Sharp CD-XP350W User manual

Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please read this
manual carefully. It will guide you in operating your SHARP product.
CD-XP350W Mini Component System consisting of CD-XP350W (main
unit), CP-XP350 (front speaker) and GBOXS0094AWM1 (surround
speaker).
MINI COMPONENT SYSTEM
MODEL
CD-XP350W
OPERATION MANUAL
CDXP350WA_FRONT 02.1.25, 9:04 AM1

E-1
02/1/23 CD-XP350W(A)E1.fm
CD-XP350W
ENGLISH
Important Instruction
- Special notes -
Special notes
Warning:
zWhen the ON/STAND-BY button is set at STAND-BY position, mains voltage is
still present inside the unit. When the ON/STAND-BY button is set at STAND-BY
position, the unit may be brought into operation by the timer mode or remote con-
trol.
zThis unit contains no user serviceable parts. Never remove covers unless qualified
to do so. This unit contains dangerous voltages, always remove mains plug from
the socket before any service operation and when not in use for a long period.
zTo prevent fire or shock hazard, do not expose this appliance to dripping or
splashing. No objects filled with liquids, such as vases, should be placed on the
apparatus.
CAUTION
Note for users in Australia:
Copyright may exist in material you wish to record. Copying or broadcasting such
material without permission of the relevant licensees or owners of the copyright is
prohibited by law. SHARP is not in a position to authorise the copying or broadcast-
ing of copyright materials and nothing in this OPERATION MANUAL should be
implied as giving that authority.
For other countries:
Audio-visual material may consist of copyrighted works which must not be recorded
without the authority of the owner of the copyright. Please refer to the relevant laws in
your country.
zThis product is classified as a CLASS 1 LASER product.
zUse of controls, adjustments or performance of procedures other than those spec-
ified herein may result in hazardous radiation exposure.
As the laser beam used in this compact disc player is harmful to the eyes, do not
attempt to disassemble the cabinet. Refer servicing to qualified personnel only.
Laser Diode Properties
Material: GaAIAs
Wavelength: 780 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW

E-2
CD-XP350W(A)E1.fm02/1/23
CD-XP350W
ENGLISH
General Information
- Accessories / Contents -
Accessories
Please confirm that the following accessories are included.
Note:
Only the above accessories are included.
Contents
Page
General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 7
Preparation for Use
System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 10
General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Basic Operation
Sound control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
CD Playback
Listening to a CD (CDs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14, 15
Repeat play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Random play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Programmed play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Radio
Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Memorising a station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
To recall a memorised station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
To scan the preset stations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
To erase entire preset memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Page
Tape Playback
Listening to a cassette tape (TAPE 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Listening to a cassette tape (TAPE 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Karaoke
Playing karaoke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21, 22
Tape Recording
Recording from a CD (CDs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Recording from the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Dubbing from tape to tape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Erasing recorded tapes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Advanced Features
Timer and sleep operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25, 26
Enhancing your system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28, 29
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Remote control 1 "AAA" size battery (UM-4, R03, HP-16
or similar) 2 AM loop aerial 1 FM aerial 1

