NOTES
It is the intent of Sharp that this product be used in full compliance
with the copyright laws of the United States and that prior permission
be obtained from copyright owners whenever necessary.
Licensed under one or more of U.S. Pat. 4,972,484, 5,214,678,
5,323,396, 5,530,655, 5,539,829, 5,544,247, 5,606,618, 5,610,985,
5,740,317, 5,777,992, 5,878,080 or 5,960,037.
FO
R Y
OU
R RE
CO
RD
S
F
or your ass
i
stance
i
n report
i
n
g
t
hi
sun
i
t
i
n case o
f
l
oss or t
h
e
f
t,
pl
ease recor
d
b
e
l
ow t
h
e mo
d
e
l
num
b
er an
d
ser
i
a
l
num
b
er w
hi
c
h
are
located
o
n
the
r
ea
r
of
the
u
n
it
.
Please
r
etai
n
this
i
n
fo
rm
atio
n
.
Model
n
u
m
be
r
.......................................................
Se
ri
a
l n
u
m
be
r
.......................................................
D
ate o
f
p
urc
h
ase
.......................................................
Pl
ace o
f
p
urc
h
ase
.......................................................

2008/June/16 CD-DK890N_US
3
CD-DK890N
Important Instruction
IMPORTANT SAFETY INSTRUCTIONS
Electricity is used to perform many useful functions, but it can also
cause personal injuries and property damage if improperly handled.
This product has been engineered and manufactured with the
highest priority on safety. However, improper use can result in
electric shock and/or fire. In order to prevent potential danger, please
observe the following instructions when installing, operating and
cleaning the product. To ensure your safety and prolong the service
life of this product, please read the following precautions carefully
before use.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician
for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from
the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for
long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
Additional Safety Information
15) Power Sources - This product should be operated only from the
type of power source indicated on the marking label. If you are
not sure of the type of power supply to your home, consult your
product dealer or local power company. For product intended
to operate from battery power, or other sources, refer to the
operating instructions.
16) Overloading - Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a risk of
fire or electric shock.
17) Object and Liquid Entry - Never push objects of any kind into
this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.

2008/June/16 CD-DK890N_US
4
CD-DK890N
Important Instruction
IMPORTANT SAFETY INSTRUCTIONS
(continued)
18) Damage Requiring Service - Unplug this product from the wall
outlet and refer servicing to qualified service personnel under
the following conditions :
a) When the AC cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the
product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the operating instructions as an
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the product to its normal
operation,
e) If the product has been dropped or damaged in
any way, and
f) When the product exhibits a distinct change in
performance - this indicates a need for service.
19) Replacement Parts - When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics
as the original part. Unauthorized substitutions may result in
fire, electric shock, or other hazards.
20) Safety Check - Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
21) Wall or ceiling mounting - When mounting the product on a wall
or ceiling, be sure to install the product according to the method
recommended by the manufacturer.
22) Power Lines - An outside antenna system should not be located
in the vicinity of overhead power lines or other electric light or
power circuits,or where it can fall into such power lines or circuits.
When installing an outside antenna system, extreme care should
be taken to keep from touching such power lines or circuits as
contact with them might be fatal.
23) Outdoor Antenna Grounding - If an outside antenna or cable system
is connected to the product, be sure the antenna or cable system is
grounded so as to provide some protection against voltage surges
and built-up static charges. Article810 of the National Electrical Code,
ANSI/NFPA 70, provides information with regards to proper grounding
of the mast and supporting structure, grounding of the lead-in wire to
an antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
24) Protective Attachment Plug - The product is equipped with an attachment
plug having overload protection. This is a safety feature. See Instruction
Manual for replacement or resetting of protective device. If replacement
of the plug is required, be sure the service technician has used a replace-
ment plug specified by the manufacturer that has the same overload
protection as the original plug.
25) Stand - Do not place the product on an unstable cart, stand, tripod or
table. Placing the product on an unstable base can cause the product to
fall, resulting in serious personal injuries as well as damage to the product.
Use only a cart, stand, tripod, bracket or table recommended by the
manufacturer or sold with the product. When mounting the product on a
wall, be sure to follow the manufacturer's intructions. Use only the mounting
hardware recommended by the manufacturer.
ANTENNA LEAD IN WIRE
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
NEC - NATIONAL ELECTRICAL CODE
S2898A
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMP
Example of antenna grounding as per
National Electrical Code, ANSI/NFPA 70
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)

