Sharp 21FL94 User manual

1
Dimension: 140mm x 215mm
COLOR TELEVISION
OPERATION MANUAL
MODEL
21FL94
B246 WJ
READ THIS OPERATION MANUAL
COMPLETELY BEFORE OPERATING
THIS PRODUCT.
CONTENTS
PAGE
• IMPORTANT INFORMATION ......................................... 02
• Supplied Accessories ................................................... 02
• IMPORTANT SAFEGUARDS ............................ 03 ~ 04
• Before Operating Your Television ................................ 05
• Antenna Connections ...................................... 05 ~ 06
• Quick Reference Control Operation ............... 07 ~ 08
• EZ SETUP during First Use ........................................... 09
• Demo Mode .................................................................... 10
• Accessing the MAIN MENU screen without
Remote Control .............................................................. 10
• Language ........................................................................ 11
• Timer .................................................................. 12 ~ 17
Sleep Timer ................................................................ 12
Clock Set .................................................................... 13
ON Timer ....................................................... 14 ~ 15
OFF Timer ..................................................... 16 ~ 17
• Video Adjust ................................................................... 18
• Audio Adjust .................................................................. 19
• Audio Select ...................................................... 20 ~ 21
MTS (Multichannel TV Sound) .................................. 20
INTERNAL SPEAKER SWITCH ................................. 20
FAO (Fixed Audio Output) ........................................ 20
• Closed Caption .............................................................. 22
• VIEW TIMER ...................................................... 23 ~ 25
• Ch Setup ............................................................ 26 ~ 31
EZ Setup ..................................................................... 26
Channel Setting ............................................ 27 ~ 29
Personal Preference .................................................. 30
Universal Plus Function ........................................... 31
• Set Up ................................................................ 32 ~ 34
Energy Save ............................................................... 32
Blue Screen ................................................................ 33
Auto Input .................................................................. 34
• Using the Video and Audio Input Terminals ... 35 ~ 36
• Using the Audio Output Terminals ............................... 37
• Operation of Remote Control .......................... 38 ~ 41
• Specifications ................................................................ 42
• Before Calling for Service ............................................. 43
• Calling for Service ......................................................... 43
21FL94_01_EN 27/2/04, 8:56 am1

2
Dimension: 140mm x 215mm
Welcome to the SHARP Family. We are pleased that you are now the owner of a SHARP Color Television
– built for outstanding quality, reliability and performance.
Every SHARP Color Television set is tuned and adjusted for proper color and sound, and has passed
through the most stringent quality control tests at the factory. We have prepared this OPERATION MANUAL
so that you may adjust the picture and color to your personal viewing preference.
We sincerely hope that you receive the greatest satisfaction and enjoyment from your new SHARP Color
Television set for years to come.
Please read these instructions carefully, and keep them handy for your future reference.
Model No.:
Serial No.:
IMPORTANT
To aid reporting in case of loss or theft, please record the TV’s
model and serial numbers in the space provided. The numbers
are located at the rear of the TV.
IMPORTANT INFORMATION
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO WET LOCATIONS.
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with
arrowhead within a triangle is
intended to tell the user that
parts inside the product are a
risk of electric shock to
persons.
The exclamation point within a
triangle is intended to tell the
user that important operating
and servicing instructions are
in the papers with the
appliance.
Supplied Accessories
321 654 987
100
0
TV • CATV • VCR • DVD
ABCD
PERSONAL PREFERENCE
9
VCR-CH
8
FLASHBACK
POWER (DVD/VCR)
REC
PLAY
:
L
STOP
FWD
)
REW
(
PAUSE
J
POWER
DISPLAY
CATV
INPUT
TV
DVD VCR
ENTER
;:
CH
8
VOL
–VOL
+
9
CH
MENU MUTE
g
SKIP
f
Infrared Remote Control
108WJ
Dry batteries size “AA”/
1.5 V cc AC Plug Adaptor
CAUTION:
•Do not place the AC power cord under the TV set or other heavy items.
•To prevent fire, never place any type of candle or naked flames on the top or near the TV set.
•To prevent fire or shock hazard, do not expose this products to dripping or splashing. No objects filled with
liquids, such as vases, should be placed on the product.
21FL94_02-04_EN 19/3/04, 11:51 am2

