Sharp SD-CX1W User manual

1-BIT DIGITAL AUDIO SYSTEM
SYSTÈME AUDIO NUMÉRIQUE 1-BIT
SISTEMA DE AUDIO DIGITAL 1-BIT
SD-CX1W
OPERATION MANUAL
MODE D’EMPLOI
MANUAL DE MANEJO
SHARP CORPORATION
Se reporter aux
pages F-1 à
F-56.
FRANÇAIS
Consulte las
páginas S-1 al
S-56.
ESPAÑOL
Please refer to
pages E-1 to
E-56.
ENGLISH
Downloaded from: http://www.usersmanualguide.com/

E-1
00/12/17 CX1W_E01-09.fm
ENGLISH
ENGLISH
Important Instruction
Introduction / Contents
Introduction
Thank you for purchasing this SHARP product. To obtain the best performance from
this product, please read this manual carefully. It will guide you in operating your
SHARP product.
Contents
Page
Important Instruction
Special Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 3
General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 5
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Controls and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 9
Preparation for Use
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
System Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 - 15
Basic Operation
General Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Sound Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
CD Playback
Listening to a CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 - 21
MD Playback
Listening to a MiniDisc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 - 24
Advanced CD/MD Playback
Direct Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Repeat or Random Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Programmed Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Page
Radio
Listening to the Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 - 29
MD Recording
Before Recording to a MiniDisc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Recording to a MiniDisc from a CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 - 34
Recording to a MiniDisc from the Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Checking Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
MD Editing
Titling a MiniDisc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37-39
Editing a Recorded MiniDisc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 - 43
Advanced Features
Timer and Sleep Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 - 48
Enhancing Your Stereo System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 - 50
References
What is a MiniDisc? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
MiniDisc System Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 - 54
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 - 56
Downloaded from: http://www.usersmanualguide.com/

E-2
CX1W_E01-09.fm00/12/17
ENGLISH
Important Instruction
Special Notes
Special Notes
CAUTION

This 1-Bit Digital Audio System is classified as a CLASS 1 LASER product.

The CLASS 1 LASER PRODUCT label is located on the rear cover.

Use of controls, adjustments or performance of procedures other than those spec-
ified herein may result in hazardous radiation exposure.
As the laser beam used in this compact disc player is harmful to the eyes, do not
attempt to disassemble the cabinet. Refer servicing to qualified personnel only.
Laser Diode Properties

Material: GaAIAs

Wavelength: 785 nm

Pulse time:
Read mode:0.8 mW Continuous
Write mode:max 10 mW 0.5S
min cycle 1.5S
Repetition
CAUTION - INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED
AVOID EXPOSURE TO BEAM .
VARNING - OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRRAR
ÄR URKOPPLADE. STRÅLEN ÄR FARLIG.
ADVARSEL - USYNLIG LASERSTRÅLING NÅR DEKSEL ÅPNES OG SIKKERHEDSLÅS
BRYTES. UNNGÅ EKSPONERING FOR STRÅLEN.
VARO! AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTIINA
NÄKYMÄTÖN LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEN.
VARNING - OSYNLIG LASERSTRÅLING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRREN
ÄR URKOPPLAD. BETRAKTA EJ STRÅLEN.
ADVARSEL - USYNLIG LASERSTRÅLING VED ÅBNING NÅR SIKKERHEDSAFBRYDERE
ER UDE AF FUNKTION. UNDGÅ UDSETTELSE FOR STRÅLING.
Downloaded from: http://www.usersmanualguide.com/

E-3
CX1W_E01-09.fm00/12/17
ENGLISH
Important Instruction
Special Notes
Special Notes (continued)
WARNING

When the ON/STAND-BY button is set at STAND-BY position, mains voltage is still
present inside the unit. When the ON/STAND-BY button is set at STAND-BY posi-
tion and the clock is displayed, the unit may be brought into operation by the timer
mode or remote control.

This unit contains no user serviceable parts. Never remove covers unless qualified
to do so. This unit contains dangerous voltages, always remove mains plug from
the socket before any service operation and when not in use for a long period.