2008/June/16 CD-DK890N_US
5
CD-DK890N
General Information
Special Note
Supply of this product does not convey a license nor imply any right
to distribute content created with this product in revenue-generating
broadcast systems (terrestrial, satellite, cable and/or other
distribution channels), revenue-generating streaming applications
(via Internet, intranets and/or other networks), other revenue-
generating content distribution systems (pay-audio or audio-on-
demand applications and the like) or on revenue-generating physical
media (compact discs, digital versatile discs, semiconductor chips,
hard drives, memory cards and the like). An independent license for
such use is required. For details, please visit http://mp3licensing.com
MPEG Layer-3 audio coding technology licensed from Fraunhofer
IIS and Thomson.
Contents
Page
General Information
Precautions................................................................................... 6
Controlsand indicators.......................................................... 7 - 9
Preparation for Use
System connections.............................................................10 - 12
Remote control ............................................................................13
Basic Operation
General control ...........................................................................14
Setting the clock (Remote control only) ....................................15
iPod
Listening to the iPod ............................................................16 - 19
CD or MP3/WMA disc Playback
Listening to a CD or MP3/WMA disc .................................. 20 - 22
Advanced CD or MP3/WMA disc playback ........................ 23 - 25
MP3/WMA navigation (only for MP3/WMA files) ............... 26 - 29
Radio
Listening to the radio .......................................................... 30 - 31
Tape Playback
Listening to a cassette tape (TAPE 1 or TAPE 2) ............. 32 - 33
Tape Recording
Recording on a cassette tape ............................................. 33 - 35
Advanced Features
Timer and sleepoperation (Remote control only) ............ 36 - 39
Enhancing your system ....................................................... 39 - 40
References
Troubleshooting chart ......................................................... 40 - 42
Maintenance ................................................................................ 42
Specifications............................................................................. 43
CONSUMER LIMITED WARRANTY ............................. Back cover
ENERGY STAR®Program Information
Productsthat have earned
the ENERGY STAR®are
designed to protect the
environment through
superior energy efficiency.
To comply with the ENERGY STAR®standards mentioned above,
please cancel the demonstration mode, as described on page 12.
ENERGY STAR®isa U.S. registered mark.

2008/June/16 CD-DK890N_US
6
CD-DK890N
General Information
Precautions
General
Please ensure that the equipment is positioned in a well ventilated
area and ensure that there is at least 4" (10 cm) of free space
along the sides, top and back of the equipment.
Do not place anything on top of the unit.
Do not expose the unit to moisture, to temperatures higher than
140
˚
F (60
˚
C) or to extremely low temperatures.
If your system does not work properly, disconnect the AC power
cord from the AC outlet. Plug the AC power cord back in, and then
turn on your system.
This unit should only be used within the range of 41
˚
F - 95
˚
F
(5
˚
C - 35
˚
C).
Warning:
The voltage used must be the same as that specified on this unit.
Using this product with a higher voltage other than that which is
specified is dangerous and may result in a fire or other type of
accident causing damage. SHARP will not be held responsible for
any damage resulting from use of this unit with a voltage other than
that which is specified.
Volume control
The sound level at a given volume setting depends on speaker
efficiency, location, and various other factors. It is advisable to avoid
exposure to high volume levels, which occurs while turning the unit
on with the volume control setting up high, or while continually
listening at high volumes. Excessive sound pressure from earphones
and headphones can cause hearing loss.
Use the unit on a firm, level surface free from
vibration.
Place the speakers at least 12" (30 cm) away from any CRT TV
to avoid color variations across the TV screen. If the variations
persist, move the speakers further away from the TV. LCD TV is
not prone to such variation.
Keep the unit away from direct sunlight,
strong magnetic fields, excessive dust,
humidity and electronic/electrical
equipment (home computers, facsimiles,
etc.) which generate electrical noise.
4" (10 cm)
4" (10 cm) 4" (10 cm) 4" (10 cm)
TIMER
CD
4
3
1
5
4
5
3
2
1
PHONES
RECORD/PLAYBACKPLAYBACK(PLAY&STOP)
2
AUDIO
IN
12" (30 cm) 12" (30 cm)
TIMER
CD
4
3
1
5
4
5
3
2
1
PHONES
RECORD/PLAYBACK
PLAYBACK(PLAY&STOP)
2
AUDIO
IN
TIMER
CD
4
3
1
5
4
5
3
2
1
PHONES
S
RECORD/
P
L
A
Y
B
A
CK
P
L
A
Y
A
A
B
A
CK
(PL
A
Y&STOP)
2
AUDIO
IN
In case of an electrical storm, unplug the
unit for safety.
Hold the AC power plug by the head when
removing it from the AC outlet, as pulling
the cord can damage internal wires.
The AC power plug is used as a disconnect
device and shall always remain readily
operable.
Do not remove the outer cover, asthis
may result in electric shock. Refer
internal service to your local SHARP
service facility.
A
CINPUT
CINPU T

