Sharp Aquos LC-46D84X User manual

MODEL
LC-46D84X
LC-52D84X
LCD COLOUR TELEVISION
OPERATION MANUAL
cover_52D84X.indd 1cover_52D84X.indd 1 6/16/2008 9:28:16 AM6/16/2008 9:28:16 AM

1
Dear SHARP customer
Contents
Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many years of
trouble-free operation of your product, please read the Important Safety Precautions carefully before
using this product.
OPERATION MANUAL
Introduction
Dear SHARP customer ................................................................................................ 1
Contents .......................................................................................................................1
Important Safety Precautions..................................................................................... 4
Supplied accessories .................................................................................................. 5
Trademarks .................................................................................................................. 5
Preparation
Attaching the stand ..................................................................................................... 6
Part names ................................................................................................................... 7
TV (Front/Side) ................................................................................................. 7
TV (Rear)........................................................................................................... 8
Remote control unit.......................................................................................... 9
Before turning on the power..................................................................................... 10
Connecting external devices .................................................................................... 11
Connecting a VCR, game console or camcorder .......................................... 11
Connecting a DVD player............................................................................... 11
Connecting a STB (Satellite, Cable, etc.) ....................................................... 12
Connecting a PC ............................................................................................ 12
Inserting the batteries ............................................................................................... 13
Using the remote control unit................................................................................... 13
Cautions regarding the remote control unit ................................................... 13
Turning the TV on/off................................................................................................. 14
Turning on the power ..................................................................................... 14
Turning off the power..................................................................................... 14
About Menu operations............................................................................................. 15
What is Menu? ............................................................................................... 15
Basic Menu operations .................................................................................. 15
About Guide Display ...................................................................................... 15
A-TV/D-TV/AV input mode menu items ......................................................... 16
PC input mode menu items ........................................................................... 17
Watching TV
Setting channels automatically ................................................................................ 18
Selecting programmes .............................................................................................. 19
Adjusting the volume................................................................................................. 19
Menu language settings............................................................................................ 19
Setting channels to your preference........................................................................ 20
Auto search .................................................................................................... 20
Manual setting for each channel .................................................................... 20
Sorting programmes ...................................................................................... 22
Erasing programmes...................................................................................... 23
Labelling programmes ................................................................................... 23
Useful viewing functions ........................................................................................... 24
Split-screen viewing ...................................................................................... 24
Returning to the previously selected channel ................................................ 25
Muting the audio temporarily ......................................................................... 25
Outputting only audio..................................................................................... 25
Switching the analogue audio format ............................................................ 26
52D84X_en_a.indd 152D84X_en_a.indd 1 6/5/2008 5:06:09 PM6/5/2008 5:06:09 PM