3
Dimension: 140mm x 215mm
IMPORTANT SAFEGUARDS
CAUTION: Please read all of these instructions before you operate your television and save
these instructions for later use.
Electrical energy can perform many useful functions. This unit has been engineered and manufactured to
assure your personal safety. BUT IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK
OR FIRE HAZARDS. In order not to defeat the safeguards incorporated in this equipment, observe the
following basic rules for its installation, use and servicing.
1. Unplug this television equipment from the wall outlet before cleaning.
2. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
3. Do not use attachments not recommended by the television equipment manufacturer as they may
cause hazards.
4. Do not use this television equipment near water —for example, near a bathtub, washbowl, kitchen sink
or laundry tub, in a wet basement, or near a swimming pool, etc.
5. Do not place this equipment on an unstable cart, stand, or table. The television equipment may fall,
causing serious injury to a child or an adult, and serious damage to the equipment.
Use only with a cart or stand recommended by the manufacturer or sold with the
television equipment.
Television equipment and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the equipment and cart combination
to overturn.
6. Wall or shelf mounting should follow the manufacturer’s instructions, and should use a mounting kit
approved by the manufacturer.
7. Slots and openings in the cabinet and the back or bottom are provided for ventilation, and to insure
reliable operation of the television equipment and to protect it from overheating, these openings must
not be blocked or covered. This television equipment should not be placed in a built-in insulation such
as a bookcase unless proper ventilation is provided.
8. The openings should never be covered with a cloth or other material, and the bottom openings should
not be blocked by placing the television equipment on a bed, sofa, rug, or other similar surface. This
television equipment should never be placed near or over a radiator or heat register.
9. This television equipment should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supplied to your home, consult your television
dealer or local power company.
For television equipment designed to operate from battery power, refer to the operating instructions.
If the plug does not fit, ask your electrician to replace your obsolete outlet. Do not modify the plug and
defeat this safety feature.
10. Do not allow anything to rest on the power cord. Do not locate this television equipment where the cord
will be abused by persons walking on it.
11. As a safety feature, television equipment is equipped with a 2-wire polarized plug (one plug blade
bigger than the other.) The 2-wire polarized plug will fit only one way into the power outlet.
If the plug does not fit, ask your electrician to replace your obsolete outlet. Do not modify the plug and
defeat this safety feature.
12. Follow all warnings and instructions marked on the television equipment.
13. If an outside antenna is connected to the television equipment, be sure the antenna system is grounded
so as to provide some protection against voltage surges and built-up static charges.
21FL94_02-04_EN 19/3/04, 11:51 am3

4
Dimension: 140mm x 215mm
IMPORTANT SAFEGUARDS (Continued)
EXAMPLE OF ANTENNA GROUNDING
ACCORDING TO NATIONAL ELECTRICAL CODE.
ANTENNA LEAD-IN WIRE
GROUND CLAMP
ANTENNA DISCHARGE UNIT
GROUND CLAMPS
14. For added protection for this television equipment during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This
will prevent damage to the equipment due to lightning and power-line surges.
15. An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching such power lines or circuits as
contact with them might be fatal.
16. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
17. Never push objects of any kind into this television equipment through cabinet slots as they may touch
dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid
of any kind on the television equipment.
18. Do not attempt to service this television equipment yourself as opening or removing covers may
expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
19. Unplug this television equipment from the wall outlet and refer servicing to qualified service personnel
under the following conditions:
A. When the power cord or plug is damaged or frayed.
B. If liquid has been spilled into the television equipment.
C. If the television equipment has been exposed to rain or water.
D. If the television equipment does not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as improper adjustment of other
controls may result in damage and will often require extensive work by a qualified technician to
restore the television equipment to normal operation .
E. If the television equipment has been dropped or the cabinet has been damaged.
F. When the television equipment exhibits a distinct change in performance —this indicates a need
for service.
20. Upon completion of any service or repairs to this television equipment, ask the service technician to
perform routine safety checks to determine that the television is in safe operating condition.
21. When replacement parts are required, be sure the service technician has used replacement parts
specified by the manufacturer that have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other hazards.
GROUNDING CONDUCTORS
ELECTRIC
SERVICE
EQUIPMENT
POWER SERVICE GROUNDING ELECTRODE
SYSTEM
21FL94_02-04_EN 19/3/04, 11:51 am4