2008/June/16 CD-DK890N_US
7
CD-DK890N
General Information
Controlsand indicators
Front panel
Reference page
1. iPod Terminal . .......................................................................17
2. Disc Trays............................................................................. 21
3. Timer Indicator ..................................................................... 37
4. Power On/Stand-by Button ..................................... 14, 20, 30
5. CD Button ............................................................................. 20
6. Tape (1 2) Button ............................................................. 32
7. Tuner (Band) Button ............................................................ 30
8. Audio In/iPod Button ........................................................... 39
9. CD or Tape StopButton ................................................ 22, 33
10. CD Track Down or Fast Reverse, Tape 2 Rewind, Tuner
Preset Down, Time Down Button ......15, 19, 22, 31, 32, 33, 36
11. Tuning Down, Cursor Down Button.........................19, 26, 30
12. Tape 1 Cassette Compartment ...................................... 32, 35
13. Headphone Jack .................................................................. 40
14. Audio In Jack......................................................................... 39
15. Remote Sensor ......................................................................13
16. Volume Control .................................................................... 14
17. CD, iPod Play or Pause,
Tape Play Button .....................................16, 19, 20, 22, 32, 33
18. Disc Tray Open/Close Button ............................................. 20
19. Disc Number Select Buttons............................................... 20
20. CD Track Upor Fast Forward, Tape 2 Fast Forward,
Tuner Preset Up, Time UpButton ....15, 19, 22, 31, 32, 33, 36
21. Tuning Up, Cursor UpButton ..................................19, 26, 30
22. Tape 2 Cassette Compartment ..................................... 32, 35
TIMER
CD
4
3
1
5
4
5
3
2
1
PHONES
RECORD/PLAYBACK
PLAYBACK (PLAY & STOP)
2
AUDIO
IN
15
16
17
19
20
21
22
18
1
2
3
4
5
6
7
8
9
10
11
12
13
14

2008/June/16 CD-DK890N_US
8
CD-DK890N
General Information
Controlsand indicators(continued)
Display
Reference page
1. Disc Number Indicators........................................................23
2. MP3/WMA Folder Indicator .................................................. 26
3. MP3/WMA Title Indicators.................................................... 26
4. MP3 Indicator ........................................................................ 21
5. WMA Indicator .......................................................................21
6. SleepIndicator ...................................................................... 38
7. Timer Play Indicator .............................................................. 37
8. Timer Recording Indicator ................................................... 37
9. Tape 2 Record Indicator ................................................ 34, 35
10. MP3/WMA Total Indicator .................................................... 27
11. Daily Timer Indicator ............................................................ 37
12. FM Stereo Mode Indicator ................................................... 30
13. FM Stereo Receiving Indicator ............................................ 30
14.Tape Play Indicator ................................................................ 32
15. Memory Indicator ........................................................... 25, 31
16. Extra Bass Indicator ............................................................. 14
17. Disc Repeat Play Indicator .................................................. 24
18. Disc Pause Indicator ............................................................ 22
19. Disc Play Indicator ............................................................... 21
Rear panel
Reference page
1. Cooling Fan ........................................................................... 12
2. AC Power Cord ..................................................................... 12
3. FM 75 OhmsAntenna Jack .................................................. 11
4. AM Antenna Ground Terminal ............................................ 11
5. AM LoopAntenna Terminal ................................................. 11
6. Video Out Jack ..................................................................... 39
7. Front Speaker Terminals..................................................... 11
Speaker system
A
C INPUT
C INP UT
3
7
4
5
2
1
6
12 345 6 789
11 12 13
10 14
15
16 17
1819
1. Tweeter
2. Woofer
3. Bass Reflex Duct
4. Speaker Wire
2
13
4