E-3
CD-XP350W(A)E1.fm02/1/23
CD-XP350W
ENGLISH
General Information
- Precautions -
Precautions
General
zPlease ensure that the equipment is positioned in a well-ventilated area and
ensure that there is at least 10 cm (4") of free space along the sides, top and back
of the unit.
zUse the unit on a firm, level surface free from vibration.
zKeep the unit away from direct sunlight, strong magnetic fields, excessive dust,
humidity and electronic/electrical equipment (home computers, facsimiles, etc.)
which generates electrical noise.
zDo not place anything on top of the unit.
zDo not expose the unit to moisture, to temperatures higher than 60°C (140°F) or to
extremely low temperatures.
zIf your system does not work properly, disconnect the AC power lead from the wall
socket. Plug the AC power lead back in, and then turn on your system.
zIn case of an electrical storm, unplug the unit for safety.
zHold the AC power plug by the head when removing it from the wall socket, as
pulling the lead can damage internal wires.
zDo not remove the outer cover, as this may result in electric shock. Refer
internal service to your local SHARP service facility.
zThe ventilation should not be impeded by covering the ventilation openings with
items, such as newspapers, tablecloths, curtains, etc.
zNo naked flame sources, such as lighted candles, should be placed on the appa-
ratus.
zAttention should be drawn to the environmental aspects of battery disposal.
zThis unit should only be used within the range of 5°C - 35°C (41°F - 95°F).
Warning:
The voltage used must be the same as that specified on this unit. Using this product
with a higher voltage other than that which is specified is dangerous and may result
in a fire or other type of accident causing damage. SHARP will not be held responsi-
ble for any damage resulting from use of this unit with a voltage other than that which
is specified.
Volume control
The sound level at a given volume setting depends on speaker efficiency, location,
and various other factors. It is advisable to avoid exposure to high volume levels, to
avoid this do not turn the volume on to full at switch on and listen to music at moder-
ate levels.
Condensation
Care of compact discs
Compact discs are fairly resistant to damage, however mistracking can occur due to
an accumulation of dirt on the disc surface. Follow the guidelines below for maximum
enjoyment from your CD collection and player.
zDo not write on either side of the disc, particularly the non-label side from which
signals are read. Do not mark this surface.
zKeep your discs away from direct sunlight, heat, and excessive moisture.
zAlways hold the CDs by the edges. Fingerprints, dirt, or water on the CDs can
cause noise or mistracking. If a CD is dirty or does not play properly, clean it with a
soft, dry cloth, wiping straight out from the centre, along the radius.
10 cm (4") 10 cm (4") 10 cm (4")
10 cm (4")
Sudden temperature changes, storage or operation in an extremely humid environ-
ment may cause condensation inside the cabinet (CD pickup, tape heads, etc.) or on
the transmitter on the remote control.
Condensation can cause the unit to malfunction. If this happens, leave the power on
with no disc (or cassette) in the unit until normal playback is possible (about 1 hour).
Wipe off any condensation on the transmitter with a soft cloth before operating the
unit.
NO YES
Correct

E-4
CD-XP350W(A)E1.fm02/1/23
CD-XP350W
ENGLISH
General Information
- Controls and indicators -
Controls and indicators
!Front panel
Reference page
1. Disc Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2. Timer Set Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5. CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14, 23
6. Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7. Microphone Level Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
8. Microphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
9. Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19, 20, 24
10.Video/Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25, 27
11.Equaliser Mode Select/Extra Bass/Demo Mode Button . . . . . 11, 12
12.Disc Tray Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
13.Disc Skip Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
14.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
15.Tape 1 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . . . . 19, 24
16.Tape 2 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . . . . 20, 24
17.CD Track Down or Fast Reverse, Tape 2 Fast Wind,
Tuner Preset Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 18, 20
18.CD Track Up or Fast Forward, Tape 2 Fast Wind,
Tuner Preset Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 18, 20
19.Clock Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 25
20.Timer/Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25, 26
21.Tape 2 Reverse Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . 20
22.Tape 2 Reverse Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
23.CD Play or Repeat, Tape 1 Play,
Tape 2 Forward Play Button . . . . . . . . . . . . . . . . . . . . . . 14, 16, 19, 20
24.CD or Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14, 19, 20
25.Tuning and Time Down Button . . . . . . . . . . . . . . . . . . . . . . . . . 13, 17
26.Memory/Set Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 16, 18
27.Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 23, 24
28.Tuning and Time Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 17
3
2
1
4
9
10
11
12
13
14
16
5
6
7
8
15
17
23 24 25 282726
1918 20
22
21
Description of remote control (See page 7.)

E-5
CD-XP350W(A)E1.fm02/1/23
CD-XP350W
ENGLISH
General Information
- Controls and indicators -
Controls and indicators (continued)
Display
1. CD Pause Indicator
2. Extra Bass Indicator
3. Disc Number Indicators
4. Tape 2 Record Indicator
5. FM Stereo Mode Indicator
6. FM Stereo Receiving Indicator
7. Timer Play Indicator
8. Sleep Indicator
9. Timer Recording Indicator
10.CD Play Indicator
11.CD Repeat Play Indicator
12.Karaoke Mode Indicator
13.Tape Reverse Mode Indicator
14.Tape 2 Reverse Play Indicator
15.Tape 1 Play or Tape 2 Forward Play Indicator
16.Memory Indicator
Rear panel
Reference page
1. Cooling Fan
2. AC Voltage Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
3. AC Power Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8, 10
4. Transport Screw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8, 29
5. FM 75 Ohms Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
6. FM Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
7. AM Loop Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
8. Span Selector Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
9. Video/Auxiliary (Audio Signal) Input Sockets . . . . . . . . . . . . . . . . .27
10.Surround Speaker Terminals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8, 9
11.Front Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8, 9
Note:
This product is equipped with a cooling fan inside, which begins to run at a specified
volume level for better heat radiation.
24567931 8
12
13
14 15 16
10
11
5
6
7
8
1
3
29
11
10
4

