Sharp QT-CD250H User manual

QT-CD250H
OPERATION MANUAL
MODEL
HK <P=001>
PORTABLE CD STEREO SYSTEM
Thank you for purchasing this SHARP product.
For the best performance, read this manual care-
fully. It will guide you in operating your SHARP
product.
NOTE FOR USERS IN THE U.K.
SERVICE INFORMATION
In the unlikely event of your equipment requiring repair,
please contact the dealer or supplier from whom it was
purchased. Where this is not possible, please contact
the telephone number listed below. You will then be
given details of how to obtain service.
- 0345-125387 -
Please note; all calls will be charged at local rate.
Certain replacement parts and accessories may be ob-
tained from our main parts distributor.
WILLOW VALE ELECTRONICS LTD.
In the unlikely event of this equipment requiring repair
during the guarantee period, you will need to provide
proof of the date of purchase to the repairing company.
Pleasekeepyourinvoiceorreceipt,whichissuppliedat
the time of purchase.
Themainsleadofthisproductisfittedwithanon-rewire-
able(moulded)plugincorporating a 3Afuse.Shouldthe
fuse need to be replaced, a BSI or ASTA approved BS
1362 fuse marked or and of the same rating as
above,whichis also indicatedonthepin face oftheplug
must be used.
Alwaysrefitthefusecoverafterreplacingthefuse.Never
use the plug without the fuse cover fitted.
In the unlikely event of the socket outlet in your home
not being compatible with the plug supplied, cut-off the
mains plug and fit an appropriate type.
DANGER:
The fuse from the cut-off plug should be removed and
the cut-off plug destroyed immediately and disposed of
in a safe manner.
Under no circumstances should the cut-off plug be in-
serted elsewhere into a 13A socket outlet as a serious
electric shock may occur.
To fit an appropriate plug to the mains lead, follow the
instructions below:
IMPORTANT:
The wires in the mains lead are coloured in accordance
with the following code:
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of this
productmaynotcorrespondwiththe coloured markings
identifyingtheterminalsinyourplug,proceedasfollows:
● The wire which is coloured blue must be connected to
the plugterminal which is marked Nor coloured black.
● The wire which is coloured brown must be connected
totheplug terminal whichismarkedLor coloured red.
Ensure that neither the brown nor the blue wire is con-
nected to the earth terminal in your three pin plug.
Before replacing the plug cover, make sure that:
MANCHESTER 0161-682-1415
READING 01189-876444
● If the new fitted plug contains a fuse, its value is the
same as that removed from the cut-off plug.
● Thecordgripisclampedoverthesheathofthemains
lead and not simply over the lead wires.
IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED
ELECTRICIAN.
QT-CD250H(SUK)TINSE0043SJZZ

TO <P=001>
SPECIAL NOTES
●The letters in brackets contained in the model
number indicate the colour of the product only.
Operation and specifications are unaffected.
●Recording and playback of any material may
requireconsent, whichSHARPis unableto give.
Please refer particularly to the provisions of the
Copyright Act 1956, the Dramatic and Musical
Performers Protection Act 1958, the Performers
Protection Acts 1963 and 1972 and to any sub-
sequent statutory enactments and orders.
●This equipment complies with the requirements
of Directives 89/336/EEC and 73/23/EEC as
amended by 93/68/EEC.
●When the ON/STAND-BY switch is set at
STAND-BY position, mains voltage is still pres-
ent inside the unit.
Warning:
This unit contains no user serviceable parts. Never
remove covers unless qualified to do so. This unit
containsdangerousvoltages,alwaysremovemains
plug from the socket before any service operation
and when not in use for a long period.
Warning:
To prevent fire or shock hazard, do not expose this
appliance to dripping or splashing. No objects filled
with liquids, such as vases, shall be placed on the
apparatus.
Caution:
Use of controls, adjustments or performance of pro-
ceduresotherthanthosespecifiedhereinmayresult
in hazardous radiation exposure.
As the laser beam used in this compact disc player
isharmfultotheeyes,donotattempttodisassemble
the cabinet. Refer servicing to qualified personnel
only.