2008/June/16 CD-DK890N_US
9
CD-DK890N
General Information
Remote control
Reference page
1. Remote Control Transmitter ................................................ 13
2. Disc Number Select Buttons............................................... 20
3. Tuning Up, Cursor UpButton .................................. 19, 26, 30
4. Disc Track Down or Fast Reverse, Tape 2 Rewind,
Tuner Preset Down, Time Down, Cursor Left Button
............................................................. 15, 19, 22, 31, 32, 33, 36
5. Clock/Timer Button ......................................................... 15, 36
6. Character Input/Disc Direct Search Buttons............... 23, 28
7. Equalizer Mode Select Button ............................................. 14
8. Extra Bass/Demo Button ...................................................... 14
9. On/Stand-by Button ................................................. 14, 20, 30
10. CD Button .............................................................................. 20
11. Tuner (Band) Button ............................................................. 30
12. Tape (1 2) Button ............................................................. 32
13. Audio In/iPod Button ........................................................... 39
14. Disc Track Upor Fast Forward, Tape 2 Fast Forward,
Tuner Preset Up, Time Up, Cursor Right Button
............................................................. 15, 19, 22, 31, 32, 33, 36
15. Tuning Down, Cursor Down Button ........................ 19, 26, 30
16. Volume Upand Down Buttons............................................. 14
17. Clear/Dimmer, iPod MENU Button .......................... 18, 19, 25
18. Play Mode Button ................................................................. 19
19. Disc StopButton .................................................................. 22
20. Tape StopButton ................................................................. 33
21. Memory, iPod ENTER Button ...................... 15, 19, 25, 31, 36
22. iPod Play/Pause Button ........................................................ 16
23. Disc Play/Pause Button ....................................................... 24
24. Tape Play Button ............................................................ 32, 33
25. Tape 2 Record Pause Button .............................................. 34
26. MP3/WMA Navigation Mode Select Button ........................ 26
27. Character Button ................................................................... 26
28. Display Button ................................................................ 19, 22
29. Enter Button ......................................................................... 26
1
2
5
7
8
3
4
6
10
11
9
12
13
14
16
15
21
23
22
17
19
18
25
24
20
26 27 28 29

2008/June/16 CD-DK890N_US
10
CD-DK890N
Preparation for Use
System connections
A
C INPUT
C INP UT
t
hgiR ps re
ka
e
annetna MF
teltuO CA
)zH 06
~ V
02
1 C
A(
tfeL ps r
eka
e
ool MA p annetna
CA p ( no
i
tcennoc
rewo s ee p )
2
1
ega
( n
o
it
c
e
n
noc annet
nA s ee p )1
1
ega
Spn
oitc
e
nn
o
c
r
e
ka
e
(s e
ep)
1
1
e
g
a
ekaM s nu
ot
eru p CA
the
g
u
lp droc
rewo b noitcenn
o
c yna gnikam e
r
ofe s