E-6
CD-XP350W(A)E1.fm02/1/23
CD-XP350W
ENGLISH
General Information
- Controls and indicators -
Front speaker
1. Tweeter
2. Woofer
3. Bass Reflex Duct
4. Speaker Wire
Surround speaker
1. Full-Range Speaker
2. Speaker Wire
Note:
The speaker grilles on the front and surround speakers are not removable.
Placing the speaker system
To enjoy the surround effect, we recommend that you place each speaker as shown
to the below.
Installation of the surround speakers:
If possible, mount the surround speakers on the wall. Install them 60 cm - 90 cm (23"
- 35") above the height of your ears when you are seated.
Note:
When the surround speakers are hung on the wall, the speaker badge reads verti-
cally. In this case, you can adjust the badge to point the proper direction by turning it
manually.
1
2
33
4
1
2
Main unit
Front
speaker
(Left)
Front
speaker
(Right)
Surround
speaker
(Left)
Surround
speaker
(Right)
TV
Wall
Example: when installed on the wall Example: when installed vertically
60 - 90 cm
(23" - 35")
Badge

E-7
CD-XP350W(A)E1.fm02/1/23
CD-XP350W
ENGLISH
General Information
- Controls and indicators -
Controls and indicators (continued)
Remote control
Reference page
1. Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
3. Disc Number Select Buttons . . . . . . . . . . . . . . . . . . . . . . . .14, 16, 23
4. CD Random Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
5. CD Memory Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
6. Karaoke Mode Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
7. Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . .23, 24
8. CD Track Down or Fast Reverse, Tape 2 Fast Wind Button . . . . .15, 20
9. CD or Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14, 19, 20
10.Tape 2 Reverse Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
11.CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14, 23
12.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
13.Video/Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
14.Extra Bass Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
15.Equaliser Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
16.CD Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
17.Echo Level Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . .21
18.Tuner Preset Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . .18
19.CD Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
20.CD Track Up or Fast Forward, Tape 2 Fast Wind Button . . . . . . .15, 20
21.CD Play or Repeat, Tape 1 Play,
Tape 2 Forward Play Button . . . . . . . . . . . . . . . . . . . . . . .14, 16, 19, 20
22.Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19, 20, 24
23.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
1
2
3
4
5
6
7
8
9
11
12
14
18
19
20
21
22
15
16
23
10
13
17
Buttons with " " mark in the illustration can be operated on the remote control
only.
Battery installation for remote control (See page 11.)

E-8
CD-XP350W(A)E1.fm02/1/23
CD-XP350W
ENGLISH
Preparation for Use
- System connections -
System connections
Removing the transport screw
Before turning the power on, be sure to remove the transport screw
on the back of the unit using a flat head screwdriver or a coin.
Note:
This screw is required when transporting the unit again. Please keep it (see page
29).
Aerial connection
Note:
Placing the aerial on the stereo system or near the AC power lead may cause noise
pickup. Place the aerial away from the stereo system for better reception.
Installing the AM loop aerial:
External FM aerial:
Use an external FM aerial if you require better reception. Consult your dealer.
Note:
When an external FM aerial is used, disconnect the supplied FM aerial wire.
AM loop aerial
FM aerial
Surround speaker
(Left)
Front speaker
(Right)
Surround speaker
(Right)
Transport screw
Front speaker
(Left)
Wall socket
(See page 10.)
Supplied FM aerial:
Connect the FM aerial wire to the FM 75
OHMS terminal and position the FM aerial wire
in the direction where the strongest signal can
be received.
Supplied AM loop aerial:
Connect the AM loop aerial to the AM LOOP
socket. Position the AM loop aerial for opti-
mum reception. Place the AM loop aerial on a
shelf, etc., or attach it to a stand or a wall with
screws (not supplied).
< Assembling > < Attaching to the wall >
Wall Screws (not supplied)
External
FM aerial
75 ohm
coaxial
cable

