Shinco SDP1731A User manual

SERVICE MANUAL
CAUTION : Before servicing this chassis, read the "PRODUCT SAFETY SERVICE FOR VIDEO PRODUCTS" section
on page 2 of this manual.
CONTENTS
SERVICE PRECAUTIONS......................................................2,3
BLOCK DIAGRAMS...................................................................4
TROUBLE SHOOTING...........................................................5,8
BOARD DIAGRAM...............................................................9,10
DVD and CD
PLAYER
MODEL
SDP1731A
REPLACEMENT PARTS LIST............................................11,20

Whenthepowersupplyisbeingturnedon,youmaynotremovethislasercautionslabel.Ifitremoves,radiationoflaser
maybereceived.
LASERBEAMCAUTIONLABEL
PREPARATIONOFSERVICING
PickupHeadconsistsofalaserdiodethatisverysusceptibletoexternalstaticelectrocity.
Althoughitoperatesproperlyafterreplacement,ifitwassubjecttoelectrostaticdischargeduringreplacement,
itslifemightbeshortened.Whenreplacing,useaconductivemat,solderingironwithgroundwire,etc.to
protectthelaserdiodeformdamagebystaticelectricity.
Andalso,theLSIandICaresameasabove.
Solderingiron
withgroundwire
orceramictype
Groundconductive
wriststrapforbody.
Conductivemat
Thegroundresistance
betweenthegroundline
andthegroundislessthan10
1M

SAFTY NOTICE
Plug the AC line cord directly into a 120V AC outlet (do
not use an isolation transformer for this check). Use an
AC voltmeter, having 5000 per volt or more sensitivity.
Connect a 1500 10W resistor,paralleled by a 0.15uF
150V AC capacitor between a knomn good earth ground
(water pipe, conduit, etc.) and all exposed metal parts of
cabinet (antennas, handle bracket, metal cabinet
screwheads, metal overlays, control shafts, etc.).
SAFTY PRECAUTIONS
LEAKAGE CURRENT CHECK
Measure the AC voltage across the 1500 resistor.
The test must be conducted with the AC switch on and
then repeated with the AC switch off. The AC voltage
indicated by the meter may not exceed 0.3V.A reading
exceeding 0.3V indicates that a dangerous potential
exists, the fault must be located and corrected.
Repeat the above test with the DVD VIDEO PLAYER
power plug reversed.
NEVER RETURN A DVD VIDEO PLAYER TO THE
CUSTOMER WITHOUT TAKING NECESSARY
CORRECTIVE ACTION.
READING SHOULD NOT EXCEED 0.3V
DVD VIDEO PLAYER
AC OUTLET
AC VOLTMETER
Test all exposed metal.
Voltmeter Hook-up for Leakage Current Check
0.15uF 150V AC
1500
10W
(5000 per volt
or more sensitivity)
Good earth ground
such as a water pipe,
conduit, etc.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.

SERVO & DVD PROCESSOR
MPEG-2 DECODER
& VIDEO ENCODER
D2881
OVERALL BLOCK DIAGRAM
AC
Adapter
DC IN +9V
DC / DC
(R1224)
DC / DC
(R1224) (TPS5100)
(BQ2057C) (TPC8207) (VG202C)
110~240V
50/60Hz
BATTERY
KHM-252
PU mechanism
DRIVER
(BA5954FP)
RF AMP
D2891
8M FlashROM
MX29LV008TTC-70
64M SDRAM
NT56V6620C0T-75S
TC4W53
27MHz
AUDIO D/A
(PCM1742)
UPD5100 TFT MONITOR
AUDIO AMP
(NJM4558)
PHONE AMP
(NJM4580)
SPEAKER AMP
(D2822)
HIGH VOLTAGE ASS'Y
74HCU04
27MHz
VIDEO OUT
AUDIO OUT
PHONE OUT
SPEAKER LOUT
SPEAKER ROUT
L
R
L
R
RL
DRIVER +5V
+5V
AUDIO +/-5V
+3.3V
AUDIO +5V
TFT POWER
+5V -14.5V +16V
S-VIDEO OUT
DC 9V
DC 9V

1. Troubleshooting
1. No power when turned on.
2. The initial screen is not displayed on the LCD.
3. The DVD drive does not work.
4. The operation of the DVD player stops at initializing display.
5. Image output stops during the operation.
6. No sound or abnormal sound comes out form the speakers in the DVD player.
7. No image or sound comes out form the external output.
8. No sound comes out form the headphones.
9. No image or sound is output by external input.
10. The DVD drive does not operate with the battery.
1.1 No power when turned on.
When the power is turned on, and if the LED on the front panel does not light green, check
the following items and repair the defective parts.
(1) Check the power supply cable
If the cable is not the supplied one, replace it with the supplied cable and turn on the
power again.
If the power supply cable is good, the AC adapter may be defective.
If the LED does not light after replacing, check the following items.
(2) Check the AC adapter
If the AC adapter is not the supplied one, replace it with the supplied AC adapter and
turn on the power.
If the AC adapter is good, the power supply boards may be defective.
If the LED does not light after replacing, check the following items.
(3) Check the Power and Play buttons
Press the POWER button or the PLAY button on the DVD player. If the power does
not turn on, check the following:
zCheck the connector of the switch unit in the DVD player.
(If the connection is loose, repair the connection.)
zReplace the switch unit and turn on the power again.
If the LED does not light after replacing, check the following items.
(4) Replace the main board

1.2 The initial screen is not displayed on the LCD.
If the initial screen is not displayed on the LCD, check the following items.
(1) Check the LED on the front
If the LED does not light, proceed to 1.1.
(2) Check the backlight
If the backlight does not light up, separate. The DVD player into top assembly and
bottom assembly, and check the connector harness, and check the connectors for
defects.
If the connector harness is broken:
Replace the broken harness.
If the connector harness is not broken:
Remove the LCD cover and plate of the LCD unit and check the following:
zCheck the connector of the FL harness, repair connectors.
zIf the connectors are good, replace the FL inverter or the LCD.
(3) Check the lighting of LCD
If the LCD does not light, separate the DVD player into the top assembly and bottom
assembly, and check the LCD harness, and check the connectors on the main board.
If the connector is broken:
Replace the LCD harness or the main board.
If the connector is not broken:
Remove the LCD cover and plate of the LCD unit, and check the connection to the
harness of the LCD unit.
zIf a bad connection is found.
Connect the LCD harness to the LCD unit.
zOther than the above
Replace the LCD unit or the main board.