To prevent fire or shock hazard, do not expose this appliance to dripping or splash-
ing. No objects filled with liquids, such as vases, shall be placed on the apparatus.
NOTES

US and foreign patents licensed from Dolby Laboratories.

SD-CX1W 1-Bit Digital Audio System consisting of SD-CX1W (main unit) and CP-
CX1W (speaker system).

The letters in brackets contained in the model number indicate the colour of the
product only. Operation and specifications are unaffected.
Note for users in Australia:

Copyright may exist in material you wish to record. Copying or broadcasting such
material without permission of the relevant licensees or owners of the copyright is
prohibited by law. SHARP is not in a position to authorise the copying or broad-
casting of copyright materials and nothing in this OPERATION MANUAL should be
implied as giving that authority.
For other countries:

Audio-visual material may consist of copyrighted works which must not be
recorded without the authority of the owner of the copyright. Please refer to the rel-
evant laws in your country.
Downloaded from: http://www.usersmanualguide.com/

E-4
CX1W_E01-09.fm00/12/17
ENGLISH
General Information
Precautions
Precautions
General

Please ensure that the equipment is positioned in a well-ventilated area and
ensure that there is at least 10 cm (4") of free space along the sides, top and back
of the equipment.

Do not place anything on top of the unit.

Do not expose the unit to moisture, to temperatures higher than 60°C (140°F) or to
extremely low temperatures.

If your system does not work properly, disconnect the AC power lead from the wall
socket. Plug the AC power lead back in, and then turn on your system.

No naked flame sources, such as lighted candles, should be placed on the appa-
ratus.

Attention should be drawn to the environmental aspects of battery disposal.

This unit should only be used within the range of 5°C - 35°C (41°F - 95°F).

Use the unit on a firm, level surface free from
vibration.

Keep the unit away from direct sunlight, strong
magnetic fields, excessive dust, humidity and
electronic/electrical equipment (home comput-
ers,facsimiles,etc.)which generateselectrical
noise.
10 cm (4") 10 cm (4")
10 cm (4")
10 cm (4")

In case of an electrical storm, unplug the unit for
safety.

Hold the AC power plug by the head when removing
it from the wall socket, as pulling the lead can dam-
age internal wires.

Do not remove the outer cover, as this may result in
electric shock. Refer internal service to your local
SHARP service facility.

The ventilation should not be impeded by covering
the ventilation openings with items, such as newspa-
pers, tablecloths, curtains, etc.
Downloaded from: http://www.usersmanualguide.com/

E-5
CX1W_E01-09.fm00/12/17
ENGLISH
General Information
Precautions / Accessories
Precautions (continued)
Warning:

The voltage used must be the same as that specified on this unit. Using this prod-
uct with a higher voltage other than that which is specified is dangerous and may
result in a fire or other type of accident causing damage. SHARP will not be held
responsible for any damage resulting from use of this unit with a voltage other than
that which is specified.

CD players use a laser pickup which can damage the eyes if viewed directly. Do
not look at the pickup, and do not touch the pickup directly.

This product is equipped with a cooling fan on its back for better heat radiation.
Volume control
The sound level at a given volume setting depends on speaker efficiency, location,
and various other factors. It is advisable to avoid exposure to high volume levels,
which occurs whilst turning the unit on with the volume control setting up high, or
whilst continually listening at high volumes.
Care of compact discs
Compact discs are fairly resistant to damage, however mistracking can occur due to an
accumulation of dirt on the disc surface. Follow the guidelines below for maximum enjoy-
ment from your CD collection and player.

Do not write on either side of the disc, particularly the non-label side from which signals
are read. Do not mark this surface.

Keep your discs away from direct sunlight, heat, and excessive moisture.

