SERVICE MANUAL
CAUTION : Before servicing this chassis, read the "PRODUCT SAFETY SERVICE FOR VIDEO PRODUCTS" section
on page 2 of this manual.
CONTENTS
SERVICE PRECAUTIONS......................................................2,3
BLOCK DIAGRAMS...................................................................4
TROUBLE SHOOTING...........................................................5,8
BOARD DIAGRAM...............................................................9,10
DVD and CD
PLAYER
MODEL
SDP1720A
REPLACEMENT PARTS LIST............................................11,21

Whenthepowersupplyisbeingturnedon,youmaynotremovethislasercautionslabel.Ifitremoves,radiationoflaser
maybereceived.
LASERBEAMCAUTIONLABEL
PREPARATIONOFSERVICING
PickupHeadconsistsofalaserdiodethatisverysusceptibletoexternalstaticelectrocity.
Althoughitoperatesproperlyafterreplacement,ifitwassubjecttoelectrostaticdischargeduringreplacement,
itslifemightbeshortened.Whenreplacing,useaconductivemat,solderingironwithgroundwire,etc.to
protectthelaserdiodeformdamagebystaticelectricity.
Andalso,theLSIandICaresameasabove.
Solderingiron
withgroundwire
orceramictype
Groundconductive
wriststrapforbody.
Conductivemat
Thegroundresistance
betweenthegroundline
andthegroundislessthan10
1M

SAFTY NOTICE
Plug the AC line cord directly into a 120V AC outlet (do
not use an isolation transformer for this check). Use an
AC voltmeter, having 5000 per volt or more sensitivity.
Connect a 1500 10W resistor,paralleled by a 0.15uF
150V AC capacitor between a knomn good earth ground
(water pipe, conduit, etc.) and all exposed metal parts of
cabinet (antennas, handle bracket, metal cabinet
screwheads, metal overlays, control shafts, etc.).
SAFTY PRECAUTIONS
LEAKAGE CURRENT CHECK
Measure the AC voltage across the 1500 resistor.
The test must be conducted with the AC switch on and
then repeated with the AC switch off. The AC voltage
indicated by the meter may not exceed 0.3V.A reading
exceeding 0.3V indicates that a dangerous potential
exists, the fault must be located and corrected.
Repeat the above test with the DVD VIDEO PLAYER
power plug reversed.
NEVER RETURN A DVD VIDEO PLAYER TO THE
CUSTOMER WITHOUT TAKING NECESSARY
CORRECTIVE ACTION.
READING SHOULD NOT EXCEED 0.3V
DVD VIDEO PLAYER
AC OUTLET
AC VOLTMETER
Test all exposed metal.
Voltmeter Hook-up for Leakage Current Check
0.15uF 150V AC
1500
10W
(5000 per volt
or more sensitivity)
Good earth ground
such as a water pipe,
conduit, etc.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.

RF AMP & SERVO & DVD PROCESSOR
MPEG-2 DECODER & VIDEO ENCODER
D3800
OVERALL BLOCK DIAGRAM
AC
Adapter
DC IN +9V
DC / DC
(BQ2057C) (TPC8207) (VG202C)
110~240V
50/60Hz
BATTERY
DV23
PU mechanism
DRIVER
(BA5954FP)
8M FlashROM
MX29LV008TTC-70
64M SDRAM
NT56V6620C0T-75S
TC4W53 27MHz
AUDIO D/A
(PCM1742)
UPD5100 TFT MONITOR
AUDIO AMP
(NJM4558)
PHONE AMP
(NJM4580)
SPEAKER AMP
(D2822)
HIGH VOLTAGE ASS'Y
74HCU04
27MHz
VIDEO OUT
AUDIO OUT
PHONE OUT
SPEAKER LOUT
SPEAKER ROUT
L
R
L
R
RL
DRIVER +5V
+5V
AUDIO +/-5V
+3.3V
AUDIO +5V
TFT POWER
+3.3V +5V -14.5V +16V
COAXIAL OUT
DC 9V
DC 9V
R1224 IRF7304
PQ05DZ11
BA033
TPS5100
TFT VDD
16V
-14.5V
5V
MPEG3.3V
MPEG1.8V
G1117-1.8
PQ1R33 3.3V
OSCILLATOR
OZ960
+1.8V

1. Troubleshooting
1. No power when turned on.
2. The initial screen is not displayed on the LCD.
3. The DVD drive does not work.
4. The operation of the DVD player stops at initializing display.
5. Image output stops during the operation.
6. No sound or abnormal sound comes out form the speakers in the DVD player.
7. No image or sound comes out form the external output.
8. No sound comes out form the headphones.
9. No image or sound is output by external input.
10. The DVD drive does not operate with the battery.
1.1 No power when turned on.
When the power is turned on, and if the LED on the front panel does not light green, check
the following items and repair the defective parts.
(1) Check the power supply cable
If the cable is not the supplied one, replace it with the supplied cable and turn on the
power again.
If the power supply cable is good, the AC adapter may be defective.
If the LED does not light after replacing, check the following items.
(2) Check the AC adapter
If the AC adapter is not the supplied one, replace it with the supplied AC adapter and
turn on the power.
If the AC adapter is good, the power supply boards may be defective.
If the LED does not light after replacing, check the following items.
(3) Check the Power and Play buttons
Press the POWER button or the PLAY button on the DVD player. If the power does
not turn on, check the following:
zCheck the connector of the switch unit in the DVD player.
(If the connection is loose, repair the connection.)
zReplace the switch unit and turn on the power again.
If the LED does not light after replacing, check the following items.
(4) Replace the main board

1.2 The initial screen is not displayed on the LCD.
If the initial screen is not displayed on the LCD, check the following items.
(1) Check the LED on the front
If the LED does not light, proceed to 1.1.
(2) Check the backlight
If the backlight does not light up, separate. The DVD player into top assembly and
bottom assembly, and check the connector harness, and check the connectors for
defects.
If the connector harness is broken:
Replace the broken harness.
If the connector harness is not broken:
Remove the LCD cover and plate of the LCD unit and check the following:
zCheck the connector of the FL harness, repair connectors.
zIf the connectors are good, replace the FL inverter or the LCD.
(3) Check the lighting of LCD
If the LCD does not light, separate the DVD player into the top assembly and bottom
assembly, and check the LCD harness, and check the connectors on the main board.
If the connector is broken:
Replace the LCD harness or the main board.
If the connector is not broken:
Remove the LCD cover and plate of the LCD unit, and check the connection to the
harness of the LCD unit.
zIf a bad connection is found.
Connect the LCD harness to the LCD unit.
zOther than the above
Replace the LCD unit or the main board.