2
Contents
Watching TV (Continued)
Reducing the start-up time ........................................................................... 26
Password setting for the child lock (for A-TV/D-TV input mode)................... 27
Energy conservation settings ................................................................................... 28
Auto power-off at a designated time ............................................................. 28
Auto power-off after the end of broadcast .................................................... 28
Auto power-off when there are no operations performed ............................. 28
Power Management ....................................................................................... 29
Ecology ......................................................................................................... 29
Picture size settings .................................................................................................. 30
Selecting the Wide Screen Signalling (WSS) picture size automatically........ 30
Selecting the Wide Screen Signalling (WSS) picture size manually............... 30
Selecting the picture size manually................................................................ 31
Selecting a preset AV MODE .................................................................................... 32
Manual picture settings............................................................................................. 33
Picture adjustment ......................................................................................... 33
Advanced picture settings ............................................................................. 34
Other picture settings................................................................................................ 35
DNR (Digital Noise Reduction) ....................................................................... 35
Adjusting the image position.......................................................................... 35
Game Play Time ............................................................................................ 35
Audio adjustment....................................................................................................... 36
Output Volume Select ................................................................................... 36
A-TV (Analogue) D-TV/RADIO buttons........................................................... 37
Basic adjustment settings (Digital)
D-TV input mode menu items ........................................................................ 38
Selecting D-TV Menu .................................................................................... 38
EPG ............................................................................................................... 39
Selecting a programme using EPG ............................................................... 39
Programme Guide ......................................................................................... 41
INFO .............................................................................................................. 41
Favourite Programme List ............................................................................. 41
Programme List ............................................................................................. 42
Favourite & Lock ........................................................................................... 42
Parental Rate ................................................................................................. 42
Installation ..................................................................................................... 43
Auto Search .................................................................................................. 43
Manual Adjust ............................................................................................... 43
Reset Data ..................................................................................................... 44
Video Setup ................................................................................................... 44
Digital Output ................................................................................................ 45
Multilingual .................................................................................................... 45
Time Setup .................................................................................................... 46
I-Plate Setup (Information Plate Setup) ......................................................... 46
Information .................................................................................................... 46
OAD Option.................................................................................................... 46
S/W Update.................................................................................................... 46
Settings when using external devices
Settings when using HDMI output devices ............................................................. 47
Selecting the input source and signal type ............................................................ 48
Selecting input source ................................................................................... 48
Selecting input signal type ............................................................................ 48
Labelling input sources ............................................................................................. 49
Skipping HDMI/PC input .......................................................................................... 49
Colour system settings ............................................................................................. 49
52D84X_en_a.indd 252D84X_en_a.indd 2 6/5/2008 5:06:10 PM6/5/2008 5:06:10 PM

3
Contents
AQUOS LINK
Controlling HDMI devices using AQUOS LINK ..................................................... 50
AQUOS LINK connection ........................................................................................ 51
Connecting an AQUOS BD Player via the AQUOS LINK-compatible
audio system ........................................................................................... 51
Connecting an AQUOS BD Player ............................................................... 51
AQUOS LINK Setup ................................................................................................. 51
AQUOS LINK Auto power on ....................................................................... 51
Selecting recorder ........................................................................................ 52
Operating an AQUOS LINK device ......................................................................... 52
Listening with the AQUOS LINK-compatible audio system ......................... 52
Listening with the AQUOS TV speaker system ............................................ 53
Manually changing the AQUOS LINK-compatible audio system’s sound
mode ........................................................................................................ 53
Playback of titles using AQUOS LINK .......................................................... 53
Selecting media type for CEC-compatible recorder .................................... 54
One Touch Recording (D-TV only) ............................................................... 54
HDMI device selection ................................................................................. 54
Recording via the AQUOS Recorder EPG (only for recorders) .................... 54
Connecting a PC
Displaying a PC image on the screen ...................................................................... 55
Selecting the picture size ............................................................................... 56
Adjusting the PC image automatically ........................................................... 57
Adjusting the PC image manually .................................................................. 57
Input resolution settings ........................................................................................... 58
Selecting the input resolution......................................................................... 58
PC Control of the TV.................................................................................................. 59
PC compatibility chart............................................................................................... 60
RS-232C commands list............................................................................................ 60
Teletext function
About Teletext............................................................................................................ 61
Teletext language setting.......................................................................................... 62
Displaying Subpages ................................................................................................. 62
Displaying Subtitles ................................................................................................... 62
DVB Subtitle
Switching subtitle languages.................................................................................... 63
Appendix
Troubleshooting......................................................................................................... 64
Troubleshooting (D-TV) ............................................................................................. 64
Error messages about recording using AQUOS LINK ........................................... 65
Reset ........................................................................................................................... 66
Specifications ............................................................................................................ 67
Optional accessory ................................................................................................... 67
Dimensional drawings............................................................................................... 68
Mounting the TV on the wall .................................................................................... 70
Removing the stand ...................................................................................... 70
Handling and precautions with the wall-mounted TV ................................... 70
CLEARING THE PASSWORD .................................................................................... 71
52D84X_en_a.indd 352D84X_en_a.indd 3 6/6/2008 10:28:14 AM6/6/2008 10:28:14 AM