1.3 The DVD drive does not work.
When the DVD drive does not work after the power is turned on, check the following items
and repair or replace the defective parts.
(1) Press the DISC cover switch at the center of the DVD player and turn on the
power. Then check whether or not the optical pick-up lens of the DVD drive
lights.
CAUTION: Visible laser radiation when open and interlock defeated. Do not stare into
Laser beam.
The optical pick-up lens lights dim:
It is caused by deterioration of the optical pick-up lens. Replace the DVD drive.
The optical pick-up lens does not light:
Check the connectors of the DVD-FFC. Also check the connection to the main
board and to the DVD drive.
zLoose connection is found.
Repair the connection, and then check the operation of the DVD drive again.
zThe DVD-FFC is broken.
Replace the DVD-FFC.
zOther than the above.
Replace the DVD drive or the main board.
(2) Insert a DVD disk and turn on the power
The DVD drive does not work:
The motor of the DVD drive or the main board is defective. Replace the DVD drive
or the main board.
The DVD drive works but the initializing operation of the optical pick-up lens
does not start (the optical pick-up lens operates twice), or abnormal noise
sound:
The DVD drive is defective. Replace the DVD drive.
1.4 The operation of the DVD player stops at initializing display.
If the DVD player does not work after the initializing screen is displayed, check the
indication on the screen. Then repair the defect according to it.
(1) Insert a DVD disk and close the DISC cover, and turn on the power. Then check
the LCD screen or use an external display.
zThe message “loading” is not displayed or the operation stops at the
message “Loading”.
Since the DVD drive or the main board is defective, check in the following order:
1) DVD drive
2) Main board
zThe message “CHECK DISK” is displayed.
Check the DVD disk for fingerprints, dirt, etc.
If the DVD disk is OK, then check the following items:
1) Check the DVD-FFC
If a loose connection, repair the connection.
If it is damaged, replace it with new one.
2) Other than above
For other cases, replace the unit in the following order:
zDVD drive (defective optical pick-up)
zMain board

1.5 Image output stops during the operation.
If the image output form the media in the DVD player stops during the operation, replace
the DVD drive.
1.6 No sound or abnormal sound comes out from the speakers in the DVD player.
If no sound comes out form the speakers in the DVD player, check the following:
(1) Check for moving images on the LCD screen
Check whether or not the move of image stops in halfway. If it stops, replace the DVD
drive.
(2) Check the operation of the DVD driver.
Check whether or not the DVD drive works. If it stops, replace the DVD drive.
(3) Check the connection of the speakers in the LCD unit.
Separate the DVD player into the top assembly and bottom assembly, and then check
the connection of the speaker harnesses to the main board. If a bad connection, repair
the connection.
Other than the above, disassemble the LCD unit and replace the speakers or the main
board.
1.7 No image or sound comes out form the external output
If any image or sound is output form the TV connected by the external cable, replace the
main board or the connector.
NOTE: Before this test, make sure the drive works.
1.8 No sound comes out form the headphones.
If no sound comes out form the headphones, replace the main board or the connector.
1.9 No image or sound is output by the external input.
If any image or sound is output by external input, replace the main board or the connector.
1.10 The DVD drive does not operate with the battery.
(1) Check the operation with a good battery.
Install a good battery and make sure the LED lights up orange while the AC adapter is
connected. When the LED does not light up or blinks, check the connection of the
battery harness inside the DVD player. If the connection is loose, repair connection. If
the harness has been connected firmly, replace the main board.
(2) Other than the above, replace the battery.
NOTE:
zFor this check, use a battery which is not fully charged (because the LED does
not light when the battery is fully charged.)
zBefore this check, make sure other function work correctly.

DVD1731BM-AS MAIN PCB BOARD DIAGRAM

DVD1731T-AS IF PCB BOARD DIAGRAM
DVD1731H-L HV PCB BOARD DIAGRAM

PART No. PART NAME Q'TY
11079j RB-LI24 LITHIUM BATTERY 1
21328 DVD1731H-L HV PCB ASS'Y 1
21186 DVD1731 FUNCTION PCB ASS'Y 1
21385 DVD1731BM-AS MAIN PCB ASS'Y 1
21344 DVD1731T-AS IF PCB ASS'Y 1
S8064 KHM-252 LOADING ASS'Y 1
S0578e ADPV18A AC POWER ADAPTER 1
S5006a SPEAKER 2
S1177d OWNER MANUAL 1
S06024 RC-1730 REMOTE 1
S3421a 20 PIN HARNESS (LE105) 1
S3421c 20 PIN HARNESS (LE140) 1
a7187e LB070W02-S TFT LCD 1
S0535 CAR CIGARETTE ADAPTER 1
S3589 SPEAKER CONNECT WIRE 2
S3590 TFT EARTHING WIRE 1
S3736 HV POWER CONNECT WIRE 1
S3153 RCA CORD VIDEO 1
S3154 RCA CORD AUDIO 1
S4353 EARPHONE 1
S3501 FFC-0.5-24-130 1
ELECTRICAL PARTS LIST
SDP1731A