5
Dimension: 140mm x 215mm
Location
• For normal operation, your TV should be located in an area of the room where cool adequate ventilation
is provided. Do not place the back of the television set in a place where free airflow will be restricted.
• Any magnetic force may disturb the color picture. Make sure that magnets, electric clocks, toys using
magnets or any other magnetic substance, such as iron are kept well away from the TV set.
Power
Your TV operates on 110-220 Volts, 50/60 Hz (normal household current).
Note:
• If the set will not be used for a long period, such as during a vacation, unplug the set from the wall
outlet to economize power. (If the TV set is plugged in, a slight current still flows, even with the
POWER BUTTON in the OFF position.)
• Lines and other noise may appear in TV broadcast images when an FM tuner or radio is located near
the TV and both radio and TV broadcasts are being received. Should such noise appear, turn off
either the TV or the radio.
• If you are listening to an AM broadcast, turn the TV off. AM broadcast signals may not be received
due to interference from the TV.
LBefore using the television, prepare the Remote Control
To use the remote control, insert batteries first.
Insert the batteries
• With your thumbnail, pull up the slit as indicated by the arrow to remove the back cover. Insert two
batteries (size “AA”/ 1.5 V cc). Be sure to match the battery e/dterminals with the e/dmarks inside
the compartment.
Before Operating Your Television
Battery
Cover
Pull up
Antennas
• The antenna requirements for good color television reception are more important than those for
black & white television reception. For this reason, a good quality outdoor antenna is strongly
recommended.
The following is a brief explanation of the type of connections that are provided with the various
antenna systems:
Antenna Connections
F-type connector
75-ohm coaxial cable (round)
300-ohm twin-lead cable (flat)
1. A 75 ohm system is generally a round cable with
F-type connector that can easily be attached to a
terminal without tools (not supplied).
2. A 300 ohm system is a flat “twin-lead” cable that
can be attached to a 75 ohm terminal through a
300-75 ohm ADAPTOR (not supplied).
21FL94_05-10_EN 19/3/04, 11:52 am5

6
Dimension: 140mm x 215mm
Antenna Connections (Continued)
OUT
A
IN
B
PR
PB
Y
IN1
LINE
OUT
R
L
AUDIO
VIDEO
R
L
COMPONENT
REAR OF TV
75-ohm
coaxial cable
300-ohm
twin-lead
VHF/UHF ANTENNA
VHF/UHF ANTENNA
300/75-ohm
ADAPTOR
(Not supplied)
or
A. Combination VHF/UHF Antennas
OUTDOOR ANTENNA CONNECTION
•Use one of the following two diagrams if you connect an outdoor antenna.
A: Using a VHF/UHF combination outdoor antenna.
B: Using separate VHF and/or UHF outdoor antenna.
•Connect an outdoor antenna cable lead-in to the COAXIAL CABLE CONNECTOR on the rear of the
TV set.
CABLE TV (CATV) CONNECTION
•A 75 ohm coaxial cable connector is built into the set for easy hookup. When connecting the 75 ohm
coaxial cable to the set, screw the 75 ohm cable to the COAXIAL CABLE CONNECTOR.
•Some cable TV companies offer “premium pay channels”. Since the signals of these premium pay
channels are scrambled, a cable TV converter/descrambler is generally provided to the subscriber by
the cable TV company. This converter/descrambler is necessary for normal viewing of the scrambled
channels. (Set your TV on channel 3 or 4. Typically one of these channels is used. If this is unknown,
consult your cable TV company.) For more specific instructions on installing cable TV, consult your
cable TV company. One possible method of utilizing the converter/descrambler provided by your
cable TV company is explained below.
Please note: RF switch equipped with position A/B (not provided) is required.
“A”position on the RF switch (not supplied) : You can view all unscrambled channels using the TV’s
channel keys.
“B”position on the RF switch (not supplied) : You can view the scrambled channels via the converter/
descrambler using the converter’s channel keys.
Note:
•Consult your SHARP Dealer or Service Center for the type of splitter, RF switch or combiner that
might be required.
B. Separate VHF/UHF Antenna
Cable TV converter/
descrambler
(not supplied)
Two-set
signal
splitter
(not
supplied)
Cable TV Line
RF switch (not supplied)
OUT IN
P R
P B
Y
IN1
LINE
OUT
R
L
AUDIO
VIDEO
R
L
COMPONENT
IN OUT
300-ohm
twin-lead
300-ohm
twin-lead
75-ohm coaxial
cable
VHF
ANTENNA
UHF
ANTENNA
COMBINER
(not supplied)
or
REAR OF TV
F-type connector
75-ohm coaxial cable
When connecting the RF cable to the TV set, do not
tighten F-type connector with tools.
If tools are used, it may cause damage to your TV
set.
(The breaking of Internal circuit, etc.)
F-type connector should be finger tightened only
NOTICE
21FL94_05-10_EN 19/3/04, 11:52 am6

7
Dimension: 140mm x 215mm
Quick Reference Control Operation
LLocation of Controls
Front Panel
Quick Reference Control Operation
CHANNEL UP/DOWN
(8) Selects next higher channel.
(9) Selects next lower channel.
SENSOR AREA FOR
REMOTE CONTROL
POWER
Press →On.
Press again →Off.
VOLUME UP/DOWN
(+) Increases sound.
(–) Decreases sound.
VIDEO IN 2 L-AUDIO-R
MENU.
Press →Accesses MAIN MENU.
Press again →Exits MAIN MENU.
(INSIDE DOOR)
ON TIMER indicator
Light up red when the ON
TIMER is set.
To open the door
Using the projection located under the “PULL-OPEN”indication,
pull and lift the door open.
To close the door
Using the projection, lower the door until closed.
Caution:
•When opening or closing the door, do not insert your fingers into
the gap between the door and front panel. This may result in an
injury.
P R
P B
Y
IN 1
LINE
OUT
R
L
AUDIO
VIDEO
R
L
COMPONENT
P R
P B
Y
IN 1
LINE
OUT
R
L
AUDIO
VIDEO
R
L
COMPONENT
Rear Panel
ANTENNA/CABLE INPUT TERMINAL COMPONENT TERMINALS
IN 1 TERMINALS
LINE OUT TERMINALS
21FL94_05-10_EN 19/3/04, 11:52 am7