4
Important Safety Precautions
• Cleaning — Unplug the AC cord
from the AC outlet before cleaning
the product. Use a damp cloth to
clean the product. Do not use liquid
cleaners or aerosol cleaners.
• Water and moisture — Do not use
the product near water, such as
bathtub, washbasin, kitchen sink,
laundry tub, swimming pool and in a
wet basement.
• Do not place vases or any other
water-filled containers on this product.
The water may spill onto the product
causing fire or electric shock.
• Stand — Do not place the product
on an unstable cart, stand, tripod
or table. Doing so can cause the
product to fall, resulting in serious
personal injuries as well as damage
to the product. Use only a cart,
stand, tripod, bracket or table
recommended by the manufacturer
or sold with the product. When
mounting the product on a wall, be
sure to follow the manufacturer’s
instructions. Use only the mounting
hardware recommended by the
manufacturer.
• When relocating the product
placed on a cart, it must be moved
with utmost care. Sudden stops,
excessive force and uneven floor
surface can cause the product to fall
from the cart.
• Ventilation — The vents and other
openings in the cabinet are designed
for ventilation. Do not cover or block
these vents and openings since
insufficient ventilation can cause
overheating and/or shorten the life
of the product. Do not place the
product on a bed, sofa, rug or other
similar surface, since they can block
ventilation openings. This product is
not designed for built-in installation;
do not place the product in an
enclosed place such as a bookcase
or rack, unless proper ventilation
is provided or the manufacturer’s
instructions are followed.
• The LCD panel used in this product
is made of glass. Therefore, it can
break when the product is struck
forcefully or with a sharp object. If
the LCD panel is broken, be careful
not to be injured by broken glass.
• Heat sources — Keep the product
away from heat sources such as
radiators, heaters, stoves and other
heat-generating products (including
amplifiers)
• To prevent fire, never place any type
of candle or naked flames on the
top or near the TV set.
• To prevent fire or shock hazard, do
not place the AC power cord under
the TV set or other heavy items.
• Do not place heavy objects on this
product or stand on it. Doing so
could cause injury if the product
overturns. Take special care near
children and pets.
The LCD panel is a very high technology product
with 2,073.600 pixels, giving you fine picture details.
Due to the very large number of pixels, occasionally
a few non-active pixels may appear on the screen
as a fixed point of blue, green or red.
This is within product specifications and does not
constitute a fault.
• Do not display a still picture for a long time, as this could
cause an afterimage to remain.
• Install the product on the place where the AC cord can
be unplugged easily from the AC outlet, or from the AC
INPUT terminal on the rear of the product.
Precautions when
transporting the TV
When transporting the TV, never
carry it by holding or otherwise
putting pressure onto the display.
Be sure to always carry the TV
by two people holding it with two
hands — one hand on each side
of the TV.
52D84X_en_b.indd 452D84X_en_b.indd 4 5/21/2008 10:58:54 AM5/21/2008 10:58:54 AM

Supplied accessories
5
Make sure the following accessories are provided with the product.
Remote control unit “AAA” size battery (g2) AC cord
Cable clamp
Operation manual
Stand unit
Page 9 Page 13
Page 10
Used with batteries inserted.
For bundling cables.
Always use the AC cord supplied with
the TV.
Trademarks
• Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
• TruSurround XT, SRS and h®symbol are trademarks of SRS Labs, Inc.
TruSurround XT technology is incorporated under license from SRS Labs, Inc.
• “HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.”
Page 6
Stand base Short screws (g4)
Long screws (g4)
Stand post Hex key Cloth
Put all parts of the stand unit together and then attach it to the TV.
Page 10
52D84X_en_b.indd 552D84X_en_b.indd 5 6/17/2008 4:02:17 PM6/17/2008 4:02:17 PM