1.3 The DVD drive does not work.
When the DVD drive does not work after the power is turned on, check the following items
and repair or replace the defective parts.
(1) Press the DISC cover switch at the center of the DVD player and turn on the
power. Then check whether or not the optical pick-up lens of the DVD drive
lights.
CAUTION: Visible laser radiation when open and interlock defeated. Do not stare into
Laser beam.
The optical pick-up lens lights dim:
It is caused by deterioration of the optical pick-up lens. Replace the DVD drive.
The optical pick-up lens does not light:
Check the connectors of the DVD-FFC. Also check the connection to the main
board and to the DVD drive.
zLoose connection is found.
Repair the connection, and then check the operation of the DVD drive again.
zThe DVD-FFC is broken.
Replace the DVD-FFC.
zOther than the above.
Replace the DVD drive or the main board.
(2) Insert a DVD disk and turn on the power
The DVD drive does not work:
The motor of the DVD drive or the main board is defective. Replace the DVD drive
or the main board.
The DVD drive works but the initializing operation of the optical pick-up lens
does not start (the optical pick-up lens operates twice), or abnormal noise
sound:
The DVD drive is defective. Replace the DVD drive.
1.4 The operation of the DVD player stops at initializing display.
If the DVD player does not work after the initializing screen is displayed, check the
indication on the screen. Then repair the defect according to it.
(1) Insert a DVD disk and close the DISC cover, and turn on the power. Then check
the LCD screen or use an external display.
zThe message “loading” is not displayed or the operation stops at the
message “Loading”.
Since the DVD drive or the main board is defective, check in the following order:
1) DVD drive
2) Main board
zThe message “CHECK DISK” is displayed.
Check the DVD disk for fingerprints, dirt, etc.
If the DVD disk is OK, then check the following items:
1) Check the DVD-FFC
If a loose connection, repair the connection.
If it is damaged, replace it with new one.
2) Other than above
For other cases, replace the unit in the following order:
zDVD drive (defective optical pick-up)
zMain board

1.5 Image output stops during the operation.
If the image output form the media in the DVD player stops during the operation, replace
the DVD drive.
1.6 No sound or abnormal sound comes out from the speakers in the DVD player.
If no sound comes out form the speakers in the DVD player, check the following:
(1) Check for moving images on the LCD screen
Check whether or not the move of image stops in halfway. If it stops, replace the DVD
drive.
(2) Check the operation of the DVD driver.
Check whether or not the DVD drive works. If it stops, replace the DVD drive.
(3) Check the connection of the speakers in the LCD unit.
Separate the DVD player into the top assembly and bottom assembly, and then check
the connection of the speaker harnesses to the main board. If a bad connection, repair
the connection.
Other than the above, disassemble the LCD unit and replace the speakers or the main
board.
1.7 No image or sound comes out form the external output
If any image or sound is output form the TV connected by the external cable, replace the
main board or the connector.
NOTE: Before this test, make sure the drive works.
1.8 No sound comes out form the headphones.
If no sound comes out form the headphones, replace the main board or the connector.
1.9 No image or sound is output by the external input.
If any image or sound is output by external input, replace the main board or the connector.
1.10 The DVD drive does not operate with the battery.
(1) Check the operation with a good battery.
Install a good battery and make sure the LED lights up orange while the AC adapter is
connected. When the LED does not light up or blinks, check the connection of the
battery harness inside the DVD player. If the connection is loose, repair connection. If
the harness has been connected firmly, replace the main board.
(2) Other than the above, replace the battery.
NOTE:
zFor this check, use a battery which is not fully charged (because the LED does
not light when the battery is fully charged.)
zBefore this check, make sure other function work correctly.

DVD1730A(H3) MAIN PCB BOARD DIAGRAM

DVD1710AT-AS(LG) IF PCB BOARD DIAGRAM
DVD1731H-L HV PCB BOARD DIAGRAM

PART No. PART NAME Q'TY
11078c RB-LI20LITHIUM BATTERY 1
21328 DVD1731H-L HV PCB ASS'Y 1
21489 DVD1720A FUNCTION PCB ASS'Y 1
21443 DVD1720A MAIN PCB ASS'Y 1
21391 DVD1710AT-AS(LG) IF PCB ASS'Y 1
S8115 DV23 LOADING ASS'Y 1
S0578e ADPV18A AC POWER ADAPTER 1
S5006 SPEAKER 2
S4353 TS-043 EARPHONE 1
S4522a OWNER MANUAL 1
S06024 DVP700 REMOTE 1
S3421a 20 PIN HARNESS (LE105) 1
S3421c 20 PIN HARNESS (LE140) 1
a7187b LB070W02-A5\C5K1\C12E\D11C TFT LCD 1
S0535 CAR CIGARETTE ADAPTER 1
S3589 SPEAKER CONNECT WIRE 2
S3590 TFT EARTHING WIRE 1
S3545 HV POWER CONNECT WIRE 1
S3747 RCA CORD AV 1
S2839 LGK-G1628-161D 1
ELECTRICAL PARTS LIST
SDP1720A