8
Dimension: 140mm x 215mm
Basic Remote Control Functions
Infrared Transmitter Window
CATV/DVD-TV/VCR MODE buttons
Press TV/VCR, sends power and
channel select commands (Channel
up/down and Random Access buttons)
to the TV and VCR control.
Press CATV/DVD, sends power and
channel select commands to a cable
TV converter and DVD control.
DISPLAY
Press →Displays receiving channel for
4 seconds.
Press 2 times →Displays Off Timer,
Sleep Timer, View Timer and Clock for
4 seconds.
Press 3 times →Removes display.
•
Temporarily displays receiving channel
when in Closed Caption mode.
INPUT
Press →Switch to external video
INPUT 1 mode or COMPONENT
mode.
Press 2 times →Switch to external
video INPUT 2 mode.
Press 3 times →Switch back to the
original TV mode.
See page 36.
ENTER
Used in some instances where a Cable
Converter Box requires an “enter”
command after selecting channels,
when using the REMOTE KEYPAD
button. (See page 38)
CHANNEL UP/DOWN
(8) Selects next higher channel.
(9) Selects next lower channel.
•See pages 27 ~ 29 for channel
presetting.
•Moves the “a”mark of the MENU
screens.
SKIP/VCR-CH
See page 38
REC
See page 38
POWER
Press →On.
Press again →Off.
REMOTE KEYPAD
Accesses any channel from keypad.
FLASHBACK
Returns to previous channel.
PERSONAL PREFERENCE
With the Personal Preference buttons,
you can program your favorite
programs by using the 4 categories A,
B, C and D. The channels can be
accessed quickly by using these
buttons. (See page 30.)
VOLUME UP/DOWN
(+) Increases sound.
(–) Decreases sound.
•In menu mode, changes or selects
the TV adjustments.
MENU
Press →Accesses MAIN MENU.
Press again →Exits MAIN MENU.
MUTE
Press →Mutes sound.
Press again →Restores sound.
•CLOSED CAPTION appears when
sound is muted.
POWER (DVD/VCR)
Press →On.
Press again →Off.
DVD/VCR CONTROL
See page 38.
321
654
987
100 0
TV • CATV • VCR • DVD
ABCD
PERSONAL PREFERENCE
9 VCR-CH 8
FLASHBACK
POWER (DVD/VCR)
REC
PLAY
:
L
STOP
FWD
)
REW
(
PAUSE
J
POWER
DISPLAY
CATV
INPUT
TV
DVD VCR
ENTER
;:
CH
8
VOL
–VOL
+
9
CH
MENU MUTE g SKIP f
Note:
•The above shaded buttons on the Remote Control glow in the dark. To use the glow-in-the-dark display on the
remote control, place it under a fluorescent light or other lighting.
•The phosphorescent material contains no radioactive or toxic material, so it is safe to use.
•The degree of illumination will vary depending on the strength of lighting used.
•The degree of illumination will decrease with time and depending on the temperature.
•The time needed to charge the phosphorescent display will vary depending on the surrounding lighting.
•Sunlight and fluorescent lighting are the most effective when charging the display.
Quick Reference Control Operation (Continued)
21FL94_05-10_EN 19/3/04, 11:52 am8