REF No. PART No. PART NAME REF No. PART No. PART NAME
R52 P11000 Resistor chip 0
¡
R53 P11000 Resistor chip 0
¡
R1 P11038 Resistor chip 39K
¡
R54 P11000 Resistor chip 0
¡
R3 P11013 Resistor chip 10K
¡
R55 P11012 Resistor chip 4.7K
¡
R4 P11000 Resistor chip 0
¡
R002 P11254 SL1TE100MF
R6 P11012 Resistor chip 4.7K
¡
R003 P11042 Resistor chip 120K
¡
R7 P11004 Resistor chip 33
¡
R004 P11019 Resistor chip 100K
¡
R8 P11004 Resistor chip 33
¡
R005 P11041 Resistor chip 82K
¡
R01 P11039 Resistor chip 56K
¡
R006 P11013 Resistor chip 10K
¡
R02 P11039 Resistor chip 56K
¡
R007 P11009 Resistor chip 1K
¡
R03 P11010 Resistor chip 2K
¡
R008 P11009 Resistor chip 1K
¡
R04 P11018 Resistor chip 47K
¡
R009 P11009 Resistor chip 1K
¡
R05 P11009 Resistor chip 1K
¡
R100 P11035 Resistor chip 20K
¡
R06 P11018 Resistor chip 47K
¡
R101 P11052 Resistor chip 3K
¡
R10 P11207 Resistor chip 0.5
¡
R102 P11030 Resistor chip 2.7K
¡
R12 P11009 Resistor chip 1K
¡
R103 P11003 Resistor chip 10
¡
R14 P11000 Resistor chip 0
¡
R104 P11034 Resistor chip 18K
¡
R17 P11072 Resistor chip 300
¡
R105 P11014 Resistor chip 12K
¡
R20 P11072 Resistor chip 300
¡
R106 P11030 Resistor chip 2.7K
¡
R22 P11013 Resistor chip 10K
¡
R107 P11003 Resistor chip 10
¡
R23 P11023 Resistor chip 1M
¡
R108 P11009 Resistor chip 1K
¡
R24 P11147 Resistor chip 750
¡
R109 P11018 Resistor chip 47K
¡
R25 P11006 Resistor chip 100
¡
R110 P11069 Resistor chip 13K
¡
R26 P11006 Resistor chip 100
¡
R111 P11012 Resistor chip 4.7K
¡
R27 P11035 Resistor chip 20K
¡
R114 P11018 Resistor chip 47K
¡
R28 P11010 Resistor chip 2K
¡
R115 P11009 Resistor chip 1K
¡
R29 P11017 Resistor chip 33K
¡
R120 P11009 Resistor chip 1K
¡
R30 P11013 Resistor chip 10K
¡
R129 P11000 Resistor chip 0
¡
R31 P11013 Resistor chip 10K
¡
R140 P11044 Resistor chip 220K
¡
R32 P11013 Resistor chip 10K
¡
R141 P11054 Resistor chip 7.5K
¡
R33 P11013 Resistor chip 10K
¡
R142 P11034 Resistor chip 18K
¡
R34 P11013 Resistor chip 10K
¡
R143 P11006 Resistor chip 100
¡
R36 P11072 Resistor chip 300
¡
R144 P11044 Resistor chip 220K
¡
R39 P11013 Resistor chip 10K
¡
R145 P11008 Resistor chip 470
¡
R44 P11013 Resistor chip 10K
¡
R146 P11008 Resistor chip 470
¡
R45 P11013 Resistor chip 10K
¡
R147 P11040 Resistor chip 68K
¡
R46 P11013 Resistor chip 10K
¡
R148 P11040 Resistor chip 68K
¡
R47 P11053 Resistor chip 5.6K
¡
R149 P11040 Resistor chip 68K
¡
R49 P11025 Resistor chip 680
¡
R150 P11040 Resistor chip 68K
¡
R50 P11005 Resistor chip 75
¡
R151 P11142 Resistor chip 6.2K
¡
DVD1731BM-AS MAIN PCB ASS'Y
RESISTOR