Always hold the CDs by the edges. Fingerprints, dirt, or water on the CDs can cause
noise or mistracking. If a CD is dirty or does not play properly, clean it with a soft, dry
cloth, wiping straight out from the centre, along the radius.
Accessories
Please confirm that the following accessories are included.
Note:
Only the above accessories are included.
Remote control 1 "AA" size batteries (UM/SUM-3, R6,
HP-7 or similar) 2
AM loop aerial 1 FM aerial 1
Speaker wire 2 AC power lead 1
Non-slip sheet for speakers 8
Downloaded from: http://www.usersmanualguide.com/

E-6
CX1W_E01-09.fm00/12/17
ENGLISH
General Information
Controls and Indicators
Controls and Indicators
Front panel Reference page
1.CD Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.CD Cover Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.Remote Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.Function Indicator
5.Timer Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.MD Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
8.MD Eject Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
9.MD Record Mode Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
10.CD/MD Play Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
11.MD Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
12.MD Play/Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
13.CD Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
14.CD Play/Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
15.Volume Up or Down Buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
16.Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
17.Erase Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
18.MD Record Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
19.Auxiliary/Demo Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16, 50
20.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
21.CD/MD Fast Reverse, Tuning Down Button . . . . . . . . . . . . 20, 23, 27
22.MD +10 Track Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
23.CD/MD Fast Forward, Tuning Up Button . . . . . . . . . . . . . . . 20, 23, 27
1
23
4
5
678910
12 13 14 15
16 17 18 19 20 21
11
22 23
Downloaded from: http://www.usersmanualguide.com/

E-7
CX1W_E01-09.fm00/12/17
ENGLISH
General Information
Controls and Indicators
Controls and Indicators (continued)
Multi-function LCD display
1.Level Meter/Character Information/Frequency Indicator
2.Band Selector Indicator
3.Record Indicator
4.CD/MD Play Indicator
5.Top Position Indicator
6.Record Mode Indicator
7.MD Record Pause Indicator
8.CD/MD Repeat Indicator
9.Surround Indicator
10.Random Play Indicator
11.Programme Play Indicator
12.Sound Synchronised Recording Indicator
13.Track Edit Indicator
14.TOC Indicator
15.FM Stereo Indicator
16.FM Stereo Mode Indicator
17.Sleep Indicator
18.Timer Play/Recording Indicator
2
1
3
4
6
5
78
10
12 13 14
15
16
17
18
9
11
Downloaded from: http://www.usersmanualguide.com/

E-8
CX1W_E01-09.fm00/12/17
ENGLISH
General Information
Controls and Indicators
Rear panel Reference page
1.Cooling Fan
2.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.Span Selector Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.FM 75 Ohms Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.FM Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6.AM Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.AM Loop Aerial Terminal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
8.Voltage Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
9.AC Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
10.Auxiliary Input Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Speaker system
1.Speaker Grille
2.Tweeter
3.Woofer
4.Bass Reflex Duct
5.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Placing the speaker system:
There is no distinction between the right and the left speakers.
Speaker grilles are removable:
Make sure nothing comes into contact with the speaker diaphragms when you
remove the speaker grilles.
The arrow on the back of the net must face upward.
12
910
3
4
7
2
3
45
1
5
6
8
Downloaded from: http://www.usersmanualguide.com/

E-9
CX1W_E01-09.fm00/12/17
ENGLISH
General Information
Controls and Indicators
Controls and Indicators (continued)
Remote control Reference page
1.Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.CD/MD Play Mode Select Button
3.MD Record Mode Button
4.On/Stand-by Button
5.MD Record Button
6.Top Position Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
7.Track Edit Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
8.Sound Synchronise Record Button . . . . . . . . . . . . . . . . . . . . . . . .50
9.Volume Up or Down Buttons
10.CD/MD Fast Reverse, Tuning Down Button
11.Extra Bass Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
12.CD/MD Programme Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
13.Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
14.Name/TOC-Edit Button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
15.Timer/Delete Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18, 44
16.Time Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21, 24
17.Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
18.MD Stop Button
19.MD Play/Pause Button
20.CD Stop Button
21.CD Play/Pause Button
22.Tuner (Band) Button
23.Auxiliary Button
24.Surround Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
25.CD/MD Fast Forward, Tuning Up Button
26.Preset Equalizer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
27.Character Input/CD, MD, Tuner Direct Buttons . . . . . . . . . . . . .25, 37
28.Display Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21, 24
29.Recording Level/Cursor/Tuner Preset Buttons . . . . . . . . . .28, 34, 37
30.CD/MD Edit Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
1
2
3
4
5
6
7
8
9
10
11
12
*
*
*
*
*
*
*
*
*
*
18
19
20
21
22
23
24
25
26
27
28
29
30
*
*
*
*
*
*
13
14
15
16
17
Buttons with "*" mark in the illustration can be operated on the remote control only.
Other buttons can be operated both on the main unit and the remote control.
Downloaded from: http://www.usersmanualguide.com/