9
Dimension: 140mm x 215mm
LWhen you turn on the TV for the first time, it will automatically
memorize the broadcast channels.
Please perform the following instructions before pressing the
POWER button.
(1) Insert the batteries into the remote control. (See page 5)
(2) Connect the antenna cable to the TV set. (See page 5 ~ 6)
(3) Plug in the AC POWER cord to the wall outlet.
1Press POWER on the TV set or on the Remote Control to turn
on the TV. The SELECT LANGUAGE mode will be displayed.
2Press CH ( 8 ) or ( 9 ) to select “ENGLISH”, “ESPAÑOL (SPANISH)”
or “FRANCAIS (FRENCH)”.
3Press VOL (+) or (–) to SET LANGUAGE and access EZ SETUP
mode.
4Press VOL (+) .
The tuner will automatically search for the broadcast
and cable TV channels. (The CH No. will
automatically increase when it appears.)
If you want to stop the EZ SETUP process once it
has started, press
VOL (–) and it will be canceled.
If you want to SETUP again, please refer to page
26 on EZ SETUP.
To cancel EZ SETUP
Press
VOL (–) .
5Once EZ SETUP is completed, the lowest channel number
memorized will be displayed.
Note:
•If EZ SETUP does not memorize all the channels in your region, please refer to page 27 ~ 29
for more information on manually memorizing the channels using CHANNEL SETTING.
•It may be difficult to PRESET when the broadcast signals are weak, the channel cycle frequency is
incorrect or frequency jamming is occurring around the area. Please refer to pages 27 ~ 29 for
more information on manually memorizing the channels using CHANNEL SETTING.
FR NCA I S
ENGL I SH
ESPAÑOL
FAVORABIDIOMA LE
A
SE EC . : CH 8/9
VO
L
AJ :USTE L+ –/
FR NCA I S
ENGL I SH
ESPAÑOL
A
SE ECT : CH 8/9
VO
L
SE :TL+–/
LANGUAGSELECT E
CABLE
TSART SETUP?ZE
ANTENNCONNECT A
TARTS
TS OP
OR
AUTO RGGAMM I NORP
WA I TPLE EAS
STA
TSOP
125
RT
2
;:
VOL
–VOL
+
:
VOL
+
321
654
987
100 0
ABCD
PERSONAL PREFERENCE
9 VCR-CH 8
FLASHBACK
POWER (DVD/VCR)
POWER
DISPLAY
CATV
INPUT
TV
DVD VCR
ENTER
;:
CH
8
VOL
–VOL
+
9
CH
MENU MUTE g SKIP f
POWER
POWER
CH
(8)/ (9)
MENU
VOL
(+)/(–)
(EZ SETUP mode)
EZ SETUP during First Use
(On the Set) (Remote Control)
(SELECT LANGUAGE mode)
CH
8
9
CH
or
21FL94_05-10_EN 19/3/04, 11:52 am9

10
Dimension: 140mm x 215mm
Demo Mode
•To quickly learn more about the TV set, press and hold for
more than three seconds both
CH (
88
88
8 ) and (
99
99
9 ) or MENU on
the TV set. The TV set will go into DEMO mode and briefly
explain the various features.
•To cancel DEMO mode, again press both CH (
88
88
8 ) and (
99
99
9 ) or
MENU on the TV set.
Example:
DEMO mode display
Accessing the MAIN MENU screen without Remote Control
•If you misplaced your Remote Control you can still access most settings
via the MAIN MENU screen when you press MENU on the TV set.
•Some features of your TV set will not be accessible without the Remote
Control. If you lost your Remote Control, contact a Sharp Service
Center for a replacement.
(On the Set)
CH ( 8 )/( 9 )
(On the Set)
MENU
MENU
or
21FL94_05-10_EN 19/3/04, 11:52 am10

11
Dimension: 140mm x 215mm
LThe language for the ON SCREEN DISPLAY can be set to ENGLISH, ESPAÑOL (SPANISH) or
FRANCAIS (FRENCH).
LSetting the ON SCREEN DISPLAY Language.
1Press MENU to access the MAIN MENU screen.
2Press CH ( 8 ) or ( 9 ) to move the “a” mark to “SETUP”.
3Press VOL (+) or (–) to access SETUP mode.
4Press VOL (+) or (–) to access LANGUAGE change mode.
5Press CH ( 8 ) or ( 9 ) to select “ENGLISH”, “ESPAÑOL (SPANISH)”
or “FRANCAIS (FRENCH)”.
6Press MENU to exit.
Language
(LANGUAGE change mode)
(MAIN MENU screen)
(SETUP mode)
TIMER
VIDEO ADJUST
ADJUST
AUD I O
AUD I O
SELECT
SETUP
CAPT I ONCLOSED
RVIEW ET
CH P
IM
SETU
MENU
TIMER
VIDEO ADJUST
ADJUST
AUD I O
AUD I O
SELECT
SETUP
CAPT I ONCLOSED
RVIEW ET
CH P
IM
SETU
MENU
EN L I SGH
ESPAÑ LO
FRA ANC I S
LANGUAGE
EN L I SGH
ESPAÑLO
FRA ANC I S
IDIOMA
MENU
MENU
LA AGUNGE
ENERGY SAVE
BLUE SCREE
AUTO I NPUT
N
SETUP
CH
8
9
CH
;:
VOL
–VOL
+
;:
VOL
–VOL
+
CH
8
9
CH
21FL94_11-22_EN 22/3/04, 3:11 pm11

