Sharp 21JF2-GA User manual

No. S95O521JF2-RU
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS ......................................... 1-1
CHAPTER 2. IMPORTANT SERVICE NOTES
[1] IMPORTANT SERVICE NOTES .................... 2-1
CHAPTER 3. ADJUSTMENT PRECAUTIONS
[1] ADJUSTMENT PRECAUTIONS .................... 3-1
[2] ADJUSTMENT ............................................. 3-14
CHAPTER 4. MEMORY MAP
[1] MEMORY MAP .............................................. 4-1
CHAPTER 5. TROUBLE SHOOTING FLOWCHART
[1] TROUBLE SHOOTING FLOWCHART .......... 5-1
CHAPTER 6. SOLID STATE DEVICE BASE DIA-
GRAM
[1] SOLID STATE DEVICE BASE DIAGRAM........ 6-1
CHAPTER 7. CHASSIS LAYOUT
[1] CHASSIS LAYOUT ........................................ 7-1
CHAPTER 8. BLOCK DIAGRAM
[1] BLOCK DIAGRAM: CRT UNIT ...................... 8-1
[2] BLOCK DIAGRAM: HEADPHONE UNIT........8-1
[3] BLOCK DIAGRAM: MAIN UNIT ....................8-2
CHAPTER 9. DESCRIPTION OF SCHEMATIC DIA-
GRAM
[1] DESCRIPTION OF SCHEMATIC DIA-
GRAM............................................................9-1
CHAPTER 10. WAVEFORMS
[1] WAVEFORMS .............................................10-1
CHAPTER 11. SCHEMATIC DIAGRAM
[1] SCHEMATIC DIAGRAM: MAIN UNIT.......... 11-1
[2] SCHEMATIC DIAGRAM: CRT UNIT ........... 11-7
[3] SCHEMATIC DIAGRAM: HEADPHONE
UNIT ............................................................ 11-7
CHAPTER 12. PRINTED WIRING BOARD ASSEM-
BLIES
[1] PWB-B: CRT UNIT ......................................12-1
[2] PWB-C: HEADPHONE UNIT ......................12-1
[3] PWB-A: MAIN UNIT ....................................12-2
Parts Guide
SERVICE MANUAL
CONTENTS
SHARP CORPORATION
The chassis in this receiver is partially hot. Use an isolation transformer between the line cord plug and power receptacle, when servicing
this chassis. To prevent electric shock, do not remove cover. No user - serviceable parts inside. Refer servicing to qualified service personnel.
WARNING
Multi 18 Systems
Full Auto Channel Preset and Auto Channel Skip
100-CH Program Memory
CATV (Hyper Band) Ready
<Used Frequency Synthesizer Tuner>
Black Stretch Circuit
On Timer / Off Timer / Reminder Timer
Blue Back Function
ع
ع
ع
ع
ع
ع
ع
ع
ع
ع
ع
ع
ع
ع
ع
Front AV IN & Rear AV IN / OUT Terminals
Front Headphone Jack
Aperture Control Circuit
Auto Fine Tuning
NTSC Colour Comb Filter (AV THRU)
High Contrast Picture
Hotel Mode
White Temperature Select
ع
ع
Multi Languages OSD
(ENG / CHI / FRE / MAL / ARA / RUS)
for Model 21JF2-SF / SS Only.
(ENG / CHI / FRE / MAL / ARA)
for Model 21JF2-GA / SA Only.
(ENG / RUS)
for Model 21JF2-RU Only.
MONO
FEATURES
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and
only parts identical to those specified should be used.
21JF2-RU
MODELS
COLOUR TELEVISION
Chassis No. GA-4M
21JF2-GA
21JF2-SA
21JF2-SF
21JF2-SS
21JF2-RU/GA/SA/SF/SS

21JF2-RU/GA/SA/SF/SS
1 – 1
21JF2-RU/GA/SA/SF/SS Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Convergence ................................................................................................................ Self Convergence System
Focus
............................................................................................................................... UNI-BI Focusing
Sweep Deflection ..................................................................................................................................... Magnetic
Intermediate Frequencies
Picture IF Carrier ................................................................................................................................. 38.9MHz
Sound IF Carrier Frequency
6.5MHz ............................................................................................................................................. 32.4MHz
6.0MHz ............................................................................................................................................. 32.9MHz
5.5MHz ............................................................................................................................................. 33.4MHz
Colour Sub-Carrier Frequency........................................................................................................... 34.47MHz
Cabinet material ..................................................................................................................................... All Plastics
Specifications are subject to change without prior notice
Aerial Input Impedance
VHF/UHF .......................................................................................................................... 75 ohms Unbalanced
Receiving System ................................................................................. PAL I, B/G, D/K & SECAM B/G, D/K, -K1
Receiving Channel
VHF-Channels ......................................................................................... E2(48.25MHz) thru E12(224.25MHz)
C1(49.75MHz) thru C12(216.25 MHz)
S1(105.25MHz) thru S41(463.25HMz)
UHF-Channels ..................................................................................... E21(471.25MHz) thru E69(855.25MHz)
C13(471.25MHz) thru C57(863.25MHz)
.
Power Input ..................................................................................................................... 110 ~ 240V AC 50/60 Hz
Power Consumption........................................................................................................................................ 95W
Audio Power Output Rating ............................................................................................................. 2.5W(rms) x 2
Voice Coil Impedance .............................................................................................................16 ohms at 400 Hz
..............................................................................................................................
Speaker
9 x 5 cm Elliptic (2 pcs)
Size
Dimensions ..................................................................................................................................... Width: 605mm
Height: 468mm
Depth: 482mm
Weight(approx): 21.7 kg

21JF2-RU/GA/SA/SF/SS
2 – 1
21JF2-RU/GA/SA/SF/SS Service Manual
CHAPTER 2. IMPORTANT SERVICE NOTES
[1] IMPORTANT SERVICE NOTES
Maintenance and repair of this receiver should be done by qualified service personnel only.
1. SERVICE OF HIGH VOLTAGE SYSTEM AND PICTURE TUBE
When servicing the high voltage system, remove static charge from it by connecting a 10K ohm resistor in series with an insulated wire (such as a test
probe) between picture tube dag and 2nd anode lead. (AC line cord should be disconnected from AC outlet.)
1) Picture tube in this receiver employs integral implosion protection.
2) Replace with the same type number of picture tube for continued safety.
3) Do not lift picture tube by the neck.
4) Handle the picture tube only when wearing shatterproof goggles and after discharging the high voltage completely.
2. X-RAY
This receiver is designed so that any X-Ray radiation is kept to an absolute minimum. Since certain malfunctions or servicing may produce potentially
hazardous radiation with prolonged exposure at close range, the following precautions should be observed:
1) When repairing the circuit, please make sure do not increase the high voltage of the set to more than 30.0kV (at beam 0µA).
2) To keep the set in a normal operation, please make sure it’s function at 26.5kV ±0.5kV (at beam 1000µA). The set has been factory - adjusted to
the above-mentioned high voltage.
*If there is a possibility that the high voltage fluctuates as a result of the repairs, never forget to check for such high voltage after the work.
3) Do not substitute a picture tube with unauthorizerd types and/or brands which may cause excessive X-ray radiation.
3. BEFORE RETURNING THE RECEIVER
Before returning the receiver to the user, perform the following safety checks.
1) Inspect all lead dress to make certain that leads are not pinched or that hardware is not lodged between the chassis and other metal parts in the
receiver.
2) Inspect all protective devices such as non-metal control knobs, insulating materials, cabinet backs, adjustment and compartment covers or
shields, isolation resistor-capacity networks, mechanical insulators etc.