2008/June/16 CD-DK890N_US
11
CD-DK890N
Preparation for Use
Antenna connection
Note:
Placing the antenna on the unit or near the AC power cord may
cause noise pickup. Place the antenna away from the unit for better
reception.
Installing the AM loopantenna:
Speaker connection
Connect the black wire to the FRONT SPEAKERS minus (–)
terminal, and the red wire to the FRONT SPEAKERS plus (+)
terminal.
Caution:
Connecting
iPod
to a TV
The iPod with photo and video can be viewed by connecting to a TV/
monitor.
If the TV/monitor has a video input, connect it to the VIDEO OUT
jack on the rear of the unit.
Note:
Please make sure to set iPod unit to either NTSC or PAL to match
your TV signal. Please visit Apple’s home page for further
information.
Supplied FM antenna:
Connect the FM antenna wire to the
FM 75 OHMS jack and position the FM
antenna wire in the direction where the
strongest signal can be received.
Supplied AM loopantenna:
Connect the AM loop antenna to the
AM and GND terminals. Position the
AM loop antenna for optimum
reception. Place the AM loop antenna
on
a shelf, etc., or attach it to a stand
or a wall with screws (not supplied).
< Assembling > < Attaching to the wall >
Wall Screws (not supplied)
FM
antenna
AM loop
antenna
A
C INPUT
C INPUT
Red
Black
Use speakers with an impedance of 6 ohms or more, as lower
impedance speakers can damage the unit.
Do not mistake the right and the left
channels. The right speaker is the one on the
right side when you face the unit.
Do not let the bare speaker wirestouch
each other.
Do not stand or sit on the speakers. You may
be injured.
Do not allow any objects to fall into or to be
placed in the bass reflex duct.
Incorrect
A
C INPUT
C INPUT
TV
Video cable
(not supplied)
To video
input jack

2008/June/16 CD-DK890N_US
12
CD-DK890N
Preparation for Use
System connections(continued)
AC power connection
After checking all the connections have been made correctly, plug
the AC power cord of this unit into the AC outlet. If you plug in the unit
first, the unit will enter the demonstration mode.
Notes:
The unit will start the tape initialization when plugged in to the AC
outlet. During this process, initializing sound will be heard and the
unit cannot be turned on. Wait until the process is finished.
Unplug the AC power cord from the AC outlet if the unit will not be
in use for a prolonged period of time.
Demonstration mode
Outdoor FM antenna
Use an outdoor FM antenna if you require better reception. Consult
your dealer.
Note:
When an outdoor FM antenna is used, disconnect the supplied FM
antenna wire.
Cooling fan:
The main unit is built with a cooling fan at the rear of the unit
for improved cooling. Please do not cover the opening of the
fan with any obstacles, as this will block proper ventilation.
A
C INPUT
C INPUT
AC outlet
(AC 120 V ~ 60 Hz)
A
C INPUT
C INPU T
The first time the unit is plugged in, the
unit will enter the demonstration mode.
You will see words scroll.
To cancel the demonstration mode:
When the unit is in the power
stand-by mode (demonstration
mode), press the X-BASS/DEMO
button. The unit will enter the low
power consumption mode.
To return to the demonstration mode:
When the unit is in the power stand-by mode, press the
X-BASS/DEMO button again.
Note:
When the power is on, the X-BASS/DEMO button can be used to
select the extra bass mode.
75 ohms
coaxial cable
Outdoor
FM antenna

2008/June/16 CD-DK890N_US
13
CD-DK890N
Preparation for Use
Remote control
Battery installation
Precautionsfor battery use:
Replace all old batteries with new ones at the same time.
Do not mix old and new batteries.
Remove the batteries if the unit will not be used for long periods
of time. This will prevent potential damage due to battery leakage.
Caution:
Do not use rechargeable batteries (nickel-cadmium battery, etc.).
Installing the batteries incorrectly may cause the unit to
malfunction.
Batteries (battery pack or batteries installed) shall not be exposed
to excessive heat such as sunshine, fire or the like.
Battery removal:
Open the battery cover and pull up the battery to take out.
Notesconcerning use:
Replace the batteries if the operating distance is reduced or if the
operation becomes erratic.
Periodically clean the transmitter on the remote control and the
sensor on the unit with a soft cloth.
Exposing the sensor on the unit to strong light may interfere with
operation. Change the lighting or the direction of the unit.
Keep the remote control away from moisture, heat, shock, and
vibrations.
Test of the remote control
Check the remote control after checking all the connections (see
pages 10 - 12).
Point the remote control directly at the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now, you
can enjoy the music.
Use 2 “AA” size batteries (UM/SUM-3, R6, HP-7 or similar).
Batteries are not included.
1Open the battery cover.
2Insert the batteriesaccording to the direction indicated in
the battery compartment.
When inserting or removing the batteries, push them toward the
battery terminals.
3 Close the battery cover.
TIMER
CD
4
3
1
5
4
5
3
2
1
PHONES
RECORD/PLAYBACK
PLAYBACK(PLAY & STOP)
2
AUDIO
IN
Remote sensor
8" - 20'
(0.2 m - 6 m)