E-9
CD-XP350W(A)E1.fm02/1/23
CD-XP350W
ENGLISH
Preparation for Use
- System connections -
System connections (continued)
Speaker connection
Front speakers
Connect the black wire to the FRONT (-) terminal, and the red wire to the FRONT (+)
terminal.
Surround speakers
Connect the black wire to the SURROUND (-) terminal, and the grey wire to the SUR-
ROUND (+) terminal.
Caution:
To mount the surround speakers on the
wall
The design of the surround speakers allows them to be hung on the wall. Be sure to
use the type and size of screw that is shown to the below.
zIf you use other speakers with impedance lower than that
specified, the unit may be damaged. Front speakers: 8
ohms Surround speakers: 16 ohms
zDo not mistake the right and the left channels. The right
speaker is the one on the right side when you face the unit.
zDo not let the bare speaker wires touch each other.
zDo not allow any objects to fall into or to be placed in the
bass reflex ducts.
zDo not stand or sit on the speakers. You may be injured.
Incorrect
Black
Grey
Red
Front speaker (Right)
Surround speaker (Right) Surround speaker (Left)
Front speaker (Left)
1Drive one screw through the
wall for each speaker.
zMake sure that both the screw and the wall can support a load of 20 kg (45
lbs.).
zDrive the screws, so there is about a 5 mm (3/16") space between the wall and
the head of the screw.
2Mount the surround speaker
on the wall so that the screw
head is inserted into the slot
on the surround speaker.
5 mm (3/16") 3.2 mm (1/8")
Min. 22 mm (7/8") 9 mm (3/8")
5 mm (3/16")
Wall mounting screw
Min. 17 mm (11/16")
Wall surface
Wall surface

E-10
CD-XP350W(A)E1.fm02/1/23
CD-XP350W
ENGLISH
Preparation for Use
- System connections -
Setting the AC voltage selector
Check the setting of the AC voltage selector located on the rear panel before plug-
ging the unit into a wall socket. If necessary, adjust the selector to correspond to the
AC power voltage used in your area.
Turn the selector with a screwdriver until the appropriate voltage
number appears in the window (110 V, 127 V, 220 V or 230 V - 240 V
AC).
Connecting the AC power lead
After making all connections, plug the unit. If you plug the unit first,
the unit will enter the demonstration mode.
Notes:
zThe unit will start the tape initialisation when plugged in to the AC socket. During
this process, initialising sound will be heard and the unit cannot be turned on. Wait
until the process is finished.
zUnplug the AC power lead from the wall socket if the unit will not be in use for a
prolonged period of time.
Setting the FM/AM span selector
The International Telecommunication Union (ITU) has established that member
countries should maintain either a 100 kHz or a 50 kHz interval between broadcast-
ing frequencies of FM stations and 10 kHz or 9 kHz for AM station. The illustration
shows the 50/9 kHz zones (regions 1 and 3), and the 100/10 kHz zone (region 2).
Before using the unit, set the SPAN SELECTOR switch (on the rear panel) to the
interval (span) of your area.
To change the tuning zone:
Caution:
This operation will erase all data stored in memory including clock, timer settings,
tuner preset, and CD programme.
(230 - 240 V, 50/60 Hz)
Wall socket
230V
240V
1 Press the ON/STAND-BY button to enter the stand-by mode.
2 Set the SPAN SELECTOR switch (on the rear panel) as follows.
zFor 50 kHz FM interval (9 kHz in AM) 50/9
zFor 100 kHz FM interval (10 kHz in AM) 100/10
3 Whilst pressing down the CLOCK button and the EQUALIZER/X-BASS/DEMO but-
ton, press the ON/STAND-BY button until "CLEAR AL" appears.
Demonstration mode (See page 11.)