ACCESSORIES
AC power lead ×1 Remote control ×1
Notes:
●The AC power lead and remote control are located in the packing material.
●Parts and accessories mentioned in this operation manual other than those in the drawing are not
included.
QT-CD250H(SUK)TINSE0043SJZZ
1

<P=002>
PRECAUTIONS
■General
●Do not use oil, solvents, petrol, paint thinners or
insecticides on the unit.
●Do not expose the unit to moisture, to tempera-
tures higher than 60˚C (140˚F) or to extreme low
temperatures.
●Keep the unit away from direct sunlight, strong
magnetic fields, excessive dust, humidity and
electronic/electrical equipment (home compu-
ters, facsimiles, etc.) which generates electrical
noise.
●Hold the AC power plug by the head when re-
moving it from the AC socket, as pulling the lead
can damage internal wires.
●When cleaning the heads, pinch roller, etc,
remove the AC power plug from the wall socket
as the unit contains high voltages.
Donotremovetheoutercover,asthismayresult
in electric shock. Refer internal service to your
local SHARP service facility.
●Use the unit on a firm, level surface free from
vibration, and do not place anything on the top
of the unit.
●If the unit does not work properly whilst in use,
settheON/STAND-BYswitchtoSTAND-BYand
then to ON again.
●If an electrical storm is taking place near you, it
is suggested that you disconnect the AC power
lead from the AC socket for safety.
●The ventilation should not be impeded by cover-
ing the ventilation openings with items, such as
newspapers, tablecloths, curtains, etc.
●No naked flame sources, such as lighted cand-
les, should be placed on the apparatus.
●Attention should be drawn to the environmental
aspects of battery disposal.
●The apparatus is designed for use in moderate
climate.
Warning:
Thevoltageusedmustbethesameasthatspecified
on this unit. Using this product with a higher voltage
other than which is specified is dangerous and may
result in a fire or other type of accident causing
damage.SHARPwillnotbeheldresponsibleforany
damage resulting from use of this unit with a voltage
other than that which is specified.
■Condensation
Sudden temperature changes, storage or operation
in an extremely humid environment may cause con-
densation inside the cabinet (CD pickup, tape
heads,etc.) or on the transmitter LEDonthe remote
control.
Condensation can cause the unit to malfunction.
If this happens, leave the power on with no disc (or
cassette)intheunituntilnormalplaybackispossible
(about 1 hour). Wipe off any condensation on the
transmitterLEDwithasoftclothbeforeoperatingthe
unit.
Warning:
CD players use a laser pickup which can damage
theeyes if vieweddirectly.Do not lookatthe pickup,
and do not touch the pickup directly.
■Battery use
●Replace all old batteries with new ones at the
same time.
●Do not mix old and new batteries.
●Remove the batteries if they are weak or if the
unitwill not be used for long periods oftime.This
will prevent potential damage due to battery
leakage.
●Batteries are not included.
Caution:
●Do not use rechargeable batteries (nickel-cad-
mium battery, etc.).
■Care of compact discs
Compact discs are fairly resistant to damage, how-
ever mistracking can occur due to an accumulation
of dirt on the disc surface.
Followtheguidelinesbelowformaximumenjoyment
from your CD collection and player.
●Donotwriteoneithersideofthedisc,particularly
the non-label side. Signals are read from the
non-label side. Do not mark this surface.
●Keep your discs away from direct sunlight, heat,
and excessive moisture.
●Always hold the CDs by the edges. Fingerprints,
dirt, or water on the CDs can cause noise or
mistracking. If a CD is dirty or does not play
properly, clean it with a soft, dry cloth, wiping
straight out from the centre, along the radius.
■Cassette tape
●For playback, use normal or low-noise tape for
the best sound. (Metal or CrO2tape is not rec-
ommended.)
For recording, use only normal tape.
●Do not use C-120 tapes, tapes with large
diameter reels, or poor-quality tapes, as they
may cause malfunctions.
●Before loading a tape into the cassette compart-
ment, tighten the slack with a pen or pencil.
