Shelly Dimmer 2 User manual

EN
SHELLY DIMMER SMART DIMMING
L
N
ONLLLSW2SW1
L
N
ONLLLSW2SW1
L
N
ONLLLSW2SW1
L
N
Bypass
ONLLLSW2SW1
g. 1
g. 3
g. 2
g. 4
Legend
• SW1 - Switch input 1 for on/off/dimming
• SW2 - Switch input 2 for on/off/dimming
• O - Output
• L - Line input (110-240V)
• N - Neutral input (Zero)
⚠CAUTION! When using the device without neutral, Shelly Dimmer
2 requires at least 10W of power consumption, in order to operate.
If the connected light has a smaller power consumption, then Shelly
Bypass is required for the operation of the Device.
The Shelly smart WiFi dimmer by Allterco Robotics is intended to
be installed directly to your lights in order to control and dim the
light. It is intended to be mounted into a standard in-wall console,
behind the light switches or other places with limited space. Shelly
may work as a standalone device or as an accessory to a home
automation controller.
⚠CAUTION! Shelly dimmer cannot be connected and operate a fan.
Doing so may cause damage to the unit or fan, including causing
a re!
⚠CAUTION! For multiple bulbs connected to one Dimmer 2, all
bulbs need to be equal in power load and technology!
Specication
• Power supply - 110-240V ±10% 50/60Hz AC
• Operational current - 0.1 - 1.1A
• Device temperature protection - 105°C
• Complies with EU standards - RE Directive 2014/53/EU, LVD
2014/35/EU, EMC 2004/108/WE, RoHS2 2011/65/UE
• Working temperature - from 0°C to 35°C
• Radio signal power - 1mW
• Radio protocol - WiFi 802.11 b/g/n
• Frequency - 2400 – 2483.5 MHz
• Operational range (depending on local construction) - up to 50 m
outdoors, up to 30 m indoors
• Dimensions (HxWxL) - 42 x 36 x 14 mm
• Electrical consumption - < 1,5 W
• Supported light types - Incandescent and halogen light sources
1-220W, Dimmable LED 50-200VA/1W – 200W, Resistive-inductive
loads ferromagnetic transformers 50-150VA
Technical Information
• Control through WiFi from a mobile phone, PC, automation sys-
tem or any other Device supporting HTTP and/or UDP protocol.
• Microprocessor management.
• Shelly may be controlled by an external button/switch.
⚠CAUTION! Danger of electrocution. Mounting the Device to the
power grid has to be performed with caution.
⚠ CAUTION! Do not allow children to play with the button/switch
connected the Device. Keep the Devices for remote control of Shelly
(mobile phones, tablets, PCs) away from children.
Introduction to Shelly
Shelly® is a family of innovative Devices, which allow remote
control of electric appli-ances through mobile phone, PC or home
automation system. Shelly® uses WiFi to connect to the devices
controlling it. They can be in the same WiFi network or they can
use remote access (through the Internet). Shelly® may work stand-
alone, without being managed by a home automation controller,
in the local WiFi network, as well as through a cloud service, from
everywhere the User has Internet access.
Shelly® has an integrated web server, through which the User
may adjust, control and monitor the Device. Shelly® has two WiFi
modes - access Point (AP) and Client mode (CM). To operate in
Client Mode, a WiFi router must be located within the range of the
Device. Shelly® devices can communicate directly with other WiFi
devices through HTTP protocol.
An API can be provided by the Manufacturer. Shelly® devices may
be available for monitor and control even if the User is outside the
range of the local WiFi network, as long as the WiFi router is con-
nected to the Internet. The cloud function could be used, which is
activated through the web server of the Device or through the set-
tings in the Shelly Cloud mobile application.
The User can register and access Shelly Cloud, using either Android
or iOS mobile applications, or any internet browser and the web
site: https://my.Shelly.cloud/.
Installation Instructions
⚠CAUTION! Danger of electrocution. The mounting/installation of
the Device should be done by a qualied person (electrician).
⚠CAUTION! Do not connect the Device to appliances exceeding the
given max load!
⚠CAUTION! Connect the Device only in the way shown in these
instructions. Any other method could cause damage and/or injury.
⚠CAUTION! Before beginning the installation please read the ac-
companying documentation carefully and completely. Failure to fol-
low recommended procedures could lead to malfunction, danger to
your life or violation of the law. Allterco Robotics is not responsible
for any loss or damage in case of incorrect installation or operation
of this Device.
⚠CAUTION! Use the Device only with power grid and appliances
which comply with all applicable regulations. Short Circuit in the
power grid or any appliance connected to the Device may damage
the Device.
⚠RECOMMENDATION! Тhe Device may be connected to and may
control electric circuits and appliances only if they comply with the
respective standards and safety norms.
