Shineway Tech OTS-20A User manual

OTS-20 Series Optical Talk Sets
User’s Manual
Shineway Technologies, Inc.
All rights reserved.

OTS-20
Optical Talk Sets

User’s Manual for OTS-20
Shineway Technologies, Inc. - i -
Safety Instructions
Safety Terms Used in This Manual
“WARNING” identifies any procedure or practice that if not followed could
result in serious injury.
“CAUTION” identifies any procedure or practice that if not followed could
result in damage to the instrument or serious injury.
“NOTE” identifies information that may be beneficial during the use and
maintenance of the instrument.
WARNINGS
Optical talk sets is a laser instrument. Users should avoid looking directly into the optic output.
And the use of microscope or magnifier should also be avoided, for the use of such devices can
focus a highly intense beam onto the retina which may result in permanent eye damage.
CAUTIONS
Battery: Battery for this instrument is rechargeable NiMH battery. If unused for a long time,
battery should be recharged before being used. If the instrument is left idle for more than two
months, it should be recharged to maintain adequate power volume.
Battery Power: Do not recharge batteries for more than 8 hours. Do not take batteries out without
technical staff’s help. Do not expose batteries to fire or intense heat. Do not open or mutilate

User’s Manual for OTS-20
Shineway Technologies, Inc. - ii -
batteries. Avoid touching the electrolyte in the batteries, which is corrosive and may cause injuries
to eyes, skin or damage to clothes.
External Power: All hand-held instruments from our company support external power. Power
requirements: DC 13.8V/1.2A.
Laser Radiation: To avoid serious eye injury, never look directly into the optic outputs of fiber
optic network equipment, test equipment, patch cords, or test jumpers.
Always avoid looking directly into the optic output port, when the instrument is
working.
Always replace protective dust caps on the detector port when the instrument is not
being used.
Always avoid looking directly at the unconnected end of optic fiber in testing and
make the unconnected end pointing at a non-reflective object, if possible.
Protective Sleeve: When the instrument is not in use, don’t remove the protective sleeve so as to
avoid possible damage in case of a fall or collision.

User’s Manual for OTS-20
Shineway Technologies, Inc. - iii -
Table of Contents
SAFETY INSTRUCTIONS................................................................................................................ I
1. GENERAL INFORMATION.........................................................................................................1
1.1 SCOPE OF THIS MANUAL............................................................................................................1
1.2 UNPACKING AND INSPECTION....................................................................................................1
1.3 INTRODUCTION..........................................................................................................................2
2. TECHNICAL SPECIFICATIONS................................................................................................3
3. BASIC OPERATION......................................................................................................................4
3.1 FOREWORD................................................................................................................................4
3.2 INSTRUMENT INTERFACES INSTRUCTIONS.................................................................................4
3.3 MAINTENANCE OF BATTERIES...................................................................................................5
3.4 CLEANING OF INTERFACES ........................................................................................................5
4. SPECIFIC FUNCTIONS AND OPERATIONS...........................................................................6
4.1 FUNCTIONS..................................................................................................................................6
4.2 KEYPAD FUNCTIONS..................................................................................................................7
4.3 INDICATOR LIGHT FUNCTIONS...................................................................................................7
4.4TYPICALAPPLICATION...............................................................................................................8
4.4.1 Full Duplex Communication ............................................. 8
4.4.2 Multiparty Communication .............................................. 9
4.4.3 Optical Fiber Identification .......................................... 9
4.4.4 Set Reference Power Value ............................................ 10
4.4.5 Optical Fiber Attenuation Measurement ................................ 11
4.4.6 Together with Optical Clip-on Coupler to Perform Online Communication 12
5. MAINTENANCE AND CALIBRATION ...................................................................................13
5.1 MAINTENANCE OF BATTERIES.................................................................................................13
5.2 CLEANING OF INTERFACES ......................................................................................................13
5.3 CALIBRATION REQUIREMENTS ................................................................................................13
6. WARRANTY INFORMATION...................................................................................................14
6.1TERMS OF WARRANTY.............................................................................................................14
6.2 EXCLUSIONS............................................................................................................................14
6.3 WARRANTY REGISTRATION .....................................................................................................14
6.4 RETURNING EQUIPMENT .........................................................................................................14
6.5 CONTACTING CUSTOMER SERVICE ..........................................................................................15