●Cassettes have removable tabs which prevent
accidental recording or erasing from taking
place. Removing the tab will protect the corre-
sponding side from being erased. Cover the tab
holes with adhesive tape to erase or record
again. Side A (1)
Tab for side B (2) Tab for side A (1)
QT-CD250H(SUK)TINSE0043SJZZ
2

<P=003>
NAMES OF CONTROLS AND INDICATORS
11. (TAPE) Record Button
12. (TAPE) Play Button
13. (TAPE) Rewind Button
14. (TAPE) Fast Forward Button
15. (TAPE) Stop/Eject Button
16. (TAPE) Pause Button
17. Cassette Compartment
18. CD Compartment
19. CD Eject Button
10. (CD) Stop Button
3(TUNER) Tuning Down Button
11. (CD) Repeat Button
3(TUNER) Band Selector Button
12. (TUNER) Preset Memory Button
13. Extra Bass Button
14. (CD) Play/Pause Button
3(TUNER) Tuning Up Button
15. (CD) Track Up/Cue Button
3(TUNER) Preset Up Button
16. (CD) Track Down/Review Button
3(TUNER) Preset Down Button
17. Volume Up/Down Buttons
18. Stand-by, On/Function Switch
19. (CD) Play Indicator
20. (CD) Repeat Indicator
21. (CD) Pause Indicator
22. Extra Bass Indicator
23. (TUNER) Memory Indicator
24. (TUNER) FM Stereo Mode Indicator
25. (TUNER) FM Stereo Indicator
26. Battery Compartment
27. FM Telescopic Rod Aerial
28. Headphone Socket
29. AC Power Input Socket
30. Backup Memory Battery Compartment
31. (CD) Play/Pause Button
3(TUNER) Tuning Up Button
32. (CD) Track Down/Review Button
3(TUNER) Preset Down Button
33. (CD) Stop Button
3(TUNER) Tuning Down Button
34. (CD) Repeat Button
3(TUNER) Band Selector Button
35. (TUNER) Memory Button
36. (TUNER) Clear Button
37. (CD) Track Up/Cue Button
3(TUNER) Preset Up Button
38. Extra Bass Button
39. Volume Up/Down Buttons
26 27 28 29
30
31
32 38
35
34
33
36
37
39
12345678
10
11
12
13
14
15
16
17
18
21 22 23 24
20
19 25
9
QT-CD250H(SUK)TINSE0043SJZZ
3

TO <P=001>
POWER SOURCE
■AC power
To AC INPUT
AC 230-240 V, 50 Hz
To an AC socket
Connect the AC power lead to the AC power input
socket, then connect the AC power lead plug to an
AC socket.
Notes:
●If the unit will not be used for a long period of
time, remove the AC power lead from the AC
socket.
●Connection of the AC power lead to the unit
disconnects the batteries.
●Never use a power lead other than the one
supplied. Use of a power lead other than the one
supplied may cause an electric shock or fire.
■Battery power
5
46
132
1Disconnect the AC power lead, and remove the
battery compartment cover.
2Insert 6 "D" size batteries (UM/SUM-1, R20,
HP-2 or similar) into the battery compartment.
●Insert the batteries according to the direction
indicated on the rear panel.
●When inserting or removing the batteries ③and
⑥, push them towards the ë battery terminals.
●Installing the batteries incorrectly may cause the
unit to malfunction.
3Replace the battery compartment cover.
Note:
Replace the batteries when they become weak
and/or recording or playback is impaired. This may
occur even though radio broadcasts are audible.
REMOTE CONTROL
15
15
1Remove the battery compartment cover on the
remote control.
2Insert 2 "AA" size batteries (UM/SUM-3, R6,
HP-7 or similar) into the battery compartment on
the remote control.
●When inserting or removing the batteries, push
them towards the ë battery terminals.
●Installing the batteries incorrectly may cause the
unit to malfunction.
Notes:
●Replace the batteries if the operating distance is
reduced or if the operation becomes erratic.
●Periodically clean the transmitter LED on the
remote control and the sensor on the main unit
with a soft cloth.