21JF2-RU/GA/SA/SF/SS
3 – 1
21JF2-RU/GA/SA/SF/SS Service Manual
CHAPTER 3. ADJUSTMENT PRECAUTIONS
[1] ADJUSTMENT PRECAUTIONS
This model's setting are adjusted in two different ways: through the I2C bus control and in the conventional analog manner. The
adjustments via the I2C bus control include preset-only items and variable data.
CAUTION: Make sure TV set in "Normal condition" before switch to Service Mode for adjustment.
1. Setting the service mode by the microprocessor.
i) Press SERVICE key on the remote controller to set the TV set to SERVICE mode position, and the microprocessor is in input
mode. (Adjustment through the I2C bus control).
ii) Press the MENU key on the remote controller to get ready to select the mode (Adjustment mode, Setting mode, Check mode and Option
mode) one by one.
iii) Press the CH DOWN / UP key on the remote controller to select the item in Adjustment mode, Setting mode or Option mode.
iv) Using the VOLUME UP/ DOWN key on the remote controller, the data can be modified. Please wait approximately 200 msec for data storage
in EEPROM before select to another mode.
v) In Check mode the data cannot be changed.
vi) Press the SERVICE key again, it will switch to the NORMAL mode position, and the microprocessor is out of the SERVICE mode.
2. Factory Presetting.
i) Power ON the TV set, press the SERVICE key on the remote controller, then press both the CH UP and VOL UP button on the set
simultaniously for 5secs. Initial values are automatically preset, only when a new EEPROM is used.
ii) The initial data are preset as listed in page 3-7 to 3-13.
iii) Make sure the data need modification or not (Initial data).
Precaution: If haven't done this initialization, it may possibly generate excessive Beam current.
3. For reference please check with memory map RH-IXB226WJZZ. (See Page 4-1 ~ 4-16)

21JF2-RU/GA/SA/SF/SS
3 – 2
1. ADJUSTMENT ITEM
***Below are the adjustment items that should be done, PLS FOLLOW THE PROCEDURE. Otherwise some adjustment items will
not be accurate.
NO *** ADJUSTMENT ITEM EFFECTIVE MODEL REVISION
1BUSSETUP
ALL MODELS
2 OPTION SET UP
3H-VCO
4VIF-VCO
5 S-TRAP fo
6RF-AGC
7 PURITY ADJ
8 CONVERGENCE ADJ
9 FOCUS ADJ
10 V-SHIFT (50 Hz)
11 H-SHIFT (50 Hz)
12 V-SIZE (50 Hz)
13 SCREEN
14 WHITE BALANCE
15 SUB-BRIGHTNESS
16 SUB-CONTRAST
17 SUB-TINT
18 SUB-COLOR
19 SECAM-OFFSET
20 SIF VCO ADJ
21 BEAM CURRENT CHECK
22 BEAM PROTECTOR CHECK
23 HV PROTECTOR CHECK
24 OTHER PROTECTOR CHECK
25 AV OUT CHECK
26 AV IN CHECK
27 CONTRAST CONTROL CHECK
28 COLOR CONTROL CHECK
29 BRIGHTNESS CONTROL CHECK
30 TINT CONTROL CHECK
31 SHARPNESS CONTROL CHECK
32 CH DISPLAY COLOR CHECK
33 NORMAL DISPLAY CHECK
34 WHITE TEMP CONTROL CHECK
35 COLOR SYSTEM CHECK
36 SOUND SYSTEM CHECK
37 NOISE MUTE CHECK
38 OSD LANGUAGE QUANTITY CHECK
39 HEAD PHONE CHECK
40 SHOCK TEST CHECK
41 ROM CORRECTION CHECK

21JF2-RU/GA/SA/SF/SS
3 – 3
2. USER DATA IN SERVICE MODE
1) While SERVICE mode ON, EEPROM DATA will switch to the service data. Also, once SERVICE mode OFF, EEPROM will switch back to previous
USER DATA.
2) In the service mode, the user data establish as below,
*1: For each CH, data is same as before switch to Service mode.
The flow of Mode list as following,
* Direct Key-in Mode for Service Items in Service Mode
USER DATA
CONTRAST MAX (60)
COLOUR CENT (0)
BRIGHTNESS CENT (0)
TINT CENT (0)
SHARPNESS CENT (0)
WHITE TEMP STANDARD
S-VOLUME MIN
BLUE BACK OFF
C SYSTEM AUTO
S SYSTEM *1
RC CODE (HEX) R/C KEY NAME SERVICE-ITEM
80 POS 1 R-C UP (IN SERVICE MODE V00)
40 POS 2 G-C UP (IN SERVICE MODE V00)
C0 POS 3 B-C UP (IN SERVICE MODE V00)
20 POS 4 R-C DOWN (IN SERVICE MODE V00)
A0 POS 5 G-C DOWN (IN SERVICE MODE V00)
60 POS 6 B-C DOWN (IN SERVICE MODE V00)
E0 POS 7 R-D UP (IN SERVICE MODE V00)
10 POS 8 B-D UP (IN SERVICE MODE V00)
50 POS 0 B-D DOWN (IN SERVICE MODE V00)
E4 FLASHBACK R-D DOWN (IN SERVICE MODE V00)
E4 FLASHBACK Y-MUTE (BESIDES OF SERVICE MODE V00)
75 WHITE TEMP UP RF-AGC (V01)
F5 WHITE TEMP DOWN VIF-VC0 (V02)
C2 TUNE DOWN H-VCO (V03)
8D SHARPNESS DOWN SUB-CON (V04)
D6 BALANCE LEFT SUB-COL (V05)
0D SHARPNESS UP SUB-BRIGHT (V06)
36 BALANCE RIGHT SUB-TINT (V07)
46 TREBLE UP SUB-SHP (V08)
C6 TREBLE DOWN SUB-COL-YUV (V09)
26 BASS UP SUB-TINT-YUV (V10)
24 COLOUR UP V-SIZE (V11), V-SIZE60 (V17)
54 BRIGHTNESS DOWN V-SHIFT (V12), V-SHIFT60 (V18)
74 TINT DOWN H-SHIFT (V13), H-SHIFT60 (V19)
66 SURROUND UP SCM-BR (V14)
E6 SURROUND DOWN SCM-BB (V15)
C4 CONTRAST DOWN SUB-VOL (V16)
4C PICTURE S-TRAP-BG (V20)
CC HOLD S-TRAP-I (V21)
2C TEXT S-TRAP-DK (V22)
AC CANCEL S-TRAP-M (V23)
EC SIZE S-TRAP-574 (V24)
80 POS 1 R-C UP YUV (IN SERVICE MODE V25)
40 POS 2 G-C UP YUV (IN SERVICE MODE V25)
C0 POS 3 B-C UP YUV (IN SERVICE MODE V25)
20 POS 4 R-C DOWN YUV (IN SERVICE MODE V25)
A0 POS 5 G-C DOWN YUV (IN SERVICE MODE V25)
60 POS 6 B-C DOWN YUV (IN SERVICE MODE V25)
E0 POS 7 R-D UP YUV (IN SERVICE MODE V25)
10 POS 8 B-D UP YUV (IN SERVICE MODE V25)
50 POS 0 B-D DOWN YUV (IN SERVICE MODE V25)