6
Preparation
• Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being
damaged.
CAUTION
• Attach the stand in the correct direction.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
Attaching the stand
1 3 1Insert the stand into the openings on the
bottom of the TV.
2Insert and tighten the 4 short screws into
the 4 holes on the rear of the TV.
Hex key
Short
screw
Soft
cushion
NOTE
• To detach the stand, perform the steps in reverse order.
2Attach the supporting post for the stand unit
onto the base as shown below.
Confirm the 8 screws supplied with the TV.
Short screws (g4)
(used in step 3) Long screws (g4)
(used in step 2)
Hex
key
Long screw
52D84X.indb 652D84X.indb 6 4/24/2008 3:47:25 PM4/24/2008 3:47:25 PM

7
Preparation
Part names
Volume up (e)/down (f) buttons
Channel up (r)/down (s) buttons
OPC indicator*
POWER (On/Off) button
TV/VIDEO button
*OPC: Optical Picture Control (See page 33.)
** See page 14 for the TV status indicator.
MENU button
OPC sensor
Remote control sensor
POWER indicator**
• The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations.
• The illustrations used throughout this manual are based on LC-46D84X.
TV (Front/Side)
SLEEP timer indicator
52D84X_en_b.indd 752D84X_en_b.indd 7 5/29/2008 9:21:50 AM5/29/2008 9:21:50 AM

8
Preparation
TV (Rear)
Regarding the headphone jack
• Use headphones with a stereo mini plug (Ø 3.5 mm).
• Be sure to unplug headphones from the jack when they are not
in use.
• The speakers do not output volume when headphones are
plugged in.
• The “Audio” menu cannot be operated when headphones are
plugged in.
• You can set the volume to different levels for each input source.
Volume display when headphones are plugged in
20
RS-232C terminal
INPUT 4 (HDMI)
terminals
INPUT 7 (PC) terminals
INPUT 2 terminals
INPUT 1 terminals
Antenna input terminal
AC INPUT terminal
Headphone jack
INPUT 5 (HDMI) terminals
INPUT 6 (HDMI) terminals
INPUT 3 terminals
MONITOR OUTPUT terminal
DIGITAL AUDIO OUTPUT terminal
52D84X_en_b.indd 852D84X_en_b.indd 8 5/29/2008 9:21:50 AM5/29/2008 9:21:50 AM

9
Preparation
Remote control unit
1 POWER (STANDBY/ON)
To switch the power on and off. (See page 14.)
2 0 – 9
Set the channel. (See page 19.)
TELETEXT mode: Set the page. (See pages 61 and 62.)
3 A(Flashback)
Press to return to the previous selected channel or external input
mode. (See page 25.)
4 A-TV
Press to access ANALOGUE mode. (See page 37.)
5 D-TV
Press to access D-TV mode. (See page 37.)
6 MPX
Select the sound multiplex mode. (See page 26 and 45.)
7 VOLk/VOLl
Set the volume. (See page 19.)
8 e(Mute)
Mute the sound. (See page 25.)
9 GUIDE
D-TV mode: Display the programme list. (See page 41.)
10 EPG
D-TV mode: To display EPG (Electronic Programme Guide)
screen. (See page 39 to 40.)
11 EXIT
Turn off the On-Screen Display.
12 OPC
To switch the Optical Picture Control on and off.
(See page 33.)
AV MODE
Select a video setting. (See page 32.)
WIDE
Change the wide image mode. (See pages 31 and 56.)
FREEZE
Freeze a motion picture on the screen. (See page 24.)
P&P
Set the dual picture mode. Press P&P again to return to normal
view. (See page 24.)
SELECT
To select either screen to be active in Dual screen mode.
13 m(TELETEXT)
Select the TELETEXT mode. (all TV image, all TEXT image,
TV/TEXT image) (See pages 61 and 62.)
k(Reveal hidden for TELETEXT)
TELETEXT mode: Display hidden characters. (See page 61.)
[(SUBTITLE for TELETEXT)
To turn the subtitles on and off. (See page 62 and 63.)
3(Hold)
TELETEXT mode: Stop updating Teletext pages automatically.
Press 3again to release the hold mode. (See pages 61 and
62.)
1(Subpage)
Display the Teletext subpage directly. (See page 62.)
v(Top/Bottom/Full)
TELETEXT mode: Set the area of magnification. (See page 61.)
14 TV/VIDEO (INPUT SOURCE)
Select an input source. (A-TV, D-TV, INPUT 1, INPUT 2, INPUT 3,
INPUT 4, INPUT 5, INPUT 6, INPUT 7 (PC)) (See pages 11, 24,
47 to 49.)
15 FAV.
Display the favourite channel setting. (See page 41.)
16 RADIO
Press to access RADIO mode. (See page 37.)
17 DISPLAY
Displays the channel or input information.
18 CHr/CHs
TV input mode: Select the channel. (See page 19.)
TELETEXT mode: Select the page. (See page 61.)
19 SLEEP
Set the Sleep timer. (See page 28.)
20 INFO
D-TV mode: Display the programme information. (See page 41.)
21 MENU
Display the menu screen. (See page 15.)
22 a/b/c/d(Cursor)
Select a desired item on the setting screen.
ENTER
Execute a command.
23 RETURN
MENU mode: Return to the previous menu screen. (See page
15.)
24 Colour (Red/Green/Yellow/Blue)
TELETEXT mode: Select a page. (See page 61.)
25 AQUOS LINK buttons
If external equipment such as a AQUOS BD Player is connected
via HDMI cables and is AQUOS LINK compatible, you can use
these AQUOS LINK buttons. See pages 50 to 54 for details.
2
6
11
12
1
8
7
10
5
9
17
18
23
21
20
14
15
19
16
24
25
22
13
4
3
A-TV D-TV RADIO FAV.
52D84X_en_b.indd 952D84X_en_b.indd 9 6/18/2008 3:48:23 PM6/18/2008 3:48:23 PM