E-11
CD-XP350W(A)E2.fm02/1/23
CD-XP350W
ENGLISH
Preparation for Use
- General control / Remote control -
General control
Demonstration mode
To cancel the demonstration mode:
When the unit is in the power stand-by mode (demonstration mode), press the
EQUALIZER/X-BASS/DEMO button. The demonstration mode will be cancelled and
the display will disappear.
To return to the demonstration mode:
When the unit is in the power stand-by mode, press the EQUALIZER/X-BASS/DEMO
button again.
Note:
When the power is on, the EQUALIZER/X-BASS/DEMO button can be used to select
the extra bass and pre-programmed equaliser modes.
To turn the power on
Press the ON/STAND-BY button to turn the power on.
To set the unit to stand-by mode:
Press the ON/STAND-BY button again.
Remote control
Battery installation
Precautions for battery use:
zReplace all old batteries with new ones at the same time.
zDo not mix old and new batteries.
zRemove the batteries if the unit is not to be used for long periods of time. This will
prevent potential damage due to battery leakage.
Caution:
zDo not use rechargeable batteries (nickel-cadmium battery, etc.).
zInstalling the batteries incorrectly may cause the unit to malfunction.
Notes concerning use:
zReplace the batteries if the operating distance is reduced or if the operation
becomes erratic. Purchase 2 "AAA" size batteries (UM-4, R03, HP-16 or similar).
zPeriodically clean the transmitter on the remote control and the sensor on the unit
with a soft cloth.
zExposing the sensor on the unit to strong light may interfere with operation.
Change the lighting or the direction of the unit.
zKeep the remote control away from moisture, heat, shock, and vibrations.
Test of the remote control
The first time the unit is plugged in, the unit will enter
the demonstration mode. You will see words scroll.
1 Open the battery cover.
2 Insert the batteries according to the direction indicated in the bat-
tery compartment.
When inserting or removing the batteries, push them towards the battery terminals.
3 Close the battery cover.
Point the remote control directly at the remote
sensor on the unit.
The remote control can be used within
the range shown:
Press the ON/STAND-BY button. Does the pow-
er turn on? Now, you can enjoy the music.
Remote sensor
0.2 m - 6 m
(8" - 20')

E-12
CD-XP350W(A)E2.fm02/1/23
CD-XP350W
ENGLISH
Basic Operation
- Sound control -
Sound control
Volume control
Press the VOLUME ( or ) button to increase or decrease the volume.
Extra bass (X-BASS)/Pre-programmed
equaliser
(Main unit operation)
You can select the extra bass and pre-programmed equaliser modes with the same
button on the main unit.
Changing the mode:
When the EQUALIZER/X-BASS/DEMO button is pressed, the current mode setting
will be displayed. To change to a different mode, press the EQUALIZER/X-BASS/
DEMO button repeatedly until the desired sound mode appears.
(Remote control operation)
To enter or cancel the extra bass mode:
When the power is first turned on, the unit will enter the extra bass mode which
emphasises the bass frequencies, and "X-BASS" will appear. To cancel the extra
bass mode, press the X-BASS button.
Selecting a pre-programmed equaliser mode:
When the EQ-MODE button is pressed, the current mode setting will be displayed.
To change to a different mode, press the EQ-MODE button repeatedly until the
desired sound mode appears.
Note:
If the EQ-MODE button on the remote control is pressed in the extra bass mode, it
will be cancelled automatically.
012 29 30 MAXIMUM
.....
ROCK (X-BASS off)
X-BASS (X-BASS on)
FLAT (X-BASS off)
CLASSIC (X-BASS off)
The sound is not modified.
Bass frequencies are emphasised.
Bass and treble are emphasised.
POPS (X-BASS off) Bass and treble are slightly emphasised.
JAZZ (X-BASS off) Treble is cut a little.
Treble is reduced a lot.
VOCAL (X-BASS off) Vocals (midrange tones) are emphasised.
FLAT ROCK
POPS
JAZZ
CLASSIC
VOCAL