21JF2-RU/GA/SA/SF/SS
3 – 4
1) Please set the MCL to MCL1 as below:
2) After set the MCL, please set the INITIAL SETTING for each models.
INITIAL 3 : For Singapore and Africa ( All Channel Sound System are set to B/G )
INITIAL 4 : For Middle-East ( All Channel Sound System are set to B/G )
INITIAL 5 : For Russia ( All Channel Sound System are set to D/K )
E4 FLASHBACK R-D DOWN YUV (IN SERVICE MODE V25)
C1 AUTO ADJ FOR V01, V02, V03, V20, V21, V22, V23, V24
CA T-SET
81 SERVICE MODE
MCL1 (HEX AE)
CH-No Fv (MHz) Sound Sys
0
1 48.25 B/G
2 62.25 B/G
3 77.25 D/K
4 175.25 B/G
5 182.25 B/G
6 183.25 D/K
7 191.25 D/K
8 196.25 B/G
9 199.25 M
10 210.25 B/G
11 224.25 B/G
12 471.25 B/G
13 487.25 I
14 503.25 B/G
15 575.25 B/G
16 583.25 B/G
17 599.25 B/G
18 621.25 M
19 639.25 D/K
20 703.25 B/G
21 735.25 I
22 767.25 B/G
23 815.25 B/G
24 855.25 I
25 855.25 B/G
26 55.25 M
27 83.25 M
28 183.25 M
29 193.25 M
30 217.25 M
31 471.25 M
32 477.25 M
33 693.25 M
34 885.25 M
35 112.25 B/G
36 168.25 B/G
37
38 294.25 B/G
39 463.25 B/G
40
41 647.25 B/G
42 663.25 B/G
43 679.25 B/G
44 174.95 B/G
45 175.55 B/G
46
47
48
49
RC CODE (HEX) R/C KEY NAME SERVICE-ITEM

21JF2-RU/GA/SA/SF/SS
3 – 5
NOTE: PLL DATA OF ABOVE FREQ SHOULD TAKE THE ACCOUNT OF PIF SETTING IN SERVICE OPTION O04 (VIF) BEFORE STORING INTO
EEPROM.
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
MCL1 (HEX AE)
CH-No Fv (MHz) Sound Sys

21JF2-RU/GA/SA/SF/SS
3 – 6
3. SHIPPING SETTING & CHECKING
(1) The following default data has been factory-set for the E2PROM follow by INITIAL DATA selected.
(Reference: Geomagnetism Adjustment)
ITEMS DATA SETTING
LAST POWER ON
LAST TV/AV MODE TV MODE
LAST POSITION CH 1
FLASHBACK CHANNEL CH 1
1/2 DIGIT ENTRY 2 DIGIT ENTRY
VOLUME 0 (Min)
BLUE BACK OFF
OFF TIMER --:--
ON TIMER --:--
ON TIMER POSITION --
ON TIMER VOLUME --
REMINDER --:--
AFT ALL CH ON
COLOR SYSTEM ALL CH AUTO
SKIP ALL CH OFF
CONTRAST 60
COLOR 0
BRIGHTNESS 0
TINT 0
SHARPNESS 0
WHITE TEMP 0
INITIAL LANGUAGE SOUND SYSTEM
1 CHINESE D/K
2 CHINESE I
3 ENGLISH B/G
4 ARABIC B/G
5 RUSSIAN D/K
6 MALAY B/G
7 FRENCH D/K
MODEL MAGNETIC FIELD(V, H) nT BACKGROUND LANG. S-SYS LANG QTY
SINGAPORE -10000 40000 12300°K ENGLISH B/G 5
AFRICA -10000 40000 12300°K ENGLISH B/G 5
MID-EAST 30000 20000 18000°KARABICB/G6
RUSSIA 45000 20000 7500°K RUSSIAN D/K 2
*NOTE FOR OSD TYPE:
2: ENGLISH/RUSSIAN
5: ENGLISH/CHINESE/FRENCH/ARABIC/MALAY
6: ENGLISH/CHINESE/FRENCH/ARABIC/MALAY/RUSSIAN

21JF2-RU/GA/SA/SF/SS
3 – 7
**AFTER INITIALIZED THE EEPROM (REFER TO FACTORY PRESETTING), READ DATA FROM EEPROM ADDRESS 00H ~ 03H, AND COM-
PARE TO THE LIST BELOW, IF DIFFERENT, INITIALIZE THE EEPROM.
*** There are four stages of service mode data. First stage data from V00 ~ V31 (Adjustment Mode).
To go into second stage of service mode data, press MENU key. Second stage data from F01 ~ F142 (Setting Mode).
To go into third stage of service mode data, press MENU key. Third stage data is Check Mode.
To go into fourth stage of service mode data, press MENU key. Fourth stage data from O01 ~ O31 (Option Mode).
ADDRESS DATA ADDRESS DATA
00H: 7BH 02H: 72H
01H: 72H 03H: 76H
ADJUSTMENT MODE (FIRST STAGE)
EEPROM ITEMS OSD DATA LENGTH INITIAL DATA FIX/ADJ/AUTO REMARK
R-DRIVE V00 0~127 63 ADJ PLS REFER TO
B-DRIVE V00 0~127 63 ADJ ADJ ITEM FOR
R-CUT V00 0~255 127 ADJ SCREEN AND
G-CUT V00 0~255 127 ADJ WHITE BALANCE
B-CUT V00 0~255 127 ADJ
RF-AGC V01 0~127 50 AUTO
VIF-VCO V02 0~63 31 AUTO
H-VCO V03 0~7 3 AUTO
SUB-CONTRAST V04 0~127 100 ADJ
SUB-COLOR V05 0~127 63 ADJ
SUB-BRIGHT V06 0~255 127 ADJ
SUB-TINT V07 0~127 63 ADJ
SUB-SHARPNESS V08 0~63 43 *FIX BUS SETUP
SUB-COLOR -YUV V09 0~127 90 FIX
SUB-TINT-YUV V10 0~127 63 FIX
V-SIZE 50 Hz V11 0~63 38 ADJ
V-SHIFT 50 Hz V12 0~7 3 ADJ
H-SHIFT 50 Hz V13 0~31 9 ADJ
SECAM-BR V14 0~63 37 ADJ
SECAM-BB V15 0~63 22 ADJ
SUB-VOL V16 0~60 60 FIX
V-SIZE 60 Hz V17 -31~0~+31 0 FIX IF NECESSARY, ADJ
V-SHIFT 60 Hz V18 -7~0~+7 -1 FIX IF NECESSARY, ADJ
H-SHIFT 60 Hz V19 -15~0~+15 +2 FIX IF NECESSARY, ADJ
S-TRAP (BG) V20 0~15 7 AUTO
S-TRAP (I) V21 0~15 7 AUTO
S-TRAP (DK) V22 0~15 7 AUTO
S-TRAP (M) V23 0~15 7 AUTO
S-TRAP (5.74) V24 0~15 7 AUTO
CUTOFF/BKGD YUV V25
R-DRI YUV V25 0~127 63 FIX
B-DRI YUV V25 0~127 63 FIX
R-CUT YUV V25 0~255 127 FIX
G-CUT YUV V25 0~255 127 FIX
B-CUT YUV V25 0~255 127 FIX
SUB-CON YUV V26 0~127 100 FIX
SUB-BRGHT YUV V27 0~255 127 FIX
VS-CORRECT V28 0~63 32 FIX ONLY FOR M61266
VC-CORRECT OFFSET V29 -13~+13 0 FIX ONLY FOR M61266
V LINEARITY V30 0~63 32 FIX ONLY FOR M61266
V LINEARITY OFFSET V31 -13~+13 0 FIX ONLY FOR M61266