User’s Manual for OTS-20
Shineway Technologies, Inc. - 1 -
1. General Information
1.1 Scope of this Manual
Thank you for purchasing a ShinewayTechinstruments. Please read this manual carefully before
using any of ShinewayTechseries fiber-optic instruments. Always observe the warnings and
cautions appearing throughout this manual.
This manual contains the information necessary for proper operation and maintenance of
ShinewayTechseries optical talk sets, troubleshooting instructions as well as information
regarding obtaining services.
All ShinewayTechseries optical talk sets are carefully assembled and undergo a rigorous
mechanical, electrical, and optical inspection prior to shipment. Beside the instrument, the package
should also include a data transfer cable, two power adapters and this users’ manual etc.. For
detailed information, refer to the packing list
Upon receiving the instrument, please check for any obvious signs of physical damage that may
have occurred during shipment. Report any damage to the shipping agent or the representative of
Shineway Technologies Inc. immediately. Retain the original packing materials in case reshipment
becomes necessary.
1.2Unpacking and Inspection
This instrument has been carefully packed in accordance with standard shipping procedures. Examine
the instrument for damage that may have occurred during shipment. If you find any damage or the
instrument is not working, or if any of the following items are not included, please contact your
representative of Shineway Technologies, Inc.
If necessary, you may contact the Representative of Shineway Technologies for Mainland directly or
contact Shineway Technologies, Inc via this email: [e-mail].
To return the instrument in the case of repair, calibration or other maintenance,
please note the following:
a) Be sure to pack the instrument with soft cushion like Polyethylene, so as to protect
the shell of the instrument.

User’s Manual for OTS-20
Shineway Technologies, Inc. - 2 -
b) Please use the original hard packing box. If use other packing material, please
ensure at least 3 cm soft material around the instrument.
c) Be sure to correctly fill out and return the warranty registration card which should
include the following information: company name, postal address, contact, phone
number, email address and problem description.
d) Be sure to seal the packing box with exclusive tape.
e) Be sure to ship to your representative or the agent of the Company in a reliable way.
1.3 Introduction
The ShinewayTechOTS-20 Series is an advanced tool for optical fiber networks field operations,
which features by quality voice transmission, laser inspection and handling technology, digital voice
coding and decoding, full duplex and hands-free operation, field portable, intelligentized,
multi-functional and dual-way powering system. The OTS-20 Series are designed according to
human engineering, and its LED display enables easy application of human-machine interface.
Besides the basic function of voice communication, they also provide stabilized laser source, and are
an inexpensive solution to meet your communication needs. The OTS-20 Series can be wildly used in
optical fiber networks of digital data, telecommunication and cable TV for engineering construction,
checking & testing, maintenance as well as optical fiber attenuation measurement. The OTS-20
Series are designed to fully embody the user’s needs in mind, with easy-of-use multi-function
backpack, taking into consideration the convenience of fieldwork, and thus become one of the
indispensable tools for the construction of optical fiber network, routine inspection and maintenance.
Features
Single fiber, full duplex
Digital voice coding and decoding process
Multi-function, providing stabilized laser source
Multiparty communication
Together with Optical Clip-On Coupler, realizing online communication
Field portable, hands-free operation
Compact size, lightweight, and damp, dust, shock proof in order to handle tough
conditions in the field
Dual-way powering system, auto recharging
Auto off function conserving battery life

User’s Manual for OTS-20
Shineway Technologies, Inc. - 3 -
2. Technical Specifications
Model
OTS-20A
OTS-20B
Wavelength(±20nm)
1310
1550
SpectralWidth(nm)
≤ 5 nm
Optical Talk Sets Module
DynamicRange(SM)
≥40dB
Maxi.TransmissionRange
110Km
160 Km
130Km
180Km
Laser SourceModule
OutputPower
≥-5dBm
≥-1dBm
Stability
±0.05dB/15min; ±0.15dB/8hrs
Modulation Frequencies
2KHz
Power
NiMHchargeablebattery;AC adapter
BatteryLife
16hrsstandbyor>10hrs uninterruptedoperation(Onecharge)
Other Specifications
OperatingTemperature
0℃to50℃
StorageTemperature
-20℃to70℃
RelativeHumidity
0to95%(non-condensing)
Weight
1.3 lbs (0.6kg)
Dimensions (H×W×T)
7.7×3.9×1.7inch(196×100×44mm)