E-13
CD-XP350W(A)E2.fm02/1/23
CD-XP350W
ENGLISH
Basic Operation
- Setting the clock -
Setting the clock
In this example, the clock is set for the 24-hour (0:00) display.
Note:
The "CLOCK" or time will flash at the push of the CLOCK button when the AC power
supply is restored after a power failure or unplugging the unit.
Readjust the clock as follows.
To readjust the clock:
Perform "Setting the clock" from step 1. If the time display is flashing, step 3 (for
selecting the 24-hour or 12-hour display) will be skipped.
To change the 24-hour or 12-hour display:
1Press the ON/STAND-BY button to turn the power on.
2Press the CLOCK button and within 5 seconds, press the MEMO-
RY/SET button.
3Press the TUNING/TIME ( or ) button to select 24-hour or 12-
hour display and then press the MEMORY/SET button.
"0:00" The 24-hour display will appear.
(0:00 - 23:59)
"AM 12:00" The 12-hour display will appear.
(AM 12:00 - PM 11:59)
"AM 0:00" The 12-hour display will appear.
(AM 0:00 - PM 11:59)
Note that this can only be set when the unit is first installed or it has been reset.
[Refer to "Clearing all the memory (reset)" on page 29 for details.]
4Press the TUNING/TIME ( or ) button to adjust the hour and then
press the MEMORY/SET button.
zPress the TUNING/TIME ( or ) button once to advance the time by 1 hour.
Hold it down to advance continuously.
zWhen the 12-hour display is selected, "AM" will change automatically to "PM".
5Press the TUNING/TIME ( or ) button to adjust the minutes and
then press the MEMORY/SET button.
zPress the TUNING/TIME ( or ) button once to advance the time by 1
minute. Hold it down to change the time in 5-minute intervals.
zThe hour will not advance even if minutes advance from "59" to "00".
zThe clock begins counting from "0" seconds. (Seconds are not displayed.)
The time display will disappear after a few seconds.
To confirm the time display:
Press the CLOCK button.
The time display will appear for about 5 seconds.
1 Clear all the programmed contents. [Refer to "Clearing all the memory (reset)" on
page 29 for details.]
2 Perform "Setting the clock" from step 1.

E-14
CD-XP350W(A)E2.fm02/1/23
CD-XP350W
ENGLISH
CD Playback
- Listening to a CD (CDs) -
Listening to a CD (CDs)
This system can also play audio CD-R and CD-RW discs, but cannot record.
Some audio CD-R and CD-RW discs may not be playable due to the state of disc or
the device that was used for recording.
To interrupt playback:
Press the CD button on the remote control.
To resume playback from the same point, press the button.
To stop playback:
Press the button.
To remove the CDs:
Whilst in the stop mode, press the OPEN/CLOSE button.
The disc tray will open. Remove the two discs. Then, press the DISC SKIP button to
rotate the disc tray and remove the remaining disc.
After use:
Press the ON/STAND-BY button to enter the power stand-by mode.
1Press the ON/STAND-BY button to turn the power on.
2Press the CD button.
3Press the OPEN/CLOSE button to open the disc tray.
4Place the CD(s) on the disc tray, label side up.
When loading a third disc, press the DISC SKIP button to turn the
disc tray, then place the CD in the open position.
zCDs can be placed on any open position on the disc tray.
zBe sure to place 8 cm (3") CD(s) in the middle of the disc positions.
12 cm (5") 8 cm (3")
5Press the OPEN/CLOSE button to close the disc tray.
Total number of tracks on the CD
whose number is flashing Total playing time of the CD whose number is flashing
6To select the CD you want to listen to first, press one of 1 - 3
buttons on the remote control.
7Press the ( ) button to start playback.
zPlayback will begin from track 1 on the disc you have selected to play. After
that disc finishes playing, the next disc will automatically start playback.
zWhen the last track on the third disc has finished playing, the CD player will
stop automatically.
zWhen there is no CD in one of the disc 1 - 3 positions, that position will be
skipped and the next CD will be played.
Sound control (See page 12.)