REF No. PART No. PART NAME REF No. PART No. PART NAME
R152 P11044 Resistor chip 220K
¡
R455 P11019 Resistor chip 100K
¡
R153 P11034 Resistor chip 18K
¡
R456 P11009 Resistor chip 1K
¡
R157 P11018 Resistor chip 47K
¡
R457 P11023 Resistor chip 1M
¡
R158 P11013 Resistor chip 10K
¡
R458 P11013 Resistor chip 10K
¡
R159 P11013 Resistor chip 10K
¡
R459 P11009 Resistor chip 1K
¡
R180 P11010 Resistor chip 2K
¡
R460 P11004 Resistor chip 33
¡
R312 P11004 Resistor chip 33
¡
R462 P11038 Resistor chip 39K
¡
R401 P11006 Resistor chip 100
¡
R463 P11025 Resistor chip 680
¡
R402 P11013 Resistor chip 10K
¡
R464 P11025 Resistor chip 680
¡
R405 P11023 Resistor chip 1M
¡
R465 P11004 Resistor chip 33
¡
R406 P11000 Resistor chip 0
¡
R471 P11013 Resistor chip 10K
¡
R407 P11013 Resistor chip 10K
¡
R476 P11004 Resistor chip 33
¡
R413 P11003 Resistor chip 10
¡
R482 P11003 Resistor chip 10
¡
R414 P11019 Resistor chip 100K
¡
R484 P11057 Resistor chip 51K
¡
R415 P11000 Resistor chip 0
¡
R485 P11018 Resistor chip 47K
¡
R417 P11034 Resistor chip 18K
¡
R487 P11002 Resistor chip 4.7
¡
R419 P11207 Resistor chip 0.5
¡
R488 P11002 Resistor chip 4.7
¡
R421 P11207 Resistor chip 0.5
¡
R489 P11004 Resistor chip 33
¡
R425 P11015 Resistor chip 15K
¡
R490 P11004 Resistor chip 33
¡
R426 P11000 Resistor chip 0
¡
R491 P11004 Resistor chip 33
¡
R428 P11013 Resistor chip 10K
¡
R492 P11013 Resistor chip 10K
¡
R429 P11035 Resistor chip 20K
¡
R494 P11004 Resistor chip 33
¡
R430 P11035 Resistor chip 20K
¡
R501 P11018 Resistor chip 47K
¡
R432 P11002 Resistor chip 4.7
¡
R502 P11018 Resistor chip 47K
¡
R433 P11055 Resistor chip 8.2K
¡
R503 P11000 Resistor chip 0
¡
R434 P11063 Resistor chip 1
¡
R506 P11000 Resistor chip 0
¡
R435 P11117 Resistor chip 510
¡
R507 P11020 Resistor chip 150K
¡
R436 P11035 Resistor chip 20K
¡
R508 P11020 Resistor chip 150K
¡
R438 P11122 Resistor chip 750K
¡
R509 P11013 Resistor chip 10K
¡
R440 P11035 Resistor chip 20K
¡
R510 P11013 Resistor chip 10K
¡
R442 P11038 Resistor chip 39K
¡
R511 P11002 Resistor chip 4.7
¡
R443 P11000 Resistor chip 0
¡
R512 P11002 Resistor chip 4.7
¡
R444 P11013 Resistor chip 10K
¡
R513 P11053 Resistor chip 5.6K
¡
R445 P11015 Resistor chip 15K
¡
R514 P11031 Resistor chip 3.9K
¡
R449 P11013 Resistor chip 10K
¡
R515 P11013 Resistor chip 10K
¡
R450 P11013 Resistor chip 10K
¡
R516 P11019 Resistor chip 100K
¡
R451 P11013 Resistor chip 10K
¡
R517 P11013 Resistor chip 10K
¡
R452 P11002 Resistor chip 4.7
¡
R518 P11006 Resistor chip 100
¡
R453 P11002 Resistor chip 4.7
¡
R519 P11053 Resistor chip 5.6K
¡
R454 P11013 Resistor chip 10K
¡
R520 P11013 Resistor chip 10K
¡

REF No. PART No. PART NAME REF No. PART No. PART NAME
R521 P11031 Resistor chip 3.9K
¡
RN5 P1006 Row of resistor 100
¡
R522 P11019 Resistor chip 100K
¡
RN419 P11206 Row of resistor 22
¡
R523 P11013 Resistor chip 10K
¡
R524 P11002 Resistor chip 4.7
¡
C1 P30014 Electrolytic CAP 100uF/16V
R525 P11003 Resistor chip 10
¡
C2 P30014 Electrolytic CAP 100uF/16V
R526 P11009 Resistor chip 1K
¡
C4 P20015 Capacitor chip 0.1uF
R527 P11009 Resistor chip 1K
¡
C5 P31100 Ceramic CAP 10uF/16V
R529 P11006 Resistor chip 100
¡
C6 P20015 Capacitor chip 0.1uF
R530 P11006 Resistor chip 100
¡
C8 P20015 Capacitor chip 0.1uF
R535 P11034 Resistor chip 18K
¡
C9 P20015 Capacitor chip 0.1uF
R536 P11009 Resistor chip 1K
¡
C01 P20009 Capacitor chip 1000pF
R540 P11013 Resistor chip 10K
¡
C12 P20034j Capacitor chip 390pF
R541 P11013 Resistor chip 10K
¡
C13 P31100 Ceramic CAP 10uF/16V
R542 P11013 Resistor chip 10K
¡
C14 P30003 Electrolytic CAP 100uF/6V
R543 P11019 Resistor chip 100K
¡
C15 P31100 Ceramic CAP 10uF/16V
R544 P11055 Resistor chip 8.2K
¡
C16 P31100 Ceramic CAP 10uF/16V
R545 P11019 Resistor chip 100K
¡
C17 P31100 Ceramic CAP 10uF/16V
R546 P11013 Resistor chip 10K
¡
C18 P31100 Ceramic CAP 10uF/16V
R547 P11055 Resistor chip 8.2K
¡
C20 P20015 Capacitor chip 0.1uF
R548 P11002 Resistor chip 4.7
¡
C22 P20015 Capacitor chip 0.1uF
R550 P11024 Resistor chip 330
¡
C23 P20052 Capacitor chip 20pF
R551 P11006 Resistor chip 100
¡
C24 P20052 Capacitor chip 20pF
R554 P11009 Resistor chip 1K
¡
C27 P31100 Ceramic CAP 10uF/16V
R555 P11009 Resistor chip 1K
¡
C29 P20015 Capacitor chip 0.1uF
R556 P11009 Resistor chip 1K
¡
C30 P20017 Capacitor chip 0.47uF
R557 P11009 Resistor chip 1K
¡
C31 P20012 Capacitor chip 0.01uF
R558 P11013 Resistor chip 10K
¡
C32 P31100 Ceramic CAP 10uF/16V
R559 P11012 Resistor chip 4.7K
¡
C33 P20015 Capacitor chip 0.1uF
R560 P11008 Resistor chip 470
¡
C34 P30014 Electrolytic CAP 100uF/16V
R567 P11006 Resistor chip 100
¡
C39 P31100 Ceramic CAP 10uF/16V
R568 P11019 Resistor chip 100K
¡
C001 P20009 Capacitor chip 1000pF
R575 P11013 Resistor chip 10K
¡
C002 P20015 Capacitor chip 0.1uF
R577 P11009 Resistor chip 1K
¡
C003 P20015 Capacitor chip 0.1uF
L4 P11002 Resistor chip 4.7
¡
C004 P30014 Electrolytic CAP 100uF/16V
L8 P11000 Resistor chip 0
¡
C005 P20015 Capacitor chip 0.1uF
L10 P11000 Resistor chip 0
¡
C006 P30014 Electrolytic CAP 100uF/16V
C21 P11195 Resistor chip 10K
¡
C007 P30014 Electrolytic CAP 100uF/16V
RN2 P1006 Row of resistor 100
¡
C008 P30010 Electrolytic CAP 10uF/16V(Al)
RN3 P1006 Row of resistor 100
¡
C101 P30014 Electrolytic CAP 100uF/16V
RN4 P1006 Row of resistor 100
¡
C102 P20015 Capacitor chip 0.1uF
CAPACITOR