2008/June/16 CD-DK890N_US
14
CD-DK890N
Basic Operation
General control
To turn the power on
Press the ON/STAND-BY button to turn the power on.
Display brightness control
To dim the display brightness, hold down the CLEAR/DIMMER
button on the remote control for 2 seconds or more.
Volume auto fade-in
If you turn off and on the main unit with the volume set to 27 or
higher, the volume starts at 16 and fades in to the last set level.
Volume control
Bass control (X-BASS)
Equalizer
When the EQUALIZER MODE button is pressed, the current mode
setting will be displayed. To change to a different mode, press the
EQUALIZER MODE button repeatedly until the desired sound mode
appears.
After use:
Press the ON/STAND-BY button to enter the power stand-by mode.
—VOL.VOL.
TIMER
CD
4
3
1
5
4
5
3
2
1
2
POWER
ON/ STAND-BY
30 MAXIMUM0.....
X-BASS
POPS
VOCAL
JAZZ
FLAT
ROCK
CLASSIC
o tinu niaM p :noitare
denrut si lortnoc EMULOV eht ne
h
W
.esaercni lliw e
m
ulov eht ,esiwkcolc
eht ,esiwkcolcretnuoc denrut si ti ne
h
W
.esaerced lliw emulov
o
l
o
rtnoc
e
tomeR p :noitare
ot nottub )– ro +( EMULOV eht sserP
.emulov eht esa
e
rced ro esa
e
rcni
eht ,no denrut tsrif si rewop eht ne
h
W
hcihw edom ssab artxe eht ret
n
e lli
w
tinu
dna ,seicneuqerf ssab eht
s
ezisahpme
eht lecnac oT .raeppa lliw
”
S
SAB-X“
eht sserp ,edom ssab artxe
.
n
ottub O
M
ED/SSAB-X
ff
o
r
ez
il
au
qE
c
is
u
m kc
o
r
r
o
F
cisu
m
l
acissalc
r
o
F
cis
um
p
o
p
r
o
F
d
ecn
ah
ne
e
r
a slac
oV
zzaj
r
o
F

2008/June/18 CD-DK890N_US
15
CD-DK890N
Basic Operation
Setting the clock (Remote control only)
In this example, the clock is set for the 12-hour (AM 12:00) display.
To confirm the time display:
[When the unit is in the stand-by mode]
Press the CLOCK/TIMER button.
The time display will appear for about 10 seconds.
[When the power is on]
Press the CLOCK/TIMER button.
Within 10 seconds, press the or button to display the
time.
ONCE DAILY SLEEP AM 10:30
The time display will appear for about 10 seconds.
Notes:
The “CLOCK” will appear or time will flash to confirm the time
display when the AC power supply is restored after a power failure
or unplugging the unit. If incorrect, readjust the clock as follows.
In case the display exit while performing the clock setting, please
reset the clock from step 2 onwards.
To readjust the clock:
Perform “Setting the clock” from step 1. If the “CLOCK” does not
appear in step 3, step 4 (for selecting the 12-hour or 24-hour
display) will be skipped.
To change the 12-hour or 24-hour display:
1
Press the ON/STAND-BY button to turn the power on.
2
Press the CLOCK/TIMER button.
3
Within 10 seconds, press the or button to
select “CLOCK”, and press the MEMORY button.
4
Press the or button to select 12-hour or 24-
hour display and then press the MEMORY button.
“AM 12:00” The 12-hour display will appear.
(AM 12:00 - PM 11:59)
“AM 0:00” The 12-hour display will appear.
(AM 0:00 - PM 11:59)
“0:00” The 24-hour display will appear.
(0:00 - 23:59)
5
Press the or button to adjust the hour and
then press the MEMORY button.
Press the or button once to advance the time by
1 hour. Hold it down to advance continuously.
6
Press the or button to adjust the minutes and
then press the MEMORY button.
Press the or button once to advance the time by
1 minute. Hold it down to change the time in 5-minutes
intervals.
1 Clear all the programmed contents. [Refer to “Clearing all the
memory (reset)” on page 42 for details.]
2 Perform “Setting the clock” from step 1 onwards.