E-15
CD-XP350W(A)E2.fm02/1/23
CD-XP350W
ENGLISH
CD Playback
- Listening to a CD (CDs) -
Listening to a CD (CDs) (continued)
To locate the beginning of a track
Notes:
zYou can locate the beginning of a track on a single disc only.
zThe or button on the remote control allows you to locate the begin-
ning of a track.
To locate the desired portion
Notes:
zNormal playback will resume when the / or / button is released.
zYou can locate the desired portion on a single disc only.
zWhen the end of the last track is reached during fast forward, "END" will appear on
the display and CD operation will be paused. When the beginning of the first track
is reached during fast reverse, the unit will enter the playback mode.
zThe or button on the remote control allows you to locate the desired
portion.
Starting playback with a desired track
You can play a disc starting with the desired track.
Notes:
zWhen the DISC SKIP button is pressed during playback, the next disc will begin
automatically.
zWhen one of the 1 - 3 buttons on the remote control is pressed during play-
back, the selected disc will begin automatically.
Caution:
zDo not place two CDs in one disc tray.
zDo not play discs with special shapes (heart- or octagon-shaped). It may cause
malfunctions.
zDo not push the disc tray whilst it is moving.
zDo not turn the disc tray by hand. This may cause malfunctions.
zIf the power fails whilst the tray is open, wait until the power is restored.
zIf the disc tray is stopped forcibly, "ER-CD10" will appear on the display for 3 sec-
onds and the unit will not function. If this occurs, press the ON/STAND-BY button
to enter the power stand-by mode and then turn the power on again.
zIf TV or radio interference occurs during CD operation, move the unit away from
the TV or radio.
zIf a disc is damaged, dirty, or loaded upside down, the disc will skip.
To move to the beginning of the next track:
Press the / button for less than 0.5 seconds during playback.
zYou can skip to any track by pressing the / button repeatedly until the de-
sired track number appears.
To restart the track being played:
Press the / button for less than 0.5 seconds during playback.
zYou can skip to any track by pressing the / button repeatedly until the de-
sired track number appears.
For audible fast forward:
Press and hold down the / button during playback.
For audible fast reverse:
Press and hold down the / button during playback.
1Whilst in the stop mode, press one of the 1 - 3 buttons on the
remote control or DISC SKIP button to select the desired disc.
2Press the / or / button to select the desired track.
Selected disc number
Selected track number
You can also select a track by pressing the or button on the remote
control.
3Press the ( ) button to start playback.
Playback of the selected track is started. When the end of last track of the disc
selected is reached, the next disc will be automatically started.

E-16
CD-XP350W(A)E2.fm02/1/23
CD-XP350W
ENGLISH
CD Playback
- Listening to a CD (CDs) -
Repeat play
All tracks on up to 3 discs, or a programmed sequence can be continuously
repeated.
To repeat a desired track:
Perform steps 1 - 4 in the "Programmed play" section and then press the ( )
button twice.
To cancel repeat play:
Press the ( ) button again.
" " will go out.
Random play
The tracks on the disc(s) can be played in random order automatically.
To cancel random play:
Press the button.
Notes:
zIf you press the button during random play, you can move to the track
selected next by the random operation. On the other hand, the button does
not allow you to move to the previous track. The beginning of the track being
played will be located.
zIn random play, the CD player will select and play tracks automatically. (You can-
not select the order of the tracks.)
Caution:
After performing repeat or random play, be sure to press the button. Otherwise, the
disc(s) will play continuously.
Programmed play
You can choose up to 32 selections for playback in the order you like.
Adding tracks to the programme:
If a programme has been previously stored, the "MEMORY" indicator will be dis-
played. Then follow steps 1 - 3 to add tracks. The new tracks will be stored after the
last track of the original programme.
Notes:
zOpening the disc tray automatically cancels the programmed sequence.
zEven if you press the ON/STAND-BY button to enter the stand-by mode or change
the function from CD to another, the programmed selections will not be cleared.
zDuring programme operation, random play is not possible.
To repeat all tracks on up to 3 discs:
Press the ( ) button twice.
Press the RANDOM button on the remote control to begin random
play.
1
Whilst in the stop mode, press one
of the 1 - 3 buttons on the remote
control to select the desired disc.
Selected disc number
2Press the / or / button to
select the desired track.
Selected track number
You can also select a track by pressing the or button on the remote
control.
3
Press the MEMORY/SET (MEMORY) button to save the track number.
Playback order
When the track is memorised, "MEMORY" will appear.
4Repeat steps 1 - 3 for other tracks. Up to 32 tracks can be pro-
grammed.
If you make a mistake, the programmed tracks can be cleared by pressing the
CLEAR button.
5Press the ( ) button to start playback.
To clear the programmed selections:
Press the CLEAR button on the remote control whilst the
"MEMORY" indicator is lit.
Each time the button is pressed, one track will be cleared,
beginning with the last track programmed. When all the
tracks are cleared, "MEMORY" will disappear.