E-10
CX1W_E10-17.fm00/12/17
ENGLISH
Preparation for Use
Remote Control
Remote Control
Battery installation
1Open the battery cover.
2Insert the supplied batteries according to the direction indicated in
the battery compartment.

When inserting or removing the batteries, push them towards the battery termi-
nals.
3Close the battery cover.
Precautions for battery use:

Replace all old batteries with new ones at the same time.

Do not mix old and new batteries.

Remove the batteries if the unit will not be used for long periods of time. This will
prevent potential damage due to battery leakage.
Caution:

Do not use rechargeable batteries (nickel-cadmium battery, etc.).

Installing the batteries incorrectly may cause the unit to malfunction.
Notes concerning use:

Replace the batteries if the operating distance is reduced or if the operation
becomes erratic. Purchase 2 "AA" size batteries (UM/SUM-3, R6, HP-7 or similar).

Periodically clean the transmitter on the remote control and the sensor on the ste-
reo system with a soft cloth.

Exposing the sensor on the stereo system to strong light may interfere with opera-
tion. Change the lighting or the direction of the stereo system.

Keep the remote control away from moisture, heat, shock, and vibrations.
Test of the remote control
Check the remote control after checking all connections have been made correctly.
(See pages 11 - 15.)
Face the remote control directly to the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy the
music.
Remote sensor
0.2 m - 6 m
(8" - 20')
Downloaded from: http://www.usersmanualguide.com/

E-11
CX1W_E10-17.fm00/12/17
ENGLISH
Preparation for Use
System Connections
System Connections
FM aerial
Left speaker
Right speaker
AM loop aerial
Downloaded from: http://www.usersmanualguide.com/

E-12
CX1W_E10-17.fm00/12/17
ENGLISH
Preparation for Use
System Connections
Aerial connection
Supplied FM aerial:
Supplied AM loop aerial:
Note:
Placing the aerial on the stereo system or near the AC power lead and speaker wires
may cause noise pickup. Place the aerial away from the stereo system for better
reception.
Installing the AM loop aerial:
External FM or AM aerial
Use an external FM or AM aerial if you require better reception. Consult your dealer.
Notes:

When an external FM aerial is used, disconnect the supplied FM aerial wire from the FM
75 OHMS terminal.

When using an external AM aerial, be sure to keep the wire of the AM loop aerial con-
nected.
Speaker connection
Connect the wire with the black line to the (-) and transparent one to the (+) .
Caution:

Connect the speaker wires to the speakers first, then to the unit.

Use speakers with an impedance of 6 ohms or more, as lower impedance speak-
ers can damage the unit.

Do not mistake the right and the left channels. The right speaker is the one on the
right side when you face the unit.

Do not let the bare speaker wires touch each other.

Do not stand or sit on the speakers. You may be injured.
Connect the FM aerial wire to the FM 75 OHMS
terminal and position the FM aerial wire in the di-
rection where the strongest signal can be re-
ceived.
Connect the AM loop aerial wire to
the AM and GND terminals. Position
the AM loop aerial for optimum re-
ception. Place the AM loop aerial on
a shelf, etc., or attach it to a stand or
a wall with screws (not supplied).
< Assembling > < Attaching to the wall >
White
Black
Wall Screws
AM loop aerial 15 m (49 feet)
7.5 m
(25 feet)
External AM aerial
Earth rod
External FM aerial
2
13
Left speaker
Clear
Black line
Right speaker
Downloaded from: http://www.usersmanualguide.com/

E-13
CX1W_E10-17.fm00/12/17
ENGLISH
Preparation for Use
System Connections
System Connections (continued)
To mount the speakers on the wall
The design of the speakers allows them to be hung on the wall. Be sure to use the type and
size of screw that is shown below.
1Drive one screw into the wall for each speaker as shown in the
illustration.