21JF2-RU/GA/SA/SF/SS
3 – 8
SETTING MODE (SECOND STAGE)
EEPROM ITEMS FUNCTION OSD DATA LENGTH INITIAL
DATA
FIX/ADJ/
AUTO REMARK
C.CLIP-LVL CLIP LEVEL CONTRAST CONTROL OF
RGB INPUT
F01 0(20H) / 1(40H) 0 FIX
RGB-CLIP CLIPPING OF RGB CONTRAST CON-
TROL
F02 0 (CLIP OFF) / 1(CLIP ON) 0 FIX
BS BLACK STRETCH F03 0(ON) / 1(OFF) 0 FIX
ABCL ABCL PROCESSING (ACL PROCESSING) F04 0(OFF) / 1(ON) 0 FIX
ABCL-GAIN ABCL PROCESSING GAIN F05 0(LOW) / 1(HIGH) 0 FIX
S-OUT-LVL AUDIO OUTPUT GAIN CONTROL F06 0~127 95 *FIX BUS SETUP
VIF-G P-IF DETECTION GAIN OUTPUT F07 0~7 4 FIX
SHPG SHARPNESS GAIN F08 0(NORMAL) / 1(HIGH) 0 FIX
SHPG-P SHARPNESS GAIN PAL F09 0(NORMAL) / 1(HIGH) 0 FIX
SHPG-S SHARPNESS GAIN SECAM F10 0(NORMAL) / 1(HIGH) 0 FIX
SHPG-N4 SHARPNESS GAIN N443 F11 0(NORMAL) / 1(HIGH) 0 FIX
SHPG-N3 SHARPNESS GAIN N358 F12 0(NORMAL) / 1(HIGH) 1 FIX
YDL Y SIGNAL DELAY F13 0~7 5 FIX
YDL-P Y SIGNAL DELAY PAL F14 0~7 5 FIX
YDL-S Y SIGNAL DELAY SECAM F15 0~7 7 FIX
YDL-N4 Y SIGNAL DELAY N443 F16 0~7 5 FIX
YDL-N3 Y SIGNAL DELAY N358 F17 0~7 5 FIX
YDL-AV Y SIGNAL DELAY AV F18 0~7 6 FIX
YDL-AV-P Y SIGNAL DELAY PAL (AV) F19 0~7 6 FIX
YDL-AV-S Y SIGNAL DELAY SECAM (AV) F20 0~7 7 FIX
YDL-AV-N4 Y SIGNAL DELAY N443 (AV) F21 0~7 6 FIX
YDL-AV-N3 Y SIGNAL DELAY N358 (AV) F22 0~7 6 FIX
YDL-YUV Y SIGNAL DELAY YUV F23 0~7 6 FIX
COL-AV (OFFSET) COLOUR OFFSET AV F24 -31~0~+31 +10 *FIX BUS SETUP
COL-P (OFFSET) COLOUR OFFSET PAL F25 -31~0~+31 0 FIX
COL-S (OFFSET) COLOUR OFFSET SECAM F26 -31~0~+31 +9 FIX
COL-N4 (OFFSET) COLOUR OFFSET N443 F27 -31~0~+31 -8 FIX
COL-N3 (OFFSET) COLOUR OFFSET N358 F28 -31~0~+31 -7 FIX
COL-ADJ (OFFSET) COLOUR OFFSET ADJUST F29 -31~0~+31 0 *FIX BUS SETUP
SHP-AV (OFFSET) SHARPNESS OFFSET AV F30 -31~0~+31 +5 *FIX BUS SETUP
SHP-YUV (OFFSET) SHARPNESS OFFSET YUV F31 -31~0~+31 0 FIX
SHP-P (OFFSET) SHARPNESS OFFSET PAL F32 -31~0~+31 0 FIX
SHP-S (OFFSET) SHARPNESS OFFSET SECAM F33 -31~0~+31 -5 FIX
SHP-N4 (OFFSET) SHARPNESS OFFSET N443 F34 -31~0~+31 0 FIX
SHP-N3 (OFFSET) SHARPNESS OFFSET N358 F35 -31~0~+31 0 FIX
TINT-AV (OFFSET) TINT OFFSET AV F36 -63~0~+63 0 *FIX BUS SETUP
TINT-ADJ (OFFSET) TINT OFFSET ADJUST F37 -63~0~+63 0 *FIX BUS SETUP
TINT-YUV-ADJ (OFF-
SET)
TINT YUV OFFSET ADJUST F38 -63~0~+63 0 FIX
R-R (OFFSET) R-DRIVE OFFSET WHEN WHITE TEMP IS
RED
F39 -63~0~+63 +8 *FIX BUS SETUP
B-R (OFFSET) B-DRIVE OFFSET WHEN WHITE TEMP IS
RED
F40 -63~0~+63 -10 *FIX BUS SETUP
R-B (OFFSET) R-DRIVE OFFSET WHEN WHITE TEMP IS
BLUE
F41 -63~0~+63 -3 *FIX BUS SETUP
B-B (OFFSET) B-DRIVE OFFSET WHEN WHITE TEMP IS
BLUE
F42 -63~0~+63 +13 *FIX BUS SETUP
TRAP CENTER VALUE OF CHROMA TRAP F43 0~3 2 FIX
TRAP-P CENTER VALUE OF CHROMA TRAP PAL F44 0~3 2 FIX
TRAP-S CENTER VALUE OF CHROMA TRAP
SECAM
F45 0~3 2 FIX
TRAP-N4 CENTER VALUE OF CHROMA TRAP N443 F46 0~3 2 FIX
TRAP-N3 CENTER VALUE OF CHROMA TRAP N358 F47 0~3 2 FIX
1W-TV VERT SYNC DETECTION MODE FOR AV
(1 WINDOW/2 WINDOW)
F48 ACCEPTABLE PERIOD:
0(AUTOMATIC CHANGE)
/ 1(FIX (WIDE))
0FIX
1W-AV VERT SYNC DETECTION MODE FOR TV
(1 WINDOW/2 WINDOW)
F49 ACCEPTABLE PERIOD:
0(AUTOMATIC CHANGE)
/ 1(FIX (WIDE))
1FIX
V-FREE (NO SYNC) SET VERTICAL TO FORCED FREE RUN
MODE
F50 0(NORMAL) / 1(FRE-
ERUN)
0FIX