REF No. PART No. PART NAME REF No. PART No. PART NAME
R52 P11004 Resistor chip 33
Ω
R53 P11004 Resistor chip 33
Ω
R1 P11013 Resistor chip 10K
Ω
R54 P11004 Resistor chip 33
Ω
R2 P11057 Resistor chip 51K
Ω
R55 P11012 Resistor chip 4.7K
Ω
R3 P11018 Resistor chip 47K
Ω
R56 P11012 Resistor chip 4.7K
Ω
R4 P11013 Resistor chip 10K
Ω
R57 P11023 Resistor chip 1M
Ω
R5 P11009 Resistor chip 1K
Ω
R58 P11006 Resistor chip 100
Ω
R6 P11207 Resistor chip 0.5
Ω
R59 P11013 Resistor chip 10K
Ω
R8 P11051 Resistor chip 1.5K
Ω
R60 P11013 Resistor chip 10K
Ω
R9 P11003 Resistor chip 10
Ω
R61 P11013 Resistor chip 10K
Ω
R01 P11013 Resistor chip 10K
Ω
R62 P11004 Resistor chip 33
Ω
R10 P11003 Resistor chip 10
Ω
R63 P11004 Resistor chip 33
Ω
R11 P11000 Resistor chip 0
Ω
R64 P11050 Resistor chip 560
Ω
R12 P11000 Resistor chip 0
Ω
R65 P11004 Resistor chip 33
Ω
R13 P11003 Resistor chip 10
Ω
R66 P11019 Resistor chip 100K
Ω
R14 P11028 Resistor chip 1.8K
Ω
R67 P11061 Resistor chip 680K
Ω
R15 P11005 Resistor chip 75
Ω
R68 P11000 Resistor chip 0
Ω
R17 P11067 Resistor chip 200
Ω
R69 P11000 Resistor chip 0
Ω
R19 P11004 Resistor chip 33
Ω
R71 P11013 Resistor chip 10K
Ω
R20 P11004 Resistor chip 33
Ω
R79 P11000 Resistor chip 0
Ω
R21 P11063 Resistor chip 1
Ω
R86 P11000 Resistor chip 0
Ω
R22 P11000 Resistor chip 0
Ω
R90 P11013 Resistor chip 10K
Ω
R23 P11003 Resistor chip 10
Ω
R92 P11004 Resistor chip 33
Ω
R24 P11006 Resistor chip 100
Ω
R93 P11122 Resistor chip 750K
Ω
R25 P11000 Resistor chip 0
Ω
R94 P11000 Resistor chip 0
Ω
R26 P11020 Resistor chip 150K
Ω
R98 P11002 Resistor chip 4.7
Ω
R30 P11004 Resistor chip 33
Ω
R99 P11002 Resistor chip 4.7
Ω
R36 P11013 Resistor chip 10K
Ω
R000 P11254 SL1TE100MF
R37 P11038 Resistor chip 39K
Ω
R002 P11009 Resistor chip 1K
Ω
R38 P11015 Resistor chip 15K
Ω
R006 P11012 Resistor chip 4.7K
Ω
R39 P11035 Resistor chip 20K
Ω
R007 P11009 Resistor chip 1K
Ω
R40 P11034 Resistor chip 18K
Ω
R008 P11014 Resistor chip 12K
Ω
R41 P11015 Resistor chip 15K
Ω
R009 P11003 Resistor chip 10
Ω
R43 P11207 Resistor chip 0.5
Ω
R010 P11013 Resistor chip 10K
Ω
R45 P11004 Resistor chip 33
Ω
R011 P11009 Resistor chip 1K
Ω
R47 P11035 Resistor chip 20K
Ω
R012 P11003 Resistor chip 10
Ω
R48 P11035 Resistor chip 20K
Ω
R013 P11014 Resistor chip 12K
Ω
R49 P11013 Resistor chip 10K
Ω
R014 P11030 Resistor chip 2.7K
Ω
R50 P11207 Resistor chip 0.5
Ω
R015 P11034 Resistor chip 18K
Ω
R51 P11000 Resistor chip 0
Ω
R016 P11018 Resistor chip 47K
Ω
DVD1720A MAIN PCB ASS'Y
RESISTOR

REF No. PART No. PART NAME REF No. PART No. PART NAME
R018 P11030 Resistor chip 2.7K
Ω
R207 P11013 Resistor chip 10K
Ω
R019 P11011 Resistor chip 3.3K
Ω
R208 P11023 Resistor chip 1M
Ω
R020 P11034 Resistor chip 18K
Ω
R209 P11017 Resistor chip 33K
Ω
R029 P11009 Resistor chip 1K
Ω
R210 P11013 Resistor chip 10K
Ω
R030 P11042 Resistor chip 120K
Ω
R211 P11013 Resistor chip 10K
Ω
R031 P11019 Resistor chip 100K
Ω
R212 P11013 Resistor chip 10K
Ω
R032 P11009 Resistor chip 1K
Ω
R213 P11013 Resistor chip 10K
Ω
R033 P11013 Resistor chip 10K
Ω
R214 P11013 Resistor chip 10K
Ω
R034 P11041 Resistor chip 82K
Ω
R216 P11032 Resistor chip 5.1K
Ω
R035 P11039 Resistor chip 56K
Ω
R218 P11000 Resistor chip 0
Ω
R036 P11039 Resistor chip 56K
Ω
R219 P11006 Resistor chip 100
Ω
R051 P11028 Resistor chip 1.8K
Ω
R220 P11006 Resistor chip 100
Ω
R080 P11012 Resistor chip 4.7K
Ω
R224 P11017 Resistor chip 33K
Ω
R081 P11003 Resistor chip 10
Ω
R225 P11072 Resistor chip 300
Ω
R088 P11018 Resistor chip 47K
Ω
R226 P11072 Resistor chip 300
Ω
R092 P11018 Resistor chip 47K
Ω
R227 P11072 Resistor chip 300
Ω
R106 P11003 Resistor chip 10
Ω
R229 P11000 Resistor chip 0
Ω
R118 P11009 Resistor chip 1K
Ω
R230 P11000 Resistor chip 0
Ω
R122 P11000 Resistor chip 0
Ω
R231 P11000 Resistor chip 0
Ω
R123 P11000 Resistor chip 0
Ω
R233 P11008 Resistor chip 470
Ω
R129 P11020 Resistor chip 150K
Ω
R234 P11006 Resistor chip 100
Ω
R132 P11061 Resistor chip 680K
Ω
R235 P11006 Resistor chip 100
Ω
R138 P11003 Resistor chip 10
Ω
R236 P11010 Resistor chip 2K
Ω
R139 P11040 Resistor chip 68K
Ω
R237 P11010 Resistor chip 2K
Ω
R140 P11040 Resistor chip 68K
Ω
R238 P11005 Resistor chip 75
Ω
R149 P11061 Resistor chip 680K
Ω
R239 P11005 Resistor chip 75
Ω
R150 P11035 Resistor chip 20K
Ω
R241 P11024 Resistor chip 330
Ω
R151 P11013 Resistor chip 10K
Ω
R242 P11006 Resistor chip 100
Ω
R181 P11000 Resistor chip 0
Ω
R312 P11004 Resistor chip 33
Ω
R183 P11000 Resistor chip 0
Ω
R407 P11013 Resistor chip 10K
Ω
R189 P11040 Resistor chip 68K
Ω
R444 P11013 Resistor chip 10K
Ω
R190 P11040 Resistor chip 68K
Ω
R454 P11013 Resistor chip 10K
Ω
R191 P11142 Resistor chip 6.2K
Ω
R501 P11018 Resistor chip 47K
Ω
R192 P11044 Resistor chip 220K
Ω
R502 P11018 Resistor chip 47K
Ω
R193 P11054 Resistor chip 7.5K
Ω
R507 P11042 Resistor chip 120K
Ω
R194 P11044 Resistor chip 220K
Ω
R508 P11042 Resistor chip 120K
Ω
R195 P11034 Resistor chip 18K
Ω
R509 P11013 Resistor chip 10K
Ω
R196 P11019 Resistor chip 100K
Ω
R510 P11013 Resistor chip 10K
Ω
R197 P11035 Resistor chip 20K
Ω
R511 P11002 Resistor chip 4.7
Ω
R198 P11000 Resistor chip 0
Ω
R512 P11002 Resistor chip 4.7
Ω