REF No. PART No. PART NAME REF No. PART No. PART NAME
C103 P31100 Ceramic CAP 10uF/16V C182 P30014 Electrolytic CAP 100uF/16V
C104 P20009 Capacitor chip 1000pF C188 P30014 Electrolytic CAP 100uF/16V
C105 P20009 Capacitor chip 1000pF C190 P30014 Electrolytic CAP 100uF/16V
C110 P30014 Electrolytic CAP 100uF/16V C401 P31100 Ceramic CAP 10uF/16V
C111 P20035 Capacitor chip 1uF C403 P20061 Capacitor chip 0.015uF
C112 P30014 Electrolytic CAP 100uF/16V C405 P20034j Capacitor chip 390pF
C124 P30014 Electrolytic CAP 100uF/16V C406 P20015 Capacitor chip 0.1uF
C128 P30003 Electrolytic CAP 100uF/6V C408 P20049 Capacitor chip 33000pF
C131 P30014 Electrolytic CAP 100uF/16V C411 P31100 Ceramic CAP 10uF/16V
C132 P30014 Electrolytic CAP 100uF/16V C412 P31100 Ceramic CAP 10uF/16V
C139 P20015 Capacitor chip 0.1uF C417 P31100 Ceramic CAP 10uF/16V
C141 P30014 Electrolytic CAP 100uF/16V C418 P20035 Capacitor chip 1uF
C142 P30014 Electrolytic CAP 100uF/16V C419 P20035 Capacitor chip 1uF
C143 P30014 Electrolytic CAP 100uF/16V C420 P20035 Capacitor chip 1uF
C149 P20053 Capacitor chip 68pF C421 P20035 Capacitor chip 1uF
C150 P20015 Capacitor chip 0.1uF C426 P20009 Capacitor chip 1000pF
C151 P31100 Ceramic CAP 10uF/16V C427 P20061 Capacitor chip 0.015uF
C153 P20035 Capacitor chip 1uF C433 P20061 Capacitor chip 0.015uF
C154 P31100 Ceramic CAP 10uF/16V C436 P20061 Capacitor chip 0.015uF
C155 P20035 Capacitor chip 1uF C437 P20009 Capacitor chip 1000pF
C157 P20015 Capacitor chip 0.1uF C439 P20009 Capacitor chip 1000pF
C158 P20053 Capacitor chip 68pF C441 P20027 Capacitor chip 150pF
C160 P20015 Capacitor chip 0.1uF C442 P20027 Capacitor chip 150pF
C161 P20015 Capacitor chip 0.1uF C443 P30014 Electrolytic CAP 100uF/16V
C162 P20015 Capacitor chip 0.1uF C444 P31100 Ceramic CAP 10uF/16V
C163 P20015 Capacitor chip 0.1uF C445 P20009 Capacitor chip 1000pF
C164 P20053 Capacitor chip 68pF C446 P20012 Capacitor chip 0.01uF
C165 P20016 Capacitor chip 0.33uF C447 P20035 Capacitor chip 1uF
C166 P20015 Capacitor chip 0.1uF C448 P20012 Capacitor chip 0.01uF
C167 P20015 Capacitor chip 0.1uF C449 P20012 Capacitor chip 0.01uF
C168 P20016 Capacitor chip 0.33uF C450 P20012 Capacitor chip 0.01uF
C169 P20015 Capacitor chip 0.1uF C451 P20012 Capacitor chip 0.01uF
C173 P20015 Capacitor chip 0.1uF C452 P20015 Capacitor chip 0.1uF
C174 P20027 Capacitor chip 150pF C453 P31100 Ceramic CAP 10uF/16V
C175 P20015 Capacitor chip 0.1uF C455 P20029 Capacitor chip 330pF
C176 P20015 Capacitor chip 0.1uF C456 P20009 Capacitor chip 1000pF
C178 P30014 Electrolytic CAP 100uF/16V C457 P20061 Capacitor chip 0.015uF
C179 P30014 Electrolytic CAP 100uF/16V C461 P30003 Electrolytic CAP 100uF/6V
C181 P30014 Electrolytic CAP 100uF/16V C466 P20057 Adjustable capacitor