21JF2-RU/GA/SA/SF/SS
3 – 9
AFC2 (NO SYNC) HORIZONTAL AFC2 GAIN F51 0(NORMAL) / 1(DOWN) 0 FIX
GAMMA GAMMA CORRECTION QTY F52 0~3 0 FIX
BS-D/C BLACK STRETCH CONTROL LEVEL F53 0~15 10 FIX
BS-GAIN BLACK STRETCH LEVEL F54 0(NORMAL) / 1(DOWN) 0 FIX
OM-DET OVER MODULATION DETECT F55 0(OFF) / 1(ON) 0 FIX
SL-TV SLICE LEVEL OF SYNC DETECTION TV F56 0~7 2 FIX
SL-AV SLICE LEVEL OF SYNC DETECTION AV F57 0~7 4 FIX
SL-YUV SLICE LEVEL OF SYNC DETECTION YUV F58 0~7 4 FIX
VD2/VD1/AS/FBP-TV VD2 & VD1-VERT SYNC DETECT MIN
WIDTH MSB & LSB RESPECTIVELY, AS-
TV/AV/YUV SWITCH & CH CHANGE, FBP-
FLYBACK PULSE SLICE LEVEL (TV)
F59 0~15 6 FIX
VD2/VD1/AS/FBP-AV VD2 & VD1-VERT SYNC DETECT MIN
WIDTH MSB & LSB RESPECTIVELY, AS-
TV/AV/YUV SWITCH & CH CHANGE, FBP-
FLYBACK PULSE SLICE LEVEL (AV)
F60 0~15 14 FIX
VD2/VD1/AS/FBP-YUV VD2 & VD1-VERT SYNC DETECT MIN
WIDTH MSB & LSB RESPECTIVELY, AS-
TV/AV/YUV SWITCH & CH CHANGE, FBP-
FLYBACK PULSE SLICE LEVEL (YUV)
F61 0~15 14 FIX
VDL COLOUR DIFF. INPUT PHASE ADJ F62 0~3 0 FIX
UDL COLOUR DIFF. INPUT PHASE ADJ F63 0~3 0 FIX
AUTO-SCM-KIL-TV SECAM COLOUR KILLER SENSITIVITY
(TV)
F64 0~3 1 FIX
SECAM-BGP INTERNAL SECAM BGP TIMING F65 0~3 0 FIX
N45 INHIBIT 50Hz NTSC 4.43 F66 0(NORMAL) / 1(INHIBIT) 0 FIX
TXT-POS-H (TELE-
TEXT)
TELETEXT HORIZONTAL POSITION F67 0~63 30 FIX
TXT-POS-V (TELE-
TEXT)
TELETEXT VERTICAL POSITION F68 0~63 34 FIX
OSD-POS OSD POSITION F69 0~127 9 FIX
CP CHARGE PUMP F70 0(FAST TUNING) /
1(MODERATE SPEED
TUNING)
1FIX
SMALL-SURR (S-
CTRL)
SURROUND MODE SELECT F71 0(EALA EFFECT LARGE)
/ 1(EALA EFFECT SMALL)
0FIX
SUB-BASS (S-CTRL) SUB BASS CONTROL F72 0(0dB), 1(-1dB), 2(-2dB),
3(-3dB), 4(0dB), 5(+1dB),
6(+2dB), 7(+3dB)
6FIX
SUB-TREB (S-CTRL) SUB TREBLE CONTROL F73 0(0dB), 1(-1dB), 2(-2dB),
3(-3dB), 4(0dB), 5(+1dB),
6(+2dB), 7(+3dB)
0*FIX
AGC-ADJ (S-CTRL) AGC LEVEL ADJUST F74 0(AGC Off), 1(300mVrms),
2(400mVrms), 3(500Vrms),
4(600mVrms)
0*FIX
AGC-SW-OFF
(NICAM)
NICAM AGC SWITCH OFF F75 0(DISABLE, FIX GAIN),
1(ENABLE)
1FIX
AGC-GAIN-ADJ
(NICAM)
NICAM AGC GAIN ADJUST F76 0~31 16 FIX
FM-LEVEL-ADJ
(NICAM)
FM LEVEL ADJUST F77 -15~0~+15 0 FIX
IGR-LEVEL-ADJ
(NICAM)
IGR LEVEL ADJUST F78 -15~0~+15 +1 FIX
NICAM-BG-LVL-ADJ
(NICAM)
NICAM B/G LEVEL ADJUST F79 -15~0~+15 -2 FIX
NICAM-I-LVL-ADJ
(NICAM)
NICAM I LEVEL ADJUST F80 -15~0~+15 +3 FIX
NICAM-DK-LVL-ADJ
(NICAM)
NICAM D/K LEVEL ADJUST F81 -15~0~+15 -1 FIX
NICAM-LOW-ERR-LIM
(NICAM)
NICAM LOWER ERROR LIMIT F82 0~255 35 FIX
NICAM-UPP-ERR-LIM
(NICAM)
NICAM UPPER ERROR LIMIT F83 0~255 70 FIX
IGR-GAIN-ADJ (IGR) IGR GAIN ADJUST F84 -6~0~+7 0 FIX
SETTING MODE (SECOND STAGE)
EEPROM ITEMS FUNCTION OSD DATA LENGTH INITIAL
DATA
FIX/ADJ/
AUTO REMARK