E-17
CD-XP350W(A)E2.fm02/1/23
CD-XP350W
ENGLISH
Radio
- Listening to the radio -
Listening to the radio
Tuning
To receive an FM stereo transmission:
Press the TUNER (BAND) button to display the "ST" indicator.
z" " will appear when an FM broadcast is in stereo.
zIf the FM reception is weak, press the TUNER (BAND) button to extinguish the
"ST" indicator. The reception changes to monaural, and the sound becomes
clearer.
After use:
Press the ON/STAND-BY button to enter the power stand-by mode.
Note:
This product can receive FM stereo/FM monaural and AM monaural broadcasts. AM
stereo broadcasts will not be played in stereo.
1Press the ON/STAND-BY button to turn the power on.
2Press the TUNER (BAND) button repeatedly to select the desired
frequency band (FM or AM).
3Press the TUNING/TIME ( or ) button to tune in to the desired
station.
Manual tuning:
Press the TUNING/TIME button as many times as required to tune in to the de-
sired station.
Auto tuning:
When the TUNING/TIME button is pressed for more than 0.5 seconds, scanning
will start automatically and the tuner will stop at the first receivable broadcast sta-
tion.
Notes:
zWhen radio interference occurs, auto scan tuning may stop automatically at
that point.
zAuto scan tuning will skip weak signal stations.
zTo stop the auto tuning, press the TUNING/TIME button again.
FM stereo mode indicator
FM stereo receiving indicator
Sound control (See page 12.)

E-18
CD-XP350W(A)E2.fm02/1/23
CD-XP350W
ENGLISH
Radio
- Listening to the radio -
Memorising a station
You can store 40 AM and FM stations in memory and recall them at the push of a
button. (Preset tuning)
Note:
The backup function protects the memorised stations for a few hours should there be
a power failure or the AC power lead disconnection.
To recall a memorised station
To scan the preset stations
The stations saved in memory can be scanned automatically. (Preset memory scan)
To erase entire preset memory
1Perform steps 1 - 3 in "Tuning" on page 17.
2Press the MEMORY/SET button to enter the preset tuning saving
mode.
3Within 30 seconds, press the PRESET ( or ) button to select the
preset channel number.
Store the stations in memory, in order, starting with preset channel 1.
4Within 30 seconds, press the MEMORY/SET button to store that
station in memory.
If the "MEMORY" and preset number indicators go out before the station is
memorised, repeat the operation from step 2.
5Repeat steps 1 - 4 to set other stations, or to change a preset sta-
tion.
When a new station is stored in memory, the station previously memorised will
be erased.
Press the PRESET ( or ) button for less than 0.5 seconds to select
the desired station.
Preset channel Frequency and frequency band
This operation can be performed by pressing the TUNER PRESET ( or ) button
or or button on the remote control.
1 Press the PRESET ( or ) button for more than 0.5 seconds.
zThe preset number will flash and the programmed stations will be tuned in se-
quentially, for 5 seconds each.
zThis operation can be performed by pressing the TUNER PRESET ( or )
button or or button on the remote control.
2 Press the PRESET ( or ) button again when the desired station is located.
1 Press the ON/STAND-BY button to enter the stand-by mode.
2 Whilst pressing down the TUNER (BAND) button and the EQUALIZER/X-BASS/
DEMO button, press the ON/STAND-BY button until "TUNER CL" appears.
Tuning (See page 17.)

E-19
CD-XP350W(A)E2.fm02/1/23
CD-XP350W
ENGLISH
Tape Playback
- Listening to a cassette tape (TAPE 1) -
Listening to a cassette tape (TAPE 1)
To stop playback:
Press the button.
Note:
You cannot fast-forward or rewind the cassette in the TAPE 1 compartment.
Before playback:
zFor playback, use normal or low-noise tapes for the best sound.
(Metal or CrO tapes are not recommended.)
zDo not use C-120 tapes or poor-quality tapes, as they may cause mal-
functions.
zBefore loading a tape into the cassette compartment, tighten the slack
with a pen or a pencil.
1Press the ON/STAND-BY button to turn the power on.
2Press the TAPE (1 2) button to select TAPE 1.
3Open the cassette door by pushing the area marked " PUSH
EJECT".
4Load a cassette into the TAPE 1 cassette compartment with the
side to be played facing toward you.
5Press the ( ) button to start playback.
Sound control (See page 12.)