REF No. PART No. PART NAME REF No. PART No. PART NAME
C467 P31100 Ceramic CAP 10uF/16V C535 P30002 Electrolytic CAP 47uF/6V
C471 P20051 Capacitor chip 5.1pF C536 P30014 Electrolytic CAP 100uF/16V
C472 P20009 Capacitor chip 1000pF C537 P20015 Capacitor chip 0.1uF
C473 P20051 Capacitor chip 5.1pF C538 P30014 Electrolytic CAP 100uF/16V
C474 P20002 Capacitor chip 22pF C539 P20015 Capacitor chip 0.1uF
C475 P20015 Capacitor chip 0.1uF C540 P31100 Ceramic CAP 10uF/16V
C476 P30010 Electrolytic CAP 10uF/16V(Al) C541 P31100 Ceramic CAP 10uF/16V
C480 P20009 Capacitor chip 1000pF C544 P20064 Capacitor chip 51pF
C493 P30014 Electrolytic CAP 100uF/16V C545 P20064 Capacitor chip 51pF
C495 P31100 Ceramic CAP 10uF/16V C546 P20015 Capacitor chip 0.1uF
C496 P30006 Electrolytic CAP 47uF/4V C550 P20059 Capacitor chip 4700pF
C498 P31100 Ceramic CAP 10uF/16V C551 P31100 Ceramic CAP 10uF/16V
C499 P31100 Ceramic CAP 10uF/16V C552 P31100 Ceramic CAP 10uF/16V
C500 P31100 Ceramic CAP 10uF/16V C553 P31100 Ceramic CAP 10uF/16V
C501 P30006 Electrolytic CAP 47uF/4V C555 P30004 Electrolytic CAP 220uF/4V
C502 P30006 Electrolytic CAP 47uF/4V C556 P30004 Electrolytic CAP 220uF/4V
C503 P30014 Electrolytic CAP 100uF/16V C557 P31100 Ceramic CAP 10uF/16V
C505 P30006 Electrolytic CAP 47uF/4V C559 P31100 Ceramic CAP 10uF/16V
C506 P30006 Electrolytic CAP 47uF/4V CB1 P20015 Capacitor chip 0.1uF
C507 P30014 Electrolytic CAP 100uF/16V CB2 P20015 Capacitor chip 0.1uF
C508 P30006 Electrolytic CAP 47uF/4V CB3 P20015 Capacitor chip 0.1uF
C509 P30006 Electrolytic CAP 47uF/4V CB4 P20015 Capacitor chip 0.1uF
C510 P30002 Electrolytic CAP 47uF/6V CB5 P20015 Capacitor chip 0.1uF
C511 a3690 CDV-220uF-M-10V CB6 P20015 Capacitor chip 0.1uF
C512 P30010 Electrolytic CAP 10uF/16V(Al) CB7 P20015 Capacitor chip 0.1uF
C513 P30010 Electrolytic CAP 10uF/16V(Al) CB8 P20015 Capacitor chip 0.1uF
C514 P30014 Electrolytic CAP 100uF/16V CB9 P20015 Capacitor chip 0.1uF
C516 P20030 Capacitor chip 2700pF CB01 P20015 Capacitor chip 0.1uF
C517 P20030 Capacitor chip 2700pF CB02 P20015 Capacitor chip 0.1uF
C518 P20048 Capacitor chip 300pF CB03 P20015 Capacitor chip 0.1uF
C519 P20048 Capacitor chip 300pF CB04 P20015 Capacitor chip 0.1uF
C523 P20015 Capacitor chip 0.1uF CB05 P20015 Capacitor chip 0.1uF
C528 P20015 Capacitor chip 0.1uF CB06 P20015 Capacitor chip 0.1uF
C529 P20015 Capacitor chip 0.1uF CB07 P20015 Capacitor chip 0.1uF
C530 P20015 Capacitor chip 0.1uF CB08 P20015 Capacitor chip 0.1uF
C531 P30014 Electrolytic CAP 100uF/16V CB09 P20015 Capacitor chip 0.1uF
C532 P20043 Capacitor chip 3300pF CB11 P20015 Capacitor chip 0.1uF
C533 P20043 Capacitor chip 3300pF CB12 P20015 Capacitor chip 0.1uF
C534 P30002 Electrolytic CAP 47uF/6V CB13 P20015 Capacitor chip 0.1uF

REF No. PART No. PART NAME REF No. PART No. PART NAME
CB14 P20015 Capacitor chip 0.1uF CB55 P20015 Capacitor chip 0.1uF
CB15 P20015 Capacitor chip 0.1uF CB56 P20015 Capacitor chip 0.1uF
CB16 P20015 Capacitor chip 0.1uF CB57 P20015 Capacitor chip 0.1uF
CB17 P20015 Capacitor chip 0.1uF CB58 P20015 Capacitor chip 0.1uF
CB18 P20015 Capacitor chip 0.1uF CB59 P20015 Capacitor chip 0.1uF
CB19 P20015 Capacitor chip 0.1uF CB60 P20015 Capacitor chip 0.1uF
CB20 P20015 Capacitor chip 0.1uF CB63 P20015 Capacitor chip 0.1uF
CB21 P20038 Capacitor chip 470pF CB64 P20009 Capacitor chip 1000pF
CB22 P20015 Capacitor chip 0.1uF CB65 P20015 Capacitor chip 0.1uF
CB23 P20015 Capacitor chip 0.1uF CB70 P20015 Capacitor chip 0.1uF
CB24 P20015 Capacitor chip 0.1uF CB71 P20015 Capacitor chip 0.1uF
CB25 P20015 Capacitor chip 0.1uF CB73 P20015 Capacitor chip 0.1uF
CB26 P20015 Capacitor chip 0.1uF CB74 P20015 Capacitor chip 0.1uF
CB27 P20015 Capacitor chip 0.1uF CB76 P20015 Capacitor chip 0.1uF
CB28 P20015 Capacitor chip 0.1uF CB77 P20015 Capacitor chip 0.1uF
CB29 P20015 Capacitor chip 0.1uF CB82 P20015 Capacitor chip 0.1uF
CB30 P20015 Capacitor chip 0.1uF CB86 P20015 Capacitor chip 0.1uF
CB31 P20015 Capacitor chip 0.1uF CB87 P20015 Capacitor chip 0.1uF
CB32 P20015 Capacitor chip 0.1uF CB91 P20009 Capacitor chip 1000pF
CB33 P20015 Capacitor chip 0.1uF CB92 P20015 Capacitor chip 0.1uF
CB34 P20015 Capacitor chip 0.1uF CB95 P20015 Capacitor chip 0.1uF
CB35 P20015 Capacitor chip 0.1uF CB96 P20015 Capacitor chip 0.1uF
CB36 P20015 Capacitor chip 0.1uF CB97 P20015 Capacitor chip 0.1uF
CB37 P20015 Capacitor chip 0.1uF CB98 P20015 Capacitor chip 0.1uF
CB38 P20015 Capacitor chip 0.1uF
CB39 P20015 Capacitor chip 0.1uF L2 P6659 Impedance at 100MHz:600
¡
CB40 P20015 Capacitor chip 0.1uF L3 P6659 Impedance at 100MHz:600
¡
CB41 P20015 Capacitor chip 0.1uF L5 P6659 Impedance at 100MHz:600
¡
CB42 P20015 Capacitor chip 0.1uF L6 P6659 Impedance at 100MHz:600
¡
CB43 P20015 Capacitor chip 0.1uF L7 P6659 Impedance at 100MHz:600
¡
CB44 P20015 Capacitor chip 0.1uF L11 P6681 100uH
CB45 P20015 Capacitor chip 0.1uF L12 P6659 Impedance at 100MHz:600
¡
CB46 P20015 Capacitor chip 0.1uF L101 P60003 33uH
CB48 P20015 Capacitor chip 0.1uF L102 P60003 33uH
CB49 P20015 Capacitor chip 0.1uF L105 P6659 Impedance at 100MHz:600
¡
CB50 P20015 Capacitor chip 0.1uF L120 P6681 100uH
CB51 P20015 Capacitor chip 0.1uF L125 P6659 Impedance at 100MHz:600
¡
CB52 P20015 Capacitor chip 0.1uF L130 P6679 10uH
CB53 P20015 Capacitor chip 0.1uF L131 P60039 470uH
CB54 P20015 Capacitor chip 0.1uF L132 P60039 470uH
INDUCTOR