REF No. PART No. PART NAME REF No. PART No. PART NAME
R513 P11032 Resistor chip 5.1K
Ω
RN6 P1006 Row of resistor 100
Ω
R514 P11031 Resistor chip 3.9K
Ω
RN7 P1078 Row of resistor 10K
Ω
R515 P11013 Resistor chip 10K
Ω
RN8 P1006 Row of resistor 100
Ω
R516 P11019 Resistor chip 100K
Ω
RN9 P1006 Row of resistor 100
Ω
R517 P11013 Resistor chip 10K
Ω
R518 P11006 Resistor chip 100
Ω
C1 P31100 Ceramic CAP 10uF/16V
R519 P11032 Resistor chip 5.1K
Ω
C2 P20015 Capacitor chip 0.1uF
R520 P11013 Resistor chip 10K
Ω
C3 P31100 Ceramic CAP 10uF/16V
R521 P11031 Resistor chip 3.9K
Ω
C4 P31100 Ceramic CAP 10uF/16V
R522 P11019 Resistor chip 100K
Ω
C5 P30003 Electrolytic CAP 100uF/6V
R523 P11013 Resistor chip 10K
Ω
C6 P30002 Electrolytic CAP 47uF/6V
R526 P11009 Resistor chip 1K
Ω
C8 P31100 Ceramic CAP 10uF/16V
R527 P11009 Resistor chip 1K
Ω
C02 P20015 Capacitor chip 0.1uF
R529 P11006 Resistor chip 100
Ω
C10 P31100 Ceramic CAP 10uF/16V
R530 P11006 Resistor chip 100
Ω
C12 P30003 Electrolytic CAP 100uF/6V
R535 P11034 Resistor chip 18K
Ω
C15 P30002 Electrolytic CAP 47uF/6V
R540 P11013 Resistor chip 10K
Ω
C18 P20015 Capacitor chip 0.1uF
R541 P11013 Resistor chip 10K
Ω
C21 P30014 Electrolytic CAP 100uF/16V
R542 P11013 Resistor chip 10K
Ω
C26 P31100 Ceramic CAP 10uF/16V
R543 P11019 Resistor chip 100K
Ω
C27 P31100 Ceramic CAP 10uF/16V
R544 P11055 Resistor chip 8.2K
Ω
C28 P20015 Capacitor chip 0.1uF
R545 P11019 Resistor chip 100K
Ω
C30 P31100 Ceramic CAP 10uF/16V
R546 P11013 Resistor chip 10K
Ω
C31 P31100 Ceramic CAP 10uF/16V
R547 P11055 Resistor chip 8.2K
Ω
C32 P31100 Ceramic CAP 10uF/16V
R548 P11002 Resistor chip 4.7
Ω
C33 P30003 Electrolytic CAP 100uF/6V
R556 P11009 Resistor chip 1K
Ω
C34 P31100 Ceramic CAP 10uF/16V
R557 P11009 Resistor chip 1K
Ω
C35 P31100 Ceramic CAP 10uF/16V
R558 P11013 Resistor chip 10K
Ω
C37 P31100 Ceramic CAP 10uF/16V
R559 P11012 Resistor chip 4.7K
Ω
C39 P20052 Capacitor chip 20pF
R560 P11012 Resistor chip 4.7K
Ω
C41 P31100 Ceramic CAP 10uF/16V
R567 P11000 Resistor chip 0
Ω
C42 P31002 Electrolytic CAP 10uF/16V(Ta)
R568 P11019 Resistor chip 100K
Ω
C43 P31100 Ceramic CAP 10uF/16V
R570 P11004 Resistor chip 33
Ω
C44 P20035 Capacitor chip 1uF
R587 P11009 Resistor chip 1K
Ω
C46 P20035 Capacitor chip 1uF
R593 P11002 Resistor chip 4.7
Ω
C47 P20035 Capacitor chip 1uF
R594 P11002 Resistor chip 4.7
Ω
C49 P20029 Capacitor chip 330pF
C45 P11000 Resistor chip 0
Ω
C50 P20042 Capacitor chip 2200pF
L14 P11004 Resistor chip 33
Ω
C51 P20034j Capacitor chip 390pF
RN4 P1006 Row of resistor 100
Ω
C52 P31100 Ceramic CAP 10uF/16V
RN5 P11206 Row of resistor 22
Ω
C53 P20027 Capacitor chip 150pF
CAPACITOR