2008/June/16 CD-DK890N_US
16
CD-DK890N
iPod
Listening to the iPod
Supported iPod models:
iPod nano (software 1.2 above)
iPod mini (software 1.2 above)
5th Generation iPod (software 1.3 above) (Dock connector
equipped Click Wheel model)
4th Generation iPod (software 3.0.2 above) (Dock connector
equipped Click Wheel model)
iPod nano (2nd generation) (software 1.0.0 above)
iPod nano (3rd generation) (software 1.0.3 above)
iPod classic (software 1.0.3 above)
iPod touch (software 1.1 above)
Caution:
Please update your iPod unit to the latest software version before
using it. Please visit Apple’s homepage to download the latest
version for your iPod.
Notes:
Once the iPod is connected to the unit it will begin charging.
The iPod unit cannot be charged while the main unit is in the
stand-by mode.
Auto power on function:
When you press any of the following buttons, the unit turns on.
iPod button: The unit turns on and the iPod function is activated.
iPod / button on the remote control: The unit turns on and the
iPod playback start (regardless of the last function).
/ button on the main unit: The unit turns on and playback of
the last function will start (iPod, CD, TUNER, AUDIO IN, TAPE).
iPod adaptor connection
Choose the iPod adaptor that fits your iPod. Your iPod will fit snuggly
into the correct adaptor. If your iPod is not mentioned below, an iPod
adaptor may have been included with your iPod unit.
Notes:
iPod nano (2nd generation), iPod nano (3rd generation) and iPod
touch are not compatible with the iPod adaptors listed above.
Please use the adaptor supplied with your iPod unit.
If you have an iPod that does not have an iPod 30 Pin connector,
you can use an audio cable to connect it to the AUDIO IN jack.
TIMER
CD
4
3
1
5
4
5
3
2
1
2
iPod
Adaptor
No.
iPod Description Capacity
3iPod mini 4GB & 6GB
44G iPod & U2 iPod 20GB
54G iPod 40GB
6iPod photo & Color U2 iPod 20GB & 30GB
6iPod with color display 20GB
7iPod photo 40GB & 60GB
7iPod with color display 60GB
8iPod nano 2GB & 4GB
95G iPod (with video) 30GB
9U2 iPod with video 30GB
9iPod classic 80GB
10 5G iPod with video 60GB & 80GB
10 iPod classic 160GB
7
The number (3 - 10)
shows which iPod fits

2008/June/16 CD-DK890N_US
17
CD-DK890N
To insert iPod adaptor
1. Press the ON/STAND-BY button to turn the power on.
2. Insert the iPod adaptor into the iPod dock and connect your iPod.
To remove iPod adaptor
1. Adaptor with tip.
Hold this tip and pull as direction shown to remove adaptor.
iPod playback
To disconnect iPod
Simply remove the iPod from the iPod dock. It is safe to do so even
during playback.
iPod dock
iPod connector
iPod adaptor
iPod
iPod (bottom)
Dock connector
pull up
main unit
(top)
2. Adaptor without tip.
Insert the tip of a screwdriver (“–” type,
small) into the iPod adaptor hole as shown
and lift upward to remove.
1Press the ON/STAND-BY button to turn the power on.
2Press the iPod button to select iPod function.
3Insert iPod unit in iPod dock of main unit. “DOCK OK” will
be displayed for 3 secondsexcept for iPod mini and 4th
Generation iPod.
4Press the / button to start playback.
iPod
iPod adaptor
iPod