REF No. PART No. PART NAME REF No. PART No. PART NAME
L133 P6679 10uH VD001 P5722a B240A
L137 P6681 100uH VD002 P5722a B240A
L140 P60003 33uH VD004 P5752 2SJ401
L403 P6817 Impedance at 100MHz:60
¡
VD101 P1219 1N5402T
L404 P6659 Impedance at 100MHz:600
¡
VD102 P90211 RN1224N332F
L407 P6659 Impedance at 100MHz:600
¡
VD103 P90211 RN1224N332F
L409 P6817 Impedance at 100MHz:60
¡
VD105 P5771 UDZS7E-1715B
L410 P6659 Impedance at 100MHz:600
¡
VD106 P90092 UPC29M05T-E1
L416 P6659 Impedance at 100MHz:600
¡
VD107 P90072 BA033FP
L419 P6659 Impedance at 100MHz:600
¡
VD108 P1200 1SS355TE Switch Diode
L420 P6659 Impedance at 100MHz:600
¡
VD110 P5722a B240A
L430 P6659 Impedance at 100MHz:600
¡
VD111 P5722a B240A
L435 P6659 Impedance at 100MHz:600
¡
VD112 P5073a 2SD601AR
L501 P6659 Impedance at 100MHz:600
¡
VD113 P1200 1SS355TE Switch Diode
L502 P6681 100uH VD114 P5772 UDZS7E-174.7B
L503 P6659 Impedance at 100MHz:600
¡
VD115 P1566 CRG01
L504 P6659 Impedance at 100MHz:600
¡
VD116 P1200 1SS355TE Switch Diode
FB101 P6659 Impedance at 100MHz:600
¡
VD117 P5073a 2SD601AR
FB103 P6659 Impedance at 100MHz:600
¡
VD122 P5700 2SB709AR
FB104 P6659 Impedance at 100MHz:600
¡
VD123 P1556 MA152
EM302 P60006 FK2125T186AL VD125 P5073a 2SD601AR
EM401 P60006 FK2125T186AL VD126 P1556 MA152
EM402 P60006 FK2125T186AL VD127 P5073a 2SD601AR
EM407 P60006 FK2125T186AL VD128 P1556 MA152
EM503 P60006 FK2125T186AL VD129 P90277 TPS60400DBVR
EM504 P60006 FK2125T186AL VD130 P1200 1SS355TE Switch Diode
EM506 P60006 FK2125T186AL VD131 P5067 KTA1298
EM507 P60006 FK2125T186AL VD132 a1604a LED
VD401 P1200 1SS355TE Switch Diode
VD1 P1200 1SS355TE Switch Diode VD404 P5067 KTA1298
VD2 P1200 1SS355TE Switch Diode VD406 P5067 KTA1298
VD4 P5706 DTC144EUAT106 VD407 P5067 KTA1298
VD5 P5722a B240A VD410 P1200 1SS355TE Switch Diode
VD6 P5073a 2SD601AR VD411 P1200 1SS355TE Switch Diode
VD7 P5722a B240A VD503 P5706 DTC144EUAT106
VD8 P5722a B240A VD504 P5769 2SB1561T100Q
VD12 P1200 1SS355TE Switch Diode VD509 P5073a 2SD601AR
VD15 P5714 FMC3AT148 VD510 P5073a 2SD601AR
VD17 P5706 DTC144EUAT106 VD520 P5073a 2SD601AR
VD18 P5706 DTC144EUAT106 VD521 P1200 1SS355TE Switch Diode
TRANSISTOR