12
Dimension: 140mm x 215mm
Timer
(TIMER mode)
TIMER
VIDEO ADJUST
ADJUST
AUD I O
AUD I O
SELECT
SETUP
CAPT I ONCLOSED
RVIEW ET
CH P
IM
SETU
MENU
TIMER
SLEEP T IMER
ON T I MER
OF F T I MER
CLOCK SET
MENU
;:
VOL
–VOL
+
SL EPETIMER
12 M0INREMA
;:
VOL
–VOL
+
(SLEEP TIMER mode)
MENU
LSLEEP TIMER
You can preset your television to turn off automatically in increments of 30, 60, 90, or 120
minutes.
1Press MENU to access the MAIN MENU screen.
2Press VOL (+) or (–) to access TIMER mode.
3Press VOL (+) or (–) to access SLEEP TIMER mode.
4Press VOL (+) or (–) to set a sleep time of 30, 60, 90 or 120
minutes.
5Press MENU to exit.
Note:
• To turn off the SLEEP TIMER, repeat the above SLEEP TIMER steps and select “– – – M REMAIN”
during step 3.
• While SLEEP TIMER is active, the time remaining will be briefly displayed on-screen at regular intervals
or when the remote’s DISPLAY key is pressed.
(MAIN MENU screen)
;:
VOL
–VOL
+
→
21FL94_11-22_EN 22/3/04, 3:11 pm12

13
Dimension: 140mm x 215mm
Timer (Continued)
LCLOCK SET
1Press MENU to access the MAIN MENU screen.
2Press VOL (+) or (–) to access TIMER mode.
3Press CH ( 8 ) or ( 9 ) to move the “a” mark to “CLOCK SET”.
4Press VOL (+) or (–) to access CLOCK SET mode.
5Press VOL (+) / (–) or CH ( 8 ) / ( 9 ) to set a CLOCK SET time.
6Press VOL (+) or (–) to select hour, then press CH ( 8 ) or ( 9 )
to change hour.
7Press VOL (+) or (–) to select minute, then press CH ( 8 ) or
( 9 ) to change minute.
8Press MENU to exit.
Note:
• “12:00 AM” will appear for the first time you access CLOCK SET mode during step 5.
• To reset the CLOCK SET, turn off and on again the AC power supply.
• Depending on using condition, time may have a small deviation.
(TIMER mode)
(CLOCK SET mode)
(MAIN MENU screen)
TIMER
VIDEO ADJUST
ADJUST
AUD I O
AUD I O
SELECT
SETUP
CAPT I ONCLOSED
RVIEW ET
CH P
IM
SETU
MENU
TIMER
SLEEP T IMER
ON T I MER
OF F T I MER
CLOCK SET
MENU
CLOCK SET
–– :––
CLOCK SET
12 : 00AM
;:
VOL
–VOL
+
MENU
;:
VOL
–VOL
+
CH
8
9
CH
→
;:
VOL
–VOL
+
CH
8
9
CH
CLOCK SET
11 : 00PM
;:
VOL
–VOL
+
CH
8
9
CH
→
CLOCK SET
11 : 13PM
;:
VOL
–VOL
+
CH
8
9
CH
→
or
21FL94_11-22_EN 22/3/04, 3:11 pm13

14
Dimension: 140mm x 215mm
Timer (Continued)
LON TIMER
Automatically turns TV power on at the time set.
1Press MENU to access the MAIN MENU screen.
2Press VOL (+) or (–) to access TIMER mode.
3Press CH ( 8 ) or ( 9 ) to move the “a” mark to “ON TIMER”.
4Press VOL (+) or (–) to access ON TIMER mode.
5Press VOL (+) to select hour, then press CH ( 8 ) or ( 9 ) to
change hour.
6Press VOL (+) to select minute, then press CH ( 8 ) or ( 9 ) to
change minute.
7Press VOL (+) again to move the “a” mark to “STATUS”
position.
(TIMER mode)
(MAIN MENU screen)
TIMER
VIDEO ADJUST
ADJUST
AUD I O
AUD I O
SELECT
SETUP
CAPT I ONCLOSED
RVIEW ET
CH P
IM
SETU
MENU
MENU
TIMER
SLEEP T IMER
ON T I MER
OF F T I MER
CLOCK SET
(ON TIMER mode)
ON T I MER
12 : 00AM
STATUS :OFF
;:
VOL
–VOL
+
;:
VOL
–VOL
+
CH
8
9
CH
→
ON T I MER
11 : 00PM
STATUS :OFF
:
VOL
+
CH
8
9
CH
→
ON T I MER
11 : 10PM
STATUS :OFF
CH
8
9
CH
→
ON T I MER
11 : 10PM
STATUS :OFF
:
VOL
+
:
VOL
+
21FL94_11-22_EN 22/3/04, 3:11 pm14