21JF2-RU/GA/SA/SF/SS
3 – 10
FM-ID-SPEED
(NICAM)
FM SOUND IDENTIFICATION MODE F85 0(SLOW) / 1(MEDIUM) /
2(FAST) / 3(OFF)
1FIX
NICAM-AUTO-MUTE NICAM AUTO DETECTION F86 0(MUTE) / 1(DEMUTE) 0 FIX
AUTO-SCM-KIL-AV-
YUV
SECAM COLOUR KILLER SENSITIVITY
(AV/YUV)
F87 0~3 1 FIX
AFC1-GAIN-TV MSB OF HORIZONTAL AFC GAIN1 (TV) F88 0(NORMAL) / 1(x2) /
2(x1.5) / 3(3.5)
0FIX
AFC1-GAIN-AV MSB OF HORIZONTAL AFC GAIN1 (AV) F89 0(NORMAL) / 1(x2) /
2(x1.5) / 3(3.5)
3FIX
AFC1-GAIN-YUV MSB OF HORIZONTAL AFC GAIN1 (YUV) F90 0(NORMAL) / 1(x2) /
2(x1.5) / 3(3.5)
3FIX
CON-REDUCE CONTRAST (PICTURE LEVEL) CONTROL F91 0(0%)~1(25%)~2(50%) 0 FIX
TAKE-OFF-TV TAKEOFF/BPF OF CHROMA BPF PRO-
CESSING TV
F92 0(BPF) / 1(TAKEOFF) 1 FIX
TAKE-OFF-AV TAKEOFF/BPF OF CHROMA BPF PRO-
CESSING AV
F93 0(BPF) / 1(TAKEOFF) 0 FIX
TAKE-OFF-YUV TAKEOFF/BPF OF CHROMA BPF PRO-
CESSING YUV
F94 0(BPF) / 1(TAKEOFF) 0 FIX
C-ANGLE (103 DEG/
95 DEG)
CHROMA MODULATION ANGLE F95 0(103DEG) / 1(95DEG) 1 FIX
AC-FAIL-WO-BRIGHT PICTURE BLACK LEVEL (BRIGHT) CON-
TROL - AC FAILURE
F96 0~255 255 FIX
FORCED-SCM-KIL-TV FORCED SECAM COLOUR KILLER SEN-
SITIVITY (TV)
F97 0~3 2 FIX
FORCED-SCM-KIL-AV-
YUV
FORCED SECAM COLOUR KILLER SEN-
SITIVITY (AV/YUV)
F98 0~3 2 FIX
R-Y ADJ. COLOUR EDGE IMPROVEMENT F99 0(DISABLE) / 1(ENABLE) 1 FIX
V-DEMUTE-DELAY VIDEO DEMUTE DELAY F100 0~255 0 *FIX BUS SETUP
S-DEMUTE-DELAY SOUND DEMUTE DELAY F101 0~255 0 *FIX BUS SETUP
MER S-BOOSTER FREQ. CHARACTERISTIC
CONTROL
F102 0~255 70 FIX
MEL1 S-BOOSTER LEVEL1 F103 0~255 150 FIX
MEL2 S-BOOSTER LEVEL2 F104 0~255 156 FIX
MEL3 S-BOOSTER LEVEL3 F105 0~255 163 FIX
MEL4 S-BOOSTER LEVEL4 F106 0~255 165 FIX
MEL5 S-BOOSTER LEVEL5 F107 0~255 170 FIX
MEL6 S-BOOSTER LEVEL6 F108 0~255 180 FIX
S-ST-POINT S-BOOSTER START POINT F109 0~60 21 FIX
S-SP-POINT S-BOOSTER STOP POINT F110 0~60 60 FIX
S-STEP S-BOOSTER STEP F111 0~60 7 FIX
POW-STORAGE CONTRAST/BRIGHTNESS INCREASE
GRADUALLY
F112 0(DISABLE) / 1(ENABLE) 1 FIX
S-B-BASS S-BOOSTER BASS LIMITER (WHEN S-
BOOSTER ON)
F113 -30~0~+30 +15 FIX
S-B-TREB S-BOOSTER TREBLE LIMITER (WHEN S-
BOOSTER ON)
F114 -30~0~+30 +15 FIX
S-BASS S-BOOSTER BASS LIMITER (WHEN S-
BOOSTER OFF)
F115 -30~0~+30 +30 FIX
S-TREB S-BOOSTER TREBLE LIMITER (WHEN S-
BOOSTER OFF)
F116 -30~0~+30 +30 FIX
V-STD-TV VERTICAL STANDARD SIGNAL DETEC-
TOR SWITCH (TV)
F117 0(DISABLE) / 1(ENABLE) 0 FIX
V-STD-AV VERTICAL STANDARD SIGNAL DETEC-
TOR SWITCH (AV)
F118 0(DISABLE) / 1(ENABLE) 0 FIX
V-STD-YUV VERTICAL STANDARD SIGNAL DETEC-
TOR SWITCH (YUV)
F119 0(DISABLE) / 1(ENABLE) 0 FIX
WO-Bright-after-WO-
TIME
WHITE OUT BRIGHT AFTER WHITE OUT
TIME
F120 0~255 255 FIX
WO-Contrast-after-
WO-TIME
WHITE OUT CONTRAST AFTER WHITE
OUT TIME
F121 0~127 127 FIX
WO-Bright-before-WO-
TIME
WHITE OUT BRIGHT BEFORE WHITE
OUT TIME
F122 0~255 255 FIX
WO-Contrast-before-
WO-TIME
WHITE OUT CONTRAST BEFORE WHITE
OUT TIME
F123 0~127 127 FIX
WO-TIME WHITE OUT F124 0~31 0 FIX
SETTING MODE (SECOND STAGE)
EEPROM ITEMS FUNCTION OSD DATA LENGTH INITIAL
DATA
FIX/ADJ/
AUTO REMARK

21JF2-RU/GA/SA/SF/SS
3 – 11
A2-ID-Response SETTING IDENTIFICATION RESPONSE
TIME
F125 0(NORMAL) / 1(FAST) 1 FIX
R-DRI YUV OFFSET RGB OUTPUT RED GAIN OFFSET (YUV) F126 -63~0~+63 0 FIX
B-DRI YUV OFFSET RGB OUTPUT BLUE GAIN OFFSET (YUV) F127 -63~0~+63 0 FIX
R-CUT YUV OFFSET RGB OUTPUT-RED BIAS LEVEL OFFSET
(YUV)
F128 -63~0~+63 0 FIX
G-CUT YUV OFFSET RGB OUTPUT-GREEN BIAS LEVEL OFF-
SET (YUV)
F129 -63~0~+63 0 FIX
B-CUT YUV OFFSET RGB OUTPUT-BLUE BIAS LEVEL OFFSET
(YUV)
F130 -63~0~+63 0 FIX
CON YUV OFFSET SUB-CONTRAS OFFSET (YUV) F131 -63~0~+63 0 FIX
BRT YUV OFFSET SUB-BRIGHT OFFSET (YUV) F132 -63~0~+63 0 FIX
SHP ANT-ONII OFF-
SET
SHARP ANT-ON II OFFSET FOR VIDEO
TONE
F133 -31~0~+31 0 FIX
WAIT MD TIME SETTING CYCLE PROCESS TIME AT
LOW POWER
F134 0~4 2 FIX
Contrast OFFSET CONTRAST (PICTURE LEVEL) OFFSET F135 -63~0~+63 0 FIX
Bright OFFSET PICTURE BLACK LEVEL (BRIGHT) OFF-
SET
F136 -63~0~+63 0 FIX
CR-PEDESTEL-ADJ Cr SIGNAL LEVEL ADJUSTMENT F137 0~15 8 FIX ONLY FOR
M62166
CB-PEDESTEL-ADJ Cb SIGNAL LEVEL ADJUSTMENT F138 0~15 8 FIX ONLY FOR
M62166
SIF-PAL SOUND S/N SWITCH FOR PAL F139 0(DISABLE) / 1(ENABLE) 0 FIX ONLY FOR
M62166
AV2 BRIGHTNESS
OFFSET
AV2 BRIGHT OFFSET F140 -15~0~+15 +7 FIX
BASS OFFSET BASS OFFSET F141 -30~0~+30 0 FIX
TREBLE OFFSET TREBLE OFFSET F142 -30~0~+30 0 FIX
SETTING MODE (SECOND STAGE)
EEPROM ITEMS FUNCTION OSD DATA LENGTH INITIAL
DATA
FIX/ADJ/
AUTO REMARK

