Sony MHC-EC69i/C2 User manual

MHC-EC69i/C2
Mini Hi - Fi Shelf System
Key Features
Made for iPod®: charge, play and
control your iPod
2
Single disc CD player with CD-R/RW and
MP3 playback capability
1
100W (RMS) Total Power Output (50W x 2)
3
AM/FM tuner with 30 station presets
Remote control with full iPod menu control
Key Technologies
Made for iPod®
Charge, play, and control your compatible iPod.
2
Single Disc CD Player
With CD, CD -R/RW and MP3 Playback. Accommodates not only
factory -pressed CD-Audio discs, but also consumer- recorded CD -R and CD-RW discs .
1
2 -way 2-driver, Bass Reflex Speaker System
Woofer: 130 mm, cone type
Tweeter: 40mm, horn type
AM/FM Tuner with 30 Station Presets
Provides accurate, drift- free tuning of AM/FM stations
and allows you to preset up to 30 of your favorite stations: 10 AM and 20 FM.
100W (RMS) Total Power Output (50W x 2) .
3
Remote Control with Full iPod® Menu Control
Allows you to control your iPod from across
the room.

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 07/12/2010
MHC-EC69i/C2
Mini Hi - Fi Shelf System
Please visit the Dealer Source for current
information at www.sony.com/dealersource
Features
General
SpeakerTerminal: pig tale
System: 2 - way
Audio
Band: FM/AM
ExternalAntenna: Simple Type
Convenience
TimerEvents: Play/Sleep
Power Save Mode: Yes
Specifications
Audio
Digital - to - AnalogConverter: 44.1kHz/24bit
Format(s)Supported: CD,CD - R,CD - RW,MP3
AntennaSystem: Simple Type
Impedance: 6 ohms
CD Play Mode(s): Normal, Shuffle, Program,
Repeat
StationPreset(s): FM 20/AM 10
Equalizer: Preset EQ: 7
Audio Power Output: Channel - wise Amp
Measurement: 50W x 2
SpeakerType: 2way
Band: FM/AM
Convenience
Timer: Play/Sleep (Tuner); Play/Sleep (CD
Timer)
Inputs and Outputs
HeadphoneJack: Yes (3.5mm)
PC Audio Input(s): Yes
Power
OutputPower: 100W Total
BatteryType: Remote Battery Size/Type:
AA/Manganese
Speaker
WooferSize(s): 13cm
Tweeter: Unit: Horn, 4cm
Function
CD: Yes
Audio: Yes
DMPORT: Yes
Tuner: Yes
iPod1: Yes
Weights and Measurements
Dimensions(Approx.): Main Unit:200 x 306
x 415 (WHD); Front Speaker: 220 x 306 x
195 (WHD); Front Speaker: 220 x 306 x
195 (WHD)
Weight(Approx.): Main Unit: 5.3Kg; Front
Speaker: 2.3Kg; Front Speaker: 2.3Kg
Cord Length (Approx.): Supplied
Cable:1.5m
General
Power
Power Save Mode: Yes
Equalizer
Bass Boost function: DSGX
PresetEqualizer: 7
Supplied Accessories
RM - AMU009 Remote Control
TDM - iP10 Digital Media Port
UPC Code: 027242752276
1.NotallWMAandMP3filesmayplaybackduetofilevariations.
Playback depends on recording conditions.
2.Compatible with iPod touch, iPod nano 3rd generation, iPodclassic,
iPodnano2nd generation, iPod 5th generation, iPod nano 1st
generation, iPod 4th generation, iPod mini.
3.Unitaudiooutputtestedat6ohmsinfrequencyrange120Hzto10kHz
witha Total Harmonic Distortion of 0.07 percent.
©2009SonyElectronicsInc.Allrightsreserved.Reproduction in whole or
inpartwithoutwrittenpermissionisprohibited.Sony® isa trademarkof
Sony.iPod ® isatrademarkof Apple Computers, Inc. All other
trademarksare trademarks of theirrespectiveowners. Features and
specifications are subject to change without notice. Non - metricweights
and measures are approximate.