⚠RECOMMENDATION! The Device may be connected to and may
control electric circuits and light sockets only if they comply with the
respective standards and safety norms.
⚠CAUTION! If the Device is not connected to the supported light
types, the dimming functionality may not be present. However, you
will still be able to turn on and off your lights.
Declaration of conformity
Hereby, Allterco Robotics EOOD declares that the radio equipment
type Shelly Dimmer 2 is in compliance with Directive 2014/53/
EU, 2014/35/EU, 2004/108/WE, 2011/65/UE. The full text of the
EU declaration of conformity is available at the following internet
address:
https://shelly.cloud/declaration-of-conformity/
Manufacturer: Allterco Robotics EOOD
Address: Soa, 1407, 103 Cherni vrah Blvd.
Tel.: [phone]
E-mail: [e-mail]
Web: http://www.shelly.cloud
Changes in the contact data are published by the Manufacturer at
the ocial website of the Device http://www.shelly.cloud
The User is obliged to stay informed for any amendments of these
warranty terms before exercising his/her rights against the Man-
ufacturer.
All rights to trademarks She® and Shelly® , and other intellectu-
al rights associated with this Device belong to Allterco Robotics
EOOD.

INITIAL INCLUSION
Before installing/mounting the Device ensure that the grid is
powered off (turned down breakers).
Connect the Device to the power grid and install it in the con-
sole behind the switch/power socket following the scheme
that suites the desired purpose.
• Connecting to a standard power grid with neutral – g. 1
• Connecting to a power grid without neutral, with a minimal
consumption of 10W – g. 2
• Connecting to a standard power grid with neutral, and
switches also connected to neutral – g. 3
• Connecting to a power grid without neutral, with no mini-
mal consumption and using Shelly Bypass – g. 4
You may choose if you want to use Shelly with the Shelly
Cloud mobile application and Shelly Cloud service. You can
also familiarize yourself with the instructions for Manage-
ment and Control through the embedded Web interface.
CONTROL YOUR HOME WITH YOUR VOICE
All Shelly devices are compatible with Amazon Echo and
Google Home. Please see our step-by-step guide on:
https://shelly.cloud/compatibility/Alexa
https://shelly.cloud/compatibility/Assistant
SHELLY APPLICATION
Shelly Cloud gives you opportunity to control and adjust all
Shelly® Devices from anywhere in the world. You only need
an internet connection and our mobile application, installed
on your smartphone or tablet.
Registration
The rst time you load the Shelly Cloud mobile app, you have
to create an account which can manage all your Shelly® de-
vices.
Forgotten Password
In case you forget or lose your password, just enter the e-mail
address you have used in your registration. You will then re-
ceive instructions to change your password.
⚠WARNING! Be careful when you type your e-mail address
during the registration, as it will be used in case you forget
your password.
First steps
After registering, create your rst room (or rooms), where you
are going to add and use your Shelly devices.
Shelly Cloud gives you opportunity to create scenes for auto-
matic turning on or off of the Devices at predened hours or
based on other parameters like temperature, humidity, light
etc. (with available sensor in Shelly Cloud).
Shelly Cloud allows easy control and monitoring using a mo-
bile phone, tablet or PC.
Device Inclusion
To add a new Shelly device, install it to the power grid fol-
lowing the Installation Instructions included with the Device.
Step 1
After the installation of Shelly following the Instalation In-
structions and the power is turned on, Shelly will create its
own WiFi Access Point (AP).
⚠WARNING! In case the Device has not created its own WiFi
network with SSID like shellydimmer2-35FA58 check if you
have connected Shelly correctly by the wiring schemes. If you
do not see an active WiFi network with SSID like shellydim-
mer2-35FA58, reset the Device. If the Device has been pow-
ered on, you have to power it off and on again. After turning the
power on, you have 60 seconds to press 5 consecutive times
either switch connected I1/I2. Or if you have physical access
to the Device, press and hold the reset button for 10 seconds.
Shelly should return to AP Mode. If not, please repeat or con-
tact our customer support at [email protected]
Step 2
Choose “Add Device”. In order to add more Devices later, use
the app menu at the top right corner of the main screen and
click “Add Device”. Type the name (SSID) and password for
the WiFi network, to which you want to add the Device.
Step 3
If using iOS: you will see the following screen:
Press the home button of your iPhone/iPad/iPod. Open
Settings > WiFi and connect to the WiFi network created by
Shelly, e.g. shellyswitch25-35FA58. If using Android your
phone/tablet will automatically scan and include all new
Shelly Devices in the WiFi network that you are connected to.
Upon successful Device Inclusion to the WiFi network you will
see the following pop-up:
Step 4
Approximately 30 seconds after discovery of any new Devic-
es оn the local WiFi network, а list will be displayed by default
in the “Discovered Devices” room.