Preparation
10
1
Before turning on the power
Notes on installing the TV
• Avoid direct sunlight and place the TV in a well-ventilated location.
• Place the TV in a level location.
• Do not turn on the power of the TV before connecting the AC cord.
Cable clamp
CAUTION
• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT TOUCH UN-INSULATED PARTS OF ANY CABLES WITH THE
AC CORD CONNECTED.
Bundling the cables
Insert the cable clamp in the hole on the TV as shown.
4
AC cord
Connecting the AC cord
AC outlet
• Place the TV close to the AC outlet, and keep the power plug within reach.
• Disconnect the AC cord from the AC outlet if the TV will not be used for a long period of time.
TV (rear view)
Connecting the antenna cable
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of
connections that are used for coaxial cable.
Standard DIN45325 plug (IEC169-2)
75-ohm coaxial cable (round cable)
Room antenna terminal
(75-ohm type)
Antenna cable
(commercially available)
To antenna
terminal
Connecting external devices
See pages 11 to 12 for connecting external equipment, such as a VCR and DVD player.
2
3
52D84X.indb 1052D84X.indb 10 5/20/2008 2:49:20 PM5/20/2008 2:49:20 PM

11
Preparation
CAUTION
• To protect all equipment, always turn off the TV before connecting to a VCR, game console, camcorder, DVD player, Digital
TV STB (Set Top Box), PC or other external equipment.
• Refer to the relevant operation manual (VCR, DVD player, etc.) carefully before making connections.
Connecting a VCR, game console or camcorder
A VCR, game console, camcorder and some other audiovisual equipment can be conveniently connected using
the INPUT 1/INPUT 2 (component) or INPUT 3 terminals.
Connecting a DVD player
You can use the INPUT 1/INPUT 2 (component), INPUT 3 or INPUT 4/INPUT 5/INPUT 6 (HDMI) terminals when
connecting to a DVD player and other audiovisual equipment.
When using HDMI cable
(commercially available)
When using component cable
(commercially available)
NOTE
• When using a DVI-HDMI conversion adaptor, input the Audio Signal from the AUDIO terminal of INPUT 6. (See page 47.)
R – AUDIO – LY
PB
(CB)
PR
(CR)
When using component cable
(commercially available)
R – AUDIO – LY
PB
(CB)
PR
(CR)
Connecting external devices
You can connect many types of external equipment to your TV, like a VCR, game console, camcorder, DVD
player, Digital TV STB (Set Top Box) and PC. To view external source images, select the input source from TV/
VIDEO on the remote control unit or TV/VIDEO on the TV.
When using composite cable or
S-VIDEO cable (commercially available)
VCR/
Game console/
Camcorder
L
R
AUDIO
VIDEO
S-VIDEO
DVD player
VCR/
Game console/
Camcorder
DVD player
or
52D84X_en_b.indd 1152D84X_en_b.indd 11 5/21/2008 2:34:41 PM5/21/2008 2:34:41 PM