2008/June/16 CD-DK890N_US
18
CD-DK890N
iPod
Listening to the iPod (continued)
Navigating the iPod menuswith the remote
control
Note:
The volume level is adjusted by pressing the VOL (+ or –) button on
the main unit or the remote control. Adjusting the volume on the iPod
unit gives no effect.
Watching videoson a TV connected to iPod
Notes:
If the TV Out setting is already turned On at video menu, the video
is automatically displayed on the TV screen when [ENTER] key is
pressed.
To return to watching video on iPod screen, press the [MENU]
button to enter video menu. Then press the DISPLAY button for
more than 2 seconds until “iPod DISP” appears. Repeat steps 2
and 3.
During iPod video playback, pressing the DISPLAY button will not
toggle video out display between iPod and TV.
iPod operation
The operations described below depend on the generation iPod you
are using.
System on operation
When the main unit is powered on, the iPod unit will automatically
power on when docked in the unit (including TIMER function).
System off (stand-by operation)
When the main unit is turned to stand-by mode, the docked iPod unit
will automatically turn to stand-by mode.
iPod playback detection function
Once the play button on the iPod unit is pressed, the main unit will
automatically change to iPod function overriding the previous
function selected.
Caution:
Unplug all accessories for the iPod before inserting it into the iPod
dock.
Stop button ( ) at main unit is invalid during iPod function.
1Press the [MENU] button to view the menu on iPod unit.
Press it again to go back to previousmenu.
2Use the TUNING ( or ) button to select an item on the
menu and then press [ENTER] button.
1Press the DISPLAY button for more than 2 seconds.
“TV DISP” will appear on display.
2Select the desired video from iPod unit to be played.
3Press the [ENTER] button to start playback.
Pressing the [ENTER] button on the remote control will play a
selected VIDEO highlighted on the iPod.
Pressing the PLAY button on the remote control will not play the
selected VIDEO highlighted.

2008/June/19 CD-DK890N_US_N
19
CD-DK890N
iPod
VariousiPod functions
iPod
Function
Main unit Remote control Operation
Play Press in the
pause mode.
PausePress in the
playback mode.
Track up/
down
Press in the
playback or
pause mode.
If you press the
button in the
pause mode,
press the /
button to start
the desired
track.
Fast
forward/
reverse
Press and hold
down in the
playback mode.
Release the
button to
resume
playback.
iPod
Function
Main unit Remote control Operation
Back
light/TV
OUT
____ iPod back light
ON. Press for
more than 2
secondsto toggle
the video out
display between
iPod or TV.
Repeat ____ Press to toggle
repeat mode.
Shuffle ____ Press and hold
down to toggle
shuffle mode.
Menu ____ Press to view the
iPod menu during
iPod function.
Enter ____ Press to confirm
the selection.
Press to play the
selected VIDEO
highlighted on the
iPod.
Cursor
Up/
Down
Press to select the
iPod menu.

2008/June/16 CD-DK890N_US
20
CD-DK890N
CD or MP3/WMA disc Playback
Listening to a CD or MP3/WMA disc
This system can play back a standard CD, CD-R/RW in the CD format
and CD-R/RW with MP3 or WMA files, but cannot record on them.
Some audio CD-R and CD-RW discs may not be playable due to the
state of the disc or the device that was used for recording.
MP3:
MP3 isa form of compression. It isan acronym which stands
for MPEG Audio Layer 3.
MP3 isa type of audio code which isprocessed by significant
compression from the original audio source with very little loss
in sound quality.
This system supports MPEG 1 Layer 3, MPEG 2 Layer 3, and
VBR files.
During VBR file playback, time counter in the display may differ
from its actual playback time.
WMA:
WMA filesare Advanced System Format filesthat include audio
fileswhich are compressed with WindowsMedia Audio codec.
WMA isdeveloped by Microsoft asan audio format file for
WindowsMedia Player.
“MP3” or “WMA” indicator will light up after the unit reads
information on an MP3 or WMA disc.
Auto power on function:
When you press any of the following buttons, the unit turns on.
CD button (main unit and remote control): The unit turns on and
the “CD” function is activated.
CD / button on the remote control: The unit turns on and CD
playback starts (regardless of the last function).
/ button on the main unit: The unit turns on and playback of
the last function starts (CD, TAPE, TUNER, AUDIO IN, iPod).
Auto power off function:
In the stop mode of CD, MP3 or WMA operation, the main unit enters
the stand-by mode after 15 minutes of inactivity.
TIMER
CD
4
3
1
5
4
5
3
2
1
PHONES
RECORD/PLAYBACK
PLAYBACK(PLAY & STOP)
2
AUDIO
IN
4
5
3
2
1
OPEN/
CLOSE
CD
POWER
ON/ STAND-BY