Step 5
Enter Discovered Devices and choose the Device you want to
include in your account.
Step 6
Enter a name for the Device (in the Device Name eld).
Choose a Room, in which the Device has to be positioned.
You can choose an icon or add a picture to make it easier to
recognize. Press “Save Device”.
Step 7
To enable connection to the Shelly Cloud service for remote
control and monitoring of the Device, press “YES” on the fol-
lowing pop-up.
Shelly devices settings
After your Shelly device is included in the app, you can control
it, change its settings and automate the way it works.
To switch the Device on and off, use the Power button.
To enter at the details menu of the Device, click on it’s name.
From the details menu you may control the Device, as well as
edit its appearance and settings.
Timer - Тo manage the power supply automatically, you may
use:
• Auto OFF: After turning on, the power supply will automat-
ically shutdown after a predened time (in seconds). A value
of 0 will cancel the automatic shutdown.
• Auto ON: After turning off, the power supply will be auto-
matically turned on after a predened time (in seconds). A
value of 0 will cancel the automatic power-on.
Weekly Schedule - This function requires an Internet con-
nection.
To use Internet, your Shelly has to be connected to a local
WiFi network with an active internet connection. Shelly may
turn on/off automatically at a predened time, at sunrise/
sunset, or at a specied time before or after sunrise/sunset.
Multiple schedules are possible.
Internet/Security
• WiFi Mode - Client: Allows the device to connect to an avail-
able WiFi network. After typing the details in the respective
elds, press Connect.
• WiFi Client Backup: Add a backup WiFi network, in case
your primary one becomes unavailable.
• WiFi Mode - Acess Point: Congure Shelly to create a Wi-Fi
Access point. After typing the details in the respective elds,
press Create Access Point.
Cloud - Enable or Disable connection to the Cloud service.
Restrict Login - Restrict the web interface of Shely with a Us-
ername and Password. After typing the details in the elds,
press Restrict Shelly.

Settings
Power On Default Mode - This sets the default output state
when Shelly is powered.
• ON: Congure Shelly to turn ON, when it has power.
• OFF: Congure Shelly to turn OFF, when it has power.
• Restore Last Mode: Congure Shelly to return to last state
it was in, when it has power.
Firmware Update - Update the rmware of Shelly, when a new
version is released.
Button Type
• One Button mode: the device is controlled with a single
switch.
• Dual button mode: the device is controlled dual switch.
• Toggle switch one button: the device is controlled by a sin-
gle toggle switch.
• Edge switch: the device is controlled with an edge on/off.
Button Debounce - Adjust the sensitivity (time of reaction)
of the connected switch. If there are any interferences in the
power grid, this will prevent undesired status change (on/off)
of the device. The range is 60 - 200 ms.
Calibration - Shelly Dimmer needs callibration based on the
type of light that you are going to use it with. To make a cali-
bration, press Start Calibration.
Transition Time - Set the time (in miliseconds), for which
Shelly Dimmer goes from 0% to 100%. The value can be from
0 to 5000 ms.
Fade rate - Set the speed of dimming, when the switch is
pressed and held. Range: 1x - 5x
Minimum Brightness - If the connected light is not working
below a certain percentage, you can set the minimum per-
cent at which Shelly Dimmer will turn on. Once set, you can
not dim the light below the minimum. Range: 0 - 50%
Warm up - Some lights require a certain power impulse, in
order to start below 100% brightness. You can set the bright-
ness level and time at which Shelly Dimmer will turn on.
Brightness range: 10 - 100%. Time range: 20 - 200 ms
Night Mode - With this mode you can set a period of time
and level of brightness, in which any turning on will set the
brightness to the predened level.
Time Zone and Geo-location - Enable or Disable the automat-
ic detection of Time Zone and Geo-location.
Factory Reset - Return Shelly to its factory default settings.
Device Information - here you can see the device ID(Unique
ID of Shelly) and device IP(the IP of Shelly in your Wi-Fi net-
work)
THE EMBEDDED WEB INTERFACE
Еven without the mobile app, Shelly can be set and controlled
through a browser and WiFi connection of a mobile phone,
tablet or PC.
Abbreviations used
• Shelly-ID – the unique name of the Device. It consists of
6 or more characters. It may include numbers and letters, for
example 35FA58.
• SSID – the name of the WiFi network, created by the De-
vice, for example shellydimmer2-35FA58
• Access Point (AP) – the mode in which the Device cre-
ates its own WiFi connection point with the respective name
(SSID).
• Client Mode (CM) – the mode in which the Device is con-
nected to another WiFi network.
Initial inclusion
Step 1
Install Shelly to the power grid following the schemes de-
scribed above and place it into the console. After turning the
power on Shelly will create its own WiFi network (AP).