12
Preparation
Connecting a STB (Satellite, Cable, etc.)
You can use the INPUT 1/INPUT 2 (component) or INPUT 4/INPUT 5/INPUT 6 (HDMI) terminals when connecting
to a STB (Satellite, Cable, etc.) and other audiovisual equipment.
NOTE
• When using a DVI-HDMI conversion adaptor, input the Audio Signal from the AUDIO terminal of INPUT 6. (See page 47.)
When using HDMI cable
(commercially available)
When using component cable
(commercially available)
R – AUDIO – LY
PB
(CB)
PR
(CR)
STB
(Set Top Box)
Digital TV STB
(Set Top Box)
Connecting a PC
You can use the INPUT 7 (PC) terminal when
connecting to a PC. (See page 55.)
ANALOG
RGB
AUDIO
(L/R)
PC
52D84X_en_b.indd 1252D84X_en_b.indd 12 6/5/2008 5:44:42 PM6/5/2008 5:44:42 PM

30º 30º
30º
30º
A-TV D-TV RADIO FAV.
13
Preparation
CAUTION
Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.
• Do not mix batteries of different types. Different types of batteries have different characteristics.
• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical
leakage in old batteries.
• Remove batteries as soon as they have worn out. Chemicals that leak from batteries can cause a rash. If you find any
chemical leakage, wipe thoroughly with a cloth.
• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.
• If you will not be using the remote control unit for an extended period of time, remove the batteries from it.
Remote control sensor
1 Open the battery cover.
• Place batteries with their terminals
corresponding to the (e) and (f)
indications in the battery compartment.
2Insert the two supplied “AAA” size
batteries.
3Close the battery cover.
5 m
Use the remote control unit by pointing it towards the
remote sensor window.
Objects between the remote control unit and sensor
window may prevent proper operation.
Cautions regarding the remote control unit
• Do not subject the remote control unit to shock.
In addition, do not soak the remote control unit with liquids or place it
in an area with high humidity.
• Do not install or place the remote control unit under direct sunlight.
The heat may cause deformation of the unit.
• The remote control unit may not work properly if the remote sensor
window of the TV is under direct sunlight or strong lighting. In such
cases, change the angle of the lighting or TV, or operate the remote
control unit closer to the remote sensor window.
Inserting the batteries
Before using the TV for the first time, insert two “AAA” size batteries (supplied). When the batteries become
depleted and the remote control fails to operate, replace the batteries with new “AAA” size batteries.
Using the remote control unit
52D84X.indb 1352D84X.indb 13 4/24/2008 3:47:31 PM4/24/2008 3:47:31 PM

14
Turning on the power
Press POWER on the TV.
• POWER indicator (Green): The TV is on. (After a few
seconds, an image appears with sound.)
• After turning the power “ON” by pressing POWER on the
TV, you can turn the power ON/OFF by pressing POWER
on the remote control.
Preparation
POWER button
POWER button
Turning off the power
POWER indicator
POWER indicator
NOTE
• If you are not going to use this TV for a long period of time,
be sure to remove the AC cord from the AC outlet.
• Minor power is consumed when the unit is in standby
mode.
Turning the TV on/off
Press POWER on the remote control.
• The TV enters standby mode and the image on the screen
disappears.
• The POWER indicator on the TV changes from green to
red.
Press POWER on the TV.
• The POWER indicator on the TV turns off.
• When the TV is turned off by POWER on the TV, you
cannot turn on the power by pressing POWER on the
remote control.
Light off Power off
Lighted (Red) The TV is in standby mode.
Lighted (Green) The TV is on.
52D84X.indb 1452D84X.indb 14 4/24/2008 3:47:32 PM4/24/2008 3:47:32 PM