21JF2-RU/GA/SA/SF/SS
3 – 12
OPTION MODE (FOURTH STAGE)
EEPROM ITEMS OSD DATA LENGTH INITIAL DATA REMARK
***HOTEL MODE O01 0 (0FF) / 1 (0N) 0 OPTION SET UP
***HTL-POS O02 0~99,-- -- OPTION SET UP
***HTL-VOL O03 0~60,-- -- OPTION SET UP
VIF O04 0 (38.0) / 1 (38.9) 1 OPTION SET UP
SECAM O05 0 (DISABLE) / 1 (ENABLE) 1 OPTION SET UP
N443(RF) O06 0 (DISABLE) / 1 (ENABLE) 1 OPTION SET UP
N358(RF) O07 0 (DISABLE) / 1 (ENABLE) 1 OPTION SET UP
FORCE-COL O08 0 (DISABLE) / 1 (ENABLE) 0 OPTION SET UP
S-SYS O09 1(BG ONLY)~15(ALL) 15 OPTION SET UP
AV O10 0 (DISABLE) / 1 (ENABLE) 1 OPTION SET UP
AV2 O11 0 (DISABLE) / 1 (ENABLE) 1 OPTION SET UP
YUV O12 0 (DISABLE) / 1 (ENABLE) 1 OPTION SET UP
S-CTRL O13 0 (DISABLE) / 1 (ENABLE) 1 OPTION SET UP
NICAM O14 0 (DISABLE) / 1 (ENABLE) 0 OPTION SET UP
A2 O15 0 (DISABLE) / 1 (ENABLE) 0 OPTION SET UP
TELETEXT O16 0 (DISABLE) / 1 (ENABLE) 0 OPTION SET UP
BILLINGUAL O17 0 (DISABLE) / 1 (ENABLE) 0 OPTION SET UP
LANGUAGE O18 1~255 63 OPTION SET UP
SEARCH-SPEED O19 1(350)~2(450)~3(550)~4(650)~5(750) 3 OPTION SET UP
R/C-MENU O20 0 (ENABLE) / 1 (DISABLE) 0 OPTION SET UP
LED-CONT O21 0 (ONE LED) / 1 (TWO LED) 0 OPTION SET UP
S-BOOSTER O22 0 (DISABLE) / 1 (ENABLE) 0 OPTION SET UP
SHARP-LOGO O23 0 (DISABLE) / 1 (ENABLE) 0 OPTION SET UP
YUV BKGD ADJ O24 0 (DISABLE) / 1 (ENABLE) 0 OPTION SET UP
WHITE BACK O25 0 (DISABLE) / 1 (ENABLE) 1 OPTION SET UP
BOOSTER O26 0 (DISABLE) / 1 (ENABLE) 0 OPTION SET UP
****MESSAGE O27 0 (DISABLE) / 1 (ENABLE) 0 OPTION SET UP
****MESSAGE SCROLL TIME O28 Message Display Timing 0 OPTION SET UP
LNA TUNER O29 0(Alps) / 1(Matsushita) 0 OPTION SET UP
ONE CHIP IC O30 0(M61260 & M61262) / 1(M61266) 0 OPTION SET UP
MESSAGE INPUT TIMMING O31 0~4 2 OPTION SET UP
*** HOTEL MODE
OPERATION OF HOTEL MODE:
WHEN CHANGE SERVICE DATA O01 TO 1, HOTEL MODE IS ON
WHEN HOTEL MODE IS ON,
1. Max volume data is determined by option setting HTL-VOL (O03)
2. Channel position after POWER ON is determined by option setting HOTEL-POS (O02) (if option setting HOTEL-POS
is not set, processing is according to last position data).
3. User data updates of EEPROM regarding the video and audio control is not allowed.
4. Preset mode is disable.
5. CH SETTING menu is not available.

21JF2-RU/GA/SA/SF/SS
3 – 13
4. ADJ ITEM: BUS SET UP (1 ST & 2ND STAGE SERVICE DATA)
5. ADJ ITEM: OPTION SET UP (4TH STAGE SERVICE DATA)
SERVICE ITEMS 21JF2-RU 21JF2-GA/SA 21JF2-SF 21JF2-SS
V08 SUB-SHARPNESS 46 46 46 46
F06 S-OUT-LVL 105 105 105 105
F24 COL-AV +10 0 0 0
F29COL-ADJ 0 +5+5+5
F30SHP-AV +1+1+1+1
F36TINT-AV 0 -3-3-3
F37 TINT-ADJ 0 -8 -8 -8
F39 R-R +8 0 0 0
F40B-R -10-9-9-9
F41 R-B -3 -6 -6 -6
F42 B-B (OFFSET) +16 +8 +8 +8
SERVICE ITEMS 21JF2-RU 21JF2-GA/SA 21JF2-SF 21JF2-SS
O01 HTL MODE 0 (0FF) / 1 (0N) 0 0 0 0
O02 HTL-POS 0~99,-- -- -- -- --
O03 HTL-VOL 0~60,-- -- -- -- --
O04 VIF 0 (38.0) / 1 (38.9) 1 1 1 1
O05 SECAM 0 (DISABLE) / 1 (ENABLE) 1 1 1 1
O06 N443(RF) 0 (DISABLE) / 1 (ENABLE) 1 1 1 1
O07 N358(RF) 0 (DISABLE) / 1 (ENABLE) 0 0 0 0
O08 FORCE-COL 0 (DISABLE) / 1 (ENABLE) 0 0 0 0
O09 S-SYS 1(BG ONLY)~15(ALL) 7 7 7 7
O10 AV 0 (DISABLE) / 1 (ENABLE) 1 1 1 1
O11 AV2 0 (DISABLE) / 1 (ENABLE) 1 1 1 1
O12 YUV 0 (DISABLE) / 1 (ENABLE) 0 0 0 0
O13 S-CTRL 0 (DISABLE) / 1 (ENABLE) 0 0 0 0
O14 NICAM 0 (DISABLE) / 1 (ENABLE) 0 0 0 0
O15 A2 0 (DISABLE) / 1 (ENABLE) 0 0 0 0
O16 TEXT 0 (DISABLE) / 1 (ENABLE) 0 0 0 0
O17 BIL 0 (DISABLE) / 1 (ENABLE) 0 0 0 0
O18 LANG 1~255 9 55 63 63
O19 SEARCH-SP 1(350)~2(450)~3(550)~4(650)~5(750) 3 3 3 3
O20 R/C MENU 0 (ENABLE) / 1 (DISABLE) 1 1 1 1
O21 LED-CONT 0 (ONE LED) / 1 (TWO LED) 0 0 0 0
O22 S-BOOSTER 0 (DISABLE) / 1 (ENABLE) 0 0 0 0
O23 SHARP-LOGO 0 (DISABLE) / 1 (ENABLE) 0 0 0 0
O24 YUV BKGD ADJ 0 (DISABLE) / 1 (ENABLE) 0 0 0 0
O25 WHITE BACK 0 (DISABLE) / 1 (ENABLE) 0 0 0 0
O26 BOOSTER 0 (DISABLE) / 1 (ENABLE) 0 0 0 0
O27 MESSAGE 0 (DISABLE) / 1 (ENABLE) 0 0 0 0
O28 MESSAGE SCROLL TIME 0 ~ 20 0 0 0 0
O29 LNA TUNER 0(Alps) / 1(Matsushita) 0 0 0 0
O30 ONE CHIP IC 0(M61260 & M61262) / 1(M61266) 0 0 0 0
O31 MSG IN TM 2 2 2 2