REF No. PART No. PART NAME REF No. PART No. PART NAME
C54 P20027 Capacitor chip 150pF C021 P30014 Electrolytic CAP 100uF/16V
C55 P20042 Capacitor chip 2200pF C023 P20015 Capacitor chip 0.1uF
C57 P20010 Capacitor chip 1500pF C024 P20015 Capacitor chip 0.1uF
C58 P20015 Capacitor chip 0.1uF C031 P20015 Capacitor chip 0.1uF
C59 P31100 Ceramic CAP 10uF/16V C032 P20009 Capacitor chip 1000pF
C60 P31100 Ceramic CAP 10uF/16V C034 P20015 Capacitor chip 0.1uF
C61 P20051 Capacitor chip 5.1pF C046 P20035 Capacitor chip 1uF
C62 P20002 Capacitor chip 22pF C047 P31100 Ceramic CAP 10uF/16V
C63 P20009 Capacitor chip 1000pF C049 P30003 Electrolytic CAP 100uF/6V
C64 P31100 Ceramic CAP 10uF/16V C050 P31100 Ceramic CAP 10uF/16V
C65 P31100 Ceramic CAP 10uF/16V C051 P20015 Capacitor chip 0.1uF
C67 P30014 Electrolytic CAP 100uF/16V C052 P31100 Ceramic CAP 10uF/16V
C68 P31100 Ceramic CAP 10uF/16V C077 P30014 Electrolytic CAP 100uF/16V
C69 P31100 Ceramic CAP 10uF/16V C085 P30014 Electrolytic CAP 100uF/16V
C70 P31100 Ceramic CAP 10uF/16V C088 P20015 Capacitor chip 0.1uF
C71 P31100 Ceramic CAP 10uF/16V C091 P31100 Ceramic CAP 10uF/16V
C74 P31100 Ceramic CAP 10uF/16V C099 P20015 Capacitor chip 0.1uF
C75 P20051 Capacitor chip 5.1pF C100 P20015 Capacitor chip 0.1uF
C91 P31100 Ceramic CAP 10uF/16V C101 P20015 Capacitor chip 0.1uF
C93 P31100 Ceramic CAP 10uF/16V C102 P20049 Capacitor chip 33000pF
C95 P31100 Ceramic CAP 10uF/16V C103 P20015 Capacitor chip 0.1uF
C96 P31100 Ceramic CAP 10uF/16V C104 P20015 Capacitor chip 0.1uF
C97 P20059 Capacitor chip 4700pF C105 P20015 Capacitor chip 0.1uF
C98 P20015 Capacitor chip 0.1uF C106 P20035 Capacitor chip 1uF
C99 P20009 Capacitor chip 1000pF C107 P20015 Capacitor chip 0.1uF
C001 P20015 Capacitor chip 0.1uF C108 P20035 Capacitor chip 1uF
C002 P30014 Electrolytic CAP 100uF/16V C109 P20014 Capacitor chip 47000pF
C003 P30014 Electrolytic CAP 100uF/16V C110 P20014 Capacitor chip 47000pF
C004 P20035 Capacitor chip 1uF C111 P20017 Capacitor chip 0.47uF
C005 P20015 Capacitor chip 0.1uF C112 P31100 Ceramic CAP 10uF/16V
C007 P30003 Electrolytic CAP 100uF/6V C113 P31100 Ceramic CAP 10uF/16V
C008 P20015 Capacitor chip 0.1uF C114 P31100 Ceramic CAP 10uF/16V
C010 P20015 Capacitor chip 0.1uF C116 P31100 Ceramic CAP 10uF/16V
C012 P20009 Capacitor chip 1000pF C117 P20006 Capacitor chip 100pF
C015 P20035 Capacitor chip 1uF C118 P31100 Ceramic CAP 10uF/16V
C016 P20015 Capacitor chip 0.1uF C119 P31100 Ceramic CAP 10uF/16V
C018 P20009 Capacitor chip 1000pF C125 P31100 Ceramic CAP 10uF/16V
C019 P20015 Capacitor chip 0.1uF C126 P31100 Ceramic CAP 10uF/16V
C020 P30014 Electrolytic CAP 100uF/16V C130 P20015 Capacitor chip 0.1uF