●Exposing the sensor on the main unit to strong
light may interfere with operation. Change the
lighting or the direction of the unit.
●Keep the remote control away from moisture,
excessive heat, shock, and vibrations.
Remote sensor
0.2 m - 6 m
(8" - 20’)
QT-CD250H(SUK)TINSE0043SJZZ
4

<P=002>
COMPACT DISC OPERATION
■CD playback
1Set the function switch to CD.
2Press the CD EJECT button to open the CD
compartment.
3Place a compact disc on the spindle, label side
up.
●8 cm (3") discs may be played without an adap-
tor.
4Closethe CD compartmentby firmly pushingthe
right corner of it.
Total number of
tracks Total playing time
5Press the PLAY/PAUSE ( 0 6 ) button to start
playback from track 1.
6Press the VOLUME W button to increase the
volume and the VOLUME X button to decrease
the volume.
7Pressthe X-BASS buttonto emphasise thebass
region of the frequency spectrum.
The "X-BASS" indicator will light up.
Press the X-BASS button again to cancel the
extra bass mode.
The "X-BASS" indicator will go out.
To interrupt playback:
Press the PLAY/PAUSE ( 0 6 ) button during play-
back.
Press the PLAY/PAUSE ( 0 6 ) button again to
resume playback.
To stop playback:
Press the STOP (■) button.
Precautions:
●When"no dISC" ortracknumber is displayed,
the power is connected.
If you will not be using the CD player, set the
ON/STAND-BY switch to STAND-BY.
●Do not open the CD compartment whilst the
disc is rotating.
●If the disc is damaged, dirty, or loaded upside
down, "Er" or "no dISC" will appear in the
display.
Clean, replace, or reload the disc properly.
●Keep foreign objects out of the CD compart-
ment.
●Subjecting the unit to shock or vibration may
cause mistracking.
●Keep the CD compartment closed except
when loading discs.
●Playing certain compact discs at a high vol-
ume may cause mistracking. In this case,
listen at a lower volume.
●The temperature range for playing compact
discsis recommendedto be5˚C (41˚F)-35˚C
(95˚F).
●If TV or radio interference occurs during CD
operation, move the unit away from the TV or
radio.
ON/STAND-BY
(Function)
PLAY / PAUSE
TUNING
STOP
TUNING
REPEAT
BAND
CUE
PRESET
REVIEW
PRESET
234
TUNING
/
PRESET
/
PRESET
TUNING
BAND
QT-CD250H(SUK)TINSE0043SJZZ
5

<P=003>
(Continued)
PLAY / PAUSE
TUNING
STOP
TUNING
REPEAT
BAND
CUE
PRESET
REVIEW
PRESET
TUNING
/
PRESET
/
PRESET
TUNING
BAND
■APSS (Auto Program Search System)
APSS automatically locates the beginning of any
track.
To listen again to the track being played:
Press the DOWN ( 3/5 ) button for less than 0.5
seconds during playback.
To move to the beginning of the next track:
Press the UP ( 2 / 4 ) button for less than 0.5
seconds during playback.
Notes:
●Toskip a number of tracks at one time,pressthe
UP ( 2 / 4 ) or DOWN ( 3 / 5 ) button
repeatedly until the desired track number is
shown.
●To start playback from a desired track, press the
UP ( 2/4 ) or DOWN ( 3/5 ) button whilst
in the stop mode to select the track number, and
then press the PLAY/PAUSE ( 0 6 ) button.
■Repeat play
Duringplayback,presstheREPEAT/BAND( R )but-
ton repeatedly to select the play mode.
Each time the button is pressed, the display will
change as follows:
Flashes 1 track repeat play
Appears All track repeat play
Disappears Normal play
Repeat indicator
Note:
●When using repeat play, be sure to press the
STOP (■) button after you are through listening.
Otherwise, the CD(s) will play continuously.
■Cue and review
1Load a disc and begin playback.
2Hold down the CUE ( 2/4 ) button for audible
fast forward, and hold down the REVIEW ( 3/
5 ) button for audible fast reverse.