15
Dimension: 140mm x 215mm
ON DAILY OFF
MENU
;:
VOL
–VOL
+
Timer (Continued)
8Press VOL (+) or (–) to change the STATUS setting.
Status: ON
The ON TIMER is activated. The ON TIMER indicator will lights
up red to indicate ON TIMER is set.
Status: OFF
The ON TIMER will not operate. The ON TIMER indicator is off.
Status: DAILY
The ON TIMER is activated at the same time each day. The ON
TIMER indicator will lights up red to indicate ON TIMER is set.
9Press MENU to exit.
Note:
• The ON TIMER cannot be set when the CLOCK is not set. In this
time, “PLEASE SET UP TIME” screen will appears for
approximately 2 seconds.
• Then CLOCK SET screen will appear. Repeat step 5 ~ 8in “CLOCK
SET” steps. (Please refer to page 13 on CLOCK SET.)
If you do nothing, the CLOCK SET screen will disappear.
• If the TV set is turned on by the On Timer, then the TV set will be
automatically turned off in two hours if no buttons are pressed on
the TV set or remote control.
ON T I MER
11 : 10PM
STATUS :ON
PLEASE
TUPTSE IME
CLOCK SET
–– :––
21FL94_11-22_EN 22/3/04, 3:11 pm15

16
Dimension: 140mm x 215mm
Timer (Continued)
LOFF TIMER
The OFF TIMER function will turn off the TV power when reach the set of time.
1Press MENU to access the MAIN MENU screen.
2Press VOL (+) or (–) to access TIMER mode.
3Press CH ( 8 ) or ( 9 ) to move the “a” mark to “OFF TIMER”.
4Press VOL (+) or (–) to access OFF TIMER mode.
5Press VOL (+) to select hour, then press CH ( 8 ) or ( 9 ) to
change hour.
6Press VOL (+) to select minute, then press CH ( 8 ) or ( 9 ) to
change minute.
7Press VOL (+) again to move the “a” mark to “STATUS”
position.
(MAIN MENU screen)
TIMER
VIDEO ADJUST
ADJUST
AUD I O
AUD I O
SELECT
SETUP
CAPT I ONCLOSED
RVIEW ET
CH P
IM
SETU
MENU
MENU
(TIMER mode)
TIMER
SLEEP T IMER
ON T I MER
OF F T I MER
CLOCK SET
(OFF TIMER mode)
OFF T I MER
12 : 00AM
STATUS :OFF
OF F T I MER
11 : 10PM
STATUS :OFF
;:
VOL
–VOL
+
CH
8
9
CH
→
;:
VOL
–VOL
+
OF F T I MER
11 : 00PM
STATUS :OFF
OF F T I MER
11 : 10PM
STATUS :OFF
:
VOL
+
CH
8
9
CH
→
CH
8
9
CH
→
:
VOL
+
:
VOL
+
21FL94_11-22_EN 22/3/04, 3:11 pm16

17
Dimension: 140mm x 215mm
ON DAILY OFF
MENU
;:
VOL
–VOL
+
8Press VOL (+) or (–) to change the STATUS setting.
Status: ON
The OFF TIMER is activated.
Status: OFF
The OFF TIMER will not operate.
Status: DAILY
The OFF TIMER is activated at the same time each day.
9Press MENU to exit.
Note:
• The OFF TIMER cannot be set when the CLOCK is not set. In this
time, “PLEASE SET UP TIME” screen will appears for
approximately 2 seconds.
• Then CLOCK SET screen will appear. Repeat step 5~ 8in “CLOCK
SET” steps. (Please refer to page 13 on CLOCK SET.)
If you do nothing, the CLOCK SET screen will disappear.
• For the last 5 minutes, the “OFF TIMER” will be displayed.
• “0M REMAIN” will be displayed for 10 seconds just before the
OFF TIMER is complete.
Timer (Continued)
OF F T I MER
11 : 10PM
STATUS :ON
PLEASE
TUPTSE IME
CLOCK SET
–– :––
21FL94_11-22_EN 22/3/04, 3:11 pm17