⚠WARNING! If you don’t see the WiFi please fallow the step 1
from the device inclusion section of the guide.
Step 2
When Shelly has created an own WiFi network (own AP), with
name (SSID) such as shellydimmer2-35FA58. Connect to it
with your phone, tablet or PC.
Step 3
Type 192.168.33.1 into the address eld of your browser to
load the web interface of Shelly.
GENERAL - HOME PAGE
This is the home page of the embedded web interface. If it
has been set up is correctly, you will see information about
Current state (on/off), Current brightness level, Power button
Connection to Cloud, Present time, Settings
Timer - Тo manage the power supply automatically, you may
use:
• Auto OFF: After turning on, the power supply will automat-
ically shutdown after a predened time (in seconds). A value
of 0 will cancel the automatic shutdown.
• Auto ON: After turning off, the power supply will be auto-
matically turned on after a predened time (in seconds). A
value of 0 will cancel the automatic power-on.
Weekly Schedule - This function requires an Internet connec-
tion. To use Internet, a Shelly Device has to be connected to
a local WiFi network with working internet connection. Shelly
may turn on/off automatically at a predened time, at sun-
rise/sunset, or at a specied time before or after sunrise/
sunset. Multiple schedules are possible.
Internet/Security
• WiFi Mode - Client - Allows the device to connect to an
available WiFi network. After typing the details in the elds,
press Connect.
• WiFi Client Backup - Add a backup WiFi network, in case
your primary one becomes unavailable.
• WiFi Mode - Acess Point - Congure Shelly to create a Wi-
Fi Access point. After typing the details in the elds, press
Create Access Point.
• Cloud - Enable or Disable connection to the Cloud service.
• Restrict Login - Restrict the web interface of Shely with a
Username and Password. After typing the details in the elds,
press Restrict Shelly.
• SNTP Server - You can set a custom SNTP Server. Type the
URL address and press Save.
⚠ATTENTION! If you have entered incorrect information
(wrong settings, usernames, passwords etc.), you will not be
able to connect to Shelly and you have to reset the Device.
⚠WARNING! If you don’t see the WiFi please fallow the step 1
from the device inclusion section of the guide.
Advanced - Developer Settings - Here you can change the
action execution via CoAP (CoIOT) or Via MQTT
Firmware Upgrade - Shows present rmware version. If a
newer version is available, ocially announced and published
by the Manufacturer, you can update your Shelly Device. Click
Upload to install it to your Shelly Device.
Settings
Power On Default Mode - This sets the default output state
when Shelly is powered.
• ON: Congure Shelly to turn ON, when it has power.
• OFF: Congure Shelly to turn OFF, when it has power.
Restore Last Mode - Congure Shelly to return to last state it
was in, when it has power.
SWITCH - Congure Shelly to operate accordingly to the state
of the switch (button).
Time Zone and Geo-location - Enable or Disable the automat-
ic detection of Time Zone and Geo-location.
Firmware Update - Update the rmware of Shelly, when a new
version is released.
Button Type
• One Button mode: the device is controlled with a single
switch.
• Dual button mode: the device is controlled dual switch.
• Toggle switch one button: the device is controlled by a sin-
gle toggle switch.
• Edge switch: the device is controlled with an edge on/off.
Button Debounce - Adjust the sensitivity (time of reaction)
of the connected switch. If there are any interferences in the
power grid, this will prevent undesired status change (on/off)
of the device. Range: 60 - 200 ms
Calibration - Shelly Dimmer needs callibration based on the
type of light that you are going to use it with. To make a cali-
bration, press Start Calibration.
Transition Time - Set the time (in miliseconds), for which
Shelly Dimmer goes from 0% to 100%. The value can be from
0 to 5000 ms.
Fade Rate - Set the speed of dimming, when the switch is
pressed and held. Range: 1x - 5x
Minimum Brightness - If the connected light is not working
below a certain percentage, you can set the minimum per-
cent at which Shelly Dimmer will turn on. Once set, you can
not dim the light below the minimum. Range: 0 - 50%
Warm up - Some lights require a certain power impulse, in
order to start below 100% brightness. You can set the bright-
ness level and time at which Shelly Dimmer will turn on.
Brightness range: 10 - 100%. Time range: 20 - 200 ms
Night Mode - With this mode you can set a period of time
and level of brightness, in which any turning on will set the
brightness to the predened level.
Factory Reset - Return Shelly to its factory default settings.
Device Reboot - Reboots the device.
Device Information - Here you can see the unique ID of Shelly.
Additional Features - Shelly allows control via HTTP from
any other device, home automation controller, mobile app
or server.
For more information about the REST control protocol, please
visit: https://shelly.cloud/developers/ or send a request to:
[e-mail]