User’s Manual for OTS-20
Shineway Technologies, Inc. - 4 -
3. Basic Operation
3.1 Foreword
This part introduces the basic operations of the ShinewayTechseries hand-held optical testing instruments.
Specific operations of each type are elaborated in “Specific Functions and Operations”, chapter 4 of this manual.
Please readthis manualcarefullyfor optimaloperation.Should youencounteranyproblems duringoperation, you
arewelcometocontactthetechnicalstaffofourcompanyoragents.
3.2 Instrument InterfacesInstructions
Interfaces of Optical Talk Sets and Laser Source
Earphone Plug Multiparty communication
Power adapter jack
Caution Signal
13.8V/1.2A
Multi
Party
Figure3.1InterfacesofOpticalTalkSets
FiberOpticOutput
AnFC/PCconnector is used forthis interface.
PowerAdapterJack
PowerAdapterJackrequirements: 13.8VDC@1.2A.
EarphonePlug
3.5mmstandardearphonepluginterface, used to connectearphones
Multipartycommunicationinterface
3.5mm standard interface. Connect two sets with audio-frequency line to perform multiparty
communication.
Avoidlookingdirectlyat theopticoutputwhentheinstrumentispoweron.

User’s Manual for OTS-20
Shineway Technologies, Inc. - 5 -
3.3 MaintenanceofBatteries
BatteryforShinewayTechseries opticaltalk setsisrechargeableNiMH battery. All
the NiMH batteries have been correctly installed and gone thorough precise
debugging.Pleasedonotopentheinstrument to replacebatteriesatdiscretion.
CautionsduringOperation:
Thefollowing maybringautopoweroffof theinstrument:
—— The instrument will be auto power offwhen there is insufficientpower during operation and low
powerindicatorlightturnsred.
—— Ifunused fora longtimeandcauseinsufficientpower,the instrumentwillbeimmediatelyshut off
severalsecondsafterpoweringonsoastoprotectthebatteriesincaseofexcessivedischarging.
Inbothcases, the insidebatteriesshouldberechargedimmediatelythroughadapter.
CautionsinRecharge:
—— Quick charge is needed first and then switch to trickle chargeafter the voltage reaches a predefined
figure. Quick charge temperature is +10~+40℃, and trickle charge temperature is 0~+45℃,
suitableforindoors.Batterywillnotbefullorbedamagedifthechargingtemperatureisbeyondthe
aboverange,whichmayshortenbatterlife.
—— 4hoursforquickcharge
—— Donotchargeforover8hours.
3.4 Cleaning ofInterfaces
Inordertokeeptheaccuracyoftheinstrument,propercleaningshouldbeperformed
beforeconductinganytestprocedures.Alint-freeclothandreagent-gradeisopropyl
alcoholmaybeused tocleantheinterfaces.
Iftheinterfacesareunclean, itmaycauseperformance degradationas follows:
Failure in communication;
Degradationintransmittedvoicequality;
Adecrease indynamicrange.

User’s Manual for OTS-20
Shineway Technologies, Inc. - 6 -
4. SpecificFunctions and Operations
4.1 Functions
Besides the basic function of voice communication, OTS-20 series optical talk sets also provide pager function,
stabilized laser source and identification of optical fiber by transmitting 2 KHz modulation frequency. Detailed
introductionsareasfollows:
VoiceCommunication: For easy use of operators and fast establishment of voice communication, when a pair of
opticaltalksetsareconnected withthechosen opticalfiber，the setswillbe promptforuse aftera shortreminding
tone when power on.The setswill nowsend signalstoeachother. When Ring/Talkindicator light turns red, both
sets should receive response signals. When Ring/Talk indicator light turns red and rings at the same time, press
[Answer] key to stop the ring and start voice communication. During the process, press [] key or the
earphone knobto adjustthe volume. Duringthecourse ofvoicecommunication, sometimesblackoutoftheoptical
route may happen (for example, the tested optical fiber was bent to vertical). In this case, if the optical route
resumes in ten seconds, the communication will just carry on. If the optical route does not resume within ten
seconds,theopticaltalksetswillrenewconnection..
Pager: Under the state of communication, ifone party takes his earphone off for reasons like doing other workor
taking arest, theother party canpower offhis setsand poweronin ten seconds,which canin turn triggerthe other
party’s set ringing.
Identificationoflasersourceandopticalfiber:Press[CW]or[2KHz]atanytime，voicecommunicationwillbe
paused and the laser source function will be activated, the set will sendout continuous wave or 2KHz modulation
frequency..UnderthestateoflasersourceCW, ContinueWave/2KHzindicatorlightisred，whileunder thestate
of 2KHz, ContinueWave/2KHzindicatorlightisgreen.Press[CW]or[2KHz]oncemoretoexitthefunctionof
lasersourceand backtostandbystateforcommunication.
Duringconstructionofopticalfiber,togetherwithOpticalClip-OnCoupler,Opticaltalksetscanbe usedfortesting
communicationwith bare opticalfiber. Thiswill avoidthe troubleof welding the tie-ins. For details, pleaserefer to
TypicalApplication.