REF No. PART No. PART NAME REF No. PART No. PART NAME
C151 P20015 Capacitor chip 0.1uF C194 P20052 Capacitor chip 20pF
C153 P20015 Capacitor chip 0.1uF C195 P20015 Capacitor chip 0.1uF
C154 P20015 Capacitor chip 0.1uF C196 P20017 Capacitor chip 0.47uF
C155 P20016 Capacitor chip 0.33uF C197 P20052 Capacitor chip 20pF
C156 P20016 Capacitor chip 0.33uF C198 P20015 Capacitor chip 0.1uF
C157 P20027 Capacitor chip 150pF C199 P20034j Capacitor chip 390pF
C158 P20015 Capacitor chip 0.1uF C202 P31100 Ceramic CAP 10uF/16V
C159 P20015 Capacitor chip 0.1uF C203 P31100 Ceramic CAP 10uF/16V
C160 P20015 Capacitor chip 0.1uF C204 P31100 Ceramic CAP 10uF/16V
C161 P20015 Capacitor chip 0.1uF C205 P31100 Ceramic CAP 10uF/16V
C162 P20015 Capacitor chip 0.1uF C206 P31100 Ceramic CAP 10uF/16V
C164 P20015 Capacitor chip 0.1uF C207 P31002 Electrolytic CAP 10uF/16V(Ta)
C165 P20015 Capacitor chip 0.1uF C208 P20015 Capacitor chip 0.1uF
C166 P20015 Capacitor chip 0.1uF C416 P31100 Ceramic CAP 10uF/16V
C167 P20015 Capacitor chip 0.1uF C457 P20061 Capacitor chip 0.015uF
C168 P20015 Capacitor chip 0.1uF C491 P20057a Adjustable capacitor
C169 P20015 Capacitor chip 0.1uF C504 P31100 Ceramic CAP 10uF/16V
C171 P20015 Capacitor chip 0.1uF C508 P30006 Electrolytic CAP 47uF/4V
C172 P20015 Capacitor chip 0.1uF C509 P30006 Electrolytic CAP 47uF/4V
C173 P20015 Capacitor chip 0.1uF C510 P30002 Electrolytic CAP 47uF/6V
C174 P20052 Capacitor chip 20pF C512 P31002 Electrolytic CAP 10uF/16V(Ta)
C175 P20015 Capacitor chip 0.1uF C513 P31002 Electrolytic CAP 10uF/16V(Ta)
C176 P20015 Capacitor chip 0.1uF C514 P31002 Electrolytic CAP 10uF/16V(Ta)
C177 P20015 Capacitor chip 0.1uF C515 P31002 Electrolytic CAP 10uF/16V(Ta)
C178 P20006 Capacitor chip 100pF C516 P20030 Capacitor chip 2700pF
C179 P31100 Ceramic CAP 10uF/16V C517 P20030 Capacitor chip 2700pF
C180 P31100 Ceramic CAP 10uF/16V C518 P20048 Capacitor chip 300pF
C181 P31100 Ceramic CAP 10uF/16V C519 P20048 Capacitor chip 300pF
C182 P20017 Capacitor chip 0.47uF C523 P20015 Capacitor chip 0.1uF
C184 P20034j Capacitor chip 390pF C528 P20015 Capacitor chip 0.1uF
C185 P31100 Ceramic CAP 10uF/16V C529 P20015 Capacitor chip 0.1uF
C186 P20053 Capacitor chip 68pF C530 P20015 Capacitor chip 0.1uF
C187 P20015 Capacitor chip 0.1uF C531 P31100 Ceramic CAP 10uF/16V
C188 P20015 Capacitor chip 0.1uF C532 P20043 Capacitor chip 3300pF
C189 P20053 Capacitor chip 68pF C533 P20043 Capacitor chip 3300pF
C190 P20053 Capacitor chip 68pF C536 P30003 Electrolytic CAP 100uF/6V
C191 P31100 Ceramic CAP 10uF/16V C537 P20015 Capacitor chip 0.1uF
C192 P20015 Capacitor chip 0.1uF C538 P30003 Electrolytic CAP 100uF/6V
C193 P20015 Capacitor chip 0.1uF C539 P20015 Capacitor chip 0.1uF

REF No. PART No. PART NAME REF No. PART No. PART NAME
C542 P30004 Electrolytic CAP 220uF/4V CB72 P20015 Capacitor chip 0.1uF
C544 P20064 Capacitor chip 51pF CB74 P20015 Capacitor chip 0.1uF
C545 P20064 Capacitor chip 51pF CB75 P20015 Capacitor chip 0.1uF
C546 P20015 Capacitor chip 0.1uF CB76 P20015 Capacitor chip 0.1uF
C554 P30006 Electrolytic CAP 47uF/4V CB77 P20015 Capacitor chip 0.1uF
C555 P30006 Electrolytic CAP 47uF/4V CB78 P20015 Capacitor chip 0.1uF
C556 P30004 Electrolytic CAP 220uF/4V CB79 P20015 Capacitor chip 0.1uF
C573 P31100 Ceramic CAP 10uF/16V CB85 P20015 Capacitor chip 0.1uF
C574 P20015 Capacitor chip 0.1uF CB88 P20015 Capacitor chip 0.1uF
C576 P20015 Capacitor chip 0.1uF CB89 P20015 Capacitor chip 0.1uF
C641 P20035 Capacitor chip 1uF CB90 P20015 Capacitor chip 0.1uF
C642 P20035 Capacitor chip 1uF CB94 P20015 Capacitor chip 0.1uF
R70 P20035 Capacitor chip 1uF CB95 P20015 Capacitor chip 0.1uF
R003 P20015 Capacitor chip 0.1uF CB96 P20015 Capacitor chip 0.1uF
CB3 P20015 Capacitor chip 0.1uF CB97 P20015 Capacitor chip 0.1uF
CB4 P20015 Capacitor chip 0.1uF CB99 P20015 Capacitor chip 0.1uF
CB5 P20015 Capacitor chip 0.1uF CB100 P20015 Capacitor chip 0.1uF
CB6 P20015 Capacitor chip 0.1uF CB103 P20015 Capacitor chip 0.1uF
CB8 P20015 Capacitor chip 0.1uF CB108 P20015 Capacitor chip 0.1uF
CB04 P20015 Capacitor chip 0.1uF CB109 P20015 Capacitor chip 0.1uF
CB05 P20015 Capacitor chip 0.1uF CB110 P20015 Capacitor chip 0.1uF
CB11 P20015 Capacitor chip 0.1uF CB111 P20015 Capacitor chip 0.1uF
CB12 P20015 Capacitor chip 0.1uF CB112 P20015 Capacitor chip 0.1uF
CB13 P20015 Capacitor chip 0.1uF CB113 P20015 Capacitor chip 0.1uF
CB15 P20015 Capacitor chip 0.1uF CB114 P20015 Capacitor chip 0.1uF
CB16 P20015 Capacitor chip 0.1uF CB115 P20015 Capacitor chip 0.1uF
CB17 P20015 Capacitor chip 0.1uF CB116 P20015 Capacitor chip 0.1uF
CB20 P20015 Capacitor chip 0.1uF CB117 P20015 Capacitor chip 0.1uF
CB21 P20015 Capacitor chip 0.1uF CB118 P20015 Capacitor chip 0.1uF
CB22 P20015 Capacitor chip 0.1uF CB119 P20015 Capacitor chip 0.1uF
CB30 P20015 Capacitor chip 0.1uF CB121 P20015 Capacitor chip 0.1uF
CB40 P20015 Capacitor chip 0.1uF CB122 P20015 Capacitor chip 0.1uF
CB47 P20015 Capacitor chip 0.1uF CB124 P20015 Capacitor chip 0.1uF
CB48 P20015 Capacitor chip 0.1uF CB126 P20015 Capacitor chip 0.1uF
CB57 P20015 Capacitor chip 0.1uF CB127 P20015 Capacitor chip 0.1uF
CB66 P20015 Capacitor chip 0.1uF CB128 P20015 Capacitor chip 0.1uF
CB67 P20015 Capacitor chip 0.1uF CB129 P20015 Capacitor chip 0.1uF
CB68 P20015 Capacitor chip 0.1uF CB131 P20015 Capacitor chip 0.1uF
CB69 P20015 Capacitor chip 0.1uF CB132 P20015 Capacitor chip 0.1uF
CB71 P20015 Capacitor chip 0.1uF CB133 P20015 Capacitor chip 0.1uF