3Normal playback will resume when the REVIEW
( 3/5 ) or CUE ( 2/4 ) button is released.
Notes:
●When the end of the disc is reached whilst
cueing, "End" will appear in the display and CD
operation is paused. Press the REVIEW ( 3/
5 ) button for fast reverse or press the STOP
(■) button to stop CD operation.
●If the beginning of the disc is reached whilst
reviewing, the mode will automatically switch to
normal playback at that point.
QT-CD250H(SUK)TINSE0043SJZZ
6

<P=004>
CASSETTE OPERATION
■Tape playback
1Set the function switch to TAPE.
2Load the cassette into the cassette compart-
ment.
3Press the PLAY button.
4To advance the tape, press the STOP/EJECT
button, then press the F FWD button. To rewind,
press the STOP/EJECT button, then press the
REWIND button.
To interrupt playback:
Press the PAUSE button during playback.
Press the PAUSE button again to resume playback.
To stop playback:
Press the STOP/EJECT button.
Precautions:
●Be sure not to press the PLAY and REWIND
buttons simultaneously, or the tape will become
damaged.
●Before changing from one tape operation to an-
other, press the STOP/EJECT button.
●Do not press the PAUSE button whilst the fast
forward or rewind operations are in progress.
The F FWD or REWIND button will not be re-
leased when the tape end is reached. Once this
occurs, press the STOP/EJECT button.
ON/STAND-BY
(Function)
HEADPHONES
●Before plugging in or unplugging the head-
phones, make sure the volume level is reduced.
●Be sure your headphones have a 3.5 mm (1/8")
diameter plug and are between 16 ohms and 50
ohms impedance. The recommended imped-
ance is 32 ohms.
●Connect the headphones plug to the PHONES
socket located on the rear of the unit. The spea-
kers will be automatically disconnected. Adjust
the volume by using the VOLUME control.
QT-CD250H(SUK)TINSE0043SJZZ
7

<P=005>
RADIO OPERATION
■Tuning
1Set the function switch to TUNER.
2Press the REPEAT/BAND ( R ) button to select
the desired frequency band. (FM ST, FM or AM)
●To receive an FM stereo transmission, press the
REPEAT/BAND( R ) button so that the "ST" indi-
cator on the display lights up.
●The " j " indicator lights up when an FM broad-
cast is in stereo.
3Press the TUNING ( X or W ) button to tune into
the desired station.
FM STEREO
FM MONO
AM
ON/STAND-BY
(Function)
TUNER
MEMORY
PLAY / PAUSE
TUNING
STOP
TUNING
REPEAT
BAND
CUE
PRESET
REVIEW
PRESET
TUNING
/
PRESET
/
PRESET
TUNING
TUNER
MEMORY
CLEAR
BAND
Manual tuning:
Press the TUNING ( X or W ) button as many times
as required to adjust the frequency shown on the
display to the frequency of the desired station.
Auto tuning:
When the TUNING ( X or W ) button is pressed for
more than 0.5 seconds, scanning will start automat-
ically and the tuner will stop at the first receivable
broadcast station.
Notes:
●Whenradiointerferenceoccursduringautoscan
tuning, auto scan tuning may stop automatically
at that point.
●If a weak station signal is found during auto scan
tuning, the station will be skipped.
●To stop the auto tuning, press the TUNING ( X
or W ) button again.
●If the FM reception is poor, press the RE-
PEAT/BAND ( R ) button so that the "ST" indica-
tor goes out.
Althoughthereceptionchangestomonaural,the
sound becomes clearer.
Aerial adjustment:
FM AM
After use:
Set the ON/STAND-BY switch to STAND-BY.
QT-CD250H(SUK)TINSE0043SJZZ
8

TO <P=001>
(Continued)
■Preset tuning
You can store up to 30 stations in memory (30
stationsconsistingofanycombinationofFMandAM
stations you like) and recall them at the push of a
button. FM stations can be recalled in either stereo
or mono.
1Tune to the desired station.
(Perform steps 1 - 3 in the "Tuning" section on
page 8.)