User’s Manual for OTS-20
Shineway Technologies, Inc. - 7 -
4.2 KeypadFunctions
[On/Off] Poweronorofftheinstrument,thereisshortremindingtoneafterpoweron.
[2KHz] Press it once, the instrument will be switched to laser source state, and the output is 2KHz modulation
frequencywith indicatorlightgreen; Pressit again to turn off 2KHz modulation frequencies andback
tostandbystate forcommunication..
[CW] Press it, the instrument will be switched to laser source state，and the output of the laser source is
continuous wave with the indicator light red. Press it again to back to standby state for
communication.
[Answer] Press to answer other party’s call and stop the reminding ring.
[ ] Adjustvolume.Turnonupwardsandturndownlowwards
4.3 IndicatorLightFunctions
Ring/Talk:
Red: Voicecommunicationnotestablished.
Green: Voicecommunicationestablished.
LowBattery:
Green:LowBattery.
Charge/ChargeFull:
Red: Power supply through power adapter. The
insidebatteriesarebeingrecharged.
Green: Rechargingfinished。
ContinueWave/2KHz:
Red: Outputoflasersourceiscontinuouswave
Green: Output of laser source is modulation
frequency.
On/Off 2KHz
Talk CW
OTS-20Optical Talk Set
ShineW ay Tech®
VOL
VOL
Ring/Talk
Low Battery
Continue Wave/2KHz
Charge/Charge Full
4.1
Sketch map of
Optical talk sets

User’s Manual for OTS-20
Shineway Technologies, Inc. - 8 -
4.4 Typical Application
4.4.1 Full Duplex Communication
Figure 4.2 Sketch Map of Full Duplex Communication
Local End:
Choose the optical fiber for communication and clean its ends, interfaces and tie-ins
Connect optical talk sets properly with the chosen optical fiber
Plug into the earphones.
Power on Optical talk sets
Distance End:
Clean ends, interfaces and tie-ins of the optical fiber.
Plug into the earphones.
Search for the optical fiber for communication.
When receive the ringing signal, press Answer to answer the call.
With the above operation finished, voice communication can be performed with the help of mikes
and earphones. Volume can be adjusted by pressing [ ] key.

User’s Manual for OTS-20
Shineway Technologies, Inc. - 9 -
4.4.2 Multiparty Communication
For each optical fiber, a pair of optical talk sets need to be connected. Conference call can be
realized by connecting two optical talk sets of the intermediate station, as shown in the figure below.
Anyone at a connecting end can talk and hear others’talking simultaneously.
Figure4.3 Sketch Map of Triple-party communication
4.4.3 Optical Fiber Identification
Figure 4.4 Sketch map of optical fiber identification

User’s Manual for OTS-20
Shineway Technologies, Inc. - 10 -
Connect optical jumper to optical talk sets
Connect optical jumper to optical fiber to be tested.
Power on the talk sets, and press key 2KHz
Use our company’s optical fiber recognizer to search for the tested optical fiber at
distance end. The optical fiber recognizer will give off a reminding tone when the optical
fiber is found.
4.4.4 Set Reference Power Value
On/Off 2KHz
Talk CW
OTS-20Optical Talk Set
ShineW a yTe c h ?
VOL
VOL
Ring/Talk
Low Battery
Continue Wave/2KHz
Charge/Charge Ful l
Emitting optical jumper Receiving optical jumper
Tie-in
Optical Power Meter
ShineW ayTech?
dB
dBm Ref
Store Recall
On/
Off
RS232
λ
1310 nm
-1.46 dBm
Do no alter this tie-in
Figure4.5 Set Reference Power Value
The above figure shows how to use optical talk sets to measure optical fiber attenuation:
Power on optical dynamometer and choose the corresponding wave length.(wave length of the
laser that the optical talk sets send off ).
Power on optical talk sets, press [CW] and wait for laser stabilization (three minutes).
Clean all interfaces
Connect optical talk sets with optical dynamometer as shown in Figure 4.5
Choose dBm measurement for optical dynamometer
Press key Ref till “HELD” shows on the screen, then release the key, and save this value as
reference value;
Press [dBm/uW] to directly startAttenuation Measurement.