ENTER MENU RETURN
wUsing the control panel of the TV
You can also operate the Menu using the control panel
of the TV.
Button operations on the control panel correspond to
the ones on the remote control as shown below.
NOTE
• Menu options differ in the selected input modes, but the
operating procedures are the same.
• The screens in the operation manual are for explanation
purposes (some are enlarged, others cropped) and may
vary slightly from the actual screens.
About Menu operations
TV control panel buttons Remote control buttons
TV/VIDEO ENTER
CH ra
CH sb
VOL kd
VOL lc
15
MENU [Picture]
Picture Audio Power Control Setup
Contrast
OPC [Off]
AV Mode [STANDARD]
Brightness
Colour
Tint
Sharpness
Advanced
Reset
[ 30]
[ 0]
[ 0]
[ 0]
[ 0]
Backlight [+16]
+
+
+
+
Preparation
Basic Menu operations
The bar above is an operational guide for
the remote control. The bar will change in
accordance with each menu setting screen.
What is Menu?
• You need to bring up the On-Screen Display to perform
settings for the TV. The On-Screen Display for the settings
is called “Menu”.
• The Menu enables various settings and adjustments. (See
pages 16 and 17.)
• The Menu can be operated with the remote control unit.
Press MENU and the MENU screen displays.
Press c/dto select the desired menu, and
then press ENTER.
Press a/bto select the desired menu item.
Press ENTER to proceed if necessary.
1
2
3
Press EXIT or MENU to exit the MENU.
Press RETURN as necessary to return to the
previous MENUs.
5
Press a/bor c/dto select the desired item
or adjust the item to the desired level. Press
ENTER if necessary.
4
About Guide Display
The Guide Display at the bottom of the screen shows
operations with an On-Screen Display.
Audio
Treble
Bass
Balance
Surround
Bass Enhancer
Reset
[ 0]
[ 0]
-
L
+
[ 0] - +
R
STANDARD
Power Control
Audio
Treble
Bass
Balance
Surround
Bass Enhancer
Reset
[ 0]
[ 0]
-
L
+
[ 0]
R
STANDARD
Power Control
-+
52D84X_en_c.indd 1552D84X_en_c.indd 15 6/18/2008 4:00:51 PM6/18/2008 4:00:51 PM

16
Preparation
A-TV/D-TV/AV input mode menu items
List of A-TV/D-TV/AV menu items to help you with operations
AV Mode ..................................................................... Page 32
OPC ............................................................................. Page 33
Backlight .................................................................... Page 33
Contrast ...................................................................... Page 33
Brightness .................................................................. Page 33
Colour ......................................................................... Page 33
Tint .............................................................................. Page 33
Sharpness .................................................................. Page 33
Advanced
Colour Temp. .................................................. Page 34
Fine Motion Advanced ................................... Page 34
Film Mode ....................................................... Page 34
Black ............................................................... Page 34
3D-Y/C ............................................................ Page 34
Monochrome .................................................. Page 34
Reset ........................................................................... Page 33
Audio
AV Mode ..................................................................... Page 32
Treble .......................................................................... Page 36
Bass ............................................................................ Page 36
Balance ....................................................................... Page 36
Surround ..................................................................... Page 36
Bass Enhancer............................................................ Page 36
Reset ........................................................................... Page 36
Setup
Auto Installation ......................................................... Page 18
Programme Setup .............................................. Pages 20-23
Child Lock .................................................................. Page 27
Input Skip ................................................................... Page 49
Input Label ................................................................. Page 49
Position ....................................................................... Page 35
WSS ............................................................................ Page 30
4:3 Mode ..................................................................... Page 30
Standby Mode ............................................................ Page 26
Language .................................................................... Page 19
Text Language ........................................................... Page 62
Reset ........................................................................... Page 66
Option
AQUOS LINK Setup .................................................... Page 51
D-TV Menu ...........................................................Pages 38-46
DNR ............................................................................. Page 35
Input Select
INPUT1 ............................................................ Page 48
INPUT2 ............................................................ Page 48
INPUT3 ............................................................ Page 48
Output Volume Select ............................................... Page 36
Audio Only .................................................................. Page 25
Game Play Time ......................................................... Page 35
Colour System ........................................................... Page 49
HDMI Setup
Auto View ........................................................ Page 47
Audio Select ................................................... Page 47
Power Control
No Signal Off .............................................................. Page 28
No Operation Off ....................................................... Page 28
Ecology ....................................................................... Page 29
NOTE
• Some menu items may not be displayed depending on the selected input source.
52D84X.indb 1652D84X.indb 16 5/20/2008 2:49:24 PM5/20/2008 2:49:24 PM