21JF2-RU/GA/SA/SF/SS
3 – 14
[2] ADJUSTMENT
ADJUSTMENT PRECAUTION: Makesure TV Set is in “Normal Condition” before switch to Service Mode for Adjustment.
1. PIF ADJUSTMENT
No. Adjustment point Adjustment procedure/conditions Waveform and others
Tuner IFT
( PRESET )
11. Get the tuner ready to receive the CH. E - 9
signal,but with no signal input.
Adjust the PLL data.
2. Connect the sweep generator's output cable to
the tuner antenna. ( RF SWEEP )
3. Adjust the sweep generator's to 80dBµV.
4. Connect the response lead ( use LOW IMPED-
ANCE probe with wave detector ; see Fig.1 ) to
the tuner's IF output terminal. ( This terminal must
have the probe alone connected ).
5. Set the RF AGC to 0 - 6 V with no saturation with
the waveform.
6. Adjust the tuner IF coil to obtain the waveform as
showninFig.2.
Note: Be sure to keep the tuner cover in posi-
tion during this adjustment.
RF-AGC
TAKE OVER
POINT AD-
JUSTMENT
(I
2
C BUS
CONTROL)
(AUTO &
MANUAL ADJ)
1. Receive "PAL COLOUR BAR" signal.
Signal Strength: 56 ±1dBµV (75 ohm open)
2. Connect the oscilloscope to TP201 (Tuner’s AGC
Terminal) as shown in Fig. 3-1.
3. Call "V01" mode in service mode. Adjust the "V01"
bus data to obtain the Tuner output pin drop
0.1~1.0V below maximum voltage.
4. Change the antenna input signal to 63~67dBµV,
and make sure there is no noise.
5. Turn up the input signal to 90~95 dBµVtobesure
that there is no cross modulation beat.
* for Auto ADJ
1)Receive “PAL COLOUR BAR”
signal.
signal strength: 56 ±1dBµV(75
ohm open)
1)Go to service mode.
2)Go to service data V01, press
R/C to operate auto key (Hex
C1) and confirm the ‘OK’
display on the screen.
3)If appear NG, increase data
some step and pls repeat step
2.
4)Proceed step 4 & 5 in manual
mode.
2
»
»
Bias box: About 4.5 V
Oscilloscope
0.1V
TV Set
Bias box
TP201+
+
—
—
Fig. 3-1
E-9 CH
PC
10k
100k
1n60
75ohm
IF OUT
-1.5+/-0.8dB
1000p
1000p
Oscilloscope
Fig.1
Fig.2

21JF2-RU/GA/SA/SF/SS
3 – 15
2. PURITY ADJUSTMENT
No. Adjustment point Adjustment procedure/conditions Waveform and others
1. Receive the GREEN-ONLY signal. Adjust the
beam current to ~700 µA.
2. Degauss the CRT enough with the degausing coil.
Note: Follow the Job Instruction Sheet to adjust
the magnetic field.
(Reference: page 3-6)
3. Maintain the purity magnet at the zero magnetic
field and keep the static convergence roughly
adjusted.
4. Observe the points a, b,as shown in Fig. 1-1
through the microscope. Adjust the landings to A
rank requirement.
5. Orient the raster rotation to 0 eastward.
6. Tighten up the deflection coil screws.
Tightening torque: 108 ±20N(11±2kgf)
7. Make sure the CRT corners landing meet the A
rank requirements. If not, stick the magnet sheet
to correct it.
Note: This adjustment must be done after
warming up the unit for 30 minutes or
longer with a beam current over 700
µ A.
Note:
* For the following colours press R/C RGB(Hex 7E)
key to change.
PURITY ADJ.1
ab
A
B
A
30mm 30mm
B
A=B
A=B
Rank "A"
(on the right of the CRT)
Rank "A"
(on the left of the CRT)
Fig. 1-1
Fig. 1-2
Fig. 1-3
* Press R/C RGB key for 1 sec-
ond in NORMAL MODE, the
colour will change to RGB
mono colour mode.
Signal-colour
screen cleared
GREEN
ONLY
BLUE
ONLY
RED
ONLY
Set to service mode by remote con-
troller then press factory process R/C
RGB key to change to RGB mono col-
our mode.

21JF2-RU/GA/SA/SF/SS
3 – 16
3. CONVERGENCE ADJUSTMENT
No. Adjustment point Adjustment procedure/conditions Waveform and others
CONVERGENCE
ADJ.
(Tobedone
after the purity
adjustment.)
1. Receive the "Crosshatch Pattern" signal.
2. Using the remote controller, call NORMAL mode.
Static convergence
1. Turn the 4-pole magnet to a proper opening an-
gle in order to superpose the blue and red col-
ours.
2. Turn the 6-pole magnet to a proper opening an-
gle in order to superpose the green colour over
the blue and red colours.
Dynamic convergence
1. Adjust the convergence on the fringes of the
screen in the following steps.
a) Fig. a: Drive the wedge at point "a" and swing
the deflection coil upward.
b) Fig. b: Drive the wedge at point "b" and "c" and
swing the deflection coil downward.
c) Fig. c: Drive the "c" wedge deeper and swing
the deflection coil rightward.
d) Fig. d: Drive the "b" wedge deeper and swing
the deflection coil leftward.
2. Fix all the wedges on the CRT and apply glass
tape over them.
3. Apply lacquer to the deflection yoke lock screw,
magnet unit (purity, 4-pole, 6-pole magnets) and
magnet unit lock screw.
Finally received the Red-only and Blue-only sig-
nals to make sure there is no other colours on the
screen.
1
RGB
BGR
R
G
B
R
G
B
B
G
R
B
G
R
RGB
BGR
Lacquer
Wedge "a"
Wedge
"b"
Wedge
"c"
About
100Deg
About
100Deg
Fig. a
Fig. b
Fig. c
Fig. d
4-pole magnet
6-pole magnet
CRT neck
20mm
Lacquer
Purity magnet

21JF2-RU/GA/SA/SF/SS
3 – 17
4. H-VCO, VIF-VCO & S-TRAP fo ADJUSTMENT
No. Adjustment point Adjustment procedure/conditions Waveform and others
H-VCO ADJ
(I
2
C BUS
CONTROL)
(AUTO &
MANUAL ADJ)
(MANUAL ADJ)
1) In No signal (RASTER) condition.
2) Go to service mode, choose service data V03.
3) Connect oscilloscope to IC801 pin11, adj V03 until
freq become 15.625 ±0.15 KHz
(Auto Adj)
1) In No signal (RASTER) condition.
2) Go to service mode.
3) Choose service data V03, by pressing R/C Auto
(Hex C1) key, OSD will appear “OK” at screen.
4) If appear “NG” pls repeat step 3.
(Manual ADJ)
1) In No signal (RASTER) condition.
2) Go to service mode, choose service data V02.
3) Connect oscilloscope to IC801 pin2, adj V02 until
voltage become 2.5 ±1V.
(Auto Adj)
1) In No signal (RASTER) condition.
2) Go to service mode, choose service data V02.
3) Press the R/C Auto (Hex C1) key, OSD will appear
“OK” at screen.
4) If appear “NG” pls repeat step 3.
(Manual ADJ)
1) In No signal (RASTER) condition.
2) Go to service mode, choose service data V21.
3) Connect oscilloscope to TP 801, adj V21 until
voltage become Min (below 5 V).
4) After that pls adj service data V20 & V24 same as
“V21”, V22 to “V21-1”, V23 to “V21+2”.
(Auto Adj)
1) In No signal (RASTER) condition.
2) Go to service mode, choose service data V21.
3) Press the R/C Auto (Hex C1) key, OSD will appear
“OK” at screen.
4) If appear “NG” pls repeat step 3.
1
VIF-VCO ADJ
(I
2
C BUS
CONTROL)
(AUTO &
MANUAL ADJ)
2
S-TRAP fo
ADJ
(I
2
C BUS
CONTROL)
(AUTO &
MANUAL ADJ)
3
This adjustment must be done
after aging at least 3 minutes.