Make sure that both screw and the wall can support a load of 20 kg (45 lbs.).

Drive the screws, so there is about a 5 mm (3/16") space between the wall and the
head of the screw.
2Mount the speaker on the wall so that the screw head is inserted
into the slot on the speaker.
How to apply non-slip sheets
3.2 mm (1/8")
9 mm (3/8")
5 mm
(3/16")
Min.22 mm (7/8")
Wall surface Wall mounting screw
Min. 17 mm (11/16")
5 mm (3/16")
Wall surface
Adhere the non-slip sheets to the
bottom of the speaker. Adhere the non-slip sheets on the lower back of the speaker, and then
mount it to the wall.
Downloaded from: http://www.usersmanualguide.com/

E-14
CX1W_E10-17.fm00/12/17
ENGLISH
Preparation for Use
System Connections
Setting the AC voltage selector
Check the setting of the AC voltage selector located on the rear panel before plug-
ging the unit into an AC socket. If necessary, adjust the selector to correspond to the
AC power voltage used in your area.
Turn the selector with a screwdriver until the appropriate voltage number
appears in the window (110 V, 127 V, 220 V or 230 V - 240 V AC).
Connecting the AC power lead
After making all connections, plug the unit. If you plug the unit first, the unit
will enter the demonstration mode (see page 16).
Notes:

Plug the AC power lead into an AC socket, after any connections.

Unplug the AC power lead from the AC socket if the unit will not be in use for a pro-
longed period of time.
AC Plug Adaptor
In areas (or countries) where an AC socket as shown in illustration is used, con-
nect the unit using the AC plug adaptor supplied with the unit, as illustrated. The AC
plug adaptor is not included in areas where the AC wall socket and AC power plug
can be directly connected (see illustration ).
Note for users in Australia and New Zealand:
An AC plug adaptor is not supplied if the lead has an Australian Standard plug.
Downloaded from: http://www.usersmanualguide.com/

E-15
CX1W_E10-17.fm00/12/17
ENGLISH
Preparation for Use
System Connections
System Connections (continued)
Setting the FM/AM span selector
The International Telecommunication Union (ITU) has established that member coun-
tries should maintain either a 100 kHz or a 50 kHz interval between broadcasting fre-
quencies of FM stations and 10 kHz or 9 kHz for AM station. The illustration shows
the 50/9 kHz zones (regions 1 and 3), and the 100/10 kHz zone (region 2).
Before using the unit, set the SPAN SELECTOR switch (on the rear panel) to the
interval (span) of your area.
To change the tuning zone:
1Unplug the AC power lead from the AC socket.
2Set the SPAN SELECTOR switch (on the rear panel) as follows.

For 50 kHz FM interval (9 kHz in AM) 50/9

For 100 kHz FM interval (10 kHz in AM) 100/10
3Plug the AC power lead to the AC socket.
Caution:
This operation will erase all data stored in memory including clock, timer settings,
tuner preset, and CD or MiniDisc programme.
Downloaded from: http://www.usersmanualguide.com/

E-16
CX1W_E10-17.fm00/12/17
ENGLISH
Basic Operation
General Control
General Control
Demonstration mode
The first time the unit is plugged in, the unit will enter the demonstration mode. You
will see words scroll.
To cancel the demonstration mode:
When the unit is in the power stand-by mode (demonstration mode), press the AUX
(DEMO) button. The unit will enter the low power consumption mode.
To return to the demonstration mode:
When the unit is in the power stand-by mode, press the AUX (DEMO) button again.
You can select and change to the colour
you like from 7 different colours.
To change the display illumination bright-
ness
To dim:
To brighten:
1 Press the ON/STAND-BY button to turn the power on.
2 Press the DISPLAY button for 2 seconds or more.
3 Press the REC LEVEL/CURSOR or button to select "COLOR".
4 Press the ENTER button.
5 Press the REC LEVEL/CURSOR or button.
INITIAL The colour changes automatically along with the operation.
FIXED You can select a colour you like.
DAILY The colour changes according to the day of the week.
RANDOM The colour changes at random.
6 Press the ENTER button.
7 When FIXED or DAILY is selected:

Press ENTER button after selecting your favourite colour with the REC REV-
EL/CURSOR or button.