2Press the TUNER MEMORY button.
Preset number
3Within 5 seconds, press the PRESET ( X or W )
buttonuntilthepresetnumbertobeprogrammed
flashes in the display.
4Within 5 seconds, press the TUNER MEMORY
button to store that station in the selected station
preset number memory.
●If the "MEMORY" and preset number indicators
go out before the station is memorised, repeat
the operation from step 2.
●The preset numbers in step 2 are displayed
starting from the low numbers which have not
been assigned. If the preset numbers are as-
signed in order, step 3 can also be omitted.
If you want to change the station assigned to a
presetnumber, select that preset numberinstep
3.
5Repeat steps 1 - 4 to set other preset stations,
or to change a preset station.
■To recall a memorised station
1Set the function switch to TUNER.
2Press the PRESET ( X or W ) button to recall the
desired preset channel number.
●Iftherearenostationsmemorised,thisoperation
can not be performed.
■To clear all memorised stations
1Set the function switch to TUNER.
2Press the TUNER MEMORY button.
3PressthePRESET ( W or X )buttontoselectthe
channel number you want to erase.
4Within 5 seconds, press the CLEAR button on
the remote control.
■Howtobackupthepresettuningstations
When the backup memory battery is installed, the
contents of the preset tuning can be stored even
when the power is turned off.
1Remove the backup memory battery compart-
ment cover located on the bottom of the unit.
2Insert 3 "AA" size batteries (UM/SUM-3, R6,
HP-7 or similar) into the backup memory battery
compartment.
●When inserting or removing the batteries, push
them towards the ë battery terminals.
●Installing the batteries incorrectly may cause the
unit to malfunction.
Notes:
●Whenthe backup memory batteriesare installed
in the unit, the memory recalls the last station
received even after setting the ON/STAND-BY
switch to STAND-BY or unplugging the unit from
AC power.
It also stores the sound level.
●If the backup memory batteries are not inserted
andthepowerisdisconnected,thetuner’spreset
memories will be erased.
●Replace the backup memory batteries approxi-
mately once a year.
Caution:
●When inserting or replacing the batteries for the
backupmemory,connect theACpower leadand
set the ON/STAND-BY switch to ON. This will
extend battery life.
QT-CD250H(SUK)TINSE0043SJZZ
9

<P=002>
RECORDING
●When recording important selections, be sure to
makeapreliminarytesttoensurethatthedesired
material is being properly recorded.
●The ALC (Automatic Record Level Control) cir-
cuit automatically controls the level of the input
signal used for recording.
●The VOLUME control may be adjusted with no
effect on the recorded signal. (Variable Sound
Monitor)
●Metal and CrO2tapes cannot be used for recor-
ding.
■Recording from the built-in CD player
1Set the function switch to CD.
●Load the disc to be recorded.
2Load the cassette into the cassette compart-
ment.
3Press the RECORD button.
4PressthePLAY/PAUSE( 0 6 )buttonontheCD.
To stop recording:
ON/STAND-BY
(Function)
STOP
TUNING PLAY / PAUSE
TUNING
REPEAT
BAND
Press the STOP/EJECT button.
The tape will stop.
Note:
●If the STOP(■) or PLAY/PAUSE ( 0 6 ) button
on the CD player is pressed whilst recording, or
if the CD comes to its end, the tape deck will not
stop.
To record a specific track:
Press the UP ( 2/4 ) or DOWN ( 3/5 ) button
on the CD player until the desired track number is
displayed, then start recording.
■Recording from the built-in radio
1Set the function switch to TUNER.
●Tune in to the station to be recorded.
2Loada blank cassette into thecassettecompart-
ment.
3Press the PAUSE button.
4Press the RECORD button.
5Press the PAUSE button again.
To stop recording:
Press the STOP/EJECT button.
■Erasing a recorded tape
1Set the function switch to TAPE.
2Load the tape to be erased into the cassette
compartment.
3Press the RECORD button.
MAINTENANCE
■Internal care
●DonottouchtheLaserpickuplens.Iffingerprints
or dust accumulate on the pickup, clean it gently
with a dry cotton swab.