17
PC input mode menu items
List of PC menu items to help you with operations
AV Mode ..................................................................... Page 32
OPC ............................................................................. Page 33
Backlight .................................................................... Page 33
Contrast ...................................................................... Page 33
Brightness .................................................................. Page 33
Advanced
Colour Temp. .................................................. Page 34
Black ............................................................... Page 34
Reset ........................................................................... Page 33
Audio
AV Mode ..................................................................... Page 32
Treble .......................................................................... Page 36
Bass ............................................................................ Page 36
Balance ....................................................................... Page 36
Surround ..................................................................... Page 36
Bass Enhancer............................................................ Page 36
Reset ........................................................................... Page 36
Setup
Input Skip ................................................................... Page 49
Input Label ................................................................. Page 49
Standby Mode ............................................................ Page 26
Language .................................................................... Page 19
Text Language ........................................................... Page 62
Reset ........................................................................... Page 66
Option
NOTE
• Some menu items may not be displayed depending on the selected input source.
AQUOS LINK Setup .................................................... Page 51
Input Select
INPUT1 ............................................................ Page 48
INPUT2 ............................................................ Page 48
INPUT3 ............................................................ Page 48
Output Volume Select ............................................... Page 36
Audio Only .................................................................. Page 25
Game Play Time ......................................................... Page 35
Fine Sync.
Input Signal ..................................................... Page 58
Auto Sync. ...................................................... Page 57
H-Position ....................................................... Page 57
V-Position ....................................................... Page 57
Clock ............................................................... Page 57
Phase .............................................................. Page 57
Reset ............................................................... Page 57
Power Control
Power Management .................................................. Page 29
No Operation Off ....................................................... Page 28
Ecology ....................................................................... Page 29
Preparation
52D84X.indb 1752D84X.indb 17 5/15/2008 2:06:00 PM5/15/2008 2:06:00 PM

18
Press MENU and the MENU screen displays.
Press c/dto select “Setup”.
Press a/bto select “Auto Installation”, and
then press ENTER.
1
2
3
A-TV D-TV RADIO FAV.
MENU [Setup ... Auto Installation]
Setup Option
Child Lock
Input Skip
Input Label
Auto Installation
Programme Setup
Position
Language
Standby Mode
Text Language
Reset
4:3 Mode
WSS
If you have already set the password, enter it
here.
• See page 27 for setting a password.
4
6Press a/bto select the desired language
listed on the screen, and then press ENTER.
Press a/bto select the desired sound
system, and then press ENTER.
You do not need to do anything during the
auto search.
“Search is completed.” is displayed. Press
MENU to exit.
Press a/bto select “Yes”, and then press
ENTER.
5
Watching TV
Setting channels automatically
You can run auto installation again, even after setting
up the preset channels.
52D84X_en_c.indd 1852D84X_en_c.indd 18 5/29/2008 9:24:28 AM5/29/2008 9:24:28 AM