User’s Manual for OTS-20
Shineway Technologies, Inc. - 11 -
4.4.5 Optical FiberAttenuation Measurement
On/Off 2KHz
Talk CW
OTS-20Optical Talk Set
Shin eW a yTech?
VOL
VOL
Ring/Talk
Low Battery
Continue Wave/2KHz
Optical Power Meter
ShineW ayTech?
dB
dBm Ref
Store Recall
On/
Off
RS232
λ
1310 nm
-20.6 dBm
emitting optical jumper Receiving tie-in
Tie-in Tie-in
Tested Optical fiber
Do not alter this tie-in
Charge/Charge Full
4.6 Sketch Map of Optical Fiber Attenuation Measurement
Disconnect tie-ins between emitting optical jumper and receiving optical jumper.
Connect emitting optical jumper and receiving optical jumper with the front end and back end
of the optical fiber respectively.
The value shows on the optical dynamometer is optical fiber attenuation value.
In order to secure the accuracy of measurement, the tie-in connecting
emitting optical jumper and receiving optical jumper with the instrument
shall not be touched.

User’s Manual for OTS-20
Shineway Technologies, Inc. - 12 -
4.4.6 Together with Optical Clip-on Coupler to Perform Online
Communication
On/Off 2KHz
Talk CW
OTS-20Optical Talk Set
Shin eW a y Tech®
VOL
VOL
Ring/Talk
Low Battery
Continue Wave/2KHz
Charge/Charge Full
On/Off 2KHz
Talk CW
OTS-20Optical Talk Set
Shin eW a y Tech®
VOL
VOL
Ring/Talk
Low Battery
Continue Wave/2KHz
Charge/Charge Full
Figure4.7 Voice communication through bare optical fiber
Local End:
Clean tie-ins of optical clip-on coupler and connect with optical talk sets
Choose the optical fiber (bare fiber) and make connection as shown above. Pay attention
to the direction of putting in the bare optical fiber
Plug in the earphones and mikes.
Power on the optical talk sets
Distance End:
Clean ends and tie-ins of the optical fiber.
Plug in the earphones and mikes.
Search for the optical fiber for communication.
When it rings, pressAnswer to answer.

User’s Manual for OTS-20
Shineway Technologies, Inc. - 13 -
5. Maintenance and Calibration
5.1 Maintenance of Batteries
Notes for maintenance of batteries in the instrument:
1) One rechargeable NiMH battery is inside the instrument. Do not replace the battery by
yourself.
2) If the instrument is left unused for a long time (idle for over 2 months), it is
recommended to recharge the battery every other month.
3) Do not charge the battery for too long (more than 8 hours). Otherwise permanent damage
may happen to the battery.
5.2 Cleaning of Interfaces
Interfaces must be kept clean. Special alcohol may be used to clean optic output. Always replace
protective dust caps when the unit is not being used, and keep the protective dust caps clean.
5.3 Calibration Requirements
Calibration of the instrument is recommended every two years. Please contact ShinewayTech, Inc.
or our agent for proper calibration.

User’s Manual for OTS-20
Shineway Technologies, Inc. - 14 -
6. Warranty Information
6.1 Terms of Warranty
All ShinewayTechproducts are warranted against defective material and workmanship for a period
of one (1) year from the date of shipment to the original customer. Any product found to be defective
within the warranty period would be repaired or replaced by Shineway Technologies Inc. free of
charge. In no case will Shineway Technologies, Inc. liabilities exceed the original purchase price of
the product.
This warranty does not cover accessories or optional parts.
6.2 Exclusions
The warranty on your equipment shall not apply to defects resulting from the following:
1) Unauthorized repair or modification
2) Misuse, negligence, or accident
Shineway Technologies, Inc. reserves the right to make changes to any of its products at any time
without having to replace or change previously purchased units.
6.3 Warranty Registration
A warranty registration card is included with the original shipment of equipment. Please take a few
moments to fill out the card and mail or fax it to the local Customer Service Center of Shineway
Technologies, Inc. to ensure proper initiation of your warranty term and scope of your warranty.
6.4 Returning Equipment
To return equipment for reasons of yearly calibration or other, please contact the local Customer
Service Center of Shineway Technologies, Inc. to obtain additional information and a RMA# (Return
Materials Authorization number). And describe briefly reasons for the return of the equipment, to
allow us offer you more efficient service.

User’s Manual for OTS-20
Shineway Technologies, Inc. - 15 -
6.5 Contacting Customer Service
Please check our web site (www.shinewaytech.com) for updates to this manual and additional
application information. If you need technical or sales support, please contact local Shineway
Technologies Customer Service.
Shineway Technologies (China), Inc.:
Address: Fl.7, Zhongtai Plaza, No.3 Shuangqing Rd, Haidian District, Beijing, China
Postal code: 100085
Tel: [phone]
Fax: [phone]
Email: [e-mail]
WEB: www.shinewaytech.com
THANK YOU FOR CHOOSING SHINEWAY TECHNOLOGIES!