REF No. PART No. PART NAME REF No. PART No. PART NAME
VD522 P1200 1SS355TE Switch Diode N406 a6733 HS0038B
VD523 P1200 1SS355TE Switch Diode N409 P4516 74HCU04
VD524 P5067 KTA1298 N412 P90157c SST39VF-080-70 4C-EI
VD525 P1200 1SS355TE Switch Diode N413 P4620a BR24C02F-WE2
VD526 P1200 1SS355TE Switch Diode N417 P90129 PCM1742E/2K
VD535 P5766 STZ6.2NT146 N419 P90074 NT56V6620COT-75S
VD536 P5766 STZ6.2NT146 N501 P4530 NJM4558
VD537 P5766 STZ6.2NT146 N502 P4513 NJM4580
VD538 P5766 STZ6.2NT146 N503 P4535 CD2822CB
VD539 P5766 STZ6.2NT146 N508 P4530 NJM4558
N509 P90204b D2881C
F1 P60045 FUSE 451005
F101 P60047 FUSE 452003 JS2 a6674c CK35-15
JS3 a6905b HSJ1456-010330
FM102 a6916 LV-R0489 FILTER JS5 a7420 MS100-22AD40
JS101 a6663 HEC3600-010110 SOCKET
G1 a6476 14.31818MHz JS302 a6674c CK35-15
G401 a6603a 27.000MHz JS503 a6704a CK35-17
JX1 a9135 BATTERY CONNECT WIRE
VR1 P0620 POZ3AN-1-503N-T00 XS1 a7345 BATTERY CONNECT
VR2 P0620 POZ3AN-1-503N-T00 XS2 P60043 MOLEX-53261-0790
VR001 P0619a TMC3K-B5K-TR XS3 P60083 SM20B-SURS-TF SOCKET
VR501 a0654 WHE10xB-2-20K XS4 P60083 SM20B-SURS-TF SOCKET
XS401 P60061 53261-0690 6P SOCKET
SW101 P60078 SSSS710603 XS402 P6971 FPL0.5B-SMT-24P SOCKET
SW102 a6683 ESE11SV1 XS403 P60081 53261-0890 8P SOCKET
SW103 a6683 ESE11SV1
N1 P4582 NJM3414AM-TE1 R1 P11023 Resistor chip 1M
¡
N2 P90113a BA033LBSG-TR R2 P11023 Resistor chip 1M
¡
N3 P90332 UPD5100 R3 P11013 Resistor chip 10K
¡
N001 P5770 UPA1716G-E2 R4 P11051 Resistor chip 1.5K
¡
N002 P90103 BQ2057CTSTR R5 P11026 Resistor chip 1.2K
¡
N003 P5770 UPA1716G-E2 R6 P11006 Resistor chip 100
¡
N102 P5759 IRF7304 R7 P11060 Resistor chip 560K
¡
N106 P90090 PQ05DZ11 R8 P11209 Resistor chip 43K
¡
N112 P90015 TPS5100IPWR R9 P11029 Resistor chip 2.2K
¡
N401 P90205 D2891 R11 P11156 Resistor chip 300K
¡
N402 P90007 BA5954FP R13 P11013 Resistor chip 10K
¡
N403 P4581 TC4W53FU R14 P11057 Resistor chip 51K
¡
SOCKET
SWITCH
POTENTIOMETERS
FUSE
IC
FILTER
CRYSTAL OSCILLATOR
DVD1731H-L HV PCB ASS'Y
RESISTOR

REF No. PART No. PART NAME REF No. PART No. PART NAME
R15 P11013 Resistor chip 10K
¡
C1 P31091 EEVMC1C470P
C2 P20035 Capacitor chip 1uF C2 P31100 Ceramic CAP 10uF/16V
C3 P20012 Capacitor chip 0.01uF C3 P31100 Ceramic CAP 10uF/16V
C4 P20015 Capacitor chip 0.1uF C4 P31100 Ceramic CAP 10uF/16V
C5 P20035 Capacitor chip 1uF C5 P31100 Ceramic CAP 10uF/16V
C6 P20014 Capacitor chip 47000pF C6 P31100 Ceramic CAP 10uF/16V
C7 P20006 Capacitor chip 100pF C7 P31100 Ceramic CAP 10uF/16V
C8 P20010 Capacitor chip 1500pF C8 P31100 Ceramic CAP 10uF/16V
C9 P20012 Capacitor chip 0.01uF C9 P31100 Ceramic CAP 10uF/16V
C11 P20043 Capacitor chip 3300pF C10 P31100 Ceramic CAP 10uF/16V
C14 P20031a GHM1038SL120J3K C11 P31100 Ceramic CAP 10uF/16V
C15 P20013 Capacitor chip 22000pF C12 P31091 EEVMC1C470P
C16 P20021 Capacitor chip 4.7uF CB1 P20015 Capacitor chip 0.1uF
C17 P20023 Capacitor chip 10uF CB2 P20015 Capacitor chip 0.1uF
C18 P20014 Capacitor chip 47000pF CB3 P20015 Capacitor chip 0.1uF
C20 P20028 Capacitor chip 220pF CB4 P20015 Capacitor chip 0.1uF
D1 P1557 DAN217T146 XS1 P6849 MOLEX-52437-3091
D2 P1557 DAN217T146 XS3 P60083 SM20B-SURS-TF SOCKET
Q1 P5750 MMST3904T146 XS4 P6981 MOLEX-53261-0490
Q2 P5706 DTC144EUAT106 XS6 P60083 SM20B-SURS-TF SOCKET
Q3 P5749 RK7002T116
Z1 P1558 UDZSTE-175.6B
Z2 P1558 UDZSTE-175.6B
Z3 P1558 UDZSTE-175.6B
U1 P90100 OZ960S
U2 P90102 SI5504DC
U3 P90102 SI5504DC
F1 a7276 K12 FUSE
CN1 P6981 MOLEX-53261-0490
XS1 P7045 BHS-2P
R1 P11052 Resistor chip 3K
¡
R2 P11014 Resistor chip 12K
¡
R3 P11000 Resistor chip 0
¡
R5 P11000 Resistor chip 0
¡
TRANSISTOR
CAPACITOR
RESISTOR
CAPACITOR
SOCKET
IC
OTHER
DVD1731T-AS IF PCB ASS'Y