REF No. PART No. PART NAME REF No. PART No. PART NAME
CB134 P20015 Capacitor chip 0.1uF L40 P6659 Impedance at 100MHz:600
Ω
CB135 P20015 Capacitor chip 0.1uF L41 P6681 100uH
CB136 P20015 Capacitor chip 0.1uF L42 P6659 Impedance at 100MHz:600
Ω
CB137 P20015 Capacitor chip 0.1uF L43 P6681 100uH
CB138 P20015 Capacitor chip 0.1uF L44 P60039 470uH
CB139 P20015 Capacitor chip 0.1uF L46 P6681 100uH
CB140 P20015 Capacitor chip 0.1uF L001 P60003 33uH
CB141 P20015 Capacitor chip 0.1uF L002 P60003 33uH
CB142 P20015 Capacitor chip 0.1uF L005 P60003 33uH
CB143 P20015 Capacitor chip 0.1uF L008 P6681 100uH
CB144 P20015 Capacitor chip 0.1uF L015 P6659 Impedance at 100MHz:600
Ω
CB145 P20015 Capacitor chip 0.1uF L501 P6659 Impedance at 100MHz:600
Ω
CB146 P20015 Capacitor chip 0.1uF L502 P6681 100uH
CB147 P20015 Capacitor chip 0.1uF FB1 P6659 Impedance at 100MHz:600
Ω
FB2 P6659 Impedance at 100MHz:600
Ω
L1 P6659 Impedance at 100MHz:600
Ω
FB4 P6659 Impedance at 100MHz:600
Ω
L4 P6659 Impedance at 100MHz:600
Ω
EM1 P60006 FK2125T186AL
L5 P6659 Impedance at 100MHz:600
Ω
EM7 P60006 FK2125T186AL
L6 P6659 Impedance at 100MHz:600
Ω
EM503 P60006 FK2125T186AL
L9 P6659 Impedance at 100MHz:600
Ω
EM504 P60006 FK2125T186AL
L02 P6659 Impedance at 100MHz:600
Ω
EM506 P60006 FK2125T186AL
L10 P6659 Impedance at 100MHz:600
Ω
EM507 P60006 FK2125T186AL
L15 P6659 Impedance at 100MHz:600
Ω
L16 P6659 Impedance at 100MHz:600
Ω
VD1 P5722a B240A
L19 P6659 Impedance at 100MHz:600
Ω
VD2 P5722a B240A
L20 P6659 Impedance at 100MHz:600
Ω
VD3 P5766 STZ6.2NT146
L21 P6659 Impedance at 100MHz:600
Ω
VD4 P5722a B240A
L22 P6659 Impedance at 100MHz:600
Ω
VD6 P1219 1N5402T
L23 P6659 Impedance at 100MHz:600
Ω
VD8 P1200 1SS355TE Switch Diode
L24 P6659 Impedance at 100MHz:600
Ω
VD9 P5706 DTC144EUAT106
L26 P6659 Impedance at 100MHz:600
Ω
VD01 a1618 LED
L27 P6659 Impedance at 100MHz:600
Ω
VD10 P5067 KTA1298
L28 P6659 Impedance at 100MHz:600
Ω
VD11 P5067 KTA1298
L29 P6659 Impedance at 100MHz:600
Ω
VD12 P1200 1SS355TE Switch Diode
L30 P6659 Impedance at 100MHz:600
Ω
VD13 P1200 1SS355TE Switch Diode
L31 P6659 Impedance at 100MHz:600
Ω
VD14 P1200 1SS355TE Switch Diode
L32 P6659 Impedance at 100MHz:600
Ω
VD15 P1200 1SS355TE Switch Diode
L35 P6659 Impedance at 100MHz:600
Ω
VD16 P5714 FMC3AT148
L37 P6659 Impedance at 100MHz:600
Ω
VD30 P5700 2SB709AR
L39 P6681 100uH VD31 P5713 2SC2412K146R
INDUCTOR
TRANSISTOR