You can select the colour you like from 7 colours (COLOR 1 to COLOR 7).
1 Press the ON/STAND-BY button to turn the power on.
2 Hold the DISPLAY button down for 2 seconds or more.
3 Press the REC LEVEL/CURSOR or button to select "DIMMER ON ?".
4 Press the ENTER button.

The light goes out and characters are dimmed.
1 Hold the DISPLAY button down for 2 seconds or more.
2 Press the ENTER button.
Downloaded from: http://www.usersmanualguide.com/

E-17
CX1W_E10-17.fm00/12/17
ENGLISH
Basic Operation
Sound Control
Sound Control
Volume control
Press the VOLUME button to increase the volume and the VOLUME button for
decreasing.
Bass control
When the X-BASS button is pressed, the unit will enter the extra bass mode which
emphasises the bass frequencies. To cancel the extra bass mode, press the X-BASS
button.
Surround
Press the SURROUND button to allow you to enjoy music that seems to surround you.
"SURROUND" will appear.
Press the SURROUND button again to cancel the surround mode.
"SURROUND" will go out.
Equalizer
Press the PASS/EQ button repeatedly until the desired sound mode appears.
Bass is emphasised. Cancelled.
Bass and treble are emphasised.The sound is not modified.
Vocals (midrange tones)
are emphasised.
Treble is reduced.
Downloaded from: http://www.usersmanualguide.com/

E-18
CX1W_E18-26.fm00/12/17
ENGLISH
Basic Operation
Setting the Clock
Setting the Clock
In this example, the clock is set for 9:30 15. 02 '01 .
To confirm the time display:
[When the unit is in the stand-by mode]
Press the DISPLAY button on the remote control.
The time display will appear for about 5 seconds.
[When the power is on]
Press the TIMER/DELETE button.
Within 10 seconds, press the REC LEVEL/CURSOR or button.
The time display will appear for about 10 seconds.
Note:
The clock setting will be cleared when the unit is unplugged or the power failure
occurs.
To reset the clock:
Perform "Setting the Clock" from the beginning.
1Press the ON/STAND-BY button to turn the power on.
2Press the TIMER/DELETE button.
3Within 10 seconds, press the REC LEVEL/CURSOR or button to
select the "TIME ADJUST".
4Within 10 seconds, press the ENTER button.
5Press the REC LEVEL/CURSOR or button to adjust the year,
and then press the ENTER button.
6Press the REC LEVEL/CURSOR or button to adjust the month,
and then press the ENTER button.
7Press the REC LEVEL/CURSOR or button to adjust the date,
and then press the ENTER button.
8Press the REC LEVEL/CURSOR or button to adjust the hour,
and then press the ENTER button.
9Press the REC LEVEL/CURSOR or button to adjust the minutes,
and then press the ENTER button.

The hour will not advance even if minutes advance from "59" to "00".

The clock starts from "0" second. (Seconds are not displayed.) The time display
will disappear after a few seconds.
Downloaded from: http://www.usersmanualguide.com/

E-19
CX1W_E18-26.fm00/12/17
ENGLISH
CD Playback
Listening to a CD
Listening to a CD
To interrupt playback:
Press the CD button.
To resume playback from the same point, press the CD button again.
To stop playback:
Press the CD button.
Load a CD firmly with the
label side facing toward you.
1Press the ON/STAND-BY button to turn the power on.
2Press the CD button.
3Press the CD button to open the CD cover.
4Set a CD and press the CD button.
Total number of tracks Total playing time
5Press the CD button to start playback.

When the last track has finished playing, the CD player will stop automatically.
Downloaded from: http://www.usersmanualguide.com/