18
Dimension: 140mm x 215mm
Description of Adjustment Items
Video Adjust
VOL
(+)/(–)
CH
(8)/ (9)
MENU
ABCD
PERSONAL PREFERENCE
9 VCR-CH 8
POWER (DVD/VCR)
;:
CH
8
VOL
–VOL
+
9
CH
MENU MUTE g SKIP f
1Press MENU to access the MAIN MENU screen.
2Press CH ( 8 ) or ( 9 ) to move the “a” mark to “VIDEOADJUST”.
3Press VOL (+) or (–) to access PICTURE adjust mode.
4Press CH ( 8 ) or ( 9 ) to select the desired mode.
(Refer to the diagram below.)
5Press VOL (+) or (–) to adjust the setting.
6Repeat steps 4to 5to adjust other settings.
7Press MENU to exit.
Note:
• VIDEO ADJUST setting is available for AIR or CABLE/INPUT 1/INPUT 2 and COMPONENT respectively.
(PICTURE adjust mode)
→
VOL (–)
decrease contrast
(MAIN MENU screen)
P I CTURE 7
_______
2
P I CTURE 27
_______
VOL (+)
increase contrast
MENU
TIMER
VIDEO ADJUST
ADJUST
AUD I O
AUD I O
SELECT
SETUP
CAPT I ONCLOSED
RVIEW ET
CH P
IM
SETU
MENU
;:
VOL
–VOL
+
CH
8
9
CH
CH
8
9
CH
;:
VOL
–VOL
+
MENU
PICTURE TINT COLOR
COLOR TEMP.
RESET
: CH (9)
: CH (8)
BRIGHT
SHARP
Selected item VOL (+) button VOL (–) button
PICTURE To increase contrast To decrease contrast
TINT To make skin tones greenish To make skin tones purplish
COLOR To increase color intensity To decrease color intensity
BRIGHT To increase brightness To decrease brightness
SHARP To increase sharpness To decrease sharpness
COLOR TEMP. To choose a MH, HIGH, LOW or ML COLOR TONE.
RESET To return all adjustments to factory preset levels.
21FL94_11-22_EN 22/3/04, 3:11 pm18

19
Dimension: 140mm x 215mm
Audio Adjust
Selected item VOL (+) button VOL (–) button
TREBLE To increase treble response To decrease treble response
BASS To increase bass response To decrease bass response
BALANCE To emphasize the right speaker’s volume To emphasize the left speaker’s volume
RESET To return all adjustments to factory preset levels.
1Press MENU to access the MAIN MENU screen.
2Press CH ( 8 ) or ( 9 ) to move the “a” mark to “AUDIOADJUST”.
3Press VOL (+) or (–) to access TREBLE adjust mode.
4Press CH ( 8 ) or ( 9 ) to select the desired mode.
(Refer to the diagram below.)
5Press VOL (+) or (–) to adjust the setting.
6Repeat steps 4to 5to adjust other settings.
7Press MENU to exit.
TIMER
VIDEO ADJUST
ADJUST
AUD I O
AUD I O
SELECT
SETUP
CAPT I ONCLOSED
RVIEW ET
CH P
IM
SETU
MENU
(MAIN MENU screen)
MENU
CH
8
9
CH
→
BLE 0TER
(TREBLE adjust mode)
;:
VOL
–VOL
+
TREBLE RESET BASS BALANCE
CH
8
9
CH
BLE 0TER
;:
VOL
–VOL
+
MENU
21FL94_11-22_EN 22/3/04, 3:11 pm19

20
Dimension: 140mm x 215mm
LMTS (Multichannel TV Sound)
This circuit allows reception of stereo or bilingual TV sound.
LINTERNAL SPEAKER SWITCH
This function turns the TV’s internal speakers “ON”or “OFF”when listening to sound from
external speakers by using the AUDIO OUTPUT JACKS on page 37.
LFAO (Fixed Audio Output)
This function turns the TV’s internal speakers “OFF”and allows fixed audio output from the
AUDIO OUTPUT JACKS on page 37. With FAO, the TV’s volume control is disabled.
1Press MENU to access the MAIN MENU screen.
2Press CH ( 8 ) or ( 9 ) to move the “a” mark to “AUDIO SELECT”.
3Press VOL (+) or (–) to access AUDIO SELECT mode.
4Press CH ( 8 ) or ( 9 ) to move the “a” mark to “MTS”,
“SPEAKER” or “FAO”.
5Press VOL (+) or (–) to select “STEREO”, “SAP” or “MONO”
when the “a” mark is at “MTS” position.
6Press MENU to exit.
Ex: Actual screen indicating ON AIR when receiving STEREO
broadcasts
Actual channel number
“←ON AIR” will appear next to STEREO or
SAP when receiving STEREO or SAP
broadcasts.
Audio Select
MENU
;:
VOL
–VOL
+
CH
8
9
CH
MENU
MTS
STEREO
SAP
MONO
SPEAKER
ON
OFF
FAO
ON
OFF
CH
8
9
CH
;:
VOL
–VOL
+
(MAIN MENU screen)
→
(AUDIO SELECT mode)
→
(AUDIO SELECT mode)
12
STEREO
SAP
ON A RI
ON A RI
MO ON
(CHANNEL call on screen)
TIMER
VIDEO ADJUST
ADJUST
AUD I O
AUD I O
SELECT
SETUP
CAPT I ONCLOSED
RVIEW ET
CH P
IM
SETU
MENU
MTS : STEREO
SPE EAK R : ON
OSELECT
:OFFFAO
AUD I
MTS : SAP
SPE EAK R : ON
OSELECT
:OFFFAO
AUD I
21FL94_11-22_EN 22/3/04, 3:11 pm20