●Dirty heads, capstan or pinch roller can cause
poor sound and tape jams. Clean these parts
with a cotton swab moistened with commercial
head/pinch roller cleaner or isopropyl alcohol.
●After long use, the deck’s heads and capstan
may become magnetised, causing poor sound.
Demagnetise these parts once every 30 hours
of playing/recording by using a commercial tape
head demagnetiser. Read the demagnetiser’s
instructions carefully before use.
■External care
●Periodicallywipethecabinetwithasoftclothand
a diluted soap solution, then wipe with a dry
cloth.
●Do not use chemically treated cleaning cloths or
other chemicals.
QT-CD250H(SUK)TINSE0043SJZZ
10

<P=003>
SPECIFICATIONS
SHARP reserves the right to make design and specification changes for product improvement without
prior notice.
●General
Power source: AC 230-240 V, 50 Hz
DC 9 V ["D" size (UM/SUM-1, R20
or HP-2) battery ×6]
DC 4.5 V ["AA" size (UM/SUM-3,
R6 or HP-7) battery ×3 for backup
memory]
Power
consumption: 8 W
Output power: RMS; 4.6 W (2.3 W + 2.3 W)
(DC operation, 10 % T.H.D.)
MPO; 8.4 W (4.2 W + 4.2 W)
(AC operation, 10 % T.H.D.)
Speakers: 10 cm (4") full-range speaker x 2
Output
terminals: Headphones; 16-50 ohms (recommended; 32 ohms)
Dimensions: Width; 400 mm (15-3/4")
Height; 158 mm (6-1/4")
Depth; 212 mm (8-3/8")
Weight: 2.7 kg (6.0 lbs.) without batteries
●Compact disc player
Type: Compact disc
Signal
readout: Non-contact, 3-beam semi- conductor laser pickup
Audio
channels: 2
Filter: 8-times oversampling digital filter
D/A converter: 1-bit D/A converter
Wow and
flutter: Unmeasurable (less than 0.001% W. peak)
●Radio
Frequency
range: FM; 87.5 - 108 MHz AM; 522 - 1,620 kHz
●Tape recorder
Frequency
response: 50 - 14,000 Hz (Normal tape)
Signal/noise
ratio: 50 dB
Wow and
flutter: 0.25 % (WRMS)
Motor: DC 9 V electric governor
Bias system: AC bias
Erase
system: Magnet erase
SHARP ELECTRONICS (U.K.) LTD.
Sharp House, Thorp Road, Newton Heath, Manchester, M40 5BE
SHARP CORPORATION
9906
TINSE0043SJZZ A0002.TO
TERMS OF GUARANTEE
1.
2.
3.
4.
5.
6.
7.
Sharp Customer Information Centre - Telephone [phone]
This guarantee shall only apply to faults which are due to inferior workmanship or materials. It does not
cover faults or damage caused by accident, misuse, fair wear and tear, neglect, tampering with the product,
or repair other than by a Service Facility appointed by Sharp.
As this product is intended for private domestic use only, the guarantee will not apply if the product is used
in the course of a business, trade or profession.
To benefit from this guarantee, any fault which occurs must be notified to Sharp, or its appointed Service
Facility within one year from the date this product was purchased. Proof of purchase must be provided.
This guarantee is offered as an additional benefit to your statutory rights, and does not affect these rights
in any way.
In the unlikely event of this product requiring repair, please contact the supplier from whom it was purchased.
Where this is not possible, please contact the Sharp Customer Information Centre on the telephone number
given below.
The guarantee does not cover carriage costs, jewelled styli, audio tapes, compact discs or batteries.
No person has any authority to vary the terms or conditions of this guarantee.
Sharp Electronics (UK) Ltd. (“Sharp”) guarantees to provide for the repair, or at its option the replacement, of
this product subject to the conditions listed below:-
If you have any difficulty operating this product, or would like information on other Sharp products, please
telephone the Sharp Customer Information Centre on the number given below.
QT-CD250H(SUK)TINSE0043SJZZ