REF No. PART No. PART NAME REF No. PART No. PART NAME
VD32 P5073a 2SD601AR F004 P60088 FUSE 0433005NR
VD33 P1200 1SS355TE Switch Diode
VD40 P1200 1SS355TE Switch Diode FM001 a6916 LV-R0489 FILTER
VD42 P1556 MA152
VD43 P1556 MA152 G402 a6603a 27.000MHz
VD44 P1556 MA152 G403 a6476 14.31818MHz
VD45 P5766 STZ6.2NT146
VD001 P5770 UPA1716G-E2 VR1 P0620 POZ3AN-1-503N-T00
VD003 P5722a B240A VR3 P0618 POZ3AN-1-103N-TOO
VD004 P5722a B240A VR001 P0619a TMC3K-B5K-TR
VD009 P1200 1SS355TE Switch Diode VR501 a0654 WHE10xB-2-20K
VD010 P1200 1SS355TE Switch Diode
VD011 P1200 1SS355TE Switch Diode SW3 P6983 SW1AF-360-T10
VD012 P1200 1SS355TE Switch Diode SW101 P60078 SSSS710603
VD013 P1200 1SS355TE Switch Diode SW102 P6983 SW1AF-360-T10
VD014 P5073a 2SD601AR
VD015 P5073a 2SD601AR N1 P90277 TPS60400DBVR
VD017 P5722a B240A N2 P4530b BA4558
VD018 P5722a B240A N3 P5770 UPA1716G-E2
VD024 P5706 DTC144EUAT106 N12 P90015 TPS5100IPWR
VD028 P5752 2SJ401 N13 P90090 PQ05DZ11
VD029 P5073a 2SD601AR N14 P4582 NJM3414AM-TE1
VD045 P5067 KTA1298 N15 P90113 PQ1R33
VD407 P5067 KTA1298 N001 P90211 RN1224N332F
VD501 P5766 STZ6.2NT146 N003 P5759 IRF7304
VD502 P5766 STZ6.2NT146 N004 P90211 RN1224N332F
VD503 P5706 DTC144EUAT106 N005 P90072 BA033FP
VD504 P5769 2SB1561T100Q N006 P90092 UPC29M05T-E1
VD509 P5073a 2SD601AR N020 P90103 BQ2057CTSTR
VD510 P5073a 2SD601AR N401 P90157a MX29LV008TTC-70
VD520 P5073a 2SD601AR N403 P90346a D3800
VD521 P1200 1SS355TE Switch Diode N405 P90332 UPD5100
VD522 P1200 1SS355TE Switch Diode N406 a6733 HS0038B
VD523 P1200 1SS355TE Switch Diode N501 P4530 NJM4558
VD524 P5067 KTA1298 N502 P4513 NJM4580
VD525 P1200 1SS355TE Switch Diode N503 P4535 CD2822CB
VD538 P5766 STZ6.2NT146 D1 P4581 TC4W53FU
VD539 P5766 STZ6.2NT146 D3 P90386 LM1117ST18T3
D02 P90129 PCM1742E/2K
F003 P60089 FUSE 0430003WR D001 P4620a BR24C02F-WE2
FILTER
CRYSTAL OSCILLATOR
FUSE
IC
SWITCH
POTENTIOMETERS

REF No. PART No. PART NAME REF No. PART No. PART NAME
D002 P4516 74HCU04 C8 P20010 Capacitor chip 1500pF
D003 P90007 BA5954FP C9 P20012 Capacitor chip 0.01uF
D004 P90074 NT56V6620COT-75S C11 P20043 Capacitor chip 3300pF
C14 P20031a GHM1038SL120J3K
XS1 P60081 53261-0890 8P SOCKET C15 P20013 Capacitor chip 22000pF
XS4 P60038 GF055-SS-LSS 24P SOCKET C16 P20021 Capacitor chip 4.7uF
XS001 a7345 Battery connector (male) C17 P20023 Capacitor chip 10uF
JS4 a7420 MS100-22AD40 C18 P20014 Capacitor chip 47000pF
JS5 P60083 SM20B-SURS-TF SOCKET C20 P20028 Capacitor chip 220pF
JS6 P60083 SM20B-SURS-TF SOCKET
JS7 a6704 HSJ1494-01-010 SOCKET D1 P1557 DAN217T146
JS9 a7302a HSJ1594-010060 SOCKET D2 P1557 DAN217T146
JS10 a6905 HSJ1456-010330 SOCKET Q1 P5750 MMST3904T146
JS001 a6663a HEC3600-010110 SOCKET Q2 P5706 DTC144EUAT106
JS101 a9017 POWER CONTROL WIRE Q3 P5749 RK7002T116
JS102 P60041 53261-0390 3P SOCKET Z1 P1558 UDZSTE-175.6B
JS103 P60061 53261-0690 6P SOCKET Z2 P1558 UDZSTE-175.6B
JS503 a6704 HSJ1494-01-010 SOCKET Z3 P1558 UDZSTE-175.6B
U1 P90100 OZ960S
R1 P11023 Resistor chip 1M
Ω
U2 P90102 SI5504DC
R2 P11023 Resistor chip 1M
Ω
U3 P90102 SI5504DC
R3 P11013 Resistor chip 10K
Ω
R4 P11051 Resistor chip 1.5K
Ω
F1 a7276 K12 FUSE
R5 P11026 Resistor chip 1.2K
Ω
CN1 P6981 MOLEX-53261-0490
R6 P11006 Resistor chip 100
Ω
XS1 P7045 BHS-2P
R7 P11060 Resistor chip 560K
Ω
R8 P11209 Resistor chip 43K
Ω
R9 P11029 Resistor chip 2.2K
Ω
R1 P11052 Resistor chip 3K
Ω
R11 P11156 Resistor chip 300K
Ω
R2 P11014 Resistor chip 12K
Ω
R13 P11013 Resistor chip 10K
Ω
R3 P11000 Resistor chip 0
Ω
R14 P11057 Resistor chip 51K
Ω
R15 P11013 Resistor chip 10K
Ω
C2 P31100 Ceramic CAP 10uF/16V
C3 P31100 Ceramic CAP 10uF/16V
C2 P20035 Capacitor chip 1uF C4 P31100 Ceramic CAP 10uF/16V
C3 P20012 Capacitor chip 0.01uF C5 P31100 Ceramic CAP 10uF/16V
C4 P20015 Capacitor chip 0.1uF C6 P31100 Ceramic CAP 10uF/16V
C5 P20035 Capacitor chip 1uF C7 P31100 Ceramic CAP 10uF/16V
C6 P20014 Capacitor chip 47000pF C8 P31100 Ceramic CAP 10uF/16V
C7 P20006 Capacitor chip 100pF C9 P31100 Ceramic CAP 10uF/16V
DVD1731T-AS(LG) IF PCB ASS'Y
RESISTOR
CAPACITOR
CAPACITOR
RESISTOR
OTHER
IC
TRANSISTOR
SOCKET
DVD1731H-L HV PCB ASS'Y
